First Edition/ November 2016
Model: ASUS_Z01HD (ZE553KL)
ASUS_Z01HDA (ZE553KL)
Before you start, ensure that you have read all the
safety information and operating instructions in this
User Guide to prevent injury or damage to your
device.
NOTE: For the latest updates and more detailed
information, please visit www.asus.com.
Front features
Touch screen
display
Receiver
LED indicator
Touch keys
Proximity sensor and light sensor
Front camera
E12130_ZE553KL_Booklet_EU_UM.indd 2 2016/11/28 17:23:35
Side features
Power Key
Audio jack
USB Type-C port
Microphone
Volume Key
Nano SIM1, Nano
SIM2 / MicroSD
combo card slot
Speaker
NOTE: The USB Type-C port supports USB2.0
transfer rate.
Microphone
E12130_ZE553KL_Booklet_EU_UM.indd 3 2016/11/28 17:23:36
Rear features
Rear cameras
Camera flash
Rear cover
Laser focus
Finger print
sensor
RGB sensor
E12130_ZE553KL_Booklet_EU_UM.indd 4 2016/11/28 17:23:36
Rear features
Charging your ASUS Phone
To charge your ASUS Phone:
1. Connect the USB connector into the power
adapter’s USB port.
2. Connect the other end of the USB Type C
cable to your ASUS Phone.
3. Plug the power adapter into a wall socket.
NOTES:
• Forsafetypurposes,useONLY the bundled
power adapter and cable to avoid damaging
your device and prevent the risk of injury.
• Forsafetypurposes,useONLY the bundled
power adapter and cable to charge your
ASUS Phone.
• Theinputvoltagerangebetweenthewall
outlet and this adapter is AC 100V - 240V.
The output voltage of the Type C cable is
+5V 2A, 10W.
IMPORTANT!
• WhenusingyourASUSPhonewhileitis
plugged to a power outlet, the grounded
power outlet must be near to the unit and
easily accessible.
• WhenchargingyourASUSPhonethrough
your computer, ensure that you plug the USB
Type C cable to your computer’s USB 2.0 /
USB 3.0 port.
• AvoidchargingyourASUSPhoneinan
environment with ambient temperature of
above 35oC (95oF).
2
3
1
E12130_ZE553KL_Booklet_EU_UM.indd 5 2016/11/28 17:23:36
1. Push a pin into the hole on
the Nano SIM / MicroSD
card tray to eject it.
Installing a Nano SIM / MicroSD card
To install a Nano SIM / MicroSD card:
2. Insert the Nano SIM / MicroSD card(s) into the
card slot(s).
3. Push the tray to close it.
IMPORTANT: You can only use the Nano SIM2
card or the MicroSD card at a time.
Nano-SIM2
Nano-SIM1
Nano-SIM1
Micro SD
E12130_ZE553KL_Booklet_EU_UM.indd 6 2016/11/28 17:23:36
NOTES:
• TheNanoSIMcardslotssupportLTE,
WCDMA and GSM/EDGE network bands.
• TheMicroSDcardslotsupportsMicroSDand
MicroSDHC card formats.
CAUTION!
• Donotusesharptoolsorsolventonyour
device to avoid scratches on it.
• UseonlyastandardNanoSIMcardonyour
ASUS Phone.
IMPORTANT: Both Nano SIM card slots support
3G WCDMA/ 4G LTE network band. But only one
SIM card can connect to 4G LTE service at a time.
Charging other devices
Use your ASUS Phone to power-charge other
mobile devices.
E12130_ZE553KL_Booklet_EU_UM.indd 7 2016/11/28 17:23:36
Federal Communications
Commission Statement
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference,
and (2) this device must accept any interference
received, including interference that may cause
undesired operation.
Changesormodicationsnotexpresslyapprovedby
the party responsible for compliance could void the
user‘s authority to operate the equipment.
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant
to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against
harmful interference in a residential installation. This
equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However,
there is no guarantee that interference will not occur
in a particular installation. If this equipment does
cause harmful interference to radio or television
reception, which can be determined by turning the
equipment off and on, the user is encouraged to
try to correct the interference by one or more of the
following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment
and receiver.
- Connect the equipment into an outlet on a
circuit different from that to which the receiver is
connected.
- Consultthedealeroranexperiencedradio/TV
technician for help.
The antenna(s) used for this transmitter must not be
co-located or operating in conjunction with any other
antenna or transmitter.
E12130_ZE553KL_Booklet_EU_UM.indd 8 2016/11/28 17:23:36
The country code selection is for non-US model
only and is not available to all US model. Per FCC
regulation, all WiFi product marketed in US must
xedtoUSoperationchannelsonly.
Canada, Industry Canada (IC)
Notices
This device complies with Industry Canada’s
licence-exemptRSSstandard(s).Operationis
subject to the following two conditions:
(1) This device may not cause interference; and
(2) This device must accept any interference,
including interference that may cause
undesired operation of the device.
