Quick Start Guide
PCE-AC88
Wireless Local Area Network Card
(For 802.11 a/g/b/n/ac Wireless Networks)
!
Driver Installation
Insert the support CD into the optical drive.
Insérez le CD de support dans le lecteur optique.
Inserte el CD de soporte en la unidad óptica.
When the setup is complete, connect your desktop
PC to the Internet wirelessly via PCE-AC88.
Une fois la conguration terminée, connectez votre
ordinateur au réseau sans l par le biais du
PCE-AC88.
Use la utilidad ASUS para congurar la tarjeta
PCE-AC88.
Adjust the magnetic antenna base to get the best
signal with your router.
Ajustez la base de l’antenne magnétique pour
améliorer la qualité du signal sans l du routeur.
Ajuste la base de antena magnética para obtener la
mejor señal con su enrutador
Follow the onscreen instructions to complete the
installation.
Suivez les instructions apparaissant à l’écran pour
compléter l'installation.
Siga las instrucciones que aparezcan en la pantalla
para completar la instalación.
Setting up a Home Network
Setting up a Home Network
To install the antennas properly:
1. Install the antennas to the antenna base.
2. Connect the antenna base to the PCE-AC88 network card.
Manufacturer ASUSTeK Computer Inc.
Tel: +886-2-2894-3447
Address: 4F, No. 150, LI-TE RD., PEITOU, TAIPEI 112, TAIWAN
Authorised
representative
in Europe
ASUS Computer GmbH
Address: HARKORT STR. 21-23, 40880 RATINGEN,
GERMANY
Authorised
distributors in
Turkey
BOGAZICI BIL GISAYAR SAN. VE TIC. A.S.
Tel: +90 212 3311000
Address: AYAZAGA MAH. KEMERBURGAZ CAD. NO.10
AYAZAGA/ISTANBUL
CIZGI Elektronik San. Tic. Ltd. Sti.
Tel: +90 212 3567070
Address: CEMAL SURURI CD. HALIM MERIC IS MERKEZI
No: 15/C D:5-6 34394 MECIDIYEKOY/ ISTANBUL
KOYUNCU ELEKTRONiK BiLGi iSLEM SiST. SAN. VE DIS
TIC. A.S.
Tel: +90 216 5288888
Address: EMEK MAH.ORDU CAD. NO:18, SARIGAZi,
SANCAKTEPE ISTANBUL
AEEE Yönetmeliğine Uygundur.
