ARRIS SBG6782HH Wireless Gateway User Manual

ARRIS Taiwan, Ltd. Wireless Gateway

User Manual

b
User Guide
Motorola SURFboard®
SBG6782 DOCSIS® 3.0 Wireless Gateway
DRAFT
B
©2012 Motorola Mobility, LLC All rights reserved.
MOTOROLA and the Stylized M Logo are trademarks or registered trademarks of Motorola Trademark Holdings, LLC. All other
product or service names are the property of their respective owners.
No part of this publication may be reproduced in any form or by any means or used to make any derivative work (such as
translation, transformation, or adaptation) without written permission from Motorola Mobility, LLC. Motorola Mobility reserves the
right to revise this publication and to make changes in content from time to time without obligation on the part of Motorola Mobility
to provide notification of such revision or change. Motorola Mobility provides this guide without warranty of any kind, implied or
expressed, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose. Motorola
Mobility may make improvements or changes in the product(s) described in this manual at any time.
DRAFT
B
SBG6782 DOCSIS 3.0 Wireless Gateway • User Guide
i
589054-001-a
i Safety and Regulatory Information
IMPORTANT SAFETY INSTRUCTIONS
Read This Before You BeginWhen using your equipment, basic safety precautions should always be
followed to reduce the risk of fire, electric shock, and injury to persons, including the following:
Read all of the instructions listed here and/or in the user manual before you operate this device. Give
particular attention to all safety precautions. Retain the instructions for future reference.
This device must be installed and used in strict accordance with manufacturer’s instructions, as described in
the user documentation that is included with the device.
Comply with all warning and caution statements in the instructions. Observe all warning and caution symbols
that are affixed to this device.
To prevent fire or shock hazard, do not expose this device to rain or moisture. The device must not be
exposed to dripping or splashing. Do not place objects filled with liquids, such as vases, on the device.
This device was qualified under test conditions that included the use of the supplied cables between system
components. To ensure regulatory and safety compliance, use only the provided power and interface cables
and install them properly.
Different types of cord sets may be used for connections to the main POWER supply circuit. Use only a main
line cord that complies with all applicable device safety requirements of the country of use.
Installation of this device must be in accordance with national wiring codes and conform to local regulations.
Operate this device only from the type of power source indicated on the device’s marking label. If you are not
sure of the type of power supplied to your home, consult your dealer or local power company.
Do not overload outlets or extension cords, as this can result in a risk of fire or electric shock. Overloaded AC
outlets, extension cords, frayed power cords, damaged or cracked wire insulation, and broken plugs are
dangerous. They may result in a shock or fire hazard.
Route power supply cords so that they are not likely to be walked on or pinched by items placed upon or
against them. Pay particular attention to cords where they are attached to plugs and convenience
receptacles, and examine the point where they exit from the device.
Place this device in a location that is close enough to an electrical outlet to accommodate the length of the
power cord.
Place the device to allow for easy access when disconnecting the power cord of the device from the AC wall
outlet.
Do not connect the plug into an extension cord, receptacle, or other outlet unless the plug can be fully
inserted with no part of the blades exposed.
Place this device on a stable surface.
Avoid damaging the cable modem with static by touching the coaxial cable when it is attached to the earth-
grounded coaxial cable-TV wall outlet.
Always first touch the coaxial cable connector on the cable modem when disconnecting or reconnecting the
Ethernet cable from the cable modem or user’s PC.
It is recommended that the customer install an AC surge protector in the AC outlet to which this device is
connected. This is to avoid damaging the device by local lightning strikes and other electrical surges.
Postpone installation until there is no risk of thunderstorm or lightning activity in the area.
Do not use this product near water: for example, near a bathtub, washbowl, kitchen sink or laundry tub, in a
wet basement, or near a swimming pool.
DRAFT
B
SBG6782 DOCSIS 3.0 Wireless Gateway • User Guide
ii
589054-001-a
Do not cover the device or block the airflow to the device with any other objects. Keep the device away from
excessive heat and humidity and keep the device free from vibration and dust.
Wipe the device with a clean, dry cloth. Never use cleaning fluid or similar chemicals. Do not spray cleaners
directly on the device or use forced air to remove dust.