LeprésentappareilestconformeauxCNR
d’IndustrieCanadaapplicablesauxappareilsradio
exemptsdelicence.L’exploitationestautoriséeaux
deuxconditionssuivantes:
(1) l’appareil ne doit pas produire de brouillage, et
(2) l’utilisateur de l’appareil doit accepter tout
brouillage radioélectrique subi, même si le
brouillage est susceptible d’en compromettre le
fonctionnement.
Radio Frequency (RF) Exposure Information
The radiated output power of the Wireless Device
is below the Industry Canada (IC) radio frequency
exposurelimits.TheWirelessDeviceshouldbe
used in such a manner such that the potential
for human contact during normal operation is
minimized. This device has been evaluated for and
showncompliantwiththeICSpecicAbsorption
Rate(“SAR”)limitswheninstalledinspecichost
productsoperatedinportableexposureconditions.
Canada’s REL (Radio Equipment List) can be found
at the following web address: http://www.ic.gc.ca/
app/sitt/reltel/srch/nwRdSrch.do?lang=eng
AdditionalCanadianinformationonRFexposure
also can be found at the following web address:
E12130_ZE553KL_Booklet_EU_UM.indd 9 2016/11/28 17:23:36
http://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf08792.
html
Informations concernant l’exposition aux
fréquences radio (RF)
La puissance de sortie émise par cet appareil
sanslestinférieureàlalimited’expositionaux
fréquences radio d’Industrie Canada (IC). Utilisez
l’appareilsansldefaçonàminimiserlescontacts
humains lors du fonctionnement normal.
Ce périphérique a été évalué et démontré conforme
auxlimitesSAR(SpecicAbsorptionRate–Taux
d’absorptionspécique)d’IClorsqu’ilestinstallé
dans des produits hôtes particuliers qui fonctionnent
dansdesconditionsd’expositionàdesappareils
portables.
Ce périphérique est homologué pour l’utilisation
au Canada. Pour consulter l’entrée correspondant
àl’appareildanslalisted’équipementradio(REL
- Radio Equipment List) d’Industrie Canada rendez-
vous sur:
http://www.ic.gc.ca/app/sitt/reltel/srch/nwRdSrch.
do?lang=eng
Pour des informations supplémentaires concernant
l’expositionauxRFauCanadarendez-voussur:
http://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf08792.
html
CAN ICES-3(B)/NMB-3(B)
This Class B digital apparatus complies with
Canadian ICES-003.
Cet appareil numérique de la classe B est conforme
àlanormeNMB-003duCanada.
This device and its antenna(s) must not be co-
located or operating in conjunction with any other
antennaortransmitter,excepttestedbuilt-inradios.
The County Code Selection feature is disabled for
products marketed in the US/ Canada.
Cet appareil et son antenne ne doivent pas être
situés ou fonctionner en conjonction avec une autre
E12130_ZE553KL_Booklet_EU_UM.indd 10 2016/11/28 17:23:36
antenneouunautreémetteur,exceptionfaitesdes
radios intégrées qui ont été testées.
La fonction de sélection de l’indicatif du pays est
désactivéepourlesproduitscommercialisésaux
États-Unis et au Canada.
The IC ID for this device is 3568A-Z01HD.
L’identiantIndustrieCanadadecetappareilest:
3568A-Z01HD.
RF Exposure Information (SAR)
This device has been tested and meets applicable
limitsforRadioFrequency(RF)exposure.
SpecicAbsorptionRate(SAR)referstotherateat
which the body absorbs RF energy. SAR limits are
1.6 Watts per kilogram (over a volume containing
a mass of 1 gram of tissue) in countries that follow
the United States FCC limit and 2.0 W/kg (averaged
over 10 grams of tissue) in countries that follow the
Council of the European Union limit. Tests for SAR
are conducted using standard operating positions
withthedevicetransmittingatitshighestcertied
power level in all tested frequency bands.
ToreduceexposuretoRFenergy,useahands-free
accessory or other similar option to keep this device
away from your head and body. Carry this device
at least 10 mm away from your body to ensure
exposurelevelsremainatorbelowtheas-tested
levels. Choose the belt clips, holsters, or other
similar body-worn accessories which do not contain
metallic components to support operation in this
manner. Cases with metal parts may change the RF
performance of the device, including its compliance
withRFexposureguidelines,inamannerthat
hasnotbeentestedorcertied,andusesuch
accessories should be avoided.
The highest FCC SAR value for the device is:
• 1.16W/Kg@1g(forASUS_Z01HD)
E12130_ZE553KL_Booklet_EU_UM.indd 11 2016/11/28 17:23:36
The FCC has granted an Equipment Authorization
for this device with all reported SAR levels evaluated
asincompliancewiththeFCCRFexposure
guidelines.SARinformationonthisdeviceisonle
with the FCC and can be found under the Display
Grant section of www.fcc.gov/oet/ea/fccid after
searching on FCC ID: MSQZ01HD.
NOTE: The FCC statement and IC notices are for
ASUS_Z01HD only.
CE RF Exposure Compliance
This device meets the EU requirements (1999/519/
EC)onthelimitationofexposureofthegeneral
publictoelectromagneticeldsbywayofhealth
protection.
