ASUSTeK Computer K007 ASUS Tablet User Manual
ASUSTeK Computer Inc ASUS Tablet
User Manual.pdf
![](/img.php?id=2345968&img=bg1.png)
E9131
User Guide
E9404
ASUS Tablet
First Edition / August 2014
![](/img.php?id=2345968&img=bg2.png)
Charging your device
Ensure to fully charge your ASUS Tablet before using it in
battery mode for extended periods. Remember that the power
adapter charges your ASUS Tablet as long as it is plugged into
an AC power source. Be aware that it takes much longer to
charge the ASUS Tablet when it is in use.
IMPORTANT! Do not leave the ASUS Tablet connected to
the power supply once it is fully charged. ASUS Tablet is not
designed to be left connected to the power supply for extended
periods of time.
Airplane precautions
Contact your airline provider to learn about related inight
services that can be used and restrictions that must be followed
when using your ASUS Tablet in-ight.
IMPORTANT! You can send your ASUS Tablet through x-ray
machines (used on items placed on conveyor belts), but do not
expose them from magnetic detectors and wands.
Safety precautions
This ASUS Tablet should only be used in enviroments with
ambient temperatures between 0°C to 35°C (32°F to 95°F).
Long time exposure to extremely high or low temperature
may quickly deplete and shorten the battery life. To ensure the
battery’s optimal performance, ensure that it is exposed within
the recommended environment temperature.
![](/img.php?id=2345968&img=bg3.png)
ASUS Tablet
3
DRAFT v3
Package contents
NOTES:
• Ifanyoftheitemsisdamagedormissing,contactyour
retailer.
• Thebundledpoweradaptervarieswithcountryorregion.
ASUS Tablet Power adapter
ASUS Tablet
Micro USB cable Technical documentations and
warranty card
![](/img.php?id=2345968&img=bg4.png)
ASUS Tablet
4
DRAFT v3
Your ASUS Tablet
Touch screen panel
Micro USB 2.0 port
Front view
Audio speaker
Front camera
Ambient light sensor
![](/img.php?id=2345968&img=bg5.png)
ASUS Tablet
5
DRAFT v3
Rear view
Speaker/Headset port
Rear camera
Audio speaker
![](/img.php?id=2345968&img=bg6.png)
ASUS Tablet
6
DRAFT v3
Side views
* The microSD card slot supports microSD, microSDHC, and microSDXC card formats.
Left view
microSD card slot*
Right view
Power button
Volume button
Microphone
![](/img.php?id=2345968&img=bg7.png)
ASUS Tablet
7
DRAFT v3
Charging your ASUS Tablet
To charge your ASUS Tablet:
Connect the micro USB cable to the power adapter.
Plug the micro USB connector into your ASUS Tablet.
Plug the power adapter into a grounded power outlet.
Charge your ASUS Tablet for eight (8) hours before
using it in battery mode for the rst time.
![](/img.php?id=2345968&img=bg8.png)
ASUS Tablet
8
DRAFT v3
IMPORTANT!
• UseonlythebundledpoweradapterandmicroUSBcable
to charge your ASUS Tablet. Using a dierent power adapter
may damage your ASUS Tablet.
• Peeltheprotectivelmofromthepoweradapterandmicro
USB cable before charging the ASUS Tablet to prevent risk or
injury.
• Ensurethatyouplugthepoweradaptertothecorrectpower
outlet with the correct input rating. The output voltage of this
adapter is DC 5.2 V, 1.35 A.
• WhenusingyourASUSTabletwhileplugged-intoapower
outlet, the grounded power outlet must be near the unit and
easily accessible.
• DonotplaceobjectsontopofyourASUSTablet.
NOTES:
• YourASUSTabletcanbechargedviatheUSBportonthe
computer only when it is in sleep mode (screen o) or turned
o.
• ChargingthroughtheUSBportofacomputermaytake
longer time to complete.
• Ifyourcomputerdoesnotprovideenoughpowerfor
charging your ASUS Tablet, charge your ASUS Tablet via the
grounded power outlet instead.
![](/img.php?id=2345968&img=bg9.png)
ASUS Tablet
9
DRAFT v3
Appendices
Federal Communications Commission
Statement
This device complies with FCC Rules Part 15. Operation is
subject to the following two conditions:
• Thisdevicemaynotcauseharmfulinterference.
• Thisdevicemustacceptanyinterferencereceived,including
interference that may cause undesired operation.
