ARRIS Global 0DC60XU HD Digital Transport Adaptor User Manual II
Pace Micro Technology plc HD Digital Transport Adaptor II
User Manual II
SAFETY
INFORMATION
To ensure you use this product safely,
please read all the safety information
included in this document.
This digital adapter has been manufactured
and tested with your safety in mind. However,
improper use can result in potential electric
shock or fire hazards. To avoid defeating the
safeguards that have been built into your
digital adapter, please observe the precautions
discussed in this document.
The model number and serial number of your
digital adapter are on a label on its base.
OTHER WARNINGS
Do not remove the cover of your digital
adapter. There are no user-serviceable parts
inside it.
Do not perform any servicing unless you are
qualified to do so. Refer all servicing to qualified
service personnel. Servicing your digital adapter
yourself will invalidate the warranty.
On the rear panel of your digital adapter there
is a tamper-evident label that states “Warranty
void if broken or removed”.
To reduce the risk of fire or electric shock, do not
expose your digital adapter to rain or moisture.
To avoid possible damage to your digital
adapter or to a connected TV or component, all
AC power cords must be plugged into properly
wired outlets. As with all electrical products,
connection to faulty or defective components,
or the failure to connect your digital adapter to
a properly wired outlet, may cause sparking,
property damage or damage to any TV or other
component connected to your digital adapter
and pose a fire hazard.
Risk of fire or scorching
Never place naked flame sources, such as lighted
candles, on or adjacent to your digital adapter.
Ambient temperature
The operating temperature range of your
digital adapter is 32-104°F. If the ambient
temperature around your digital adapter falls
outside this range, you must correct this in
order for your digital adapter to work correctly
and safely. For example, if the temperature is
too high, switch on the air conditioning.
Ventilation
Slots and openings in the casing of your
digital adapter are provided for ventilation,
to ensure reliable operation of your digital
adapter and to protect it from overheating.
• Neverblocktheventilationopeningsby
placing your digital adapter on a bed,
sofa, rug or other similar surface.
• Nevercovertheventilationopeningswith
items such as newspapers, tablecloths or
curtains.
CAUTION
Do not attempt to modify your digital adapter
without written authorization from the
manufacturer. Unauthorized modification
could void your authority to operate your
digital adapter.
Failure to heed the Safety Information
provided by failing to connect to a properly
wired outlet may void the manufacturer’s
warranty.
SAVE THIS INFORMATION FOR FUTURE
REFERENCE
IMPORTANT SAFETY INSTRUCTIONS
Before you install or use the apparatus, you must read and understand these
Important Safety Instructions. At all times when using the apparatus you must
follow these Important Safety Instructions to reduce the risk of fire, electrical
shock and injury to persons.
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the
manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat registers,
stoves, or other apparatus (including amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A
polarized plug has two blades with one wider than the other. A grounding
type plug has two blades and a third grounding prong. The wide blade or the
third prong are provided for your safety. If the provided plug does not fit into
your outlet, consult an electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at
plugs, convenience receptacles, and the point where they exit from the
apparatus.
11. Only use attachments/accessories specified by the manufacturer.
12. Use only with the cart, stand, tripod, bracket, or table
specified by the manufacturer, or sold with the apparatus.
When a cart is used, use caution when moving the cart/
apparatus combination to avoid injury from tip-over.
13. Unplug this apparatus during lightning storms or when
unused for long periods of time.
14. Refer all servicing to qualified service personnel. Servicing is required
when the apparatus has been damaged in any way, such as power-supply
cord or plug is damaged, liquid has been spilled or objects have fallen into
the apparatus, the apparatus has been exposed to rain or moisture, does
not operate normally, or has been dropped.
REGULATORY
INFORMATION
NOTE
Your digital adapter has been tested and
found to comply with the limits for a Class
B digital device, pursuant to Part 15 of
the FCC Rules. These limits are designed
to provide reasonable protection against
harmful interference in a residential
installation. Your digital adapter
generates, uses and can radiate radio-
frequency energy and, if not installed and
used in accordance with the instructions,
may cause harmful interference to radio
communications.
However, there is no guarantee that
interference will not occur in a particular
installation. If your digital adapter does
cause harmful interference to radio
or television reception, which can be
determined by turning your digital adapter
off and on, you are encouraged to try to
correct the interference by one or more of
the following measures:
• Reorientorrelocatethereceiving
antenna.