For added protection, unplug the device from the wall outlet and disconnect the cables to avoid damage to
this device due to lightning and power surges.
Upon completion of any service or repairs to this device, ask the service technician to perform safety checks
to determine that the device is in safe operating condition.
Do not open the device. Do not perform any servicing other than that contained in the installation and
troubleshooting instructions. Refer all servicing to qualified service personnel.
This device should not be used in an environment that exceeds 104º F (40º C).
SAVE THE ABOVE INSTRUCTIONS
Note to CATV System InstallerThis reminder is provided to call the CATV system installer’s attention to
Article 820.93 and 820.100 of the National Electric Code, which provides guidelines for proper grounding and, in
particular, specifies that the Coaxial cable shield shall be connected to the grounding system of the building, as
close to the point of cable entry as practical.
FCC STATEMENTS
FCC Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential environment. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the device off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the device and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)
This device may not cause harmful interference, and (2) This device must accept any interference received,
including interference that may cause undesired operation.
FCC CAUTION: Any changes or modifications not expressly approved by Motorola for compliance could void
the user’s authority to operate the equipment.
FCC Radiation Exposure Statement
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. To
comply with the FCC RF exposure compliance requirements, the separation distance between the antenna and
any person’s body (including hands, wrists, feet and ankles) must be at least 20 cm (8 inches).
This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter except
those already approved in this filing.
DRAFT
B
SBG6782 DOCSIS 3.0 Wireless Gateway • User Guide
iii
589054-001-a
The availability of some specific channels and/or operational frequency bands are country dependent and are
firmware programmed at the factory to match the intended destinations. The firmware setting is not accessible
by the end user.
AVIS D'INDUSTRIE CANADA (IC)
Cet appareil est conforme à la réglementation RSS-210 d'Industrie Canada. Son utilisation est assujettie aux
deux conditions suivantes :
Cet appareil ne doit pas causer d'interférences et
Cet appareil doit accepter toute interférence reçue, y compris les interférences causant un fonctionnement
non désiré.
Cet appareil numérique de classe B est conforme à la norme NMB-003 du Canada.
Au Canada, les appareils de réseau local sans fil ne sont pas autorisés à utiliser les bandes de fréquence 5600-
5650 MHz.
AVERTISSEMENT: afin de réduire les risques de brouillage préjudiciable aux systèmes de satellites mobiles
utilisant les mêmes canaux, les dispositifs fonctionnant dans la bande 5150-5250 MHz sont réservés
uniquement pour une utilisation à l'intérieur
Les radars à haute puissance sont définis en tant qu'utilisateurs principaux (c.-à-d. prioritaires) des bandes de
fréquences 5250-5350 MHz et 5650-5850 MHz. Ces radars peuvent causer de l'interférence ou des
dommages susceptibles de nuire aux appareils exempts de licenceréseau local (LAN-EL).
DÉCLARATION DE IC SUR L'EXPOSITION AUX RAYONNEMENTS
NOTE IMPORTANTE : cet équipement est conforme aux limites d'exposition aux rayonnements établies par IC
pour un environnement non contrôlé. Cet équipement doit être installé et utilisé de manière à maintenir une
distance d'au moins 20 cm entre la source de rayonnement et votre corps.
INDUSTRY CANADA (IC) STATEMENT
This device complies with RSS-210 of the Industry Canada Rules. Operation is subject to the following two
conditions:
This device may not cause interference, and
This device must accept any interference, including interference that may cause undesired operation of the
device.
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
In Canada, RLAN devices are restricted from using the 5600-5650 MHz frequency band.
CAUTION: To reduce the potential for harmful interference to co-channel mobile satellite systems, use of the
5150-5250 MHz frequency band is restricted to indoor use only.
High power radars are allocated as primary users (meaning they have priority) of 5250-5350 MHz and 5650-
5850 MHz frequency bands. These radars could cause interference and/or damage to License ExemptLocal
Area Network (LE-LAN) devices.
IC RADIATION EXPOSURE STATEMENT
IMPORTANT NOTE: This equipment complies with IC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with a minimum distance of 20 cm between the
radiator and your body.