For body-worn operation, this device has been
tested and meets the ICNIRP guidelines and the
European Standard EN 62209-2, for use with
dedicated accessories. SAR is measured with
this device at a separation of 0.5 cm to the body,
whiletransmittingatthehighestcertiedoutput
power level in all frequency bands of this device.
Use of other accessories which contain metals
maynotensurecompliancewithICNIRPexposure
guidelines.
CE Mark Warning
E12130_ZE553KL_Booklet_EU_UM.indd 12 2016/11/28 17:23:36
CE marking for devices with wireless
LAN/ Bluetooth
This equipment complies with the requirements of
Directive 1999/5/EC of the European Parliament
and Commission from 9 March, 1999 governing
Radio and Telecommunications Equipment and
mutual recognition of conformity. The highest CE
SAR values for the device are as follows:
• 0.558W/Kg@10g(Head)/1.55W/Kg@10g
(Body) for ASUS_Z01HD
• 0.426W/Kg@10g(Head)/1.450W/Kg@10g
(Body) for ASUS_Z01HDA
Laser safety information
CLASS 1 LASER PRODUCT
NOTE: For more Regulatory information and
compliance marks (E-labels) about FCC/IC/
MIC/VCCI, please refer to your device via the
following steps: Settings > About > Regulatory
Information.
E12130_ZE553KL_Booklet_EU_UM.indd 13 2016/11/28 17:23:36
Using GPS (Global Positioning
System) on your ASUS Phone
To use the GPS positioning feature on your ASUS
Phone:
• Ensure that your device is connected to the
Internet before using Google Map or any
GPS-enabled apps.
• Forrst-timeuseofaGPS-enabledappon
your device, ensure that you are outdoors to
get the best positioning data.
• When using a GPS-enabled app on
your device inside a vehicle, the metallic
component of the car window and other
electronic devices might affect the GPS
performance.
Prevention of Hearing Loss
To prevent possible hearing damage, do not listen
at high volume levels for long periods.
For France, headphones/earphones for this
device are compliant with the sound pressure level
requirement laid down in the applicable EN 50332-
1:2013 and/or EN50332-2:2013 standard required
by French Article L.5232-1.
E12130_ZE553KL_Booklet_EU_UM.indd 14 2016/11/28 17:23:37
Safety information
ASUS Phone care
• UseyourASUSPhoneinanenvironmentwith
ambient temperatures between 0 °C (32 °F)
and 35 °C (95 °F).
The battery
WARNING: Disassembling the battery by yourself
will void its warranty and may cause serious harm.
Your ASUS Phone is equipped with a high
performance non-detachable Li-polymer battery.
Observe the maintenance guidelines for a longer
battery life.
• Donotremovethenon-detachableLi-polymer
battery as this will void the warranty.
• Avoidcharginginextremelyhighorlow
temperature. The battery performs optimally in
an ambient temperature of +5 °C to +35 °C.
• Donotremoveandreplacethebatterywitha
non-approved battery.
• UseonlyASUSbattery.Usingadifferent
battery may cause physical harm/injury and
may damage your device.
• Donotremoveandsoakthebatteryinwateror
any other liquid.
• Nevertrytoopenthebatteryasitcontains
substances that might be harmful if swallowed
or allowed to come into contact with
unprotected skin.
• Donotremoveandshort-circuitthebattery,as
itmayoverheatandcauseare.Keepitaway
from jewelry or metal objects.
• Donotremoveanddisposeofthebattery
inre.Itcouldexplodeandreleaseharmful
substances into the environment.
E12130_ZE553KL_Booklet_EU_UM.indd 15 2016/11/28 17:23:37
• Donotremoveanddisposeofthebatterywith
your regular household waste. Take it to a
hazardous material collection point.
• Donottouchthebatteryterminals.
• Toavoidreorburns,donotdisassemble,
bend, crush, or puncture the battery.
NOTES:
• Riskofexplosionifbatteryisreplacedbyan
incorrect type.
• Disposeofusedbatteryaccordingtothe
instructions.
The charger
• UseonlythechargersuppliedwithyourASUS
Phone.
Caution
Your ASUS Phone is a high quality piece of
equipment. Before operating, read all instructions
and cautionary markings on the (1) AC Adapter.
• DonotusetheASUSPhoneinanextreme
environment where high temperature or high
humidityexists.TheASUSPhoneperforms
optimally in an ambient temperature between 0
°C (32 °F) and 35 °C (95 °F).
• DonotdisassembletheASUSPhoneorits
accessories. If service or repair is required,
return the unit to an authorized service center.
If the unit is disassembled, a risk of electric
shockorremayresult.
• Donotshort-circuitthebatteryterminalswith
metal items.
E12130_ZE553KL_Booklet_EU_UM.indd 16 2016/11/28 17:23:37
Operator access with a tool
If a TOOL is necessary to gain access to an
OPERATOR ACCESS AREA, either all other
compartments within that area containing a hazard
shall be inaccessible to the OPERATOR by the use
of the same TOOL, or such compartments shall be
marked to discourage OPERATOR access.
