ASUSTeK Computer T00D PADFONE X User Manual
ASUSTeK Computer Inc PADFONE X
User Manual
Important Notices
Station (T00DP)
(T00D)
AT&T_Padfone-X_Safety_Notices.in1 1 2/14/14 5:27:12 PM
Copyright © 2014 ASUSTeK COMPUTER INC.
All Rights Reserved.
No part of this manual, including the products and software described
in it, may be reproduced, transmitted, transcribed, stored in a retrieval
system, or translated into any language in any form or by any means,
except documentation kept by the purchaser for backup purposes,
without the express written permission of ASUSTeK COMPUTER INC.
(“ASUS”).
Product warranty or service will not be extended if: (1) the product
is repaired, modied or altered, unless such repair, modication of
alteration is authorized in writing by ASUS; or (2) the serial number of
the product is defaced or missing.
ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY
OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING BUT
NOT LIMITED TO THE IMPLIED WARRANTIES OR CONDITIONS OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. IN
NO EVENT SHALL ASUS, ITS DIRECTORS, OFFICERS, EMPLOYEES
OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL, INCIDENTAL,
OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR
LOSS OF PROFITS, LOSS OF BUSINESS, LOSS OF USE OR DATA,
INTERRUPTION OF BUSINESS AND THE LIKE), EVEN IF ASUS HAS
BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING
FROM ANY DEFECT OR ERROR IN THIS MANUAL OR PRODUCT.
SPECIFICATIONS AND INFORMATION CONTAINED IN THIS
MANUAL ARE FURNISHED FOR INFORMATIONAL USE ONLY, AND
ARE SUBJECT TO CHANGE AT ANY TIME WITHOUT NOTICE, AND
SHOULD NOT BE CONSTRUED AS A COMMITMENT BY ASUS.
ASUS ASSUMES NO RESPONSIBILITY OR LIABILITY FOR ANY
ERRORS OR INACCURACIES THAT MAY APPEAR IN THIS MANUAL,
INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT.
Products and corporate names appearing in this manual may or may not
be registered trademarks or copyrights of their respective companies,
and are used only for identication or explanation and to the owners’
benet, without intent to infringe.
First Edition
AT&T_Padfone-X_Safety_Notices.in2 2 2/14/14 5:27:12 PM
IMPORTANT: All throughout this document, the term
“PadFone X device” is used to refer to the two PadFone X
devices: PadFone X and PadFone X Station.
Safety information
PadFone X care
• Do not attempt to open your PadFone X device
casing. There are no user serviceable parts inside
and you might damage sensitive electronic circuits
and components. Unauthorized disassembly will
void the warranty.
• Do notDo not leave your PadFone X device exposed to
strong sunlight or excessive heat for a prolonged
period. This may damage it.
• Do not handle your PadFone X device with wet
hands or expose it to moisture or liquids of any
kind. Continuous changes from a cold to a warm
environment may lead to condensation inside
your PadFone X device, resulting in corrosion and
possible damage.
• If you pack your PadFone X device in your suitcase
during travel, beware of damage. Cramming the
device into a suitcase may crack the LCD display.
Remember to switch off your wireless connection
during air travel.
• Use your PadFone X device in an environment
with ambient temperatures between -10 °C (14
°F) and 35 °C (95 °F).
IMPORTANT! To provide electrical insulation and maintain
electrical safety, a coating is applied to insulate the ASUS
PadFone X body except on the sides where the I/O ports
are located.
The battery
Your PadFone X device is equipped with a high performance
non-detachable Li-Ion battery. Observe the following
maintenance guidelines for a longer battery life:
• Avoid charging in extremely high or low
temperature. The battery performs optimally in an
ambient temperature of +5 °C to +35 °C.
• Do not remove and replace the battery with a non-
approved battery.
• Do not remove and immerse the battery in water or
any other liquid.
AT&T_Padfone-X_Safety_Notices.in3 3 2/14/14 5:27:13 PM
• Never try to open the battery as it contains
substances that might be harmful if swallowed or
allowed to come into contact with unprotected skin.
• Do not remove and short-circuit the battery, as it
may overheat and cause a re. Keep it away from
jewellery and other metal objects.
• Do not remove and dispose of the battery in re. It
could explode and release harmful substances into
the environment.