DRAFT
B
SBG6782 DOCSIS 3.0 Wireless Gateway • User Guide
iv
589054-001-a
WIRELESS LAN INFORMATION
This device is a wireless network product that uses Direct Sequence Spread Spectrum (DSSS) and Orthogonal
Frequency-Division Multiple Access (OFDMA) radio technologies. The device is designed to be interoperable
with any other wireless DSSS and OFDMA products that comply with:
The IEEE 802.11 Standard on Wireless LANs (Revision B, Revision G, and Revision N), as defined and
approved by the Institute of Electrical Electronics Engineers
The Wireless Fidelity (Wi-Fi) certification as defined by the Wireless Ethernet Compatibility Alliance (WECA).
Restrictions on the Use of Wireless Devices
In some situations or environments, the use of wireless devices may be restricted by the proprietor of the
building or responsible representatives of the organization. For example, using wireless equipment in any
environment where the risk of interference to other devices or services is perceived or identified as harmful.
If you are uncertain of the applicable policy for the use of wireless equipment in a specific organization or
environment, you are encouraged to ask for authorization to use the device prior to turning on the equipment.
The manufacturer is not responsible for any radio or television interference caused by unauthorized modification
of the devices included with this product, or the substitution or attachment of connecting cables and equipment
other than specified by the manufacturer. Correction of the interference caused by such unauthorized
modification, substitution, or attachment is the responsibility of the user.
The manufacturer and its authorized resellers or distributors are not liable for any damage or violation of
government regulations that may arise from failing to comply with these guidelines.
Note: The use of the 5150-5250 MHz frequency band is restricted to Indoor Use Only.
SECURITY WARNING: This device allows you to create a wireless network. Wireless network connections
may be accessible by unauthorized users. For more information on how to protect your network, see the
SBG6580 User Guide for instructions or visit the Motorola website.
CARING FOR THE ENVIRONMENT BY RECYCLING
When you see this symbol on a Motorola product, do not dispose of the product
with residential or commercial waste.
Recycling your Motorola Equipment
Please do not dispose of this product with your residential or commercial waste.
Some countries or regions, such as the European Union, have set up systems to
collect and recycle electrical and electronic waste items. Contact your local
authorities for information about practices established for your region. If
collection systems are not available, call Motorola Customer Service for
assistance. Please visit www.motorola.com/recycle for instructions on
recycling.
DRAFT
B
SBG6782 DOCSIS 3.0 Wireless Gateway • User Guide
v
589054-001-a
Contents
Safety and Regulatory Information ...................................................................................................................... i
Getting Started ...................................................................................................................................................... 1
Introduction ............................................................................................................................................................. 1
In the Box ................................................................................................................................................................ 1
Additional Items You May Need ....................................................................................................................... 1
System Requirements ............................................................................................................................................. 2
Contact Information ................................................................................................................................................. 2
Product Overview .................................................................................................................................................. 3
Front Panel .............................................................................................................................................................. 3
Wi-Fi Protected Setup (WPS) ............................................................................................................................ 4
Rear Panel ............................................................................................................................................................... 5
Gateway Label ......................................................................................................................................................... 5
Installing the Gateway .......................................................................................................................................... 6
Connecting to Your Computer................................................................................................................................. 6
Connecting Your MoCA-Enabled Devices ........................................................................................................ 7
Testing the Gateway Connections .......................................................................................................................... 7
Connecting the Gateway to the Internet ................................................................................................................. 7
Setting Up a Wireless Network Connection ...................................................................................................... 9
Changing the Wireless Network Options on Your Computer ................................................................................. 9
Using the WPS Pairing Button ................................................................................................................................ 9
Testing Your Wireless Network Connection ......................................................................................................... 10
Troubleshooting .................................................................................................................................................. 11
Solutions ................................................................................................................................................................ 11
Front Panel LED Icons and Error Conditions ......................................................................................................... 12
Warranty Information ......................................................................................................................................... 13
Tables
Table 1 SBG6782 Package Contents .................................................................................................................... 1
Table 2 SBG6782 Front Panel LED Icons ............................................................................................................. 3
Table 3 SBG6782 Rear Panel Ports & Connectors ............................................................................................... 5
Table 4 – Troubleshooting Solutions ..................................................................................................................... 11
Table 5 – Front Panel LED Icons and Error Conditions ......................................................................................... 12
Figures
Figure 1 SBG6782 Front View .............................................................................................................................. 3
Figure 2 SBG6782 Rear View ............................................................................................................................... 5
Figure 3 SBG6782 Connection Diagram ............................................................................................................... 6
DRAFT
B
SBG6782 DOCSIS 3.0 Wireless Gateway • User Guide 1
589054-001-a
1 Getting Started
Introduction
The Motorola SURFboard® SBG6782 DOCSIS® 3.0 Wireless Cable Modem Gateway is a combination
wireless cable modem, router, and MoCA (Multimedia over Coax ) device that provides wireless high-
speed data and multimedia service access on your home network. With built-in MoCA technology, the
SBG6782 also provides high-speed Internet access to multiple MoCA-enabled devices using the existing
coaxial cable connection in your home. The SBG6782 includes a Wi-Fi Pairing option for quick and easy
connections for your wireless devices.
