ASAP Technology LACA071 Wireless Charger User Manual
ASAP Technology(Jiangxi) Co., Ltd. Wireless Charger
User Manual
Ver.00 Rev.06/19/18
Wireless Charging Pad
Model: BWB18WI705
PRODUCT GUIDE
Ver.00 Rev.06/19/18
What is included?
• Wireless Charging Pad
• A 3ft/914mm Micro-USB cable
• A 18W AC QC Adaptor
Specifications
• Wireless Charging Pad
Model
BWB18WI705
Input
Micro-USB, 5V/2A, 9V/1.67A
Output
5W/7.5W/10W
Wireless Charging Pad LED Indicator/Status
LED Indicator
Status
Green
Connected to power, standby for charging.
Or, device is fully charged.
Blue
Charging mobile device
Flashing blue
Foreign object detected
(Remove it before charging)
How to Charge Your Devices
○
1
1, Insert the USB end of cable into power adaptor, and connect Micro-USB end of the cable with the
wireless charger, the green LED indicator lights up after it is connected well.
Ver.00 Rev.06/19/18
○
2
2, Put your mobile phone on the wireless charging pad and ensure its center aligns with the center
of wireless charger.
Note: Using an ultra-thick protective phone case (≥5mm) or a case with a magnetic/iron is not
recommended as it may affect the wireless charging function.
Caution
• Avoid dropping.
• Do not disassemble.
• No metal object between devices and wireless charging pad.
• Keep wireless charging pad away from any liquids or moisture.
• The maximum ambient temperature during use of this product must not exceed 45°C . Do not
place device in fire or other excessively hot environments.
• Only use dry cloth or brush to clean this product.
• Do not use if visible defects are observed on the wireless charging pad.
Fast Wireless Charging
Ver.00 Rev.06/19/18
• This new charger supports 5W and 10W modes on Android phones.
• Experience wireless charging using the Qi wireless standard, which delivers up to 7.5W to your
iPhone.
• Leverages quick-charging speeds with up to 10W of power for newer Samsung flagship phone.
Warning
Any changes or modifications not expressly approved by the party responsible for compliance could void
the user's authority to operate this equipment.
FCC Statements
This device complies with Part 15 of the FCC Rules
Operation is subject to the following two conditions
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received including interference that may cause undesired
operation
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur
in a particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna
• Increase the separation between the equipment and receiver
• Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected
• Consult the dealer or an experienced radio/TV technician for help
Note: The manufacturer is not responsible for any radio or TV interference caused by unauthorized
modifications to this equipment. Such modifications could void the user s authority to operate this
equipment. Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment. The distance between user and products
should be no less than 20cm.
