BGR135C_Boarding_Gate_Reader_with_NFC_Datasheet
![](/img.php?id=2374852&img=bg1.png)
Access IS
18 Suttons Business Park
Reading, Berkshire
RG6 1AZ, United Kingdom
Tel: +44 (0) 118 966 3333
Fax: +44 (0) 118 926 7281
Access (North America) inc
Atlanta
Georgia
USA
Tel: +1-770-645-2771
For further information email: sales@access-is.com or visit our website: www.access-is.com
All trademarks acknowledged. Specications subject to change without prior notice. This literature is for outline information only.
The BGR135C reading a contactless frequent yer card
Compact, rugged, 2D BCBP and NFC boarding gate
solution with receipt printing port.
BGR135C 2D BCBP and
Contactless Boarding Gate Reader
Description
The BGR135C is a compact boarding gate reader for 2D
barcoded boarding passes (BCBP’s), with contactless
functionality for NFC-enabled phones, PDA’s and smart
cards. In addition the BGR135C includes a receipt printing
port and an integrated on/off switch.
The BGR135C reads barcodes face up, enabling
operators to more quickly align barcodes to the reader
interface. Speed of transaction is also enhanced by
near-zero latency in the omnidirectional imager, so that
barcodes are read instantly on presentation.
Additional features to ensure fast passenger processing
include 2 x 16 character interface to clearly display
passenger information, bright green and red LED visual
indicators, and a user-programmable audio beep to
conrm successful data capture.
A wide range of emulations is available for connection to
Common Use Terminal Equipment (CUTE®) or dedicated
systems. Additionally, to ensure that the units are future-
proof, new rmware can be remotely downloaded to them.
Housed in an attractive ABS enclosure, the BGR135C is
rugged, very compact and lightweight. Its quality-assured
UK manufacture ensures it will withstand years of frontline
use.
Features
• Fast, omnidirectional 1D/2D barcode imager
• Contactless and NFC-enabled
• Bright VFD 2 x 16 character display
• Reads on presentation of a document
• Reads IATA-recommended PDF417, 2D and linear
symbologies
• Large document throat allows A4/full-page documents
to be read
• Reads 2D barcode images on PDA and smartphone
displays
• Wide range of emulations available
• Single RS-232 cable connection to host
• FLASH upgradeable software
• Green and red indicator beacons and audio beeper
• Additional RJ45 port for receipt printer functionality
• Integrated on/off switch
Options
• Quick release bracket
• Integrated SAM module
The BGR135C has
NFC read capability
![](/img.php?id=2374852&img=bg2.png)
Access IS
18 Suttons Business Park
Reading, Berkshire
RG6 1AZ, United Kingdom
Tel: +44 (0) 118 966 3333
Fax: +44 (0) 118 926 7281
Access (North America) inc
Atlanta
Georgia
USA
Tel: +1-770-645-2771
For further information email: sales@access-is.com or visit our website: www.access-is.com
All trademarks acknowledged. Specications subject to change without prior notice. This literature is for outline information only.
BGR135C 2D BCBP and NFC boarding gate reader specications
Passenger/agent displays
Display: Bright VFD 2 x 16 characters
Visible/audible: Green (good read) and
red (bad read) indicator beacons and
audio beeper. Programmable capability
Interface
USB interface
Host interface: RS-232C Baud rates
9600, 19200, 38400 & 115200
Other: RJ45 port for optional RP9000
receipt printer, keypad or auto boarding
gate applications
The receipt printer can print seat, ight
and passenger data from M1 format bar
code documents
Physical characteristics
Dimensions: 130W x 142H (excluding
rubber feet 6 mm) x 185D mm
Weight: 850 g
Barcode reader
Compliance: AEA2008
1D symbologies: Code 128, Code
2 of 5, Interleaved 2 of 5, IATA 2 of 5,
Code 39, EAN
2D symbologies: IATA resolution 792,
PDF417, Aztec, Datamatrix and QR
codes. Will also read from PDA and
smartphone displays
Performance: Less than 1 second read
capability
Construction: Compact and durable
ABS enclosure with no moving parts
Contactless RF reader
Compliance: Supports ISO 14443 and
ISO 8092 protocols: ISO 14443 type A
& B tags; MIFARE classic; FeliCa tags;
NFC type 1 tags
Operating frequency: 13.56 MHz
Operating distance: 20 mm
SAM support
1 x ISO 7816 T=0 protocol slot available
Power supply
Input voltage: 9-15 VDC; AC universal
power adapter supplied
Protocols supported (pending)
ARINC Muse & iMuse ®
RESA CREWS ®
SABRE EGR ®
SITA CUTE ® NT and APC
Ultra CUSE®
Environmental
Temperature:
Operating 0 °C to +50 °C;
storage 0 °C to +60 °C
Humidity: 0 to 95%, non-condensing
® All trademarks acknowledged
Ver: 1.6 November 2013
The BGR135C reads 2D barcodes from the
screen of a mobile phone
The BGR135C reads 2D barcodes from a
home printed travel document
The BGR135C reads NFC-enabled
phones and NFC tags
