ATake Digital Technology ASP-792 Frisbee Bluetooth Speaker User Manual
ATake Digital Technology (ShenZhen) Co., Ltd. Frisbee Bluetooth Speaker
User Manual
INSTRUCTION MANUAL
Music Frisbee Bluetooth Speaker
1.
About
Frisbee
Bluetooth
Speaker
With Bluetooth wireless technology, the Music
Frisbee enables you to connect between
Smartphone, PC notebook, iPad, or portable handheld devices within 32 feet.
You can enjoy all your music anywhere with your friends.
This music frisbee speaker uses a new generation of amplifiers and you will be
surprised
by the incredible sound
from such a small device!
2.
Getting
to
Know
Your
Music Frisbee Bluetooth
Speaker
PRODUCT
ILLUSTRAION
3.
Getting
Started
To
use
the
Bluetooth
speaker,
please
follow
these
simple
steps:
(a)Prior
to
using
the
speaker,
it
is
recommended
to
charge
the
battery
fully
for
the
first
time.
(b)Use
the provided
magnetic charging
cable
to
connect
the
speaketoany
computer
with
USB
port.After
completion
of
charge,
please
remove
the
cable
fromspeaker.
(c)
Make sure the speaker and your Bluetooth-enabled device
such
as
your
smart
phone
or
Tablet is
nomore
than3 feet
away
for
the
initial
pairing
process.
(d)
Once
paired,
ensure
your
speaker
and
your
Smartphone
is
always
within
a
32 feet
Bluetooth
sensing
distance.
(Obstructions
could
cause
shorter
sensing
distance.)
Note:
-
Charge
indication:
When
charge
is
in
process,
the
charging
indicator
light
will
be
red.
When
the
charge
is
completed,
the
charging
indicator
will
turn
off.
-
Low
battery
indication:
A voice alert of “low battery, please charge” appears when the battery is getting low.
It’s
recommended
to
charge
the
speaker
immediately
to
prolong
durability
of
battery
and
standby
time.
When
the
speaker
has
a
low
battery
status,
if
the
battery
is
not
charged
within
a
certain
time,
the
speaker
will
switch
itself
off.
4.
Turning
the
speaker
On/Off
Turning
On:
Press
and
hold
the button
for
4
seconds,
you
will
hear a beep.
The
Standby
indicator
light
will
flash
.
Turning
Off:
Speaker
is
under
standby
mode
or
running
mode:
Press
and
hold
the
button
for
4
seconds,
you
will
hear
a beep.
All
standby
indicator
lights
will
be
turned
off.
5.
Pairing
Prior
to
using
the
speaker
for
the
first
time,
you
must
pair
it
with
a
Bluetooth-enabled
device,
eg.
your
Smartphone,
iPad,
iPhone
etc.
The
following
steps
describe the
pairing
process
for
a
typical
Bluetooth-enabled
devices.
(a)
Turn
on
the
speaker and it’s ready for pairing automatically
.
(b)
Activate
your
Smartphone's
Bluetooth
function,
the
Smartphone
will
search
for
accessible
Bluetooth
devices.
(For
details,
please
refer
to
the
user
guide
of
the
Smartphone)
(c)
Select
"792”
from
the
searching
list of Bluetooth device
and
press
to
pair
the
speaker
(d)
Some
Bluetooth
smart
phones
or
devices
will
ask
for
a
passkey,
please
enter
“0000”
（
4 zeros
）
and
press
“OK”
to
pair
the
speaker.
(e)
When
pairing
is
completed,
you
will
hear
3 continuous beepsand the 3 LED lights will be on.
Now
the
speaker
is
ready
for
use
and
in
standby
mode.
(f)
You
should
now
be
able
to
use
the
wireless
speaker
to
play
the
music.
Please
place
your
Bluetooth
device
within
32 feet
of
the
speaker.
(Obstructions
could
cause
shorter
sensing
distance.)
6.
Operate
the
Speaker
Once
pairing
is
completed
and
battery
is
fully
charged,
you
may
access
the
following
functions.
(a)
Play
/
Pause
the
music:
Short
press
the
PLAY
button
to
pause
and
re-play
music
Smartphone
or
you
can
do
it
via
your
Smartphone
in
the
normal
way.
(b)
Adjusting
the
Volume:
During
speaker
playing,
press
"－"
the
reduce
volume
button
and
"
＋
"
the increase
volume
button
repeatedly
until
you
reach
the
desiredvolume
level. Adjust via your smartphone for
louder volume.
NOTE:
Volume
level
of
your
Smartphone
is
controled
by
the
Smartphone,
volume
control button
of
speaker
will
not
control
your
Smartphone
volume
level.
7.
Safety
Cautions
&
Maintenance
(a)
Do
not
charge
the
speaker
with
other
unsuitable
AC/DC
power
adaptor,
it
may
cause
damage
to
the
speaker.
The
speaker
must
be
charged
properly
by
USB
ports
or
by
a
AC/DC
adaptor
with
Input:
AC100-240V,50-60Hz
Output:
DC
5V
.
(b)
Stop
using
the
speaker
and
switch
on
the
speaker
immediately,
if
you
find
any
overheating
situation,
strange
noise
and
strange
working
performance
during
use
(c)
Do
not
use
abrasive
cleaning
solvents
to
clean
the
speaker.
(d)
Do
not
place
the
speaker
in
high
temperature,
as
it
will
result
in
an
explosion.
(e)
Do
not
expose
the
speaker
to
contact
with
sharp
objects
as
this
will
cause
scratching
and
damage.
(f)
Do
not
stick
anything
inside
the
speaker
or
front
panel
as
this
may
damage
internal
components.
(g)
Do
not
attempt
to
disassemble
the
speaker,
as
it
does
not
contain
serviceable
components.
(h)
If
you
do
not
use
the
speaker
for
long
periods,
be
sure
to
store
it
in
a
dry
place,
free
from
extreme
temperature,
humidity
and
dust.
SAFETY
REMINDER:
(a)
Observe
all
signs
that
require
an
electrical
device
or
RF
radio
product
to
be
switched
off
in
the
designated
areas.
These
could
include
hospitals,
blasting
areas,
and
potentially
explosive
atmospheres.
(b)
Turn
off
your
speaker
and
Bluetooth
signal
prior
to
boarding
an
aircraft.
Do
not
use
your
speaker
in
an
aircraft.
(c)
Never
mount
or
store
your
speaker
over
any
air
bag
deployment
area.
Serious
injury
may
be
resulted
when
an
air
bag
deploys.
8. Troubleshooting
If you are unable to connect your speaker and your Smartphone, please try the following:
(a)
Ensure
the
speaker
is
paired
with
your
Smartphone by the steps in section 5,“Pairing”.
(b)
Ensure
your
Smartphone’s
Bluetooth
feature
is
activated.
Please
refer
to
your
Smartphone
user
guide
for
specific
instruction.
(c)
Ensure
the
speaker
is
within
a
maximum
of
32 feet
of
your
mobile
device
and
there
are
no
obstructions,
such
as
thick
solid
wall
or
other
electronic
devices
in
between
as
it
may
cause
shorter
or
interference
transmission.
(d)
If
all
the
above
steps
do
not
resolve
your
problem,
please
turn
off
the
speaker
for
a
while.
(e)
If
you
are
not
able
to
link
up
with
Bluetooth,
please
check
whether
any
other
devices
are
connecting
with
the
Bluetooth
speaker,
or
the
speaker
did
not
link
up
the
audio
and
media
channel
of
the
devices
after
pairing.
NOTE: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help
Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment. This device complies with Part
15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may
cause undesired operation.
