ATI Electronics SH819 Bluetooth Earphones User Manual
ATI Electronics (Shenzhen) Co. Ltd Bluetooth Earphones
User Manual
Introduction
Thank you for purchasing the Vivitar 6+ Bluetooth® Earphones. You can use your earphones
with iPads, iPhones, iPods and many other types of smartphones and Bluetooth devices to stream
music and enjoy hands-free calling. Please read this manual carefully FIRST in order to get the most
out of your earphones.
Important Safety Precautions
When using your earphones basic safety precautions should always be followed, including the
following:
1. READ ALL INSTRUCTIONS BEFORE USING YOUR EARPHONES.
2. Never expose your earphones to water, excessive moisture, high temperatures, or extreme cold,
3. In order to avoid the risk of electric shock, never attempt to open your earphones or repair them
without the assistance of certified professionals.
4. Your earphones are not to be used by children or the infirm without suitable adult supervision.
5. Always press all buttons carefully. Do not manhandle your earphones.
6. Do not use your earphones at temperatures under 32°F (0°C) or over 104°F (40°C).
7. Do not drop your earphones, throw them, or subject them to strong impacts or physical trauma.
8. If you detect any abnormalities when using your earphones, contact the manufacturer for support.
In addition do not continue to use your earphones if you detect any leakage, smoke or fire.
9. If fluid from inside the battery gets in your eyes, do not rub your eyes. Wash your eyes with clean
water and immediately contact a physician.
10. When charging, do not place your earphones on flammable materials such as rugs, carpets or
bedding.
11. Your earphones are not intended for commercial use.
12. Use only the supplied chargers and cables. Unplug when not in use for long periods of time or
during lightning storms.
Risk of Fire and Burns.
Do Not Open, Crush, Heat Above 104°F (40°C) or Incinerate.
Always Follow All Manufacturer’s Instructions When Using.
CAUTION
Package Contents
1. Vivitar 6+ Bluetooth Earphones
2. USB Charging Cable
3. Owner’s Manual with Warranty Information
Features
- Bluetooth Technology Allows You to Listen to Music Wirelessly
- Built-In Microphone to Manage Phone Calls
- Rechargeable Battery
Specifications
• Bluetooth Specification: V3.0+EDR
• Operation Frequency: 2.402-2.48GHz
• Supported Profile: HSP, HFP, A2DP, AVRCP
• Operation Range: Up to 33 feet (10 meters)
• Talk Time: 2 hours
• Play Time: 2 hours
• Standby Time: 2 hours
• Battery Type: 70mAh, 3.7V, Polymer Lithium Ion Battery
• Charge Time: 2 Hours
A Quick Look at Your Earphones
① LED Indicator Light
② Microphone
③ Power / Play / Pause / Answer
④ Charging Port
④
①②③
Charging Your Earphones
Your earphones have a built-in, rechargeable lithium-polymer battery. To avoid damage, do not
attempt to remove the battery. The full performance of the battery is only achieved after two or three
charging-discharging cycles. Charge the battery fully before first use. To do so, follow the steps
below:
1. Connect one end of the included USB charging cable to the charging port on your earphones. Then
plug the other end of the USB charging cable into a USB port on your computer or a suitable power
adapter in order to recharge the internal rechargeable battery.
NOTE: The internal battery of your earphones takes approximately two hours to charge when
completely drained.
2. When the battery is charging, the LED indicator light will turn red. The LED indicator light will turn
off when the battery is fully charged.
NOTE: Overcharging could reduce the life of the battery. A charged battery will lose its capacity if it
is not used on a regular basis.
Important!
To avoid a complete discharge of the battery, charge your earphones at least once every six months.
Battery Notes
• A fully charged battery provides up to two hours of talk-time, two hours of music playback, and up to
two hours of standby time. However, the talk and standby times may vary with different Bluetooth
devices, usage settings, usage styles, and environments. When the battery power is low, the
headset will beep every 30 seconds and the red indicator light will flash.
Pairing Your Earphones with a Bluetooth Device
Your earphones can be paired with most Bluetooth devices including iPads, iPhones, iPod Touches,
and most smartphones, laptops and tablets. In order to pair your earphones with a phone, follow the
steps below:
1. Press and hold the "POWER" button for three seconds to turn on your earphones. The LED
indicator light will start alternately flash red and then blue repeatedly. This indicates that your
earphones are in pairing mode.
2. Go to the Bluetooth Manager of your Bluetooth device.
3. Search Bluetooth devices and select your speaker (most frequently listed as "Viv earphones") to
start connecting.
4. Enter "0000" if your device asks for the PIN code.
5. Once paired, the LED indicator light will slowly blink blue twice approximately every three seconds.
Note: If pairing is not completed within ten minutes, the earphones will turn off. If this happens, please
repeat the pairing steps above.
Using Your Earphones
Powering Your Earphones On and OFF
1. Press and hold the "POWER" button for three seconds to power on your earphones. If you have
already paired your earphones to your Bluetooth device, it will automatically remain paired each
time you power on your earphones.
2. Press and hold the "POWER" button for three seconds to turn power off your earphones.
Note: Your earphones will automatically power off when left idle for approximately ten minutes.
Listening to Music
• Play/Pause Button: Press to play or pause a track.
Note: You can adjust volume and playback settings
on your phone or connected audio device.
Play/Pause
Using the Phone Function
• Last Number Re-dial: Press the ANSWER button twice
to re-dial the last number called.
