AOB ELECTRONICS ES-13039BT Bluetooth Speaker User Manual 13039
SHENZHEN AOB ELECTRONICS CO.,LTD Bluetooth Speaker 13039
User Manual
1
Portable Bluetooth Speaker with Mic
INSTRUCTION MANUAL
PLEASE READ ALL INSTRUCTIONS CAREFULLY
AND RETAIN FOR FUTURE USE
Getting started
• Remove the Bluetooth speaker & accessories from the box.
• Remove all packaging from the Bluetooth speaker.
• Place the packaging inside the box to either store or dispose of safely.
2
In the Box
• Bluetooth Speaker
• AUX Cable
• USB Charging Cable
• Instruction Manual
Features
• Enjoy music wirelessly
• Easy to switch between calls and music, you will not miss the incoming call whilst listening
to music
• Answer & end a call at click of a button.
• Redial last number
• Volume Control
• Every time the speaker is turned on, it connects to last connected device automatically
Safety Instructions
Keep the unit away from heat sources, direct sunlight, humidity, water and any other liquids.
Do not operate the unit if it has been exposed to water, moisture or any other liquids to prevent
against electric shock, explosion and/or injury to yourself and damage to the unit.
Do not use the unit if it has been dropped or damaged in any way.
Repairs to electrical equipment should only be performed by a qualified electrician. Improper
repairs may place the user at serious risk.
Do not use the unit with wet hands.
Do not put objects into any of the openings.
Keep the unit free from dust, lint etc.
Do not use this unit for anything other than its intended use.
Keep the unit out of reach of children.
This product is not a toy.
3
Description of Parts
1 ON/OFF Switch
2 Call Answer Button
3 Skip Backward / Decrease Volume
4 Play / Pause
5 Skip Forward / Increase Volume
6 Microphone
7 Mini USB Charging Port
8 LED Indicator
9 AUX Jack
4
INSTRUCTIONS FOR USE
Charging Instructions
The speaker comes with a built in rechargeable battery. Before using it for the first time we
recommend you charge the battery fully.
Connect the USB cable to a computer USB port and the Mini USB plug to the charging port of
the speaker. The Red LED illuminates while the speaker is being charged. It takes around 3
hours for the unit to fully charge. When the battery is fully charged the red LED will turn off.
When the battery is low, an indication tone (only at Bluetooth paired mode) will alert you. When
this occurs, please charge the speaker.
Turning on/off the speaker
There is an on/off switch at the bottom of the speaker. You can turn on/off the speaker with this
switch. In order to save power, put the switch to off position when the speaker is not in use.
Pairing the speaker with Bluetooth devices (phone or music device)
Switch on the speaker.
Place the speaker and Bluetooth device (phone or music device) so that they are no further
than 1 meter apart.
Activate the Bluetooth function on your Bluetooth device (phone or music device). Please refer
to the manufacturer’s instructions for instructions on enabling Bluetooth on your device.
Once you have activated Bluetooth on your device, select the speaker “SL BT Speaker” from
the list of available Bluetooth devices.
If required, enter the password ‘0000’ to confirm & finalize pairing.
Once paired successfully, the blue LED flashes two times every three seconds.
You can now start to use the speaker.
If pairing is unsuccessful, turn off the speaker first and then re-pair following the above steps.
Once you have paired the speaker with a device, the speaker will remember this device and
will pair automatically when the device’s Bluetooth is activated and in range. You do not need
to re-pair any previously connected devices.
The speaker will attempt to automatically connect to the last device it was paired with when
switched on. If you want to pair it with a new device please follow the steps outlined above.
Once the speaker is paired with your device the music will transmit directly to the speaker.
Please refer to your device’s user manual for further information.
5
Function Summary
Listening to Music
Once the speakers are paired with your device you can stream music wirelessly through the
speaker. Select the track you wish to listen to and it will be streamed to your Bluetooth speaker.
Should you encounter any problems while streaming please refer your device’s user manual
for further information.
Function Operation Button
Increase Volume Playing music Long press the Skip Forward / Volume Increase button
will increase the volume
Decrease Volume Playing music Long press the Skip Backward / Volume Decrease
button will decrease the volume
Pause Playing music
A short press on the Play / Pause button will pause the
music
Play Pausing
A short press on the Play / Pause button will resume the
music
Skip Forward While playing
music
Short press the Skip Forward / Volume Increase button
and it would skip one track forward
Skip Backward While playing
music
Short press the Skip Backward / Volume Decrease
button and it would skip one track backward
An indication tone will alert you when the volume is adjusted to the minimum or maximum
level.
Making a call with the speaker
Basic operation
Function Operation Button
Answer A Call Incoming Call Short press the Call Answer Button to answer
an incoming call
Reject a call Incoming Call Press and hold the Call Answer Button for 3
seconds
End a call Incoming Call After your phone conversation, short press the
Call Answer Button.
Increase Volume During a call Long press the Skip Forward / Volume Increase
button will increase the volume
Decrease Volume During a call Long press the Skip Backward / Volume
Decrease button will decrease the volume
Redial last number Standby mode and
connected to a device
Short press the Call Answer Button twice
6
Please Note
• Not all mobile phones support all the functions listed above. Please refer to your cell
phone’s user’s manual for further information.
