ASUSTeK Computer K010 ASUS TABLET User Manual

ASUSTeK Computer Inc ASUS TABLET

Contents

User Manual

USER GUIDE
ASUS Tablet
E9029
First Edition
March 2014
Charging your device
Ensure to fully charge your ASUS Tablet before using it in
battery mode for extended periods. Remember that the power
adapter charges your ASUS Tablet as long as it is plugged into
an AC power source. Be aware that it takes much longer to
charge the ASUS Tablet when it is in use.
IMPORTANT! Do not leave the ASUS Tablet connected to
the power supply once it is fully charged. ASUS Tablet is not
designed to be left connected to the power supply for extended
periods of time.
Airplane precautions
Contact your airline provider to learn about related inight
services that can be used and restrictions that must be followed
when using your ASUS Tablet in-ight.
IMPORTANT! You can send your ASUS Tablet through x-ray
machines (used on items placed on conveyor belts), but do not
expose them from magnetic detectors and wands.
Safety precautions
This ASUS Tablet should only be used in enviroments with
ambient temperatures between 0°C to 35°C (32°F to 95°F).
Long time exposure to extremely high or low temperature
may quickly deplete and shorten the battery life. To ensure the
battery’s optimal performance, ensure that it is exposed within
the recommended environment temperature.
ASUS Tablet
3
DRAFT v6.1
Package contents
NOTES:
• Ifanyoftheitemsisdamagedormissing,contactyour
retailer.
• Thebundledpoweradaptervarieswithcountryorregion.
Micro USB cable
ASUS Tablet Power adapter
ASUS Tablet
USER GUIDE
User guide Warranty card
ASUS Tablet
4
DRAFT v6.1
Your ASUS Tablet
Front view
Front camera
Touch screen panel
ASUS Tablet
5
DRAFT v6.1
Rear view
Microphone
Audio speaker
Rear camera
Power button
Volume button
MicroSD card slot*
Micro USB
2.0 port
Speaker/
Headset port
Dock port
Hinge hole Hinge hole
* The microSD card slot supports microSD, microSDHC, and microSDXC card formats.
** The model with NFC tag may vary by country or region.
Audio speaker
NFC tag**
ASUS Tablet
6
DRAFT v6.1
Charging your ASUS Tablet
To charge your ASUS Tablet:
Charge your ASUS Tablet for eight (8) hours before
using it in battery mode for the rst time.
Connect the micro USB cable to the power adapter.
Plug the micro USB connector into your ASUS Tablet.
Plug the power adapter into a grounded power outlet.
ASUS Tablet
7
DRAFT v6.1
IMPORTANT!
• UseonlythebundledpoweradapterandthemicroUSBcable
to charge your ASUS Tablet. Using a dierent power adapter
may damage your ASUS Tablet.
• Peeltheprotectivelmofromthepoweradapterandmicro
USB cable before charging the ASUS Tablet to prevent risk or
injury.
• Ensurethatyouplugthepoweradaptertothecorrectpower
outlet with the correct input rating. The output voltage of this
adapter is DC 5.2 V, 1.35 A.
• WhenusingyourASUSTabletwhileplugged-intoapower
outlet, the grounded power outlet must be near the unit and
easily accessible.
• DonotplaceobjectsontopofyourASUSTablet.
NOTES:
• YourASUSTabletcanbechargedviatheUSBportona
computer only when it is in sleep mode (screen o) or turned
o.
• ChargingthroughaUSBportofacomputermaytakelonger
time to complete.
• Ifyourcomputerdoesnotprovideenoughpowerfor
charging your ASUS Tablet, charge your ASUS Tablet via the
grounded power outlet instead.
ASUS Tablet
8
DRAFT v6.1
Appendices
Federal Communications Commission
Statement
This device complies with FCC Rules Part 15. Operation is
subject to the following two conditions:
• Thisdevicemaynotcauseharmfulinterference.
• Thisdevicemustacceptanyinterferencereceived,including
interference that may cause undesired operation.
This equipment has been tested and found to comply with
the limits for a class B digital device, pursuant to Part 15 of the
Federal Communications Commission (FCC) rules. These limits
are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment
generates, uses, and can radiate radio frequency energy and,
if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur
inaparticularinstallation.Ifthisequipmentcausesharmful
interference to radio or television reception, which can be
determined by turning the equipment o and on, the user is
encouraged to try to correct the interference by doing one or
more of the following measures:
• Reorientorrelocatethereceivingantenna.
