Charging your device
Ensure to fully charge your ASUS Tablet before using it in battery
mode for extended periods. Remember that the power adapter
charges your ASUS Tablet as long as it is plugged into an AC
power source. Be aware that it takes much longer to charge the
ASUS Tablet when it is in use.
IMPORTANT! Do not leave the ASUS Tablet connected to the
power supply once it is fully charged. ASUS Tablet is not designed
to be left connected to the power supply for extended periods of
time.
Airplane precautions
Contact your airline provider to learn about related in-ight
services that can be used and restrictions that must be followed
when using your ASUS Tablet in-ight.
IMPORTANT! You can send your ASUS Tablet through x-ray
machines (used on items placed on conveyor belts), but do not
expose them from magnetic detectors and wands.
Safety precautions
This ASUS Tablet should only be used in environments with
ambient temperatures between 0°C to 35°C (32°F to 95°F).
Long time exposure to extremely high or low temperature
may quickly deplete and shorten the battery life. To ensure the
battery’s optimal performance, ensure that it is exposed within
the recommended environment temperature.
Charging your ASUS Tablet
To charge your ASUS Tablet:
Connect the micro USB cable to the power adapter.
Plug the power adapter into a grounded power outlet.
Plug the micro USB connector into your ASUS Tablet.
Charge your ASUS Tablet for eight (8) hours before
using it in battery mode for the rst time.
IMPORTANT!
• UseonlythebundledpoweradapterandmicroUSBcableto
charge your ASUS Tablet. Using a dierent power adapter may
damage your ASUS Tablet.
• Peeltheprotectivelmofromthepoweradapterandmicro
USB cable before charging the ASUS Tablet to prevent risk or
injury.
• Ensurethatyouplugthepoweradaptertothecorrectpower
outlet with the correct input rating. The output voltage of this
adapter is DC 5.2 V, 1.35 A.
• WhenusingyourASUSTabletwhileplugged-intoapower
outlet, the grounded power outlet must be near the unit and
easily accessible.
• DonotplaceobjectsontopofyourASUSTablet.
NOTES:
• YourASUSTabletcanbechargedviatheUSBportonthe
computer only when it is in sleep mode (screen o) or turned
o.
• ChargingthroughtheUSBportofacomputermaytakelonger
time to complete.
• Ifyourcomputerdoesnotprovideenoughpowerforcharging
your ASUS Tablet, charge your ASUS Tablet via the grounded
power outlet instead.
Installing a microSD card
NOTE: The memory card slot supports microSD, microSDHC, and
microSDXC card formats.
Installing a micro SIM card
NOTE: ThemicroSIMcardslotsupportsWCDMAandEDGE/GSM
bands.
Before you can make calls, send text messages, or connect to a
mobile broadband network using your ASUS Tablet, you need to
installamicroSIM(SubscriberIdentityModule)card.
Speaker/Headsetport
Rear camera
Volume button
Power button
Groove
Microphone
MicroUSB2.0port
Your ASUS Tablet
Audio speaker
Front camera
Touch screen panel
Appendices
Federal Communications Commission Statement
This device complies with FCC Rules Part 15. Operation is subject to the following two conditions:
• Thisdevicemaynotcauseharmfulinterference.
• Thisdevicemustacceptanyinterferencereceived,includinginterferencethatmaycauseundesired
operation.
This equipment has been tested and found to comply with the limits for a class B digital device, pursuant
to Part 15 of the Federal Communications Commission (FCC) rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no guarantee
thatinterferencewillnotoccurinaparticularinstallation.Ifthisequipmentcausesharmfulinterferenceto
radio or television reception, which can be determined by turning the equipment o and on, the user is
encouraged to try to correct the interference by doing one or more of the following measures:
• Reorientorrelocatethereceivingantenna.
• Increasetheseparationbetweentheequipmentandreceiver.
• Connecttheequipmentintoanoutletonacircuitdierentfromthattowhichthereceiveris
connected.
• Consultthedealeroranexperiencedradio/TVtechnicianforhelp.
Changes or modications not expressly approved by the party responsible for compliance could void the
user‘s authority to operate the equipment.
The antenna(s) used for this transmitter must not be co-located or operating in conjunction with any
other antenna or transmitter.
RF Exposure Information (SAR)
This device meets the government’s requirements for exposure to radio waves. This device is designed
and manufactured not to exceed the emission limits for exposure to radio frequency (RF) energy set by
theFederalCommunicationsCommissionoftheU.S.Government.
The exposure standard employs a unit of measurement known as the Specic Absorption Rate, or SAR.
TheSARlimitsetbytheFCCis1.6W/kg.TestsforSARareconductedusingstandardoperatingpositions
accepted by the FCC with the EUT transmitting at the specied power level in dierent channels.
