ASUSTeK Computer VAC105 PORTABLE WIRELESS ACCESS POINT User Manual VUDU Wireless Kit02 1 indd
ASUSTeK Computer Inc PORTABLE WIRELESS ACCESS POINT VUDU Wireless Kit02 1 indd
USERS MANUAL
Wireless Kit
Designed exclusively for use with the VUDU product.
©2008 VUDU, Inc. All Rights Reserved.
Start Here
VUDU_Wireless_Kit02.1.indd 1 3/12/08 11:24:24 AM
FCC Warning Statement
This device complies with Par 15 of the FCC Rules Operation is subject to
the following 2 conditions:
1) this device may not cause harmful interference and
2) this device must accept any interference, including interference that
may cause undesired operation.
This device has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC rules. These limits
are design to provide reasonable protection against harmful interference in
a residential installation.
This equipment generates, uses an can radiate radio frequency energy
and, if not installed and used in accordance with the installation instruc-
tions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined bu turning the equipment
off and on, the user is encouraged to try to correct the interference by one
of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the outlet into an outlet on a circuit different from that to which
the receiver is connected
- Consult the dealer or an experienced radio/TV technician for help
CAUTION: Any changes or modifications not expressly approved by the
party responsible for compliance could void the user’s authority to operate
the equipment.
Prohibition of Co-Location
This device and its antenna(s) must not be co-located or used in conjunc-
tion with any other antenna or transmitter.
Safety Information
To maintain compliance with FCC’s RF exposure guidelines, this equip-
ment should be installed and operated with a minimum of 20 cm between
the radiator and your body. Use only the supplied antenna.
VUDU_Wireless_Kit02.1.indd 2 3/12/08 11:24:24 AM
What’s Included
(2) Ethernet network cables
(1) USB to DC cable
(2) AC to DC power cables
Wireless adapter
Wireless adapter
VUDU_Wireless_Kit02.1.indd 3 3/12/08 11:24:25 AM
Locate the provided 5-foot Ethernet cable. Connect one
end to the wireless adapter marked
Connect the other end to your home network router or
modem.
.
1.
VUDU_Wireless_Kit02.1.indd 4 3/12/08 11:24:25 AM
.
Locate the provided power adapter plug. Insert one
end into the DC-IN socket of
Plug the other end into a wall outlet.
2.
VUDU_Wireless_Kit02.1.indd 5 3/12/08 11:24:26 AM
LED LIGHTS
The LED indicators for Power and Ethernet on
will light up.
3.
VUDU_Wireless_Kit02.1.indd 6 3/12/08 11:24:26 AM
Locate the provided 10-foot Ethernet cable. Connect one
end to the wireless adapter marked
Connect the other end to your VUDU box.
1.
VUDU_Wireless_Kit02.1.indd 7 3/12/08 11:24:26 AM
Locate the provided USB power cord. Insert one
end into the DC-IN socket of
Affix the other end to one of the USB ports on the
VUDU box—on the back or left side.
2.
VUDU_Wireless_Kit02.1.indd 8 3/12/08 11:24:26 AM
LED LIGHTS
The LED indicators for Power and Ethernet on
will light up.
3.
The LED indicators for Power and Ethernet on
will light up and, after a few seconds, the LED indicator for
Wireless will start blinking. The wireless adapters have been set
up successfully.
Going forward, when the LED indicators for Wireless and/or
Ethernet start to blink, data is being transmitted.
Should you have any questions or problems, please refer to the
Wireless Kit Instructions at www.vudu.com/vudu_documenta-
tion.html or call Customer Care at 1-888-554-8838 (VUDU).
VUDU_Wireless_Kit02.1.indd 9 3/12/08 11:24:27 AM