ASUS Recycling/Takeback
Services
ASUS recycling and takeback programs come
from our commitment to the highest standards for
protecting our environment. We believe in providing
solutions for you to be able to responsibly recycle
our products, batteries, other components as well
as the packaging materials. Please go to http://
csr.asus.com/english/Takeback.htm for detailed
recycling information in different regions.
Regional notice for Singapore
This ASUS Phone complies
with IMDA Standards.
E12130_ZE553KL_Booklet_EU_UM.indd 17 2016/11/28 17:23:37
Proper disposal
WARNING! This product may contain chemicals
known to the State of California to cause cancer,
birth defects, or other reproductive harm. Wash
hands after handling.
Risk of explosion if battery is replaced
by an incorrect type. Dispose of used
batteries according to the instructions.
DO NOT throw the battery in municipal
waste. The symbol of the crossed out
wheeled bin indicates that the battery
should not be placed in municipal waste.
DO NOT throw this product in municipal
waste. This product has been designed to
enable proper reuse of parts and recycling.
The symbol of the crossed out wheeled
bin indicates that the product (electrical,
electronic equipment and mercury-
containing button cell battery) should not
be placed in municipal waste. Check
local regulations for disposal of electronic
products.
DONOTthrowthisproductinre.DO
NOT short circuit the contacts. DO NOT
disassemble this product.
E12130_ZE553KL_Booklet_EU_UM.indd 18 2016/11/28 17:23:37
Risk of explosion if battery is replaced
by an incorrect type. Dispose of used
batteries according to the instructions.
DO NOT throw the battery in municipal
waste. The symbol of the crossed out
wheeled bin indicates that the battery
should not be placed in municipal waste.
DO NOT throw this product in municipal
waste. This product has been designed to
enable proper reuse of parts and recycling.
The symbol of the crossed out wheeled
bin indicates that the product (electrical,
electronic equipment and mercury-
containing button cell battery) should not
be placed in municipal waste. Check
local regulations for disposal of electronic
products.
DONOTthrowthisproductinre.DO
NOT short circuit the contacts. DO NOT
disassemble this product.
EU Declaration of Conformity
We, the undersigned,
Manufacturer:
ASUSTeK COMPUTER INC.
Address:
4F, No. 150, LI-TE Rd., PEITOU, TAIPEI 112, TAIWAN
Authorized representative in Europe:
ASUS COMPUTER GmbH
Address, City:
HARKORT STR. 21-23, 40880 RATINGEN
Country:
GERMANY
declare the following apparatus:
Product name :
ASUS Phone
Model name :
ASUS_Z01HD, ASUS_Z01HDA
The object of the declaration described above is in conformity with the relevant Union harmonisation legislation:
EMC – Directive 2004/108/EC (until April 19th, 2016) and Directive 2014/30/EU (from April 20th, 2016)
EN 55022:2010+AC:2011
EN 61000-3-2:2014
EN 55032:2012+AC:2013
EN 55024:2010
EN 61000-3-3:2013
EN 55020:2007+A11:2011
R&TTE – Directive 1999/5/EC
EN 300 328 V1.9.1(2015-02)
EN 300 330-1 V1.8.1(2015-03)
EN 300 330-2 V1.6.1(2015-03)
EN 300 440-1 V1.6.1(2010-08)
EN 300 440-2 V1.4.1(2010-08)
EN 301 511 V12.1.1(2015-06)
EN 301 908-1 V7.1.1(2015-03)
EN 301 908-2 V7.1.1(2015-12)
EN 301 908-13 V7.1.1(2015-12)
EN 301 893 V1.8.1(2015-03)
EN 62479:2010
EN 62311:2008
EN 301 489-1 V1.9.2(2011-09)
EN 301 489-3 V1.6.1(2013-08)
EN 301 489-7 V1.3.1(2005-11)
EN 301 489-17 V2.2.1(2012-09)
EN 301 489-24 V1.5.1(2010-10)
EN 302 291-1 V1.1.1(2005-07)
EN 302 291-2 V1.1.1(2005-07)
EN 50360:2001/A1:2012
EN 50566:2013/AC:2014
EN 62209-1:2006
EN 62209-2:2010
LVD – Directiv e 2006/95/EC (until April 19th, 2016) and Directive 2014/35/EU (from April 20th, 2016)
EN 60950-1: 2006 / A12: 2011
EN 60950-1: 2006 / A2: 2013
EN 60065:2002 / A12: 2011
Ecodesign – Directive 2009/125/EC
Regulation (EC) No. 1275/2008
Regulation (EC) No. 642/2009
Regulation (EC) No. 278/2009
Regulation (EU) No. 617/2013
RoHS – Directive 2011/65/EU Ver. 160217
CE marking
Equipment Class 1
0560
Signature
Jerry Shen
Printed Name
CEO
Position
Taipei, Taiwan
Place of issue
30/11/2016
Date of issue
2016
Year CE marking was first affixed
(EU conformity marking)
EU Konformitätserklärung
Hiermit erklären wir,
Hersteller:
ASUSTeK COMPUTER INC.
