This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1) This device may not cause harmful interference. and
(2) This device must accept any interference received, including interference that may
cause undesired operation.
This symbol on the product or in the instructions means that your electrical and electronic equipment should
be disposed at the end its life separately from your household waste. There are sparate collection system
for recycling in the EU.
For more information, please contact the local authority or your retailer where you purchased the product.
Wireless
Optical Mouse
User's Guide
B006SR
The unit offers a strong power saving management. Once the mouse accesses the sleeping mode, " to click any
button of the mouse" is compulsory to wake it up.
Power on/off:
There is a Power on/off switch designed to save the batteries power while non-usage of a longer period.
User can push DPI button to change the resolution. The LED on wheel bar will be flashed when dpi has been
successfully switched.
Power on/off switch
Wheel button
Dpi button
ID reset button
Mouse
Battery cover
Receiver
Internet Forward & Backward button
Low power indicator
Receiver
Congratulations on your purchase of the most innovative mini wireless mouse. With an
incredible sensitivity to surface details and high tracking speed than other mice, the mouse can
track reliably even on tricky polished or wood-grain surfaces. It offers even more advance that
will make you more productive and more comfortable
a. Remove the battery compartment cover on the bottom case of the mouse.
b. Fit in the batteries accordingly to the diagram indicated in the battery cabinet.
c. Close the battery compartment cover properly.
d. Make sure the Power on-off switch on the bottom of the mouse is ON.
e. The Low Power LED on the wheel bar will be on for 6 seconds if the mouse power is on.
Introduction
A. Hardware Installation
2.4GHz (distance 6~8m), 34 Channels/224 ID
Using state-of-art technology. High tracking speed and sensitivity.
Hyper-Fast Scrolling
Nano receiver.
Longer battery life.
Auto-Link, Plug and Play! No need to set the channel ID.
Power on/off switch.
800/1600 dpi switchable button.
Ergonomic design.
2*AAA Alkaline batteries included.
Features +
-
A wrong battery placement
may cause batteries overheat.
Battery compartment cover
2 * AAA batteries
3. Communication : The mouse & the receiver
The 2.4Ghz RF mouse features a dual-way transmission technology which enables the
mouse and the receiver auto-communication.
A. Auto-link mode
1. Make sure the Power On-Off Switch on the bottom of the mouse is ON.
2. Operate the mouse, and cursor's movement is mapping mouse movement. Now the
mouse and the receiver is auto-linked successfully.
2. Connect the receiver
PC
USB port
1. Insert the batteries
Pull out
the receiver
a. Turn on your PC.
b. Connect the receiver to USB port on PC.
◎ Troubleshooting
a. Make sure you have connected the receiver correctly to the computer's USB port.
b. For the best performance, we suggest you to locate the receiver with a distance from other
electrical devices, such as the computer, the computer monitor or external storage drives.
c. Make sure you have set the communication between the receiver and the mouse. Refer to
the Communication:The mouse and the receiver.
B. Manual mode
If you find the communication channel does not connect well, you can use the software
connection tool to re-connect the mouse & receiver to reset a new channel ID. You are
able to download the software from your local brand vendor's website.
Press ID reset button
Execute ID connection software
12 3
ID links OK!
The red LED on the scroll wheel is the low battery power indicator. It indicates that battery inside the mouse is
needed to be replaced.
While the mouse is working, if encountering any interference, the mouse and the receiver will automatically source
out and transfer to another free channel. During the transferring, the cursor movement may have a second delay.
5. Switch scroll mode
Standard scroll mode:
When switched to the normal speed mode, the wheel can
scroll at normal speed and with a feeling of graduations.
Hyper speed scroll mode:
When switched to the hyper speed mode, the wheel can
scroll at hyper speed, enabling users to browse very fast.
4. Replace a new battery
Please replace a new battery and follow the previous instructions. (2, 3)
d. If you find the communication channel does not connect well. You can use the software
connection tool to re-connect the mouse & receiver to reset a new channel ID. You are able
to get the software from the included diskette of the package or download from your local
brand vendor's website.
e. Make sure that you are not working the mouse on glossy or reflective surfaces.
◎ Battery use reminders
1. Remove worn-out batteries from equipment immediately and dispose of promptly.
2. Keep all battery (used or new) out of the reach of children.
3. To have the battery with a regular check and replace a new battery if not used for a long time.
4. Never dispose of battery in fire, as it could explode.
5. Do not use the wrong type of battery (e.g. Ni MH, NiCd, and etc) in the mouse.
6. Remove battery from the electrical device if the device is not going to be used for a long time.
7. If the performance of the battery decreases substantially, it is time to replace the battery.
◎ FCC statementattery
This equipment has been tested and found to comply with the limits for a class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation.
This equipment generates uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio communica-
tions. However, there is no guarantee that interference will not occur in a particular installation if
this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
To assure continued compliance, any changes or modifications not expressly approved by the
party responsible for compliance could void the user's authority to operate this equipment.
(Example-use only shielded interface cables when connecting to computer or peripheral
devices).
◎ FCC Radiation Exposure Statement
This equipment complies with FCC RF radiation exposure limits sent forth for an uncontrolled
environment. This equipment should be installed and operated with a minimum distance of 20
centimeters between the radiator and your body.