• Answering a Call: Quickly press the ANSWER button to
answer an incoming call.
• Reject an Incoming Call: Press and hold the ANSWER button for
two seconds to reject an incoming call.
• Ending a Call: Quickly press the ANSWER button to end a call.
Answer
Technical Support
For technical support issues please visit our website at www.vivitar.com. You can find manuals,
software and FAQ’s at the website. Can’t find what you are looking for? Fill out an online ticket and
one of our technical support team members will answer questions or call 1-800-592-9541 in the U.S.
or 0-800-917-4831 in the UK to access our technical support information on the phone.
FCC Statement
This device complies with the part 15 of the FCC rules. Operation is subject to the following two
conditions:(1)this device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
Caution: Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates.
Uses and can radiate radio frequency energy and, if not installed and used in accordance with
instructions may cause harmful interference to radio or -television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
__ Reorient or relocate the receiving antenna.
__ Increase the separation between the equipment and receiver.
__ Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
__ Consult the dealer or experienced radio/ TV technician for help.
EC Declaration of Conformity
Operation is subject to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that may cause undesired
operation.
Note: The manufacturer is not responsible for ANY interference, for example RADIO or TV
interference, caused by unauthorized modifications to this equipment. Such modifications could
void the user's authority to operate the equipment. This product is CE certified according to the
provision of the R&TTE Directive (99/5/EC). This declares that this product is in compliance
with the essential requirements and other relevant provisions of Directive 1999/5/EC. Please
note that this product uses radio frequency bands not harmonized within EU. Within the EU this
product is intended for use in Austria, Belgium, Denmark, Finland, France, Germany, Greece,
Ireland, Italy, Luxembourg, the Netherlands, Portugal, Spain, Sweden, and United Kingdom
and within EFTA in Iceland, Norway and Switzerland
Vivitar One Year Warranty Card
This warranty covers the original consumer purchaser only and is not transferable.
This warranty covers products that fail to function properly UNDER NORMAL USAGE, due to defects
in material or workmanship. Your product will be repaired or replaced at no charge for parts or labor
for a period of one year.
What Is Not Covered by Warranty
Damages or malfunctions not resulting from defects in material or workmanship and damages or
malfunctions from other than normal use, including but limited to, repair by unauthorized parties,
tampering, modification or accident.
To obtain Warranty Service and Troubleshooting information:
Call 1-800-592-9541 in the U.S. or 0-800-917-4831 in the UK or Visit our website at www.vivitar.com.
To receive Warranty service along with the name and address of an authorized product service
center, the original consumer purchaser must contact us for problem determination and service
procedures. Proof of purchase in the form of a bill of sale or receipted invoice, evidencing that the
Product is within the applicable Warranty period(s), MUST be presented in order to obtain the
requested service. It is your responsibility to properly package and send any defective products along
with a dated copy of proof of purchase, a written explanation of the problem, and a valid return
address to the authorized service center at your expense. Do not include any other items or
accessories with the defective product. Any products received by the authorized service center that
are not covered by warranty will be returned unrepaired.
NO WARRANTIES, WHETHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, ANY
IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE,
OTHER THAN THOSE EXPRESSLY DESCRIBED ABOVE SHALL APPLY. DISTRIBUTOR
FURTHER DISCLAIMS ALL WARRANTIES AFTER THE EXPRESS WARRANTY PERIOD STATED
ABOVE. NO OTHER EXPRESS WARRANTY OR GUARANTY GIVEN BY ANY PERSON, FIRM OR
ENTITY WITH RESPECT TO THE PRODUCT SHALL BE BINDING ON DISTRIBUTOR. REPAIR,
REPLACEMENT, OR REFUND OF THE ORIGINAL PURCHASE PRICE - AT DISTRIBUTOR’S
SOLE DISCRETION -ARE THE EXCLUSIVE REMEDIES OF THE CONSUMER. IN NO EVENT WILL
DISTRIBUTOR, ITS MANUFACTURERS, OR SAKAR INT. BE LIABLE FOR ANY INCIDENTAL,
DIRECT, INDIRECT, SPECIAL, PUNITIVE OR CONSEQUENTIAL DAMAGES (SUCH AS, BUT NOT
LIMITED TO, DAMAGES FOR LOSS OF PROFITS, BUSINESS, SAVINGS, DATA OR RECORDS)
CAUSED BY THE USE, MISUSE OR INABILITY TO USE THE PRODUCT. EXCEPT AS STATED
HEREIN, NO OTHER WARRANTIES SHALL APPLY. NOTWITHSTANDING THE FOREGOING,
CONSUMER’S RECOVERY AGAINST DISTRIBUTOR SHALL NOT EXCEED THE PURCHASE
PRICE OF THE PRODUCT SOLD BY DISTRIBUTOR. THIS WARRANTY SHALL NOT EXTEND TO
ANYONE OTHER THAN THE ORIGINAL CONSUMER WHO PURCHASED THE PRODUCT AND IS
NOT TRANSFERABLE.
Some countries, states or provinces do not allow the exclusion or limitation of incidental or
consequential damages or allow limitations on warranties, so limitation or exclusions may not apply to
you. This warranty gives you specific legal rights, and you may have other rights that vary from state
to state or province to province. Contact your authorized retailer to determine if another warranty
applies. This product is manufactured, distributed and sold by SAKAR International, Inc. All other
trademarks are the property of the respective owner, who has not sponsored, endorsed or approved
this product.