• Increasetheseparationbetweenyour
digital adapter and the receiver.
• Connectyourdigitaladaptertoan
outlet on a circuit different from that to
which the receiver is connected.
• Consultyourdealeroranexperienced
radio/TV technician for help.
CONNECTING TO THE
AC POWER SUPPLY
You must not plug your digital adapter into
the power supply until you have connected
your digital adapter to the other equipment in
your system.
Your digital adapter itself is designed for use
only with the supplied power supply unit.
On the power supply unit there is a label that
specifies the correct AC power supply input
for it. Do not connect the power supply unit
to any supply other than this.
Always connect the 5 volt DC cord from the
power supply unit to your digital adapter
before you insert the power supply unit into
the wall AC outlet.
To disconnect power from your digital
adapter, always remove the power supply unit
from the wall AC outlet (i.e. not by removing
the 5 volt cord from your digital adapter).
Therefore you must install your digital
adapter near to the wall AC outlet, which
should be easily accessible.
If you are in any doubt about the
power supply lead, its plug or its
connection, consult a qualified
electrician.
504-3395200
Introducing the Pace High-definition Digital
Transport Adapter
Your new Pace digital adapter allows you to receive your channels in full digital
and high-definition (HD) format, which improves both the overall sound and
picture quality.
You should connect your digital adapter to any television that has cable service
connected but does not have a digital cable box.
Televisions that already have a digital cable box installed do not require a
digital adapter.
By following the instructions in this guide, you will be able to install your
digital adapter with relative ease.
WELCOME BEFORE YOU BEGIN
INSTRUCTIONS IMPORTANTES SUR LA SÉCURITÉ
Avant d’installer et d’utiliser cet appareil, il est important de lire et de comprendre
les instructions concernant la sécurité. Ces instructions doivent en tout temps être
observées lors de l’utilisation de l’appareil afin de réduire les risques d’incendie, de
choc électrique et de blessures.
1. Lire les instructions.
2. Conserver les instructions.
3. Observer tous les avertissements.
4. Observer toutes les instructions.
5. Ne pas utiliser cet appareil près de l’eau.
6. Nettoyer uniquement avec un chiffon sec.
7. Ne pas obstruer les ouvertures d’aération de l’appareil. Installer l’appareil
suivant les recommandations du fabricant.
8. Ne pas installer l’appareil à proximité d’une source de chaleur telle que
radiateur, registre de chaleur, cuisinière ou autre appareil produisant de la
chaleur (y compris les amplificateurs).
9. Ne pas contourner le dispositif de sécurité de la fiche polarisée ou de la fiche avec
mise à la terre. Une fiche polarisée est pourvue de deux broches; l’une étant plus
large que l’autre. Une fiche avec mise à la terre est pourvue de deux lames et d’une
broche de mise à la terre. La broche plus large et la troisième broche sont destinées
à assurer la sécurité. Si la fiche de l’appareil ne convient pas à la prise électrique
murale, s’adresser à un électricien pour faire remplacer la prise murale.
10. S’assurer que le cordon d’alimentation ne sera ni piétiné ni écrasé, particulièrement au
niveau de la fiche, de la prise électrique ainsi qu’au point de sortie du fil de l’appareil.
11. Utiliser uniquement les fixations et accessoires recommandés par le fabricant.
12. Utiliser uniquement l’appareil avec un chariot, un pied, un trépied, une table ou un
support recommandé par le fabricant, ou vendu avec l’appareil. Lors de l’utilisation
d’un chariot, faire preuve de prudence pour transporter l’unité chariot/appareil afin
de ne pas la faire basculer.
13. Débrancher l’appareil pendant les orages électriques ou lorsque
l’appareil n’est pas utilize pendant une longue période.
14. Confier toute réparation à du personnel d’entretien compétent.
Un entretien est essentiel dans les cas suivants : la fiche ou
le cordon d’alimentation sont endommagés; du liquide a été
renversé ou des objets sont tombés dans l’appareil; l’appareil a été exposé à la
pluie ou à l’humidité; l’appareil ne fonctionne pas adéquatement ou il est tombé.
DC60Xu
Quick Start Guide
High-definition Digital Transport Adapter
BRINGING TECHNOLOGY HOME
www.pace.com
Warnings on the power supply unit
The lightning flash with arrowhead symbol, within a triangle, is intended to alert you to the
presence of uninsulated “dangerous” voltages within the power supply unit’s enclosure
that may be of sufficient magnitude to constitute a risk of electric shock to persons.