Anschrift:
4F, No. 150, LI-TE Rd., PEITOU, TAIPEI 112, TAIWAN
Bevollmächtigter:
ASUS COMPUTER GmbH
Anschrift des Bevollmächtigten:
HARKORT STR. 21-23, 40880 RATINGEN
Land:
GERMANY
dass nachstehend bezeichnete Produkte
Produktbezeichnung
ASUS Phone
Modellbezeichnung:
ASUS_Z01HD, ASUS_Z01HDA
mit den nachstehend angegebenen, für das Produkt geltenden Richtlinien/Bestimmungen übereinstimmen:
EMV – Richtlinie 2004/108/EG (bis 19. April 2016) und Richtlinie 2014/30/EU (ab 20. April 2016)
EN 55022:2010+AC:2011
EN 61000-3-2:2014
EN 55032:2012+AC:2013
EN 55024:2010
EN 61000-3-3:2013
EN 55020:2007+A11:2011
R&TTE – Richtlinie 1999/5/EG
EN 300 328 V1.9.1(2015-02)
EN 300 330-1 V1.8.1(2015-03)
EN 300 330-2 V1.6.1(2015-03)
EN 300 440-1 V1.6.1(2010-08)
EN 300 440-2 V1.4.1(2010-08)
EN 301 511 V12.1.1(2015-06)
EN 301 908-1 V7.1.1(2015-03)
EN 301 908-2 V7.1.1(2015-12)
EN 301 908-13 V7.1.1(2015-12)
EN 301 893 V1.8.1(2015-03)
EN 62479:2010
EN 62311:2008
EN 301 489-1 V1.9.2(2011-09)
EN 301 489-3 V1.6.1(2013-08)
EN 301 489-7 V1.3.1(2005-11)
EN 301 489-17 V2.2.1(2012-09)
EN 301 489-24 V1.5.1(2010-10)
EN 302 291-1 V1.1.1(2005-07)
EN 302 291-2 V1.1.1(2005-07)
EN 50360:2001/A1:2012
EN 50566:2013/AC:2014
EN 62209-1:2006
EN 62209-2:2010
LVD – Richtlinie 2006/95/EG (bis 19. April 2016) und Richtlinie 2014/35/EU (ab 20. April 2016)
EN 60950-1: 2006 / A12: 2011
EN 60950-1: 2006 / A2: 2013
EN 60065:2002 / A12: 2011
Ökodesign – Richtlinie 2009/125/EG
Verordnung (EG) No. 1275/2008
Verordnung (EG) No. 642/2009
Verordnung (EG) No. 278/2009
Verordnung (EU) No. 617/2013
RoHS – Richtlinie 2011/ 65 /EU Ver. 160217
CE Kennzeichen
Geräteklasse 1
0560
Unterschrift
Jerry Shen
Name
CEO
Position
Taipei, Taiwan
Ort
30/11/2016
Datum
2016
Jahr der Kennzeichenvergabe
(EU Konformitätszeichen)
E12130_ZE553KL_Booklet_EU_UM.indd 19 2016/11/28 17:23:37
DECLARATION UE DE CONFORMITE
Nous, soussignés
Fabricant:
ASUSTeK COMPUTER INC.
Adresse:
4F, No. 150, LI-TE Rd., PEITOU, TAIPEI 112, TAIWAN
Représentant autorisé en Europe:
ASUS COMPUTER GmbH
Adresse, ville:
HARKORT STR. 21-23, 40880 RATINGEN
Pays:
GERMANY
Déclarons l’appareil suivant:
Nom du produit :
ASUS Phone
Nom du modèle :
ASUS_Z01HD, ASUS_Z01HDA
L’objet de la déclaration décrit ci-dessus est conforme avec la législation d’harmonisation de l’Union applicable
Directive CEM 2004/108/CE (jusqu’au 19 avril 2016) et la directive 2014/30 /UE (à partir du 20 avril 2016)
EN 55022:2010+AC:2011
EN 61000-3-2:2014
EN 55032:2012+AC:2013
EN 55024:2010
EN 61000-3-3:2013
EN 55020:2007+A11:2011
Directive R&TTE 1999/5/CE
EN 300 328 V1.9.1(2015-02)
EN 300 330-1 V1.8.1(2015-03)
EN 300 330-2 V1.6.1(2015-03)
EN 300 440-1 V1.6.1(2010-08)
EN 300 440-2 V1.4.1(2010-08)
EN 301 511 V12.1.1(2015-06)
EN 301 908-1 V7.1.1(2015-03)
EN 301 908-2 V7.1.1(2015-12)
EN 301 908-13 V7.1.1(2015-12)
EN 301 893 V1.8.1(2015-03)
EN 62479:2010
EN 62311:2008
EN 301 489-1 V1.9.2(2011-09)
EN 301 489-3 V1.6.1(2013-08)
EN 301 489-7 V1.3.1(2005-11)
EN 301 489-17 V2.2.1(2012-09)
EN 301 489-24 V1.5.1(2010-10)
EN 302 291-1 V1.1.1(2005-07)
EN 302 291-2 V1.1.1(2005-07)
EN 50360:2001/A1:2012
EN 50566:2013/AC:2014
EN 62209-1:2006
EN 62209-2:2010
Directive LVD 2006//125/CE (jusqu’au 19 avril 2016) et la directive 2014/34/UE (à partir du 20 avril 2016)
EN 60950-1: 2006 / A12: 2011
EN 60950-1: 2006 / A2: 2013
EN 60065:2002 / A12: 2011
Directive écoconception 2009/125/CE
Regulation (CE) No. 1275/2008
Regulation (CE) No. 642/2009
Regulation (CE) No. 278/2009
Regulation (UE) No. 617/2013
Directive RoHS 2011/65/UE Ver. 160217
Marquage CE
Equipement de classe 1
0560
Signature
Jerry Shen
Nom en caractères d’imprimerie
CEO
Position
Taipei, Taiwan
Lieu de délivrance
30/11/2016
Date d'Emission
2016
Année où commence l’apposition
du marquage CE
(Marquage UE de conformité)
UE Declaración de Conformidad
Nosotros, los abajo firmantes,
Fabricante:
ASUSTeK COMPUTER INC.
