ASUSTeK Computer T300CHIDOCK ASUS Mobile Dock User Manual T300 Chi Mobile Dock UserMan

ASUSTeK Computer Inc ASUS Mobile Dock T300 Chi Mobile Dock UserMan

(T300 Chi Mobile Dock) UserMan

ASUS Tablet and
ASUS Mobile Dock
E-Manual
T300 Chi
T300 Chi Mobile Dock
First Edition
December 2014
E9717
2
ASUS Tablet and ASUS Mobile Dock E-Manual
DRAFT 9 12/19/2014
COPYRIGHT INFORMATION
No part of this manual, including the products and software described in it, may be reproduced,
transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or by
any means, except documentation kept by the purchaser for backup purposes, without the express
written permission of ASUSTeK COMPUTER INC. (“ASUS”).
ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS OR IMPLIED,
INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OR CONDITIONS OF MERCHANTABILITY OR
FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT SHALL ASUS, ITS DIRECTORS, OFFICERS, EMPLOYEES
OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES
(INCLUDING DAMAGES FOR LOSS OF PROFITS, LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION
OF BUSINESS AND THE LIKE), EVEN IF ASUS HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES
ARISING FROM ANY DEFECT OR ERROR IN THIS MANUAL OR PRODUCT.
Products and corporate names appearing in this manual may or may not be registered trademarks or
copyrights of their respective companies, and are used only for identication or explanation and to the
owners’ benet, without intent to infringe.
SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE FURNISHED FOR INFORMATIONAL
USE ONLY, AND ARE SUBJECT TO CHANGE AT ANY TIME WITHOUT NOTICE, AND SHOULD NOT BE
CONSTRUED AS A COMMITMENT BY ASUS. ASUS ASSUMES NO RESPONSIBILITY OR LIABILITY FOR ANY
ERRORS OR INACCURACIES THAT MAY APPEAR IN THIS MANUAL, INCLUDING THE PRODUCTS AND
SOFTWARE DESCRIBED IN IT.
Copyright © 2014 ASUSTeK COMPUTER INC. All Rights Reserved.
LIMITATION OF LIABILITY
Circumstances may arise where because of a default on ASUS’ part or other liability, you are entitled to
recover damages from ASUS. In each such instance, regardless of the basis on which you are entitled to
claim damages from ASUS, ASUS is liable for no more than damages for bodily injury (including death)
and damage to real property and tangible personal property; or any other actual and direct damages
resulted from omission or failure of performing legal duties under this Warranty Statement, up to the
listed contract price of each product.
ASUS will only be responsible for or indemnify you for loss, damages or claims based in contract, tort or
infringement under this Warranty Statement.
This limit also applies to ASUS’ suppliers and its reseller. It is the maximum for which ASUS, its suppliers,
and your reseller are collectively responsible.
UNDER NO CIRCUMSTANCES IS ASUS LIABLE FOR ANY OF THE FOLLOWING: (1) THIRD-PARTY CLAIMS
AGAINST YOU FOR DAMAGES; (2) LOSS OF, OR DAMAGE TO, YOUR RECORDS OR DATA; OR (3) SPECIAL,
INCIDENTAL, OR INDIRECT DAMAGES OR FOR ANY ECONOMIC CONSEQUENTIAL DAMAGES (INCLUDING
LOST PROFITS OR SAVINGS), EVEN IF ASUS, ITS SUPPLIERS OR YOUR RESELLER IS INFORMED OF THEIR
POSSIBILITY.
SERVICE AND SUPPORT
Visit our multi-language web site at http://support.asus.com
ASUS Tablet and ASUS Mobile Dock E-Manual
3
DRAFT 9 12/19/2014
Table of Contents
About this manual ..................................................................................................... 7
Conventions used in this manual ............................................................................. 8
Icons .................................................................................................................................... 8
Typography .......................................................................................................................8
Safety precautions .....................................................................................................9
Using your ASUS Tablet and ASUS Mobile Dock ................................................. 9
Caring for your ASUS Tablet and ASUS Mobile Dock ......................................... 10
Proper disposal ................................................................................................................11
Chapter 1: Hardware Setup
ASUS Tablet .................................................................................................................. 14
Front View ..........................................................................................................................14
Top View ............................................................................................................................. 16
Bottom side ...................................................................................................................... 18
Left side .............................................................................................................................. 19
Right side ........................................................................................................................... 20
ASUS Mobile Dock .....................................................................................................21
Top View ............................................................................................................................. 21
Left side .............................................................................................................................. 24
Chapter 2: Using your ASUS Tablet and ASUS Mobile Dock
Getting started ...........................................................................................................26
ASUS Tablet ....................................................................................................................... 26
ASUS Mobile Dock .......................................................................................................... 29
Using your ASUS Tablet with the ASUS Mobile Dock ........................................ 31
Gestures for the touch screen panel and touchpad .....................................32
Using the touch screen panel ....................................................................................32
Using the touchpad ....................................................................................................... 35
Using the keyboard ................................................................................................... 42
Function keys ................................................................................................................... 42
Windows® 8.1 keys .........................................................................................................43
4
ASUS Tablet and ASUS Mobile Dock E-Manual
DRAFT 9 12/19/2014
Chapter 3: Working with Windows® 8.1
Starting for the rst time .........................................................................................46
Windows® UI .................................................................................................................47
Start screen ....................................................................................................................... 47
Hotspots ............................................................................................................................. 48
Start button ...................................................................................................................... 51
Customizing your Start screen ...................................................................................53
Working with Windows® apps ...............................................................................54
Launching apps ............................................................................................................... 54
Customizing apps ...........................................................................................................54
Accessing the Apps screen .......................................................................................... 57
Charms bar ........................................................................................................................ 59
Snap feature .....................................................................................................................62
Other keyboard shortcuts ......................................................................................64
Connecting to wireless networks ........................................................................66
Wi-Fi ..................................................................................................................................... 66
Bluetooth .......................................................................................................................... 67
Airplane mode ................................................................................................................. 68
Turning your ASUS Tablet o.................................................................................69
Putting your ASUS Tablet to sleep ............................................................................ 69
Windows® 8.1 lock screen ........................................................................................70
To proceed from the lock screen ...............................................................................70
Customizing your lock screen .................................................................................... 71
Chapter 4: Power-On Self-Test (POST)
The Power-On Self-Test (POST) ............................................................................. 74
Using POST to access BIOS and Troubleshoot......................................................74
BIOS ................................................................................................................................74
Accessing BIOS ................................................................................................................75
BIOS Settings .................................................................................................................... 75
Recovering your system ..........................................................................................82
Enabling a recovery option ........................................................................................ 83
ASUS Tablet and ASUS Mobile Dock E-Manual
5
DRAFT 9 12/19/2014
Tips and FAQs
Useful tips for your ASUS Tablet and ASUS Mobile Dock ............................88
Hardware FAQs ...........................................................................................................89
Software FAQs ............................................................................................................. 92
Appendices
Internal Modem Compliancy ..................................................................................... 96
Overview ............................................................................................................................ 96
Network Compatibility Declaration ......................................................................... 96
Non-Voice Equipment ..................................................................................................97
Federal Communications Commission Interference Statement ................... 98
Slave Equipment ............................................................................................................. 99
RF Exposure warning ..................................................................................................... 99
FCC Radio Frequency (RF) Exposure Caution Statement ................................. 100
RF Exposure Information (SAR) .................................................................................. 100
RF Exposure information (SAR) - CE ......................................................................... 101
CE Mark Warning .............................................................................................................101
IC Radiation Exposure Statement for Canada ...................................................... 102
Déclaration d’Industrie Canada relative à l’exposition aux ondes radio ... 103
Radiation Exposure Statement .................................................................................. 104
Déclaration d'exposition aux radiations.................................................................104
Caution ............................................................................................................................... 104
Avertissement .................................................................................................................. 105
Wireless Operation Channel for Dierent Domains ...........................................106
France Restricted Wireless Frequency Bands ....................................................... 106
UL Safety Notices ............................................................................................................ 108
6
ASUS Tablet and ASUS Mobile Dock E-Manual
DRAFT 9 12/19/2014
Power Safety Requirement .......................................................................................... 109
TV Notices ......................................................................................................................... 109
REACH ................................................................................................................................. 109
Macrovision Corporation Product Notice .............................................................. 109
Nordic Lithium Cautions (for lithium-ion batteries) ........................................... 110
Optical Drive Safety Information .............................................................................. 111
CTR 21 Approval (for ASUS Tablet and ASUS Mobile Dock with built-in
modem) .............................................................................................................................. 112
ENERGY STAR complied product .............................................................................. 114
European Union Eco-label ........................................................................................... 114
Global Environmental Regulation Compliance and Declaration .................. 115
ASUS Recycling/Takeback Services .......................................................................... 115
Prevention of Hearing Loss ......................................................................................... 115
Notices for removeable batteries..............................................................................116
Avis concernant les batteries remplaçables..........................................................116
Rechargeable Battery Recycling Service in North America............................. 116
Regional notice for India .............................................................................................. 116
Regional notice for California ..................................................................................... 116
Regional notice for Singapore ...................................................................................117
Japan Technical Conformity Mark ............................................................................ 117
National Telecommunications Commission of the Philippines .................... 117
ASUS Tablet and ASUS Mobile Dock E-Manual
7
DRAFT 9 12/19/2014
About this manual
This manual provides information about the hardware and software
features of your ASUS Tablet and ASUS Mobile Dock organized through
the following chapters:
Chapter 1: Hardware Setup
This chapter details the hardware components of your ASUS
Tablet and ASUS Mobile Dock.
Chapter 2: Using your ASUS Tablet and ASUS Mobile Dock
This chapter shows you how to use the dierent parts of your
ASUS Tablet and ASUS Mobile Dock.
Chapter 3: Working with Windows® 8.1
This chapter provides an overview of using Windows® 8.1 in your
ASUS Tablet and ASUS Mobile Dock.
Chapter 4: Power-On Self-Test(POST)
This chapter shows you how to use POST to change the settings
of your ASUS Tablet.
Tips and FAQs
This section presents some recommended tips, hardware FAQs,
and software FAQs you can refer to for maintaining and xing
common issues with your ASUS Tablet and ASUS Mobile Dock.
Appendices
This section includes notices and safety statements for your ASUS
Tablet and ASUS Mobile Dock.
8
ASUS Tablet and ASUS Mobile Dock E-Manual
DRAFT 9 12/19/2014
Conventions used in this manual
To highlight key information in this manual, some text are presented as
follows:
IMPORTANT! This message contains vital information that must be
followed to complete a task.
NOTE: This message contains additional information and tips that can
help complete tasks.
WARNING! This message contains important information that must be
followed to keep you safe while performing tasks and prevent damage to
your ASUS Tablet and ASUS Mobile Dock's data and components.
Icons
The icons below indicate the devices you can use for completing a series
of tasks or procedures on your ASUS Tablet and ASUS Mobile Dock.
Typography
Bold = This indicates a menu or an item that must be selected.
Italic = This indicates sections that you can refer to in this manual.
= Use the touch screen panel.
= Use the touchpad.
= Use the keyboard.
ASUS Tablet and ASUS Mobile Dock E-Manual
9
DRAFT 9 12/19/2014
Safety precautions
Using your ASUS Tablet and ASUS Mobile Dock
This ASUS Tablet and ASUS Mobile Dock should
only be used in environments with ambient
temperatures between 5°C (41°F) and 35°C (95°F).
