AES CHEMUNEX FC0062 13.56 MHz RFID module to be integrated in AES equipment User Manual USERS MANUAL

AES CHEMUNEX 13.56 MHz RFID module to be integrated in AES equipment USERS MANUAL

USERS MANUAL

• InstalltheRFIDcardhorizontallyorvertically.
• Makesuretheconnectorsfacetowardstheinsideofthemachine.
• ThisRFIDcardislimitedtoOEMinstallationonly.
• ItcanonlybeusedindevicesdistributedbybioMérieuxunderthefollowingconditions:
-Theantenna(s)mustbeinstalledsuchthataminimumseparationdistanceof20cmismaintained
betweentheantennaanduser’s/nearbyperson’sbodyatalltimes
-thedevicemustnotbeco-locatedwithanyotherantennaortransmitter.
-Itcanonlybeusedinaclosedmachine.
• OEMintegratorsshallnotprovideinstallationand/orremovalinstructionstoend-users.
• End-user’soperatingmanualdeliveredwithfinishedproductsshallincludeonlythefollowing
information:
-Equipementcompliances(FCC,IC,ROHS)
-Technicalspecifications
-Disposalandrecyclingrequirements
• InnoeventshallAESChemunexbeliableforanyconsequential,incidentalorindirectdamageor
consequencerelatedto,arisingoutoforinconnectionwith,anyuseofthismanualand/oritsresults
bytheuserand/oranythirdparty.
• FinishedproductsintegratingthisRFIDcardshallbearthefollowinglabel:
ThisdevicecontainsRFmodule
FCCID:S3X-FC0062
IC:10929A-FC0062
RoutedeDol,35270CombourgFRANCE
Tel.:+33(0)223501212•Fax:+33(0)223501200
www.aeschemunex.com•contact@aeschemunex.com
Installing the RFID card
Thecommunicationand
powercablelengthmust
notexceed350mm.
Communicationandpowercableconnectors
Integration requirements
OEM_RFID_UM_EN_A
OEM
Integrator Manual
RFIDcard
[ref-FC0062]
ROHScompliance
TheRoHSdirective(RestrictionofuseofcertainHazardousSubstances)applicablefrom1rstJuly2006
restrictstheuseof6componentsthataredangerousforenvironment:
-Lead
-Mercury
-Hexavalentchromium
-Cadmium
-2flameretardants:
Polybrominatedbiphenyl(PBB)Polybromodiphénylséthers(PBBE)
WecertifythattheAPSOnecompliesto2002/95/ECeuropeandirective(directiveRoHS-LSDEE)that
limitstheuseofcertainhazardoussubstancesinelectronicequipment.
FCCandICstatements
FCCID:S3X-FC0062
IC:10929A-FC0062
ThisequipmenthasbeentestedandfoundtocomplywiththelimitsforaClassBdigitaldevice,
pursuanttoPart15oftheFCCRules.Theselimitsaredesignedtoprovidereasonableprotection
againstharmfulinterferenceinaresidentialinstallation.Thisequipmentgenerates,usesandcan
radiateradiofrequencyenergyand,ifnotinstalledandusedinaccordancewiththeinstructions,may
causeharmfulinterferencetoradiocommunications.However,thereisnoguaranteethatinterference
willnotoccurinaparticularinstallation.
Ifthisequipmentdoescauseharmfulinterferencetoradioortelevisionreception,whichcan
bedeterminedbyturningtheequipmentoffandon,theuserisencouragedtotrytocorrectthe
interferencebyoneormoreofthefollowingmeasures:
• Reorientorrelocatethereceivingantenna.
• Increasetheseparationbetweentheequipmentandreceiver.
• Connecttheequipmentintoanoutletonacircuitdifferentfromthattowhichthereceiveris
connected.
• Consultthedealeroranexperiencedradio/TVtechnicianforhelp.
Caution:
• Anychangesormodificationsnotexpresslyapprovedbythepartyresponsibleforcompliancecould
voidtheuser’sauthoritytooperatethisdevice.
Thisdevicecomplieswithpart15oftheFCCRules/IndustryCanadalicence-exemptRSSstandards.
Operationissubjecttothefollowingtwoconditions:
-(1)Thisdevicemaynotcauseharmfulinterference,and
-(2)Thisdevicemustacceptanyinterferencereceived,includinginterferencethatmaycause
undesiredoperation.
Equipment compliance
RoutedeDol,35270CombourgFRANCE
Tel.:+33(0)223501212•Fax:+33(0)223501200
www.aeschemunex.com•contact@aeschemunex.com
OEM_RFID_UM_EN_A
Thisequipmentismadeofmetal,plastic,electricandelectroniccomponents.
ThedirectiveimposesproperrecyclingofEEE(ElectricalandElectronic
Equipment).
Consequently,finalusersmustdisposeofendoflifeElectricalandElectronic
Equipmentindedicatedcollectingpoints.
Disposal and recycling
OEM_RFID_UM_EN_A
RoutedeDol,35270CombourgFRANCE
Tel.:+33(0)223501212•Fax:+33(0)223501200
www.aeschemunex.com•contact@aeschemunex.com
Environmental
conditions
Altitude upto2000m
Temperature from0to45°Cmax.
RelativeHumidity from10to80%
Operatingvoltage 8-30VDC
Pollutiondegree 2
Ratedpower 300mW
Equipmentdimensions(WxHxD) 140x70x1.54mm
Weight 15g
Communicationandpowercablelength 350mmmax.
Readingdistance 30to50mm
Communicationprotocol ISO15693,ISO14443A,SO14443B
Technical specifications
