ASUSTeK Computer Inc Wireless-AC2900 Dual Band Gigabit Router

Contents

User Manual

Quick Start Guide
RT-AC86U
Wireless-AC2900 Dual band
Gigabit Router
US12549 / First Edition / March 2017
US12549_RT-AC86U_QSG_172x144mm.indb 1 2017/3/31 10:52:18
Table of contents
Package contents ....................................................................... 3
A quick look at your router ..................................................... 3
Preparing your modem ............................................................ 4
Setting up your router .............................................................. 5
A. Wired connection .............................................................................5
B. Wireless connection ........................................................................6
Remembering your wireless router settings ................... 7
FAQ .................................................................................................. 7
Networks Global Hotline Information ..............................23
English
Français
Português
Español
This QSG contains these languages:
US12549_RT-AC86U_QSG_172x144mm.indb 2 2017/3/31 10:52:18
3
A quick look at your router
NOTE: If any of the items is damaged or missing, contact your retailer.
Package contents
RT-AC86U Wireless Router 3 * wireless antennas
AC adapter Network cable (RJ-45)
Quick Start Guide
1. LAN LED 8. Power (DC-IN) port
2. WAN (Internet) LED 9. USB 2.0 port
3. 2.4GHz / 5GHz Wi-Fi LED 10. USB 3.0 port
4. Power LED 11. WAN (Internet) port
5. WPS button 12. LED On/O button
6. Wi-Fi On/O button 13. LAN ports
7. Power button 14. Reset button
English
US12549_RT-AC86U_QSG_172x144mm.indb 3 2017/3/31 10:52:19
4
Preparing your modem
1. Unplug the power cable/DSL modem. If it has a battery
backup, remove the battery.
NOTE: If you are using DSL for Internet, you
will need your username/password from your In-
ternet Service Provider (ISP) to properly congure
the router.
2. Connect your modem to the router with the bundled
network cable.
3. Power on your cable/DSL modem.
4. Check your cable/DSL modem LED lights to ensure the
connection is active.
Unplug
English
US12549_RT-AC86U_QSG_172x144mm.indb 4 2017/3/31 10:52:20
5
Setting up your router
You can set up your router via wired or wireless connection.
A. Wired connection
1. Plug your router into a power
outlet and power it on. Connect the
network cable from your computer
to a LAN port on your router.
RT-AC86U
1
Internet
Modem
4
3
WAN
2
LAN
Laptop
2. The web GUI launches automatically when you open a web browser. If it does not
auto-launch, enter http://router.asus.com
3. Set up a password for your router to prevent unauthorized access.
English
US12549_RT-AC86U_QSG_172x144mm.indb 5 2017/3/31 10:52:21
6
B. Wireless connection
1. Plug your router into a power
outlet and power it on.
RT-AC86U
Laptop
Tablet
Smart phone
1
Internet
Modem
3
2
WAN
2. Connect to the network name(SSID) shown on the product label on the back side
of the router. For better network security, change to a unique SSID and assign a
password.
ASUS router
2.4G Wi-Fi Name (SSID): ASUS_XX_2G
5G Wi-Fi Name (SSID): ASUS_XX_5G
* XX refers to the last two digits of 2.4GHz MAC
address. You can nd it on the label on the
back of your router.
English
US12549_RT-AC86U_QSG_172x144mm.indb 6 2017/3/31 10:52:21
7
3. Once connected, the web GUI launches automatically when you open a web
browser. If it does not auto-launch, enter http://router.asus.com.
4. Set up a password for your router to prevent unauthorized access.
Remembering your wireless router settings
• Rememberyourwirelesssettingsasyoucompletetheroutersetup.
Router Name: Password:
2.4 GHz network SSID: Password:
5GHz network SSID: Password:
FAQ
1. Where can I nd more information about the wireless router?
 •OnlineFAQsite:http://support.asus.com/faq
 •Technicalsupportsite:http://support.asus.com
 •Customerhotline:refertotheSupportHotlinesectioninthisQuickStartGuide
English
US12549_RT-AC86U_QSG_172x144mm.indb 7 2017/3/31 10:52:21
Français
8
Aperçu rapide de votre routeur
REMARQUE : Si l'un des éléments est endommagé ou manquant, veuillez contacter
votre revendeur.