Refer to the rating label on the bottom of your ASUS
Tablet and ASUS Mobile Dock and ensure that your
power adapter complies with this rating.
Do not leave your ASUS Tablet and ASUS Mobile
Dock on your lap or near any part of your body to
prevent discomfort or injury from heat exposure.
Do not use damaged power cords, accessories, and
other peripherals with your ASUS Tablet and ASUS
Mobile Dock.
While powered on, ensure that you do not carry or
cover your ASUS Tablet and ASUS Mobile Dock with
any materials that can reduce air circulation.
Do not place your ASUS Tablet and ASUS Mobile
Dock on uneven or unstable work surfaces.
You can send your ASUS Tablet and ASUS Mobile
Dock through x-ray machines (used on items placed
on conveyor belts), but do not expose them to
magnetic detectors and wands.
Contact your airline provider to learn about related
inight services that can be used and restrictions
that must be followed when using your ASUS Tablet
and ASUS Mobile Dock in-ight.
10
ASUS Tablet and ASUS Mobile Dock E-Manual
DRAFT 9 12/19/2014
Caring for your ASUS Tablet and
ASUS Mobile Dock
Disconnect the AC power and remove the battery
pack (if applicable) before cleaning your ASUS
Tablet and ASUS Mobile Dock. Use a clean cellulose
sponge or chamois cloth dampened with a solution
of nonabrasive detergent and a few drops of warm
water. Remove any extra moisture from your ASUS
Tablet and ASUS Mobile Dock using a dry cloth.
Do not use strong solvents such as thinners,
benzene, or other chemicals on or near your ASUS
Tablet and ASUS Mobile Dock.
Do not place objects on top of your ASUS Tablet and
ASUS Mobile Dock.
Do not expose your ASUS Tablet and ASUS Mobile
Dock to strong magnetic or electrical elds.
Do not use or expose your ASUS Tablet and ASUS
Mobile Dock near liquids, rain, or moisture.
Do not expose your ASUS Tablet and ASUS Mobile
Dock to dusty environments.
Do not use your ASUS Tablet and ASUS Mobile Dock
near gas leaks.
ASUS Tablet and ASUS Mobile Dock E-Manual
11
DRAFT 9 12/19/2014
Proper disposal
Do not throw your ASUS Tablet and ASUS Mobile
Dock in municipal waste. This product has been
designed to enable proper reuse of parts and
recycling. The symbol of the crossed out wheeled
bin indicates that the product (electrical, electronic
equipment and mercury-containing button cell
battery) should not be placed in municipal waste.
Check local regulations for disposal of electronic
products.
Do not throw the battery in municipal waste. The
symbol of the crossed out wheeled bin indicates
that the battery should not be placed in municipal
waste.
12
ASUS Tablet and ASUS Mobile Dock E-Manual
DRAFT 9 12/19/2014
ASUS Tablet and ASUS Mobile Dock E-Manual
13
DRAFT 9 12/19/2014
Chapter 1:
Hardware Setup
14
ASUS Tablet and ASUS Mobile Dock E-Manual
DRAFT 9 12/19/2014
ASUS Tablet
Front View
Microphone
The built-in microphone can be used for video conferencing,
voice narrating, or simple audio recording.
Ambient light sensor
The ambient light sensor detects the amount of ambient light in
your environment. It allows the system to automatically adjust
the brightness of the display depending on the ambient light
condition.
Camera
The built-in camera allows you to take pictures or record videos.
ASUS Tablet and ASUS Mobile Dock E-Manual
15
DRAFT 9 12/19/2014
Camera indicator
The camera indicator lights up when the built-in camera is in use.
Touch screen panel
This high-denition touch screen panel provides excellent
viewing features for photos, videos, and other multimedia les. It
also allows you to operate Windows® 8.1 using touch gestures.
NOTE: For more details, refer to the Gestures for the touch screen
panel and touchpad section in this manual.
16
ASUS Tablet and ASUS Mobile Dock E-Manual
DRAFT 9 12/19/2014
Top View
Power button
Press the power button to turn your ASUS Tablet on or o. You
can also use the power button to put your ASUS Tablet to sleep
or hibernate mode, and wake it up from sleep or hibernate
mode.
In the event that your ASUS Tablet becomes unresponsive,
press and hold the power button for about ten (10) seconds
until your ASUS Tablet shuts down.
Two-color battery charge indicator
The two-color LED provides a visual indication of the battery’s
charge status. Refer to the following table for details:
ASUS Tablet and ASUS Mobile Dock E-Manual
17
DRAFT 9 12/19/2014
Color Status
Solid White The ASUS Tablet is plugged to
a power source and the battery
power is between 95% and
100%.
Solid Orange The ASUS Tablet is plugged to
a power source, charging its
battery, and the battery power
is less than 95%.
Blinking Orange The ASUS Tablet is running on
battery mode and the battery
power is less than 10%.
Lights o The ASUS Tablet is running on
battery mode and the battery
power is between 10% to 100%.
18
ASUS Tablet and ASUS Mobile Dock E-Manual
DRAFT 9 12/19/2014
Bottom side
Keyboard dock slots
These slots help align the keyboard dock tabs to securely attach
the tablet with the keyboard dock.
MicroSD card slot
This built-in memory card reader slot supports microSD and
microSDHC card formats.
ASUS Tablet and ASUS Mobile Dock E-Manual
19
DRAFT 9 12/19/2014
Left side
Power (DC) input port
Insert the bundled power adapter into this port to charge the
battery pack and supply power to your ASUS Tablet.
WARNING! The adapter may become warm to hot while in use.
Do not cover the adapter and keep it away from your body while
it is connected to a power source.
IMPORTANT! Use only the bundled power adapter to charge
the battery pack and supply power to your ASUS Tablet.
Audio speakers
The built-in audio speakers allow you to hear audio straight
from your tablet. Audio features are software controlled.
Windows® button
Press this button to go back to Start screen. If you are already in
the Start screen, press this button to go back to the last app you
opened.
Volume button
Press this button to increase or decrease the volume.
20
ASUS Tablet and ASUS Mobile Dock E-Manual
DRAFT 9 12/19/2014
Right side
Audio speakers
The built-in audio speakers allow you to hear audio straight
from your tablet. Audio features are software controlled.
USB 3.0 Micro-B port
Connect the bundled USB 3.0 Micro-B dongle into this port to
charge or supply power to your ASUS Mobile Dock using the
ASUS Tablet.
Micro HDMI port
This port is for a micro HDMI (High-Denition Multimedia
Interface) connector and is HDCP compliant for HD DVD, Blu-
ray, and other protected content playback.
Headphone output/microphone input combo jack port
This port allows you to connect your tablet to amplied
speakers or headphones. You can also use this port to connect
your tablet to an external microphone.
ASUS Tablet and ASUS Mobile Dock E-Manual
21
DRAFT 9 12/19/2014
esc
f1 f2 f3 f4 f5 f6 f7 f8 f9 f10 f11 f12
pause
prt sc
delete
home
pgup
pgdn
end
enter
scr lk
sysrq break
backspace
tab
caps lock
shift
shift
ctrl
ctrl
alt
alt
fn
ASUS Mobile Dock
Top View
NOTE: The keyboard's layout may vary per model, region, or country.
Bluetooth switch
Move this swich to the right or left to turn on or turn o your
ASUS Mobile Dock’s Bluetooth connectivity.
Bluetooth indicator
This indicator lights up when your ASUS Mobile Dock’s Bluetooth
is enabled.
22
ASUS Tablet and ASUS Mobile Dock E-Manual
DRAFT 9 12/19/2014
Two-color battery charge indicator
The two-color LED provides a visual indication of the battery’s
charge status. Refer to the following table for details:
Color Status
Solid White The ASUS Mobile Dock is
plugged to a power source and
the battery power is between
95% and 100%.
Solid Orange The ASUS Mobile Dock is
plugged to a power source,
charging its battery, and the
battery power is less than 95%.
Blinking Orange The ASUS Mobile Dock is
running on battery mode and
the battery power is less than
10%.
Lights o The ASUS Mobile Dock is
running on battery mode and
the battery power is between
10% to 100%.
ASUS Tablet and ASUS Mobile Dock E-Manual
23
DRAFT 9 12/19/2014
Keyboard dock hinge
This hinge allows you to connect the tablet to the keyboard
dock. It also holds the tablet in place as you adjust it to dierent
viewing angles.
Keyboard
The keyboard provides full-sized QWERTY keys with a
comfortable travel depth for typing. It also enables you to use
the function keys, allows quick access to Windows®, and controls
other multimedia functions.
NOTE: The keyboard layout diers by model or region.
Touchpad
The touchpad allows the use of multi-gestures to navigate
onscreen, providing an intuitive user experience. It also simulates
the functions of a regular mouse.
NOTE: For more details, refer to the Gestures for the touchscreen
panel and touchpad section in this manual.
24
ASUS Tablet and ASUS Mobile Dock E-Manual
DRAFT 9 12/19/2014
Micro USB 2.0 port
You may also insert the bundled power adapter into this port to
charge the battery pack and supply power to your ASUS Mobile
Dock.
WARNING! The adapter may become warm to hot while in use.
Do not cover the adapter and keep it away from your body while
it is connected to a power source.
IMPORTANT! Use only the bundled power adapter to charge the
battery pack and supply power to your ASUS Mobile Dock.
Left side
ASUS Tablet and ASUS Mobile Dock E-Manual
25
DRAFT 9 12/19/2014
Chapter 2:
Using your ASUS Tablet and
ASUS Mobile Dock
26
ASUS Tablet and ASUS Mobile Dock E-Manual
DRAFT 9 12/19/2014
IMPORTANT!
Power adapter information:
• Inputvoltage:100-240Vac
• Inputfrequency:50/60Hz
• Ratingoutputcurrent:1.75Amax.(33W)
• Ratingoutputvoltage:19V
Getting started
ASUS Tablet
Charging your ASUS Tablet
A. Plug the AC power adapter into a 100V~240V power source.
B. Connect the DC power connector into your ASUS Tablet’s power
(DC) input.
NOTE: The power adapter may vary in appearance, depending on models
and your region. Use only the bundled power adapter for charging.
ASUS Tablet and ASUS Mobile Dock E-Manual
27
DRAFT 9 12/19/2014
IMPORTANT!
• Locatetheinput/outputratinglabelonyourASUSTabletandASUS
Mobile Dock and ensure that it matches the input/output rating
information on your power adapter. Some ASUS Tablet and ASUS
Mobile Dock models may have multiple rating output currents based
on the available SKU.
• EnsurethatyourASUSTabletandASUSMobileDockisconnectedto
the power adapter before turning it on for the rst time. We strongly
recommend that you use a grounded wall socket while using your
ASUS Tablet and ASUS Mobile Dock on power adapter mode.
• ThesocketoutletmustbeeasilyaccessibleandnearyourASUS
Tablet and ASUS Mobile Dock.
• TodisconnectyourASUSTabletandASUSMobileDockfromitsmain
power supply, unplug your ASUS Tablet and ASUS Mobile Dock from
the power socket.
Powering on your ASUS Tablet
28
ASUS Tablet and ASUS Mobile Dock E-Manual
DRAFT 9 12/19/2014
WARNING!
Read the following precautions for your ASUS Tablet and ASUS
Mobile Dock’s battery.
• Thebatteryusedinthisdevicemaypresentariskofreorchemical
burn if removed or disassembled.
• Followthewarninglabelsforyourpersonalsafety.
• Riskofexplosionifbatteryisreplacedbyanincorrecttype.
