ASUSTeK Computer K00C ASUS Tablet User Manual

ASUSTeK Computer Inc ASUS Tablet

User Manual

Mobile Dock
ASUS
ASUS Tablet
USER MANUAL
E8315
E8315_TF701T_UM.indd 1 8/15/13 9:49:13 AM
Charging your device
Ensure to fully charge your ASUS Tablet before using it in
battery mode for extended periods. Remember that the power
adapter charges your ASUS Tablet as long as it is plugged into
an AC power source. Be aware that it takes much longer to
charge the ASUS Tablet when it is in use.
IMPORTANT! Do not leave the ASUS Tablet connected to
the power supply once it is fully charged. ASUS Tablet is not
designed to be left connected to the power supply for extended
periods of time.
Airplane precautions
Contact your airline provider to learn about related inight
services that can be used and restrictions that must be followed
when using your ASUS Tablet in-ight.
IMPORTANT! You can send your ASUS Tablet through x-ray
machines (used on items placed on conveyor belts), but do not
expose them from magnetic detectors and wands.
Safety precautions
This ASUS Tablet should only be used in enviroments with
ambient temperatures between 0°C (32°F) and 35°C (95°F).
Long time exposure to extremely high or low temperature
may quickly deplete and shorten the battery life. To ensure the
batterys optimal performance, ensure that it is exposed within
the recommended environment temperature.
E8315_TF701T_UM.indd 2 8/15/13 9:49:13 AM
ASUS Tablet
3
Package contents
NOTES:
If any of the items is damaged or missing, contact your
retailer.
The bundled power adapter varies with country or region.
USB Dock cable
ASUS Tablet Power adapter
ASUS Tablet
User manual Warranty card
E8315_TF701T_UM.indd 3 8/15/13 9:49:15 AM
ASUS Tablet
4
Your ASUS Tablet
Front view
Rear view
Ambient light sensor Front camera
Touch screen
panel
Microphone
Audio
speaker
Rear camera Power button
Volume
button
MicroSD
card slot*
Micro HDMI
port
Speaker/
Headset port
Dock portHinge hole Hinge hole
*The microSD card slot supports microSD, microSDHC, and microSDXC card formats.
E8315_TF701T_UM.indd 4 8/15/13 9:49:15 AM
ASUS Tablet
5
Charging your ASUS Tablet
To charge your ASUS Tablet:
Connect the USB Dock cable to the power adapter.
Plug the 36-pin connector into your ASUS Tablet.
Plug the power adapter into a grounded power outlet.
Charge your ASUS Tablet for eight (8) hours before
using it in battery mode for the rst time.
E8315_TF701T_UM.indd 5 8/15/13 9:49:17 AM
ASUS Tablet
6
IMPORTANT!
Use only the bundled power adapter and the USB Dock cable
to charge your ASUS Tablet. Using a dierent power adapter
may damage your ASUS Tablet.
Peel the protective lm o from the power adapter and USB
Dock cable before charging the ASUS Tablet to prevent risk or
injury.
Ensure that you plug the power adapter to the correct power
outlet with the correct input rating. The output voltage of this
adapter is DC 15V, 1.2A.
Ensure that the 36-pin connector is fully inserted into your
ASUS Tablet.
When using your ASUS Tablet while plugged-in to a power
outlet, the grounded power outlet must be near the unit and
easily accessible.
Do not place objects on top of your ASUS Tablet.
NOTES:
Your ASUS Tablet can be charged via the USB port on a
computer only when it is in sleep mode (screen o) or turned
o.
Charging through a USB port of a computer may take longer
time to complete.
If your computer does not provide enough power for
charging your ASUS Tablet, charge your ASUS Tablet via the
grounded power outlet instead.
E8315_TF701T_UM.indd 6 8/15/13 9:49:17 AM
ASUS Tablet
7
Appendices
Federal Communications Commission
Statement
This device complies with FCC Rules Part 15. Operation is
subject to the following two conditions:
This device may not cause harmful interference.
This device must accept any interference received, including
interference that may cause undesired operation.