Contenu de la boîte
Routeur Wi-Fi RT-AC86U 3 * Antennes Wi-Fi
Adaptateur secteur Câble réseau (RJ-45)
Guide de démarrage rapide
1. Voyant réseau local (LAN) 8. Prise d'alimentation (CC)
2. Voyant réseau étendu (WAN) (Internet) 9. Port USB 2.0
3. Voyant Wi-Fi de bande 2,4 GHz / 5 GHz 10. Port USB 3.0
4. Voyant d'alimentation 11. Port réseau étendu (WAN) (Internet)
5. Bouton WPS 12. Bouton voyant allumé/éteint
6. Bouton Wi-Fi activé/désactivé 13. Ports réseau local (LAN)
7. Bouton d'alimentation 14. Bouton de réinitialisation
US12549_RT-AC86U_QSG_172x144mm.indb 8 2017/3/31 10:52:22
Français
9
Préparer votre modem
1. Débranchez le câble d'alimentation / le modem DSL. Si
votre modem possède une batterie de secours, retirez-la.
REMARQUE : Si vous utilisez le DSL pour accéder à Inter-
net, vous aurez besoin du nom d'utilisateur et du mot de
passe fournis par votre fournisseur d'accès internet pour
congurer votre routeur.
2. Raccordez votre modem au routeur à l'aide du câble
réseau fourni.
3. Allumez votre modem câble/DSL.
4. Vériez les voyants lumineux de votre modem câble/DSL
pour vous assurer que la connexion est établie.
Débranchez
US12549_RT-AC86U_QSG_172x144mm.indb 9 2017/3/31 10:52:22
Français
10
Congurer votre routeur
Vous pouvez congurer votre routeur via une connexion laire ou Wi-Fi.
A. Connexion laire
1. Branchez le routeur sur une prise électrique, puis allumez-le. Utilisez le câble réseau
pour relier votre ordinateur au port
réseau local (LAN) du routeur.
RT-AC86U
1
Internet
Modem
4
3
WAN
2
LAN
Laptop
2. L'interface de gestion du routeur s'ache automatiquement lors de l'ouverture de
votre navigateur internet. Si ce n'est pas le cas, entrez http://router.asus.com dans la
barre d'adresse.
3. Dénissez un mot de passe an d'éviter les accès non autorisés au routeur.
US12549_RT-AC86U_QSG_172x144mm.indb 10 2017/3/31 10:52:22
Français
11
B. Connexion Wi-Fi
1. Branchez le routeur sur une prise
électrique, puis allumez-le.
RT-AC86U
Laptop
Tablet
Smart phone
1
Internet
Modem
3
2
WAN
2. Connectez-vous au réseau dont le nom (SSID) est aché sur l'étiquette du produit
située à l'arrière du routeur. Pour garantir une plus grande sécurité, modiez le nom
du réseau et le mot de passe.
ASUS router
Nom du réseau Wi-Fi de
2,4 G (SSID) :
ASUS_XX_2G
Nom du réseau Wi-Fi de
5 G (SSID) :
ASUS_XX_5G
* XX correspond aux deux derniers chires de l'adresse
MAC 2,4 GHz. Vous pouvez les trouver sur l'étiquette
située à l'arrière de votre routeur.
US12549_RT-AC86U_QSG_172x144mm.indb 11 2017/3/31 10:52:23
Français
12
3. Une fois connecté, l'interface de gestion du routeur s'ache automatiquement
lors de l'ouverture de votre navigateur internet. Si ce n'est pas le cas, entrez http://
router.asus.com dans la barre d'adresse.
4. Dénissez un mot de passe an d'éviter les accès non autorisés au routeur.
Se rappeler des paramètres de votre routeur Wi-Fi
• NotezlesparamètresWi-Fichoisislorsdelacongurationdevotrerouteur.
Nom du routeur : Mot de passe :
Nom du réseau de 2,4 GHz (SSID) : Mot de passe:
Nom du réseau de 5 GHz (SSID) : Mot de passe:
US12549_RT-AC86U_QSG_172x144mm.indb 12 2017/3/31 10:52:23
Português
13
Visão geral do seu router
NOTA: Caso algum item esteja danicado ou em falta, contacte o seu
revendedor.