• Increasetheseparationbetweentheequipmentand
receiver.
• Connecttheequipmentintoanoutletonacircuitdierent
from that to which the receiver is connected.
ASUS Tablet
9
DRAFT v6.1
• Consultthedealeroranexperiencedradio/TVtechnicianfor
help.
Changes or modications not expressly approved by the party
responsible for compliance could void the user‘s authority to
operate the equipment.
The antenna(s) used for this transmitter must not be co-
located or operating in conjunction with any other antenna or
transmitter.
Operation on the 5.15-5.25 GHz frequency band is restricted for
indoor use only. The FCC requires indoor use for the 5.15-5.25
GHz band to reduce the potential for harmful interference to
co-channelMobileSatelliteSystems.Itwillonlytransmiton
5.25-5.35 GHz, 5.47-5.725 GHz and 5.725-5.850 GHz bands
when associated with an access point (AP).
RF Exposure Information (SAR)
This device meets the government’s requirements for exposure
to radio waves. This device is designed and manufactured not
to exceed the emission limits for exposure to radio frequency
(RF) energy set by the Federal Communications Commission of
the U.S. Government.
The exposure standard employs a unit of measurement
known as the Specic Absorption Rate, or SAR. The SAR limit
set by the FCC is 1.6 W/kg. Tests for SAR are conducted using
standard operating positions accepted by the FCC with the EUT
transmitting at the specied power level in dierent channels.
The highest SAR value for the device as reported to the FCC is
1.14 W/kg when placed next to the body.
ASUS Tablet
10
DRAFT v6.1
The FCC has granted an Equipment Authorization for this device
with all reported SAR levels evaluated as in compliance with the
FCC RF exposure guidelines. SAR information on this device is
on le with the FCC and can be found under the Display Grant
section of www.fcc.gov/oet/ea/fccidaftersearchingonFCCID:
MSQK010.
Canada, Industry Canada (IC) Notices
ThisClassBdigitalapparatuscomplieswithCanadianICES-003,
RSS-210,andCANICES-3(B)/NMB-3(B).
Operation is subject to the following two conditions: (1) this
device may not cause interference, and (2) this device must
accept any interference, including interference that may cause
undesiredoperationofthedevice.TheICIDforthisdeviceis
3568A-K010.
Radio Frequency (RF) Exposure Information
The radiated output power of the Wireless Device is below
theIndustryCanada(IC)radiofrequencyexposurelimits.The
Wireless Device should be used in such a manner such that
the potential for human contact during normal operation is
minimized.
This device has been evaluated for and shown compliant with
theICSpecicAbsorptionRate(“SAR”)limitswheninstalled
in specic host products operated in portable exposure
conditions.
ASUS Tablet
11
DRAFT v6.1
Canada, avis d’Industrie Canada (IC)
Cet appareil numérique de classe B est conforme aux normes
canadiennesICES-003,RSS-210,etCANICES-3(B)/NMB-3(B).
Son fonctionnement est soumis aux deux conditions suivantes:
(1) cet appareil ne doit pas causer d’interférence et (2) cet
appareil doit accepter toute interférence, notamment les
interférences qui peuvent aecter son fonctionnement.
L’identiantICdecetappareilest3568A-K010.
Informations concernant l’exposition aux fréquences
radio (RF)
La puissance de sortie émise par cet appareil sans l est
inférieure à la limite d’exposition aux fréquences radio d’
IndustrieCanada(IC).Utilisezl’appareilsansldefaçonà
minimiser les contacts humains lors du fonctionnement normal.
Ce périphérique a été évalué et démontré conforme aux limites
SAR (Specic Absorption Rate – Taux d’absorption spécique) d’
IClorsqu’ilestinstallédansdesproduitshôtesparticuliersqui
fonctionnent dans des conditions d’exposition à des appareils
portables.
Canada’s REL (Radio Equipment List) can be found at the
following web address:
http://www.ic.gc.ca/app/sitt/reltel/srch/nwRdSrch.
do?lang=eng
Additional Canadian information on RF exposure also can be
found at the following web address:
http://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf08792.html
ASUS Tablet
12
DRAFT v6.1
Ce périphérique est homologué pour l’utilisation au Canada.