This guide provides instructions for installing and configuring the SBG6782 gateway, setting up a secure
wireless network connection, and managing your gateway and network configurations.
In the Box
Before installing your new wireless gateway, check that the following items are included in the box with
the gateway. If any items are missing, please contact Motorola Broadband Technical Support at:
1-877-466-8646.
Table 1 – SBG6782 Package Contents
ITEM DESCRIPTION
Power Cord
Provides power to the gateway through an
electrical outlet connection
10/100/1000 Base-T
Ethernet Cable
Standard Category 5, or higher, cable for
connecting to the network
Software License &
Regulatory Card
Contains software license, warranty, and
safety information for the gateway
SBG6782 Quick Start
Guide
Provides basic information for connecting
the gateway
Additional Items You May Need
Coaxial cable, if one is not already connected to a cable outlet
RF splitter (for additional coaxial cable connections, e.g., multi-room MR-DVR)
DRAFT
B
SBG6782 DOCSIS 3.0 Wireless Gateway • User Guide 2
589054-001-a
System Requirements
High-speed Internet access account
Compatible operating systems:
ο Windows Vista, Service Pack 1 or later
ο Windows® 7
ο Windows XP, Service Pack 2 or later
ο Mac® 10.4 or higher
ο UNIX®
ο Linux®
Contact Information
For technical support additional Motorola product information, please visit the Motorola Support website
at www.motorola.com/us/support.
Motorola Broadband Technical Support is also available at 1-877-466-8646. When you call, you will need
the following information from the gateway product label located on the bottom of the gateway:
Gateway model number (HFC MAC ID)
Gateway serial number (S/N)
DRAFT
B
SBG6782 DOCSIS 3.0 Wireless Gateway • User Guide
3
589054-001-a
2 Product Overview
Front Panel
Figure 1 – SBG6782 Front View
Table 2 – SBG6782 Front Panel LED Icons
BUTTON/|
LED ICON
FLASHING
ON
WPS
button
Not applicable no LED on button Not applicable no LED on button
See Wi-Fi Protected Security (WPS) for
description
Not applicable icon does not
flash
Green: Power is properly connected
Scanning for a downstream
(receive) channel connection
Green: Non-bonded downstream channel
is connected
Blue*: High-speed Internet connection
with bonded downstream channels
Scanning for an upstream (send)
channel connection
Green: Non-bonded upstream channel is
connected
Blue*: High-speed Internet connection
with bonded upstream channels
Scanning for an Internet
connection
Green: Gateway is connected to the
network
DRAFT
B
SBG6782 DOCSIS 3.0 Wireless Gateway • User Guide
4
589054-001-a
BUTTON/|
LED ICON
FLASHING
ON
Green: Wi-Fi enabled with
encrypted wireless data activity.
Long/short flash indicates wireless
pairing in progress
Amber: Wi-Fi enabled with
unencrypted wireless data activity
Green: 2.4 GHz wireless connection is
made between the SBG6782 and another
Wi-Fi enabled device on your network
printer, tablet, laptop, etc.
Amber: Turns ON during the wireless
pairing process. LED turns green after
five minutes.
Green: Wi-Fi enabled with
encrypted wireless data activity.
