ASUSTeK Computer WL330NUL All-in-One Wireless-N pocket router User Manual E7564 WL 330NNUL QSG 1224
ASUSTeK Computer Inc All-in-One Wireless-N pocket router E7564 WL 330NNUL QSG 1224
User Manual
®
Quick Start Guide
WL-330NUL
All-in-One Wireless-N Pocket Router
(For 802.11g/b/n Wireless Networks)
全方位隨身分享器
2
E7564 / First Edition / December 2012
English ............................................................................................................. 3
繁體中文
.......................................................................................................12
簡體中文 ........................................................................................................21
Bahasa Indonesia .........................................................................................30
Bahasa Malaysia ...........................................................................................39
ไทย
.................................................................................................................. 48
Türkçe ..............................................................................................................57
3
• Use WL-330NUL as a portable router
English
In circumstances of weak wireless signal or Ethernet network alone, such as in a
hotel, conference room or oce, follow the steps below to access the Internet
through WL-330NUL.
Supervisor code: xxxxxxxx
1. Connect the Ethernet cable to WL-330NUL and
plug it into a power outlet.
2. When the LED indicator stops blinking and
turns into a solid light in about 30 seconds, it
indicates that WL-330NUL has nished booting
up.
3. Select WL-330NUL’s private network name. The
default network name is WL-330NUL-private-
xxxx (xxxx is the last four numbers of
WL-330NUL’s MAC address).
4. Enter the private network password, which
you can nd on your WL-330NUL labeled as
supervisor code.
Internet
Supervisor code: xxxxxxxx
Supervisor code: xxxxxxxx
5. Launch your web browse.
MAC address
4
English
1. Insert WL-330NUL into the device’s
USB port.
A. Utility installation
• For Windows® users
If your device is running on Windows® operating system,
ensure that you have
installed the WL-330NUL Utility before connecting to the Internet.
2. Click Start > Computer or click the
computer icon on the desktop.
3. Click the WL-330NUL icon in Device
with Removable Storage.4. Double-click Setup.exe to install the
WL-330NUL utility.
5
English
B. Internet connection
Mode 1
Connect an Ethernet cable to WL-
330NUL and plug to a power source
Mode 2
Connect WL-330NUL to a computer
via an Ethernet cable
Internet
Internet
Select one of the following ways to access the Internet:
1. Connect to the WL-330NUL
private network name.
2. Enter the private network
password.
3. Launch your web browser and
start surng the Internet.
1. Launch your browser and start
surng the Internet.
To congure the router settings,
please launch the WL-330NUL
utility.
Mode 3
Plug WL-330NUL to a power source
Mode 4
Connect WL-330NUL to a computer
Internet
1. Connect to the WL-330NUL
private network name.
2. Enter the private network
password.
3. Use the WL-330NUL utility to
select a Wi-Fi network (SSID) and
connect to the Internet.
1. Select a Wi-Fi network (SSID)
through the Utility and connect
to the Internet.
Internet
6
C. One-click sharing
To share Internet access:
1. Let the guest client connect
to Wi-Fi network (SSID): WL-
330NUL-Guest-xxxx (xxxx is the
last four numbers of WL-330NUL’s
MAC address).
2. Launch the web browser.
3. Follow the onscreen instructions.
Ensure to launch the utility before using the Guest Access function.
Send a request
Approve
English
Internet
To access the Internet wirelessly:
1. Connect to the WL-330NUL private network
name.
2. Enter your private network password.
3. Go to http://www.asusnetwork.net.
4. Enter the supervisor code shown on the sur-
face of WL-330NUL.
5. Open the Wireless Setting page.
6. Select a Wi-Fi network (SSID) and connect to the Internet.
7. Launch the web browser and start surng the Internet.
•
For tablet PC and smartphone users
To access the Internet via an Ethernet
cable :
1. Connect to the
WL-330NUL private network
name.
2. Enter the private network password.
3. Launch the web browser and start surng the
Internet.
Internet
7
Mode 2
Connect WL-330NUL to a computer
via an Ethernet cable
Internet
1. Launch your browser and start
surng the Internet.
Mode 3
Plug WL-330NUL to a power source
Mode 4
Connect WL-330NUL to a computer
Internet
Internet
Follow the steps in To access the
Internet wirelessly in section For
tablet PC and smartphone users.
1. Go to
http://www.asusnetwork.net.
2. Enter the supervisor code shown
on the surface of WL-330NUL.
3. Open the Wireless Setting
page.
4. Select a Wi-Fi network (SSID) and
connect to the Internet.
•
For MAC OS X users
Select one of the ways to access the Internet:
Mode 1
Connect an Ethernet cable to WL-
330NUL and plug to a power source
Internet
Follow the steps in To access the
Internet via Ethernet in section For
tablet PC and smartphone users.
