USERS MANUAL
Bluetooth Headset
H901A
,
What s in the box
The headset conta in s the follo wing parts:
1
1
1 B luetooth Headset
2. Travel Charger
3. USB Charging Cable
4. User Manual
Package contents list:
1. Speaker
2. Multi-function Button
3. Indicator Light
4. Microphone
5. Volume Up Button
6. Volume Down Button
7. Charging Socket
8. Ear Hook
H901A
2Pair to your Bluetooth phone
2
Before you use your headset the firs t tim e, you must pair the unit with a Bluetooth devic e e.g.
Bluetooth mobile phone. This operatio n guide based on the Bluetooth phone as the host's device.
Ple ase refer to the follo wing step to set up the pairin g:
****
Press and hold the MFB for 4 seconds
until you see the Blue and Red LED
light flash alternately to enterthe
pairing mode.
Your phone will find the headset and show
the device name on the screen, select the
device name and confirm to pairing.
Enter PIN code as 0000 (4 zeros) and
confirm to complete pairing.
Following your phone's instruction
guide, operate your Bluetooth phone
to active Bluetooth function and
search the headset.
Ensure th e
headset is off.
Blue tooth devic es Sca n re sults
Enter Blue too th
Passkey
1 2 3
45
H901A
NOTE:
l If the pairing is successful, the headset will connect to your phone automatically, you may
need to confirm the enquiry.
l While the headset is paired with the phone and connected, the indication light will flash 2
times every 5 seconds. If failed or didn't connect to the phone, the blue indicator light will
flash 1 time every 3 seconds.
l Once you paired the headset with one device or more, the Headset will automatically
connect to the phone you last connected wherever you turn the headset on, but make sure
your phone's Bluetooth function is active.
l The headset is supports Bluetooth v2.1+EDR specification, the simplified pairing process
will make paring your devices easily, if your mobile phone supports Bluetooth v2.1+EDR
specification, you just need turn on both of them, and add new Bluetooth device on your
phone, the headset and your phone will find each other and connect automatically.
nd
l The headset supports multi-point technology. If you need connect the headset to the 2
Bluetooth phone, please repeat the pairing operation steps above. When finish the pairing,
turn off the headset and turn on again, the headset will connect to the both 2 phones
automatically.
3
Charging the battery
4
3
This headset has an internal, non-removable, rechargeable battery. Do not attempt to remove
the battery from the device as you may damage the device. Please refer to the following step to
charge the battery:
1. Connect the charger to the correct outlet.
2. When the charger is connected to headset, the red indicator
light will turn on during charging. Charging the battery
fully may take up to 2 hours.
3. When the battery is fully charged, the red indicator light
will turn off. Disconnect the charger from the headset and
the wall outlet. The headset is ready to use.
NOTE:
l The fully charged battery has power for up to 3 hours of talk-time
or up to 100 hours of standby time. However, the talk and standby
times may vary when used with different mobile phones or other
compatible Bluetooth devices, usage settings, usage styles, and
environments.
l When battery power is low, the headset will remind you by beeps every
20 seconds, and the red indicator light starts to flash.
Battery informatio n
Your device is powered by a chargeable battery. The full perform ance of a new battery 's an
achieved only afte r two or three complete charge and disc harge cy cle. The batt ery can be
charged and disc harged hundreds of tim es, but it will eventually wear out.
Unplug the charger from the electric al plu g and the devic e when not in use. Do not leave a fully
charged battery connected to a charger, sin ce overcharging may shorte n its life tim e. If left
unused, a fully charged battery will lose its charge over tim e.
If the headset would be leave unused for a long tim e, please charge fully and tu rn off the headset.
To prevent over disc harge endangerin g th e battery, you are recommended to charge the
headset fu lly each month.
Never use any oth er charger that is damaged.
Turning headset on /off
5
4
5
*Turn on the headset
If the headset is turned off, press and hold MFB for 2 seconds until you hear a melody from low to
high, the headset turns on, the Blue indicator light will flash 3 times at the same time.
*Connects to the phone
1.If your headset has finished the pairing operation successfully, when the headset is turned on,
it will connect to the phone(s) you last connected automatically, but make sure your phone's
Bluetooth function is active.
2.The headset supports multi-point and connects to 2 phones at the same time. In some
operations, you need to distinguish the connection sequence, so we appoint the phone first
connected as phone 1, the second one as phone 2.