Long/short flash indicates wireless
pairing in progress
Amber: Wi-Fi enabled with
unencrypted wireless data activity
Green: 5 GHz wireless connection is
made between the SBG6782 and another
Wi-Fi enabled device on your network
printer, tablet, laptop, etc
Amber: Turns ON during the wireless
pairing process. LED turns green after
five minutes
Green: Indicates MoCA activity in
progress
Green: A MoCA-enabled device is
connected and running
*Indicates DOCSIS 3.0 operation (high-speed Internet access) which may not be available in all
locations. Check with your service provider for availability in your area.
Note: To increase the bandwidth available for receiving and transmitting data, your service provider
may also implement bonded channels for RECEIVE and SEND channel connections.
Wi-Fi Protected Setup (WPS)
The Wi-Fi Protected Setup (WPS) is a wireless network setup option that provides a quick and easy
solution for setting up a secure wireless network connection for any WPS-enabled device; such as a
computer, tablet, or printer. WPS automatically configures your wireless network connections and sets
up wireless security.
DRAFT
B
SBG6782 DOCSIS 3.0 Wireless Gateway • User Guide
5
589054-001-a
Rear Panel
Figure 2 – SBG6782 Rear View
Table 3 – SBG6782 Rear Panel Ports & Connectors
PORT NAME DESCRIPTION
1
Four one-gigabit Ethernet ports for RJ-45 cable
connections
Green LED is ON - Indicates a data transfer rate of one
gigabit per second
Amber LED is ON - Indicates a data transfer rate of less
than one gigabit per second
2
MoCA 1.1 coaxial cable connector
3
100 - 240VAC Power connector
Gateway Label
The SBG6782 gateway product label is located on the bottom of the gateway. It contains specific
gateway ID information that may be needed when contacting your service provider.
To receive Internet access, you may have to provide the MAC address (HFC MAC ID) and serial
number (S/N) listed on the gateway label to your Internet service provider.
DRAFT
B
SBG6782 DOCSIS 3.0 Wireless Gateway • User Guide
6
589054-001-a
3 Installing the Gateway
This product is for indoor use only. Do not route the Ethernet cable
outside of the building. Exposure of the cables to lightning could
create a safety hazard and damage the product.
Connecting to Your Computer
Before installing the gateway:
Check with your service provider to ensure high-speed Internet service is available in your
area.
Choose a location where your computer and gateway are preferably near existing cable and
electrical wall outlets.
Make sure your computer is powered OFF.
Note: The following procedure steps you through the wired Ethernet connection process to
ensure the gateway is properly connected and your network access is working. Upon successful
completion, you can proceed with the wireless setup. See Connecting Your Wireless Devices
for more information.
Figure 3 – SBG6782 Connection Diagram
1. Check that a coaxial cable is connected to a cable wall outlet or RF splitter.
2. Connect the other end of the coaxial cable to the Cable connector on the gateway.
Hand-tighten the connectors to avoid damaging them.
3. Connect the Ethernet cable to any open Ethernet port on the gateway.
4. Connect the other end of the Ethernet cable to the Ethernet port on your computer.
DRAFT
B
SBG6782 DOCSIS 3.0 Wireless Gateway • User Guide
7
589054-001-a
5. Plug the power cord into the Power port on the gateway.
6. Plug the other end of the power cord into an electrical outlet. This automatically powers ON
the gateway.
Connecting Your MoCA-Enabled Devices
You can also connect your MoCA-enabled devices, such as a multi-room DVR, to the SBG6782.
You will need to use an RF cable splitter and an additional coaxial cable to connect the device
and SBG6782 to the same cable wall outlet. Follow the instructions included with the device to
complete the applicable connections for that device.
Testing the Gateway Connections
Perform the following gateway connectivity test to verify that all the components were
connected properly:
1. Power ON your computer and then log on.
2. Check that the POWER, RECEIVE, and SEND front panel LEDs on the gateway first FLASH
in sequential order and then light SOLID. See Front Panel for additional LED status
information.
If an LED did not light SOLID, contact your service provider for assistance.
3. Contact your service provider to activate (provision) the gateway.
Note: Your service provider may allow for automatic activation which will automatically
launch a special website when you open a web browser.
4. Once your gateway is provisioned, open a web browser on your computer, such as Internet
Explorer, Firefox, Google Chrome, or Safari.
