ALPS ALPINE WB1U859 TRANSMITTER ASSY KEYLESS (Hand Unit) User Manual
Alps Electric Co., Ltd. TRANSMITTER ASSY KEYLESS (Hand Unit) Users Manual
(Short Confidential)UsersManual(TWB1U859)
Immobilizer Function
Ke
y
less Function
LOCK Button
UNLOCK Button
Trunk Button
■CAUTION■
When the user pushes LOCK, UNLOCK, and the TRUNK button of
HAND UNIT, the RF electric wave is output, and IMMOBI UNIT receives
it, and an open lock, the close lock of the door, and the signal of the trunk
ope
nin
g
a
r
e
ou
t
pu
t.
Please DO NOT the following. Engine is not started by failure of
electronic parts. (Product can not receive the signal correctly)
Pay attention to the following.
・It may not be operated when using the equipment of the same
frequency band in the vicinity.
0.056kg
Operating temperature
range
-20~＋60 degree C Keyless
RF : 313.85MHz
LF: 125kHz
Weight
User's Manual
This unit is installed in vehicle. It performs communication with keyless unit
by LF, processes RF signal from keyless unit, and performs actions according
to the signal.
Unit Assy Immobi&Keyless communicates with the transponder in the
hand unit when the user inserts the hand unit in the key cylinder, and it
rotates
Product name : TRANSMITTER ASSY KEYLESS
Type : TWB1U859
Changes or modifications not expressly approved by the part
y
responsible for compliance could void the user’s authority to operate the
Batter
y
・Give a shock.
・Get it wet. If it got wet, wipe and dry up.
・Disassembly and modification.
FCC WARNING
This device complies with Part 15 of FCC Rules and Industry Canada
licence-exempt RSS standard(s). Operation is subject to the following two
conditions: (1) this device may not cause interference, and (2) this
device must accept any interference, including interference that may
cause undesired operation of this device.
-40~＋85 degree C Immobilizer
Operation of frequency
Operation Voltage typ. 3.0V / max 3.3V
Lithium battery CR2032
HUND UNIT UNIT ASSY IMMOBI&KEYLESS