This equipment has been tested and found to comply with
the limits for a class B digital device, pursuant to Part 15 of the
Federal Communications Commission (FCC) rules. These limits
are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment
generates, uses, and can radiate radio frequency energy and,
if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur
in a particular installation. If this equipment causes harmful
interference to radio or television reception, which can be
determined by turning the equipment o and on, the user is
encouraged to try to correct the interference by doing one or
more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and
receiver.
Connect the equipment into an outlet on a circuit dierent
from that to which the receiver is connected.
E8315_TF701T_UM.indd 7 8/15/13 9:49:17 AM
ASUS Tablet
8
Consult the dealer or an experienced radio/TV technician for
help.
Changes or modications not expressly approved by the party
responsible for compliance could void the user‘s authority to
operate the equipment.
This device and it's antennas(s) must not be co-located or operating
in conjunction with any other antenna or transmitter except in
accordance with FCC multi-transmitter product procedures.
Operation on the 5.15-5.25 GHz frequency band is restricted for
indoor use only. The FCC requires indoor use for the 5.15-5.25
GHz band to reduce the potential for harmful interference to
co-channel Mobile Satellite Systems.
RF Exposure Information (SAR)
This device meets the government’s requirements for exposure
to radio waves. This device is designed and manufactured not
to exceed the emission limits for exposure to radio frequency
(RF) energy set by the Federal Communications Commission of
the U.S. Government.
The exposure standard employs a unit of measurement
known as the Specic Absorption Rate, or SAR.Tests for SAR are
conducted using standard operating positions accepted by the FCC
with the EUT transmitting at the specied power level in dierent channels.
Federal Communication Commission (FCC) Radiation Exposure Statement
This EUT is compliant with SAR for general population/uncontrolled exposure
limits in ANSI/IEEE C95.1-1999 and has been tested in accordance with the
measurement methods and procedures specified in OET Bulletin 65 Supplement
C.
E8315_TF701T_UM.indd 8 8/15/13 9:49:17 AM
ASUS Tablet
9
The FCC has granted an Equipment Authorization for this device
with all reported SAR levels evaluated as in compliance with the
FCC RF exposure guidelines. SAR information on this device is
on le with the FCC and can be found under the Display Grant
section of www.fcc.gov/oet/ea/fccid after searching on FCC ID:
MSQK00C.
Canada, Industry Canada (IC) Notices
CAN ICES-3 (B)/NMB-3(B).
Operation is subject to the This device complies with Industry Canada
license-exempt RSS standard(s). Operation is subject to the following
two conditions: (1) this device may not cause interference, and (2) this device
must accept any interference, including interference that may cause undesired
operation of the device.: (1) this device may not cause interference, and
(2) this device must accept any interference, including interference that
may cause undesired operation of the device. The IC ID for this device is
3568A-K00C.
Radio Frequency (RF) Exposure Information
The radiated output power of the Wireless Device is below
the Industry Canada (IC) radio frequency exposure limits. The
Wireless Device should be used in such a manner such that
the potential for human contact during normal operation is
minimized.
This device has been evaluated for and shown compliant with
the IC Specic Absorption Rate (“SAR”) limits when installed
in specic host products operated in portable exposure
conditions.
E8315_TF701T_UM.indd 9 8/15/13 9:49:17 AM
ASUS Tablet
10
Canada, avis d’Industrie Canada (IC)
CAN ICES-3 (B)/NMB-3(B).
Son Le pr?sent appareil est conforme aux CNR d'Industrie Canada
applicables aux appareils radio exempts de licence. L'exploitation est autoris?
e aux deux conditions suivantes : (1) l'appareil ne doit pas produire de
brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage
radio?lectrique subi, m?me si le brouillage est susceptible d'en compromettre
le fonctionnement. suivantes: (1) cet appareil ne doit pas causer d’interférence
et (2) cet appareil doit accepter toute interférence, notamment les
interférences qui peuvent aecter son fonctionnement. Lidentiant IC de cet
appareil est 3568A-K00C.
Inf orma tions concernant l exp osition aux fr équences
radio (RF)
La puissance de sortie émise par cet appareil sans l est
inférieure à la limite d’exposition aux fréquences radio d’
Industrie Canada (IC). Utilisez l’appareil sans l de façon à
minimiser les contacts humains lors du fonctionnement normal.
