J201 User Manual HTML Version

Manual

Asus J201

User Manual

Contents

Welcome 6

Left View 7

Package Contents 7

Overview 8

Features 8

Speciﬁ cations 9

Menu Map 10

Getting Started 13

Inserting the SIM card

and battery 13

Charging the battery 14

Low Battery Indicators 14

Turning the phone on/off 14

Function Keys 15

Unlocking the keypad 16

Standby Mode 16

Using the Menu 17

Text Entry 19

Basics 19

Choosing text entry methods 19

Calls 22

Making a call 22

Making International Calls 22

Answering a Call 22

Answer Mode 22

Canceling an Incoming Call 23

Diverting a Call 23

Redialing a Number 23

Call Logs 23

Returning a Missed Call 23

Call Log Options 24

Deleting Call Logs 24

Call Time/Cost 24

Options During a Call 25

Other call options 25

Phonebook 26

Adding Contacts 26

Adding a New Entry 26

Searching for a Contact 26

Quick Find 26

Search Entry 26

Copying and Moving 27

Deleting Contacts 27

Caller Groups 28

Extra Number 29

Phonebook Settings 29

My vCard 30

Messages 31

SMS 31

Composing an SMS Message 31

Common Words 32

Message Settings 32

SMS Counter 33

MMS 33

Writing an MMS Message 33

Viewing an MMS Message 34

Using Templates 34

Message Settings 34

Chat 36

E-mail 37

Voice Mail 37

Cell Broadcast 38

Input Methods 38

Manner 39

Manner Settings 39

Settings 40

Phone Settings 40

Date/Time 40

Power On/Off Timer 40

Input Method 40

Language 40

Default Encoding 41

Shortcuts 41

Greeting Text 41

Speed Dial 41

Auto Datetime Update 41

Display Settings 42

Themes 42

Wallpaper 42

Sub Wallpaper 42

Screen Saver 43

Power On Animation 43

Power Off Animation 43

Main Idle Screen 43

Tone Settings 44

Call Settings 44

Hide My Number 45

Call Waiting 45

Call Forwarding 45

Call Barring 45

Line Switching 45

Call Time Reminder 46

Call Time Display 46

Auto Redial 46

Closed User Group 46

Call Filter 47

Network Settings 47

Preferred Network 47

Network Selection 47

Band Selection 47

GPRS Connection 47

Bluetooth Settings 48

Power 48

Search Audio Device 48

My Device 48

Bluetooth Settings 48

Disconnect Device 48

Security Settings 49

SIM Lock 49

Phone Lock Code 49

Auto Keypad Lock 49

Fixed Dialing 49

Barred Dialing 50

Change Password 50

Restore Factory Settings 50

Camera 51

Taking Photos 51

Zoom Function 51

Viewing and Managing

Photos 51

Photo Capture Settings 52

Camera Settings 52

Image Settings 52

Effect 52

Add Frame 53

Multi-Capture 53

Capture Timer 53

Self Capture 53

Restore Default 53

Recording Videos 53

Zoom Function 54

Viewing and Managing

Videos 54

Full-Screen Mode 54

Rewind and Fast Forward 54

Video Playback Speed 54

Volume 55

Capturing a Still Photo 55

Video Capture Settings 55

Camcorder Settings 55

Video Settings 55

Effect 56

Restore Default 56

Photo Artist 56

Media Center 58

Audio Player 58

Adding music ﬁ les 58

Editing Music Files 58

FM Radio 59

FM Radio Options 59

Java 60

Java Settings 60

Games 60

Game Setting 61

Melody Composer 61

Tone Settings 61

Organizer 62

Alarm 62

Calendar 62

Tasks List 63

Calculator 63

World Clock 63

Voice Recorder 63

Image editor 64

Stopwatch 64

File Manager 64

Units Converter 65

Currency Exchange 65

Health Manager 65

Network 67

Service Provider Settings 67

WAP 67

Browsing WAP pages 67

Scrolling 67

Viewing Links 67

WAP Settings 67

WAP Push 68

Data Account 68

Appendix 69

Additional Information 69

European Notice 69

RF Exposure Information (SAR) 69

Proper Disposal 70

Welcome

Congratulations on your purchase of an Asus J201 cell phone. The following illustration displays the

features found on the front of your phone.

Receiver

Screen

Up joystick key: Displays the

SMS inbox; scrolls up through

menu items

Right soft key: Displays phone

book when idle; selects right menu

items

Power/end key: Turns power on or

off; ends a call; exits menu

Right joystick key: Displays the

Media Center menu; scrolls right

through menu items

Down joystick key: Displays

your shortcuts menu; scrolls down

through menu items

Left soft key: Displays the main

menu; selects left menu items

Call key: Answers a call; displays

previously dialed numbers

Left joystick key: Displays the

camera menu; scrolls left through

menu items

Enter key: Displays the main menu;

conﬁ rms selection of a menu item

Joystick: Includes up, down, right,

left keys for on-screen navigation

Welcome

Left View Package Contents

warranty card

User Manual

Quick Start Guide

J201 handset 720 mAh Li-ion

battery

Travel charger

Stereo headset

Handset Manager

manual

Warranty card

User manual

Quick start guide

Handset Manager

CD-ROM

Captures photos

Increases or decreases the volume

for calls, key tones, or playing

media ﬁ les.

USB cable

Handset Manager

Manual

Headset In

Overview

The J201 is a stylish and fashionable new phone from Asus, with all the functions and utilities to

make it a useful tool in today’s mobile world. The J201 comes equipped with a built-in megapixel

camera, MMS/SMS messaging capability, Bluetooth capability, FM radio, organizer, java games,

audio player, WAP, and GPRS. The J201’s audio player enables you to play back your favorite

music.

Features

• Wide variety of calling and messaging functions

• Built-in mega-pixel camera

• Media center with audio player, FM radio receiver, and games for your entertainment

• MMS and SMS messaging capability

• Bluetooth capability

• Personal information organizer with alarm, calendar, calculator and other useful tools to

manage your time

• WAP and GPRS capability to check e-mail or browse web services

Welcome

Speciﬁ cations

System supported GSM900/1800/1900, Class 10

Size 81.5 x 43 x 23.5 mm

Weight 90g

Battery 720 mAh Li-ion

Standby Time 200 ~ 300 hours

Talk Time 2.5 ~ 5 hours

Color Silver, White

Display Main: 1.8-inch, 262K colors, TFT, 128 x 160, Sub: 1.1-inch, 65K colors, CSTN, 96 x 64

Camera 1.3 Megapixel CMOS

Supports video recording

4/6/9 continuous shots

WAP Supports WAP 1.2.1 and WAP 2.0

Java Supports J2ME (CLDC 1.0 + MiDP 2.0)

Built-in Java games

Messaging Supports SMS, EMS, MMS

Ring tone 64 polyphonic ring tones

Supports SMF (standard MIDI format) and MP3

Phone book 300 sets + SIM card

Caller ID with photos

10 sets for speed dialing

Record Record an unlimited number of ﬁ les, up to memory capacity

Calendar 100 Sets

Internal Memory 128MB

PIM tool Alarm, Calendar, Tasks List, Calculator, World Clock, Voice Recorder, Image Editor,

Stopwatch, etc.

Note: All speciﬁ cations are subject to change without further notice.

Menu Map

Network

• WAP

• Data Account

Messages

• SMS

• MMS

• Chatting Rooms

• Email

• Voice Mail

• Cell Broadcast

• Input Methods

Manner

• General

• Meeting

• Indoor

• Outdoor

• Headset

Settings

• Phone Settings

Date/Time

Power On/Off Timer

Input Method

Language

Default Encoding

Shortcut

Greeting Text

Speed Dial

Auto Datetime Update

LED

• Display Settings

 Themes

 Wallpaper

 Sub Wallpaper

 Screen Saver

 Power On Animation

 Power Off Animation

 Show Date and Time

 Main Idle Screen

 Brightness

 Sub LCD Contrast

 Backlight Timer

• Tone Settings

 Incoming Ringtone

 Alarm Tone

 Power On

 Power Off

 Flip Open

 Flip Close

 Message Tone

 Key Tone

• Call Settings

 Hide My No.

 Call Waiting

 Call Forwarding

 Call Barring

 Line Switch

 Call Time Reminder

 Call Time Display

 Auto Redial

 Closed User Group

 Call Filter

Welcome

Video Settings

Effect

Restore Default

• My Album

• My Video

• Photo Artist

Media Center

• Audio Player

• FM Radio

• Java

Java Settings

Games

• Game Settings

• Melody Composer

• Tone Settings

Organizer

• Alarm

• Calendar

• To Do List

• Calculator

• World Clock

• Sound Recorder

• Image Editor

• Stopwatch

Typical Stopwatch

nWay Stopwatch

• File Manager

• Units Converter

• Currency Converter

• Health Manager

BMI

Menstrual

• Network Settings

Network Selection

Preferred Networks

Band Selection

GPRS Connection

• Bluetooth

Power

Search Audio Device

My Device

Settings

• Security Settings

SIM Lock

Phone Lock

Auto Keypad Lock

Fixed Dial

Barred Dial

Change Password

• Restore Factory Settings

Camera

• Capture

 My Album

 Camera Settings

 Image Settings

 Effect

 Frame

 Multi-Capture

 Capture Timer

 Self Capture

Restore Default

• Video Recorder

My Video

CamCorder Settings

Phone Book

• Quick Search

• Search Entry

• Add

• Copy All

• Delete All

• Delete

• Caller Group

• Extra number

My Phone Number

Service Number

SOS Number

• Settings

Memory Status

Default Storage

Fields

My vCard

Calls

• Missed Calls

• Dialed Calls

• Received Calls

• Delete Call Log

• Call Time

• Call Cost

• SMS Counter

• GPRS Counter

Getting Started

Inserting the SIM card and

battery

When you register with a service provider, you

receive a SIM card (Subscriber Identity Module

card). Your phone must have a SIM card in

order to make calls. The SIM card is a computer

chip that contains your phone number,

phonebook information, and service provider

information. Handle it with care and do not bend

it or expose it to static electricity or dirt. Be sure

the power to your phone is off before you insert

your SIM card.

The SIM card slot is situated underneath the

battery. To insert the card, follow these steps:

3. Insert the SIM card into

the holder with the correct

orientation. The gold

contacts of the SIM card

should face down.

1. Press the back cover

and slide the cover off to

remove it.

2. Remove the battery. The

battery compartment has

a notch at the top to make

it easier to grasp and

remove it.

4. Place the battery back into

the battery compartment

noting the correct polarity.

5. Replace the battery cover.

Place the back cover

against the phone case,

then slide it upwards to

lock into place.

Caution:

• Use only the battery recommended by the

manufacturer. Using an incompatible battery with the

phone may cause risk of an explosion.

• Dispose of the used batteries as instructed by

the manufacturer or ask your local authorities for

assistance.

Turning the phone on/off

To turn the phone on, do the following:

1. Hold down the power/end key until the

screen lights up.

2. If needed, enter your SIM card PIN code

and press the Enter key.

To turn the phone off, do the following:

• Press the power/end key and hold until

the phone shuts down.

Note: If you set an alarm using the Organizer menu and turn

off the phone, the phone will turn itself on when the alarm is

activated. After you disable the alarm, the phone prompts you if

you want to keep the phone turned on or off. See the Organizer

section for details about setting an alarm.

Charging the battery

1. Connect the charger plug to a power

outlet.

2. Connect the charger to the socket at the

bottom of the phone. The connector can

only be inserted one way.

3. The phone will be turned on and charge

the battery.

Note: If the battery has been deeply discharged, it may take

several minutes before the phone is turned on by the charger.

Low Battery Indicators

The battery indicator in the upper right corner of

the screen indicates how much charge remains

in the battery. As additional reminders, when the

battery is low, the phone emits a double beep.

The message “battery low” also appears on the

screen.

Getting Started

Call key

• Press after dialing or answer calls.

• Press to open Call Logs and press

again to redial the last number

called.

Function Keys

The following table lists the phone keys and

their functions.

Power/end key

• Hold to turn the phone on or off.

• Press to stop an incoming call or

cancel a call you are dialing.

• Press to exit a menu or submenu.

Left soft key

• Press to display the menu.

• Press to perform the function

currently displayed in the lower left

corner of the screen.

• Press to move left while navigating

menus.

Right soft key

• Press to view phone book when

the phone is in idle mode.

• Press to perform the function

currently displayed in the lower

right corner of the screen.

• Press to move right while

navigating menus.

Up joystick key

• Press to scroll up through menu

items.

• Press to display the SMS inbox when

the phone is in standby mode

Down joystick key

• Press to scroll down through menu

items.

• Press to display a list of your

shortcuts when the phone is in

standby mode.

Left joystick key

• Press to scroll left through menu

items.

• Press to display the Camera menu

when the phone is in standby mode.

