AONI ELECTRONIC 922923924 Bluetooth Stereo Headphones User Manual Manual
ShenZhen Aoni Electronic Industry Co., Ltd. Bluetooth Stereo Headphones Manual
Manual
922BT Bluetooth Stereo Headphone User Manual
OPERATION INSTRUCTION
a) To turn on, press and hold the MFB button for approximately 2 seconds, the headphone will have a prompt tone
and the blue indicator light will flash several times; it should automatically connect to last connected device.
b) To turn off, press and hold the MFB button for approximately 4 seconds. When turning off, the headphone will
have a prompt tone and red LED light will flash one time,then turn off
c) Pairing with Bluetooth Devices, press and hold the MFB button for approximately 4 seconds, the headphone will
have a prompt tone and the LED light on the headphone will flash red and blue in an alternating manner.(Note:
The headphone will enter standby mode if not paired within 3 minutes)
d) Multi-pairing, Phone 1 connected with earphone successfully, Then turn on Bluetooth of phone 2 and
connect .Then it can connected with two phone at the same time .Earphone will default device which connected
first as priority device .
Using the 922BT headphones
e) Adjusting Volume
Function
Operation
Notes
Increase volume
Single press or press and hold the
Volume up V+ button
When the Volume reaches the
minimum or maximum level the AF16
will produce a short tone
Decrease volume
Single press or press and hold the
Volume Down V-button
f) Controlling Phone Calls
Status
Function
Operation
Incoming call
Answer a call
Single press the MFB button
Reject a call
Press and hold the MFB button for 2
seconds
Call in progress
End a call
Single press the MFB button
g) Controlling Media Playback
No media Playing
Play media
Press the Play/Pause button
Media playing
Pause media playback
Press the Play/Pause button
Either media playing or stopped
Skip to next track
Long press V+ button about 1s
Restart the track/previous track
Long press V- button about 1s
Note: if you answer or make a call while listening to media, the media will be paused until the call has ended.
h) Additional Functionality
Action/Status
Button Function
Sounds
Activate voice assistant
In standby mode, Press and hold the
MFB button for 2 seconds
Short tone
Cancel Voice assistant
single press the MFB button
/
Redial last number
Double click on the MFB button, the BT
headphone will make a redial to your
last called number
/
i) LED indicator
During Charging
Red LED light on
Full charge
Blue LED light on
Standby
Blue LED light will flash two times every 5 seconds
Call in progress
Blue LED light will flash two times every 5 seconds
Incoming call
Blue LED light will flash quickly
Unconnected to bluetooth device
Blue LED light will flash one time every 5 seconds
Low battery
Red LED light will flash one time every 20 seconds
Pairing
Red and Blue LED light will flash in an alternating manner
Specification
Bluetooth Version
V3.0
Support agreement
HSP. HFP. A2DP. AVRCP
Transport distance
15 meters
Pairing Name
922BT
Password
0000
Speaker frequency response
20Hz~20KHz
Media Playing Time
About 5hrs
Call Time
About 7hrs
Standby Time
About 120hrs
Working temperature
0-40℃
Storage temperature
-20~60℃
FCC STATEMENT
1. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received, including interference that may cause
undesired operation.
2. Changes or modifications not expressly approved by the party responsible for compliance could
void the user's authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation.
This equipment generates uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
Consult the dealer or an experienced radio/TV technician for help.
