ASUSTeK Computer RTACBV00 Lyra mini User Manual

ASUSTeK Computer Inc Lyra mini

User Manual

Quick Start Guide
E13046 / First Edition / May 2017
English .............................................................................................................................................. 3
ENGLISH
3
Setting up Lyra mini
1. Unplug your cable / DSL modem*. Remove the battery if it has one.
* If you are using DSL for internet, you will need a username/password from your internet
service provider (ISP).
* Make sure your device support BLE, Bluetooth 4.0 or above.
2. Plug in your rst Lyra mini and connect it to the modem with the cable provided in the
box.
3. Plug your modem back in.
4. Download the Lyra mini app and follow the steps to setup your Wi-Fi and other Lyra mini.
4
ENGLISH
Colors of Lyra mini
Buttons
Random Breathing
Lyra mini is booting up or applying settings.
Light Cyan
Everything is good!
Red
Loss connection to the primary Lyra mini. Move it closer.
Solid White
Lyra mini is ready for setup. It will start blinking when setting up with the app.
Orange
Loss connection to the Internet. Please check the cable connected with your
modem.
Reset
Hold it for 3 seconds to reset this Lyra mini to default setting.
Pairing
Hold it for 3 seconds on both the primary Lyra mini and the new Lyra mini you
wish to add into the network. You’ll see blinking cyan on both Lyra mini.
Note: After you set up the rst Lyra mini, you can use this button to add another
one.
Federal Communications Commission Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
• Thisdevicemaynotcauseharmfulinterference.
• Thisdevicemustacceptanyinterferencereceived,includinginterferencethatmaycause
undesired operation.
This equipment has been tested and found to comply with the limits f or a class B dig ital device,
pursuant to par t 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. I f this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment
o and on, the user is encouraged to tr y to correct the interference by one or more of the
following measures:
• Reorientorrelocatethereceivingantenna.
• Increasetheseparationbetweentheequipmentandreceiver.
• Connecttheequipmentintoanoutletonacircuitdierentfromthattowhichthereceiver
is connected.
• Consultthedealeroranexperiencedradio/TVtechnicianforhelp
The operation frequency of the device is in the 5150-5250 MHz band is f or indoor use only .
WARNING!
Any changes or modications not expressly approved by the party responsible for compliance
could void the user ’s authority to operate the equipment.
Prohibition of Co-location
This device and its antenna(s) must not be co-located or operating in conjunction with any other
antenna or transmitter.
This equipment must be installed and operated in accordance with provided instructions and
the antenna(s) used for this transmitter must be installed to provide a separation distance of at
least 20 cm from all persons and must not be co-located or operating in conjunction with any
other antenna or transmitter.
IMPORTANT NOTE:
Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set
forth for an uncontrolled environment. End users must follow the specic operating instructions
for satisfying RF exposure compliance. To maintain compliance with FCC exposure compliance
requirement, please follow operation instruction as documented in this manual .
This device within the 5.15 ~ 5.25 GHz is restricted to indoor operations to reduce any potential
for harmful interference to co-channel MSS operations.
Declaration of Conformity for R&TTE directive 1999/5/EC
Essential requirements – Article 3
Protection requirements for health and safety – Article 3.1a
Testing for electric safety according to EN 60950-1 has been conducted.
These are considered relevant and sucient.
Protection requirements for electromagnetic compatibility – Article 3.1b
Testing for electromagnetic compatibility according to EN 301 489-1 and EN 301
489-17 has been conducted. These are considered relevant and sucient.
Eective use of the radio spectrum – Article 3.2
Testing for radio test suites according to EN 300 328 & EN 301 893 have been conducted. These
are considered relevant and sucient. The operation frequency of the device is in the 5150-5250
MHz band is for indoor use only.
CE Mark Warning
This is a Class B product, in a domestic environment, this product may cause radio interfer-
ence, in which case the user may be required to take adequate measures. Operation Channels:
CH1~11 for N. America; Ch1~14 for Japan; CH1~13 for Europe (ETSI).
This equipment may be operated in AT, BE, CY, CZ, DK, EE, FI, FR, DE, GR, HU, IE,IT, LU, MT, NL, PL,
PT, SK, SL, ES, SE, GB, IS, IS, LI, NO, CH, BG, R O, TR.