This equipment has been tested and found to comply with
the limits for a class B digital device, pursuant to Part 15 of the
Federal Communications Commission (FCC) rules. These limits
are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment
generates, uses, and can radiate radio frequency energy and,
if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur
inaparticularinstallation.Ifthisequipmentcausesharmful
interference to radio or television reception, which can be
determined by turning the equipment o and on, the user is
encouraged to try to correct the interference by doing one or
more of the following measures:
• Reorientorrelocatethereceivingantenna.
• Increasetheseparationbetweentheequipmentand
receiver.
• Connecttheequipmentintoanoutletonacircuitdierent
from that to which the receiver is connected.
![](/img.php?id=2345968&img=bga.png)
ASUS Tablet
10
DRAFT v3
• Consultthedealeroranexperiencedradio/TVtechnicianfor
help.
Changes or modications not expressly approved by the party
responsible for compliance could void the user‘s authority to
operate the equipment.
The antenna(s) used for this transmitter must not be co-
located or operating in conjunction with any other antenna or
transmitter.
RF Exposure Information (SAR)
This device meets the government’s requirements for exposure
to radio waves. This device is designed and manufactured not
to exceed the emission limits for exposure to radio frequency
(RF) energy set by the Federal Communications Commission of
the U.S. Government.
The exposure standard employs a unit of measurement
known as the Specic Absorption Rate, or SAR. The SAR limit
setbytheFCCis1.6W/kg.TestsforSARareconductedusing
standard operating positions accepted by the FCC with the EUT
transmitting at the specied power level in dierent channels.
The highest SAR value for the device as reported to the FCC is
0.82W/kgwhenplacednexttothebody.
The FCC has granted an Equipment Authorization for this device
with all reported SAR levels evaluated as in compliance with the
FCC RF exposure guidelines. SAR information on this device is
on le with the FCC and can be found under the Display Grant
sectionofwww.fcc.gov/oet/ea/fccidaftersearchingonFCCID:
MSQK007.
![](/img.php?id=2345968&img=bgb.png)
ASUS Tablet
11
DRAFT v3
Canada, Industry Canada (IC) Notices
ThisClassBdigitalapparatuscomplieswithCanadianICES-003,
RSS-210,andCANICES-3(B)/NMB-3(B).
Operation is subject to the following two conditions: (1) this
device may not cause interference, and (2) this device must
accept any interference, including interference that may cause
undesiredoperationofthedevice.TheICIDforthisdeviceis
3568A-K007.
Radio Frequency (RF) Exposure Information
TheradiatedoutputpoweroftheWirelessDeviceisbelow
theIndustryCanada(IC)radiofrequencyexposurelimits.The
WirelessDeviceshouldbeusedinsuchamannersuchthat
the potential for human contact during normal operation is
minimized.
This device has been evaluated for and shown compliant with
theICSpecicAbsorptionRate(“SAR”)limitswheninstalled
in specic host products operated in portable exposure
conditions.
Canada’s REL (Radio Equipment List) can be found at the
following web address:
http://www.ic.gc.ca/app/sitt/reltel/srch/nwRdSrch.
do?lang=eng
Additional Canadian information on RF exposure also can be
found at the following web address:
http://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf08792.html
![](/img.php?id=2345968&img=bgc.png)
ASUS Tablet
12
DRAFT v3
Canada, avis d’Industrie Canada (IC)
Cet appareil numérique de classe B est conforme aux normes
canadiennesICES-003,RSS-210,etCANICES-3(B)/NMB-3(B).
Son fonctionnement est soumis aux deux conditions suivantes:
(1) cet appareil ne doit pas causer d’interférence et (2) cet
appareil doit accepter toute interférence, notamment les
interférences qui peuvent aecter son fonctionnement.
L’identiantICdecetappareilest3568A-K007.
Informations concernant l’exposition aux fréquences
radio (RF)
La puissance de sortie émise par cet appareil sans l est
inférieure à la limite d’exposition aux fréquences radio
d’IndustrieCanada(IC).Utilisezl’appareilsansldefaçonà
minimiser les contacts humains lors du fonctionnement normal.
Ce périphérique a été évalué et démontré conforme aux limites
SAR (Specic Absorption Rate – Taux d’absorption spécique)
d’IClorsqu’ilestinstallédansdesproduitshôtesparticuliersqui
fonctionnent dans des conditions d’exposition à des appareils
portables.