Dirección:
4F, No. 150, LI-TE Rd., PEITOU, TAIPEI 112, TAIWAN
Representante autorizado en Europa:
ASUS COMPUTER GmbH
Dirección, Ciudad:
HARKORT STR. 21-23, 40880 RATINGEN
País:
GERMANY
Declaramos el siguiente producto:
Nombre del aparato :
ASUS Phone
Nombre del modelo :
ASUS_Z01HD, ASUS_Z01HDA
El objeto de la declaración descrita anteriormente es conforme con la legislación de armonización pertinente de la Unión:
EMC Directiva 2004/108/CE (hasta el 19 de abril, 2016) y Directiva 2014/30/UE (desde el 20 de abril, 2016)
EN 55022:2010+AC:2011
EN 61000-3-2:2014
EN 55032:2012+AC:2013
EN 55024:2010
EN 61000-3-3:2013
R&TTE – Directiva 1999/5/CE
EN 300 328 V1.9.1(2015-02)
EN 300 330-1 V1.8.1(2015-03)
EN 300 330-2 V1.6.1(2015-03)
EN 300 440-1 V1.6.1(2010-08)
EN 300 440-2 V1.4.1(2010-08)
EN 301 511 V12.1.1(2015-06)
EN 301 908-1 V7.1.1(2015-03)
EN 301 908-2 V7.1.1(2015-12)
EN 301 908-13 V7.1.1(2015-12)
EN 62479:2010
EN 62311:2008
EN 301 489-1 V1.9.2(2011-09)
EN 301 489-3 V1.6.1(2013-08)
EN 301 489-7 V1.3.1(2005-11)
EN 301 489-17 V2.2.1(2012-09)
EN 301 489-24 V1.5.1(2010-10)
EN 302 291-1 V1.1.1(2005-07)
EN 302 291-2 V1.1.1(2005-07)
EN 50360:2001/A1:2012
EN 50566:2013/AC:2014
EN 62209-1:2006
EN 62209-2:2010
LVD Directiva 2006/95/CE (hasta el 19 de abril, 2016) y Directiva 2014/35/UE (desde el 20 de abril, 2016)
EN 60950-1: 2006 / A12: 2011 EN 60950-1: 2006 / A2: 2013
Diseño Ecológico – Directiva 2009/125/CE
Regulation (EC) No. 1275/2008
Regulation (EC) No. 278/2009
RoHS – Directiva 2011/65/UE Ver. 160217
Marcado CE
Clase de equipo 1
0560
Firma
Jerry Shen
Nombre impreso
CEO
Posición
Taipei, Taiwan
Lugar de emisión
30/11/2016
Fecha de emisión
2016
Año en que se colocó
el marcado CE por primera vez
(marcado CE de conformidad)
E12130_ZE553KL_Booklet_EU_UM.indd 20 2016/11/28 17:23:37
Declaração CE de Conformidade
Nós, os abaixo-assinados,
Fabricante:
ASUSTeK COMPUTER INC.
