ALPS ALPINE WE1G0003 Straight Key FOB User Manual Short Term Confidential
Alps Electric Co., Ltd. Straight Key FOB Short Term Confidential
(Short-Term Confidential) User Manual
Since this device is always used with vehicle, it is not sold to general end users separately.
Therefore there is no user manual of this device by alone.
The following statements must be described on the user manual of the vehicle;
Immobilizer Function
Ke
y
less Function
UNLOCK Button
LOCK Button
Trunk Button
User's Manual
Transmitter is carried by the owner of the vehicle.
It performs transmission through RF antenna to tuner, vehicle performs
actions according to the signal.
Unit Assy Immobi&Keyless communicates with the transponder in the
hand unit when the user inserts the hand unit in the key cylinder, and it
rotates
Product name : Straight Key FOB
Type : TWE1G0003
Lithium battery CR2032
typ. 3.0V / max 3.3V
Battery
Weight
Operation of frequency RF : 433.92MHz
LF: 125kHz
When the user pushes UNLOCK, LOCK, and Trunk button of HAND
UNIT, the RF electric wave is output, and TUNER receives it, and an
open lock, the close lock of the door, and the signal of the trunk opening
are out
p
ut.
0.030kg
Operating temperature
range
-20~＋60 degree C Keyless
-40~+85 degree C Immobilizer
Operation Voltage
HUND UNIT UNIT ASSY IMMOBI
■CAUTION■
Procedure to check Model name, FCC ID and IC Number.
1. Remove the half cover with a flathead screwdriver.
2. Take out a PWB from the half cover.
3. FCC ID and IC Number are written on the button side of PWB.
Procedure to check CE Marking.
1. Remove the half cover with a flathead screwdriver.
2. CE Marking is written on the inside of half cover.
・Give a shock.
・Get it wet. If it got wet, wipe and dry up.
・Disassembly and modification.
This device complies with Part 15 of FCC Rules and RSS-Gen of IC
Rules. Operation is subject to the following two conditions: (1) this device
may not cause interference, and (2) this device must accept any
interference, including interference that may cause undesired operation
of this device.
FCC WARNING
Changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate the
equipment.
Replace only with the same or equivalent type
-CAUTION - Do not exposed to excessive heat such as sunshine, fire or the like.
-CAUTION - Danger of explosion if battery is incorrectly replaced.
Please DO NOT the following. Engine is not started by failure of
electronic parts. (Product can not receive the signal correctly)
Pay attention to the following.
・It may not be operated when using the equipment of the same
frequency band in the vicinity.
half cover PWB
Model name
FCC IDandIC
half cover CEMarking