Pour consulter l’entrée correspondant à l’appareil dans la liste
d’équipementradio(REL-RadioEquipmentList)d’Industrie
Canada rendez-vous sur:
http://www.ic.gc.ca/app/sitt/reltel/srch/nwRdSrch.
do?lang=eng
Pour des informations supplémentaires concernant l’exposition
aux RF au Canada rendez-vous sur :
http://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf08792.html
IC Warning Statement
The device could automatically discontinue transmission in
case of absence of information to transmit, or operational
failure. Note that this is not intended to prohibit transmission of
control or signaling information or the use of repetitive codes
where required by the technology.
The device for the band 5150-5250 MHz is only for indoor usage
to reduce potential for harmful interference to co-channel
mobile satellite systems; the maximum antenna gain permitted
(for device in the bands 5250-5350 MHz and 5470-5725 MHz)
tocomplywiththeEIRPlimit;andthemaximumantennagain
permitted (for devices in the band 5275-5850 MHz) to comply
withtheEIRPlimitsspeciedforpoint-to-pointandnonpoint-
to-point operation as appropriate, as stated in section A9.2(3).
Inaddition,high-powerradarsareallocatedasprimaryusers
(meaning they have priority) of the band 5250-5350 MHz and
this radar could cause interference and/or damage to LE-LAN
devices.
ASUS Tablet
13
DRAFT v6.1
The Country Code Selection feature is disabled for products
marketed in the US/Canada. For product available in the USA/
Canada markets, only channel 1-11 can be operated. Selection
of other channels is not possible.
EC Declaration of Conformity
This product is compliant with the regulations of the R&TTE
Directive 1999/5/EC. The Declaration of Conformity can be
downloaded from http://support.asus.com.
Limitation of Liability
Circumstances may arise where because of a default on ASUS’
part or other liability, you are entitled to recover damages from
ASUS.Ineachsuchinstance,regardlessofthebasisonwhich
you are entitled to claim damages from ASUS, ASUS is liable
for no more than damages for bodily injury (including death)
and damage to real property and tangible personal property;
or any other actual and direct damages resulted from omission
or failure of performing legal duties under this Warranty
Statement, up to the listed contract price of each product.
ASUS will only be responsible for or indemnify you for loss,
damages or claims based in contract, tort or infringement
under this Warranty Statement.
ThislimitalsoappliestoASUS’suppliersanditsreseller.Itisthe
maximum for which ASUS, its suppliers, and your reseller are
collectively responsible.
ASUS Tablet
14
DRAFT v6.1
Prevention of Hearing Loss
To prevent possible hearing damage, do not listen at high
volume levels for long periods.
For France, headphones/earphones for this device are
compliant with the sound pressure level requirement laid down
in the applicable EN 50332-1:2000 and/or EN50332-2:2003
standard required by French Article L.5232-1.
UNDERNOCIRCUMSTANCESISASUSLIABLEFORANYOFTHE
FOLLOWING:(1)THIRD-PARTYCLAIMSAGAINSTYOUFOR
DAMAGES; (2) LOSS OF, OR DAMAGE TO, YOUR RECORDS OR
DATA;OR(3)SPECIAL,INCIDENTAL,ORINDIRECTDAMAGESOR
FORANYECONOMICCONSEQUENTIALDAMAGES(INCLUDING
LOSTPROFITSORSAVINGS),EVENIFASUS,ITSSUPPLIERSOR
YOURRESELLERISINFORMEDOFTHEIRPOSSIBILITY.
ASUS Tablet
15
DRAFT v6.1
CE Mark Warning
CE marking for devices with wireless LAN/ Bluetooth
This equipment complies with the requirements of Directive
1999/5/EC of the European Parliament and Commission from
9 March, 1999 governing Radio and Telecommunications
Equipment and mutual recognition of conformity.
The highest CE SAR value for the device is 0.324 W/Kg.
This equipment may be operated in:
AT BE BG CH CY CZ DE DK
EE ES FI FR GB GR HU IE
IT IS LI LT LU LV MT NL
NO PL PT RO SE SI SK TR
DFS controls related to radar detection shall not be accessible
to the user.
This device is restricted for indoor use only when operating
under 5150 MHz to 5350 MHz of frequency range.
ASUS Tablet
16
DRAFT v6.1
Rechargeable Battery Recycling Service in
North America
For US and Canada customers, you can
call 1-800-822-8837 (toll-free) for recycling
information of your ASUS products’
rechargeable batteries.
RF Exposure information (SAR) - CE
This device meets the EU requirements (1999/519/EC) on the
limitation of exposure of the general public to electromagnetic
elds by way of health protection.