Endereço:
4F, No. 150, LI-TE Rd., PEITOU, TAIPEI 112, TAIWAN
Representante autorizado na Europa:
ASUS COMPUTER GmbH
Endereço, cidade:
HARKORT STR. 21-23, 40880 RATINGEN
País:
GERMANY
declaramos o seguinte aparelho:
Nome do produto:
ASUS Phone
Nome do modelo:
ASUS_Z01HD, ASUS_Z01HDA
O objeto da declaração acima descrito está em conformidade com a legislação de harmonização da União aplicável:
EMC Diretiva 2004/108/CE (até 19 de abril de 2016) e Diretiva 2014/30/UE (a partir de 20 de abril de 2016)
EN 55022:2010+AC:2011
EN 61000-3-2:2014
EN 55032:2012+AC:2013
EN 55024:2010
EN 61000-3-3:2013
EN 55020:2007+A11:2011
R&TTE – Diretiva 1999/5/CE
EN 300 328 V1.9.1(2015-02)
EN 300 330-1 V1.8.1(2015-03)
EN 300 330-2 V1.6.1(2015-03)
EN 300 440-1 V1.6.1(2010-08)
EN 300 440-2 V1.4.1(2010-08)
EN 301 511 V12.1.1(2015-06)
EN 301 908-1 V7.1.1(2015-03)
EN 301 908-2 V7.1.1(2015-12)
EN 301 908-13 V7.1.1(2015-12)
EN 301 893 V1.8.1(2015-03)
EN 62479:2010
EN 62311:2008
EN 301 489-1 V1.9.2(2011-09)
EN 301 489-3 V1.6.1(2013-08)
EN 301 489-7 V1.3.1(2005-11)
EN 301 489-17 V2.2.1(2012-09)
EN 301 489-24 V1.5.1(2010-10)
EN 302 291-1 V1.1.1(2005-07)
EN 302 291-2 V1.1.1(2005-07)
EN 50360:2001/A1:2012
EN 50566:2013/AC:2014
EN 62209-1:2006
EN 62209-2:2010
LVD Diretiva 2006/95/CE (até 19 de abril de 2016) and Diretiva 2014/35/UE (a partir de 20 de abril de 2016)
EN 60950-1: 2006 / A12: 2011
EN 60950-1: 2006 / A2: 2013
EN 60065:2002 / A12: 2011
EcoEcodesign – Diretiva 2009/125/CE
Regulation (EC) No. 1275/2008
Regulation (EC) No. 642/2009
Regulation (EC) No. 278/2009
Regulation (EU) No. 617/2013
RoHS – Diretiva 2011/65/UE Ver. 160217
Marcação CE
Classe de equipamento 1
0560
Assinatura
Jerry Shen
Nome impresso
CEO
Posição
Taipei, Taiwan
Local de emissão
30/11/2016
Data de emissão
2016
Ano marcação CE foi aposta por primeira vez
(Marcação CE de conformidade)
Declaraţie de conformitate UE
Subsemnatul,
Producător :
ASUSTeK COMPUTER INC.
Adresă:
4F, No. 150, LI-TE Rd., PEITOU, TAIPEI 112, TAIWAN
Reprezentant autorizat în Europa:
ASUS COMPUTER GmbH
Adresă, Oraş:
HARKORT STR. 21-23, 40880 RATINGEN
Ţară:
GERMANIA
declară următorul aparat:
Nume Produs :
ASUS Phone
Nume Model :
ASUS_Z01HD, ASUS_Z01HDA
Obiectul declarației descris mai sus este în conformitate cu legislația relevantă de armonizare a Uniunii :
CEM – Directiva 2004/108/CE (până în 19 Aprilie 2016) şi Directiva 2014/30/UE (până în 20 Aprilie 2016)
EN 55022:2010+AC:2011
EN 61000-3-2:2014
EN 55032:2012+AC:2013
EN 55024:2010
EN 61000-3-3:2013
EN 55020:2007+A11:2011
R&TTE – Directiva 1999/5/CE
EN 300 328 V1.9.1(2015-02)
EN 300 330-1 V1.8.1(2015-03)
EN 300 330-2 V1.6.1(2015-03)
EN 300 440-1 V1.6.1(2010-08)
EN 300 440-2 V1.4.1(2010-08)
EN 301 511 V12.1.1(2015-06)
EN 301 908-1 V7.1.1(2015-03)
EN 301 908-2 V7.1.1(2015-12)
EN 301 908-13 V7.1.1(2015-12)
EN 301 893 V1.8.1(2015-03)
EN 62479:2010
EN 62311:2008
EN 301 489-1 V1.9.2(2011-09)
EN 301 489-3 V1.6.1(2013-08)
EN 301 489-7 V1.3.1(2005-11)
EN 301 489-17 V2.2.1(2012-09)
EN 301 489-24 V1.5.1(2010-10)
EN 302 291-1 V1.1.1(2005-07)
EN 302 291-2 V1.1.1(2005-07)
EN 50360:2001/A1:2012
EN 50566:2013/AC:2014
EN 62209-1:2006
EN 62209-2:2010
LVD – Directiv a 2006/95/CE (până în 19 Aprilie 2016) şi Directiva 2014/35/UE (până în 20 Aprilie 2016)
EN 60950-1: 2006 / A12: 2011
EN 60950-1: 2006 / A2: 2013
EN 60065:2002 / A12: 2011
Ecodesign – Directiva 2009/125/CE
Regulation (EC) No. 1275/2008
Regulation (EC) No. 642/2009
Regulation (EC) No. 278/2009
Regulation (EU) No. 617/2013
RoHS – Directiva 2011/65/UE Ver. 160217
Marcajul CE
Echipament Clasa 1
0560
Semnătură
Jerry Shen
Nume
CEO
Funcţie
Taipei, Taiwan
Locul emiterii
30/11/2016
Data emiterii
2016
Anul în care Marcajul CE a fost aplicat pentru
prima oară
(Marcaj de conformitate UE )
E12130_ZE553KL_Booklet_EU_UM.indd 21 2016/11/28 17:23:38
EU Uygunluk Beyanı
Biz, bu imza altındakiler
Üretici:
ASUSTeK COMPUTER INC.