Ce périphérique a été évalué et démontré conforme aux limites
SAR (Specic Absorption Rate – Taux d’absorption spécique) d’
IC lorsqu’il est installé dans des produits hôtes particuliers qui
fonctionnent dans des conditions d’exposition à des appareils
portables.
Canadas REL (Radio Equipment List) can be found at the
following web address:
http://www.ic.gc.ca/app/sitt/reltel/srch/nwRdSrch.
do?lang=eng
Additional Canadian information on RF exposure also can be
found at the following web address:
http://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf08792.html
E8315_TF701T_UM.indd 10 8/15/13 9:49:17 AM
ASUS Tablet
11
Ce périphérique est homologué pour l’utilisation au Canada.
Pour consulter lentrée correspondant à l’appareil dans la liste
d’équipement radio (REL - Radio Equipment List) d’Industrie
Canada rendez-vous sur:
http://www.ic.gc.ca/app/sitt/reltel/srch/nwRdSrch.
do?lang=eng
Pour des informations supplémentaires concernant l’exposition
aux RF au Canada rendez-vous sur :
http://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf08792.html
IC Warning Statement
The device could automatically discontinue transmission in
case of absence of information to transmit, or operational
failure. Note that this is not intended to prohibit transmission of
control or signaling information or the use of repetitive codes
where required by the technology.
The device for the band 5150-5250 MHz is only for indoor usage
to reduce potential for harmful interference to co-channel
mobile satellite systems.
E8315_TF701T_UM.indd 11 8/15/13 9:49:18 AM
ICStatement:
PourlesproduitsdisponiblesauxÉtatsUnis/Canadadumarché,seullecanal1à11peuventêtre
exploités.Sélectiond'autrescanauxn'estpaspossible.
This device and it's antennas(s) must not be co-located or operating in conjunction with any
other antenna or transmitter except in accordance with IC multi-transmitter product
procedures.
Cetappareiletsonantenne(s)nedoitpasêtrecolocalisésoufonctionnementenassociationavecune
autreantenneoutransmetteur.
Le dispositif pourrait automatiquement cesser d'émettre en cas d'absence d'informations à transmettre,
ou une défaillance opérationnelle. Notez que ce n'est pas l'intention d'interdire la transmission des
informations de contrôle ou de signalisation ou l'utilisation de codes répétitifs lorsque requis par la
technologie.
lesdispositifsfonctionnantdanslabande51505250MHzsontréservésuniquementpourune
utilisationàl’intérieurafinderéduirelesrisquesdebrouillagepréjudiciableauxsystèmesdesatellites
mobilesutilisantlesmêmescanaux;
IC Radiation Exposure Statement:
This EUT is compliance with SAR for general population/uncontrolled exposure limits in IC
RSS-102 and had been tested in accordance with the measurement methods and procedures
specified in IEEE 1528.
ASUS Tablet
12
The Country Code Selection feature is disabled for products
marketed in the US/Canada. For product available in the USA/
Canada markets, only channel 1-11 can be operated. Selection
of other channels is not possible.
EC Declaration of Conformity
This product is compliant with the regulations of the R&TTE
Directive 1999/5/EC. The Declaration of Conformity can be
downloaded from http://support.asus.com.
Limitation of Liability
Circumstances may arise where because of a default on ASUS’
part or other liability, you are entitled to recover damages from
ASUS. In each such instance, regardless of the basis on which
you are entitled to claim damages from ASUS, ASUS is liable
for no more than damages for bodily injury (including death)
and damage to real property and tangible personal property;
or any other actual and direct damages resulted from omission
or failure of performing legal duties under this Warranty
Statement, up to the listed contract price of each product.
ASUS will only be responsible for or indemnify you for loss,
damages or claims based in contract, tort or infringement
under this Warranty Statement.
This limit also applies to ASUS’ suppliers and its reseller. It is the
maximum for which ASUS, its suppliers, and your reseller are
collectively responsible.
E8315_TF701T_UM.indd 12 8/15/13 9:49:18 AM
ASUS Tablet
13
Prevention of Hearing Loss
To prevent possible hearing damage, do not listen at high
volume levels for long periods.
For France, headphones/earphones for this device are
compliant with the sound pressure level requirement laid down
in the applicable EN 50332-1:2000 and/or EN50332-2:2003
standard required by French Article L.5232-1.