English
8
English
Warning: Any changes or modifications not expressly approved by the party
responsible for compliance could void the userʼs authority to operate the
equipment.Prohibition of Co-locationThis device and its antenna(s) must not be
co-located or operating in conjunction with any other antenna or transmitter.
Prohibition of Co-location
This device and its antenna(s) must not be co-located or operating in conjunction with any
other antenna or transmitter.
IMPORTANT NOTE:
Radiation Exposure Statement: This equipment complies with FCC radiation exposure
limits set forth for an uncontrolled environment. End users must follow the specific operating
instructions for satisfying RF exposure compliance. To maintain compliance with FCC exposure
compliance requirement, please follow operation instruction as documented in this manual.
Declaration of Conformity for R&TTE directive 1999/5/EC
Essential requirements – Article 3
Protection requirements for health and safety – Article 3.1a
Testing for electric safety according to EN 60950-1 has been conducted. These are considered
relevant and sufficient.
Protection requirements for electromagnetic compatibility – Article 3.1b
Federal Communications Commission Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
• This device may not cause harmful interference.
• This device must accept any interference received, including interference that may cause
undesired operation.
This equipment has been tested and found to comply with the limits for a class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV technician for help.
9
English
Testing for electromagnetic compatibility according to EN 301 489-1 and EN 301 489-17 has
been conducted. These are considered relevant and sufficient.
Effective use of the radio spectrum – Article 3.2
Testing for radio test suites according to EN 300 328- 2 has been conducted. These are
considered relevant and sufficient.
FCC/CE Mark Warning
This is a Class B product, in a domestic environment, this product may cause radio
interference, in which case the user may be required to take adequate measures.Operation
Channels: CH1~11 for N. America; Ch1~14 for Japan; CH1~13 for Europe (ETSI)
Canada, Industry Canada (IC) Notices
This Class B digital apparatus complies with Canadian ICES-003 and RSS-210.
Operation is subject to the following two conditions: (1) this device may not cause interference,
and (2) This device must accept any interference, including interference that may cause
undesired operation of the device.
Radio Frequency (RF) Exposure Information
The radiated output power of the ASUS Wireless Device is below the Industry Canada (IC)
radio frequency exposure limits. The ASUS Wireless Device should be used in such a manner
such that the potential for human contact during normal operation is minimized.
This device has been certified for use in Canada. Status of the listing in the Industry Canadaʼ
s REL (Radio Equipment List) can be found at the following web address: http://www.ic.gc.
ca/app/sitt/reltel/srch/nwRdSrch.do?lang=eng
Additional Canadian information on RF exposure also can be found at the following web
address: http://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf08792.html
Canada, avis dʼIndustry Canada (IC)
Cet appareil numérique de classe B est conforme aux normes canadiennes ICES-003 et
RSS-210.
Son fonctionnement est soumis aux deux conditions suivantes : (1) cet appareil ne doit pas
causer dʼinterférence et (2) cet appareil doit accepter toute interférence, notamment les
interférences qui peuvent affecter son fonctionnement.
Informations concernant lʼexposition aux fréquences radio (RF)
La puissance de sortie émise par lʼappareil de sans fil ASUS est inférieure à la limite dʼ
exposition aux fréquences radio dʼIndustry Canada (IC). Utilisez lʼappareil de sans fil ASUS de
façon à minimiser les contacts humains lors du fonctionnement normal.
10
English
REACH
Complying with the REACH (Registration, Evaluation, Authorisation, and Restriction of Chemicals)
regulatory framework, we published the chemical substances in our products at ASUS REACH
website at http://csr.asus.com/english/REACH.htm
Ce périphérique est homologué pour lʼutilisation au Canada. Pour consulter lʼ
entrée correspondant à lʼappareil dans la liste dʼéquipement radio (REL - Radio
Equipment List) dʼIndustry Canada rendez-vous sur: http://www.ic.gc.ca/app/sitt/
reltel/srch/nwRdSrch.do?lang=eng
Pour des informations supplémentaires concernant lʼexposition aux RF au Canada
rendez-vous sur : http://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf08792.html
Industry Canada Statement
This device complies with RSS-210 of the industry Canada Rules. Operation is subject to the
following two conditions:
• This device may not cause harmful interference.
• This device must accept any interference received, including interference that may cause
undesired operation.
IMPORTANT NOTE:
Radiation Exposure Statement: This equipment complies with IC radiation exposure limits set
forth for an uncontrolled environment. End users must follow the specific operating instructions
for satisfying RF exposure compliance. To maintain compliance with IC RF exposure
compliance requirement, please follow operation instruction as documented in this manual.
NCC 警語
經型式認證合格之低功率射頻電機，非經許可，公司、商號或使用者均不得擅自變更頻率、
加大功率或變更原設計之特性及功能。低功率射頻電機之使用不得影響飛航安全及干擾合
法通信；經發現有干擾現象時，應立即停用，並改善至無干擾時方得繼續使用。
前項合法通信，指依電信法規定作業之無線電通信。低功率射頻電機須忍受合法通信或工
業、科學及醫療用電波輻射性電機設備之干擾。
11
Networks Global Hotline Information
Area Hotline Number Support
Languages
Availability
Australia1300-2787-88 English Mon. to Fri.
