ALL BEST TECHNOLOGY PALMBOX Portable power bank bluetooth speaker User Manual

ALL BEST TECHNOLOGY LIMITED Portable power bank bluetooth speaker

User Manual

User Manual
Palmbox
Handy Bluetooth
Speaker Power Bank
1. Features
- Simple design, easy operation
- Stereo speaker-provides superior quality sound
- Handy device, pocket design, enjoy music at any time and anywhere
- Mini size, powerful sound performance
- mobile phone companion
- Built-in 2600mAH lithium battery, up to 10 hour continuous play time
- Can be used as power bank to cover all your charging needs
- Easy to connect your smartphone, tablet, laptop and other
Bluetooth-enabled devices within 10 meters
- Support TF card to play music
2. Included in this package
Palm Box unit 1PC
Cloth Bag 1PC
Micro USB charging cable 1PC
User Manual 1PC
噘
3. Technology Specification
- Bluetooth technology index
- Standard: Bluetooth 2.1+ EDR
- Receive range: up to 10 meters
- Lithium Battery: 2600mAH

- Frequency Response: 70Hz--20KHz

- USB Output Charging Port: 5V 1A
- USB Input Charging Port: Micro USB
- Product Dimension: 98x78x27.5mm
噙
- Audio output Power: 2.5W
4. Diagram of the unit.
① USB Input Charging Port
② TF Card Slot
③ USB Output Charging Port
④ Bluetooth Mode play/pause music,
answer/hang-up calls.
⑤ TF Card Mode
⑥ Previous Song / Volume Down
⑦ Next Song / Volume Up
⑧ Battery Indicator Light
⑨ Power Switch ON/OFF
⑩ Bluetooth Indicator Light
TF Card Indicator Light
① ② ③ ⑨④ ⑤ ⑥ ⑦ ⑧
⑩
噚
5． Operation Instruction
5.1. Power On/Off
Long press button to turn On/Off the speaker. Bluetooth function is on as
well, and BT indication LED will keep flash.
5.2. Bluetooth Function

mode; If not, ignore this step.
 Turn on Bluetooth function in your mobile phone, searching
Bluetooth device.
 Choose “Palmbox” to pair (No need password)
 


connected again automatically.)
 

 to pause, and press again to play music.

噛

5.3. Playing music by TF card.

and play music.

 TF card mode, press to pause, press again to play music


5.4. Micro USB Charging for the speaker

，indicate the speaker is in charging mode.
LED light will stop flashing when speaker is fully charged.
5.5. External device charging
To charge a device, connect device to USB output slot via USB cable
(not supplied).
噜
FCC Statement
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-- Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause
undesired operation.