UNDER NO CIRCUMSTANCES IS ASUS LIABLE FOR ANY OF THE
FOLLOWING: (1) THIRD-PARTY CLAIMS AGAINST YOU FOR
DAMAGES; (2) LOSS OF, OR DAMAGE TO, YOUR RECORDS OR
DATA; OR (3) SPECIAL, INCIDENTAL, OR INDIRECT DAMAGES OR
FOR ANY ECONOMIC CONSEQUENTIAL DAMAGES (INCLUDING
LOST PROFITS OR SAVINGS), EVEN IF ASUS, ITS SUPPLIERS OR
YOUR RESELLER IS INFORMED OF THEIR POSSIBILITY.
E8315_TF701T_UM.indd 13 8/15/13 9:49:18 AM
ASUS Tablet
14
CE Mark Warning
CE marking for devices with wireless LAN/ Bluetooth
This equipment complies with the requirements of Directive
1999/5/EC of the European Parliament and Commission from
9 March, 1999 governing Radio and Telecommunications
Equipment and mutual recognition of conformity.
The highest CE SAR value for the device is 0.530 W/Kg.
This equipment may be operated in:
AT BE BG CH CY CZ DE DK
EE ES FI FR GB GR HU IE
IT IS LI LT LU LV MT NL
NO PL PT RO SE SI SK TR
DFS controls related to radar detection shall not be accessible
to the user.
This device is restricted for indoor use only when operating
under 5150 MHz to 5350 MHz of frequency range.
E8315_TF701T_UM.indd 14 8/15/13 9:49:19 AM
ASUS Tablet
15
RF Exposure information (SAR) - CE
This device meets the EU requirements (1999/519/EC) on the
limitation of exposure of the general public to electromagnetic
elds by way of health protection.
The limits are part of extensive recommendations for the
protection of the general public. These recommendations
have been developed and checked by independent scientic
organizations through regular and thorough evaluations of
scientic studies. The unit of measurement for the European
Council’s recommended limit for mobile devices is the “Specic
Absorption Rate” (SAR), and the SAR limit is 2.0 W/Kg averaged
over 10 gram of body tissue. It meets the requirements of the
International Commission on Non-Ionizing Radiation Protection
(ICNIRP).
For next-to-body operation, this device has been tested and
meets the ICNRP exposure guidelines and the European
Standard EN 62311 and EN 62209-2. SAR is measured with the
device directly contacted to the body while transmitting at the
highest certied output power level in all frequency bands of
the mobile device.
E8315_TF701T_UM.indd 15 8/15/13 9:49:19 AM
ASUS Tablet
16
ASUS Recycling/Takeback Services
ASUS recycling and takeback programs come from our
commitment to the highest standards for protecting our
environment. We believe in providing solutions for you to
be able to responsibly recycle our products, batteries, other
components as well as the packaging materials. Please go to
http://csr.asus.com/english/Takeback.htm for detailed recycling
information in dierent regions.
Power Safety Requirement
Products with electrical current ratings up to 6A and weighing
more than 3Kg must use approved power cords greater than or
equal to: H05VV-F, 3G, 0.75mm2 or H05VV-F, 2G, 0.75mm2.
Coating notice
IMPORTANT! To provide electrical insulation and maintain
electrical safety, a coating is applied to insulate the device
except on the areas where the I/O ports are located.
Green ASUS notice
ASUS is devoted to creating environment-friendly products and
packaging to safeguard consumers health while minimizing
the impact on the environment. The reduction of the number
of the manual pages complies with the reduction of carbon
emission.
For the detailed user manual and related information, refer to
the user manual included in the ASUS Tablet or visit the ASUS
Support Site at http://support.asus.com/.
E8315_TF701T_UM.indd 16 8/15/13 9:49:19 AM
ASUS Tablet
17
Proper disposal
Risk of explosion if battery is replaced by
an incorrect type. Dispose of used batteries
according to the instructions.
DO NOT throw the battery in municipal waste. The
symbol of the crossed out wheeled bin indicates
that the battery should not be placed in municipal
waste.
DO NOT throw the ASUS Tablet in municipal
waste. This product has been designed to enable
proper reuse of parts and recycling. The symbol
of the crossed out wheeled bin indicates that the
product (electrical, electronic equipment and
mercury-containing button cell battery) should
not be placed in municipal waste. Check local
regulations for disposal of electronic products.
