ASUSTeK Computer GMC-1D EEE STICK User Manual USERS MANUAL
ASUSTeK Computer Inc EEE STICK USERS MANUAL
USERS MANUAL
E3992
Eee Stick
GMC-1
User manual
English
2
Package contents
Check your Eee Stick package for the following items:
Eee Stick contollers USB dongle
Quick start guide Support CD
If any of the above items is damaged or missing,
contact your retailer immediately.
English
3
Knowing your Eee Stick
Front view
Status LED
Control buttons
Top view
MODE button
Control button
Power buttons
Control keypad
Control stick
Control buttons
Wrist strap
Strap lock
English
4
Using your Eee Stick
Installing the batteries
1. Remove the battery cover.
2. Install the batteries into the slots in the correct
orientation.
3. Slide back the battery cover.
+
+
-
-
+
+
-
-
Removing or replacing the batteries
1. Remove the battery cover.
2. Pull the edge of the battery in the right
battery slot until it is released.
3. Follow step 1 and 2 to remove the
battery in the left battery slot.
+
-
-
+
-
English
5
Wearing the wrist straps
To prevent the Eee Stick from dropping while you are playing
games, properly put on the wrist straps to both of your
hands, and then tighten the straps using the strap locks.
Strap locks
Turning on your Eee Stick
1. Connect the USB dongle to your computer.
2. Hold the power buttons on both the
controllers by about 5 seconds until the
LEDs light up.
Ensure that only the LED 1 on
both controllers light up. The LED
on the USB dongle should light
up, too.
English
6
Installing the driver
1. Place the support CD to the optical drive.
2. Click Install GMC driver and applications, and then
follow the onscreen instructions to complete the
installation.
Launching the GMC
After the driver installation is completed, the GMC icon
appears on the Windows® desktop. Double click the icon to
activate the GMC application.
FEDERAL COMMUNICATIONS COMMISSION
INTERFERENCE STATEMENT
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment and receiver.
– Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
– Consult the dealer or an experienced radio/TV technician for help.
CAUTION:
Any changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
"This device complies with Part 15 of the FCC Rules.Operation is subject to the following two
conditions:
(1) this device may not cause harmful interference and(2) this device must accept any
interference received, including interference that may cause undesired operation ."