The exclamation point within a triangle is intended to alert you to the presence of
important instructions in the literature accompanying your digital adapter.
Avertissements affichés sur le bloc d’alimentation
Le symbole représentant un éclair dans un triangle a pour but de vous avertir de
la présence de tensions “dangereuses” non isolées à l’intérieur du châssis du bloc
d’alimentation, tensions qui pourraient être suffisantes pour présenter un risque de
choc électrique pour les personnes.
Le point d’exclamation dans un triangle a pour but d’attirer votre attention sur des
instructions importantes dans la documentation accompagnant votre boîtier décodeur.
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION
Manufactured under license from Dolby Laboratories. Dolby and the
double-D symbol are trademarks of Dolby Laboratories.
HDMI, the HDMI Logo, and High-Definition Multimedia Interface are
trademarks or registered trademarks of HDMI Licensing LLC in the United
States and other countries.
Pace and are trademarks and/or registered trademarks of Pace plc.
Copyright © 2012 Pace plc. All rights reserved.
Service address Adresse du service d’entretien
Pace Americas Inc.
3701 FAU Boulevard, Suite 200, Boca Raton, Florida 33431 U.S.A.
®
• Readallthesafetyinformationinthisguide.
• Checkyouhaveallthethingsyouneed(see‘What’sinthebox?’).
• Familiarizeyourselfwiththefrontandrearpanelsofyourdigitaladapter
(see‘AboutyourDigitalAdapter’).
• Choosetherightconnectionsetupforyourequipment.Yourdigital
adapter can be operated in high-definition (HD - an HD service is
required) or standard-definition (SD).
- For HD viewing, use the HDMI cable (refer to the “High-definition
Connection” diagram overleaf).
- For SD viewing, use an coaxial RF cable (refer to the “Standard-
definition Connection” diagram overleaf).
• Beforeconnectinganycables,chooseasuitablepositionforyourdigital
adapter, observing the ventilation requirements set out in the safety
information.
• Followtheinstructionsoverleaftoinstallyourdigitaladaptercorrectly.
Remember, you will need access to a working wall AC power outlet.
• Youmaywanttosecureyourdigitaladapterwiththeenclosedadhesive
fasteners. However, be careful that the adhesive doesn’t damage the
surface to which you are attaching the fastener, as your cable company will
not be responsible for any damage.
• Anyproblems?Consultthe‘SolvingProblems’tableoverleaf.
D417-QSG-Iss1.indd 1 31/01/2012 14:45
DC60Xu HD
Power
If the installed system does not seem to be working properly, first make sure that all the cables are securely connected, then carry out the
following checks, in the order shown.
Problem Suggested solution Further checks, if there is still a problem
There is nothing
illuminated on your
digital adapter’s
front panel.
Power may not be reaching your digital adapter. Make sure
that the external power supply unit is properly plugged in. If
there is a switch by the wall AC power outlet, switch it to ON.
Check that the wall AC power outlet is working (for example by plugging
in a lamp).
The remote control
does not operate
your digital adapter.
Check that nothing is blocking the path from your remote
control to the front panel.
Check that your remote control is currently set to operate your digital
adapter (consult the instructions supplied with your remote control).
If your remote control will still not operate your digital adapter, replace
the batteries in your remote control.
There is no picture
on your TV screen.
Your TV and other equipment may not be turned on. Check
that they are plugged into AC power outlets and turned on.
If your TV and digital adaper are connected using a coaxial
RF cable, make sure your TV and digital adapter are both set
to the same channel (3 or 4).
Check that you have selected the appropriate video input on your TV.
If the video path between your digital adapter and your TV loops through
other equipment (such as a VCR) you may need to turn on this equipment.
If your TV and digital adaper are connected using a coaxial RF cable, try
switching your TV and digital adapter to the other channel (3 or 4).
There are black
bars on the sides of
your TV screen.
Check the screen settings on your TV (refer to the TV user
guide to make sure it is in 16x9 mode).
If you do not subscribe to an HD service, you will not be able to view HD
channels and may see the black bars on the sides of your TV screen,
indicating that the picture is in standard-definition.
Check that the program is transmitted in HD.