• Donotdisposeofinre.
• Neverattempttoshort-circuityourASUSTabletandASUSMobile
Dock’s battery.
• Neverattempttodissambleandreassemblethebattery.
• Discontinueusageifleakageisfound.
• Thebatteryanditscomponentsmustberecycledordisposedof
properly.
• Keepthebatteryandothersmallcomponentsawayfromchildren.
ASUS Tablet and ASUS Mobile Dock E-Manual
29
DRAFT 9 12/19/2014
ASUS Mobile Dock
Charging your ASUS Mobile Dock
A. Connect the bundled USB 3.0 Micro-B dongle into your ASUS
Tablet.
B. Connect the bundled USB to micro USB cable between the ASUS
Mobile Dock and the USB 3.0 Micro-B dongle.
C. Connect the ASUS Tablet to a nearby power outlet.
NOTE: For details, refer to the Charging your ASUS Tablet section in this
E-Manual.
Powering on your ASUS Mobile Dock
IMPORTANT! Enable the Bluetooth function on your display device to
pair it with your ASUS Mobile Dock.
30
ASUS Tablet and ASUS Mobile Dock E-Manual
DRAFT 9 12/19/2014
Pairing your ASUS Mobile Dock with the ASUS Tablet
You may use your ASUS Mobile Dock to wirelessly connect with your
ASUS Tablet via Bluetooth pairing. Refer to the following steps to learn
how to establish this connection.
1. Turn on your ASUS Mobile Dock and its Bluetooth function by
pressing the switch all the way to the right.
esc
f1 f2 f3 f4 f5 f6 f7 f8 f9 f10 f11 f12
pause
prt sc delete
home
pgup
pgdn end
enter
scr lk
sysrq break
backspace
tab
caps lock
shift shift
ctrl
ctrl
alt alt
fn
2. Turn on the Bluetooth feature of your ASUS Tablet.
3. Search for the name ASUS T300CHI DOCKING under the list of
Bluetooth devices for pairing, then select it.
4. While pairing, your device displays a number code that you
should type in using your ASUS Mobile Dock.
5. A conrmation notice appears on the paired device to notify you
if Bluetooth pairing is successful.
ASUS Tablet and ASUS Mobile Dock E-Manual
31
DRAFT 9 12/19/2014
Using your ASUS Tablet with the
ASUS Mobile Dock
Refer to the following steps if you want to use both your ASUS Tablet
and ASUS Mobile Dock as a Notebook PC.
1. Ensure that both devices are charged.
2. Dock the ASUS Tablet into the ASUS Mobile Dock as shown in the
illustration below.
3. Turn on each device to enable automatic Bluetooth pairing.
32
ASUS Tablet and ASUS Mobile Dock E-Manual
DRAFT 9 12/19/2014
Left edge swipe Right edge swipe
Swipe from the left edge of the
screen to shue through your
running apps.
Swipe from the right edge of the
screen to launch the Charms bar.
Gestures for the touch screen
panel and touchpad
Gestures allow you to launch programs and access the settings of your
ASUS Tablet and ASUS Mobile Dock. Refer to the following illustrations
when using hand gestures on your tablet and touchpad.
Using the touch screen panel
ASUS Tablet and ASUS Mobile Dock E-Manual
33
DRAFT 9 12/19/2014
Zoom out Zoom in
Bring together your two ngers
on the touch screen panel.
Spread apart your two ngers on
the touch screen panel.
Tap/Double tap Tap and hold
• Tapanapptolaunchit.
• OnDesktopmode,double-
tap an application to launch
it.
• Tomoveanapp,tapand
hold the app tile then drag
it to a new location.
• Tocloseanapp,tapand
hold the top side of a
running app and drag it
down to the bottom of the
screen.
34
ASUS Tablet and ASUS Mobile Dock E-Manual
DRAFT 9 12/19/2014
Top edge swipe Finger slide
• IntheStartscreen,swipe
from the top edge of
the screen to view the
Customize bar.
• Inarunningapp,swipefrom
the top edge of the screen to
view its menu.
Slide your nger to scroll up
and down and slide your nger
to pan the screen left or right.
Swipe up Swipe down
Swipe up from the Start screen to
launch the Apps screen.
Swipe down the Apps screen to
return to the Start screen.
ASUS Tablet and ASUS Mobile Dock E-Manual
35
DRAFT 9 12/19/2014
Using the touchpad
Moving the pointer
You can tap or click anywhere on the touchpad to activate its pointer,
then slide your nger on the touchpad to move the pointer onscreen.
Slide horizontally
Slide vertically
Slide diagonally
36
ASUS Tablet and ASUS Mobile Dock E-Manual
DRAFT 9 12/19/2014
One nger gestures
Tap/Double tap
• IntheStartscreen,tapanapptolaunchit.
• InDesktopmode,double-tapanapplicationtolaunchit.
Drag and drop
Double-tap an item, then slide the same nger without lifting it o the
touchpad. To drop the item to its new location, lift your nger from the
touchpad.
ASUS Tablet and ASUS Mobile Dock E-Manual
37
DRAFT 9 12/19/2014
Left-click Right-click
• IntheStartscreen,clickan
app to launch it.
• InDesktopmode,double-
click an application to
launch it.
• IntheStartscreen,clickan
app to select it and launch
the settings bar. You can also
press this button to launch
the All Apps bar.
• InDesktopmode,usethis
button to open the right-
click menu.
NOTE: The areas inside the dotted line represent the locations of the left
mouse button and the right mouse button on the touchpad.
38
ASUS Tablet and ASUS Mobile Dock E-Manual
DRAFT 9 12/19/2014
Top edge swipe
• IntheStartscreen,swipefromthetopedgetolaunchtheAll
Apps bar.
• Inarunningapp,swipefromthetopedgetoviewitsmenu.
Left edge swipe Right edge swipe
Swipe from the left edge to shue
your running apps.
Swipe the right edge to launch
the Charms bar.
ASUS Tablet and ASUS Mobile Dock E-Manual
39
DRAFT 9 12/19/2014
Two nger gestures
Tap Rotate
Tap two ngers on the touchpad
to simulate the right-click
function.
To rotate an image, place two
ngers on the touchpad then
turn one nger clockwise or
counterclockwise while the other
stays still.
Two-nger scroll (up/down) Two-nger scroll (left/right)
Slide two ngers to scroll up or
down.
Slide two ngers to scroll left or
right.
40
ASUS Tablet and ASUS Mobile Dock E-Manual
DRAFT 9 12/19/2014
Zoom out Zoom in
Bring together your two ngers
on the touchpad.
Spread apart your two ngers on
the touchpad.
Drag and drop
Select an item then press and hold the left button. Using your other
nger, slide down the touchpad to drag and drop the item to a new
location.
ASUS Tablet and ASUS Mobile Dock E-Manual
41
DRAFT 9 12/19/2014
Three-nger gestures
Swipe up Swipe down
Swipe three ngers upward to
show all running applications.
Swipe three ngers downward to
show the Desktop mode.
Swipe down
Swipe three ngers downward to show the Desktop mode.
42
ASUS Tablet and ASUS Mobile Dock E-Manual
DRAFT 9 12/19/2014
Function keys
The function keys on your ASUS Mobile Dock can trigger the following
commands:
Using the keyboard
Puts the ASUS Tablet into Sleep mode
Decreases display brightness
Increases display brightness
Turns the display panel o
Toggles the display mode
NOTE: Ensure that the second display is connected to
your primary display device.
Enables or disables the touchpad
Turns the speaker on or o
Turns the speaker volume down
Turns the speaker volume up
ASUS Tablet and ASUS Mobile Dock E-Manual
43
DRAFT 9 12/19/2014
Windows® 8.1 keys
There are two special Windows® keys on your ASUS Mobile Dock, used
as below:
Press this key to go back to the Start screen. If you are
already in the Start screen, press this key to go back to
the last app you opened.
Press this key to simulate the right-click functions.
44
ASUS Tablet and ASUS Mobile Dock E-Manual
DRAFT 9 12/19/2014
ASUS Tablet and ASUS Mobile Dock E-Manual
45
DRAFT 9 12/19/2014
Chapter 3:
Working with Windows® 8.1
46
ASUS Tablet and ASUS Mobile Dock E-Manual
DRAFT 9 12/19/2014
Starting for the rst time
When you start your computer for the rst time, a series of screens
appear to guide you in conguring your Windows® 8.1 operating
system. The Windows® 8.1 operating system is bundled within your
ASUS Tablet.
To start for the rst time:
1. Turn on your ASUS Mobile Dock (if applicable) and ASUS Tablet.
Wait for a few minutes until the setup screen appears.
2. From the setup screen, pick your region and a language to use on
your ASUS Tablet.
3. Carefully read the License Terms. Select I accept.
4. Follow the onscreen instructions to congure the following basic
items:
• Personalize
• Getonline
• Settings
• Youraccount
5. After conguring the basic items, Windows® 8.1 proceeds to
install your apps and preferred settings. Ensure that your ASUS
Tablet is kept powered on during the setup process.
6. Once the setup process is complete, the Start screen appears.
ASUS Tablet and ASUS Mobile Dock E-Manual
47
DRAFT 9 12/19/2014
Windows® UI
Windows® 8.1 comes with a tile-based user interface (UI) which allows
you to organize and easily access Windows® apps from the Start screen.
It also includes the following features that you can use while working
on your ASUS Tablet and ASUS Mobile Dock.
Start screen
The Start screen appears after successfully signing in to your user
account. It helps organize all the applications you need in just one
place.
Windows® Apps
These are apps pinned on the Start screen and displayed on tiled-format
for easy access.
NOTE: Some apps require signing in to your Microsoft account before
they are fully launched.
48
ASUS Tablet and ASUS Mobile Dock E-Manual
DRAFT 9 12/19/2014
Hotspots
Onscreen hotspots allow you to launch programs and access the
settings of your ASUS Tablet and ASUS Mobile Dock. The functions in
these hotspots can be activated using the touchpad.
Hotspots on a running app
Hotspots on the Start screen
ASUS Tablet and ASUS Mobile Dock E-Manual
49
DRAFT 9 12/19/2014
Hotspot Action
upper left corner Hover your mouse pointer on the upper left
corner then tap/click on the recent app’s
thumbnail to revert back to that running app.
If you launched more than one app, slide
down to show all running apps.
lower left corner From a running app screen:
Hover your mouse pointer on the lower left
corner then tap/click to go back to the
Start screen.
NOTE: You can also press the Windows key
on your keyboard to go back to the
Start screen.
From the Start screen:
Hover your mouse pointer on the lower left
corner then tap/click to go back to that
app.
50
ASUS Tablet and ASUS Mobile Dock E-Manual
DRAFT 9 12/19/2014
Hotspot Action
top side Hover your mouse pointer on the top side
until it changes to a hand icon. Drag then
drop the app to a new location.
NOTE: This hotspot function only works on
a running app or when you want to use the
Snap feature. For more details, refer to the
Snap feature under Working with Windows®
apps.
upper or lower right
corner
Hover your mouse pointer on the upper or
lower right corner to launch the Charms bar.
ASUS Tablet and ASUS Mobile Dock E-Manual
51
DRAFT 9 12/19/2014
Start button
Windows® 8.1 features the Start button which allows you to switch
between the two most recent apps that you opened. The Start button
may be accessed from the Start screen, while on Desktop mode, and on
any app that is currently open onscreen.
Start button on the Start screen
NOTE: The actual color of your Start button varies depending on the
display settings you chose for your Start screen.
