ARRIS GPW2200 G.hn Powerline to Wi-Fi extender User Manual
ARRIS Group, Inc. G.hn Powerline to Wi-Fi extender Users Manual
ARRIS >
Users Manual
Quick Start Guide
GPW2200
WiFi Extender 1
3
2
A separate G.hn device (Such as the
GPE2001) must be located at the
gateway, or integrated in the gateway
to carry the data from the gateway to
the GPW2200.
Reset button
Press and hold the G.hn Secure Pairing
button on the front of the GPW2200 for
2 seconds. The pairing LED will blink.
Within 2 minutes press the G.hn pairing
button on the other G.hn device. The
pairing LEDs will blink when syncing and
become solid green once successfully
paired.
Up to 8 G.hn devices may be paired
within 2 minutes after the pairing
process is started by pressing the first
device for two seconds.
Plug the GPW2200 WiFi Extender
into an AC outlet where you want to
add WiFi coverage. Wait near 2 minutes
for start-up test & LEDs to settle.
After the G.hn & WiFi LEDs are lit the
adapter is ready to use. Any wireless
clients connect using the password
located on the GPW2200 label. There
is also an Ethernet port on the bottom
for connecting a wired device.
The adapters will initially connect on a
default network and the pairing LED
will be orange. To create a private
Network that your neighbor cannot see,
it is recommended to follow steps 5 & 6.
This pairing is not the same as pairing
WiFi, it is only for the G.hn power line
connection.
Pairing button
Ethernet port
GPW2200 WiFi Extender
4
5
6
7
xxxxxxxxxxx 0x/2017
Before you begin:
For Internet connections, you must have a
Cable, DSL or Satellite Internet service
provider (ISP) service connection to the
Internet. For further Configuration information,
please refer to the GPW2200 User Manual
available on line at the ARRIS website,
www.arris.com
© 2015 ARRIS Enterprises, Inc. All rights reserved.
ARRIS, RipCurrent, and the ARRIS logo are all trademarks or
registered trademarks of ARRIS Enterprises, Inc. Other trademarks
and trade names may be used in this document to refer to either
the entities claiming the marks and the names of their products.
ARRIS disclaims proprietary interest in the marks and names of
others.
No part of this publication may be reproduced or transmitted in any
form or by any means without written permission from ARRIS
Enterprises, Inc.
GPW2200 Features
• Easy Installation – Plug & Play
• Add WiFi at any outlet
• 2.4Ghz and 5Ghz 2x2 802.11ac
• Wired connections also
• Sends data over building power lines
Ethernet LED
Pairing LED
NOTE:
The GPW2200 WiFi Extender WiFi
LED is three colored. If the LED is green,
both 5Ghz and 2.4Ghz WiFi are active. If
blue, only 5Ghz. If yellow, only 2.4Ghz.
G.hn LED
Power LED
Important Notes:
This device complies with Part 15 of the FCC Rules. Oper-
ation is subject to the following two conditions: (1) This
device may not cause harmful interference, and (2) this
device must accept any interference received, including
interference that may cause undesired operation.
WiFi LED
WPS button
Federal Communication Commission
Interference Statement
This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection
against harmful interference in a residential
installation. This equipment generates, uses and
can radiate radio frequency energy and, if not
installed and used in accordance with the
instructions, may cause harmful interference to
radio communications. However, there is no
guarantee that interference will not occur in a
particular installation. If this equipment does cause
harmful interference to radio or television
reception, which can be determined by turning the
equipment off and on, the user is encouraged to try
to correct the interference by one of the following
measures:
●Reorient or relocate the receiving antenna.
●Increase the separation between the equipment
and receiver.
●Connect the equipment into an outlet on a circuit
different from that to which the receiver is
connected.
●Consult the dealer or an experienced radio/TV
technician for help.
FCC Caution: Any changes or modifications not
expressly approved by the party responsible for
compliance could void the user's authority to operate
this equipment.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired
operation.
IMPORTANT NOTE:
Radiation Exposure Statement:
This equipment complies with FCC radiation exposure
limits set forth for an uncontrolled environment. This
equipment should be installed and operated with
minimum distance 20cm between the radiator & your
body.
This transmitter must not be co-located or operating in
conjunction with any other antenna or transmitter.
Country Code selection feature to be disabled for
products marketed to the US/CANADA
Operation of this device is restricted to indoor use only
Industry Canada statement:
This device complies with Industry Canada’s licence-
exempt RSSs. Operation is subject to the following two
conditions:
(1) This device may not cause interference; and
(2) This device must accept any interference, including
interference that may cause undesired operation of the
device.
Le présent appareil est conforme aux CNR d’Industrie
Canada applicables aux appareils radio exempts de
licence. L’exploitation est autorisée aux deux conditions
suivantes:
1) l’appareil ne doit pas produire de brouillage;
2) l’utilisateur de l’appareil doit accepter tout brouillage
radioélectrique subi, même si le brouillage est
susceptible d’en compromettre le fonctionnement.
(For transmitters equipped with detachable antennas)
This radio transmitter (IC: 6670A-GPW2200) has been
approved by Industry Canada to operate with the
antenna types listed below with the maximum
permissible gain indicated. Antenna types not included
in this list, having a gain greater than the maximum gain
indicated for that type, are strictly prohibited for use
with this device.
Le présent émetteur radio (IC: 6670A-GPW2200) a été
approuvé par Industrie Canada pour fonctionner avec les
types d'antenne énumérés ci- dessous et ayant un gain
admissible maximal. Les types d'antenne non inclus
dans cette liste, et dont le gain est supérieur au gain
maximal indiqué, sont strictement interdits pour
l'exploitation de l'émetteur.
Caution:
The device for operation in the band 5150–5250
MHz is only for indoor use to reduce the potential
for harmful interference to co-channel mobile
satellite systems;
Avertissement:
les dispositifs fonctionnant dans la bande de 5150 à
5250MHz sont réservés uniquement pour une
utilisation à l'intérieur afin de réduire les risques de
brouillage préjudiciable aux systèmes de satellites
mobiles utilisant les mêmes canaux;
Radiation Exposure Statement:
The product comply with the Canada portable RF
exposure limit set forth for an uncontrolled
environment and are safe for intended operation as
described in this manual. The further RF exposure
reduction can be achieved if the product can be kept
as far as possible from the user body or set the
device to lower output power if such function is
available.