8:00-20:00
Austria0043-820240513 German Mon. to Fri.
9:00-18:00
Belgium 0032-78150231 Dutch /French Mon. to Fri.
9:00-17:00
China 400-620-6655 Simplified Chinese Mon. to Sun.
9:00-18:00
Denmark 0045-3832-2943 Danish/English Mon. to Fri.
9:00-17:00
Finland 00358-9693-7969 Finnish/English/
Swedish
Mon. to Fri.
10:00-18:00
France 0033-170949400 French Mon. to Fri.
9:00-17:45
Greece 00800-44-14-20-44 Mon. to Fri.
9:00-13:00
14:00-18:00
Hong Kong 3582-4770 Cantonese/
Chinese/English
Mon. to Fri.
10:00-20:00
Sat.
10:00-17:00
Indonesia0062-2129495000 Bahasa IndonesiaMon. to Fri
9:30 - 18: 00
500128 (Local Only) Sat.
9:30 - 12:00
Ireland 0035-31890719918 English Mon. to Fri.
9:00-17:00
Italy 199-400089 Italian Mon. to Fri.
9:00-13:00
14:00-18:00
12
Networks Global Hotline Information
Japan 0800-123-2787 Japanese Mon. to Fri.
9:00-18:00
Sat. to Sun.
9:00-17:00
Malaysia+603 2148 0827 (Check
Repair Detail Status
Only)/ +603-6279-5077
Bahasa Melayu/
English
Mon. to Fri.
10:00-19:00
Netherlands
/ Luxembourg 0031-591-570290 Dutch / English Mon. to Fri.
9:00-17:00
New Zealand 0800-278-788/
0800-278-778 English Mon. to Fri.
9:00-17:00
Norway 0047-2316-2682 Norwegian
/English
Mon. to Fri.
9:00-17:00
Philippines +632-636 8504/
180014410573 English Mon. to Fri.
9:00-18:00
Poland 00225-718-033/
00225-718-040 Polish Mon. to Fri.
9:00-17:00
8:30-17:30
Portugal 707-500-310 Portuguese Mon. to Fri.
9:00-17:00
Russia+8-800-100-ASUS/
+7-495-231-1999 Russian/
English
Mon. to Fri.
9:00-18:00
Singapore +65-6720-3835
(Check Repair
Detail Status Only)/
+65-66221701
English Mon. to Fri.
11:00-19:00
Slovak 00421-232-162-621 Czech Mon. to Fri.
8:00-17:00
Spain902-88-96-88 Spanish Mon. to Fri.
9:00-18:00
Sweden0046-8587-6940 Swedish/
English
Mon. to Fri.
9:00-17:00
13
MANUFACTURER
ASUSTeK Computer Inc.
Tel: +886-2-2894-3447
Address: 4F, No. 150, LI-TE RD., PEITOU, TAIPEI 112, TAIWAN
AUTHORISED REPRESENTATIVE IN EUROPE
ASUS Computer GmbH
Address: HARKORT STR. 21-23, 40880 RATINGEN, GERMANY
AUTHORISED DISTRIBUTORS IN TURKEY
BOGAZICI BIL GISAYAR SAN. VE TIC. A.S.
Tel: +90 212 3311000
Address: AYAZAGA MAH. KEMERBURGAZ CAD. NO.10 AYAZAGA/ISTANBUL
CIZGI Elektronik San. Tic. Ltd. Sti.
Tel: +90 212 3567070
Address: CEMAL SURURI CD. HALIM MERIC IS MERKEZI
No: 15/C D:5-6 34394 MECIDIYEKOY/ ISTANBUL
Networks Global Hotline Information
Switzerland0041-848111010 German/French Mon. to Fri.
9:00-18:00
0041-848111014 French Mon. to Fri.
9:00-17:45
0041-848111012 Italian Mon. to Fri.
9:00-17:00
Taiwan 0800-093-456/
02-81439000 Traditional Chinese Mon. to Fri.
9:00-12:00
13:30-18:00
Thailand +662-679-8367 -70/
001 800 852 5201 Thai/English Mon. to Fri.
9:00-18:00
Turkey +90-216-524-3000 Turkish Mon. to Fri.
09:00-18:00
United
Kingdom 0044-870-1208340/
0035-31890719918 English Mon. to Fri.
9:00-17:00
USA/Canada1-812-282-2787 English Mon. to Fri.
8:30am-12:00am EST
(5:30am-9:00pm PST)
Sat .to Sun.
9:00am-6:00pm EST
(6:00am-3:00pm PST)
EEE Yönetmeliğine Uygundur.