Conteúdo da embalagem
RT-AC86U 3 x antenas sem os
Transformador Cabo de rede (RJ-45)
Guia de consulta rápida
1. LED da LAN 8. Porta de alimentação (Entrada DC)
2. Portas WAN (Internet) 9. Portas USB 2.0
3. LED 2.4GHz / 5GHz 10. Portas USB 3.0
4. LED de Alimentação 11. Portas WAN (Internet)
5. Botão WPS 12. Botão Ligar/Desligar LED
6. Botão Ligar/Desligar Wi-Fi 13. Portas da LAN
7. Botão Alimentação 14. Vypínaè
US12549_RT-AC86U_QSG_172x144mm.indb 13 2017/3/31 10:52:24
Português
14
Preparar o modem
1. Desligue o modem por cabo/DSL. Se o mesmo tiver
uma bateria de reserva, remova-a.
NOTE: Se estiver a utilizar uma ligação DSL para
aceder à Internet, precisará dos dados de nome de
utilizador/palavra-passe fornecidos pelo seu fornecedor
de serviços de Internet (ISP) para congurar correta-
mente o seu router.
2. Ligue o seu modem ao router com o cabo de rede
fornecido.
3. Ligue o seu modem por cabo/DSL.
4. Verique as luzes LED do modem por cabo/DSL para se
certicar que a ligação está ativa.
Unplug
US12549_RT-AC86U_QSG_172x144mm.indb 14 2017/3/31 10:52:24
Português
15
Congurar o router
É possível congurar o router através de uma ligação com ou sem os.
A. Ligação com os
1. Ligue o router a uma tomada elétrica
e prima o botão de energia. Ligue o
cabo de rede do computador a uma
porta LAN do router.
2. A interface web abre automaticamente quando abrir um navegador web. Se não
abrir automaticamente, introduza http://router.asus.com
3. Congure uma palavra-passe para o seu router para impedir o acesso não
autorizado.
RT-AC86U
1
Internet
Modem
4
3
WAN
2
LAN
Laptop
US12549_RT-AC86U_QSG_172x144mm.indb 15 2017/3/31 10:52:25
Português
16
B. Ligação sem os
1. Ligue o router a uma tomada
elétrica e prima o botão de
energia.
2. Connect to the network name(SSID) shown on the product label on the back side
of the router. For better network security, change to a unique SSID and assign a
password.
ASUS router
Nome da rede Wi-Fi 2,4G
(SSID):
ASUS_XX_2G
Nome da rede Wi-Fi 5G (SSID): ASUS_XX_5G
* XX refere-se aos dois últimos dígitos do
endereço MAC 2,4GHz. Pode encontrar esse
endereço na etiqueta na traseira do router.
RT-AC86U
Laptop
Tablet
Smart phone
1
Internet
Modem
3
2
WAN
US12549_RT-AC86U_QSG_172x144mm.indb 16 2017/3/31 10:52:25
Português
17
3. Após a ligação, a interface web irá abrir automaticamente quando abrir um
navegador web. Se não abrir automaticamente, introduza http://router.asus.com.
4. Congure uma palavra-passe para o seu router para impedir o acesso não
autorizado.
Memorizar as denições do seu router sem os
• Memorizeassuasdeniçõesdeligaçãosemosquandoterminaraconguração
do router.
Nome do router:: palavra-passe:
SSID da rede 2,4 GHz: palavra-passe:
SSID da rede 5GHz: palavra-passe:
Perguntas Frequentes
1.
Onde posso encontrar mais informações acerca do router sem os
?
 •
Site de Perguntas Frequentes Online
: http://support.asus.com/faq
 •
Site de Apoio Técnico
: http://support.asus.com
 •
Linha de Apoio ao Cliente: Consulte a Linha de Apoio ao Cliente no Guia suplementar
US12549_RT-AC86U_QSG_172x144mm.indb 17 2017/3/31 10:52:25
Español
18
Un vistazo rápido a su RT-AC86U
NOTA: Si alguno de los artículos falta o se encuentra dañado, póngase en contacto
con su distribuidor.