• Do not remove and dispose of the battery with your
regular household waste. Take it to a hazardous
material collection point.
• Do not touch the battery terminals.
CAUTION:
• Risk of explosion if battery is replaced by an incorrect
type.
• Dispose of used batteries according to the
instructions.
The charger
• Use only the charger supplied with your PadFone X
device.
• Never pull the charger cord to disconnect it from the
power socket. Pull the charger itself.
Cleaning and storing
• Your PadFone X device should always be handled
with care and protected from dirt, dust and
dampness. To avoid scratches, never place your
PadFone X device face down.
• If cleaning is necessary, turn your PadFone X device
off and wipe carefully with a soft, slightly damp (not
wet) cloth. Use a cotton swab to clean the camera
lens. Allow your PadFone X device to dry completely
before switching it on. Never use solvents for
cleaning.
• If you are not going to use your PadFone X device
for some time, fully charge the battery and store
your PadFone X device in a dry place away from
direct sunlight. Your PadFone X device should be
switched off during storage. Recharge every 6 to 12
months.
• Never expose your PadFone X device to heat or
strong sunlight.
• Never expose your PadFone X device to moisture or
liquids of any kind.
AT&T_Padfone-X_Safety_Notices.in4 4 2/14/14 5:27:13 PM
• Do not place stickers that may block the keypad or
affect other components such as the microphone,
earpiece, or camera lens.
WARNING! Failure to follow these instructions may lead
to serious personal injury and possible property damage.
Driving safely
Never use handheld phones while driving. It is an offence,
that while driving, to hold a phone or cradle it in your
neck at any point, during the setup, making or taking
of a phone call, text message or any other data related
mobile communication. Use of fully installed car kits
are still permitted, as are the use of alternate handsfree
accessories.
In the interest of safety, we would recommend the use of a
cradle while using any form of handsfree accessory.
While driving, we recommend that you use voicemail
wherever possible, and that you listen to your messages
when you are not in the car. If you must make a handsfree
call when driving, keep it brief.
Do not place objects, including both installed or portable
wireless equipment, in the area over the airbag or in the
airbag deployment area. An airbag inates with great force.
If the airbag inates, serious injury could result.
Electronic devices
Most modern electronic equipment is shielded from RF
energy.
However, certain electronic equipment may not be shielded
against the RF signals from your device.
Pacemakers
The Health Industry Manufacturers’ Association
recommends that a minimum separation of six (6”) inches
be maintained between a phone and a pacemaker to
avoid potential interference with the pacemaker. These
recommendations are consistent with the independent
research by and recommendations of Wireless Technology
Research.
If you have a pacemaker:
• Always keep your PadFone X device more than six
inches (15cm) from your pacemaker when turned
on.
• Do not carry your PadFone X in your breast pocket.
• Use the ear opposite the pacemaker to minimize the
potential for interference.
• If you have any reason to suspect that interference
is taking place, switch off your PadFone X device
immediately.
AT&T_Padfone-X_Safety_Notices.in5 5 2/14/14 5:27:13 PM
Hearing aids
Some digital phones may interfere with some hearing aids.
In the event of such interference, call ASUS Customer
Service to discuss alternatives.
Other medical devices
If you use any other personal medical device, consult the
manufacturer of your device to determine if it is adequately
shielded from external RF energy. Your physician may be
able to assist you in obtaining this information.
Turn your PadFone X device off in healthcare facilities when
any regulations posted in these areas instruct you to do so.
Hospitals or healthcare facilities may be using equipment
that could be sensitive to external RF energy.
Vehicles
RF signals may affect improperly installed or inadequately
shielded electronic systems in motor vehicles. Check
with the manufacturer or its representative regarding your
vehicle. You should also consult the manufacturer of any
equipment added to your vehicle.
Posted facilities
Turn your PadFone X device off where posted notices so
require.
Magnetic media
Magnetic elds generated by mobile devices may damage
data on magnetic storage media, such as credit cards,
computer discs or tapes. Do not place your PadFone X
device next to such media.
You should never expose your PadFone X device to strong
magnetic elds as this may cause temporary malfunction.
Other Safety Guidelines
Aircraft
Regulations prohibit using your mobile device while onboard
an aircraft. Switch off your PadFone X device before
boarding an aircraft or turn off the wireless connection.
