Users Manual

Manual for GKB641B

Keyboard Font view

1. 14 hot keys:

Home, input method, Siri, virtual keyboard, Search, backlight down, backlight up, previous track,

play/pause, next track, mute, voice down, voice up, lock

Keyboard Back view

Keyboard Side view

2. Recharge port

3. On/off button

4. Pairing button/Bluetooth LED/Power LED

Connection

1. Turn on the keyboard and keep pressing the paring button for 3 seconds until the blue LED

flash;

2. open the Bluetooth at your Iphone/Ipad and search for the keyboard;

3. choose the detected device “BT4.0 Keyboard” and confirm to pair with it (without any code).

When it pair successfully, the LED will go off.

if the paring time last too long and did not pair successfully, please re-do from the 1st step...

*After pairing well, the keyboard could restore the pairing, so when you start to use the keyboard

after a break, no need to re-pair it..

Low power indicator

When the power is less than 3.65V, the LED will be changed in Red and flash for 1 minute to remind

the user to recharge it.

Recharge

When recharging, the Blue LED keeps lighting up until full recharged, then the light will be off.

Specification

Dimension: 279.6(L) x111(W) x13.7(H) mm

Working Voltage: 3.3V~4.2V

Power consumption 3mA

Battery type Lithium battery, 320mAh

ThisdevicecomplieswithIndustry

Canadalicence‐exemptRSSstandard(s).Operationissubjecttothefollowingtwoconditions:(1)

thisdevicemaynotcauseinterference,and(2)thisdevicemustacceptanyinterference,including

interferencethatmaycauseundesiredoperationofthedeviceChangesormodificationsnot

expresslyapprovedbythepartyresponsibleforcompliancecouldvoidtheuser'sauthorityto

operatetheequipment.

NOTE:THEMANUFACTURERISNOTRESPONSIBLEFORANYRADIOORTVINTERFERENCECAUSED

BYUNAUTHORIZEDMODIFICATIONSTOTHISEQUIPMENT.SUCHMODIFICATIONSCOULDVOID

THEUSER’SAUTHORITYTOOPERATETHEEQUIPMENT.



LeprésentappareilestconformeauxCNR

d'IndustrieCanadaapplicablesauxappareilsradioexemptsdelicence.L'exploitationestautorisée

auxdeuxconditionssuivantes:



(1)l'appareilnedoitpasproduiredebrouillage,et(2)l'utilisateurdel'appareildoitacceptertout

brouillageradioélectriquesubi,mêmesilebrouillageestsusceptibled'encompromettrele

fonctionnement.



ComplieswiththeCanadianICES‐003ClassBspecifications.

CetappareilnumériquedelaclasseBestconformeàlanormeNMB‐003duCanada.



ThisequipmentcomplieswithFCCRFradiationexposure

limitssetforthforanuncontrolledenvironment.Thisdevice

anditsantennamustnotbeco‐locatedoroperatingin

conjunctionwithanyotherantennaortransmitter.