Contenido del paquete
RT-AC86U 3*antenas inalámbricas
AC adapter Cable de red
Guía de inicio rápido
1. LED LAN 8. Puerto de alimentación (DC-IN)
2. WAN LED (Internet) 9. USB 2.0 Puerto
3. LED de 2.4 GHz / 5GHz 10. USB 3.0 Puerto
4. LED de alimentación 11. WAN (Internet) puerto
5. Botón WPS 12. Botón Activar/Desactivar LED
6. Botón Activar/Desactivar Wi-Fi 13. LAN puertos
7. Vypínaè 14. Botón Restablecer
US12549_RT-AC86U_QSG_172x144mm.indb 18 2017/3/31 10:52:25
Español
19
Preparar el módem
1.
Desenchufe la alimentación del módem de cable
o DSL. Si tiene una batería de reserva, quítela.
NOTA: Si utiliza DSL para Internet, necesitará
el nombre de usuario y la contraseña de su
proveedor de servicio de Internet (ISP) para con-
gurar adecuadamente el router.
2. Conecte el módem al router con el cable de red
proporcionado.
3. Encienda su módem de cable o DSL.
4. Compruebe las luces de los LED del módem de cable o
DLS para asegurarse de que la conexión está activa.
Unplug
US12549_RT-AC86U_QSG_172x144mm.indb 19 2017/3/31 10:52:26
Español
20
Congurar el router
Puede congurar el router a través de la conexión cableada o inalámbrica.
A. Conexión cableada
1. Enchufe el router a una toma de
corriente eléctrica y enciéndalo.
Conecte el cable de red desde el
equipo a un puerto LAN del router.
2. La GUI Web se inicia automáticamente cuando abre un explorador Web. Si no se inicia
automáticamente, escriba http://router.asus.com.
3. Congure una contraseña para el router para evitar el acceso no autorizado.
RT-AC86U
1
Internet
Modem
4
3
WAN
2
LAN
Laptop
US12549_RT-AC86U_QSG_172x144mm.indb 20 2017/3/31 10:52:26
Español
21
B.
Conexión inalámbrica
1. Enchufe el router a una toma de
corriente eléctrica y enciéndalo.
2. Conéctese al nombre de red (SSID) mostrado en la etiqueta del producto que se
encuentra en la parte posterior del router. Para mejorar la seguridad de la red,
cambie a un SSID único y asigne una contraseña.
ASUS router
Nombre Wi-Fi 2,4 GHz (SSID): ASUS_XX_2G
Nombre Wi-Fi 5GHz (SSID): ASUS_XX_5G
* XX y hace referencia a los dos últimos dígitos
de la dirección MAC de 2,4 GHz. Puede
encontrarlo en la etiqueta situada en la parte
posterior del router.
RT-AC86U
Laptop
Tablet
Smart phone
1
Internet
Modem
3
2
WAN
US12549_RT-AC86U_QSG_172x144mm.indb 21 2017/3/31 10:52:27
Español
22
3. La GUI Web se inicia automáticamente cuando abre un explorador Web. Si no se
inicia automáticamente, escriba http://router.asus.com.
4. Congure una contraseña para el router para evitar el acceso no autorizado.
Recordar la conguración del router inalámbrico
•
Recuerde la conguración inalámbrica cuando complete la conguración del
router.
Nombre del router: Contraseña:
SSID de red de 2,4 GHz: Contraseña:
SSID de red de 5 GHz: Contraseña:
FAQ
1. ¿De qué otros recursos dispongo para obtener más información acerca del router inalámbrico?
• Elsitiowebdepreguntasmásfrecuentes:http://support.asus.com/faq
• Elsitiowebdesoportetécnico:http://support.asus.com/
• LíneaDirecta:ConsulteelnúmerodelalíneatelefónicadesoportetécnicoenestaGuía
de inicio rápido.