5. Type a valid URL (for example, www.motorola.com) in the address bar and then click or
press Enter.
If the web page did not open, contact your service provider for assistance or proceed to
Connecting the Gateway to the Internet to manually set up the network options on your
computer.
Connecting the Gateway to the Internet
IMPORTANT! Your computer may already be configured to automatically connect to
the Internet. If so, do not change the network options before contacting your
service provider for assistance.
If you cannot access the Internet after completing the gateway installation, you may have to set
up your computer to connect to the Internet. To do this, you will have to enable the network
options on your computer to automatically obtain an IP address and DNS server address.
Operating system-specific commands for configuring computer network options are not provided
in this document. The general steps provided in this section apply to the following Microsoft
Windows platforms supported by the SBG6782:
Windows 7
Windows XP
Consult the documentation for the Windows operating system you are running for specific
command selections.
DRAFT
B
SBG6782 DOCSIS 3.0 Wireless Gateway • User Guide
8
589054-001-a
1. Click the Start button from the Taskbar on your desktop to select Network Connections.
Note: Additional selections may be necessary for Windows 7 systems.
2. Step through to open the Local Area Connection Properties window.
3. Select Internet Protocol (TCP/IP) option and click Properties to open the Internet Protocol
(TCP/IP) Properties window.
4. Select Obtain an IP address automatically and Obtain DNS server address
automatically.
5. Click OK to save the TCP/IP settings and close the Internet Protocol (TCP/IP) Properties
window.
6. Step through to close the remaining windows and exit.
7. To verify the IP address, open a command prompt window using the Start button from the
Taskbar on your desktop.
8. Type ipconfig and press Enter to display the IP configuration.
9. To renew the IP address, type ipconfig /renew and press Enter. A new IP address for your
computer will display.
10. Type exit and then press Enter to return to Windows.
If you still cannot access the Internet, contact your service provider.
DRAFT
B
SBG6782 DOCSIS 3.0 Wireless Gateway • User Guide
9
589054-001-a
4 Setting Up a Wireless
Connection
You cannot set up a wireless network connection or connect wireless devices without being able to
access a broadband or high-speed Internet service from your computer. There are two options available
for setting up a wireless network connection:
Changing Your Computer Wireless Network Options
Using the WPS Pairing Button
After setting up your wireless network connection, make sure to check that the wireless network
connection was set up properly. See Testing Your Wireless Network Connection for more
information.
Changing the Wireless Network Options on Your Computer
Note: The steps for setting up a wireless network may differ slightly depending on the operating
system installed on your computer. The following steps apply for Windows 7.
1. From the Windows taskbar, click Start, Control Panel, Network and Internet Connections,
Network Connections, Wireless Network Connection to open Wireless Network Connection
window.
2. Scroll down and select the SBG6782 wireless network name (SSID is listed on the gateway label).
Click the MOTOROLA wireless network name and then click Connect.
3. Enter Network key code in the Network key & Confirm network key fields listed as Wi-Fi Security
key on the gateway label.
4. Click Connect to complete the wireless network connection. Connected status should display.
5. Close the Wireless Network Connection window.
Using the WPS Pairing Button
Note: To use the WPS Pairing button option, your computer hardware must support WPS and also
have WPA security compatibility.
This option automatically configures the SSID wireless network name and Wi-Fi Security Key to
connect your gateway and other WPS-enabled devices to a wireless network.
1. Power ON your gateway and other WPS-enabled devices that you want to connect to the wireless
network.
2. Press the WPS button located on the top of the SBG6782.
3. Press the WPS button on your WPS-enabled computer or other device.
Repeat for each additional WPS-enabled device.
DRAFT
B
SBG6782 DOCSIS 3.0 Wireless Gateway • User Guide
10
589054-001-a
Testing Your Wireless Network Connection
Perform the following test to verify that your wireless network is set up properly and all the devices
were connected properly.
1. If you installed the SBG6782 using the wired Ethernet connection option, disconnect the Ethernet
cable from the rear of the gateway and your computer.
2. Open a web browser on your computer, such as Internet Explorer, Firefox, Google Chrome, or
Safari.