Hover your mouse pointer over the left corner of your Start
screen or any opened app to call out the Start button.
52
ASUS Tablet and ASUS Mobile Dock E-Manual
DRAFT 9 12/19/2014
Context menu
The context menu appears as a box lled with quick access to some of
the programs inside Windows® 8.1 when you right-click on the Start
button.
The context menu also includes the following shut down options for
your ASUS Tablet: sign out, sleep, shut down, restart.
Start button on Desktop mode
ASUS Tablet and ASUS Mobile Dock E-Manual
53
DRAFT 9 12/19/2014
Customizing your Start screen
Windows® 8.1 also enables you to customize your Start screen,
allowing you to boot directly to the Desktop mode and customize the
arrangement of your apps onscreen.
To customize the settings of your Start screen:
or
1. Launch the Desktop.
2. Right-click anywhere on the taskbar, except on the
Start button, to launch the pop-up window.
3. Click Properties then select the Navigation tab to
tick the Navigation and Start screen options you
want to use.
4. Tap/click Apply to save the new settings then exit.
54
ASUS Tablet and ASUS Mobile Dock E-Manual
DRAFT 9 12/19/2014
Working with Windows® apps
Use your ASUS Tablet or ASUS Mobile Dock to launch, customize, and
close apps.
Launching apps
Customizing apps
You can move, resize, unpin, or close apps from the Start screen using
the following steps:
Tap an app to launch it.
Position your mouse pointer over the app then left-click
or tap once to launch it.
Press twice then use the arrow keys to browse
through the apps. Press to launch an app.
Moving apps
Tap and hold the app tile then drag it to a new location.
Double-tap on the app then drag and drop the app to a
new location.
ASUS Tablet and ASUS Mobile Dock E-Manual
55
DRAFT 9 12/19/2014
Tap and hold the app to activate the Customize bar then
tap and select an app tile size.
Tap and hold the app to activate the Customize bar, then
tap to unpin an app.
Unpinning apps
Resizing apps
Right-click on the app to activate the Customize bar,
then tap/click and select an app tile size.
Right-click on the app to activate the Customize bar
then tap/click .
56
ASUS Tablet and ASUS Mobile Dock E-Manual
DRAFT 9 12/19/2014
Tap and hold the top side of the running app then drag
it down to the bottom of the screen to close it.
1. Move your mouse pointer on the top side of the
launched app then wait for the pointer to change
to a hand icon.
2. Drag then drop the app to the bottom of the
screen to close it.
From the running app’s screen, press .
Closing apps
ASUS Tablet and ASUS Mobile Dock E-Manual
57
DRAFT 9 12/19/2014
Accessing the Apps screen
Aside from the apps already pinned on your Start screen, you can also
open other applications through the Apps screen.
NOTE: Actual apps shown onscreen may vary per model. The following
screenshot is for reference only.
Launching the Apps screen
Launch the Apps screen using your ASUS Tablet or ASUS Mobile Dock.
Swipe up on the Start screen.
On the Start screen, click the button.
From the Start screen, Press then press .
58
ASUS Tablet and ASUS Mobile Dock E-Manual
DRAFT 9 12/19/2014
Pinning more apps on the Start screen
You can pin more apps on the Start screen using your touch screen
panel or touchpad.
1. Launch the All Apps screen.
2. Tap and hold an app you want to add on the
start to activate the Customize bar. Once the
Customize bar is launched, you may also tap
other more apps to add on the Start screen.
3. Tap to pin the selected apps on the Start
screen.
1. Launch the All Apps screen
2. Right-click on the apps that you want to add on
the Start screen.
3. Tap/click on the icon to pin the selected
apps on the Start screen.
ASUS Tablet and ASUS Mobile Dock E-Manual
59
DRAFT 9 12/19/2014
Charms bar
The Charms bar is a toolbar that can be triggered on the right side
of your screen. It consists of several tools that allow you to share
applications and provide quick access for customizing the settings of
your ASUS Tablet and ASUS Mobile Dock.
Charms bar
60
ASUS Tablet and ASUS Mobile Dock E-Manual
DRAFT 9 12/19/2014
Launching the Charms bar
NOTE: When called out, the Charms bar initially appears as a set of
white icons. The image above shows how the Charms bar looks like once
activated.
Use your ASUS Tablet or ASUS Mobile Dock to launch the Charms bar.
Swipe from the right edge of the screen to launch the
charms bar.
Move your mouse pointer on the upper or lower right
corner of the screen.
Press
ASUS Tablet and ASUS Mobile Dock E-Manual
61
DRAFT 9 12/19/2014
Search
This charm allows you to look for les, applications, or
programs in your ASUS Tablet.
Share
This charm allows you to share applications via social
networking sites or email.
Start
This charm reverts the display back to the Start screen.
From the Start screen, you can also use this to revert back
to a recently opened app.
Devices
This charm allows you to access and share les with the
devices attached to your ASUS Tablet such as an external
display or printer.
Settings
This charm allows you to access the PC settings of your
ASUS Tablet.
Inside the Charms bar
62
ASUS Tablet and ASUS Mobile Dock E-Manual
DRAFT 9 12/19/2014
Snap feature
The Snap feature displays two apps side-by-side, allowing you to work
or switch between apps.
IMPORTANT! Ensure that your screen resolution is set to 1366 x 768 pixels
or higher before using the Snap feature.
Snap bar
ASUS Tablet and ASUS Mobile Dock E-Manual
63
DRAFT 9 12/19/2014
Using Snap
Use your ASUS Tablet or ASUS Mobile Dock to activate and use Snap.
1. Launch the app you wish to snap.
2. Hover the mouse point on the top side of your
screen.
3. Once the pointer changes to a hand icon, drag
then drop the app to the left or right side of the
display panel.
4. Launch another app.
1. Launch the app you wish to snap.
2. Press and the left or right arrow key to snap
the app to the left or right pane.
3. Launch another app. This app is automatically
placed in the empty pane.
1. Launch the app you wish to snap.
2. Tap and hold the app’s topmost part then drag it
to the left or right side of the screen until the snap
bar appears.
3. Launch another app.
64
ASUS Tablet and ASUS Mobile Dock E-Manual
DRAFT 9 12/19/2014
Other keyboard shortcuts
Using the keyboard, you can also use the following shortcuts to help
you launch applications and navigate Windows® 8.1.
\
Switches between the Start screen and the last
running app
Launches the desktop
Launches the This PC window on Desktop mode
Opens the File option from the Search charm
Opens the Share charm
Opens the Settings charm
Opens the Devices charm
Activates the Lock screen
Minimizes all currently active windows
ASUS Tablet and ASUS Mobile Dock E-Manual
65
DRAFT 9 12/19/2014
Launches the Project pane
Opens the Everywhere option from the
Search charm
Opens the Run window
Opens Ease of Access Center
Opens the Settings option under the Search
charm
Opens the context menu of the Start button
Launches the magnier icon and zooms in
your screen
Zooms out your screen
Opens the Narrator Settings
66
ASUS Tablet and ASUS Mobile Dock E-Manual
DRAFT 9 12/19/2014
Connecting to wireless networks
Wi-Fi
Access emails, surf the Internet, and share applications via social
networking sites using Wi-Fi connection.
IMPORTANT! The Airplane mode disables this feature. Ensure that
Airplane mode is turned o before enabling the Wi-Fi connection.
Enabling Wi-Fi
Activate Wi-Fi using the following steps on your touch screen panel or
touchpad.
1. Launch the Charms bar.
2. Tap/click and tap/click .
3. Select an access point from the list of available Wi-Fi connections.
4. Tap/click Connect to start the network connection.
NOTE: You may be prompted to enter a security key to activate the Wi-Fi
connection.
5. If you want to enable sharing between your ASUS Tablet and
other wireless-enabled systems, tap/click Yes. Tap/click No if you
do not want to enable the sharing function.
ASUS Tablet and ASUS Mobile Dock E-Manual
67
DRAFT 9 12/19/2014
Bluetooth
Use Bluetooth to facilitate wireless data transfers with other Bluetooth-
enabled devices.
IMPORTANT! The Airplane mode disables this feature. Ensure that
Airplane mode is turned o before enabling the Bluetooth connection.
Pairing with other Bluetooth-enabled devices
You need to pair your ASUS Tablet with other Bluetooth-enabled
devices to enable data transfers. To do this:
1. Launch the Charms bar.
2. Tap/click then tap/click Change PC Settings.
3. Under PC Settings, select Devices then tap/click Add a Device
to search for Bluetooth-enabled devices.
4. Select a device from the list. Compare the passcode on your ASUS
Tablet with the passcode sent to your chosen device. If they are
the same, tap/click Yes to successfully pair your ASUS Tablet with
the device.
NOTE: For some bluetooth-enabled devices, you may be prompted to
key in the passcode of your ASUS Tablet.
68
ASUS Tablet and ASUS Mobile Dock E-Manual
DRAFT 9 12/19/2014
or
1. Launch the Charms bar.
2. Tap/click and tap/click .
3. Move the slider to the right to turn the Airplane
mode on.
Airplane mode
The Airplane mode disables wireless communication, allowing you to use
your ASUS Tablet and ASUS Mobile Dock safely while in-ight.
Turning Airplane mode on
Turning Airplane mode o
or
1. Launch the Charms bar.
2. Tap/click and tap/click .
3. Move the slider to the left to turn the Airplane
mode o.
NOTE: Contact your airline provider to learn about related inight services
that can be used and restrictions that must be followed when using your
ASUS Tablet and ASUS Mobile Dock in-ight.
ASUS Tablet and ASUS Mobile Dock E-Manual
69
DRAFT 9 12/19/2014
Turning your ASUS Tablet off
You can turn o your ASUS Tablet by doing either of the following
procedures:
or
• Tap/click from the Charms bar then
tap/click > Shut down to do a normal
shutdown.
• Fromthelog-inscreen,tap/click > Shut
down.
• YoucanalsoshutdownyourASUSTabletusing
Desktop mode. To do this, launch the desktop
then press alt + f4 to launch the Shut Down
window. Select Shut Down from the drop-down
list then select OK.
• IfyourASUSTabletisunresponsive,pressand
hold the power button for at least four (4)
seconds until your ASUS Tablet turns o.
Putting your ASUS Tablet to sleep
To put your ASUS Tablet on Sleep mode, press the power button once.
You can also put your ASUS Tablet to sleep mode using
Desktop mode. To do this, launch the desktop then
press alt + f4 to launch the Shut Down window. Select
Sleep from the drop-down list then select OK.
70
ASUS Tablet and ASUS Mobile Dock E-Manual
DRAFT 9 12/19/2014
Windows® 8.1 lock screen
The Windows® 8.1 lock screen appears when you wake your ASUS Tablet
from sleep or hibernate mode. It also appears when you lock or unlock
Windows® 8.1.
The lock screen can be customized to regulate access to your operating
system. You can change its background display and access some of your
apps while your ASUS Tablet is still locked.
To proceed from the lock screen
or
1. Tap/click on the touchpad or press any key on
your ASUS Mobile Dock.
2. (optional) If your account is password-protected,
you need to key in the password to continue to
the Start screen.
ASUS Tablet and ASUS Mobile Dock E-Manual
71
DRAFT 9 12/19/2014
Customizing your lock screen
You can customize your lock screen to show your preferred photo, a
photo slideshow, app updates, and quickly access your ASUS Tablet’s
camera. To change the settings of your lock screen, you may refer to the
following information:
1. Launch the Charms bar > Settings.
2. Select Change PC Settings > Lock screen.
3. Under the Lock screen preview, click Browse
to select the photo you would like to use as a
background on your lock screen.