Blasting areas
To avoid interfering with blasting operations, turn your
PadFone X device off when in a ‘blasting area’ or in areas
posted: “Turn off two-way radio.” Obey all signs and
instructions.
AT&T_Padfone-X_Safety_Notices.in6 6 2/14/14 5:27:14 PM
Potentially explosive environments
Turn your PadFone X device off when in any area with a
potentially explosive environment and obey all signs and
instructions.
Sparks in such areas could cause an explosion or fire
resulting in bodily injury or even death.
Areas with a potentially explosive environment are often,
but not always, clearly marked. They include fuelling
areas such as gas stations, below decks on boats, fuel or
chemical transfer or storage facilities, vehicles using liquified
petroleum gas (such as propane or butane), areas where
the air contains chemicals or articles, such as grain, dust,
or metal powders, and any other area where you would
normally be advised to turn off your vehicles engine.
Choking
Keep your PadFone X away from children as the SIM card
and other small parts present a choking hazard.
Caution
Your PadFone X device is a high quality piece of equipment.
Before operating, read all instructions and cautionary
markings on the (1) AC Adapter.
• Do not use the PadFone X device in an extreme
environment where high temperature or high
humidity exists. The PadFone X device performs
optimally in an ambient temperature between -10 °C
(14 °F) and 35 °C (95 °F).
• Do not abuse the PadFone X device. Avoid striking,
shaking, or subjecting the device to impact. When
not using the unit, place the device in a safe place
to avoid damage to the product.
• Do not expose the PadFone X device to rain or
moisture.
• Do not use unauthorized accessories.
• Do not disassemble the PadFone X device or its
accessories. If service or repair is required, return
the unit to an authorized service center. If the unit
is disassembled, a risk of electric shock or fire may
result.
• Do not short-circuit the battery terminals with metal
items.
Operator access with a tool
If a TOOL is necessary to gain access to an OPERATOR
ACCESS AREA, either all other compartments within
that area containing a hazard shall be inaccessible to
the OPERATOR by the use of the same TOOL, or such
compartments shall be marked to discourage OPERATOR
access.
AT&T_Padfone-X_Safety_Notices.in7 7 2/14/14 5:27:14 PM
Equipment
Class Mode
Highest
Reported
Head
SAR1g
(W/kg)
Highest
Reported
Body-Worn
SAR1g
(1.0cm
Gap)
(W/kg)
Highest
Reported
Hotspot
SAR1g
(1.0cm
Gap)
(W/kg)
PCE
GSM850 0.29 0.67 0.67
GSM1900 0.61 1.18 1.18
WCDMA II 0.54 0.66 0.66
WCDMA V 0.18 0.31 0.31
LTE 2 0.58 0.59 0.59
LTE 4 0.53 0.63 0.63
LTE5 0.17 0.25 0.25
LTE7 0.10 0.25 0.25
LTE17 0.16 0.35 0.35
DTS 2.4G WLAN 0.58 0.07 0.07
5.8G WLAN 0.63 0.38 N/A
NII
5.2G WLAN 0.86 0.50 N/A
5.3G WLAN 0.98 0.50 N/A
5.6G WLAN 0.65 0.37 N/A
Federal Communication Commission
Interference Statement
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1) This
device may not cause harmful interference, and (2) this
device must accept any interference received, including
interference that may cause undesired operation.
This device has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15
of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses,
and can radiate radio frequency energy, and, if not installed
and used in accordance with the instructions, may cause
harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a
particular installation If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more
of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and
receiver.
• Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV
technician for help.
AT&T_Padfone-X_Safety_Notices.in8 8 2/14/14 5:27:15 PM
FCC RF Exposure SAR Test Results
FCC Caution:
Any Changes or modications not expressly approved by
the party responsible for compliance could void the user‘s
authority to operate the equipment.
The antenna(s) used for this transmitter must not be co-
located or operating in conjunction with any other antenna
or transmitter.
NOTE: The country code selection is for non-US model only
and is not available to all US model. Per FCC regulation,
all WiFi product marketed in US must xed to US operation
channels only.
Operations in the 5.15-5.25GHz band are restricted to
indoor usage only.
RF Exposure Information (SAR)
This device meets the government’s requirements for
exposure to radio waves.
