ATI Electronics SH829 WIRELESS EARPHONES User Manual Print
ATI Electronics (Shenzhen) Co. Ltd WIRELESS EARPHONES Print
User Manual
QUICK START GUIDE * ITEM AEBTE
Important Safety Precautions
Risk of Fire and Burns.
Do Not Open, Crush, Heat Above 104°F (40°C) or Incinerate.
Always Follow All Manufacturer’s Instructions When Using.
CAUTION
When using your American Eagle Wireless Earphones, basic safety precautions should always be followed,
including the following:
1. READ ALL INSTRUCTIONS BEFORE USING YOUR EARPHONES.
2. Do not use your earphones near water. Clean using a dry or slightly moist cloth.
3. Do not place your earphones on any wet surfaces.
4. Do not allow children or the infirm to play with your earphones without adult supervision.
5. Do not expose your earphones to excessive heat, flames or fire.
6. Always press all buttons carefully. Do not manhandle your earphones.
7. Do not use in extremely dry environments, as this can lead to static discharge during usage.
8. Do not expose your earphones to temperatures above 40°C. Keep out of direct sunlight.
9. Do not attempt to repair this product yourself. Contact a qualified service center if your earphones
are in need of service.
10. Do not drop, puncture or expose your earphones to excessive trauma.
11. Your earphones are not intended for commercial use.
12. Do not place near objects that generate a strong magnetic field.
13. Use only the supplied charging cables. Unplug this device when not in use for long periods of time
or during lightning storms.
Introduction
Thank you for purchasing your American Eagle Outfitters Wireless Earphones, item AEBTE. You
can use your earphones with iPads, iPhones, iPods and many other types of smartphones and
Bluetooth devices to stream music and enjoy hands-free calling. In order to get the best results
when using this device, please read this manual first before using.
Package Contents
-American Eagle Outfitters AEBTE Wireless Earphones
-USB Charging Cable
-Quick Start Guide
Specifications
Bluetooth Specification: V3.0+EDR
Operation Frequency: 2.402-2.48GHz
Supported Profile: HSP, HFP, A2DP, AVRCP
Operation Range: Up to 33 feet (10 meters)
Play Time: ~2 hours*
Battery Type: 70mAh, 3.7V, Polymer Lithium Ion Battery
Charge Time: ~2 Hours
*Applicable at 60% of maximum volume. Results will be lower when volume is higher.
A Quick Look at Your Device
LED Indicator Light
Power / Play / Pause / Answer
Volume Down/Previous Track
Volume Up/Next Track
Charging Port
Microphone
Charging Your Earphones
Your earphones have a built-in, rechargeable lithium-polymer battery. To avoid damage, do not
attempt to remove the battery. The full performance of the battery is only achieved after a few
charging-discharging cycles. Charge the battery fully before first use. To do so, follow the steps
below:
1. Connect one end of the included USB charging cable to the charging port on your earphones.
Then plug the other end of the USB charging cable into a USB port on your computer or a
suitable power adapter in order to recharge the internal rechargeable battery.
NOTE: The internal battery of your earphones takes approximately two hours to charge when
completely drained.
2. When the battery is charging, the LED indicator light will turn red. The LED indicator light will
turn off when the battery is fully charged. Unplug when charging is complete.
NOTE: Overcharging could reduce the life of the battery. A charged battery will lose its capacity
if it is not used on a regular basis.
Important!
To avoid a complete discharge of the battery, charge your earphones at least once every six
months.
Pairing Your Earphones with a Bluetooth
Device
Your earphones can be paired with most Bluetooth devices including iPads, iPhones, iPod
Touches, and most smartphones, laptops and tablets. In order to pair your earphones with a
phone, follow the steps below:
1. Press and hold the “POWER” button until your earphones turn on. The LED indicator light will
start alternately flashing red and then blue repeatedly. This indicates that your earphones are in
pairing mode.
2. Go to the Bluetooth Manager of your Bluetooth device.
3. Search Bluetooth devices and select “AE Earphone” to start connecting.
4. Enter “0000” if your device asks for the PIN code.
5. Once paired, the LED indicator light will slowly blink blue every three seconds.
Note: If pairing is not completed after an extended period of time, the earphones will power off. If
this happens, repeat the pairing steps above.
Using Your Earphones
Powering Your Earphones On and OFF
1. Press and hold the “POWER” button for 3 seconds to power on your earphones. If you have
already paired your earphones to your Bluetooth device, they will automatically remain paired
each time you power on your earphones.
2. Press and hold the “POWER” button for 5 seconds to power off your earphones.
Listening to Music
• Play/Pause Button: Press to play or pause a track.
• Quickly tap the “NEXT TRACK/VOLUME UP” button to increase the volume.
• Quickly tap the “PREVIOUS TRACK/VOLUME DOWN” button to decrease
the volume.
• Press and hold the “NEXT TRACK/VOLUME UP” button to advance to
the next song in a playlist.
• Press and hold the “PREVIOUS TRACK/VOLUME DOWN” button to go
back to the previous song in a playlist.
Note: You can also adjust volume and playback settings on your phone.
Using the Phone Function
• Last Number Re-dial: Press the ANSWER button twice to re-dial
the last number called.
• Answering a Call: Quickly press the ANSWER button to answer an
incoming call.
• Reject an Incoming Call: Press and hold the ANSWER button to reject
an incoming call.
• Ending a Call: Quickly press the ANSWER button to end a call.
Answer
Volume Up
Volume Down
Microphone
Volume Up
Next Track
Volume Down
PreviousTrack
Maintenance and Care
-Before using your earphones, examine the ear cups to make sure that they are clean. Similarly,
inspect any ports on your earphones to make sure that they are clear of dust and debris before
charging.
-Use a soft cloth or paper towel to clean earphones. Do not allow moisture to get inside the ear
cups. Never use any harsh chemicals or detergents for cleaning. Make sure your earphones are
dry before using.
-When your earphones are not in use, they should be stored in a cool, dry place.
-Never tug or yank on the USB cable while it is connected to your earphones. Connect and
disconnect cables as carefully as possible.
-Never expose your earphones to high temperatures, extreme cold, high humidity or excessive
moisture or water.
-Please recycle or dispose of your earphones properly based on the laws and rules of your
municipality. Contact local recycling facilities and/or the manufacturer of your earphones for
further information.
FCC Statement
Changes or modifications not expressly approved by the party responsible for compliance could
void the user’s authority to operate the equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-- Consult the dealer or an experienced radio/TV technician for help.
EC Declaration of Conformity
Operation is subject to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that may cause
undesired operation.
Note: The manufacturer is not responsible for ANY interference, for example RADIO or TV
interference, caused by unauthorized modifications to this equipment. Such modifications could
void the user's authority to operate the equipment. This product is CE certified according to the
provision of the R&TTE Directive (99/5/EC). This declares that this product is in compliance with
the essential requirements and other relevant provisions of Directive 1999/5/EC. Please note that
this product uses radio frequency bands not harmonized within EU. Within the EU this product is
intended for use in Austria, Belgium, Denmark, Finland, France, Germany, Greece, Ireland, Italy,
Luxembourg, the Netherlands, Portugal, Spain, Sweden, and United Kingdom and within EFTA in
Iceland, Norway and Switzerland.
TECHNICAL SUPPORT
If You’re Having Trouble, We’re Here to Help!
Call us 24/7 at 1-877-397-8200
This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject
to the following two conditions: (1) this device may not cause interference, and (2) this device
must accept any interference, including interference that may cause undesired operation of the
device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio
exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne
doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage
radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement.