Playing a slideshow
1. Launch the Charms bar > Settings.
2. Select Change PC Settings > Lock screen.
3. Under the Lock screen preview, move the Play
a slide show on the lock screen slide bar to On.
4. Scroll down to customize the following options
for your lock screen’s slideshow:
Selecting a photo
72
ASUS Tablet and ASUS Mobile Dock E-Manual
DRAFT 9 12/19/2014
Adding app updates
1. Launch the Charms bar > Settings.
2. Select Change PC Settings > Lock screen.
3. Scroll down until you see the Lock screen apps
option.
4. Use the following options to add the apps whose
updates you would like to see from your lock
screen:
Activating your ASUS Tablet camera from the lock screen
From the lock screen, you can swipe down to activate and use your
ASUS Tablet's camera. Refer to the following steps on how to enable this
feature:
1. Launch the Charms bar > Settings.
2. Select Change PC Settings > Lock screen.
3. Scroll down until you see the Camera option.
4. Move the slide bar to On.
ASUS Tablet and ASUS Mobile Dock E-Manual
73
DRAFT 9 12/19/2014
Chapter 4:
Power-On Self-Test (POST)
74
ASUS Tablet and ASUS Mobile Dock E-Manual
DRAFT 9 12/19/2014
The Power-On Self-Test (POST)
The Power-On Self-Test (POST) is a series of software-controlled
diagnostic tests that run when you turn on or restart your ASUS Tablet.
The software that controls the POST is installed as a permanent part of
the ASUS Tablet’s architecture.
Using POST to access BIOS and Troubleshoot
During POST, you can access the BIOS settings or run troubleshooting
options using the volume button on your ASUS Tablet. You may refer to
the following information for more details.
BIOS
The Basic Input and Output System (BIOS) stores system hardware
settings that are needed for system startup in the ASUS Tablet.
The default BIOS settings apply to most conditions of your ASUS
Tablet. Do not change the default BIOS settings except in the following
circumstances:
• Anerrormessageappearsonscreenduringsystembootupand
requests you to run the BIOS Setup.
• Youhaveinstalledanewsystemcomponentthatrequiresfurther
BIOS settings or updates.
WARNING: Using inappropriate BIOS settings may result to system
instability or boot failure. We strongly recommend that you change the
BIOS settings only with the help of a trained service personnel.
ASUS Tablet and ASUS Mobile Dock E-Manual
75
DRAFT 9 12/19/2014
Accessing BIOS
1. Turn on your ASUS Tablet then press the power button and the
volume down button during POST.
2. Use the volume button to select items on the BIOS screen, then
press the Windows key to enter a selected item or tap it using the
touch screen panel.
BIOS Settings
NOTE: The BIOS screens in this section are for reference only. The actual
screens may dier by model and territory.
Boot
This menu allows you to set your boot option priorities. You may refer to
the following procedures when setting your boot priority.
1. On the Boot screen, select Boot Option #1.
F1 : General Help
F9 : Optimized Defaults
F10 : Save & Exit
ESC/Right Click : Exit
Boot Option Priorities
Boot Option #1 [Windows Boot Manager]
Sets the system
boot order
Aptio Setup Utility - Copyright (C) 2013 American Megatrends, Inc.
Main Advanced Boot Security Save & Exit
Version 2.16.1243. Copyright (C) 2013 American Megatrends, Inc.
76
ASUS Tablet and ASUS Mobile Dock E-Manual
DRAFT 9 12/19/2014
2. Press and select a device as the Boot Option #1.
Sets the system
boot order
Aptio Setup Utility - Copyright (C) 2013 American Megatrends, Inc.
Main Advanced Boot Security Save & Exit
Version 2.16.1243. Copyright (C) 2013 American Megatrends, Inc.
Boot Option Priorities
Boot Option #1 [Windows Boot Manager]
F1 : General Help
F9 : Optimized Defaults
F10 : Save & Exit
ESC/Right Click : Exit
Boot Option #1
Windows Boot Manager
Disabled
ASUS Tablet and ASUS Mobile Dock E-Manual
77
DRAFT 9 12/19/2014
Security
This menu allows you to set up the administrator and user password of
your ASUS Tablet. It also allows you to control the access to your ASUS
Tablet’s hard disk drive, input/output (I/O) interface, and USB interface.
NOTE:
• IfyouinstallaUser Password, you will be prompted to input this
before entering your ASUS Tablet and ASUS Mobile Dock's operating
system.
• IfyouinstallanAdministrator Password, you will be prompted to
input this before entering BIOS.
Password Description
If ONLY the Administrator’s password is set,
then this only limits access to Setup and is
only asked for when entering Setup. If ONLY
the user’s password is set, then this is a
power on password and must be entered to boot
or enter Setup. In Setup, the User will have
Administrator rights.
Administrator Password Status NOT INSTALLED
User Password Status NOT INSTALLED
Administrator Password
User Password
Secure Boot Menu
Set Administrator
Password. The
password length
must be in the
following range:
Minimum length 3
Maximum length 20
Must type with
character:
a-z, 0-9
Aptio Setup Utility - Copyright (C) 2013 American Megatrends, Inc.
Main Advanced Boot Security Save & Exit
Version 2.16.1243 Copyright (C) 2013 American Megatrends, Inc.
F1 : General Help
F9 : Optimized
Defaults
F10 : Save & Exit
ESC/Right Click : Exit
78
ASUS Tablet and ASUS Mobile Dock E-Manual
DRAFT 9 12/19/2014
To set the password:
1. On the Security screen, select Administrator Password or User
Password.
2. Type in a password then press .
3. Re-type to conrm the password then press .
To clear the password:
1. On the Security screen, select Administrator Password or User
Password.
2. Type in the current password then press .
3. Leave the Create New Password eld blank then press
.
4. Select Yes in the conrmation box then press .
ASUS Tablet and ASUS Mobile Dock E-Manual
79
DRAFT 9 12/19/2014
Save & Exit
To keep your conguration settings, select Save Changes and Exit
before exiting the BIOS.
Aptio Setup Utility - Copyright (C) 2013 American Megatrends, Inc.
Main Advanced Boot Security Save & Exit
Version 2.16.1243. Copyright (C) 2013 American Megatrends, Inc.
Save Changes and Exit
Discard Changes and Exit
Save Options
Save Changes
Discard Changes
Restore Defaults
Boot Override
Windows Boot Manager
Launch EFI Shell from lesystem device
Exit system setup
after saving the
changes.
F1 : General Help
F9 : Optimized Defaults
F10 : Save & Exit
ESC/Right Click : Exit
80
ASUS Tablet and ASUS Mobile Dock E-Manual
DRAFT 9 12/19/2014
To update the BIOS:
1. Verify the ASUS Tablet’s exact model then download the latest
BIOS le for your model from the ASUS website.
2. Save a copy of the downloaded BIOS le to a ash disk drive.
3. Connect your ash disk drive to your ASUS Tablet.
4. Restart your ASUS Tablet then press during POST.
5. From the BIOS menu, Select Advanced > Start Easy Flash, then
press .
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
Start Easy Flash
Network Stack Conguration
USB Conguration
Press Enter to run
the utility to
select and update
BIOS.
Aptio Setup Utility - Copyright (C) 2013 American Megatrends, Inc.
Main Advanced Boot Security Save & Exit
Version 2.16.1243. Copyright (C) 2013 American Megatrends, Inc.
F1 : General Help
F9 : Optimized Defaults
F10 : Save & Exit
ESC/Right Click : Exit
ASUS Tablet and ASUS Mobile Dock E-Manual
81
DRAFT 9 12/19/2014
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
FSO
FS1
FS2
FS3
FS4
0 EFI
<DIR>
ASUSTek Easy Flash Utility
[←→]: Switch [↑↓]: Choose [q]: Exit [Enter]: Enter/Execute
Current BIOS
Platform: T300CHI
Version: 101
Build Date: Oct 26 2012
Build Time: 11:51:05
New BIOS
Platform: Unknown
Version: Unknown
Build Date: Unknown
Build Time: Unknown
FLASH TYPE: MXIC 25L Series
6. Locate your downloaded BIOS le in the ash disk drive then
press .
7. After the BIOS update process, select Exit > Restore Defaults to
restore the system to its default settings.
82
ASUS Tablet and ASUS Mobile Dock E-Manual
DRAFT 9 12/19/2014
Recovering your system
Using recovery options on your ASUS Tablet allows you to restore the
system to its original state or simply refresh its settings to help improve
performance.
IMPORTANT!
• Back up all your data les before doing any recovery option on your
ASUS Tablet.
• Notedownimportantcustomizedsettingssuchasnetworksettings,
user names, and passwords to avoid data loss.
• Ensure that your ASUS Tablet is plugged in to a power source before
resetting your system.
Windows® 8.1 allows you to do any of the following recovery options:
• RefreshyourPCwithoutaectingyourles- This option allows
you refresh your ASUS Tablet without aecting personal les
(photos, music, videos, documents) and apps from the Windows®
store.
Using this option, you can restore your ASUS Tablet to its default
settings and delete other installed apps.
• RemoveeverythingandreinstallWindows- This option resets
your ASUS Tablet to its factory settings. You must back up your
data before doing this option.
ASUS Tablet and ASUS Mobile Dock E-Manual
83
DRAFT 9 12/19/2014
• Advancedstartup- Using this option allows you to perform
other advanced recovery options on your ASUS Tablet such as:
- Using a USB drive, network connection or Windows recovery
DVD to startup your ASUS Tablet.
- Using Troubleshoot to enable any of these advanced
recovery options: System Restore, System Image Recovery,
Startup Repair, Command Prompt, UEFI Firmware Settings,
Startup Settings.
Enabling a recovery option
Refer to the following steps if you want to access and use any of the
available recovery options for your ASUS Tablet.
1. Launch the charms bar and select Settings.
84
ASUS Tablet and ASUS Mobile Dock E-Manual
DRAFT 9 12/19/2014
2. Select Change PC Settings.
3. Under the PC Settings options, select Update and recovery.
ASUS Tablet and ASUS Mobile Dock E-Manual
85
DRAFT 9 12/19/2014
4. Under the Update and recovery options, select Recovery then
select the recovery option you would like to do.
86
ASUS Tablet and ASUS Mobile Dock E-Manual
DRAFT 9 12/19/2014
ASUS Tablet and ASUS Mobile Dock E-Manual
87
DRAFT 9 12/19/2014
Tips and FAQs
88
ASUS Tablet and ASUS Mobile Dock E-Manual
DRAFT 9 12/19/2014
Useful tips for your ASUS Tablet
and ASUS Mobile Dock
To help you maximize the use of your ASUS Tablet and ASUS Mobile
Dock, maintain its system performance, and ensure all your data are
kept secured, here are some useful tips that you can follow:
• UpdateWindows®periodicallytoensurethatyourapplications
have the latest security settings.
• UseASUSLiveUpdatetoupdateASUS-exclusiveapplications,
drivers and utilities in your ASUS Tablet and ASUS Mobile Dock.
Refer to the ASUS Tutor installed in your ASUS Tablet for more
details.
• Useananti-virussoftwaretoprotectyourdataandkeepthis
updated too.
• Unlessabsolutelynecessary,refrainfromusingforceshutdownto
turn o your ASUS Tablet and ASUS Mobile Dock.
• Alwaysbackupyourdataandmakeitapointtocreateabackup
data in an external storage drive.
