ATI Electronics SP812 Bluetooth Speaker User Manual
ATI Electronics (Shenzhen) Co. Ltd Bluetooth Speaker
User Manual
Front Back
① ② ③④⑤ ⑥
Note: The manufacturer is not responsible for ANY interference, for example RADIO or TV
interference, caused by unauthorized modificaons to this equipment. Such
modificaons could void the user's authority to operate the equipment.
Locaon of Controls
① Microphone
② Indicator LED
③ Previous Track / Volume –
④ Power / Play / Pause / Answer
⑤ Next Track / Volume +
⑥ Charging Port
First Time Use
Charging the Baery
The VZ60023BT Speaker has a built-in, rechargeable lithium-polymer baery. To avoid damage,
do not aempt to remove the baery. The full performance of the baery is achieved aer two
or three charging-discharging cycles. Charge the baery fully before first use.
1. Connect the USB cable to the speaker.
2. Connect to the correct outlet (wall, computer, car charger).
3. When the charger is connected to the speaker, the red indicator light will turn on.
Note: Charging the baery fully may take up to 2 hours.
4. When the baery is fully charged, the red indicator light will turn off. Disconnect the charger
from the speaker and the outlet. The speaker is ready for use.
Note: Overcharging could reduce the life of the baery. A charged baery will lose its capacity
if it is not used on a regular basis.
Important!
Ensure that the baery is fully charged if the speaker is not used for a long period of me. To
avoid a complete discharge of the baery, charge the speaker at least every six(6) months.
Baery Notes
• A fully charged baery provides up to six(6) hours of talk-me, four(4) hours music playback,
and up to ten(10) hours of standby me. Talk and standby mes vary depending on mobile
phones or other compable Bluetooth® devices, sengs, styles, etc.
• When the baery power is low, the speaker will beep every 30 seconds.
• When using with your iPhone, an addional baery meter feature will display the remaining
baery on your phone’s touch screen.
Thank you for purchasing the Vivitar® VZ60023BT Bluetooth® Speaker.
Introducon
With this speaker, you will enjoy listening to high quality music wirelessly using Bluetooth®
technology. Easily connect to any mobile device for both conversaon and music listening. It
also pairs with other Bluetooth-enabled devices (Bluetooth V3.0+EDR specificaon and HSP,
HFP, A2DP and AVRCP profiles).
Specificaons
• Bluetooth Specificaon: V3.0+EDR
• Operaon Frequency: 2.402-2.48GHz
• Supported Profile: HSP, HFP, A2DP, AVRCP
• Operaon Range: Up to 33 feet(10 meters)
• Rated Input: 5V 500mA
• Baery Type: 1000mAh, 3.7V, Polymer Lithium Ion Baery
In the Box
• VZ60023BT Bluetooth® Speaker
• USB Charging Cable
• User Manual
Safety Precauons
• Please read this User Manual carefully and follow all instrucons.
• To avoid damage or malfuncon of the speaker do not drop it from high locaons and/or on
to hard surfaces, do not place heavy objects on it.
• Keep speaker away from humidity, water and other liquids. If it does get wet, do not operate
as this may cause an electrical shock, explosion and damage to the device or to the user.
• Do not place or keep this product near heat sources, such as direct sunlight, radiators, stoves
or any other apparatus that produces heat. This may cause an explosion, degrade the
performance and/or reduce baery life.
• Do not modify, repair or disassemble device (especially the baery). Doing so will void the
warranty. The baery in this device may present a risk of fire or chemical burns if misused or
tampered with.
• Use only supplied and manufacturer-approved chargers and unplug this device when not in
use for long periods of me or during lightning storms.
FCC Statement
This device complies with part 15 of the FCC rules, operaon is subject to the following two
condions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that may cause
undesired operaon.
Vivitar® VZ60023BT Bluetooth® Speaker
User Guide
Warranty Informaon
This warranty is non-transferable and is limited only to the original purchaser. The condions of this
warranty and supplier's responsibilies under this warranty are as follows:
• You must be able to prove the date of original purchase of the unit with a dated receipt.