Right joystick key

• Press to scroll right through menu

items.

• Press to display the Media Center

menu when the phone is in

standby mode.

Enter key

• Press to display the main menu.

• Press to conﬁ rm selection of a menu

item when the phone is in

standby mode.

Standby Mode

When your phone is on, but not in use, it is in

standby mode. During standby mode, the upper

part of the display screen shows various icons.

Vertical bars indicate the strength of

the GSM network signal. Four bars

indicates that your current position has

the best reception.

The date and time is displayed at the lower

center of the screen. Beneath the date and time

are Menu in the left corner and Name in the

right corner. Press the left soft key to view the

main menu, and the right soft key to view the

phone book.

The Standby screen icons are as follows:

Line 1 or line 2 is selected for calls.

Indicates the ring mode selected for

the phone:

Ring Only

Vibrate

Vibrate and Ring

Vibrate, then Ring

Lights only

Unlocking the keypad

The keypad of the phone can be locked

automatically after a speciﬁ c time interval to

prevent tampering or accidental pressing of any

buttons. Refer to Security Setup in the Settings

section to learn how to lock the keypad.

To unlock the keypad, do the following:

1. The screen shows Unlock in the lower

right corner of the screen. Select this

option by pressing the right soft key which

is just under the word Unlock on the

screen.

2. Press the #key on the keypad to unlock

the keypad as prompted on the screen.

The keypad is then unlocked.

Getting Started

A text message has been received (this

icon ﬂ ashes if the SMS memory is full).

Phone is using GPRS network.

Phone is in roaming mode.

Alarm has been set.

Indicates a missed call.

Call divert is enabled.

Indicates battery charge status.

Using the Menu

Follow these tips to navigate through the menu

and menu options.

• To view the menu, press the left soft key

or the Enter key.

• Use the up, down, left, and right joystick

keys to move through the various menu

items.

• The lower left corner of the screen

displays the name of the menu item

currently selected while the lower right

corner displays Back. Press the left soft

key (situated under the name of the

menu item) to select the menu item. Press

the right soft key which is situated under

Back to exit the menu.

• Each menu item also displays a small

number beneath it. You can also press the

number corresponding to a menu item, on

the keypad to select the item.

• To quickly exit from the menu, press the

Power/End key.

• Use the joystick keys to select the

Bluetooth handset is connecting.

Manner: Enables you to select and

customize the phone settings including

the ring tone, volume, ring type, and

answer mode.

Settings: Lets you adjust phone

settings such as call settings, themes,

shortcuts, network settings, and

security settings. You can also restore

all settings to their factory default from

this menu.

Camera: Enables you to take pictures

as well as record video with your

phone. You can also access all your

pictures and videos from this menu

item.

Media Center: Consists of an audio

player, FM radio, games, and a

melody composer.

Organizer: Contains useful tools

such as an alarm, a calendar for

scheduling appointments, a to do

list, and a simple calculator. You

can also record memos, edit simple

images, manage all your data using

a ﬁ le manager, or convert units or

currency

Phonebook: Enables you to manage

names and telephone numbers for

easy access and caller recognition.

submenu items and options. The right

and left soft keys can also be used for

selecting various options in submenus.

For example, to view missed calls, do the

following:

1.Use the joystick keys to select Calls from

the main menu.

2.Press the left soft key to conﬁ rm the

selection. The Calls submenu opens.

3.Press the left soft key to select the

Missed Calls option. A list of missed calls

opens.

The following table provides a list of all the main

menu items:

Network: Enables you to specify the

WAP and data settings and set up

GSM and GPRS settings. Enables

access to the internet and to STK SIM

card services.

Messages: Gives you access to

messages received. Compose and

send text (SMS) and multimedia (MMS)

messages here. You can also check

email, chat, and broadcast a message

using this menu.

Calls: Stores information about calls

made, received, and missed.

Getting Started

Text Entry

When you add names to your phone book, send

a text message, or use your WAP browser, you

need to enter text. Your cell phone has several

text entry methods. You can enter letters

individually or with predictive text entry, which

helps you complete words as you enter them.

You can enter letters in upper case, lower case,

or both, type simpliﬁ ed or traditional Chinese

characters, or insert symbols.

Basics

• Use the alphanumeric keypad to enter

letters and numbers. Each key is assigned

multiple characters.

• Select Clear, in the lower right corner of

the screen, to delete a letter if you make a

mistake.

• To enter spaces between words, press the

0 key, this will open the symbol table,

and you can choose the 9space symbol.

Press the enter key or press the left soft

key to select and enter a space.

You can also view, select, and enter other

symbols by pressing the 0 key.

Key Assigned Characters

1 . , - ? ! ‘ @ : # $ / _ 1

A B C 2

D E F 3

G H I 4

J K L 5

M N O 6

P Q R S 7

T U V 8

W X Y Z 9

0, opens symbol table

Choosing text entry methods

From any text entry screen, such as a text

message window, select Options > Input

Method. Select ABC Input (the default is

capitalised ABC; press “*” to switch between

upper case ABC and lower case abc) for

entering letters one at a time. Select Smart

Abc (the default is Abc; press “*” to switch

between lower and upper case inputs) to let the

phone predict the words you are typing, use the

up and down joystick key to select the predicted

words.

Multitap text entry

Multitap text entry enables you to enter

individual letters one by one. This is ideal for

The following table lists the characters assigned

to the keys on the keypad:

Whenever you press a key, a list of possible

characters or character combinations is

created. To enter text, use the up and down

joystick keys to ﬁ nd the character combination

you want. Press the right joystick key to

proceed entering the next character. If you

make a mistake, press Clear.

Here is an example of how to enter the word

“baby” using smart text entry.

1.First press the

key. The letter a

appears on the screen.

2.Press the

key again quickly to go

to the next suggestion which is ba. If

you press the up/down joystick keys, the

phone scrolls through all possible two-

letter combinations of the letters a,b, and

3.Press the

key again quickly to display

three-letter combinations of the letters a,

b, and c.

4.Press the up/down joystick keys to scroll

through the possible words. When you

see the bab combination, press the right

joystick key to proceed to the next letter.

5.Press the

key and the letter x

appears. Press the up/down joystick keys

to scroll through letter options and

select y.

6.Press Option > Done when ﬁ nished.

Note: For smart text entry to work properly, ensure the

language settings in your phone match the language you

want to type in. For setting language, see Phone Setup under

Settings.

adding a phonebook entry or entering a WAP

address.

When you press a key, the characters assigned

to the key appear in the lower center of the

screen. Press the key repeatedly to scroll

through these characters. Pause for a moment

and the selected letter appears on the screen.

For practice, try entering text into a text

message (SMS) as follows:

From the menu, go to Messages > SMS >

Write Message. Before entering text, ﬁ rst make

sure that the entry method is set to multitap.

Press Option > Input Method and select ABC

Input. To enter the words “my phone” into the

text entry area, follow these steps:

1.Press the

key to select m.

2.Press the

key three times to select y.

3.Press the right joystick key to enter a

space.

4.Press

to enter p, then press

two

times to enter h. Continue in this fashion

until the word “phone” is entered.

Smart text entry

Smart text entry is a predictive text entry

method. It uses a built-in dictionary to predict

the word you are typing. You can choose the

correct word by pressing the keys repetitively

and scrolling through the words suggested

by the phone. By reducing the number of

keystrokes, the smart text entry method helps

some users to type messages more quickly.

Getting Started

Numeric text entry

Numeric text entry allows you to create a text

message composed of numbers. To use this

method, select Option > Input Method and

then select Numeric. Now you can directly

input the numbers using the keypad.

Symbols text entry

With this method, you can enter various types

of symbols. Select Option > Input Method >

Insert Symbols. A list of symbols is displayed.

Use the joystick keys to select the desired

symbol and select OK when done. You can

also press the “0” key as a shortcut to open the

symbol table.

Answering a Call

When you receive a call, the phone alerts

you by sounding the ring tone and vibration

according to the speciﬁ ed ring tone and

vibration settings. To answer the call, do the

following:

1. Press the Call key to answer the call.

2. Press the Power/end key to end the

call and disconnect.

Alternately, select Option > Answer to answer

the call.

Answer Mode

The default setting for the phone is to answer

when you press the Call key. However, you

can also set the phone to pick up by pressing

any key. To enable the phone to answer a call

by pressing any key, select Manner and then

choose the manner setting that you want.

For example, if you select General, then

choose Personalize > Answer Mode > Any

Key. Set the Any Key option to On to enable

the setting.

Remember to Activate the manner setting to

make sure that the answer mode is set.

Calls

Making a call

Follow these steps to place a call:

1.Enter the number you wish to dial using

the keypad. If you make a mistake, select

Clear to delete at any time. The right soft

key is just under the word Clear on

the lower right screen; use this key to clear

a number.

2.Press the Power/end key to cancel

the call and return to standby mode.

Alternately, select Abort using the right

soft key to cancel the call.

3.Press the Call key to connect the call

after you ﬁ nish dialing the number.

4.Press the Power/end key to disconnect

the call.

Making International Calls

To dial an international call, do the following:

1. First enter a + by holding down the * key.

2. After the +, enter the international

access code for the country you wish to

dial, followed by the telephone number

including the area code.

Calls

Canceling an Incoming Call

If you would like to cancel an incoming call,

press the Power/end key. Alternately, you

can press the right soft key to select the

Reject option to reject the call. Depending

on your service provider, the caller may be

transferred to your voice mail or may hear a

busy signal.

Diverting a Call

If you want to divert an incoming call to another

number, do the following:

1.When you receive the call, press Option

and then select the Deﬂ ect item.

2.Enter the phone number to which you

want to divert the call using the keypad.

Alternately, select Search using the left

soft key and then browse through the

phone book to select a number.

3.Select OK when done.

Redialing a Number

The phone provides a quick method to redial

a number that has been dialed previously. To

redial a number, do the following:

1. Press the Call key. A list of numbers

dialed previously appears, with the last

number dialed at the beginning of the list.

2. Select the number you wish to dial and

press the Call key to dial the number.

Dialed numbers can also be accessed from

Calls > Dialed Calls.

Call Logs

Call logs consist of information about missed,

dialed, and received calls. To view lists of

missed, dialed calls or received calls, select

Calls from the main menu. Then select Missed

Calls, Dialed Calls, or Received Calls to view

the type of calls you require. The number of

calls in a list is limited to 20 entries. Older

calls are dropped from the list when the limit is

reached. Most recent calls appear ﬁ rst in a list.

Returning a Missed Call

If you have missed a call, a message appears

on your standby screen to tell you a call was

missed. Select Read to see the most recent

missed calls. To view a complete list of missed

calls, do the following:

1.Select Calls > Missed Calls. A list of

missed calls is displayed.

2.Scroll through the list and select the

desired call. Press the Call key to call

the number.

To view additional information, select a missed

call number from the list and select OK. The

date, time, phone number of the calling party

as well as the number of times the call was

received is displayed. To call the number, press

the Call key. You may also select Option >

Dial to call the number.

To dial a number from the received or dialed

call logs, follow the same procedure as for

returning a missed call.

Call Log Options

While viewing a number from the dialed,

received or missed call logs, you can select

Option to view other functions as follows:

• Delete: Deletes the number from the

list. Deleting can create space for other

numbers.

• Save to Phone book: Adds the number to

the phonebook.

• Dial: Calls the selected number.

• Edit: Modiﬁ es the number. This may

be useful for adding an area code, for

example. Modify the number and then

select Save to save the number to your

phone book.

Deleting Call Logs

To delete call logs, do the following:

1.Select Calls from the main menu and then

select Delete Call Log.

2.Select from one of the following options:

Missed Calls

Dialed Calls

Received Calls

Delete All

Call Time/Cost

Depending on the type of service package you

have, you may pay according to the length of

your calls. Some users like to monitor the length

of their calls. Your phone offers a convenient

and accurate way to keep track of length and

costs of calls using Call Time and Call Cost.

Select Calls > Call Time to see the various

call time options. Under Last Duration you can

view the call duration for the last call made,

Dialed Calls displays the total dialing time, and

Answered Calls displays the total answering

time. You can also reset the timers using the

Clear Counters option.

Select Calls > Call Costs to calculate your

phone bill. This feature requires the phone PIN

numbers provided by your service provider.

Use the Call Costs’ Limit and Price Per Unit

options to set the call rates. Select the Last

Call Cost and All Calls’ Cost options to view

the call costs. Reset the call costs using the

Clear Counters option.

You can even set a limit for call length and have

a tone sound to remind you that the time limit

Calls

has been reached. To do this, go to Settings

> Call Setup > Call Time Reminder. This is

a reminder function only, and does not close a

call. You can specify a single reminder within an

interval of 3000 seconds or a periodic reminder

for a period between 30 ~ 60 seconds.

To view the call time during a phone call, select

Settings > Call > Call Time Display and set it

to On.