• RefrainfromusingtheASUSTabletandASUSMobileDockat
extremely high temperatures. If you are not going to use your
ASUS Tablet and ASUS Mobile Dock for a long period of time (at
least a month), we recommend that you take out the battery if
the battery is removable.
• Disconnectallexternaldevicesandensureyouhavethefollowing
items prior to resetting your ASUS Tablet and ASUS Mobile Dock:
- Product key for your operating systems and other installed
applications
- Backup data
- Log in ID and password
- Internet connection information
ASUS Tablet and ASUS Mobile Dock E-Manual
89
DRAFT 9 12/19/2014
Hardware FAQs
1. A black dot, or sometimes a colored dot, appears onscreen
when I turn on the ASUS Tablet. What should I do?
Although these dots normally appear onscreen, they will not
aect your system. If the incident continues and subsequently
aects system performance, consult an authorized ASUS service
center.
2. My display panel has an uneven color and brightness. How
can I x this?
The color and brightness of your display panel may be aected
by the angle and current position of your ASUS Tablet and
ASUS Mobile Dock. The brightness and color tone of your ASUS
Tablet may also vary per model. You may use the function keys
or the display settings in your operating system to adjust the
appearance of your display panel.
3. How can I maximize my ASUS Tablet and ASUS Mobile Dock ‘s
battery life?
You can try doing any of the following suggestions:
• Usethefunctionkeystoadjustthedisplaybrightness.
• IfyouarenotusinganyWi-Ficonnection,switchyour
system into Airplane mode.
• DisconnectunusedUSBdevices.
• Closeunusedapplications,especiallythosethattakeuptoo
much system memory.
90
ASUS Tablet and ASUS Mobile Dock E-Manual
DRAFT 9 12/19/2014
4. My battery LED indicator does not light up. What’s wrong?
• Checkwhetherthepoweradapterorbatterypackis
attached correctly. You may also disconnect the power
adapter or battery pack, wait for a minute, then reconnect
them again to the power outlet and your ASUS Tablet or
ASUS Mobile Dock.
• Iftheproblemstillexists,contactyourlocalASUSservice
center for assistance.
5. Why is my touchpad not working?
• Press to enable your touchpad.
• CheckifASUSSmartGesturehasbeensettodisablethe
touchpad when connecting an external pointing device.
6. When I play audio and video les, why can’t I hear any sound
from my ASUS Tablet’s speakers?
You can try doing any of the following suggestions:
• Checkifyourspeakersweresettomute.
• CheckifaheadphonejackisconnectedtoyourASUSTablet
and remove it.
• UnlocktheI/OInterfaceSecurityinyoursystem’sBIOS.For
more details, refer to the I/O Interface Security section in this
manual.
7. What should I do if my ASUS Tablet and ASUS Mobile Dock’s
power adapter gets lost or my battery stops working?
Contact your local ASUS service center for assistance.
ASUS Tablet and ASUS Mobile Dock E-Manual
91
DRAFT 9 12/19/2014
8. Why does audio still come out from my ASUS Tablet’s audio
speakers even if I already connected my headphone into the
right jack port?
Go to Control Panel > Hardware and Sound then access Audio
Manager to congure the settings.
9. My ASUS Tablet and ASUS Mobile Dock cannot do keystrokes
correctly because my cursor keeps on moving. What should I
do?
Make sure that nothing accidentally touches or presses on your
touchpad while you type on the keyboard. You can also disable
your touchpad by pressing .
10. My ASUS Tablet and ASUS Mobile Dock’s touchpad is not
working. What should I do?
You can try doing any of the following suggestions:
• CheckifASUSSmartGestureissettodisabletouchpadby
connecting an external pointing device to your ASUS Tablet
and ASUS Mobile Dock. If yes, disable this function.
• Press .
11. Instead of showing letters, pressing the “U”, “I”, and “O” keys
on my keyboard displays numbers. How can I change this?
Press the key or (on selected models) on your
ASUS Mobile Dock to turn o this feature and use the said keys
for inputting letters.
92
ASUS Tablet and ASUS Mobile Dock E-Manual
DRAFT 9 12/19/2014
Software FAQs
1. When I turn on my ASUS Tablet and ASUS Mobile Dock, the
power indicator lights up but not my drive activity indicator.
System bootup does not happen as well. What can I do to x
this?
You can try doing any of the following suggestions:
• ForceshutdownyourASUSTabletandASUSMobileDockby
pressing the power button for more than ten (10) seconds.
Check if the power adapter is inserted correctly then turn on
your ASUS Tablet and ASUS Mobile Dock.
• Iftheproblemstillexists,contactyourlocalASUSservice
center for assistance.
2. What should I do when my screen displays this message:
“Remove disks or other media. Press any key to restart.”?
You can try doing any of the following suggestions:
• RemoveallconnectedUSBdevicesthenrestartyourASUS
Tablet and ASUS Mobile Dock.
• Removeanyopticaldiscsthatareleftinsidetheopticaldrive
then restart.
• Iftheproblemstillexists,yourASUSTabletmighthavea
memory storage problem. Contact your local ASUS service
center for assistance.
3. My ASUS Tablet boots slower than usual and my operating
system lags. How can I x this?
Delete the applications you recently installed or were not
included with your operating system package then restart your
system.
ASUS Tablet and ASUS Mobile Dock E-Manual
93
DRAFT 9 12/19/2014
4. My ASUS Tablet does not boot up. How can I x this?
You can try doing any of the following suggestions:
• RemoveallconnecteddevicestoyourASUSTabletand
ASUS Mobile Dock then restart your system.
• Iftheproblemstillexists,contactyourlocalASUSservice
center for assistance.
5. Why can’t my ASUS Tablet wake up from sleep or hibernate
mode?
• Youneedtopressthepowerbuttontoresumeyourlast
working state.
• Yoursystemmighthavecompletelyusedupitsbattery
power. Connect the power adapter to your ASUS Tablet and
ASUS Mobile Dock and connect to a power outlet then press
the power button.
94
ASUS Tablet and ASUS Mobile Dock E-Manual
DRAFT 9 12/19/2014
ASUS Tablet and ASUS Mobile Dock E-Manual
95
DRAFT 9 12/19/2014
Appendices
96
ASUS Tablet and ASUS Mobile Dock E-Manual
DRAFT 9 12/19/2014
Internal Modem Compliancy
The ASUS Tablet with internal modem model complies with JATE (Japan), FCC
(US, Canada, Korea, Taiwan), and CTR21. The internal modem has been approved
in accordance with Council Decision 98/482/EC for pan-European single terminal
connection to the public switched telephone network (PSTN). However due
to dierences between the individual PSTNs provided in dierent countries,
the approval does not, of itself, give an unconditional assurance of successful
operation on every PSTN network termination point. In the event of problems you
should contact your equipment supplier in the rst instance.
Overview
On 4th August 1998 the European Council Decision regarding the CTR 21 has
been published in the Ocial Journal of the EC. The CTR 21 applies to all non
voice terminal equipment with DTMF-dialling which is intended to be connected
to the analogue PSTN (Public Switched Telephone Network).
CTR 21 (Common Technical Regulation) for the attachment requirements for
connection to the analogue public switched telephone networks of terminal
equipment (excluding terminal equipment supporting the voice telephony
justied case service) in which network addressing, if provided, is by means of
dual tone multi-frequency signalling.
Network Compatibility Declaration
Statement to be made by the manufacturer to the Notied Body and the vendor:
“This declaration will indicate the networks with which the equipment is designed
to work and any notied networks with which the equipment may have inter-
working diculties.”
Statement to be made by the manufacturer to the user: “This declaration will
indicate the networks with which the equipment is designed to work and any
notied networks with which the equipment may have inter-working diculties.
The manufacturer shall also associate a statement to make it clear where network
compatibility is dependent on physical and software switch settings. It will also
advise the user to contact the vendor if it is desired to use the equipment on
another network.”
Up to now the Notied Body of CETECOM issued several pan-European approvals
using CTR 21. The results are Europe’s rst modems which do not require
regulatory approvals in each individual European country.
ASUS Tablet and ASUS Mobile Dock E-Manual
97
DRAFT 9 12/19/2014
Non-Voice Equipment
Answering machines and loud-speaking telephones can be eligible as well as
modems, fax machines, auto-dialers and alarm systems. Equipment in which the
end-to-end quality of speech is controlled by regulations (e.g. handset telephones
and in some countries also cordless telephones) is excluded.
This table shows the countries currently under the CTR21
standard.
Country Applied More Testing
Austria
1
Yes No
Belgium Yes No
Czech Republic No Not Applicable
Denmark
1
Yes Yes
Finland Yes No
France Yes No
Germany Yes No
Greece Yes No
Hungary No Not Applicable
Iceland Yes No
Ireland Yes No
Italy Still Pending Still Pending
Israel No No
Lichtenstein Yes No
Luxemburg Yes No
The Netherlands
1
Yes Yes
Norway Yes No
Poland No Not Applicable
Portugal No Not Applicable
Spain No Not Applicable
Sweden Yes No
Switzerland Yes No
United Kingdom Yes No
98
ASUS Tablet and ASUS Mobile Dock E-Manual
DRAFT 9 12/19/2014
This information was copied from CETECOM and is supplied without liability. For
updates to this table, you may visit http://www.cetecom.de/technologies/ctr_21.
html
1 National requirements will apply only if the equipment may use pulse dialling
(manufacturers may state in the user guide that the equipment is only intended to
support DTMF signalling, which would make any additional testing superuous).
In The Netherlands additional testing is required for series connection and caller
ID facilities.
Federal Communications Commission
Interference Statement
This device complies with FCC Rules Part 15. Operation is subject to the following
two conditions:
• Thisdevicemaynotcauseharmfulinterference.
• Thisdevicemustacceptanyinterferencereceived,includinginterference
that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a class
B digital device, pursuant to Part 15 of the Federal Communications Commission
(FCC) rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses,
and can radiate radio frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment o and on, the user
is encouraged to try to correct the interference by one or more of the following
measures:
• Reorientorrelocatethereceivingantenna.
• Increasetheseparationbetweentheequipmentandreceiver.
ASUS Tablet and ASUS Mobile Dock E-Manual
99
DRAFT 9 12/19/2014
• Connecttheequipmentintoanoutletonacircuitdierentfromthatto
which the receiver is connected.
• Consultthedealeroranexperiencedradio/TVtechnicianforhelp.
WARNING! The use of a shielded-type power cord is required in order to meet
FCC emission limits and to prevent interference to the nearby radio and television
reception. It is essential that only the supplied power cord be used. Use only shielded
cables to connect I/O devices to this equipment. You are cautioned that changes or
modications not expressly approved by the party responsible for compliance could
void your authority to operate the equipment.
(Reprinted from the Code of Federal Regulations #47, part 15.193, 1993.
Washington DC: Oce of the Federal Register, National Archives and Records
Administration, U.S. Government Printing Oce.)
This device operates within a 5.15-5.25 GHz frequency range and is restricted for
indoor use only. Outdoor operation within 5150-5250MHz is prohibited.
Slave Equipment
This device is a slave equipment. This device is not radar detection and not ad-hoc
operation in the DFS band.
RF Exposure warning
This equipment complies with FCC RF exposure limits set forth for an uncontrolled
environment. The equipment must not be co-located or operating in conjunction
with any other antenna or transmitter.
100
ASUS Tablet and ASUS Mobile Dock E-Manual
DRAFT 9 12/19/2014
FCC Radio Frequency (RF) Exposure Caution
Statement
WARNING! Any changes or modications not expressly approved by the party
responsible for compliance could void the user’s authority to operate this equipment.