ThehighestSARvalueforthedeviceasreportedtotheFCCis1.19W/kgwhenplacednexttothebody.
The FCC has granted an Equipment Authorization for this device with all reported SAR levels evaluated as
in compliance with the FCC RF exposure guidelines. SAR information on this device is on le with the FCC
andcanbefoundundertheDisplayGrantsectionofwww.fcc.gov/oet/ea/fccidaftersearchingonFCCID:
MSQP01Y.
Canada, Industry Canada (IC) Notices
ThisdevicecomplieswithIndustryCanadalicense-exemptRSSstandard(s).
ThisClassBdigitalapparatuscomplieswithCanadianICES-003andCANICES-3(B)/NMB-3(B).
Operation is subject to the following two conditions: (1) this device may not cause interference, and (2)
this device must accept any interference, including interference that may cause undesired operation of
thedevice.TheICIDforthisdeviceis3568A-P01Y.
Radio Frequency (RF) Exposure Information
TheradiatedoutputpoweroftheWirelessDeviceisbelowtheIndustryCanada(IC)radiofrequency
exposurelimits.TheWirelessDeviceshouldbeusedinsuchamannersuchthatthepotentialforhuman
contact during normal operation is minimized. This device has been evaluated for and shown compliant
withtheICSpecicAbsorptionRate(“SAR”)limitswheninstalledinspecichostproductsoperatedin
portable exposure conditions.
Canada’s REL (Radio Equipment List) can be found at the following web address:
http://www.ic.gc.ca/app/sitt/reltel/srch/nwRdSrch.do?lang=eng
Additional Canadian information on RF exposure also can be found at the following web address:
http://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf08792.html
Modelname:P01Y
Manufacturer ASUSTekCOMPUTERINC.
Address, City 4F,No.150,LI-TERD.,PEITOU,
TAIPEI112,TAIWAN
Authorized
Representative
in Europe
ASUSCOMPUTERGmbH
Address, City HARKORTSTR.21-23,40880RATINGEN
Country GERMANY
Proper disposal
Risk of explosion if battery is replaced by an incorrect type. Dispose of used
batteries according to the instructions.
Risque d’explosion si la batterie est remplacée par une batterie de type
incorrect. Mettre les batteries au rebut conformément aux instructions fournies.
DONOTthrowthebatteryinmunicipalwaste.Thesymbolofthecrossedout
wheeled bin indicates that the battery should not be placed in municipal waste.
DONOTthrowtheASUSTabletinmunicipalwaste.Thisproducthasbeendesigned
to enable proper reuse of parts and recycling. The symbol of the crossed out wheeled
bin indicates that the product (electrical, electronic equipment and mercury-
containing button cell battery) should not be placed in municipal waste. Check local
regulations for disposal of electronic products.
DONOTthrowtheASUSTabletinre.DONOTshortcircuitthecontacts.DONOT
disassemble the ASUS Tablet.
Coating notice
IMPORTANT! To provide electrical insulation and maintain electrical safety, a coating is
appliedtoinsulatethedeviceexceptontheareaswheretheI/Oportsarelocated.
Power Safety Requirement
Products with electrical current ratings up to 6A and weighing more than 3Kg must use approved power
cordsgreaterthanorequalto:H05VV-F,3G,0.75mm2orH05VV-F,2G,0.75mm2.
ASUS Recycling/Takeback Services
ASUS recycling and takeback programs come from our commitment to the highest standards for
protectingourenvironment.Webelieveinprovidingsolutionsforyoutobeabletoresponsiblyrecycle
our products, batteries, other components as well as the packaging materials. Please go to http://csr.asus.
com/english/Takeback.htm for detailed recycling information in dierent regions.
Copyright Information
Nopartofthismanual,includingtheproductsandsoftwaredescribedinit,maybereproduced,
transmitted, transcribed, stored in a retrieval system, or translate into any language in any form or by any
means, except documentation kept by the purchaser for backup purposes, without the express written
permissionofASUSTeKCOMPUTERINC.(“ASUS”).
ASUSandASUSTabletlogoaretrademarksofASUSTekComputerInc.
Informationinthisdocumentissubjecttochangewithoutnotice.
Copyright © 2015 ASUSTeK COMPUTER INC. All Rights Reserved.
Prevention of Hearing Loss
To prevent possible hearing damage, do not listen at high volume levels for long periods.
ForFrance,headphones/earphonesforthisdevicearecompliantwiththesoundpressurelevel
requirementlaiddownintheapplicableEN50332-1:2000and/orEN50332-2:2003standardrequiredby
French Article L.5232-1.
CE Mark Warning