Options During a Call

When a call is in progress, you have the

following options available:

• Hold / Retrieve: Puts a current call on

hold or retrieves a call on hold.

• End: Ends a call.

• New Call: Places a new call.

• Phone Book: Displays the phone book

menu. You can use this function to check a

contact phone number during a call.

• SMS: Displays the messages menu. This

is convenient in loud speaker mode if you

want to send an SMS during a call.

• Sound Recorder: Starts recording the

conversation. To stop recording, select

Stop.

• Mute: Mutes a call.

• DTMF: Allows the recipient to hear key

press tones.

• H-Free: Switches to hands-free

(loudspeaker) mode.

Other call options

There are other advanced call features in your

phone, found in the Settings > Call submenu.

There are features for call waiting, to show or

hide your number when making calls, control

the time of calls, conveniently redial numbers,

or select a line.

These features are discussed in the “Call

Settings” section of the Settings chapter in this

manual.

Phonebook

Adding Contacts

Read this section to learn how to add new

contacts to your phonebook. You can enter the

Phonebook menu through the general menu

or by pressing the right soft key in Idle Mode.

When entering the Phonebook over the menu,

you can choose from the different options; if you

enter over the right soft key in Idle Mode, you

are sent directly to the list of contacts. Here,

you can make a call using the Call key, or

use the options View, Edit, Delete, Copy, Move

and Send vCards for single contacts.

Adding a New Entry

Use the Add function to add a new contact to

your phonebook. Follow these steps to add a

new entry:

1. From the main menu, select Phonebook

> Add.

2. Select the storage location. Select SIM or

Handset then press the enter key.

NOTE: If you choose to add the new entry to the phone, it will

not appear in the phonebook if you transfer your SIM card to

another phone. If you choose to add the new entry to the SIM

card, you can add only a name and a number.

3. Enter a name and number using the

keypad. If you are adding the new entry

to the phone, you can also add a home

number, company name, e-mail address,

ofﬁ ce number, fax number, an associated

sound or picture stored in the phone

memory, and put the contact in a caller

group.

Searching for a Contact

Read this section to learn how to search for

contacts in your phonebook.

Quick Find

Follow these steps to perform a Quick Find

search:

1. From the main menu, select Phonebook

> Quick Find.

A list of all the contacts in your phonebook

is displayed in alphabetical order.

2. Use the joystick to highlight a contact

3. Press the Call key to call the contact,

or the left soft key to display options

for that contact.

4. Press the right soft key to return to

the previous screen.

Search Entry

Use the Search Entry function to search for

a speciﬁ c entry. Follow these steps to use the

search entry function:

1. From the main menu, select Phonebook

> Search Entry.

Phonebook

The data entry screen opens.

2. Enter a search term using the keypad.

You don’t need to type a whole word. For

instance, if you are looking for the entry

“ofﬁ ce,” you may want to type simply “off.”

3. Press the Enter key.

4. Press the Enter key again to start the

search, or you can also change the text

input method and start the search again.

All entries that satisfy your search criteria

are displayed.

Copying and Moving

You can move contacts from your SIM card to

phone memory or from phone memory to SIM

card.

Follow these steps to move contacts:

1. From the main menu, select Phonebook

> Copy All.

2. Use the joystick to highlight From SIM to

copy contacts from the SIM card, or From

Handset to copy contacts from the phone.

3. Press the Enter key to select the option.

4. Press the left soft key to conﬁ rm, or

the right soft key to abort.

When all contacts are copied, a “Done”

message appears on-screen.

1. From Idle menu, press the right soft key

, then Option > Copy and choose to

SIM or to Handset.

2. From Idle menu, press the right soft key

, then Option > Move and conﬁ rm.

Deleting Contacts

You can delete individual contacts using the

Delete function. To delete individual contacts:

1. From the main menu, select Phonebook

> Delete.

The list of contacts in the phonebook

appears.

2 Select a contact to delete, then select

Delete.

3. A conﬁ rmation message appears, “Delete

it?” Select Yes to conﬁ rm.

You can delete all contacts from the handset or

SIM using the Delete All function. To delete all

contacts:

1. From the main menu, select Phonebook

> Delete All.

2. You are prompted to select a location.

Select From SIM to delete all contacts

stored on the SIM.

Select From Phone to delete all contacts

stored in the phone.

NOTE: When you attempt to delete all the contacts from the

SIM or phone, you are asked for a password. The default

password is 1234. See the “Security Settings” section in chapter

6 for more information on passwords.

1. From Idle menu, press the right soft key

, then Option > Delete and conﬁ rm.

Caller Groups

You can separate contacts into groups to

identify them. There are ﬁ ve caller groups:

Friends, Family, VIP, Business, and Others.

You can change the name of any caller group.

You can add contacts from your phonebook to

a caller group and you can deﬁ ne ringtones,

pictures, etc.

To change the name of a caller group:

1. From the main menu, select Phonebook

> Caller Group.

2. Use the joystick to highlight a caller group,

then press the enter key.

3. Press the enter key to select the current

group name at the top of the list.

4. Use the keypad to enter a new name.

5. Use the right soft key to clear

characters.

6. Press the left soft key when the new

name is complete. Press it a second time

to conﬁ rm. You can also change the input

method here.

To change the ringtone:

1. Select the caller group to modify as

described in the previous procedures.

2. Use the joystick to select the ringtone

option (second in the list).

3. Use the right and left joystick option to

cycle through the available ringtones.

Each tone is played as it is displayed.

The chosen ringtone will sound when

someone from the current caller group

calls the phone.

To change the picture:

1. Select the caller group to modify as

described in the previous procedures.

2. Use the joystick to select the picture option

(third in the list).

3. Use the right and left joystick option to

cycle through the picture options.

This option determines which picture is

displayed when someone from the chosen

caller group calls the phone.

NOTE: If you select a picture from ﬁ le, it must be smaller than

20K in size. You can read more about storing images in your

camera memory in the camera section, section 7.

To change the colour pattern:

1. Select the caller group to modify as

described in the previous procedures.

2. Use the joystick to select the colour option

(fourth in the list).

3. Use the right and left joystick option to

cycle through the colour options.

This option determines which colour

pattern is displayed when someone from

the chosen caller group calls the phone.

To add or delete members from a caller

group:

1. Select the caller group to modify as

described in the previous procedures.

2. Use the joystick to select the member list

option (last in the list).

3. Press the center joystick button to display

the member list.

Phonebook

4. Use the joystick to highlight a member of

the list to modify.

5. Press the left soft key to enter the

options menu.

6. Use the joystick to highlight the Add or

Delete option.

7. Press the left soft key to conﬁ rm.

NOTE: If you selected the Delete option, you must press the

left function key again to conﬁ rm. If you selected the Add

option, you must highlight a new member from the displayed list

and press the Enter key to conﬁ rm.

Extra Number

The extra number setting is used to store

special numbers. You can store your own

number here, a service dial number, and an

SOS number.

NOTE: Some of these functions may not be supported by your

service provider. The service dial number and SOS number are

not conﬁ gurable and are set by your service provider.

To add extra numbers:

1. From the main menu, select Phonebook

> Extra Number.

2. Select My Phone Number to store your

own number.

Select Service Number to store a service

number.

Select SOS Number to store an SOS

number.

3. Select an entry from the list, and a text-

entry screen appears. Enter the desired

number.

You can input both text and numbers. Use

the left soft key to select Option if you

need to change the input method.

When you have ﬁ nished typing, press the

Enter key to conﬁ rm.

4. To edit or delete previous entries, select

an entry, then the left soft key to

select Option.

NOTE: There are two lines under My Phone Number, so when

line1 is in use, My Phone Number will display the number

stored at line 1. When the user switches to line 2, My Phone

Number will display another number.

Line Switching can be done by going to Settings > Call

settings > Line Switching.

If users want to show the Owner Number of their phone to

callers, they should go to Settings > Display Settings > Show

Owner Number.

Phonebook Settings

The phonebook settings menu enables you to

view memory status, set the preferred storage

media, determine which ﬁ elds appear in the

phonebook, edit and send a vCard.

To view memory status:

1. From the main menu, select Phonebook

> Settings > Memory Status.

2. Select OK to display memory status.

To set the preferred storage:

1. From the main menu, select Phonebook

> Settings > Default Storage.

2. Highlight the preferred storage location

then select OK to conﬁ rm.

The phonebook ﬁ elds include additional contact

information, such as Fax Number, E-Mail

Address, Incoming Ringtone, etc. You can

choose to deactivate these ﬁ elds for all contacts

if this simpliﬁ es the phonebook for you. You can

later reactivate the ﬁ elds if desired.

To edit the phonebook ﬁ elds:

1. From the main menu, select Phonebook

> Settings > Fields.

A list of ﬁ elds is displayed.

2. Highlight a ﬁ eld and press the left soft key

to deactivate or activate a ﬁ eld.

My vCard

A vCard is a virtual calling card that you can

send to people. It can contain your name,

number, home number, company name, e-mail

address, ofﬁ ce number, and fax number.

To edit and send your vCard:

1. From the main menu, select Phonebook

> Settings > My vCard.

2. Select the Edit or Send to option.

The edit option enables you to ﬁ ll in all

the ﬁ elds. The send option enables you

to send by SMS, MMS, or save to a ﬁ le.

See the next chapter for more information

about sending MMS and SMS messages.

Messages

Read this section to learn how to use SMS, and

MMS messaging features of your new phone.

You can even send e-mail and use text chat.

This section also covers voice mail features,

broadcasting messages, and setting the

preferred text input.

SMS

An SMS message is a simple text message.

SMS messages can be sent and received with

your phone.

Composing an SMS Message

To compose an SMS message:

1. From the main menu, select Messages >

SMS > Write Message.

2. Enter your text message using the

alphanumeric keypad. See the section

“Text Entry,” in the Getting Started chapter

for more information about how to type

your message.

3. Press the left soft key to display the

Option menu.

The Option menu includes the following:

• Done

• Common Words

• Insert Object

• Text Format

• Input Method

A template is predeﬁ ned section of text that you

can use in any SMS message. Inserted objects

can include a picture, an animation, or a sound.

Some phones may not be able to receive SMS

messages that contain anything other than text.

Use the Text Format option to adjust the size

and style of the text.

1. Highlight an option and select OK.

2. When your message is complete, select

the Done option.

The send options menu is displayed.

3. Use the joystick to select a send option:

• Send Only

• Save and Send

• Save

• Send to Many

• Send by Group

The send options require that you type in a

telephone number or press the left soft key

to search the phonebook.

The Send to Many option lets you send to up to

10 recipients.

The Send by Group option lets you send to an

entire group. Choose a group using the joystick

and press the left soft key to send.

The Save option saves a copy of the message

in the outbox which can be recovered later for

editing or sending.

Common Words

The common words feature contains common

text phrase that you can conveniently enter

without having to type the whole phrase. There

are 10 preset common words phrase which you

can use or edit.To add a common words phrase

to an SMS:

1. Begin an SMS message as described

in the section “Composing an SMS

Message” in this chapter.

2. Before typing any text, press the left soft

key to display the Option menu.

3. Use the joystick to highlight the Common

Word option and press the enter key to

conﬁ rm.

4. Use the joystick to highlight the common

words phrase you would like to add, then

press the enter key to conﬁ rm.

The text from the template appears in the

message. You can add to the text, or edit

the text before sending or saving the

message.

5. Send or save the message as normal.

To edit a common words phrase:

1. From the main screen, select Messages >

SMS > Common Words.

The common words list is displayed.

2. Use the joystick to highlight a common

words phrase to edit, then press the enter

key to conﬁ rm.

3. Use the joystick to highlight the Edit or

Delete option, then press the enter key to

conﬁ rm.

The Edit option displays existing common

words phrases and gives you the option to

change them. The Delete option deletes the

entry entirely.

Message Settings

The message settings menu enables you to

conﬁ gure your SMS message settings. Up

to three proﬁ les can be deﬁ ned that contain

message center number, valid period for each

message and message type. You can also

conﬁ gure common settings which includes a

delivery report and reply path. You can also

view memory status, set the preferred storage

medium, and set the preferred bearer.

To conﬁ gure common settings:

1. From the main menu, select Messages >

SMS > Settings > Common Settings.

2. Select Delivery Report or Reply Path

options then press the Enter key to enable

or disable the feature.

To check the memory status:

1. From the main menu, select Messages >

SMS > Settings > Memory Status.

2. Select OK to display the Memory Status.

To set the preferred outbox storage option:

1. From the main menu, select Messages >

SMS > Settings > Default Outbox.

2. Select SIM or Handset.

Messages

A small pop out box tells you the

percentage of storage space already used

in each location.

The preferred bearer option sets the type of

network you prefer. When there is a choice of

a GSM or GPRS network, the phone then uses

the network of your preference.

