ATI Electronics SH711 Bluetooth Headphones User Manual
ATI Electronics (Shenzhen) Co. Ltd Bluetooth Headphones
User Manual
![](/img.php?id=3250311&img=bg1.png)
HEADPHONES
BLUETOOTH
USB Cable
3 Seconds
12:12 PM
Bluetooth
Bluetooth
Devices
Paired
ON
Now discoverable
Altec Over ear BT
5 Seconds
MZW300 Headhones
3. Charging: When charging, a red LED light will illuminate. The light will turn blue
when your unit is fully charged. Your headphones can take up to two
hours to fully charge.
Important Note
You can also use the 3.5mm Audio Cable to connect audio devices through the
Auxilliary Port on your headphones.
Note that when using the Audio cable instead of the standard wireless Bluetooth
connection, the Volume Up, Volume Down and Play/Pause buttons do not function.
Please use your audio source to control these functions.
2. For a look at the various buttons and parts of your headphones,
view the graphic below.
5. Pairing Your Headphones With a Bluetooth Phone
-Press and hold the Power button for around five seconds. When your
headphone is ready to pair with a Bluetooth audio source, it will go
into pairing mode, with red and blue LED lights will flash alternately.
-Go to the Bluetooth Manager of your Bluetooth device. Search
Bluetooth devices and select “Altec Over ear BT” to start connecting.
-If required, enter the PIN code "0000” and confirm the entry. Once
paired, the headphone will connect to your Bluetooth device
automatically.
4. Power ON/Power OFF Your Headphones:
-Press and hold the Power button for approximately three seconds to power
on your headphones. Your headphones will automatically connect with the
last phone they were paired with.
-Once powered on, you can press and hold the
Power button again for approximately five
seconds to power o your headphones. The
LED Indicator light will briefly turn red before
powering o.
NOTE: In order to save power, your
headphones will automatically
power o if left unpaired and idle for
over two minutes.
1. Make sure the following items are
included in your package.
Power/play/Answer
Volume Up/NEXT Volume Down/Previous
Indicator
Microphone
Charging Port
Auxiliary Port
6. Listening to Music
Play/Pause
Press the Power button to get music from your audio source to play or pause.
Next/Previous Song
Press and hold the Volume Up or Volume
Down buttons for two seconds to advance to
the next song or go back to the previous one.
Increase/Decrease Volume
Press the Volume Up or Volume
Down buttons to increase or decrease the
volume.
NOTE: Music will automatically pause when
a call is dialed out or when there is
an incoming call. It will resume when
the call ends.
7. Using Your Headphones During Phone Calls
Last Number Redialing
Quickly tap on the Answer button twice and the last
number that you dialed will be redialed.
Answering an Incoming Call
To answer an incoming call, quickly press the
Answer button.
Ending a Call
To end a call, quickly press the Answer
button, and the call will be disconnected.
Adjusting Volume
By pressing the Volume Up or Volume
Down buttons you can increase or
decrease the volume of the phone call.
Item # MZW300
Quick Start Guide
Technical Support
For technical support issues please visit our website at www.alteclansing.com.
You can find manuals and FAQ's at the website. Can't find what you are
looking for? Call 1-855-292-4087 to access our technical support information
on the phone.
![](/img.php?id=3250311&img=bg2.png)
Altec Lansing One Year Warranty Card
This warranty covers the original consumer purchaser only and is not transferable.
This warranty covers products that fail to function properly UNDER NORMAL USAGE, due to defects in material or workmanship. Your product will be repaired
or replaced at no charge for parts or labor for a period of one year.
What Is Not Covered by Warranty
Damages or malfunctions not resulting from defects in material or workmanship and damages or malfunctions from other than normal use, including but limited to,
repair by unauthorized parties, tampering, modification or accident.
To Obtain Warranty Service and Troubleshooting information:
Call 1-855-292-4087 or Visit our website at www.alteclansing.com.