3. Type a valid URL (www.motorola.com) in the address bar and click or press Enter.
If the web page did not open, see Troubleshooting Solutions for more information or contact
your service provider for assistance.
DRAFT
B
SBG6782 DOCSIS 3.0 Wireless Gateway • User Guide
11
589054-001-a
5 Troubleshooting
If the solutions listed in this section do not solve your problem, contact your service provider for
assistance.
You may have to reset the SBG6782 gateway configuration to its original factory settings if the gateway
is not functioning properly.
Your service provider may ask for the status of the LEDs as described in Front Panel LED Icons and
Error Conditions.
Solutions
Table 4 – Troubleshooting Solutions
MODEM PROBLEM POSSIBLE SOLUTION
POWER LED Icon is OFF Check the power connection between the gateway and the
electrical outlet.
Check that the electrical outlet is working (is the outlet
controlled by a light switch?).
If so, disconnect and find another electrical outlet.
Cannot Send or Receive
Data
Check each end of the coaxial cable connection on the
gateway and cable outlet. Hand tighten, if necessary.
Check the Ethernet cable to make sure it is properly
connected to the gateway and computer.
On the front panel, check the status of the LED icons and
refer to Front Panel LED Icons and Error Conditions to
identify the problem.
If you have cable television, check your television to ensure
your cable service is operating properly.
Check the IP address. Follow the steps for verifying the IP
address for your operating system in Verifying Your IP
Address in Windows 7 or Vista or Verifying Your IP
Address in Windows XP. Call your service provider if you
need an IP address.
If none of the above solutions resolve the problem, contact
your service provider for further assistance.
DRAFT
B
SBG6782 DOCSIS 3.0 Wireless Gateway • User Guide
12
589054-001-a
Front Panel LED Icons and Error Conditions
The SBG6782 front panel LED icons provide status information for the following error conditions:
Table 5 – Front Panel LED Icons and Error Conditions
LED ICON
STATUS
IF, DURING STARTUP:
IF, DURING NORMAL
OPERATION
OFF Modem is not properly plugged into
the electrical outlet
Modem is unplugged
FLASHING Downstream receive channel
cannot be acquired
Downstream channel is lost
FLASHING Upstream send channel cannot be
acquired
Upstream channel is lost
FLASHING IP registration is unsuccessful IP registration is lost
OFF No connected device is detected Device is disconnected
OFF No connected device is detected Device is disconnected
MoCA OFF No connected device is detected Device is disconnected
DRAFT
B
SBG6782 DOCSIS 3.0 Wireless Gateway • User Guide 13
589054-001-a
A Warranty Information
SURFboard SBG6782 DOCSIS 3.0 Wireless Cable Modem Gateway
Motorola Mobility, LLC (“Motorola”)
Retail Purchasers: If you purchased this Product directly from Motorola or from an authorized Motorola retail
reseller, Motorola warrants to you, the original end user customer, that (A) the Product, excluding Software,
will be free from defects in materials and workmanship under normal use, and (B) with respect to Software, (i)
the media on which the Software is provided will be free from defects in material and workmanship under
normal use, and (ii) the Software will perform substantially as described in its documentation. This Limited
Warranty to you, the original end user customer, continues (A) for Software and the media upon which it is
provided, for a period of ninety (90) days from the date of purchase from Motorola or an authorized Motorola
reseller, and (B) for the Product (excluding Software), for a period of one (1) year from the date of purchase
from Motorola or from an authorized Motorola reseller. To take advantage of this Limited Warranty or to obtain
technical support, you must call the Motorola toll-free phone number 1-877-466-8646. Technical support
charges may apply. Motorola’s sole and exclusive obligation under this Limited Warranty for retail sales shall be
to repair or replace any Product or Software that does not meet this Limited Warranty. All warranty claims
must be made within the applicable Warranty Period.
Cable Operator or Service Provider Arrangements. If you did not purchase this Product directly from
Motorola or from a Motorola authorized retail reseller, Motorola does not warrant this Product to you, the end-
user. A limited warranty for this Product (including Software) may have been provided to your cable operator or
Internet Service Provider (“Service Provider”) from whom you obtained the Product. Please contact your
Service Provider if you experience problems with this Product.