To set the preferred bearer option:

1. From the main menu, select Messages >

SMS > Settings > Preferred Bearer.

2. Select the network option you prefer.

Select Pref GMS or Pref GPRS to set a

preference, or GPRS Only or GMS only if

you want to use only one kind of network.

Press the Enter key to conﬁ rm your

selection.

SMS Counter

There is an SMS counter which can keep a

log of the number of SMS messages sent and

received.

To view the SMS counter:

1. From the main menu, select Calls > SMS

Counter.

2. Use the joystick to highlight the Sent or

Received option.

The number of sent or received messages

is displayed.

MMS

MMS messages are like SMS messages but

they can also contain sounds and pictures.

Writing an MMS Message

Writing an MMS message is not very different

from creating an SMS message. MMS

messages are made up of slides. Each slide

contains a combination of text, images, or

audio.

To create an MMS message:

1. From the main menu, select Messages >

MMS > Edit MMS.

2. Select a To ﬁ eld then select to conﬁ rm.

3. Use the joystick to highlight the Add

Number or Add E-mail option then press

the enter key to conﬁ rm.

You can either add an e-mail address or

number manually, or press the left soft key

to access the phonebook.

4. Press the left soft key when you have

entered the recipient(s).

5. Press the right soft key to return to the

recipient list. Press again to return to the

main menu.

6. Use the joystick to highlight and select

Cc, and Bcc recipients. Enter recipients

in these ﬁ elds in the same way as the To

ﬁ eld.

7. Use the joystick to highlight the Subject

ﬁ eld then press the enter key to conﬁ rm.

8. Use the keypad to enter a subject.

To create a slide:

1. To create a slide, use the joystick to

highlight the Edit Content ﬁ eld then press

the enter key to conﬁ rm.

You can enter text in the same way as you

would for an SMS message.

2. Press the left soft key to display the

Option menu.

3. Use the joystick to highlight an option and

press the center joystick button to conﬁ rm.

You can add an image, add audio, attach

a ﬁ le, or change the input method.

4. When your message is complete, highlight

Insert New Slide to add more slides or

Done to ﬁ nish, then press the enter key to

conﬁ rm.

You have just created one slide. Repeat

the process to add more slides.

To send the MMS message:

1. Press the right soft key to display the

Send menu.

2. Use the joystick to highlight a Send option,

then press the enter key to conﬁ rm.

Viewing an MMS Message

Some MMS messages are longer than the

screen. To move up or down a page, press and

hold the up or down joystick key.

Using Templates

There are templates stored on your phone

which contain text, images, and sound. You can

create MMS messages based on templates

stored on your phone. You can also edit any of

the existing templates.

To use a template:

1. From the main menu, select Messages >

MMS > Templates.

A list of available templates appears.

2. Highlight a template, then select Options.

Select View to preview the template.

Select Properties to view ﬁ elds and the

size of the template.

Select Write Message to send the

message.

3. Edit the To,Cc,Bcc, and Subject ﬁ elds

as described in the previous procedure.

4. Edit the content if required as described in

the previous procedure.

5. Send the completed message as

described in the previous procedure.

Message Settings

The Message Settings menu item helps the

user conﬁ gure various MMS settings for

sending, retrieval, ﬁ lters, proﬁ les and view

message status. The user can do the following

operations:

1. Sending:

• Validity Period - the period a message

is to be kept at MMSC. The choices are

Messages

1 hour, 12 hours, 1 day, 1 week and

maximum. The default value is maximum.

• Delivery Report - users can choose if

they want to receive delivery reports for an

MMS or not. The default value is off.

• Read Report - users can choose if they

want to receive a read report or not. The

read report will report if the recipient read

the MMS message or not, for example: the

receiver might delete the message without

reading. The default value is off.

• Priority - the priority for the MMS

message. The choices are high, normal,

and low. The default value is normal.

• Slide Timing - users can edit the default

slide duration. The range is 1~60.

• Delay Delivery - users can set the delay

in the delivery time for MMSC to send a

message. The choices are Immediate, In

one hour, In 12 hours, and in 24 hours.

The default value is Immediate.

2. Retrieval:

• Home Network - the retrieval method

for a message in a home network.

The choices are Auto Download, Deny

Download, and Manual Download. The

default value is Auto Download.

• Roaming - the retrieval method for

a message in a roaming network. The

choices are As Home (same as home

network), Deny Download, and Manual

Download. The default value is As Home.

• Read Report - users can choose if they

want to send a read report to the sender

or not. The read report will report if the

user read the MMS message or not. The

choices are On Request, Send, and Never

Send. The default value is On Request.

• Delivery Report - users can choose if

they want to send delivery reports to the

sender or not. The delivery report will

report if the user received the MMS or not.

The choices are On and Off. The default

value is On.

3. Filters:

• Anonymous - users can choose if they

want to receive anonymous MMS or not.

The choices are Allow and Reject. The

default value is Allow.

• Max Size (KB) - users can conﬁ gure

the maximum retrieval size of an MMS

message. The range is 1~100. The default

value is 100.

• Advertisement - users can choose if

they want to receive advertisement MMS

or not (based on message class). The

choices are Allow and Reject. The default

value is Allow.

4. Proﬁ les: This option helps the users

to conﬁ gure various servers and proﬁ le

related settings. All the conﬁ gurable items

are grouped into entities. Selecting the

menu item Proﬁ les will show the list of

existing proﬁ les.

Only one proﬁ le can be activated at one

time. The number of proﬁ les can be edited

if the phone is manufacture-deﬁ ned. The

default number is 10. The default six

proﬁ les are the most popular operators’

MMS network settings, eg “fetmms”,

“chtmms”, “twnmms”, “tatmms”, etc.

The handset user can change them as

well. The handset user can change the

following setting of each item:

• Name - to modify the name of a proﬁ le,

select this item, and it takes you to the

editing screen.

• Message Server - to modify the MMSC

url, select this item, and it takes you to the

editing screen.

• Data Account - to modify the setting of

the data account, select this item and it

takes you to the Data Account screen to

choose a GPRS dat account.

• Connection Type - to modify the

connection type. The choices are

Connection-oriented and Connectionless.

• Username - to modify the valid

username of the WAP gateway, select

this item, and it takes you to the editing

screen.

• Password - to modify the password of

the WAP gateway, select this item, and it

takes you to the editing screen.

5. Auto Signature: This option lets users

conﬁ gure their auto signature, and allows

them to switch it on and off. The default

value is Off.

6. Memory Status: This screen lists the

memory status of MMS.

• Usage - current message number/

maximum message number.

• Total - the total space occupied by MMS

messages.

• Free - the space left to store MMS

messages.

To conﬁ gure message settings:

1. From the main menu, select Messages >

MMS > Settings.

2. You can change any setting by highlighting

it with the joystick and then using the

joystick (left and right) to scroll through the

options for each setting.

Chat

You can use your phone to chat with other cell

phone users.

To use the chat function:

1. From the main menu, select Messages >

Chatting Rooms.

2. Use the joystick to highlight a chatroom

from the list, the press the enter key to

conﬁ rm.

3. Press the enter key to display the

chatroom information.

4. Enter a nickname and destination number

if required.

5. Press the left soft key to save your

new settings.

6. Use the joystick key to select the Start

New option, then press the Enter key to

conﬁ rm.

The chat session begins.

Messages

E-mail

You can use the phone to send e-mail

messages. Before you can use the e-mail

feature you must set up an account. Settings

such as incoming and outgoing servers are

entered in e-mail proﬁ les. Contact your service

provider for details about e-mail settings.

To set up an e-mail account:

1. From the main menu, select Messages >

Email > Email Proﬁ le.

A list of e-mail proﬁ les is displayed.

2. Use the joystick to highlight a proﬁ le to

use, then press the enter key to conﬁ rm.

3. Use the joystick button to highlight the

Edit option, then press the enter key to

conﬁ rm.

The proﬁ le menu is displayed. Here you

can conﬁ gure proﬁ le settings, the outgoing

server, the incoming server and your

signature.

4. Use the joystick to highlight the Proﬁ le

Setting option, then press the enter key to

conﬁ rm.

The Proﬁ le Setting menu is displayed.

5. Use the joystick to highlight each ﬁ eld and

press the enter key to change any ﬁ eld.

Once your e-mail proﬁ le is complete, you need

to activate it.

1. From the main menu, select Messages >

Email > Email Proﬁ le.

A list of proﬁ les is displayed.

2. Use the joystick to highlight a proﬁ le to

use, then press the enter key to conﬁ rm.

3. Press the enter key to activate the

selected proﬁ le.

Once your proﬁ le is activated, you can send

and receive e-mail with your phone.

Voice Mail

You can set up two voice mail accounts on your

phone that will take messages for you when

you are not able to answer your phone.

To set up a voice mail server:

1. From the main menu, select Messages >

Voice Mail.

A list of voice mail accounts is displayed.

2. Use the joystick to highlight a voicemail

accounts, then press the enter key to

conﬁ rm.

3. Press the enter key to dial to voice mail.

4. Type in the voice mail number.

You can also edit voice mail details or connect

to a voice mail account here.

Note: Voice mail is a service provider feature. Contact your

service provider for voice mail numbers and settings or other

voice mail assistance.

Cell Broadcast

Use the Broadcast Message option to set

broadcast message parameters.

To set broadcast message parameters:

1. From the main menu, select Messages >

Cell Broadcast.

2. Use the joystick to highlight the Activate

option, then press the enter key to toggle

the setting on or off.

3. Select the Read Topic option then press

the enter key to read stored broadcast

messages.

4. Use the joystick to highlight the

Languages option, then press the enter

key to display the language menu.

Use the joystick to check the language

options that you want to receive.

5. Use the joystick to highlight the Topics

option then press the enter key to conﬁ rm.

6. Use the joystick to select, add, edit, or

delete channels.

Input Methods

The input methods setting lets you deﬁ ne the

default input method when writing messages.

To set the input method:

1. From the main menu, select Messages >

Input Methods.

2. Use the joystick to highlight an input

method, then press the enter key to

conﬁ rm.

Manner

The phone can be set to behave in a number of

manners. Each manner is designed to be used

in a particular environment. For instance, if you

are in a meeting you may want your phone to

alert you silently when a call comes in.

To select a manner:

1. From the main menu, select Manner.

A list of manners appears.

2. Highlight a manner from the list, then

press the enter key to activate the

selected manner.

The available manners are: Normal, Meeting,

Indoor, Outdoor, Headset.

Manner Settings

Each manner can be personalized to suit your

own needs.

To personalize a manner:

1. From the main menu, select Manner >

Option > Personalize.

A list of customizable features is

displayed, including volume, ring mode,

ring tone type, connect notice, answer

mode and more.

2. Select a feature to customize from the list

and press the enter key to conﬁ rm.

The feature submenu is displayed.

For example, for Ring Mode, you can

select Ring Only, Vibrate, Vibrate and

Ring, Vibrate, then Ring, or Light only.

3. Highlight a feature to change from the

submenu and press the enter key to

conﬁ rm the changes.

Settings

Phone Settings

The Phone menu enables you to conﬁ gure

handset features including time and date,

scheduling power on and off, input methods,

language, default encoding type, shortcut,

greeting text, speed dial, automatic update of

date and time, and LED light.

To access the phone setup menu:

From the main menu, select Settings >

Phone Settings.

A list of phone settings is displayed.

Date/Time

The Settings > Phone Settings > Date/Time

option enables you not only to set the time,

but also enables you to set a time zone by

selecting your location and set a format for

displaying dates.

Power On/Off Timer

The phone can be set to turn on or off

automatically. The Settings > Phone Settings

> Power On/Off Timer option enables you to

schedule times to turn power on or off.

Up to four power on / off times can be deﬁ ned.

Highlight a number from the list using the

joystick and press the enter key.

Use the right and left joystick keys to change

settings for each ﬁ eld.

The Status ﬁ eld sets the status of the phone to

On or Off at the time of the scheduled power

on/off. The Power ﬁ eld sets whether the phone

is to turn On or Off. The Time ﬁ eld sets the time

for the power to turn on or off.

In the submenu, use the joystick to move

between ﬁ elds and the center joystick button to

change a setting.

Deﬁ ne the status, enabled or disabled. Deﬁ ne

the event, on or off, and deﬁ ne the time.

Input Method

The Settings > Phone Settings > Input

Method enables you to set the default input

method for entering numbers, or roman

alphabet or Chinese characters.

See the “Text Entry” section of the Getting

Started chapter for details on inputting text.

Language

The Settings > Phone Settings > Language

option enables you to set the default language

used in menus. Select from English, Simpliﬁ ed

Chinese, or Traditional Chinese.

Settings

Default Encoding

The Settings > Phone Settings > Default

Encoding Type option sets default encoding

for Chinese characters. Select from BIG5 or

GB2312.

Shortcuts

You can create a set of ten shortcuts that

access speciﬁ c features directly.

