ARCTIC >
User manual
Welcome Guide
P324 BT
Packaging Contents
Headphones x 1, Micro USB Charging Cable x 1,
Carrying case x 1, Welcome Guide x 1
www.arctic.ac
Dear Customer,
Thank you for choosing the ARCTIC P324 BT.
YOU are the centre of ARCTIC. We work hard to approach all
angles from a user's perspective and are fully dedicated to
create innovative, user-friendly and affordable devices. YOUR
satisfaction is our ultimate goal.
In order to assist you even better, we launched a support
platform for Smartphones (support.arctic.ac).
I hope you enjoy the P324 BT and we at ARCTIC look
forward to further enriching your life with our products. If you
would like to share how you use ARCTIC's products please
do so at https://www.facebook.com/ARCTIC.en
ARCTIC is a fully carbon neutral company and your support
helps us to compensate every kilogram of CO we produce.
2
Thank You.
Sincerely,
Magnus Huber
ARCTIC CEO
Switch the Headset On or Off
Switch on
Press the
multifunction button
for 3 seconds until the
blue LED lights up
Switch off
Press the
multifunction button
for 3 seconds until the
red LED lights up
support.arctic.ac/p324bt
EN
DE
FR
ES ...
Like us on facebook
www.facebook.com/ARCTIC.en
© 2014 ARCTIC Switzerland AG. All Rights Reserved.
No part of this manual including the products described in it, may be reproduced, transmitted,
stored in a retrieval system, or translated into any language in any form or by any means,
except documentation kept by the purchaser for backup purpose, without the express written
permission of ARCTIC Switzerland AG. In no event shall ARCTIC its directors or employees be
liable for any indirect damages, incidental or consequential damages arising from any defect or
error in this manual or product.
FCC ID Z3AP324BT
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:(1) this device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
© 2013 CSR plc and its group companies.
The Bluetooth word mark and logos are registered trademarks owned by Bluetooth SIG,
Inc., and any use of such marks by ARCTIC (HK) Ltd. is under license. Other trademarks and
trade names are those of their respective owners.
Music Stutters
Buttons Buttons
Function Diagram
Multifunction button
LED indicator
Volume +
Volume -
Micro USB charging port
Forward
Backward
Microphone
Do not wash the ear pads
with washing machine.
The magnetic ear pads are removable from the
headphone. It is possible to clean them with
water and towel.
Removable and washable ear pads
Cautions
Ÿ Wireless connections are affected by obstructions such as
walls, human body and other devices.
Ÿ Keep P324 BT dry, moisture may damage electronic
components.
Ÿ Exposure to high temperature will shorten the life and damage
electronic components.
Ÿ Opening / altering the P324 BT voids all product warranty.
Ÿ Rough handling may damage inside electronic components.
Microphone Sensitivity
Wearing Style
Bluetooth Version
Frequency Response
Driver Size
-42±5dB
Supra-aural, neck band
V4.0 +EDR Class 2
18Hz - 22kHz, THD 0.1%
30mm
Specifications
Charging Port Micro-USB
Spare Ear Pads are available at
p324bt.arctic.ac#spareparts
Battery Rechargeable 400mAh
Lithium-ion Polymer
Playback Time 20 Hours
Standby Time Up to 400 hours
Weight 78g
PKMNL00001A
Changes or modifications not expressly approved by the party responsible for
compliance could void your authority to operate the equipment.
Pair with Your Smartphone / Tablet
Press Settings > Bluetooth and switch Bluetooth on > ARCTIC P324 BT > Pair
Example: iOS
Example: Android 4.0
Press Menu > Settings > Switch on Bluetooth > Bluetooth > Search for devices > ARCTIC P324 BT > Pair
Click Settings
Select Bluetooth
Switch On
Bluetooth
Bluetooth
is On
Select
ARCTIC P324 BT
ARCTIC P3 24 BT
Now Connected
ARCTIC P3 24 BT
ON
Click Search
for Devices
ON
Bluetooth
is On
OFF
Switch On
Bluetooth
Click
Settings
ON
Select
ARCTIC P324 BT
ARCTI C P324 BT
ON
Now
Connected
ARCTI C P324 BT
1.Switch on the P324 BT by press the multifunction button for 3 seconds.
2 The P324 BT automatically enters pairing mode shown by the red and blue LED flash alternately.
If the headphone is not in pairing mode, please turn off the Bluetooth on the latest paired device.
Notes:
- Pairing mode will last up to ten minutes or until a device is found, two tones will sound to let you know when pairing has stopped.
- If you exceed the effective range of approx. 10M (33ft) the headphone will disconnect and will automatically reconnect if the speaker
re-enters the effective range within ten minutes.
How to Wear the Headset
Phone Operations
If the mobile device that is paired (via Bluetooth) with the
P324 BT headphone is a cellular phone you can:
LED Indicators
Status
Charging
Battery full
On and Paired
Paring mode
Low battery
Indication
Red LED on
Blue LED on
Blue LED flashes
Red and blue LED will flash alternately
Red LED flashes
Reconnection
1. Turn on Bluetooth on phone.
2. Switch on the P324 BT by press the multifunction button for
3 seconds.
3. If your device was the latest one to be paired with the
P324 BT it will connect automatically otherwise please
repeat pairing section.
Charging
The P324 BT can be charged while switched on or off.
1. Insert the micro USB cable into the P324 BT and the USB
side into a power source.
2. When the Blue light on constantly the P324 BT is
fully charged.
It is recommended to fully charge before initial use for better
battery life.
Headset Controls
Volume -
Forward
Play, pause,
or stop music
3.Turn on Bluetooth on your phone and pair it with the headphone. Answer Call Press the once.
End Call Press the once.
Reject Call Press and hold forward for 2 seconds.
Switch Call Press and hold the for 2 seconds
while in a call.
Backward
Volume +
USB Chargers are available at
chargers.arctic.ac