This device is designed and manufactured not to exceed the
emission limits for exposure to radio frequency (RF) energy
set by the Federal Communications Commission of the U.S.
Government.
The exposure standard for wireless device employs a unit
of measurement known as the Specic Absorption Rate,
or SAR. The SAR limit set by the FCC is 1.6W/kg. *Tests
for SAR are conducted using standard operating positions
accepted by the FCC with the device transmitting at its
highest certied power level in all tested frequency bands.
Although the SAR is determined at the highest certied
power level, the actual SAR level of the device while
operating can be well below the maximum value. This is
because the device is designed to operate at multiple power
levels so as to use only the poser required to reach the
network. In general, the closer you are to a wireless base
station antenna, the lower the power output.
The highest SAR value for the model device as reported to
the FCC when tested for use at the ear is 0.98 W/kg and
when worn on the body, as described in this user guide, is
1.18 W/kg (Body-worn measurements differ among device
models, depending upon available accessories and FCC
requirements.)
While there may be differences between the SAR levels of
various devices and at various positions, they all meet the
government requirement.
The FCC has granted an Equipment Authorization for this
model device with all reported SAR levels evaluated as in
compliance with the FCC RF exposure guidelines. SAR
information on this model device is on le with the FCC and
can be found under the Display Grant section of www.fcc.
gov/oet/ea/fccid after searching on FCC ID: MSQT00D.
For body worn operation, this device has been tested
and meets the FCC RF exposure guidelines for use with
AT&T_Padfone-X_Safety_Notices.in9 9 2/14/14 5:27:15 PM
an accessory that contains no metal and be positioned a
minimum of 1cm from the body. Use of other accessories
may not ensure compliance with FCC RF exposure
guidelines. If you do not use a body-worn accessory and
are not holding the device at the ear, position the handset
a minimum of 1cm from your body when the device is
switched on.
The Federal Communications Commission has
implementedrules and a rating system designed to enable
people who wear hearing aids to more effectively use these
wireless telecommunications devices. The standard for
compatibility of digital wireless phones with hearing aids
is set forth in American National Standard Institute (ANSI)
standard C63.19. There are two sets of ANSI standards
with ratings from one to four (four being the best rating):
an “M” rating for reduced interference making it easier to
hear conversations on the phone when using the hearing
aid microphone, and a “T” rating that enables the phone to
be used with hearing aids operating in the telecoil mode thus
reducing unwanted background noise.
The Hearing Aid Compatibility rating is displayed on the
wireless phone box.A phone is considered Hearing Aid
Compatible for acoustic coupling (microphone mode) if it
has an “M3” or “M4” rating. A digital wireless phone is
considered Hearing Aid Compatible for inductive coupling
(telecoil mode) if it has a “T3” or “T4” rating.
The tested M-Rating and T-Rating for this device
(FCC ID: MSQT00D) are M3 and T4.
This disclosure shall include the following language:This phone
has been tested and rated for use with hearing aids for some of
the wireless technologies that it uses. However, there may be some
newer wireless technologies used in this phone that have not been
tested yet for use with hearing aids. It is important to try the different
features of this phone thoroughly and in different locations, using
your hearing aid or cochlear implant, to determine if you hear any
interfering noise. Consult your service provider or the manufacturer
of this phone for information on hearing aid compatibility. If you
have questions about return or exchange policies, consult your
service provider or phone retailer.
AT&T_Padfone-X_Safety_Notices.in10 10 2/14/14 5:27:15 PM
ASUS
Address: 15 Li-Te Road, Peitou, Taipei, Taiwan
Tel: 886228943447; Fax: 886228907698
Declaration
We declare that the IMEI codes for this product, ASUS
PadFone X, are unique to each unit and only assigned to
this model. The IMEI of each unit is factory set and cannot
be altered by the user and that it complies with the relevant
IMEI integrity related requirements expressed in the GSM
standards.
Should you have any questions or comments regarding
this matter, please contact us.
Sincerely yours,
ASUSTeK COMPUTER INC.
Tel: 886228943447
Fax: 886228907698
Email: http://vip.asus.com/eservice/techserv.aspx
AT&T_Padfone-X_Safety_Notices.in11 11 2/14/14 5:27:15 PM
15060-29510000
AT&T_Padfone-X_Safety_Notices.in12 12 2/14/14 5:27:15 PM
