User Manual

LINXDISPLAYQUICKSTARTGUIDE
7450102 GETTINGSTARTED
Turningthedeviceon
PressandholdthePowerButtonkey(8)forafewseconds
untilthescreenlightsup.
Bootingup
Uponstartup,ARBLINXwillbeloadedautomatically.
Optionkeys
Theonscreenoptionkeyshelpusersnavigatearoundthe
displaydevice.TogobacktoARBLINX,simplypressthe
center widgetinthehomescreen.
Settings
Togotosettings,swipefromthetopdown.Deviceispreset
foroptimumapplicationwiththeLINXsystem.Usersare
advisedtomaintainallsettingsatdefault.
Chargingthedevice
Thechargingportisatthesideofthedisplaydevice.UseARB
USBcableprovidedformostefficientcharging.
Visitwww.arb.com.au formoreinformation.
1LightSensor
2 AudioJack
3USBPort
4 Camera
5DisplayScreen
6VolumeUpKey
7VolumeDownKey
8PowerButton
9Speaker
10 Microphone
SettingMenu
Step1 Select‘AboutPhone’
Step2 Select‘Regulatoryinformation’
FCCIDisalsoappliedinthebatterycompartment.
2AA2HLINXD1
7450102
P/N
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) this device may not cause
harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
NOTE:
FCCID
LOCATINGFCCELABELONTHEDEVICE
RegulatoryInformation
Toviewregulatorymarksandrelatedinformationonthedevice,goto:
Settings >Aboutphone>Regulatoryinformation
FCC RF Exposure Information and Statement
The SAR limit of USA (FCC) is 1.6 W/kg averaged over one gram of tissue. Device types LINX DISPLAY /
(FCC ID: 2AA2H-LINXD1) has also been tested against this SAR limit. SAR information on this and other pad
can be viewed online at http://www.fcc.gov/oet/ea/fccid/. Please use the device FCC ID number for search. This
device was tested for typical body-worn operations with the back of the handset kept 10mm from the body. To
maintain compliance with FCC RF exposure requirements, use accessories that maintain a 10mm separation
distance between the user's body and the back of the handset. The use of belt clips, holsters and similar
accessories should not contain metallic components in its assembly. The use of accessories that do not satisfy
these requirements may not comply with FCC RF exposure requirements, and should be avoided.
FCC Warning
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
NOTE 1: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
NOTE 2: Any changes or modifications to this unit not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