The limits are part of extensive recommendations for the
protection of the general public. These recommendations
have been developed and checked by independent scientic
organizations through regular and thorough evaluations of
scientic studies. The unit of measurement for the European
Council’srecommendedlimitformobiledevicesisthe“Specic
AbsorptionRate”(SAR),andtheSARlimitis2.0 W/Kg averaged
over10gramofbodytissue.Itmeetstherequirementsofthe
InternationalCommissiononNon-IonizingRadiationProtection
(ICNIRP).
For next-to-body operation, this device has been tested and
meetstheICNRPexposureguidelinesandtheEuropean
Standard EN 62311 and EN 62209-2. SAR is measured with the
device directly contacted to the body while transmitting at the
highest certied output power level in all frequency bands of
the mobile device.
ASUS Tablet
17
DRAFT v6.1
ASUS Recycling/Takeback Services
ASUS recycling and takeback programs come from our
commitment to the highest standards for protecting our
environment. We believe in providing solutions for you to
be able to responsibly recycle our products, batteries, other
components as well as the packaging materials. Please go to
http://csr.asus.com/english/Takeback.htm for detailed recycling
information in dierent regions.
Power Safety Requirement
Products with electrical current ratings up to 6 A and weighing
more than 3 Kg must use approved power cords greater than or
equal to: H05VV-F, 3G, 0.75 mm2 or H05VV-F, 2G, 0.75 mm2.
India RoHS
Thisproductcomplieswiththe“IndiaE-waste(Management
andHandling)Rule2011”andprohibitsuseoflead,mercury,
hexavalent chromium, polybrominated biphenyls (PBBs) and
polybrominated diphenyl ethers (PBDEs) in concentrations
exceeding 0.1% by weight in homogenous materials and 0.01%
by weight in homogenous materials for cadmium, except for
theexemptionslistedinSchedule-IIoftheRule.
ASUS Tablet
18
DRAFT v6.1
Coating notice
IMPORTANT! To provide electrical insulation and maintain
electrical safety, a coating is applied to insulate the device
exceptontheareaswheretheI/Oportsarelocated.
Green ASUS notice
ASUS is devoted to creating environment-friendly products and
packaging to safeguard consumers’ health while minimizing
the impact on the environment. The reduction of the number
of the manual pages complies with the reduction of carbon
emission.
For the detailed user manual and related information, refer to
the user manual included in the ASUS Tablet or visit the ASUS
Support Site at http://support.asus.com/.
Regional notice for Singapore
ThisASUSproductcomplieswithIDA
Standards.
Complies with
IDA Standards
DB103778
ASUS Tablet
19
DRAFT v6.1
Proper disposal
Risk of explosion if battery is replaced by
an incorrect type. Dispose of used batteries
according to the instructions.
DO NOT throw the battery in municipal waste. The
symbol of the crossed out wheeled bin indicates
that the battery should not be placed in municipal
waste.
DO NOT throw the ASUS Tablet in municipal
waste. This product has been designed to enable
proper reuse of parts and recycling. The symbol
of the crossed out wheeled bin indicates that the
product (electrical, electronic equipment and
mercury-containing button cell battery) should
not be placed in municipal waste. Check local
regulations for disposal of electronic products.
DO NOT throw the ASUS Tablet in re. DO NOT
short circuit the contacts. DO NOT disassemble the
ASUS Tablet.
Model name: K010 (TF103C)
ASUS Tablet
20
DRAFT v6.1
Copyright Information
No part of this manual, including the products and software
described in it, may be reproduced, transmitted, transcribed,
stored in a retrieval system, or translate into any language in
any form or by any means, except documentation kept by the
purchaser for backup purposes, without the express written
permissionofASUSTeKCOMPUTERINC.(“ASUS”).
ASUS and ASUS Tablet logo are trademarks of ASUSTek
ComputerInc.
Informationinthisdocumentissubjecttochangewithout
notice.
Copyright © 2014 ASUSTeK COMPUTER INC. All Rights
Reserved.
Manufacturer ASUSTekCOMPUTERINC.
Address, City 4F,No.150,LI-TERD.,PEITOU,
TAIPEI112,TAIWAN
Country TAIWAN
Authorized
Representative
in Europe
ASUS COMPUTER GmbH
Address, City HARKORTSTR.21-23,40880RATINGEN
Country GERMANY
ASUS Tablet
21
DRAFT v6.1
CE DOC HERE
support.asus.com
15060-XXXXXXXX

Navigation menu