“The manufacture declares that this device is limited to Channels 1 through 11 in the
2.4GHz frequency by specied rmware controlled in the USA.”
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. To maintain compliance with FCC RF exposure
compliance requirements, please avoid direct contact to the transmitting antenna
during transmitting. End users must follow the specic operating instructions for
satisfying RF exposure compliance.
RF Exposure Information (SAR)
This device meets the government’s requirements for exposure to radio waves.
This device is designed and manufactured not to exceed the emission limits for
exposure to radio ferquency (RF) energy set by the Federal Communications
Commission of the U.S. Government.
The exposure standard employs a unit of measurement known as the Specic
Absorption Rate, or SAR. The SAR limit set by the FCC is 1.6 W/kg. Tests for SAR are
conducted using standard operating positions accepted by the FCC with the EUT
transmitting at the specied power level in dierent channels.
The FCC has granted an Equipment Authorization for this device with all reported
SAR levels evaluated as in compliance with the FCC RF exposure guidelines. SAR
information on this device is on le with the FCC and can be found under the
Display Grant section of www.fcc.gov/eot/ea/fccid
MODEL NAME FCC ID FUNCTION CONTAINS MODULE
T300 Chi PD97265NG WLAN /
Bluetooth
Yes
T300 Chi Mobile
Dock
MSQT300CHIDOCK Bluetooth only N/A
This transmitter must not be co-located or operating in conjunction with any other
antenna or transmitter.
ASUS Tablet and ASUS Mobile Dock E-Manual
101
DRAFT 9 12/19/2014
RF Exposure information (SAR) - CE
This device meets the EU requirements (1999/519/EC) on the limitation of
exposure of the general public to electromagnetic elds by way of health
protection.
The limits are part of extensive recommendations for the protection of the
general public. These recommendations have been developed and checked by
independent scientic organizations through regular and thorough evaluations
of scientic studies. The unit of measurement for the European Council’s
recommended limit for mobile devices is the “Specic Absorption Rate” (SAR),
and the SAR limit is 2.0 W/Kg averaged over 10 gram of body tissue. It meets
the requirements of the International Commission on Non-Ionizing Radiation
Protection (ICNIRP).
For next-to-body operation, this device has been tested and meets the ICNRP
exposure guidelines and the European Standard EN 50566 and EN 62209-2. SAR is
measured with the device directly contacted to the body while transmitting at the
highest certied output power level in all frequency bands of the mobile device.
CE Mark Warning
This device complies with the R&TTE Directive (1999/5/EC), the EMC Directive
(2004/108/EC), and the Low Voltage Directive (2006/95/EC) issued by the
Commission of the European Community.
Countries where the device will be sold to:
T BE BG CH CY CZ DE DK
EE ES FI FR GB GR HU IE
IT IS LI LT LU LV MT NL
NO PL PT RO SE SI SK TR
102
ASUS Tablet and ASUS Mobile Dock E-Manual
DRAFT 9 12/19/2014
IC Radiation Exposure Statement for Canada
This equipment complies with IC radiation exposure limits set forth for an
uncontrolled environment. To maintain compliance with IC RF exposure
compliance requirements, please avoid direct contact to the transmitting antenna
during transmitting. End users must follow the specic operating instructions for
satisfying RF exposure compliance.
Operation is subject to the following two conditions:
• Thisdevicemaynotcauseinterferenceand
• Thisdevicemustacceptanyinterference,includinginterferencethatmay
cause undesired operation of the device.
To prevent radio interference to the licensed service (i.e. co-channel Mobile
Satellite systems) this device is intended to be operated indoors and away from
windows to provide maximum shielding. Equipment (or its transmit antenna) that
is installed outdoors is subject to licensing.
This device complies with Industry Canada licence-exempt RSS standard(s).
CAN ICES-3(B)/NMB-3(B)
This device and its antenna(s) must not be co-located or operating in conjunction
with any other antenna or transmitter, except tested built-in radios.
MODEL NAME IC ID FUNCTION CONTAINS MODULE
T300 Chi 1000M-7265NG WLAN /
Bluetooth
Yes
T300 Chi Mobile
Dock
3568A-T300CHIDOCK Bluetooth only N/A
ASUS Tablet and ASUS Mobile Dock E-Manual
103
DRAFT 9 12/19/2014
Déclaration d’Industrie Canada relative à
l’exposition aux ondes radio
Cet appareil est conforme aux limites d’exposition aux radiations d’Industrie
Canada dénies pour un environnement non-contrôlé. Pour maintenir la
conformité avec les exigences d’exposition RF d’IC, veuillez éviter tout contact
direct avec l’antenne pendant l’émission. Les utilisateurs naux doivent suivre
les instructions de fonctionnement spéciques pour satisfaire la conformité aux
expositions RF.
Son utilisation est sujette aux deux conditions suivantes :
• Cetappareilnepeutpascauserd’interférence,et
• Cetappareildoitacceptertouteinterférence,ycomprislesinterférences
qui pourraient causer un fonctionnement non souhaité de l’appareil.
Pour éviter les interférences radio avec le service sous licence (c’est à-dire le
partage de canal avec les systèmes de téléphonie satellite), cet appareil est destiné
à être utilisé en intérieur et loin des fenêtres pour fournir un blindage maximal.
Tout appareil (ou son antenne d’émission) qui est installé en extérieur est sujet à
cette licence.
Le present appareil est conforme aux CNR d’Industrie Canada applicables aux
appareils radio exempts de licence.
CAN ICES-3(B)/NMB-3(B)
Cet appareil et son antenne ne doivent pas être situés ou fonctionner en
conjonction avec une autre antenne ou un autre émetteur, exception faites des
radios intégrées qui ont été testées.
MODEL NAME IC ID FUNCTION CONTAINS MODULE
T300 Chi 1000M-7265NG WLAN /
Bluetooth
Yes
T300 Chi Mobile
Dock
3568A-T300CHIDOCK Bluetooth only N/A
104
ASUS Tablet and ASUS Mobile Dock E-Manual
DRAFT 9 12/19/2014
Radiation Exposure Statement
The product comply with the Canada portable RF exposure limit set forth for an
uncontrolled environment and are safe for intended operation as described in this
manual. The further RF exposure reduction can be achieved if the product can be
kept as far as possible from the user body or set the device to lower output power
if such function is available.
Déclaration d'exposition aux radiations
Le produit est conforme aux limites d'exposition pour les appareils portables RF
pour les Etats-Unis et le Canada établies pour un environnement non contrôlé.
Le produit est sûr pour un fonctionnement tel que décrit dans ce manuel. La
réduction aux expositions RF peut être augmentée si l'appareil peut être conservé
aussi loin que possible du corps de l'utilisateur ou que le dispositif est réglé sur la
puissance de sortie la plus faible si une telle fonction est disponible.
Caution
(i) the device for operation in the band 5150-5250 MHz is only for indoor use
to reduce the potential for harmful interference to co-channel mobile satellite
systems;
(ii) the maximum antenna gain permitted for devices in the bands 5250-5350 MHz
and 5470-5725 MHz shall comply with the e.i.r.p. limit; and
(iii) the maximum antenna gain permitted for devices in the band 5725-5825 MHz
shall comply with the e.i.r.p. limits specied for point-to-point and non point-to-
point operation as appropriate.
(iv) Users should also be advised that high-power radars are allocated as primary
users (i.e. priority users) of the bands 5250-5350 MHz and 5650-5850 MHz and that
these radars could cause interference and/or damage to LE-LAN devices.
ASUS Tablet and ASUS Mobile Dock E-Manual
105
DRAFT 9 12/19/2014
Avertissement
Le guide d’utilisation des dispositifs pour réseaux locaux doit inclure des
instructions précises sur les restrictions susmentionnées, notamment :
(i) les dispositifs fonctionnant dans la bande 5 150-5 250 MHz sont réservés
uniquement pour une utilisation à l’intérieur an de réduire les risques de
brouillage préjudiciable aux systèmes de satellites mobiles utilisant les mêmes
canaux;
(ii) le gain maximal d’antenne permis pour les dispositifs utilisant les bandes 5
250-5 350 MHz et 5 470-5 725 MHz doit se conformer à la limite de p.i.r.e.;
(iii) le gain maximal d’antenne permis (pour les dispositifs utilisant la bande 5 725-
5 825 MHz) doit se conformer à la limite de p.i.r.e. spéciée pour l’exploitation
point à point et non point à point, selon le cas.
(iv) De plus, les utilisateurs devraient aussi être avisés que les utilisateurs de radars
de haute puissance sont désignés utilisateurs principaux (c.-à-d., qu’ils ont la
priorité) pour les bandes 5 250-5 350 MHz et 5 650-5 850 MHz et que ces radars
pourraient causer du brouillage et/ou des dommages aux dispositifs LAN-EL.
106
ASUS Tablet and ASUS Mobile Dock E-Manual
DRAFT 9 12/19/2014
France Restricted Wireless Frequency Bands
Some areas of France have a restricted frequency band. The worst case maximum
authorized power indoors are:
• 10mWfortheentire2.4GHzband(2400MHz–2483.5MHz)
• 100mWforfrequenciesbetween2446.5MHzand2483.5MHz
NOTE: Channels 10 through 13 inclusive operate in the band 2446.6 MHz to 2483.5
MHz.
There are few possibilities for outdoor use: on private property or on the private
property of public persons, use is subject to a preliminary authorization procedure
by the Ministry of Defense, with maximum authorized power of 100mW in the
2446.5–2483.5MHzband.Useoutdoorsonpublicpropertyisnotpermitted.
In the departments listed below, for the entire 2.4 GHz band:
• Maximumauthorizedpowerindoorsis100mW
• Maximumauthorizedpoweroutdoorsis10mW
Wireless Operation Channel for Dierent
Domains
N. America 2.412-2.462 GHz Ch01 through CH11
Japan 2.412-2.484 GHz Ch01 through Ch14
Europe ETSI 2.412-2.472 GHz Ch01 through Ch13
ASUS Tablet and ASUS Mobile Dock E-Manual
107
DRAFT 9 12/19/2014
Departmentsinwhichtheuseofthe2400–2483.5MHzbandispermittedwithan
EIRP of less than 100mW indoors and less than 10mW outdoors:
01 Ain 02 Aisne 03 Allier
05 Hautes Alpes 08 Ardennes 09 Ariège
11 Aude 12 Aveyron 16 Charente
24 Dordogne 25 Doubs 26 Drôme
32 Gers 36 Indre 37 Indre et Loire
41 Loir et Cher 45 Loiret 50 Manche
55 Meuse 58 Nièvre 59 Nord
60 Oise 61 Orne 63 Puy du Dôme
64 Pyrénées Atlantique 66 Pyrénées Orientales 67 Bas Rhin
68 Haut Rhin 70 Haute Saône 71 Saône et Loire
75 Paris 82 Tarn et Garonne 84 Vaucluse
88 Vosges 89 Yonne 90 Territoire de Belfort
94 Val de Marne
This requirement is likely to change over time, allowing you to use your wireless
LAN card in more areas within France. Please check with ART for the latest
information (www.arcep.fr)
NOTE: Your WLAN Card transmits less than 100mW, but more than 10mW.
108
ASUS Tablet and ASUS Mobile Dock E-Manual
DRAFT 9 12/19/2014
UL Safety Notices
Required for UL 1459 covering telecommunications (telephone) equipment
intended to be electrically connected to a telecommunication network that has an
operating voltage to ground that does not exceed 200V peak, 300V peak-to-peak,
and 105V rms, and installed or used in accordance with the National Electrical
Code (NFPA 70).