To access the list of shortcuts:

1. The down joystick key has a shortcut

symbol: . Press this key to display the

list of shortcuts.

2. Highlight a shortcut, then press the enter

key to conﬁ rm.

The shortcut is then executed.

You can customize your list of shortcuts.

To edit the shortcut list:

1. From the main menu, select Settings >

Shortcut.

A list of current shortcuts is displayed.

2. Use the joystick to highlight a number

in the shortcut list. You can replace this

number with a different menu item.

3. Press the left soft key to select Set.

A list of available menu items is displayed.

4. Highlight an item from the list using the

joystick and press the enter key to conﬁ rm.

The new item replaces the previous item

on the shortcut list.

Greeting Text

The Settings > Phone Settings > Greeting

Text option sets a short phrase that appears

each time the phone is turned on.

Greeting text can be entered and edited. Set

the status to On if you want the text to appear,

or to Off if you do not want it to appear.

Speed Dial

The Settings > Phone Settings > Speed

Dial option assigns single keys to numbers in

your phone book so that you can quickly and

conveniently dial those numbers.

Number keys 2~9 can be assigned one speed

dial number each. Pressing and holding a key

with an assigned speed dial number calls that

number.

Before using the speed dial function, the Enable

Speed Dial item must be set to On.

Auto Datetime Update

Auto Datetime Update is a network service that

automatically updates the date and time in your

phone when you travel or if daylight savings

time is used in your area.

You can enable Settings > Phone Settings >

Auto datetime update option to take advan-

tage of this service, if offered by your service

provider.

To enable this option, highlight the Auto update

of date and time option and toggle between On

and Off using the right and left joystick keys.

LED

The Settings > Phone Settings > LED option

sets at which events the phone’s LED is turned

on. The options are MTC LED, Event LED,

Charging LED, Low Battery and Normal LED

Press the left soft key to toggle the LED on

or off, and the right soft key to save.

Display Settings

The Settings > Display Settings option

enables you to change wallpaper and sub

wallpaper image, screen saver image, the

power on and power off animations, the main

idle screen, brightness, sub LCD contrast, and

the backlight timer.

Themes

Themes are color schemes that can be set

on your phone. The theme can also be set

to change hourly, daily, weekly, monthly, or

seasonally.

To set a theme:

1. From the main menu, press Settings >

Display Settings > Themes.

A list of themes is displayed.

2. Use the joystick to highlight a theme.

3. Press the left soft key to select

Option.

4. Use the joystick to highlight an option and

press the enter key to conﬁ rm.

The Activate option activates the selected

theme. The Theme Timer option deﬁ nes

how often the theme is updated. The Set

Order option deﬁ nes the order in which the

themes are updated.

Wallpaper

A wallpaper is the image displayed in the

background of your phone. You can choose

between default and custom wallpapers.

To set a wallpaper:

1. From the main menu, press Settings >

Display Settings > Wallpaper.

The choice between default and custom is

displayed.

2. Use the joystick to highlight a choice and

press the left soft key to select it.

3. Use the joystick to highlight a picture and

press the enter key to view it.

4. Press the left soft key to conﬁ rm the

wallpaper, or the right soft key to go

back and choose another.

Sub Wallpaper

A sub wallpaper is the image displayed in the

background of the small screen on your phone.

You can choose between default and custom

sub wallpapers.

To set a sub wallpaper:

1. From the main menu, press Settings >

Display Settings > Sub Wallpaper.

The choice between default and custom is

displayed.

Settings

2. Use the joystick to highlight a choice and

press the left soft key to select it.

3. Use the joystick to highlight a picture and

press the enter key to view it.

4. Press the left soft key to conﬁ rm the

sub wallpaper, or the right soft key to

go back and choose another.

Screen Saver

A screen saver is an image or a video displayed

after you have not done anything with your

phone for some time, to save energy. You

can choose between default and custom

screensavers, and set the idle time after which

the screen saver starts to work.

To set a screen saver:

1. From the main menu, press Settings >

Display Settings > Screen Saver. Use

the right or left joystick key to edit the

screen saver. You can choose Settings

to set the idle time and toggle the on/off

feature, or select to choose a picture or

video to set as your screen saver. If you

choose select, the options default and

custom are displayed.

2. Use the joystick to highlight a choice and

press the left soft key to select it.

3. Use the joystick to highlight a picture and

press the enter key to view it.

4. Press the left soft key to conﬁ rm the

screensaver ﬁ le, or the right soft key

to go back and choose another.

Power On Animation

Here you can choose the animation, video or

picture that is displayed when the phone is

powered on.

To set the Power On Animation:

1. From the main menu, press Settings >

Display Settings > Power On Animation.

The choice between system and custom is

displayed.

2. Use the joystick to highlight a choice and

press the left soft key to select it.

3. Use the joystick to highlight a picture and

press the enter key to view it.

4. Press the left soft key to conﬁ rm the

ﬁ le, or the right soft key to go back

and choose another.

Power Off Animation

Here you can choose the animation, video or

picture that is displayed when the phone is

powered off. See Power On Animation for

details.

Main Idle Screen

Here you can choose to show the date and

time, the owner number, the Operator name

and the manner on the main phone display.

To show date and time on the main phone

display:

Highlight the Show Date and Timer option from

the Display Settings > Main Idle Screen menu

and press the left soft key to toggle the

option On or Off.

To show the phone owner’s number on the

main phone display:

Highlight the Show Owner Number option from

the Display Settings > Main Idle Screen menu

and press the left soft key to toggle the

option On or Off.

To show the operator number on the main

phone display:

Highlight the Show Operator Number option

from the Display Settings > Main Idle Screen

menu and press the left soft key to toggle

the option On or Off.

To show the manner on the main phone display:

Highlight the Show Manner option from the

Display Settings > Main Idle Screen menu

and press the left soft key to toggle the

option On or Off.

Brightness

Here you can choose the brightness level for

the phone’s main screen and sub screen.

Highlight the Brightness option from the

Display Settings menu and press the left soft

key to enter the Brightness settings, then

adjust the brightness level with the left and right

joystick keys and press the left soft key to

save.

Sub LCD Contrast

Here you can choose the contrast level for the

phone’s sub screen.

Highlight the Sub LCD Contrast option from

the Display Settings menu and press the left

soft key to enter the Sub LCD Contrast

settings, then adjust the contrast level manner

with the left and right joystick keys and press

the left soft key to save.

Backlight Timer

Here you can set the timer for the LCD

backlight.

Highlight the Backlight Timer option from the

Display Settings menu and press the left soft

key to enter the Backlight Timer settings.

Choose between four different timer settings

(5 seconds, 15 seconds, 30 seconds and 45

seconds) then press the left soft key to

save.

Tone Settings

The Settings > Tone Settings option enables

you to set different ringtones to several phone

events, such as Incoming Ringtone, Alarm

Tone, Power On, Power Off, Flip Open, Flip

Close, Message Tone and Key Tone.

Highlight the various options from the Tone

Settings menu and press the left soft key

to enter the settings, then choose a ringtone or

midi from the menu that appears, and press the

left soft key to save.

Settings

For some events, the additional option Silent is

also available.

Call Settings

The Call menu contains call features that

control or restrict the calls you make or receive.

There are also features to show or hide your

number when making calls, control the time of

calls, conveniently redial numbers, or select a

line.

Call menu features include Hide My No., Call

Waiting, Call Forwarding, Call Barring, Line

Switching, Call Time Reminder, Call Time

Display, Auto Redial, Closed User Groups, and

Call Filter.

Hide My Number

The Settings > Call Settings > Hide My No.

option enables you to withhold your number, so

that when you call someone, your number is not

shown.

You can choose to activate or deactivate this

option, or let the network set the option.

Call Waiting

If your service provider offers call waiting, you

ﬁ rst need to enable the Settings > Call

Settings > Call Waiting option.

To enable call waiting:

1. Highlight the Call Waiting option from the

Call Settings menu and press the center

joystick button to conﬁ rm.

2. You can choose to Activate, Deactivate, or

Query the current setting.

To use the call waiting feature:

1. When you receive a call during another

call, press the Call key to receive the

second call.

2. Press the Call key to switch back to

the ﬁ rst call or to switch between calls.

Call Forwarding

The Settings > Call Settings > Call

Forwarding option can be accessed from the

Call menu. With call forwarding, you can direct

calls directly to your voice message box when

you are busy and cannot take calls.

You can choose to forward all voice calls,

or forward if unreachable, if calls are not

answered, if busy, or divert all data calls.

Select Cancel to deactivate call forwarding.

Call Barring

Call barring is a service available through your

service provider. This service restricts different

types of incoming and outgoing calls. The

Settings > Call Settings > Call Barring option

enables you to bar outgoing calls, incoming

calls, cancel all bars, or change the barring

password.

Options for Outgoing Calls: All Calls,

International Calls, International Except Home

Options for Incoming Calls: All Calls, When

Roaming

NOTE: A call barring password is required to make changes to

call barring settings. See your service provider if you don’t know

your password.

Line Switching

Depending on your service provider and

SIM card, you may have more than one

line available for use. Although the network

automatically assigns a line to you, you may

also use the Settings > Call Settings > Line

Switching option select a line to use. This

option can be used when line quality differs or

when you have difﬁ culty placing a call because

of busy lines.

To use line switching, select the line switching

option, then press the enter key to toggle

among available lines.

Call Time Reminder

If you want to limit the length of your calls,

use the Settings > Call Settings >Call Time

Reminder option. After the time limit speciﬁ ed,

your phone sounds a reminder for you.

To set a call time reminder:

1. Select Single if you want to use a reminder

signal during your call. Select Periodic if

you would like a repeated reminder during

your calls. Press the enter key.

2. A time ﬁ eld appears. Fill in the number of

seconds after which a reminder should

sound, then select OK.

You can choose to turn the function off, turn

it on to sound once during a call, or turn it on

periodically.

Call Time Display

If you would like to monitor or keep track of the

length of your calls, use the Settings > Call

Settings > Call Time Display option. When

enabled, the screen displays the time length of

your calls.

To enable call time display, select the Call Time

Display option, then press the enter key to

toggle the function On and Off.

NOTE: Select Calls > Call Time to see records of call times.

For more information about call times and costs, refer to the

section “Call Time/Cost” in the Call chapter of this manual.

Auto Redial

When the Settings > Call Settings > Auto

Redial option is enabled, the number of the last

call whose dialing has failed will automatically

be redialed.

To activate the Auto Redial option, select it,

then press the enter key to toggle the function

On or Off.

Closed User Group

A closed user group is a service provided by

some service providers that permits network

access by members of the group only. The

Settings > Call Settings >Closed User

Group option enables you to add closed user

groups, edit existing ones, and activate or

Settings

deactivate them.

To add a closed user group:

1. Highlight the Closed User Group option,

then press enter.

2. A group list appears. Select an Empty slot,

then select Add.

3. A text entry screen appears. Enter the

telephone numbers of group members.

You can also input text if desired.

Call Filter

The Settings > Call Settings > Call Filter

option enables you to set up call ﬁ lters. Call

ﬁ lters block the numbers or types of numbers

you specify from reaching your phone.

To block numbers, select Ignore List. Use the

left soft key to select Accept Unknown

Call or Reject Unknown Call. You can enter

speciﬁ c numbers to block by selecting and entry

line and pressing the Enter key.

To enter numbers that you do not want the

phone to block, select Privileged List.

Call ﬁ lters can be turned on and off. Select

Filter Settings, then press the Enter key. To

turn ﬁ lters off, select Off then press the Enter

key. To turn ﬁ lters on, select Ignore List, then

press the Enter key. To turn ﬁ lters on, you must

have previously set one or more numbers to

block in the Ignore List.

Network Settings

The default network settings in the phone are

for automatic detection of the best available

lines for the type of content you are sending.

Your phone also offers the ﬂ exibility to let you

manually select various network options to suit

your preferences.

Network menu features include Network

Selection, Preferred Network, Band Selection,

and GPRS Connection.

Network Selection

To choose a network selection:

1. Highlight the Network Selection option,

then press the enter key.

2. There are two options: Automatic (default),

or Manual.

If you select Manual, a list of available

networks appears.

3. Highlight the desired network, then select

OK.

NOTE: There may be only one network listed, depending on

your geographic location. Higher fees may also result from

using a network other than that of your service provider.

Preferred Network

With the Network Settings > Preferred

Network option, you can set up a list of

preferred networks from a list of various service

providers, and then manually select your

preferred network.

Band Selection

Depending on your geographic location, one

or more bandwidths are available on a GSM

network. In the Network Settings > Band

Selection option, you can set bandwith

preferences.

Select from 900, 1800, 1900, or Dual Band.

GPRS Connection

Some users may prefer to use GPRS network

for faster data transmission and support of

multimedia ﬁ les, such as delivery of polyphonic

ring tones, color graphics, games, and software.

