ATI Electronics SP424 Bluetooth Speaker User Manual

ATI Electronics (Shenzhen) Co. Ltd Bluetooth Speaker

User Manual

① ② ③④⑤
user's authority to operate the equipment. This product is CE cerfied according to the
provision of the R&TTE Direcve (99/5/EC). This declares that this product is in compliance
with the essenal requirements and other relevant provisions of Direcve 1999/5/EC. Please
note that this product uses radio frequency bands not harmonized within EU. Within the EU
this product is intended for use in Austria, Belgium, Denmark, Finland, France, Germany,
Greece, Ireland, Italy, Luxembourg, the Netherlands, Portugal, Spain, Sweden, and United
Kingdom and within EFTA in Iceland, Norway and Switzerland.
Locaon of Controls
① Power / Play / Pause
Answer/Indicator LED
② LED buon
③ Charging Port
④ Microphone
⑤ Auxiliary Port
First Time Use
Charging the Baery
The VU60014BT Speaker has a built-in, rechargeable lithium-polymer baery. To avoid damage, do
not aempt to remove the baery. The full performance of the
baery is achieved aer two or three
charging-discharging cycles. Charge the
baery fully before first use.
1. Connect the USB cable to the speaker.
2. Connect to the correct outlet (wall,
computer, car charger).
3. When the charger is connected to the
speaker, the red indicator light will turn on.
Note: Charging the baery fully may take up to 2 hours.
4. When the baery is fully charged, the red indicator light will
turn off. Disconnect the charger from the speaker and the outlet. The speaker is ready for use.
any other apparatus that produces heat. This may cause an explosion, degrade the performance
and/or reduce baery life.
• Do not modify, repair or disassemble device (especially the baery). Doing so will void the warranty.
The baery in this device may present a risk of fire or chemical burns if misused or tampered with.
• Use only supplied and manufacturer-approved chargers and unplug this device when not in use for
long periods of me or during lightning storms.
FCC Statement
This device complies with the part 15 of the FCC rules. Operaon is subject to the following two
condions: (1) this device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operaon.
Cauon: Changes or modificaons not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protecon
against harmful interference in a residenal installaon. This equipment generates. Uses and can
radiate radio frequency energy and, if not installed and used in accordance with instrucons
may cause harmful interference to radio or -television recepon, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
__ Reorient or relocate the receiving antenna.
__ Increase the separaon between the equipment and receiver.
__ Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
__ Consult the dealer or experienced radio/ TV technician for help.
EC Declaraon of Conformity
Operaon is subject to the following two condions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that may cause undesired
operaon.
Note: The manufacturer is not responsible for ANY interference, for example RADIO or TV interference,
caused by unauthorized modificaons to this equipment. Such modificaons could void the
Thank you for purchasing the Vivitar® VU60014BT Bluetooth® Speaker.
Introducon
With this speaker, you will enjoy listening to high quality music wirelessly using Bluetooth®
technology. Easily connect to any mobile device for music listening. It also can pair with other
Bluetooth-enabled devices.
Specificaons
• Bluetooth Specificaton: V3.0
• Operaon Frequency: 2.402-2.48GHz
• Supported Profile: HSP, HFP, A2DP, AVRCP
• Operaon Range: Up to 33 feet(10 meters)
• Talk Time: About 4 hours
• Play Time: About 4 hours
• Standby Time: About 20 hours
• Baery Type: 400mAh, 3.7V, Polymer Lithium Ion Baery
• Charge Time: About 2 Hours
In the Box
• VU60014BT Bluetooth® Speaker
• USB Charging Cable
• User Manual
Safety Precauons
• Please read this User Manual carefully and follow all instrucons.
• To avoid damage or malfuncon of the speaker do not drop it from high locaons and/or on to
hard surfaces, do not place heavy objects on it.
• Keep speaker away from humidity, water and other liquids. If it does get wet, do not operate as this
may cause an electrical shock, explosion and damage to the device or to the user.
• Do not place or keep this product near heat sources, such as direct sunlight, radiators, stoves or
Vivitar® VU60014BT Bluetooth® Speaker
User Manual
the applicable Warranty period(s), MUST be presented in order to obtain the requested service. It is
your responsibility to properly package and send any defecve products along with a dated copy of
proof of purchase, a wrien explanaon of the problem, and a valid return address to the authorized
service center at your expense. Do not include any other items or accessories with the defecve
product. Any products received by the authorized service center that are not covered by warranty
will be returned unrepaired.
Vivitar One yea r Wa rranty (connued)
NO WARRANTIES, WHETHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, ANY IMPLIED
WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, OTHER THAN THOSE
EXPRESSLY DESCRIBED ABOVE SHALL APPLY. DISTRIBUTOR FURTHER DISCLAIMS ALL WARRANTIES