When using the ASUS Tablet modem, basic safety precautions should always be
followed to reduce the risk of re, electric shock, and injury to persons, including
the following:
• DONOTusetheASUSTabletnearwater,forexample,nearabathtub,wash
bowl, kitchen sink or laundry tub, in a wet basement or near a swimming
pool.
• DONOTusetheASUSTabletduringanelectricalstorm.Theremaybea
remote risk of electric shock from lightning.
• DONOTusetheASUSTabletinthevicinityofagasleak.
Required for UL 1642 covering primary (nonrechargeable) and secondary
(rechargeable) lithium batteries for use as power sources in products. These
batteries contain metallic lithium, or a lithium alloy, or a lithium ion, and may
consist of a single electrochemical cell or two or more cells connected in series,
parallel, or both, that convert chemical energy into electrical energy by an
irreversible or reversible chemical reaction.
• DonotdisposetheASUSTabletbatterypackinare,astheymayexplode.
Check with local codes for possible special disposal instructions to reduce
the risk of injury to persons due to re or explosion.
• Donotusepoweradaptersorbatteriesfromotherdevicestoreducethe
risk of injury to persons due to re or explosion. Use only UL certied
power adapters or batteries supplied by the manufacturer or authorized
retailers.
ASUS Tablet and ASUS Mobile Dock E-Manual
109
DRAFT 9 12/19/2014
Power Safety Requirement
Products with electrical current ratings up to 6A and weighing more than 3Kg
must use approved power cords greater than or equal to: H05VV-F, 3G, 0.75mm
2
or
H05VV-F, 2G, 0.75mm
2
.
TV Notices
Note to CATV System Installer—Cable distribution system should be grounded
(earthed) in accordance with ANSI/NFPA 70, the National Electrical Code (NEC),
in particular Section 820.93, Grounding of Outer Conductive Shield of a Coaxial
Cable–installationshouldincludebondingthescreenofthecoaxialcabletothe
earth at the building entrance.
REACH
Complying with the REACH (Registration, Evaluation, Authorization, and
Restriction of Chemicals) regulatory framework, we publish the chemical
substances in our products at ASUS REACH website at http://csr.asus.com/english/
REACH.htm.
Macrovision Corporation Product Notice
This product incorporates copyright protection technology that is protected by
method claims of certain U.S.A. patents and other intellectual property rights
owned by Macrovision Corporation and other rights owners. Use of this copyright
protection technology must be authorized by Macrovision Corporation, and
is intended for home and other limited viewing uses only
unless otherwise
authorized by Macrovision Corporation
. Reverse engineering or disassembly is
prohibited.
110
ASUS Tablet and ASUS Mobile Dock E-Manual
DRAFT 9 12/19/2014
Nordic Lithium Cautions (for lithium-ion
batteries)
CAUTION! Danger of explosion if battery is incorrectly replaced. Replace only with
the same or equivalent type recommended by the manufacturer. Dispose of used
batteries according to the manufacturer’s instructions. (English)
ATTENZIONE! Rischio di esplosione della batteria se sostituita in modo errato.
Sostituire la batteria con un una di tipo uguale o equivalente consigliata dalla
fabbrica. Non disperdere le batterie nell’ambiente. (Italian)
VORSICHT! Explosionsgefahr bei unsachgemäßen Austausch der Batterie. Ersatz
nur durch denselben oder einem vom Hersteller empfohlenem ähnlichen Typ.
Entsorgung gebrauchter Batterien nach Angaben des Herstellers. (German)
ADVARSELI! Lithiumbatteri - Eksplosionsfare ved fejlagtig håndtering. Udskiftning
må kun ske med batteri af samme fabrikat og type. Levér det brugte batteri
tilbage til leverandøren. (Danish)
VARNING! Explosionsfara vid felaktigt batteribyte. Använd samma batterityp eller
en ekvivalent typ som rekommenderas av apparattillverkaren. Kassera använt
batteri enligt fabrikantens instruktion. (Swedish)
VAROITUS! Paristo voi räjähtää, jos se on virheellisesti asennettu. Vaihda paristo
ainoastaan laitevalmistajan sousittelemaan tyyppiin. Hävitä käytetty paristo
valmistagan ohjeiden mukaisesti. (Finnish)
ATTENTION! Il y a danger d’explosion s’il y a remplacement incorrect de la
batterie. Remplacer uniquement avec une batterie du mêre type ou d’un type
équivalent recommandé par le constructeur. Mettre au rebut les batteries usagées
conformément aux instructions du fabricant. (French)
ADVARSEL! Eksplosjonsfare ved feilaktig skifte av batteri. Benytt samme
batteritype eller en tilsvarende type anbefalt av apparatfabrikanten. Brukte
batterier kasseres i henhold til fabrikantens instruksjoner. (Norwegian)
(Japanese)
ВНИМАНИЕ! При замене аккумулятора на аккумулятор иного типа возможно
его возгорание. Утилизируйте аккумулятор в соответствии с инструкциями
производителя. (Russian)
ASUS Tablet and ASUS Mobile Dock E-Manual
111
DRAFT 9 12/19/2014
CD-ROM Drive Safety Warning
CLASS 1 LASER PRODUCT
Optical Drive Safety Information
Laser Safety Information
WARNING! To prevent exposure to the optical drive’s laser, do not attempt to
disassemble or repair the optical drive by yourself. For your safety, contact a
professional technician for assistance.
Service warning label
WARNING! INVISIBLE LASER RADIATION WHEN OPEN. DO NOT STARE INTO BEAM OR
VIEW DIRECTLY WITH OPTICAL INSTRUMENTS.
CDRH Regulations
The Center for Devices and Radiological Health (CDRH) of the U.S. Food and Drug
Administration implemented regulations for laser products on August 2, 1976.
These regulations apply to laser products manufactured from August 1, 1976.
Compliance is mandatory for products marketed in the United States.
WARNING! Use of controls or adjustments or performance of procedures other
than those specied herein or in the laser product installation guide may result in
hazardous radiation exposure.
Coating Notice
IMPORTANT! To provide electrical insulation and maintain electrical safety, a
coating is applied to insulate the device except on the areas where the I/O ports
are located.
112
ASUS Tablet and ASUS Mobile Dock E-Manual
DRAFT 9 12/19/2014
CTR 21 Approval (for ASUS Tablet and ASUS
Mobile Dock with built-in modem)
Danish
Dutch
English
Finnish
French
ASUS Tablet and ASUS Mobile Dock E-Manual
113
DRAFT 9 12/19/2014
German
Greek
Italian
Portuguese
Spanish
Swedish
114
ASUS Tablet and ASUS Mobile Dock E-Manual
DRAFT 9 12/19/2014
ENERGY STAR complied product
ENERGY STAR is a joint program of the U.S. Environmental
Protection Agency and the U.S. Department of Energy helping us all
save money and protect the environment through energy ecient
products and practices.
All ASUS products with the ENERGY STAR logo comply with the ENERGY STAR
standard, and the power management feature is enabled by default. The monitor
and computer are automatically set to sleep within 10 and 30 minutes of user
inactivity. Users could wake your computer through click the mouse, press any key
on the keyboard, or press the power button.Please visit http://www.energy.gov/
powermanagement for detail information on power management and its benets
to the environment. In addition, please visit http://www.energystar.gov for detail
information on the ENERGY STAR joint program.
NOTE: Energy Star is NOT supported on FreeDOS and Linux-based operating systems.
European Union Eco-label
This ASUS Tablet and ASUS Mobile Dock has been awarded the EU Flower label,
which means that this product has the following characteristics:
1. Decreased energy consumption during use and stand-by modes.
2. Limited use of toxic heavy metals.
3. Limited use of substances harmful to the environment and health.
4. Reduction of the use of natural resources by encouraging recycling.
5. Designed for easy upgrades and longer lifetime through providing
compatible spare parts such as batteries, power supplies, the keyboard, the
memory, and if available the CD drive or DVD drive.
6. Reduced solid waste through takeback policy.
For more information on the EU Flower label, please visit the European Union Eco-
label website at http://www.ecolabel.eu.
ASUS Tablet and ASUS Mobile Dock E-Manual
115
DRAFT 9 12/19/2014
Global Environmental Regulation Compliance
and Declaration
ASUS follows the green design concept to design and manufacture our products,
and makes sure that each stage of the product life cycle of ASUS product is in line
with global environmental regulations. In addition, ASUS disclose the relevant
information based on regulation requirements.
Please refer to http://csr.asus.com/english/Compliance.htm for information
disclosure based on regulation requirements ASUS is complied with:
Japan JIS-C-0950 Material Declarations
EU REACH SVHC
Korea RoHS
Swiss Energy Laws
ASUS Recycling/Takeback Services
ASUS recycling and takeback programs come from our commitment to the
highest standards for protecting our environment. We believe in providing
solutions for you to be able to responsibly recycle our products, batteries, other
components as well as the packaging materials. Please go to http://csr.asus.com/
english/Takeback.htm for detailed recycling information in dierent regions.
Prevention of Hearing Loss
To prevent possible hearing damage, do not listen at high volume
levels for long periods.
While user turns up the volume past this point (27mV), the system will show a
pop-up with the following information: High volume can cause hearing loss. Your
ears are important. Turning up the voume past this point can cause permanent
hearing damage.
116
ASUS Tablet and ASUS Mobile Dock E-Manual
DRAFT 9 12/19/2014
For US and Canada customers, you can call 1-800-822-8837
(toll-free) for recycling information of your ASUS products’
rechargeable batteries.
Rechargeable Battery Recycling Service in
North America
Regional notice for India
This product complies with the “India E-waste (Management and Handling)Rule
2011” and prohibits use of lead, mercury, hexavalent chromium, polybrominated
biphenyls(PBBs) and polybrominated diphenyl ethers (PBDEs) in concentrations
exceeding 0.1 % by weight in homogenous materials and 0.01 % by weight
in homogenous materials for cadmium, except for the exemptions listed in
Schedule-II of the Rule.
Notices for removeable batteries
• Riskofexplosionifbatteryisreplacedbyanincorrecttype.
• Thebatteryanditscomponentmustberecycledordisposedofproperly.
Avis concernant les batteries remplaçables
• Labatteriedel’ordinateurportablepeutprésenterunrisqued’incendieou
de brûlure si celle-ci est retirée ou désassemblée.
• Labatterieetsescomposantsdoiventêtrerecyclésdefaçonappropriée.
Regional notice for California
This product contains chemicals, including lead, known to the State of California
to cause birth defects or other reproductive harm. Wash hands after handling.
ASUS Tablet and ASUS Mobile Dock E-Manual
117
DRAFT 9 12/19/2014
Regional notice for Singapore
This ASUS product complies with IDA Standards.
Complies with
IDA Standards
DB103778
Japan Technical Conformity Mark
The internal wireless module of this ASUS Tablet and ASUS Mobile Dock
has been certied by Japan Telec.
National Telecommunications Commission of the
Philippines
This ASUS product complies with NTC Standards.
for T300 Chi:
This device have been tested to comply with the Sound Pressure Level
requirement laid down in the applicable EN 50332-1 and/or EN 50332-2 standards.
Permanent hearing loss may occur if earphones or headphones are used at high
volume for prolonged periods of time.
003-140018
D140017003
ASUS Tablet ASUS Mobile Dock
XXXXX

Navigation menu