DO NOT throw the ASUS Tablet in re. DO NOT
short circuit the contacts. DO NOT disassemble the
ASUS Tablet.
Regional notice for Singapore
This ASUS product complies with IDA
Standards.
Complies with
IDA Standards
DB103778
E8315_TF701T_UM.indd 17 8/15/13 9:49:20 AM
Model name: K00C
ASUS Tablet
18
Copyright Information
No part of this manual, including the products and software
described in it, may be reproduced, transmitted, transcribed,
stored in a retrieval system, or translate into any language in
any form or by any means, except documentation kept by the
purchaser for backup purposes, without the express written
permission of ASUSTeK COMPUTER INC. (“ASUS”).
ASUS and ASUS Tablet logo are trademarks of ASUSTek
Computer Inc.
Information in this document is subject to change without
notice.
Copyright © 2013 ASUSTeK COMPUTER INC. All Rights
Reserved.
Manufacturer ASUSTek COMPUTER INC.
Address, City 4F, No. 150, LI-TE RD., PEITOU,
TAIPEI 112, TAIWAN
Country TAIWAN
Authorized
Representative
in Europe
ASUS COMPUTER GmbH
Address, City HARKORT STR. 21-23, 40880 RATINGEN
Country GERMANY
E8315_TF701T_UM.indd 18 8/15/13 9:49:20 AM
ASUS Tablet
19
EC Declaration of Conformity
We, the undersigned,
Manufacturer: ASUSTeK COMPUTER INC.
Address, City: 4F, No. 150, LI-TE Rd., PEITOU, TAIPEI 112, TAIWAN
Country: TAIWAN
Authorized representative in Europe: ASUS COMPUTER GmbH
Address, City: HARKORT STR. 21-23, 40880 RATINGEN
Country: GERMANY
declare the following apparatus:
Product name : ASUS Tablet
Model name : K00C
conform with the essential requirements of the following directives:
2004/108/EC-EMC Directive
EN 55022:2010
EN 61000-3-2:2006+A2:2009
EN 55013:2001+A1:2003+A2:2006
EN 55024:2010
EN 61000-3-3:2008
EN 55020:2007+A11:2011
1999/5/EC-R &TTE Directive
EN 300 328 V1.7.1(2006-10)
EN 300 440-1 V1.6.1(2010-08)
EN 300 440-2 V1.4.1(2010-08)
EN 301 511 V9.0.2(2003-03)
EN 301 908-1 V5.2.1(2011-05)
EN 301 908-2 V5.2.1(2011-07)
EN 301 893 V1.6.1(2011-11)
EN 302 544-2 V1.1.1(2009-01)
EN 302 623 V1.1.1(2009-01)
EN 50360:2001
EN 62479:2010
EN 50385:2002
EN 62311:2008
EN 301 489-1 V1.9.2(2011-09)
EN 301 489-3 V1.4.1(2002-08)
EN 301 489-4 V1.4.1(2009-05)
EN 301 489-7 V1.3.1(2005-11)
EN 301 489-9 V1.4.1(2007-11)
EN 301 489-17 V2.1.1(2009-05)
EN 301 489-24 V1.5.1(2010-09)
EN 302 326-2 V1.2.2(2007-06)
EN 302 326-3 V1.3.1(2007-09)
EN 301 357-2 V1.4.1(2008-11)
EN 302 291-1 V1.1.1(2005-07)
EN 302 291-2 V1.1.1(2005-07)
2006/95/EC-LVD Directive
EN 60950-1 / A12:2011 EN 60065:2002 / A12:2011
2009/125/EC-ErP Directive
Regulation (EC) No. 1275/2008
Regulation (EC) No. 642/2009
Regulation (EC) No. 278/2009
2011/65/EU-RoHS Directive
Ver. 130208
CE marking
Declaration Date: 08/08/2013
Year to begin affixing CE marking:2013
Position : CEO
Name : Jerry Shen
Signature :
__________
(EC conformity marking)
0682
E8315_TF701T_UM.indd 19 8/15/13 9:49:21 AM
support.asus.com
15060-16500000
E8315_TF701T_UM.indd 20 8/15/13 9:49:21 AM

Navigation menu
