Yale Real Living™ ZigBee Module
Installation and Programming Instructions
®
Installing the ZigBee Module
It is recommended that lock is programmed through the centralized user interface (PC or
hand-held device) to ensure communication between the lock and the controller unit. The
network controller first needs to be in enrollment or exclusion mode for the lock to be
enrolled or unenrolled from network.
To Enroll the Module:
• Enter the 4-8 digit Master PIN code followed by the key.
• Press the key followed by the key.
• Press the key followed by the key.
To Unenroll the Module:
• Enter the 4-8 digit Master PIN code followed by the key.
• Press the key followed by the key.
• Press the key followed by the key.
Enrolling/Unenrolling the Network Module:
IMPORTANT: the batteries must be removed prior
to removing and/or inserting the network module:
• Remove battery cover.
• Remove batteries.
• Remove and/or insert network module.
• Reinstall batteries.
• Replace cover.
P/N AYR200-ZB-INSTAL-FUL Rev B
![](/img.php?id=2242127&img=bg3.png)
!Warning: Changes or modifications to this device, not expressly approved by Yale Security
Inc. could void the user's authority to operate the equipment.
FCC:
FCC ID: UA4-YRHCPZB0LM
Model: YRMZB1
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment does cause harmful Interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment
should be installed and operated with minimum distance 20cm between the radiator and your body. This transmitter must
not be co-located or operating in conjunction with any other antenna or transmitter.
Industry Canada:
IC: 6982A-YRHCPZB0LM
Model: YRMZB1
Section 7.1.2 of RSS-GEN Under Industry Canada regulations, this radio transmitter may only operate using an antenna of a
type and maximum (or lesser) gain approved for the transmitter by Industry Canada. To reduce potential radio interference to
other users, the antenna type and its gain should be so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not
more than that necessary for successful communication.
En vertu des règlements d'Industrie Canada, cet émetteur radio ne peut fonctionner avec une antenne d'un type et un
maximum (ou moins) approuvés pour gagner de l'émetteur par Industrie Canada. Pour réduire le risque d'interférence aux
autres utilisateurs, le type d'antenne et son gain doivent être choisies de façon que la puissance isotrope rayonnée
équivalente (PIRE) ne dépasse pas ce qui est nécessaire pour une communication réussie.
Section 7.1.3 of RSS-GEN This Device complies with Industry Canada License-exempt RSS standard(s). Operation is
subject to the following two conditions: 1) this device may not cause interference, and 2) this device must accept any
interference, including interference that may cause undesired operation of the device.
Cet appareil est conforme avec Industrie Canada RSS standard exemptes de licence(s). Son fonctionnement est soumis aux
deux conditions suivantes: 1) ce dispositif ne peut causer des interférences, et 2) cet appareil doit accepter toute
interférence, y compris les interférences qui peuvent causer un mauvais fonctionnement du dispositif.
