ARESON Technology L185 WIRELESS MOUSE User Manual USERS MANUAL
ARESON Technology Corp. WIRELESS MOUSE USERS MANUAL
USERS MANUAL
User's Guide
Mini Wireless
Laser Mouse
Optical Mouse
Recevier
ID reset button
1. Insert the batteries
a. Remove the battery compartment cover on the top case of the mouse by pressing the
battery cover button on bottom of the mouse.
b. Fit in the batteries accordingly to the diagram indicated in the battery cabinet.
c. Close the battery compartments cover properly.
Wheel button/
Low power indicator
Dpi button
Battery cover Battery cover
button
ID reset button
Receiver
Receiver button
Mouse
Introduction
Congratulations on your purchase of the most innovative wireless mini mouse. With an
incredible sensitivity to surface details and high tracking speed than other mice, the mouse
can track reliably even on tricky polished or wood-grain surfaces. It offers even more
advance that will make you more productive and more comfortable.
A. Hardware Installation
2.4GHz (distance 6~8m)
Using state-of-art technology. High tracking speed and sensitivity.
16 Channels/4096 ID
4-way scrolling.
Storable mini receiver
Plug and Play! No need to set the channel ID.
Power on/off switch
Data report rate : 125 Report/Sec.
Alkaline batteries included.
800/1600 dpi switchable button.
Power on/off
switch
This product complies with IEC 60825-1, Class I laser product. (for Laser mouse
models only.)
Your product complies with FCC and CE rules.
Safety Notice
Please DO NOT direct the
laser beam at anyone's eyes.
(※ Only for laser model)
Features
+
-
A wrong battery placement
may cause batteries overheat. Battery compartment
Battery compartment cover
2 AAA batteries
Battery cover button
The unit offers a strong power saving management. Once the mouse accesses the sleeping mode, " to click any
button of the mouse" is compulsory to wake it up.
Power on/off:
There is a Power on/off switch designed to save the batteries power while non-usage of a longer period.
2. Connect the receiver
a. Turn off your PC.
b. Connect the receivere to USB port on PC
c. Turn on your PC
PC
USB port
3. Establish communication between the mouse and receiver
a. Please reset the ID when first time use if necessary. (step 1)
b. Press the ID reset button on the receiver, and note the red LED will blink slowly. (step 2)
c. Press the ID reset button on the bottom of the mouse to set a new ID. (step 3) The red
LED indicator will blink at a faster rate when an identical ID is located. (step 4)
d. Press any button of the mouse to confirm the ID matching. The red LED indicator on the
receiver will blink any time the mouse sends it a signal.
1
2
3
4
5
ID
links
OK!
B. Driver Installation
The mouse features plug & play. It is not necessary to install the driver to operate the mouse.
The driver is an optional item included. However if the model purchased is with 4-Way
Scrolling function, you may require the mouse software driver to make the 4-Way scrolling
function effective.
1. Un-install or removing the current mouse driver
Before installing the driver of the mouse, we suggest that you check if any other mouse
driver installed in your system. If yes, in order not to make conflict, please un-install or
remove that driver before installing the mouse.
2. Install the mouse 4-Way Scrolling driver
Press
ID
reset
button
Red
Led
indicator
blinks
slowly
Press
ID
reset
button
Red
Led
indicator
blinks
faster
a.Select setup.exe to install the driver from the CD.
b.or you can download the 4-Way Scrolling driver form vendor's website.
4. Replace the new batteries
Please replace a pair of new batteries and follow the previous instructions. (2, 3)
Note
The red LED on the scroll wheel is the low batteries power indicator. It indicates that
batteries inside the mouse are needed to be replaced.
5. Operation
4-Way Scrolling:
a. Vertical Scrolling
Roll wheel up to scroll up; roll wheel down to scroll down.
b. Horizontal Scrolling
Hold the wheel to left to scroll left; hold the wheel to right to scroll
right. Release wheel to stop scrolling function.
Note
The 4-Way scrolling function is only effective under successful installation of the
original mouse driver. The driver is an optional item included in the package or it can
be downloaded from the website of the local brand vendor.
Trouble Shooting
a. Make sure you have connected the receiver correctly to the computer's USB port.
b. For the best performance, we suggest you to locate the receiver with a distance from other electrical devices, such as the
computer, the computer monitor or external storage drives.
c. Make sure you have set the communication between the receiver and the mouse. Refer to the channel setting
instruction (refer to No.3) in your manual.
d. Some system devices might conflict with the mouse. Confirm the IRQ/address settings of these devices for conflicts,
and change the settings as required.
e. Make sure that you are not working the mouse on glossy or reflective surfaces.
f. Try unplugging then reconnecting the receiver cable to your computer.
Battery use reminders
1. Remove worn-out batteries from equipment immediately and dispose of promptly.
2. Keep all batteries (used or new) out of the reach of children.
3. To have the batteries with a regular check and replace new batteries if not used for a long time.
4. Never dispose of batteries in fire, as they could explode.
5. Always replace all the batteries at the same time. Mixing old and new batteries or mining types (such as alkaline with
zinc carbon) will reduce overall performance and could cause leakage or rupture.
6. Do not mix different types of batteries (e.g. Ni MH, NiCd, alkaline, and etc) in the mouse.
7. Remove batteries from the electrical device if the device is not going to be used for a long time.
8. If the performance of the batteries decreases substantially, it is time to replace the batteries.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may
not cause harmful interference, and (2) this device must accept any interference received, including interference that may
cause undesired operation.
FCC NOTE
The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications to this equipment.
Such modifications could void the user's authority to operate the equipment.