US12549_RT-AC86U_QSG_172x144mm.indb 22 2017/3/31 10:52:27
23
Networks Global Hotline Information
Region Country Hotline Number Service Hours
Europe
Cyprus 800-92491 09:00-13:00 ;
14:00-18:00 Mon-Fri
France 0033-170949400 09:00-18:00 Mon-Fri
Germany
0049-1805010920
09:00-18:00 Mon-Fri
10:00-17:00 Mon-Fri
0049-1805010923
(component support )
0049-2102959911 ( Fax )
Hungary 0036-15054561 09:00-17:30 Mon-Fri
Italy 199-400089 09:00-13:00 ;
14:00-18:00 Mon-Fri
Greece 00800-44142044 09:00-13:00 ;
14:00-18:00 Mon-Fri
Austria 0043-820240513 09:00-18:00 Mon-Fri
Netherlands/
Luxembourg 0031-591570290 09:00-17:00 Mon-Fri
Belgium 0032-78150231 09:00-17:00 Mon-Fri
Norway 0047-2316-2682 09:00-18:00 Mon-Fri
Sweden +46-858769407 09:00-18:00 Mon-Fri
Finland 00358-969379690 10:00-19:00 Mon-Fri
Denmark 0045-38322943 09:00-18:00 Mon-Fri
Poland 0048-225718040 08:30-17:30 Mon-Fri
Spain 0034-902889688 09:00-18:00 Mon-Fri
Portugal 00351-707500310 09:00-18:00 Mon-Fri
Slovak Republic 00421-232162621 08:00-17:00 Mon-Fri
Czech Republic 00420-596766888 08:00-17:00 Mon-Fri
Switzerland-German 0041-848111010 09:00-18:00 Mon-Fri
Switzerland-French 0041-848111014 09:00-18:00 Mon-Fri
Switzerland-Italian 0041-848111012 09:00-18:00 Mon-Fri
United Kingdom 0044-1442265548 09:00-17:00 Mon-Fri
Ireland 0035-31890719918 09:00-17:00 Mon-Fri
Russia and CIS 008-800-100-ASUS 09:00-18:00 Mon-Fri
Ukraine 0038-0445457727 09:00-18:00 Mon-Fri
US12549_RT-AC86U_QSG_172x144mm.indb 23 2017/3/31 10:52:27
24
Region Country Hotline Numbers Service Hours
Asia-Pacic
Australia 1300-278788 09:00-18:00 Mon-Fri
New Zealand 0800-278788 09:00-18:00 Mon-Fri
Japan
0800-1232787 09:00-18:00 Mon-Fri
09:00-17:00 Sat-Sun
0081-570783886
(Non-Toll Free)
09:00-18:00 Mon-Fri
09:00-17:00 Sat-Sun
Korea 0082-215666868 09:30-17:00 Mon-Fri
Thailand 0066-24011717 09:00-18:00 Mon-Fri
1800-8525201
Singapore
0065-64157917 11:00-19:00 Mon-Fri
0065-67203835 11:00-19:00 Mon-Fri
(Repair Status Only) 11:00-13:00 Sat
Malaysia 0060-320535077 10:00-19:00 Mon-Fri
Philippine 1800-18550163 09:00-18:00 Mon-Fri
India 1800-2090365 09:00-18:00 Mon-Sat
India(WL/NW) 09:00-21:00 Mon-Sun
Indonesia 0062-2129495000 09:30-17:00 Mon-Fri
500128 (Local Only) 9:30 – 12:00 Sat
Vietnam 1900-555581 08:00-12:00
13:30-17:30 Mon-Sat
Hong Kong 00852-35824770 10:00-19:00 Mon-Sat
Americas
USA 1-812-282-2787 8:30-12:00 EST Mon-Fri
Canada 9:00-18:00 EST Sat-Sun
Mexico 001-8008367847 08:00-20:00 CST Mon-Fri
08:00-15:00 CST Sat
US12549_RT-AC86U_QSG_172x144mm.indb 24 2017/3/31 10:52:27
25
Region Country Hotline Numbers Service Hours
Middle East +
Africa
Egypt 800-2787349 09:00-18:00 Sun-Thu
Saudi Arabia 800-1212787 09:00-18:00 Sat-Wed
UAE 00971-42958941 09:00-18:00 Sun-Thu
Turkey 0090-2165243000 09:00-18:00 Mon-Fri
South Africa 0861-278772 08:00-17:00 Mon-Fri
Israel *6557/00972-39142800 08:00-17:00 Sun-Thu
*9770/00972-35598555 08:30-17:30 Sun-Thu
Balkan Coun-
tries
Romania 0040-213301786 09:00-18:30 Mon-Fri
Bosnia
Herzegovina 00387-33773163 09:00-17:00 Mon-Fri
Bulgaria 00359-70014411 09:30-18:30 Mon-Fri
00359-29889170 09:30-18:00 Mon-Fri
Croatia 00385-16401111 09:00-17:00 Mon-Fri
Montenegro 00382-20608251 09:00-17:00 Mon-Fri
Serbia 00381-112070677 09:00-17:00 Mon-Fri
Slovenia 00368-59045400 08:00-16:00 Mon-Fri
00368-59045401
Baltic
Countries
Estonia 00372-6671796 09:00-18:00 Mon-Fri
Latvia 00371-67408838 09:00-18:00 Mon-Fri
Lithuania-Kaunas 00370-37329000 09:00-18:00 Mon-Fri
Lithuania-Vilnius 00370-522101160 09:00-18:00 Mon-Fri