• The warranty is not applicable if the product has been subject to physical abuse, improper
installaon, modificaon or repair by an unauthorized third party.
• Supplier's responsibility shall be limited to the repair or replacement of the product at its sole
discreon.
• Specifically exempt from any warranty are limited-life consumable components subject to normal
wear and tear such as baeries, decorates and other accessories.
• Supplier is not responsible, for failure resulng from accident, abuse, misuse, or any unauthorized
repair, or modificaon.
• Modificaon and repair of the unit should be done by an authorized and qualified service center
or returned to the manufacturer.
• This warranty gives you specific legal rights, and you may also have other rights, which vary under
local laws.
What is Covered
This warranty covers for the original consumer purchaser only and is not transferable. Products that
fail to funcon properly UNDER NORMAL USAGE, due to defects in material or workmanship will be
repaired at no charge for parts or labor for a period of one year from the me of purchase.
What is NOT Covered
Damages or malfuncons not resulng from defects in material or workmanship and damages or
malfuncons from other than normal use, including but limited to, repair by unauthorized pares,
tampering, modificaon or accidents.
Service and Returns
When returning a defecve product (postage pre-paid) for service, the package should include:
1. Copy of original bill of sale.
2. A detailed wrien descripon of the problem.
3. Your return address and telephone number (Dayme).
Where to send defecve products
United States United Kingdom / Europe Australia
Sakar Internaonal Sakar Internaonal Return faulty device to the
Aenon: Service Department Aenon: Service Department Refund Counter at the store
195 Carter Drive 2D, Siskin Parkway East where the product was
Edison, NJ 08817 4020 Middlemarch Business Park purchased.
Coventry, CV3 4SU
Technical Support
For technical support issues, visit our website at www.vivitar.com. Manuals, soware and FAQ's are
available on line. If you can’t find what you are looking for, e-mail us at support@vivitar.com where
one of our technical support team members will help you. US phone: 1-800-592-9541; UK phone:
0800 917 4831; Australia phone: 1800-006-614. Telephone numbers from other countries can be
found at: www.vivitar.com.
Previous Track / Volume –
Microphone
Power / Play / Pause /
Answer / Switch LED Mode
Power / Play / Pause /
Answer / Switch LED Mode
Next Track / Volume +
Next Track / Volume +
Pairing with your Phone
1. Place the speaker in close range of a Bluetooth®-enabled mobile phone.
2. Press and hold POWER buon for three(3) seconds. Unl indicator lights flash blue and red.
3. Set your mobile phone to pairing mode (as explained in operang instrucons for your
phone) and search for Bluetooth® devices.
4. Select "Acrylic speaker" from the list shown on your phone.
5. If requested, enter the PIN code "0000" and confirm the entry. Once the pairing is successful,
the VZ60023BT connects to your phone automacally before switching to standby mode. The
indicator will blink blue once every four(4) seconds.
Note: If pairing is not completed within ten(10) minutes, the speaker will turn off. If this
happens, repeat the pairing steps above.
General Operaon
Turning ON/OFF
1. Press and hold the POWER buon for three(3) seconds to turn the speaker ON. If pairing was
successful (instrucons above), the speaker will remain paired to your mobile device.
2. Press and hold the POWER buon for five(5) seconds to turn the speaker OFF.
Note: The speaker will turn OFF automacally when not connected to a mobile device for
approximately ten(10) minutes.
Music Playback
• Play/Pause buon: Press to play or pause music
playback. Double press to switch the LED mode
when playing music.
• Next Track / Volume + buon: Press to increase
sound level. Press and hold to skip to the next
track.
• Previous Track / Volume - buon: Press to decrease the
sound level. Press and hold to return to the previous
track.
Using the Phone Funcon
In standby mode, press the ANSWER buon twice to re-dial the last number called.
• Answering a Call: Short press the ANSWER buon to answer an incoming call.
• Reject an Incoming Call: Press and hold the ANSWER buon for two(2) seconds to reject an
incoming call.
• Transferring a Call: Press and hold Next Track / Volume + buon for two(2) seconds to
transfer a call from the phone to speaker.
• Ending a Call: Short Press the ANSWER buon to end a call.