There is no sound. Check that any audio cables between your TV and any
attached audio equipment are securely and correctly
connected.
Check that you have not muted the sound on your TV and/or any
attached audio equipment. Adjust the volume control on your TV.
If you can hear only mono sound, first check that the program is likely to
have stereo sound (an old movie, for example, may not be in stereo).
If you are still having problems contact your cable company.
SOLVING PROBLEMS
Place the batteries (supplied) into your remote control.
After you install your digital adapter, the only way to change channels
is with the supplied remote control.
If you need further help, for example to program the remote control to
operate your TV, refer to the instructions supplied with the remote control.
USING YOUR REMOTE CONTROL
HIGH-DEFINITION CONNECTION STANDARD-DEFINITION CONNECTION
1. Connect the supplied coxial RF cable from the cable service to the
connector marked CABLE IN on your digital adapter,
as shown below
.
2. Connect the supplied HMDI cable between the HDMI connector
on your digital adapter and the HDMI connector on your HDTV.
3.
Connect the external power supply unit (supplied) to the connector
marked POWER on your digital adapter.
4. After you have made the connections between your digital adapter
and your HDTV, connect your HDTV and the external power supply
unit to the AC power supply.
PLACING YOUR DIGITAL ADAPTER
Set this switch to Channel 3
Following Installation
If you have followed the steps and have picture and sound,
congratulations, you have successfully installed your Pace high-
definition digital adapter.
If you are experiencing problems, please consult the “Solving
Problems” guide located to the right.
Note: If your digital adapter requires activation, contact your cable
company.
Enjoy viewing all of your favorite TV shows, movies and sports
games with digital picture and sound.
ENJOY DIGITAL TV!
ABOUT YOUR DIGITAL ADAPTER
CABLE IN
From cable
service provider
S POWER LED
Lights when your
digital adapter is fully on
POWER INPUT
Make this connection
last of all
TO TV
RF output to
the TV
HDMI
Video and audio output
for digital HDTV
CHANNEL 3/4
Switch for tuning your
digital adapter (if required)
Front Panel
Rear Panel
To the wall
AC outlet
From your cable service
Digital Adapter
Supplied
HDMI cable
HDTV
Supplied RF cable
After you have made the connections between the cable service, your
digital adapter and your TV, place your digital adapter in a suitable
location, observing the ventilation requirements set out in the safety
information overleaf.
Make sure there is nothing blocking the path from your remote control
to the digital adapter’s front panel. You can “pair” the remote control
and digital adapter. This enables the remote control to operate the
digital adapter if the digital adapter is hidden from view. For more
information, consult the instructions supplied with your remote control.
• Youcanplaceyourdigital
adapter below or beside
your TV.
• Oncetheremotecontrol
and digital adapter are
“paired”, you can use
the adhesive fasteners
(supplied) to attach your
digital adapter to the side
or back of your TV.
DC60Xu HD
Power
CABLE IN
RF IN
CABLE
SERVICE
To the wall
AC outlet
From your cable service
Digital Adapter
Supplied RF cable
CABLE IN
RF IN
SDTV
RF cable
1. Connect the supplied coxial RF cable from the cable service to the
connector marked CABLE IN on your digital adapter,
as shown below
.
2. Connect another coxial RF cable between the TO TV connector on your
digital adapter and the ANTENNA IN/RF IN connector on your SDTV.
3.
Connect the external power supply unit (supplied) to the connector
marked POWER on your digital adapter.
4. After you have made the connections between your digital adapter
and your SDTV, connect your SDTV and the external power supply
unit to the AC power supply.
5. Make sure your TV is tuned to channel
3, and set the switch on the back of
your digital adapter to channel 3.
Note: Some parts of the country use
channel 4. If you do not have a picture,
you may need to switch both your TV
and digital adapter to channel 4.
Digital Adapter
(exact model may
differ slightly from
that shown)
Coaxial RF Cable
External 5V
Power Supply Unit
Remote Control
(exact model may differ
slightly from that shown)
AA Batteries
(for your
remote
control)
Adhesive
Fasteners
WHAT’S IN THE BOX?
HDMI® Cable
123
456
7 8 9
0
GUIDE
INFO
MENU
EXIT
PAGE
MUTE
TV CABLE
POWER
LAST
L
A
N
G
D417-QSG-Iss1.indd 2 31/01/2012 14:45