NOTES:
• UKsupporte-mail:network_support_uk@asus.com
• Formoreinformation,visittheASUSsupportsiteat:
http://support.asus.com
US12549_RT-AC86U_QSG_172x144mm.indb 25 2017/3/31 10:52:27
26
ASUS Recycling/Takeback Services
ASUS recycling and takeback programs come from our commitment to the highest stan-
dards for protecting our environment. We believe in providing solutions for you to be able
toresponsiblyrecycleourproducts,batteries,othercomponents,aswellasthepackaging
materials. Please go to http://csr.asus.com/english/Takeback.htm for the detailed recycling
information in dierent regions.
REACH
ComplyingwiththeREACH(Registration,Evaluation,Authorisation,andRestrictionof
Chemicals)regulatoryframework,wepublishedthechemicalsubstancesinourproductsat
ASUS REACH website at http://csr.asus.com/english/REACH.htm
Federal Communications Commission Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
• Thisdevicemaynotcauseharmfulinterference.
• Thisdevicemustacceptanyinterferencereceived,includinginterferencethatmaycause
undesired operation.
This equipment has been tested and found to comply with the limits for a class B digital
device,pursuanttopart15oftheFCCRules.Theselimitsaredesignedtoprovidereasonable
protection against harmful interference in a residential installation.
Thisequipmentgenerates,usesandcanradiateradiofrequencyenergyand,ifnot
installedandusedinaccordancewiththeinstructions,maycauseharmfulinterference
toradiocommunications.However,thereisnoguaranteethatinterferencewillnotoccur
in a particular installation. If this equipment does cause harmful interference to radio or
televisionreception,whichcanbedeterminedbyturningtheequipmentoandon,theuser
is encouraged to try to correct the interference by one or more of the following measures:
• Reorientorrelocatethereceivingantenna.
• Increasetheseparationbetweentheequipmentandreceiver.
• Connecttheequipmentintoanoutletonacircuitdierentfromthattowhichthe
receiver is connected.
• Consultthedealeroranexperiencedradio/TVtechnicianforhelp.
WARNING! Any changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate the
equipment.
US12549_RT-AC86U_QSG_172x144mm.indb 26 2017/3/31 10:52:27
27
Prohibition of Co-location
This device and its antenna(s) must not be co-located or operating in conjunction with any
other antenna or transmitter.
IMPORTANT NOTE:
Radiation Exposure Statement: This equipment complies with FCC radiation exposure
limits set forth for an uncontrolled environment. End users must follow the specic oper-
ating instructions for satisfying RF exposure compliance. To maintain compliance with FCC
exposurecompliancerequirement,pleasefollowoperationinstructionasdocumentedin
this manual. This equipment should be installed and operated with minimum distance 20cm
between the radiator and your body.
Declaration of Conformity for R&TTE directive 1999/5/EC
Essential requirements – Article 3
Protection requirements for health and safety – Article 3.1a
Testing for electric safety according to EN 60950-1 has been conducted. These are consid-
ered relevant and sucient.
Protection requirements for electromagnetic compatibility – Article 3.1b
Testing for electromagnetic compatibility according to EN 301 489-1 and EN 301 489-17 has
been conducted. These are considered relevant and sucient.
Eective use of the radio spectrum – Article 3.2
Testing for radio test suites according to EN 300 328- 2 has been conducted. These are con-
sidered relevant and sucient.
