L279 Wireless Laser Mouse
L279
Wireless Laser Mouse &
Remote Hall Senser &
Wireless Presenter &
Laser Pointer
![](/img.php?id=1375143&img=bg2.png)
To use at the desktop:
(1) Please follow the instructions of the "ID Setting".
(2) Use the mouse likes a standard wireless laser desktop mouse.
(3) Using the Hall Sensor on the top of the mouse as a 3D (directions) scroller.
(4) The Backward / Forward Buttons on the top of the mouse are designed for
browsing internet at the desktop.
(5) To switch dpi, press left and right buttons simultaneously for 3 seconds, the red led
will blink and dpi switch complete.
1 2
Introduction
Consolidating 2.4GHz wireless, laser and remote presenter technology.
4-in-1 design for use as a wireless laser mouse at the desktop, a Hall Sensor in the air, a
laser pointer, and a remote presenter while making presentation toward audience.
Ergonomic design for comfort use at the desktop and in the air.
16 channels with 216 ID/per channel. No interference!
800/1600 dpi switchable.
Wide range and long transmission distance for max. 10m.
Auto-mode switch between mouse mode at desktop use and remote Hall Sensor in air use.
Laser pointer available for presentation.
Page up/down between presentation slides.
Power On/Off switch to save battery life.
Auto-Link Channel ID.
2* AAA Alkaline batteries included.
!
Hall Sensor /
Middle button
Desk Sensor
ID button
Laser point
Play/Esc
button
Black screen
button
Features:
RECEIVER
Congratulations on your purchase of the most innovative 2.4GHz multi-functional wireless
remote presenter mouse.
A. Power on your PC.
B. Connect the receiver to USB port on PC.
A. Auto-link mode:
The Presenter Mouse has auto-link function itself.
B. Manual mode:
If you find the communication channel does not connect well, you can use the software
connection tool to re-connect the mouse & receiver to reset a new channel ID. You are
able to get the software from the included diskette of the package or download from your
local brand vendor's website.
4. Using Remote Presenter Mouse at the Desktop
The mouse provides great flexibility in how you control your computer and its laser sensor
allows for precise tracking on any surface. (For optimal performance, avoid highly reflective
glass or mirrored surfaces).
For optimal battery life, avoid using the mouse on dark-colored surfaces.
Tip
The presenter may not perform properly while working on
the some "dark color surfaces".
A wrong battery placement may
cause batteries overheat.
For use of page up and down between presentation slides with Power Point.
Auto-switching button function between page up / down and backward / forward
, page up / down on desk top , backward / forward in the air.
*
2. Connect the Receiver
3. Establish Communication Between the Mouse and the Receiver
1. Insert the Batteries
Note
Execute ID connection software
12 3
ID links OK!
Press ID reset button
On/Off switch
Receiver
PRESENTER
The Presenter Mouse offers a strong power saving management function. Once the mouse accesses the
sleeping mode, “to click any button of the mouse” is compulsory to wake it up
+
-
+
-
Battery compartmrnt
2* AAA
Batteries
a. Remove the battery compartment cover on the
bottom case of the mouse
b. Fit in the batteries accordingly to the diagram
indicated in the battery cabinet.
c. Close the battery compartments cover properly.
d. Make sure the Power on-off swich on the
bottom of the mouse is ON.
e. The Low Power LED on the wheel bar will blink
3 seconds if the mouse power is on.
*
Air : Page up button
Desktop : Backward
button
Air : Page down button
Desktop : Forward
button
![](/img.php?id=1375143&img=bg3.png)
3 4
6. Power On/Off
There is a Power On/Off switch designed to save
the batteries power during non-use for a long
period of time.
(4) Press and hold the pointer button for pointing the subject, while making the
presentation.
(1) Hold the mouse in a comfortable, relaxed position with your index finger on the
bottom of the mouse and your thumb at the top of the mouse.
(2) You can control the cursor movement by Hall Sensor using your thumb.
(3) The Page up/ down Buttons on the top of the mouse are designed for use of page
up and down between slides with Power Point.
While using laser pointer, please avoid laser light to direct contact with
anyone's eyes. It may occur serious hurt to anyone's eyes !
Please avoid put your finger on the top of the desk sensor, and avoid using it
under the strong light, it may cause function fault.
Power On/Off
switch
(1) Remove worn-out batteries from equipment immediately and dispose of promptly.
(2) Keep all batteries (used or new) out of the reach of children.
(3) To have the batteries with a regular check and replace new batteries if not used for a long time.
(4) Never dispose of batteries in fire, as they could explode.
(5) Always replace all the batteries at the same time. Mixing old and new batteries or mining
types (such as alkaline with zinc carbon) will reduce overall performance and could cause
leakage or rupture.
(6) Do not mix different types of batteries (e.g. Ni-MH, NiCd, alkaline, and etc) in the mouse.
(7) Remove batteries from the electrical device if the device is not going to be used for a long time.
(8) If the performance of the batteries decreases substantially, it is time to replace the batteries.
Battery use reminders
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates uses and can radiate
radio frequency energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
FCC Statement
To use in the air :
7. Replace the new batteries
Please replace a pair of new batteries and follow the instruction 1.
The red LED on the Hall Sensor bar is the low batteries power indicator. It indicates
that batteries inside the mouse are needed to be replaced.
Note
(1) Make sure you have connected the receiver correctly to the computer's USB port.
(2) For the supreme performance, we suggest you to locate the receiver with a distance from
other electrical devices, such as the computer, the computer monitor or external storage
drives.
Trouble Shooting
(3) Make sure you have set the communication between the receiver and the mouse. Refer
to the instruction 3 in this manual.
(4) Some system devices might conflict with the mouse. Confirm the IRQ/address settings of
these devices for conflicts, and change the settings as required.
(5) Make sure that you are not working the mouse on glossy or reflective surfaces.
(6) Try unplug and re-connect the receiver to your computer.
5. Using Remote Presenter Mouse in the Air
The mouse has no line of sight requirements so it's not necessary to point the device at the
computer, receiver or monitor. Find a comfortable, relaxed position and move the cursor with
easy wrist movements.
Warming : Please do not touch hall sensor and switch to power on at the same
time,otherwise the cursor will lose control. If the situation happen , please
swith to power off then poewer on again.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference. and
(2) This device must accept any interference received, including interference that may cause
undesired operation.
To assure continued compliance, any changes or modifications not expressly approved by the
party responsible for compliance could void the user’s authority to operate this equipment.
(Example-use shielded interface cables when connecting to computer or peripheral devices.)