AFTER THE EXPRESS WARRANTY PERIOD STATED ABOVE. NO OTHER EXPRESS WARRANTY OR
GUARANTY GIVEN BY ANY PERSON, FIRM OR ENTITY WITH RESPECT TO THE PRODUCT SHALL BE
BINDING ON DISTRIBUTOR. REPAIR, REPLACEMENT, OR REFUND OF THE ORIGINAL PURCHASE PRICE -
AT DISTRIBUTOR’S SOLE DISCRETION -ARE THE EXCLUSIVE REMEDIES OF THE CONSUMER. IN NO
EVENT WILL DISTRIBUTOR, ITS MANUFACTURERS, OR SAKAR INT. BE LIABLE FOR ANY INCIDENTAL,
DIRECT, INDIRECT, SPECIAL, PUNITIVE OR CONSEQUENTIAL DAMAGES (SUCH AS, BUT NOT LIMITED
TO, DAMAGES FOR LOSS OF PROFITS, BUSINESS, SAVINGS, DATA OR RECORDS) CAUSED BY THE USE,
MISUSE OR INABILITY TO USE THE PRODUCT. EXCEPT AS STATED HEREIN, NO OTHER WARRANTIES
SHALL APPLY. NOTWITHSTANDING THE FOREGOING, CONSUMER’S RECOVERY AGAINST DISTRIBUTOR
SHALL NOT EXCEED THE PURCHASE PRICE OF THE PRODUCT SOLD BY DISTRIBUTOR. THIS WARRANTY
SHALL NOT EXTEND TO ANYONE OTHER THAN THE ORIGINAL CONSUMER WHO PURCHASED THE
PRODUCT AND IS NOT TRANSFERABLE.
Some countries, states or provinces do not allow the exclusion or limitaon of incidental or
consequenal damages or allow limitaons on warranes, so limitaon or exclusions may not apply
to you. This warranty gives you specific legal rights, and you may have other rights that vary from
state to state or province to province. Contact your authorized retailer to determine if another
warranty applies. This product is manufactured, distributed and sold by SAKAR Internaonal, Inc. All
other trademarks are the property of the respecve owner, who has not sponsored, endorsed or
approved this product.
LED Buon
Power / Answer
Play / Pause
Power / Answer
Play / Pause
Music Playback
• Play/Pause buon: Press to play or pause music playback.
Using the Phone Funcon
• Last Number Re-dial: In standby mode, press the ANSWER
buon twice to re-dial the last number called.
• Answering a Call: Short press the ANSWER buon to
answer an incoming call.
• Reject an Incoming Call: Press and hold the ANSWER
buon for two(2) seconds to reject an incoming call.
• Ending a Call: Short Press the ANSWER buon to end a
call.
LED mode switch
Press LED buon to switch the flashing paerns in sequences of
wave, de, breath, dancing style in circularly.
Vivitar One year Warranty
This warranty covers the original consumer purchaser only and
is not transferable.
This warranty covers products that fail to funcon properly UNDER NORMAL USAGE, due to defects in
material or workmanship. Your product will be repaired or replaced at no charge for parts or labor for a
period of one year.
What Is Not Covered by Warranty
Damages or malfuncons not resulng from defects in material or workmanship and damages or
malfuncons from other than normal use, including but limited to, repair by unauthorized pares,
tampering, modificaon or accident.
To obtain Warranty Service and Troubleshoong informaon:
Call 1-800-592-9541 in the U.S. or 0-800-917-4831 in the UK or Visit our website at www.vivitar.com.
To receive Warranty service along with the name and address of an authorized product service center,
the original consumer purchaser must contact us for problem determinaon and service procedures.
Proof of purchase in the form of a bill of sale or receipted invoice, evidencing that the Product is within
Note: Overcharging could reduce the life of the baery. A charged baery will lose its capacity if it is
not used on a regular basis.
Important!
Ensure that the baery is fully charged if the speaker is not used for a long period of me. To avoid a
complete discharge of the baery, charge the speaker at least every six(6) months.
Baery Notes
• A fully charged baery provides up to four(4) hours of talk-me, four(4) hours music playback, and
up to twenty(20) hours of standby me. Talk and standby mes vary depending on mobile phones
or other compable Bluetooth® devices, sengs, styles, etc.
• When the baery power is low, the speaker will beep every 30 seconds.
• When using with your iPhone, an addional baery meter feature will display the remaining
baery on your phone’s touch screen.
Pairing with your Phone
1. Place the speaker in close range of a Bluetooth enabled mobile phone.
2. Press and hold POWER buon for three(3) seconds. unl you hear the prompt tone, the indicator
lights will blink blue once one(1) second.
3. Set your mobile phone to pairing mode (as explained in operang instrucons for your phone) and
search for Bluetooth devices.
4. Select "Lite Cube" from the list shown on your phone.
5. If requested, enter the PIN code "0000" and confirm the entry. Once the pairing is successful, the
VU60014BT connects to your phone automacally before switching to standby mode. The
indicator will blink blue once every six(6) seconds.
Note: If pairing is not completed within ten(10) minutes, the speaker will turn off. If this happens,
repeat the pairing steps above.
General Operaon
Turning ON/OFF
1. Press and hold the POWER buon for three(3) seconds to turn the speaker ON. If pairing was
successful (instrucons above), the speaker will remain paired to your mobile device.
2. Press and hold the POWER buon for three(3) seconds to turn the speaker OFF.
Note: The speaker will turn OFF automacally when not connected to a mobile device for
approximately ten(10) minutes.