General Information. The warranties described in this Section shall not apply: (i) to any Product subjected to
accident, misuse, neglect, alteration, Acts of God, improper handling, improper transport, improper storage,
improper use or application, improper installation, improper testing or unauthorized repair; or (ii) to cosmetic
problems or defects which result from normal wear and tear under ordinary use, and do not affect the
performance or use of the Product. Motorola’s warranties apply only to a Product that is manufactured by
Motorola and identified by Motorola owned trademark, trade name or product identification logos affixed to the
Product. Motorola does not warrant to you, the end user, or to anyone else that the Software will perform error
free or without bugs.
MOTOROLA IS NOT RESPONSIBLE FOR, AND PROVIDES “AS IS” ANY SOFTWARE SUPPLIED BY 3RD
PARTIES. EXCEPT AS EXPRESSLY STATED IN THIS SECTION (“WARRANTY INFORMATION”), THERE ARE
NO WARRANTIES OF ANY KIND RELATING TO THE PRODUCT, EXPRESS, IMPLIED OR STATUTORY,
INCLUDING BUT NOT LIMITED TO IMPLIED WARRANTIES OF MERCHANTABILITY, FITNESS FOR A
PARTICULAR PURPOSE, OR THE WARRANTY AGAINST INFRINGEMENT PROVIDED IN THE UNIFORM
COMMERCIAL CODE. Some states do not allow for the exclusion of implied warranties, so the above
exclusion may not apply to you.
What additional provisions should I be aware of? Because it is impossible for Motorola to know the purposes
for which you acquired this Product or the uses to which you will put this Product, you assume full
responsibility for the selection of the Product for its installation and use. While every reasonable effort has
been made to insure that you will receive a Product that you can use and enjoy, Motorola does not warrant that
the functions of the Product will meet your requirements or that the operation of the Product will be
uninterrupted or error-free. MOTOROLA IS NOT RESPONSIBLE FOR PROBLEMS OR DAMAGE CAUSED BY
THE INTERACTION OF THE PRODUCT WITH ANY OTHER SOFTWARE OR HARDWARE. ALL WARRANTIES
ARE VOID IF THE PRODUCT IS OPENED, ALTERED, AND/OR DAMAGED.
DRAFT
B
SBG6782 DOCSIS 3.0 Wireless Gateway • User Guide 14
589054-001-a
THESE ARE YOUR SOLE AND EXCLUSIVE REMEDIES for any and all claims that you may have arising out of
or in connection with this Product, whether made or suffered by you or another person and whether based in
contract or tort.
IN NO EVENT SHALL MOTOROLA BE LIABLE TO YOU OR ANY OTHER PARTY FOR ANY DIRECT, INDIRECT,
GENERAL, SPECIAL, INCIDENTAL, CONSEQUENTIAL, EXEMPLARY OR OTHER DAMAGES ARISING OUT
OF THE USE OR INABILITY TO USE THE PRODUCT (INCLUDING, WITHOUT LIMITATION, DAMAGES FOR
LOSS OF BUSINESS PROFITS, BUSINESS INTERRUPTION, LOSS OF INFORMATION OR ANY OTHER
PECUNIARY LOSS), OR FROM ANY BREACH OF WARRANTY, EVEN IF MOTOROLA HAS BEEN ADVISED OF
THE POSSIBILITY OF SUCH DAMAGES. IN NO CASE SHALL MOTOROLA’S LIABILITY EXCEED THE
AMOUNT YOU PAID FOR THE PRODUCT.
These matters are governed by the laws of the Commonwealth of Pennsylvania, without regard to conflict of
laws principles and excluding the provisions of the United Nations Convention on Contracts for the
International Sale of Goods.
Retail Purchasers Only. If you purchased this Product directly from Motorola or from a Motorola authorized
retail reseller, please call the Motorola toll-free number, 1-877-466-8646 for warranty service or technical
support. Technical support charges may apply.
Cable Operator or Service Provider Arrangements. If you did not purchase this Product directly from
Motorola or from a Motorola authorized retail reseller, please contact your Service Provider for technical
support.
DRAFT
Motorola Mobility, LLC
101 Tournament Drive
Horsham, PA 19044 U.S.A.
http://www.motorola.com
589054-001-a 10/2012
DRAFT

Navigation menu