To receive Warranty service along with the name and address of an authorized product service center, the original consumer purchaser must contact us for problem
determination and service procedures. Proof of purchase in the form of a bill of sale or receipted invoice, evidencing that the Product is within the applicable
Warranty period(s), MUST be presented in order to obtain the requested service. It is your responsibility to properly package and send any defective products along
with a dated copy of proof of purchase, a written explanation of the problem, and a valid return address to the authorized service center at your expense. Do not
include any other items or accessories with the defective product. Any products received by the authorized service center that are not covered by warranty will be
returned unrepaired.
NO WARRANTIES, WHETHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, ANY IMPLIED WARRANTIES OF
MERCHANT-ABILITY OR FITNESS FOR A PARTICULAR PURPOSE, OTHER THAN THOSE EXPRESSLY DESCRIBED ABOVE SHALL
APPLY. DISTRIBUTOR FURTHER DISCLAIMS ALL WARRANTIES AFTER THE EXPRESS WARRANTY PERIOD STATED ABOVE. NO
OTHER EXPRESS WARRANTY OR GUARANTY GIVEN BY ANY PERSON, FIRM OR ENTITY WITH RESPECT TO THE PRODUCT SHALL
BE BINDING ON DISTRIBUTOR. REPAIR, REPLACEMENT, OR REFUND OF THE ORIGINAL PURCHASE PRICE - AT DISTRIBUTOR'S
SOLE DISCRETION -ARE THE EXCLUSIVE REMEDIES OF THE CONSUMER. IN NO EVENT WILL DISTRIBUTOR, ITS MANUFACTURERS,
OR SAKAR INT. BE LIABLE FOR ANY INCIDENTAL, DIRECT, INDIRECT, SPECIAL, PUNITIVE OR CONSEQUENTIAL
DAMAGES (SUCH AS, BUT NOT LIMITED TO, DAMAGES FOR LOSS OF PROFITS, BUSINESS, SAVINGS, DATA OR RECORDS) CAUSED BY
THE USE, MISUSE OR INABILITY TO USE THE PRODUCT. EXCEPT AS STATED HEREIN, NO OTHER WARRANTIES SHALL APPLY.
NOTWITHSTANDING THE FOREGOING, CONSUMER'S RECOVERY AGAINST DISTRIBUTOR SHALL NOT EXCEED THE PURCHASE
PRICE OF THE PRODUCT SOLD BY DISTRIBUTOR. THIS WARRANTY SHALL NOT EXTEND TO ANYONE OTHER THAN THE ORIGI-
NAL CONSUMER WHO PURCHASED THE PRODUCT AND IS NOT TRANSFERABLE.
Some countries, states or provinces do not allow the exclusion or limitation of incidental or consequential damages or allow limitations on
warranties, so limitation or exclusions may not apply to you. This warranty gives you specic legal rights, and you may have other rights that
vary from state to state or province to province. Contact your authorized retailer to determine if another warranty applies. This product is
manufactured, distributed and sold by SAKAR International, Inc. All other trademarks are the property of the respective owner, who has not
sponsored, endorsed or approved this product.
This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference , and (2) this device must accept any
interference received, including interference that may cause undesired operation.
Caution: Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules, These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates. Uses and can radiate radio frequency energy and, if not installed and used in accordance with instructions.
May cause harmful interference to radio or -television reception, which can be determined by turning the equipment o and on, the user is encouraged to try to correct the interference by one
or more of the following measures:
__ Reorient or relocate the receiving antenna.
__ Increase the separation between the equipment and receiver.
__ Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.
__ Consult the dealer or experienced radio/ TV technician for help.
HEADPHONES
BLUETOOTH
Item # MZW300
Quick Start Guide
SOFT PADDED HEADBAND & EAR CUPS
Provides hours of listening comfort
EXTENDABLE HEADBAND
Extends for extra comfort
SOUND
Warm and rich bass sound that brings out the
best in music
DISPLAY
Displays battery life on iPhone or iPad
MICROPHONE
Conveniently built-in mic
SPECIFICATIONS
Drivers: 40mm
Frequency range: 20Hz-20kHz
BLUETOOTH