Ce périphérique est homologué pour l’utilisation au Canada.
Pour consulter l’entrée correspondant à l’appareil dans la liste
d’équipementradio(REL-RadioEquipmentList)d’Industrie
Canada rendez-vous sur:
http://www.ic.gc.ca/app/sitt/reltel/srch/nwRdSrch.
do?lang=eng
![](/img.php?id=2345968&img=bgd.png)
ASUS Tablet
13
DRAFT v3
Pour des informations supplémentaires concernant l’exposition
aux RF au Canada rendez-vous sur :
http://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf08792.html
This device and its antenna(s) must not be co-located or operating
in conjunction with any other antenna or transmitter, except tested
built-in radios. The County Code Selection feature is disabled for
products marketed in the US/ Canada.
Cet appareil et son antenne ne doivent pas être situés ou fonctionner
en conjonction avec une autre antenne ou un autre émetteur,
exception faites des radios intégrées qui ont été testées.
La fonction de sélection de l'indicatif du pays est désactivée pour
les produits commercialisés aux États-Unis et au Canada.
![](/img.php?id=2345968&img=bge.png)
ASUS Tablet
14
DRAFT v3
UNDERNOCIRCUMSTANCESISASUSLIABLEFORANYOFTHE
FOLLOWING:(1)THIRD-PARTYCLAIMSAGAINSTYOUFOR
DAMAGES; (2) LOSS OF, OR DAMAGE TO, YOUR RECORDS OR
DATA;OR(3)SPECIAL,INCIDENTAL,ORINDIRECTDAMAGESOR
FORANYECONOMICCONSEQUENTIALDAMAGES(INCLUDING
LOSTPROFITSORSAVINGS),EVENIFASUS,ITSSUPPLIERSOR
YOURRESELLERISINFORMEDOFTHEIRPOSSIBILITY.
EC Declaration of Conformity
This product is compliant with the regulations of the R&TTE
Directive 1999/5/EC. The Declaration of Conformity can be
downloaded from http://support.asus.com.
Limitation of Liability
Circumstances may arise where because of a default on ASUS’
part or other liability, you are entitled to recover damages from
ASUS.Ineachsuchinstance,regardlessofthebasisonwhich
you are entitled to claim damages from ASUS, ASUS is liable
for no more than damages for bodily injury (including death)
and damage to real property and tangible personal property;
or any other actual and direct damages resulted from omission
orfailureofperforminglegaldutiesunderthisWarranty
Statement, up to the listed contract price of each product.
ASUS will only be responsible for or indemnify you for loss,
damages or claims based in contract, tort or infringement
underthisWarrantyStatement.
ThislimitalsoappliestoASUS’suppliersanditsreseller.Itisthe
maximum for which ASUS, its suppliers, and your reseller are
collectively responsible.
![](/img.php?id=2345968&img=bgf.png)
ASUS Tablet
15
DRAFT v3
Prevention of Hearing Loss
To prevent possible hearing damage, do not listen at high
volume levels for long periods.
For France, headphones/earphones for this device are
compliant with the sound pressure level requirement laid down
in the applicable EN 50332-1:2000 and/or EN50332-2:2003
standard required by French Article L.5232-1.
![](/img.php?id=2345968&img=bg10.png)
ASUS Tablet
16
DRAFT v3
CE Mark Warning
CE marking for devices with wireless LAN/ Bluetooth
This equipment complies with the requirements of Directive
1999/5/EC of European Parliament and Commission from
9 March, 1999 governing Radio and Telecommunications
Equipment and recognition of conformity.
ThehighestCESARvalueforthedeviceis0.343W/Kg.
This equipment may be operated in:
AT BE BG CH CY CZ DE DK
EE ES FI FR GB GR HU IE
IT IS LI LT LU LV MT NL
NO PL PT RO SE SI SK TR
Rechargeable Battery Recycling Service in
North America
For US and Canada customers, you can
call 1-800-822-8837 (toll-free) for recycling
information of your ASUS products’
rechargeable batteries.
![](/img.php?id=2345968&img=bg11.png)
ASUS Tablet
17
DRAFT v3
RF Exposure information (SAR) - CE
This device meets the EU requirements (1999/519/EC) on the
limitation of exposure of the general public to electromagnetic
elds by way of health protection.