• Certain functions and indication tones maybe vary depending on your mobile phone.
• When the volume is adjusted to min or max, you will hear an indication tone.
Play music using “Aux-In” Jack
1. Turn ON the device.
2. Insert the 3.5 mm Aux in cable (provided) to the Aux jack of the speaker. And, the
other end of the cable connects to the audio device (such as computer / tablet
/ …..etc.).
3. The Blue LED will light up without flashing.
4. Select your favourite song at the source device.
(Note: When you insert 3.5 mm Aux in cable into the Aux jack of the speaker, the Bluetooth of
the speaker will Turn Off at once.)
LED indicator
Please refer to the below tables for a list of the LED statuses whilst using the speaker.
Battery Charging Indication
LED indicator Status of the speakers
Red LED Charging
Red LED turns off Charging Completed
LED Indication
LED indicator Status of the speakers
Blue LED flashes quickly Pairing mode
Blue LED flashes two times
every three seconds
Paired successfully
Tone Indication
Indication tone Status of the speakers
Emits short tones Enter pairing mode
Emits an indication tone Low Battery Power (only at Bluetooth paired mode)
7
Specifications
Bluetooth specification Bluetooth V2.1+EDR
Operating distance 33 Feet, Class II
Speaker output 2W
Working time Music: Up to 2 hours
Talk: Up to 10 hours
Standby time Up to 100 hours
Charging input voltage DC 5V
Charging time About 3 hours
Dimensions 65 x 65 x 65mm
Weight 138g
Note: Battery life & charging time may vary based on usage & types of devices used.
Care and Maintenance
Read the following recommendations before using the speaker. Following these you will be
able to enjoy the product for many years.
• Do not expose the speaker to liquid, moisture or humidity to avoid the product’s internal
circuit being affected.
• Don’t use abrasive cleaning solvents to clean the speaker.
• Do not expose the speaker to extremely high or low temperature as this will shorten the life
of electronic devices, destroy the battery or distort certain plastic parts.
• Don’t dispose of the speaker in a fire as it will result in an explosion.
• Don’t expose the speaker to contact with sharp objects as this will cause scratches and
damage.
• Don’t let the speaker fall on the floor. The internal circuit might get damaged.
• Don’t attempt to disassemble the speaker as it may get damaged if you are not
professional.
In case the speaker doesn’t function properly, send it to the store you bought it. The staff will
help you to the problem.
FCC statements:
Changes or modifications not expressly approved by the party responsible for compliance
could void the user’s authority to operate the product.
NOTE: This product has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This product generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If the product does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures :
8
- Reorient or relocate the receiving antenna.
- Increase the separation between the product and receiver.
- Connect the product into an outlet on a circuit different from that to which the receiver is
connected.
- Consult the dealer or an experienced radio/TV technician for help.
The device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
9
Limited Warranty
This manufacturer's product warranty extends to the original consumer purchaser of the product.
Neither the retailer nor any other company involved in the sale or promotion of this product is a
co-warrantor of this manufacturer warranty.
WARRANTY DURATION: All materials and workmanship are warranted to the original consumer
purchaser for a period of ninety (90) days from the original purchase date.
WARRANTY COVERAGE: This product is warranted against defective materials or workmanship.
This warranty is void if the product has been damaged by accident, in shipment, unreasonable use,
misuse, neglect, improper service, commercial use, repairs by unauthorized personnel or other
causes not arising out of defects in materials or workmanship. This warranty doesn’t cover the
following which may be supplied with this product, including but not limited to; LCD Screens,
glass parts, lenses, bulbs etc. This warranty is effective only if the product is purchased and
operated in USA and Canada, and does not extend to any units which have been used in violation
of written instructions furnished by manufacturer or to units which have been altered or modified or, to
damaged products or parts thereof which have had the serial number removed, altered, defaced or
rendered illegible.
WARRANTY DISCLAIMERS: This warranty is in lieu of all warranties expressed or implied and no
representative or person is authorized to assume for manufacturer any other liability in connection with
the sale of our products. There shall be no claims for defects or failure under any theory of tort,
contractor commercial law including but not limited to, negligence, gross negligence, strict liability,
breach of warranty and breach of contract. Under no circumstances will Manufacturer’s / Distributor’s
maximum liability exceed the retail value of the product.
WARRANTY PERFORMANCE: During the above 90 day warranty period, a product with a defect will
be either repaired or replaced with a reconditioned comparable model (at manufacturer's option).
The repaired or replacement product will be in warranty for the balance of the 90 day warranty
period and an additional one-month period. No charge will be applicable for such repair or
replacement.
SERVICE AND REPAIR: If service is required for this product, you should first contact Midwest
Trading Group Customer Service at info@mtradinggroup.com or by calling 1 (866) 815-4714,
Monday to Friday 10am to 6pm EST.
NOTE: Manufacturer cannot assume responsibility for loss or damage during incoming shipment. As
a precautionary measure, carefully package the product for shipment, and insure it with the carrier.
Be sure to enclose the following details with the product: your full name, return address and daytime
phone number, a note describing the problem you experienced, a copy of your sales receipt or other
proof of purchase to determine warranty status. C.O.D. shipments cannot be accepted.