If a GPRS network is available, you can set

your usage preference with the GPRS option

can set through the the Network Settings >

GPRS Connection option.

Highlight the GPRS option and press the

enter key to toggle between Always and When

Needed.

Bluetooth Settings

With the Bluetooth function you can exchange

information between your phone and the

Bluetooth headset.

The Bluetooth Settings menu features include

Power, Search Audio Device, My Device and

Settings. When a device is connected, a ﬁ fth

option, Disconnect Device, appears on the

menu.

To connect a Bluetooth device to your phone for

the ﬁ rst time:

1. Turn on the Bluetooth device, and then

click Bluetooth Settings > Search

Audio Device to search for Bluetooth

Headphones, or click Bluetooth Settings

> My Device > Option > Search New

Device to search for BT-enables PDA or

PC, and press OK.

2. Once the Bluetooth device is detected,

it is shown on the list of found devices.

Select the BT device you wish to connect

with, and click Pair to pair the device with

your phone. You may be asked to put

in a Bluetooth password to successfully

complete the pairing. The default

password for your phone is 1234.

3. If the pairing is successful, you will be

asked whether or not you wish to add the

Bluetooth device to your trust list. Press

yes or no.

4. After that, you will be asked if you wish to

connect with the device. Press yes or no.

Now the connection is established.

If you add a device to your trust list, you will not

have to go through this whole process again.

Merely highlight the device from the list shown

under Bluetooth Settings > My Device, and

press Option > Connect.

Power

Highlight the Power option from the Bluetooth

menu and press the left soft key to toggle

the option On or Off.

Settings

Search Audio Device

With the Bluetooth Settings > Search Audio

Device option, you can execute the phone

search for available audio devices within

transmission range. The devices are then

displayed on the screen.

To connect a Bluetooth Headset to your phone

for the ﬁ rst time:

1. Turn on the Bluetooth Headphone, and

then click Bluetooth Settings > Search

Audio Device, and press OK.

2. Once the Headset is detected, it is shown

on the list of Audio devices to choose

from. Click Pair to pair the headphones

with your phone. You will be asked to

put in a Bluetooth code to successfully

complete the coding. The default Code for

your phone is 1234.

If you select Manual, a list of available

networks appears.

3. Highlight the desired network, then select

OK.

NOTE: This option may require a password. The default

password, 1234, to access this setting.

My Device

With this option, you can connect other devices

to your phone, for example a Bluetooth

headset. Select Bluetooth Settings > My

Device and press the enter key, then press

Option. By pressing Search New Device, you

can let the phone search for available Bluetooth

devices and select the one you wish to connect

to from the list that is displayed once the search

has ﬁ nished. By pressing Option and Connect,

you connect the phone with the new device.

Settings

With the Bluetooth Settings > Settings option,

you can determine whether or not the phone

can be detected by other Bluetooth devices

(Visibility), you can change the Bluetooth device

of the phone, turn Bluetooth authentiﬁ cation on

or off, and determine whether or not you want

to set the phone audio path to the headset or

leave the audio to the handset.

Disconnect Device

To disconnect the phone from other Bluetooth

devices, go to Bluetooth Settings >

Disconnect Device, then press the enter

button, and the connection will be terminated.

Security Settings

The Security Settings menu contains features

to prevent information from being accessed

or calls being charged to your account. There

are password features to protect both your

phone and your SIM card in case of loss, theft,

or unauthorized use. You can also control the

numbers dialed from the phone with Barred

Dial.

Security features include SIM Lock, Phone Lock

Code, Auto Keypad Lock, Fixed Dial, Barred

Dial, and Change Password.

SIM Lock

Using the Security Settings > SIM Lock option

protects the SIM card from unauthorized use if

the phone is stolen or used by others.

Highlight the SIM Lock option from the Security

Setup menu and press the right and left joystick

keys to toggle the option On or Off.

NOTE: This option requires a default password from your

service provider. Consult your service provider if needed.

Phone Lock

The Security Settings > Phone Lock option

provides additional security by locking the

handset. Even if the SIM card is changed,

the phone cannot be used until a password is

entered to unlock it.

NOTE: The default password is 1234. See the

section”Change Password” in this chapter for

information on setting your own password.

Highlight the SIM Lock option from the Security

Setup menu and press the right and left

joystick keys to toggle the option On or Off.

Auto Keypad Lock

The Security Settings > Auto Keypad Lock

option locks the keypad after a speciﬁ ed period

of time.

To set the auto keypad lock:

1. Highlight the Auto Keypad Lock option,

then press the enter key.

2. Select to lock the keypad after 5 seconds,

30 seconds, 1 minute, or 5 minutes of

inactivity. Select None to disable the

function.

For information on unlocking the keypad, see

the section “Unlocking the Keypad” in the

Getting Started chapter of this manual.

Fixed Dialing

The Security Settings > Fixed Dial function

limits dialing to the numbers that you specify.

Fixed dialing is a service offered by some

service providers.

The Fixed Dial option can be turned On or Off

and a ﬁ xed dial list can be deﬁ ned.

NOTE: This option requires a password, known as PIN2.

Consult your service provider if you don’t know the password.

Barred Dialing

The Security Settings > Barred Dial option

enables you to block dialing of certain numbers.

Barred dialing is a service offered by some

service providers.

To enable the option, highlight the Barred Dial

option from the Security Setup menu and press

the enter key to toggle the option on and off.

NOTE: This option requires a password. Consult your service

provider if you don’t know your password. This function may not

be supported by all service providers.

Change Password

Use the Security Settings > Change

Password option to change passwords for SIM

card PINs or for the phone.

Settings

To change a password:

1. Highlight the Change Password option

and press the enter key

2. Select the password you wish to change:

PIN, PIN2, or Phonelock.

3. You are prompted to enter the old

password, then enter the new password.

NOTE: The default phonelock password is 1234. Consult your

service provider if you have forgotten a PIN password or need

further assistance with PIN passwords.

Restore Factory Settings

The Settings > Restore Factory Settings

option restores all settings to factory default,

just as they were when you purchased the

phone.

To restore factory default settings:Highlight

the Restore Factory Default option from the

Security Setup menu and press the enter key.

All factory default settings are then restored.

NOTE: This option requires a password. Use the default

password, 1234, to access this setting.

Camera

The phone is equipped with a high quality

camera for capturing still pictures and video.

Taking Photos

Follow these steps to capture still pictures with

your phone.

1. Press the menu button on the keypad to

display the main menu screen.

2. Use the joystick to highlight the Camera

icon and press the enter key to conﬁ rm.

3. Highlight the Capture option, then press

the enter key to enter capture mode.

4. Point the camera lens at the subject and

use the LCD screen to frame your picture.

5. Press the enter key or the capture button

on the side of the camera to capture the

image.

6. Press the left soft key to save the

image in your album.

Capture button

Zoom Function

The phone has an easy-to-use zoom function.

To zoom in on an object, press the up joystick

key.

To zoom out, press the down joystick key.

You can preview the zoom effect on the phone’s

screen. In addition, a slide bar on the right of

the screen moves as zoom is applied.

Viewing and Managing

Photos

Use the My Album option to view and manage

the still images in your album.

To open My Album:

1. While in capture mode, select Option >

My Album, or

From the main menu, select Camera > My

Album.

A list of stored images is displayed.

2. To view an enlarged thumbnail, highlight

an image and press the enter key. You can

browse photos in this enlarged view using

the up and down joystick keys.

3. Press the left soft key to display

the Option menu. You can view, send,

rename, delete, and sort photos.

Camera

Photo Capture Settings

The camera can be conﬁ gured to capture

images of different size and quality. You can

also capture photos with frames or special

effects, take multi-capture photos, use a timer,

or do a self-capture.

To access photo capture settings:

Put the camera into capture mode, as described

in the “Taking Photos” section of this manual,

then select Option.

Camera Settings

Use the camera settings option to set the white

balance, shutter sound, EV, night mode, and AC

frequency.

To access the Camera Setting menu:

1. While in capture mode, select Option >

Camera Settings.

2. Highlight an option to adjust using the

joystick.

3. Adjust the values of settings using the

joystick left and right keys.

Camera Settings Shortcuts

The number keys also act as shortcut keys for

the camera settings. The keys are assigned as

follows:

Effect

White Balance

LED Highlight

Capture Timer

Multi-Capture

Night Mode

Image Quality

Image Size

Self capture

Press the respective keys repeatedly to change

a given setting. For example, if you press

for Multi-Capture, pressing again enables you

to apply 4 Shots, 6 Shots or 9 Shots to the

setting.

Image Settings

Use the image setting option to set the image

size and quality.

To access the Image Setting menu:

1. While in capture mode, select Option >

Image Settings.

2. Highlight an option to adjust using the

joystick.

3. Adjust the values of settings using the

joystick left/right action.

Effect

Use the Effect option to apply photo effects

as you capture photos. For example, you can

capture photos with a photo negative effect,

alter colors, or make the photo look like a

sketched drawing.

To apply photo effects:

1. While in capture mode, select Option >

Effect.

A list of photo effects appears.

2. Highlight an effect from the list using the

joystick and press the enter key to apply

the setting.

Add Frame

Use the Add Frame option to add frames to

pictures you capture.

To apply frames to photos:

1. While in capture mode, select Option >

Frame.

2. Highlight a frame from the list.

You can use the up and down joystick

keys to scroll through the other frames to

view them all.

3. To select a frame, press the enter key. The

selected frame is then displayed on the

capture screen.

4. To remove a frame, select Option >

Frame > No Frame.

Multi-Capture

The Multi-Capture enables multiple capture

shots, so the camera captures three or ﬁ ve

shots with a single click of the button.

To enable the multi-capture function:

1. While in capture mode, select Option >

Multi-Capture.

2. Select a number of shots. Select

Deactivate or 4 Shots, 6 Shots or 9 Shots

for multi-capture shots.

Capture Timer

Use the delay timer to add a delay time

between pressing the capture button and the

picture actually being captured. This can allow

enough time to take pictures of yourself.

To set the capture timer:

1. While in capture mode, select Option >

Capture Timer.

2. Select 5 sec, 10 sec, or 15 sec, or

Deactivate to turn the function off.

Self Capture

Use the self capture option to take pictures of

yourself.

To enable the multi-capture function:

1. While in capture mode, select Option >

Self Capture.

2. Close the ﬂ ip top, and you can see your

own image on the sub screen. Press

the capture button on the left side of

the camera to take the snapshot. When

you are done, open the ﬂ ip top again.

The image is automatically saved to My

Album.

Restore Default

Use the Restore Default option to restore all

factory default camera settings.

To restore default settings:

1. While in capture mode, select Option >

Restore Default.

2. A message asking you to conﬁ rm the

Camera

action is displayed.

3. Select Yes with the left soft key to

restore defaults, or select No with the right

soft key to abort.

Recording Videos

Follow these instructions for shooting video:

1. From the main menu screen, highlight the

Camera icon, then press the enter key.

2. Select the Video Recorder option, then

press the enter key to enter capture mode.

3. Point the camera lens at the subject and

use the LCD screen to frame your video.

4. Press the enter key or the capture button

to begin recording. Press the enter key or

the capture button again to stop recording.

Zoom Function

The phone’s video recorder also has a zoom

function.

To zoom in on an object, press the up joystick

key.

To zoom out, press the down joystick key.

You can preview the zoom effect on the phone’s

screen. A slide bar at the bottom of the screen

moves as zoom is applied.

Viewing and Managing

Videos

Select the My Video option to view and play the

videos in your album.

To open My Video:

1. While in video capture mode, select

Option > My Video, or

From the main menu, select Camera > My

Video.

A list of stored videos is displayed.

2. Use the joystick to highlight a video and

press the enter key to play.

To pause, press the enter key. Press

the enter key again or select Resume to

resume.

3. To edit ﬁ les, select Option. You can view,

forward, rename, or delete ﬁ les. You can

also sort image ﬁ les or set the default

storage location.

Some video playing features are explained in

the following sections.

Full-Screen Mode

While the video is playing, a progress bar and

the time elapsed is shown at the bottom of the

screen. If you wish to view the video in full-

screen mode, press the * key to toggle in and

out of full-screen mode.

Rewind and Fast Forward

To rewind, press and hold the left joystick key.

To fast forward, press and hold the right joystick

key.

Video Playback Speed

You can select from ﬁ ve different video

playback speeds: 1/2, 1, 2, 4, and 8.

To select a playback speed, press the up and

down joystick key. Use the up key to iselect

a higher speed and the down key to select a

lower speed.

The current speed is shown in the lower left of

the screen.

Volume

To adjust volume, press the side volume key.

Press + to increase volume, and - to decrease

volume.

Capturing a Still Photo

You can capture a still photo from a video by

pressing the capture button on the side of the

camera while the video is playing.