The limits are part of extensive recommendations for the
protection of the general public. These recommendations
have been developed and checked by independent scientic
organizations through regular and thorough evaluations of
scientic studies. The unit of measurement for the European
Council’srecommendedlimitformobiledevicesisthe“Specic
AbsorptionRate”(SAR),andtheSARlimitis2.0W/Kgaveraged
over10gramofbodytissue.Itmeetstherequirementsofthe
InternationalCommissiononNon-IonizingRadiationProtection
(ICNIRP).
For next-to-body operation, this device has been tested and
meetstheICNRPexposureguidelinesandtheEuropean
Standard EN 62209-2 and EN 50566. SAR is measured with the
device directly contacted to the body while transmitting at the
highest certied output power level in all frequency bands of
the mobile device.
India RoHS
Thisproductcomplieswiththe“IndiaE-waste(Management
andHandling)Rule2011”andprohibitsuseoflead,mercury,
hexavalent chromium, polybrominated biphenyls (PBBs) and
polybrominated diphenyl ethers (PBDEs) in concentrations
exceeding 0.1% by weight in homogenous materials and 0.01%
by weight in homogenous materials for cadmium, except for
theexemptionslistedinSchedule-IIoftheRule.
![](/img.php?id=2345968&img=bg12.png)
ASUS Tablet
18
DRAFT v3
ASUS Recycling/Takeback Services
ASUS recycling and takeback programs come from our
commitment to the highest standards for protecting our
environment.Webelieveinprovidingsolutionsforyouto
be able to responsibly recycle our products, batteries, other
components as well as the packaging materials. Please go to
http://csr.asus.com/english/Takeback.htm for detailed recycling
information in dierent regions.
Power Safety Requirement
Products with electrical current ratings up to 6A and weighing
more than 3Kg must use approved power cords greater than or
equal to: H05VV-F, 3G, 0.75 mm2 or H05VV-F, 2G, 0.75 mm2.
Coating notice
IMPORTANT! To provide electrical insulation and maintain
electrical safety, a coating is applied to insulate the device
exceptontheareaswheretheI/Oportsarelocated.
Green ASUS notice
ASUS is devoted to creating environment-friendly products and
packaging to safeguard consumers’ health while minimizing
the impact on the environment. The reduction of the number
of the manual pages complies with the reduction of carbon
emission.
For the detailed user manual and related information, refer to
the user manual included in the ASUS Tablet or visit the ASUS
Support Site at http://support.asus.com/.
![](/img.php?id=2345968&img=bg13.png)
ASUS Tablet
19
DRAFT v3
Regional notice for Singapore
ThisASUSproductcomplieswithIDA
Standards.
Complies with
IDA Standards
DB103778
Proper disposal
Risk of explosion if battery is replaced by
an incorrect type. Dispose of used batteries
according to the instructions.
DO NOT throw the battery in municipal waste. The
symbol of the crossed out wheeled bin indicates
that the battery should not be placed in municipal
waste.
DO NOT throw the ASUS Tablet in municipal
waste. This product has been designed to enable
proper reuse of parts and recycling. The symbol
of the crossed out wheeled bin indicates that the
product (electrical, electronic equipment and
mercury-containing button cell battery) should
not be placed in municipal waste. Check local
regulations for disposal of electronic products.
DO NOT throw the ASUS Tablet in re. DO NOT
short circuit the contacts. DO NOT disassemble the
ASUS Tablet.
![](/img.php?id=2345968&img=bg14.png)
Model name: K007
ASUS Tablet
20
DRAFT v3
Copyright Information
No part of this manual, including the products and software
described in it, may be reproduced, transmitted, transcribed,
stored in a retrieval system, or translate into any language in
any form or by any means, except documentation kept by the
purchaser for backup purposes, without the express written
permissionofASUSTeKCOMPUTERINC.(“ASUS”).
ASUS and ASUS Tablet logo are trademarks of ASUSTek
ComputerInc.
Informationinthisdocumentissubjecttochangewithout
notice.
Copyright © 2014 ASUSTeK COMPUTER INC. All Rights
Reserved.
Manufacturer ASUSTekCOMPUTERINC.
Address, City 4F,No.150,LI-TERD.,PEITOU,
TAIPEI112,TAIWAN
Authorized
Representative
in Europe
ASUS COMPUTER GmbH
Address, City HARKORTSTR.21-23,40880RATINGEN
Country GERMANY
![](/img.php?id=2345968&img=bg15.png)
![](/img.php?id=2345968&img=bg16.png)
support.asus.com
XXXXX-XXXXXXXX
