ALPS ALPINE 9ZUA131 Bluetooth Module User Manual
Alpine Electronics Inc Bluetooth Module
User manual
Installation Manual
This module is to be installed only by the professional line operator and used only with a Bluetooth Module
for car audio produced by ALPINE ELECTRONICS, INC.. When this Bluetooth Module is installed in
the Car Audio, we shall consider the following points;
1. Since “PF240028” owns its FCC ID/IC Number, we shall affix an exterior label on the product if
the FCC ID is not visible. The exterior label shall use wording such as either ”Contains Transmitter
Module FCC ID: A269ZUA131 / IC: 700B-CMP2001” or “Contains FCC ID: A269ZUA131 / IC:
700B-CMP2001”.
2. “PF240028” complies with requirements of sub-sections 15.19(a)(3) in FCC Rules Part 15 Subpart
C. The manual statement 15.19 (a)(3) is included User Guide of the product.
3. “PF240028” is to be installed only by the professional line operator as shown in following pictures.
(Fig1, 2 and 3)
Fig 1. Bottom View of Bluetooth Module “PF240028”
Fig 2. Top View of MAIN PWB that installed Bluetooth Module “PF240028”
External Antenna Connector for Bluetooth
MAIN PWB
PF240028
Fig 3. Rear view of Car audio that installed “PF240028" (Example)
There isn’t an official user manual for this Bluetooth Module “PF240028”.
However, user manuals of final product, which have the module, must contain
notification corresponding to the following description.
Changes or modifications not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.
(This device complies with Part 15 of FCC Rules and RSS-Gen of IC Rules.)
Operation is subject to the following two conditions: (1) this device may not cause
interference, and (2) this device must accept any interference, including interference that may
cause undesired operation of this device.
This transmitter must not be co-located or operated in conjunction with any other antenna or
transmitter.
This equipment complies with FCC/IC radiation exposure limits set forth for uncontrolled
environment and meets the FCC radio frequency (RF) Exposure Guidelines in Supplement C to
OET65 and RSS-102 of the IC radio frequency (RF) Exposure rules. This equipment has very
low levels of RF energy that it deemed to comply without maximum permissive exposure
evaluation (MPE). But it is desirable that it should be installed and operated with at least
20cm and more between the radiator and person’s body (excluding extremities: hands, wrists,
feet and ankles).
External Antenna Connector for Bluetooth
MAIN PWB