Video Recorder Settings

The video recorder can be conﬁ gured to record

videos of different size and quality. You can also

record videos with special effects, or restore the

default settings.

To access video settings:

Select the video recorder mode, as described in

the “Recording Videos” section of this manual,

then select Option.

Camcorder Settings

The Camcorder Settings includes options

related to lighting conditions. There are settings

for white balance, LED Highlight, EV, Night

mode, and AC frequency.

To open the Camcorder Settings menu:

1. While in video recording mode, select

Option > Camcorder Settings.

2. Highlight an option to adjust.

3. Adjust the value of a setting using the

joystick left and right keys.

NOTES: EV stands for exposure value. The EV option enables

you to manually raise or lower the exposure value.

The AC Frequency option adjusts for lighting ﬂ icker. Select the

frequency of electrical current in your area.

Video Settings

Use the Video Settings option to set the video

quality, ﬁ le size limit, record time limit, turn the

audio on and off, and set the encode format.

To open the video setting menu:

1. While in video recording mode, select

Option > Video Settings.

2. Highlight a setting to adjust.

3. Adjust the value of a setting using the

joystick left and right keys.

Camera

Video Settings Shortcuts

The number keys also act as shortcut keys to

the video settings. The keys are assigned as

follows:

Effect

White Balance

LED Highlight

4 Night Mode

Effect

Use the Effect option to apply a photo effect,

such as a photo negative effect or a color effect,

when you shoot a video.

1. While in video recording mode, select

Option > Effect.

A list of effects appears.

2. Highlight an effect from the list using the

joystick and press the enter key to apply

the setting.

Restore Default

Use the Restore Default option to restore all

factory default video settings.

To restore default settings:

1. While in video recording mode, select

Option > Restore Default.

2. A message asking you to conﬁ rm the

action is displayed.

3. Select Yes with the left soft key to

restore defaults, or select No with the right

soft key to abort.

Photo Artist

Use the Photo Artist option to edit your captured

images, video and audio ﬁ les.

Select Option > Photo Artist, and press the

left soft key or the enter key. The File Manager

appears, showing the amount of space

occupied by the handset memory and the

DRM. You can start choosing image ﬁ les from

the stored data to be edited; select an image

ﬁ le from one of the handset’s folders and then

choose to automatically resize it or to prepare it

so you can later use it as your LCD or SubLCD

clip.

To automatically resize the picture:

1. Select the picture and then choose Auto

Resize > Option.

A list of options is displayed:

Save as: Use the keypad to enter the name

you wish to save the ﬁ le under, then press

the left soft key and choose Done,

Cancel, or Input Method to save or discard

the image or select a different text input

method.

Add effect: Highlight an effect from the list

using the joystick and press the enter key

to view the effect on the picture. Press the

left and right joystick key to toggle between

effects, and press the left soft key to

apply the setting or the right soft key

to discard.

Frame: Highlight a frame from the list

and press the enter key to see that frame

applied to your picture. Use the right and

left joystick keys to toggle between frames,

and press the left soft key to apply the

setting or the right soft key to discard.

Add icon: Highlight an icon from the list

and press the enter key to add that icon to

your picture. Use the right and left joystick

keys to change the position of the icon, then

press the middle key to apply the icon to the

picture. Press the left soft key (Done)

when you are ﬁ nished, or the right soft key

(Cancel) to discard.

Add Text: Use the keypad to enter the

text you wish to add to your picture the ﬁ le

under, then press the left soft key and

choose Done, Cancel, or Input Method

to save or discard the image or select a

different text input method. When you’ve

pressed Done, you can start changing the

text color, the border color, the shadow

color, the font, the font size and put the text

into italics. After you are done, press the left

soft key (OK). Then use the right and left

joystick keys to change the position of the

text, and press the middle key to apply the

text to the picture. After that, press the left

soft key (Done) to apply the setting or

the right soft key (Cancel) to discard.

Adjustment: You can choose either to

adjust the image, or the color. Highlight

one of the two choices from the list and

press OK. Adjust your image’s brightness,

contrast, saturation, hue, and color values.

Press Done, or Cancel, and then press the

left soft key to apply the setting or the

right soft key to discard.

Flip: Use the joystick keys to ﬂ ip the image

horizontally or vertically. Press the left soft

key to apply the setting or the right soft

key to discard.

Expand Canvas: You can choose to

expand the canvas to full screen size here.

Press Yes or No to apply the setting or to

discard.

To create an LCD clip:

1. Select the picture and then choose LCD

Clip > Option.

A list of options is displayed, refer to Auto

Resize for details.

2. Apply this picture as your LCD wallpaper

by following the procedures described

under Settings > Display > Settings

Wallpaper.

To create a Sub-LCD clip:

1. Select the picture and then choose Sub-

LCD Clip > Option.

A list of options is displayed, refer to Auto

Resize for details.

2. Apply this picture as your LCD wallpaper

by following the procedures described

under Settings > Display > Settings Sub

Wallpaper.

Media Center

Audio Player

The phone is equipped with a high quality

audio player for digital music ﬁ les.

To start the audio player

1. Press the menu button on the keypad to

display the main menu screen.

2. Use the joystick to highlight the Media

Center icon.

3. Press the enter key to display the media

center menu.

4. Use the joystick to highlight the Audio

Player option from the list and press the

enter key to conﬁ rm.

The audio player opens.

5. Press the left soft key to select

Option > Play List and display a list of

available digital music ﬁ les.

6. Use the joystick to highlight a music ﬁ le to

play and press the enter key to select it.

7. The enter key and the up, down, right, left

joystick keys act as play controls. When

you push a key, the corresponding on-

screen symbol lights up.

Joystick key assignments are as follows:

Enter/ Up Joystick: Play, Pause, 

Down Joystick: Stop, 

Left Joystick: Reverse, 

Right Joystick: Fast Forward, 

NOTE: You need to connect earphones to the earphone socket

on the bottom of the phone to listen to music ﬁ les.

Adding music ﬁ les

To add music ﬁ les to your phone you must ﬁ rst

connect the phone to a computer with digital

music ﬁ les.

Connect the phone to the computer USB port

using the USB cable provided.

The when the phone is connected to the

computer it will appear in Windows Explorer

as a removable disk drive (the internal phone

memory).

Drag and drop your digital music ﬁ les to the

Audio folder in the internal phone memory. If

you add ﬁ les to folders other than these, you

will not be able to play them with the phone’s

audio player.

Editing Music Files

You can play a ﬁ le, view ﬁ le details, set a ﬁ le as

a ringtone, add or remove ﬁ les, or control other

settings related to the playlist, the list of songs

played by the audio player.

To edit music ﬁ les:

1. From the main menu, select Media Center

> Audio Player > Play List.

2. Highlight a ﬁ le, then select Option.

A list of editing options appears.

NOTE: If you want to view the ID3 tag of an MP3 ﬁ le, select the

Details option.

Option > Settings contains settings to control

the playlist and the appearance of the audio

player. Select from the following options. Use

the right and left joystick keys to toggle settings:

• Skin. Select from three different skins, or

outward appearances for the audio player.

• Repeat. Select One to repeat the current

song. Select All to repeat all the songs

in the playlist. Select Deactivate to

deactivate the repeat funtion.

• Shufﬂ e. Select Activate to randomly

repeat songs in the playlist. Select

Deactivate to play the songs in order.

•Background Play. Select Background

Play to continue listening to music ﬁ les or

radio even if you leave the media center

to use other menu functions. Music stops,

however, for playing games or for making

phone calls.

• Equalizer. Set the Equalizer to match

the tone freqencies to the music you are

currently playing. The settings to choose

from are Normal, Bass, Dance, Classical,

Treble, Party, Pop, and Rock.

FM Radio

The FM radio function provides high quality

stereo radio reception through earphones.

To start the radio:

From the main menu, select Media Center >

FM Radio.

The FM radio opens.

NOTE: You must plug in the earphones and press the button on

the microphone module for the FM radio to work.

To tune the radio, use the the left and right

joystick keys.

To control the volume, use the volume key on

the side of the phone.

To turn the radio on and off, use the down

joystick key.

To search for stations, use the up joystick key.

FM Radio Options

When the radio is displayed, press the left soft

key to display the Option menu. There

are options to use the channel list, to manually

select a frequency, search for stations, create a

list of preset frequencies, and change the radio

settings.

The channel list contains preset frequencies. To

access the channel list:

1. Start the radio, then select Option >

Channel List.

The channel list is displayed.

2. Highlight any of the preset channels in the

list and press the enter key to conﬁ rm.

3. Select the Play option to play.

Select Edit to display an edit screen.

4. To edit a channel entry you must type in

a channel name and a frequency in the

ﬁ elds provided.

5. Press the left soft key to save the new

preset channel.

Media Center

To select a channel manually:

1. Start the radio, then select Option >

Manual Input.

2. Press the number keys to enter a

frequency for a radio station.

3. Press the left soft key to listen to the

station.

To search and create a list of preset channels

automatically:

1. Start the radio, then select Option >

Preset List.

2. Press the enter key to begin the search.

Strongest stations found while searching

are allocated a preset channel.

To select and play a preset channel:

1. Start the radio, then select Option >

Channel List.

2. Select a channel from the list, then press

the enter key to play, or use a number key

to switch to different preset channels.

To add the current station to the preset list:

While listening to a station, press and hold a

number key. The station is then set as a

preset station.

To change FM radio settings:

Start the radio, then select Option > Settings.

In the Settings submenu you can change the

skin and turn background play on or off.

Java

A selection of games created with Java

technology comes preloaded on your phone.

To start a Java game:

1. From the main menu, select Media Center

> Java.

A list of Java games appears.

2. Highlight a Java game from the list and

press the enter key to launch the game.

Java Settings

You can alter a number of Java settings

and view the resources available to Java

applications using the Java Settings option.

To open the Java Settings menu:

1. From the main menu, select Media Center

> Java Settings.

2. Highlight an option to change.

3. Use the right and left joystick keys to

change the setting.

NOTE: Not all settings can be changed. Some ﬁ elds only

display resources available.

Games

A selection of games comes preloaded on your

phone.

To start a game:

1. From the main menu, select Media Center

> Games.

2. Highlight a game from the list displayed

and press the enter key to launch the

game.

Game Settings

You can set audio and vibration settings of

games using the Game Settings option.

To open the Game Settings menu:

1. From the main menu, select Media Center

> Game Settings.

2. Highlight an option to change.

3. Use the right and left joystick keys to

change settings.

Melody Composer

Use the melody composer to create midi tunes

of your own. You can also edit existing midi ﬁ les

on your phone.

To create a new tune:

From the main menu, select Media Center >

Melody Composer > Option > Add.

A blank music staff is displayed.

• Use the keys 1-7 to enter notes C-B.

• Each note can be pushed up or down

an octave by highlighting it with the

joystick and then using the joystick up

down action to move it up or down.

• Sharpen a note by highlighting it with

the joystick and then pressing the # key.

• Change the length of a note by

highlighting it with the joystick and

pressing the * key.

• Add a rest using the 0 key.

• Add a vibration effect by pressing

. This effect is marked with wavy lines

on the staff.

• Add an effect to turn the LED light on

and off by pressing . This effect is

marked by a rainbow ﬂ ag on the staff,

if you press the * after the LED icon

appears.

• If you would like to edit your tune by

turning off the vibration or screen on

/ off effects, select the effect on the

staff, then press the down joystick key

to deactivate it. An “x” then appears on

the effect. Press the up joystick key to

reactivate.

You can play your tune at any time from the

Option menu. From the Option menu, you can

also select an instrument to play your tune,

adjust the speed and save your work.

Tone Settings

Here you can set the tone settings for your

phone, determining if a tone should be played

for a certain event, and if yes, which tone

should be played. The different events to

choose from are Incoming Ringtone, Alarm

Tone, Power On, Power Off, Flip Open, Flip

Close, Message Tone and Key Tone.

Organizer

The organizer menu gives you access to a

number of features including alarms, calendar,

task list, calculator, world clock, voice recorder,

image editor, stopwatch, ﬁ le manager, units

converter, currency exchange, and health

manager.

Alarm

The phone can function as an alarm clock. Up

to three alarms can be programmed.

To program an alarm.

1. From the main menu, select Organizer >

Alarm.

A list of alarms is displayed.

2. Highlight an alarm to program then press

the enter key to conﬁ rm.

The Edit Alarm screen is displayed.

3. Highlight ﬁ elds to edit. Enter new values

using the keypad or use the left right

joystick action to cycle through the

available options, including the time, alarm

type, and alarm volume.

The Repeat function lets you deﬁ ne whether the

alarm sounds just once, at the same time every

day, or on speciﬁ c days.

The left soft key (icon) and the red key can

stop the alarm, the right soft key (icon) sets it to

snooze (i.e. causes the alarm to sound every 5

minutes until the user stops it).

Calendar

The calendar function helps you keep track of

day-to-day tasks.