6
Left
Right
6
Wearing your headset
The headset can be worn on either the
Left or Right ear. If you want to carry
the headset on the other ear,
please refer to the following figures
to change the direction of the ear gel:
*Turn off the headset
At any working state after the headset turns on, press and hold MFB for 4 seconds, you will hear
a melody from high to low, and the Red indicator light will flash 3 times at the same time, the
headset turns off.
Note
l For saving the power, while the headset didn't connect to any device over 1 hour,
the headset will turn off automatically.
Making a call
7
* By phone's keypad
At the stand-by state, dia l the number on your phone dire ctly to make a call.
* Use Voice- Dialing
At the stand-by state, press the MFB shortly , you will hear a short tone from the headset, and the
phone will prompt you say the voice tag lik e your frie nd's name. If the voice tag is id entifie d by
the phone, the related number will be dial-o ut later.
Make sure whether your mobile phone supports voice dialin g functio n, and you need to set up
voice tags on your mobile phone firs t. If the headset has connected to 2 phones, double press
the MFB will start Voice-Dialin g of phone 2.
* Last number re-d ialin g
Press and hold Vol- for 2 seconds, you will hear 2 short tones, the last number
you diale d will be re-d ial out. If the headset has connected to 2 phones, press and hold Volu me
Up button for 2 seconds will start last number re-d ialin g of phone 2.
NOTE
l If the headset has connected to 2 phones, when one phone has activ e a call, the headset
will disconnect to other phone temperately, when you end the call the headset will
re-c onnect it automatic ally, ple ase make sure your phone's Bluetooth functio n would not
be inactiv e durin g the callin g.
7
Reject an incoming call
9
When you receive an in coming call, press and hold MFB for 2 seconds will reject the incoming call.
Answering a call
10
When you receive an incoming call, press the MFB shortly can pick up the incoming call; also you
can pick up the call on your mobile.
Transferring a call
11
When in the calling, press and hold Volume Up button for 2 seconds can transfer the call from headset
to phone. Repeat the operation can transfer the call between the phone and headset each other.
Call-w aiting (Three-Way Callin g)
12
Before using Call-waiting function on your headset, please ensure that your phone supports the
Hands-free profile, and you have been provide the service by the net provider.
* If there is another incoming call while you are in the calling, press MFB shortly can accept the
waiting call and end current calling.
* If there is another incoming call while you are in the calling, press and hold MFB for 2 seconds
can accept the waiting call and hold on current calling.
Ending a call
When in the callin g, press the MFB shortly will end the call, also you can end call on your mobile .
8
8
Volume control & Mute function
13
14
While you are in the callin g, you can adjust the volume by pressing vol+ and Vol- or you can
adjust the volume on your mobile .
9
Mute
While you are in the calling, Press and hold the Vol- for 2 seconds, you will
hear a melody from low to high, then the headset's MIC will be muted, and you will hear
remindful melody every 10 seconds. Repeat the operation your will hear the melody from
high to low, the mute function is cancelled.
* While you are in the calling and another call was holding on, press MFB shortly can end current
call and resume the holding on calling.
* While you are in the calling and another call was holding on, press and hold MFB for 2 seconds
can shift the current calling to the holding on calling.
* While you are in the calling and another call was holding on, press Volume Up button shortly can
add the holding on call to the current conversation to make a multiparty call.
* While you are in the calling and another call was holding on, or you are in a multiparty calling,
double press MFB can end the calling or remove yourself from the multiparty calling.
Warranty
15
10
The conditio n of this warranty and our responsibilitie s under this warranty are as follo ws:
Warranty is non-t ransferable and is lim ite d to the orig inal purchaser only.
* You must be able to prove the date of orig inal purchase of the unit with a dated receipt.
* The warr anty is not applic able if the product has been subject to physical abuse,
improper in stallatio n, modific atio n or repair by unauthoriz ed third party .
,
* The responsibility of supplie r s products shall be lim ite d to the repair or repla cement of
,
the product at it s sole discretion.
* Specific ally exempt from any warranty are lim ite d-lif e consumable components subject
to normal wear and tear such as batterie s, decorates and oth er accessorie s.
* Supplie r will not take any responsib ility if the failure of th e unit has resulte d from
accident, abuse, misuse, or any unauthoriz ed repair, modific atio n or disassemble.
* Modific atio n and repair of the unit should be done by auth oriz ed and qualifie d serv ice
center or returned to the manufacturer
*This warranty gives you specific legal rig hts, and you may also have other rig hts which
vary under local laws.
FCC WARNING
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause
undesired operation.
NOTE 1: Any changes or modifications to this unit not expressly approved by the party
responsible for compliance could void the user's authority to operate the equipment.
