ATI Electronics IMW269 Bluetooth Speaker User Manual
ATI Electronics (Shenzhen) Co. Ltd Bluetooth Speaker
User Manual
6. Listening to Music on Your Speaker
Play/Pause
Press the Power button to get music from your audio source to play
or pause.
Next/Previous Song
Press and hold the Volume + or Volume- buttons for 2s to advance to
the next song or go back to the previous one.
Increase/Decrease Volume
Press the Volume+ or Volume - buttons to increase or decrease the
volume
3 Second
3 Second
2 Second
5. True Wireless Pairing
The Altec Baby boom supports to connect to the second unit to build
the True Wireless Stereo speaker connection.
a. When a Altec Baby boom is paired to your phone successfully,
press and hold both Power button and Volume - button for 3s to
enter TWS Master pairing mode. The
speaker flashes blue and red
alternately.
b. Turn the second Altec Baby boom on by press and hold Power
button for 3s, and then press and hold both Power button and
Volume + button to enter TWS Slave pairing
mode. The speakers will pair and connect
each other after few seconds. The master
unit will be the left channel and slave one
will be the right channel.
4. Pairing Your Speaker With a Bluetooth Phone
-Press and hold the Power button for around 2s. the device will
power on and enter pairing mode with voice prompt "powering on,
welcome to ALTEC LANSING"
-Go to the Bluetooth Manager of your Bluetooth device. Search
Bluetooth devices and select "Altec Baby boom" to start
connecting.
-If required, enter the PIN code "0000" and confirm the entry. Once
paired successful, the speaker will connect to your Bluetooth
device automatically.
Indicator
3. Charging: In order to charge your speaker's internal battery, connect
one end of the included USB cable to the charging port on
your speaker. Connect the other to a USB port or AC
charging adapter(not included). The LED Light indicator
turns red when charging, and turns blue when fully
charged. Charging may take up to 3 hours.
① Charging Port
② AUX IN Port
③ Power / Play / Pause / Answer
④ Volume –
⑤ Volume +
⑥ LED Light Indicator
⑦ Microphone
① ②
⑥
⑦
③④⑤
2. For a look at the various buttons on your speaker,
view the graphic below.
USB Cable
AUX Cable
Altec Baby boom
1. Make sure the following items are
included in your package.
Item # IMW269
Quick Start Guide
RUGGED BLUETOOTH SPEAKER
BABY BOOM
Technical Support
For technical support issues please visit our website at www.alteclansing.com.
You can find manuals, software and FAQ's at the website. Can't find what you
are looking for? Call 1-855-292-4087 to access our technical support
information on the phone.
FCC ID: SF4-IMW255
PRODUCT INFO
User Guide
Thank you for purchasing the Bluetooth® Speaker . Please review the quick start guide before using the Speaker.
Battery information
The device is equipped with an integrated lithium-polymer battery. The battery cannot be replaced. Do not attempt to remove the battery from the device
since it would damage the device.
Safety information
1. To avoid any damage or malfunction of the device do not drop the device from high places.
2. Do not place or keep this device near any heat sources, such as, direct sunlight, radiators, stoves or other apparatus that produce heat. This may cause
an explosion, degrade the performance and/or reduce battery life.
3. Do not modify, repair or disassemble device (Especially the battery). Doing this will void the warranty.
4. Do not place heavy objects on the device.
5. Use only the supplied and approved chargers.
6. Unplug this device when unused for long periods of time or during lightening storms.
7. The battery used in this device may present a risk of fire or chemical burn if mistreated.
FCC Compliance Statement
This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause
undesired operation.
Note: Any changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user's authority to operate
the equipment.
EC Declaration of Conformity
Hereby, We declare that this product is compliance with to the essential requirements and other relevant provisions of the R&TTE Directive.
Disposal of the product end of life
Pursuant to Article 13 of Law July 25, 2005, No. 151 "Implementation of Directive 2002/95/EC, 2002/96/EC and 2002/96/EC, relating to the use of
hazardous substances in electrical and electronic equipment, as well as the smart waste ".
The symbol as shown on the product indicates that the end of its useful life must be separated from other waste. The user is responsible for
delivering the equipment to the appropriate recycling centers for electronic waste, or return it to the dealer when purchasing a new equivalent
product, on a one to one.
Proper waste collection equipment succession to start recycling, treatment and environmentally compatible disposal contributes in preventing
possible environmental and health eects negative and promote the recycling of the materials making up the product.
Illegal disposal of the product by the user includes the application of administrative penalties pursuant to Legislative Decree 22/1997 (art.50 and
following).
- Modification and repair of the unit should be done by an authorized and qualified service center or returned to the manufacturer.
- This warranty gives you specific legal rights, and you may also have other rights, which vary under local laws.
HANDS
FREE
SPEAKERPHONE
6
HRS
6HRS
BATTERY
LIFE
(60% Volume)
FLOATS
IN
WATER
IP67
WATERPROOF
SANDPROOF
EVERYTHING PROOF
8. Wired External Audio Input
You can also use the included 3.5mm Auxiliary Cable to connect
audio devices through the AUX In port on your speaker.
7. Using for phone call
Last number re-dialing
At standby status, double press
the Power button, the last number
you dialed will be re-dialed.
Answering a call
Press Power button shortly to
answer the incoming call.
Ending a call
Press the Power button shortly to
end a call.
Reject an Incoming Call
Press and hold the Power button
for a few seconds to reject an
incoming call.
Volume adjusting
Press the Volume Up and Volume
Down button to adjust the volume.
Item # IMW269
Quick Start Guide
RUGGED BLUETOOTH SPEAKER
BABY BOOM