To open the calendar:

1. From the main menu, select Organizer >

Calendar.

2. The calendar is displayed.

3. Use the joystick to highlight a speciﬁ c date

on the calendar and press the center joystick

button to view options for that date.

Options include viewing tasks associated

with that day and jumping to another day.

To access tasks:

1. Open the calendar as described in the

previous procedure.

2. Use the joystick to highlight a date and

press the enter key to conﬁ rm.

The Option menu is displayed.

3. Press the enter key to view tasks already

entered for that day.

4. Highlight a task, then press the enter key

to view it.

or use the Go To Date option to type in a

certain date for which you wish to have the

tasks displayed.

You can also add a new task from this

menu, edit the current task, delete the

current task, delete all tasks, or send a

vCalendar.

Tasks List

You can create a task list on your phone. The

task list is a list of tasks orderd by date.

To open the Tasks List:

1. From the main menu, select Organizer >

Tasks List.

2. Use the joystick to highlight the Tasks List

option and press the enter key.

The tasks list is displayed.

3. Select Add to add a new task. Complete

ﬁ elds for time, content, and alarms. Users

can deﬁ ne how often they want the alarm

to warn them, as well: once, every day,

a speciﬁ c day in the week, weekly, or

monthly.

4. To edit a task, highlight a task from the list

then press the enter key to conﬁ rm.

The Option menu is displayed.

From the option menu you can view the

current task, add a new task, edit the

current task, delete the current task, delete

all the tasks, or send a vCalendar.

5. Highlight an option from the option menu

and press the enter key to conﬁ rm.

Calculator

The phone includes a calculator function.

To use the calculator:

1. From the main menu, select Organizer >

Calculator.

The Calculator is displayed.

2. Use the keypad to enter numbers and the

joystick to select the +, - , ,÷ functions.

Pressing + twice selects the m+ function,

pressing - twice selects the m- function,

pressing  twice selects the mc function,

pressing ÷ twice selects the mR function.

3. Press the enter key to enter = and

compute. Press # to enter a decimal point.

World Clock

The world clock function enables you to see the

time in various major cities of the world.

To open the world clock:

1. From the main menu, select Organizer >

World Clock.

2. Use the joystick to highlight the Calculator

option and press the enter key to conﬁ rm.

The World Clock is displayed.

The clock displays a map and the current time

in your own location. You can move the location

east or west.

Voice Recorder

The voice recorder lets you record and play

back sounds and your own voice.

To open the voice recorder:

1. From the main menu, select Organizer >

Voice Recorder.

The Voice Recorder is displayed.

2. Use the joystick to highlight an existing

ﬁ le from the list and press the enter key

Organizer

to conﬁ rm. Alternatively, press the left soft

key to display the Option menu.

From the option menu you can make a

new recording, play the current recording,

append the current recording, rename

the current recording, delete the current

recording, delete all recordings, change

the settings or send the recording to

Manner, MMS, Email or EMS.

3. Highlight an item from the option menu

and press the enter key to conﬁ rm.

Image editor

Use the Image Editor to create and edit images.

To open the Image Editor:

Highlight an image from the list to edit using

the joystick, or select Add to add a new image.

Press the enter key to conﬁ rm.

Use the

key on the keypad to toggle

between the pencil tool and the cursor tool, use

the

key to the

key to draw.

Move around the screen using the other

number keys.

Under Option you get the choice to do the

following with your picture: save it, even under

different formats, change the pen settings, set

a background color, mark, zoom and resize the

picture. The Help Option explains once more

how the Image Editor works.

Stopwatch

The phone includes a stopwatch function.

There are two styles of stopwatch to choose

from. The typical stopwatch is a simple timer

that can be started and stopped using the enter

key. In this setting, you can choose between

split timing and lap timing: split timing continues

running the elapsed time after the ﬁ rst mark has

been set, lap timing resets the time display to 0

after every mark. You can also save your times

to keep track of your records: select Organizer

> Stopwatch > Typical > Record to check on

your record history.

The nWay timer consists of four timers that can

be started by pressing the joystick up, down,

left, or right. To start and stop the timers, use

the middle key , to go back and save, use

the right soft key , to set a mark or reset,

use the left soft key . Only one timer can be

running at any time. The total time appears at

the top of the screen.

To use the stopwatch:

1. From the main menu, select Organizer >

Stopwatch.

The Stopwatch menu screen is displayed.

2. Select the type of stopwatch you want to

use and press the enter key to conﬁ rm.

File Manager

The ﬁ le manager is a feature that enables

you to ﬁ nd and manipulate ﬁ les stored in the

memory of your phone.

To open the ﬁ le manager:

1. From the main menu, select Organizer >

File Manager.

Two drives are displayed, the internal

handset memory, and the DRM.

2. Use the joystick to highlight a drive and

press the enter key to conﬁ rm.

Options for the selected drive are

displayed. You can open the drive and

view contents, create a new folder, or

format the drive.

Units Converter

The Units converter is a useful tool to convert

weights and measures from imperial (pounds,

miles) to metric (kg, km) or metric to imperial.

To use the unit converter:

1. From the main menu, select Organizer >

Units Converter.

The Units Converter menu is displayed.

2. Use the joystick to highlight the Weight or

Length option and press the enter key to

conﬁ rm.

3. With the top ﬁ eld highlighted, use the left

right joystick action to select a conversion

type e.g. Km and Miles.

4. Highlight either of the measurement ﬁ elds,

e.g. Km and Miles, using the joystick.

5. Input a number using the keypad.

6. Press the enter key to conﬁ rm.

The measure is converted and displayed.

Currency Exchange

The currency exchange is a useful tool to help

you convert one currency to another.

To use the currency exchange:

1. From the main menu, select Organizer >

Currency Exchange.

The Currency Exchange is displayed.

2. Use the keypad to enter a conversion

factor and press the center button to

conﬁ rm. Use the # key to enter a decimal

point.

3. With the top ﬁ eld highlighted, use the left

right joystick keys to select the direction of

conversion (e.g. 2:1 or 1:2).

4. Use the joystick to highlight the Local or

Foreign currency ﬁ eld and enter a number

using the keypad. Use the # key to enter a

decimal point.

5. Press the enter key to display the result.

Health Manager

The health manager includes a Body Mass

Index (BMI) calculator, and a menstrual cycle

chart.

To use the BMI calculator:

1. From the main menu, select Organizer >

Health Manager> BMI.

2. With the top ﬁ eld highlighted, use the left

right joystick keys to enter your sex, Male

or Female.

3. Use the joystick to highlight the height and

weight ﬁ elds and enter a value for each.

Organizer

4. Press the enter key to calculate your BMI.

To use the menstrual cycle calculator:

1. From the main menu, select Organizer >

Health Manager> Menstrual.

2. Use the keypad to enter the date of the

start of your last menstrual cycle and the

days of an average period.

Press the center joystick button to conﬁ rm.

Your menstrual cycle chart is then

displayed.

The dates highlighted in Red signify

the days when the Health Manager has

calculated you will have your period,

Orange signiﬁ es your ovulation time, and

on days marked with Yellow the possibility

for you to get pregnant is very high. If you

press the middle key, you can see the

possibility of getting pregnant on that very

day.

Network

The Network menu lets you view and change

network settings.

Service Provider Settings

The service provider settings are dependent

upon your service provider. If you have any

questions about your service provider settings,

see your service provider for details.

To access service provider settings:

1. From the main menu, select Network >

Service Provider Settings.

2. Highlight an option to change.

3. Press the enter key to change the

highlighted setting.

WAP

Use the WAP menu to set the homepage,

bookmarks, view recent pages, enter an

internet address, push service inbox, and

change settings.

To open the WAP menu:

1. From the main menu, select Network >

WAP.

2. Highlight an option to change.

3. Press the enter key to change the

highlighted setting.

Browsing WAP pages

Browsing WAP pages is much like browsing

web pages with your computer. However, rather

than using a mouse, you navigate with the

joystick keys and with the Middle/enter and

call key.

Scrolling

Some WAP pages are longer than the phone’s

screen. To scroll up or down a page, press and

hold the up or down joystick key.

Viewing Links

Web links appear as colored or underlined,

just as on a computer. To view a link, press the

middle/enter key.

WAP Settings

Many important WAP settings are dependent

upon your service provider’s system setup.

Contact your service provider for details.

If, as part of your WAP settings, you need to

change the WAP proxy IP address, please refer

to the following instructions.

Changing the WAP Proxy IP Address

One or more WAP proﬁ les should already be

set up before changing the IP address.

Network

1. Select WAP > Settings > Proﬁ les. A list of

available proﬁ les appears.

2. Select a proﬁ le, then press the left soft key

3. Select Proﬁ les

A list of ﬁ elds appears. Select Connection

Type. Select from Connection-oriented,

Connectionless, or HTTP connection types.

WAP Push

WAP Push is a method for sending multimedia

content to your phone. If your service provider

offers WAP push services, you can use WAP

push to receive such content as wallpaper,

ringtones, or java games. The message is sent

as a WAP accessible URL, or web address.

Set WAP Push settings in WAP > Settings.

Receive WAP Push content in WAP > Push

Inbox.

Data Account

The Data Account menu provides access to

GSM data and GPRS settings.

Appendix

Additional Information

The use of this equipment may be subject to

local rules and regulations. The following rules

and regulations may be relevant in some or all

areas.

European Notice

Products with the mark comply with the Radio

& Telecommunication Terminal Equipment

Directive (1999/5/EEC), the Electromagnetic

Compatibility Directive (89/336/EEC) and

the Low Voltage Directive (73/23/EEC) - as

amended by Directive 93/68/ECC - issued by

the Commission of the European Community.

Compliance with these directives implies

conformity to the following European

Standards:

• 1999/5/EEC Radio &

Telecommunication Terminal Equipment

Directive (R&TTE) EN 301 511

• Speciﬁ c Absorption Rate (SAR)

Standard: EN 50360, EN 50361

• 73/23/EEC Low Voltage Directive

(LVD) Standard: EN 60950:2000

• 89/336/EEC Electromagnetic

Compatibility (EMC-Directive)

Standard: EN 301489-1/7

• The manufacturer cannot be held

responsible for modiﬁ cations made by

the user and the consequences thereof,

which may alter the conformity of the

product with the mark.

RF Exposure Information

(SAR)

This model phone meets the government’s

requirements for exposure to radio waves.

This phone is designed and manufactured not

to exceed the emission limits for exposure to

radio frequency (RF) energy set by the Federal

Communications Commission of the U.S.

Government.

The exposure standard for wireless mobile

phones employs a unit of measurement known

as the Speciﬁ c Absorption Rate, or SAR. The

SAR limit set by the FCC is 1.6W/kg. Tests for

SAR are conducted using standard operating

positions accepted by the FCC with the phone

transmitting at its highest certiﬁ ed power level

in all tested frequency bands. Although the SAR

is determined at the highest certiﬁ ed power

level, the actual SAR level of the phone while

operating can be well below the maximum

value. This is because the phone is designed

to operate at multiple power levels so as to use

only the power required to reach the network. In

general, the closer you are to a wireless base

station antenna, the lower the power output.

The SAR maximum result found during testing

for ASUS J201 are 0.722 w/kg for PCS head

and 0.585w/kg for PCS Body.

Appendix

For body worn operation, this phone has

been tested and meets the FCC RF exposure

guidelines for use with an accessory that

contains no metal and the positions the

handset a minimum of 1.5 cm from the body.

Use of other enhancements may not ensure

compliance with FCC RF exposure guidelines.

If you do not use a body-worn accessory and

are not holding the phone at the ear, position

the handset a minimum of 1.5 cm from your

body when the phone is switched on.

Proper Disposal

When the phone reaches the end of its

lifetime, do not dispose of it by throwing it

into the trash. Cell phones contain potentially

hazardous materials which are dangerous to

the environment if not disposed of properly.

Dispose of the phone by taking it to a cell

phone collection or recycling point. Contact

your dealer for information or assistance.

This mobile phone complies with part 15 of the

FCC Rules. Operation is subject to the

following two conditions: (1) This device may

not cause harmful interference, and (2) this

device must accept any interference received,

including interference that may cause

undesired operation.The FCC has granted an

EquipmentAuthorizationfor this model phone

with all reported SARlevels evaluated as in

compliance with the FCCRF exposure

guidelines. SAR information onthis model

hone is on file with the FCC andcan be found

under the Display Grant section of

tap://www.fcc.gov/oet/fccid after searching on

FCC ID: MSQJ201

ASUSTeK Computer J201 Triple Band GSM/GPRS Mobile Phone w/BT User Manual J201 UserMan udpated 2005 10 12

ASUSTeK Computer Inc Triple Band GSM/GPRS Mobile Phone w/BT J201 UserMan udpated 2005 10 12

Manual

Navigation menu

Namespaces

Views

Navigation