Adres:
4F, No. 150, LI-TE Rd., PEITOU, TAIPEI 112, TAIWAN
Avrupa’daki Yetkili:
ASUS COMPUTER GmbH
Adres, Şehir:
HARKORT STR. 21-23, 40880 RATINGEN
Ülke:
ALMANYA
Aşağıdaki ürünleri beyan ediyoruz :
Ürün adı :
ASUS Phone
Model adı :
ASUS_Z01HD, ASUS_Z01HDA
Yukarıda belirtilen beyanın konusu birlik yasalarına göre uygundur:
EMC – Direktif 2004/108/EC 19 Nisan 2016’ya kadar ve Direktif 2014/30/EU 20 Nisan 20 16
EN 55022:2010+AC:2011
EN 61000-3-2:2014
EN 55032:2012+AC:2013
EN 55024:2010
EN 61000-3-3:2013
EN 55020:2007+A11:2011
R&TTE – Direktifi 1999/5/EC
EN 300 328 V1.9.1(2015-02)
EN 300 330-1 V1.8.1(2015-03)
EN 300 330-2 V1.6.1(2015-03)
EN 300 440-1 V1.6.1(2010-08)
EN 300 440-2 V1.4.1(2010-08)
EN 301 511 V12.1.1(2015-06)
EN 301 908-1 V7.1.1(2015-03)
EN 301 908-2 V7.1.1(2015-12)
EN 301 908-13 V7.1.1(2015-12)
EN 301 893 V1.8.1(2015-03)
EN 62479:2010
EN 62311:2008
EN 301 489-1 V1.9.2(2011-09)
EN 301 489-3 V1.6.1(2013-08)
EN 301 489-7 V1.3.1(2005-11)
EN 301 489-17 V2.2.1(2012-09)
EN 301 489-24 V1.5.1(2010-10)
EN 302 291-1 V1.1.1(2005-07)
EN 302 291-2 V1.1.1(2005-07)
EN 50360:2001/A1:2012
EN 50566:2013/AC:2014
EN 62209-1:2006
EN 62209-2:2010
LVD – Di rektifi 2006/95/19 Nisan 2016’ya kadar ve Direktif 2014/35/EU 20 Nisan 2016
EN 60950-1: 2006 / A12: 2011
EN 60950-1: 2006 / A2: 2013
EN 60065:2002 / A12: 2011
Ecodesign – Direktif 2009/125/EC
Regulation (EC) No. 1275/2008
Regulation (EC) No. 642/2009
Regulation (EC) No. 278/2009
Regulation (EU) No. 617/2013
RoHS – Direktifi 2011/65/EU Ver. 160217
CE işareti
Ekipman Sınıfı 1
0560
İmza
Jerry Shen
Basılı Ad
CEO
Pozisyonu
Taipei, Taiwan
Sürüm yeri
30/11/2016
Sürüm tarihi
2016
CE işaretinin ilk eklendiği yıl
(EU uygunluk işareti)
E12130_ZE553KL_Booklet_EU_UM.indd 22 2016/11/28 17:23:38
Copyright © 2016 ASUSTeK COMPUTER INC.
All Rights Reserved.
You acknowledge that all rights of this Manual remain with ASUS.
Any and all rights, including without limitation, in the Manual or
website,andshallremaintheexclusivepropertyofASUSand/orits
licensors. Nothing in this Manual intends to transfer any such rights,
or to vest any such rights to you.
ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY
OF ANY KIND. SPECIFICATIONS AND INFORMATION
CONTAINED IN THIS MANUAL ARE FURNISHED FOR
INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE
AT ANY TIME WITHOUT NOTICE, AND SHOULD NOT BE
CONSTRUED AS A COMMITMENT BY ASUS.
ASUS
Address: 4F, 150 Li-Te Road, Peitou, Taipei,
Taiwan
Tel: 886228943447
Fax: 886228907698
Declaration
We declare that the IMEI codes for this product, ASUS
Phone, are unique to each unit and only assigned to
this model. The IMEI of each unit is factory set and
cannot be altered by the user and that it complies
with the relevant IMEI integrity related requirements
expressedintheGSMstandards.
Should you have any questions or comments regarding
this matter, please contact us.
Sincerely yours,
ASUSTeK COMPUTER INC.
Tel: 886228943447
Fax:886228907698
Support:http://vip.asus.com/eservice/techserv.aspx
15060-79710200
ZenTalk Fans Forum
(http://www.asus.com/zentalk/global_forward.php)
E12130_ZE553KL_Booklet_EU_UM.indd 23 2016/11/28 17:23:38

Navigation menu