Declaration of Conformity for Ecodesign directive 2009/125/EC
Testing for eco-design requirements according to (EC) No 1275/2008 and (EU) No 801/2013
hasbeenconducted.WhenthedeviceisinNetworkedStandbyMode,itsI/Oandnetwork
interfaceareinsleepmodeandmaynotworkproperly.Towakeupthedevice,presstheWi-
Fion/o,LEDon/o,reset,orWPSbutton.
CE Mark Warning
ThisisaClassBproduct,inadomesticenvironment,thisproductmaycauseradiointerfer-
ence,inwhichcasetheusermayberequiredtotakeadequatemeasures.OperationChan-
nels: CH1~11 for N. America; Ch1~13 for Japan; CH1~13 for Europe (ETSI)
ThisequipmentmaybeoperatedinAT,BE,CY,CZ,DK,EE,FI,FR,DE,GR,HU,IE,IT,LU,MT,NL,
PL,PT,SK,SL,ES,SE,GB,IS,LI,NO,CH,BG,RO,RT.
Canada, Industry Canada (IC) Notices
This Class B digital apparatus complies with Canadian ICES-003 and RSS-210.
Operation is subject to the following two conditions: (1) this device may not cause interfer-
ence,and(2)thisdevicemustacceptanyinterference,includinginterferencethatmaycause
undesired operation of the device.
US12549_RT-AC86U_QSG_172x144mm.indb 27 2017/3/31 10:52:27
28
Radio Frequency (RF) Exposure Information
The radiated output power of the ASUS Wireless Device is below the Industry Canada (IC)
radio frequency exposure limits. The ASUS Wireless Device should be used in such a manner
such that the potential for human contact during normal operation is minimized.
This device has been evaluated for and shown compliant with the IC Specic Absorption
Rate (“SAR”) limits when installed in specic host products operated in portable exposure
conditions (antennas are less than 20 centimeters of a person’s body).
This device has been certied for use in Canada. Status of the listing in the Industry Canada’s
REL (Radio Equipment List) can be found at the following web address:
http://www.ic.gc.ca/app/sitt/reltel/srch/nwRdSrch.do?lang=eng
Additional Canadian information on RF exposure also can be found at the following web:
http://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf08792.html
Canada, avis d’Industry Canada (IC)
Cet appareil numérique de classe B est conforme aux normes canadiennes ICES-003 et RSS-
210.
Son fonctionnement est soumis aux deux conditions suivantes : (1) cet appareil ne doit pas
causerd’interférenceet(2)cetappareildoitacceptertouteinterférence,notammentles
interférences qui peuvent a ecter son fonctionnement.
Informations concernant l’exposition aux fréquences radio (RF)
La puissance de sortie émise par l’appareil de sans l ASUS est inférieure à la limite d’exposition
aux fréquences radio d’Industry Canada (IC). Utilisez l’appareil de sans l ASUS de façon à
minimiser les contacts humains lors du fonctionnement normal.
Ce périphérique a été évalué et démontré conforme aux limites SAR (Speci c Absorption Rate
– Taux d’absorption spéci que) d’IC lorsqu’il est installé dans des produits hôtes particuliers
qui fonctionnent dans des conditions d’exposition à des appareils portables (les antennes se
situent à moins de 20 centimètres du corps d’une personne).
Ce périphérique est homologué pour l’utilisation au Canada. Pour consulter l’entrée
correspondant à l’appareil dans la liste d’équipement radio (REL - Radio Equipment List)
d’Industry Canada rendez-vous sur:
http://www.ic.gc.ca/app/sitt/reltel/srch/nwRdSrch.do?lang=eng
Pour des informations supplémentaires concernant l’exposition aux RF au Canada
rendezvous sur :
http://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf08792.html
US12549_RT-AC86U_QSG_172x144mm.indb 28 2017/3/31 10:52:27
29
NCC 警語
經型式認證合格之低功率射頻電機，非經許可，公司、商號或使用者均不得擅自變更頻
率、加大功率或變更原設計之特性及功能。低功率射頻電機之使用不得影響飛航安全及
干擾合法通信；經發現有干擾現象時，應立即停用，並改善至無干擾時方得繼續使用。
前項合法通信，指依電信法規定作業之無線電通信。低功率射頻電機須忍受合法通信或
工業、科學及醫療用電波輻射性電機設備之干擾。
US12549_RT-AC86U_QSG_172x144mm.indb 29 2017/3/31 10:52:27

Navigation menu
