Acer Incorporated Tablet Computer User Guide

Manual Example 3

Product overview
123 9
10
7
8
6
5
4
1. Audio jack
2. HDMI port
3. Micro USB port
4. Front camera
5. microSD card slot
6. Touchscreen
7. Power button
8. Volume button
9. Rear camera
10. Speaker
* Components may vary.
Home screen
1
2
3
4
5
5
6
Note: Your tablet may have a different wallpaper to the one shown.
1. Notification bar
2. Search
3. Widgets
4. Application menu (also known as "Apps")
5. App shortcuts
6. Navigation (Back, Home, Recent)
Getting started
Using your tablet
1. Connect the power adapter
Charge your tablet for at least four hours.
Note: It is normal for the device surface to
become warm during charging or long
periods of use.
2. Press the power button
Hold until you see the Acer logo.
Connecting to the Internet via Wi-Fi
To connect to a Wi-Fi network, tap the
Application menu, then tap Settings.
Under Wireless & networks, ensure Wi-Fi is
ON. Tap Wi-Fi and then tap a wireless
network; if necessary enter a security
password to access the network.
How to register
To register your Acer product, visit our
website at registration.acer.com.
After we receive your product registration,
you will be sent a confirmation email with
important data that you should keep in a safe
place.
Your tablet's User's Manual
To download the User's Manual, go to
www.acer.com and click Support >
DRIVERS AND MANUALS. Select the
appropriate items from Group > Series >
Products. In the Documents tab, click
Download next to the User's Manual.
Connecting a Bluetooth device
To connect to a bluetooth device, tap the
Application menu, then tap Settings.
Under Wireless & networks, ensure
Bluetooth is ON. Tap Bluetooth and then
SEARCH FOR DEVICES to scan for
available devices. Then tap an available
device to select a device.
Note: A2DP stereo headsets are supported
for playback only. Please check for updates
to the tablet's software that may add
support for additional Bluetooth devices.
Restoring to factory settings
Tap the Application menu, then tap
Settings. Tap Backup & reset > Factory
data reset; tap Reset tablet and then Erase
everything to format your tablet.
Updating your tablet’s operating
system
To check for updates, tap the Application
menu, then tap Settings. Then tap
About tablet > System updates > Check
now.
Safety and comfort
SAFETY INSTRUCTIONS
Read these instructions carefully. Keep this document for future reference. Follow all
warnings and instructions marked on the product.
Turning the product off before cleaning
Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or
aerosol cleaners. Use a damp cloth for cleaning.
WARNINGS
Accessing the power plug
Be sure that the power outlet you plug the power cord into is easily accessible and
located as close to the equipment operator as possible. When you need to disconnect
power to the equipment, be sure to unplug the power plug from the electrical outlet. Mark
sure the power plug is fixed at right position with the adaptor before plugging to the
socket on the wall.
Input rating: Refer to the rating label on the bottom of the computer and ensure that your
power adapter complies with the specified rating.
Under no circumstances should the user attempt to disassemble the power supply. The
power supply has no user-replaceable parts. Inside the power supply are hazardous
voltages that can cause serious personal injury.
A defective power supply must be returned to your dealer.
Using electrical power
- If an extension cord is used with this product, make sure that the total ampere rating
of the equipment plugged into the extension cord does not exceed the extension
cord ampere rating. Also, make sure that the total rating of all products plugged into
the wall outlet does not exceed the fuse rating.
- Do not overload a power outlet, strip or receptacle by plugging in too many devices.
The overall system load must not exceed 80% of the branch circuit rating. If power
strips are used, the load should not exceed 80% of the power strip's input rating.
General
- Do not use this product near water.
- Do not place this product on an unstable cart, stand or table. If the product falls, it
could be seriously damaged.
- Slots and openings are provided for ventilation to ensure reliable operation of the
product and to protect it from overheating.
These openings must not be blocked or covered. The openings should never be blocked
by placing the product on a bed, sofa, rug or other similar surface. This product should
never be placed near or over a radiator or heat register, or in a built-in installation unless
proper ventilation is provided.
- Never push objects of any kind into this product through cabinet slots as they may
touch dangerous voltage points or shortout parts that could result in a fire or electric
shock. Never spill liquid of any kind onto or into the product.
- To avoid damage of internal components and to prevent battery leakage, do not
place the product on a vibrating surface.
- Your device and its enhancements may contain small parts. Keep them out of the
reach of small children.
Product servicing
Do not attempt to service this product yourself, as opening or removing covers may
expose you to dangerous voltage points or other risks. Refer all servicing to qualified
service personnel.
Unplug this product from the wall outlet and refer servicing to qualified service personnel
when:
- The power cord or plug is damaged, cut or frayed.
- Liquid was spilled into the product.
- The product was exposed to rain or water.
- The product has been dropped or the case has been damaged.
- The product exhibits a distinct change in performance, indicating a need for service.
- The product does not operate normally after following the operating instructions.
Note: Adjust only those controls that are covered by the operating
instructions, since improper adjustment of other controls may result in
damage and will often require extensive work by a qualified technician to
restore the product to normal condition.
DISPOSAL INSTRUCTIONS
Do not throw this electronic device into the trash when discarding. To
minimize pollution and ensure utmost protection of the global environment,
please recycle. For more information on the Waste from Electrical and
Electronics Equipment (WEEE) regulations, visit www.acer-group.com/
public/Sustainability/sustainability01.htm
REGULATORY INFORMATION
CAUTION when listening
To protect your hearing, follow these instructions.
- Increase the volume gradually until you can hear clearly and comfortably.
- Do not increase the volume level after your ears have adjusted.
- Do not listen to music at high volumes for extended periods.
- Do not increase the volume to block out noisy surroundings.
- Decrease the volume if you can’t hear people speaking near you.
Prevention of hearing loss
Caution: Permanent hearing loss may occur if earphones or
headphones are used at high volume for prolonged periods of time.
This device has been tested to comply with the Sound Pressure Level
requirement laid down in the applicable EN 50332-1 and/or EN 50332-2
standards.
Note: For France, mobile headphones or earphones for this device have been
tested to comply with the Sound Pressure requirement laid down in the
applicable NF EN 50332-1:2000 and/or NF EN 50332-2:2003 standards as
required by French Article L. 5232-1.
WIRELESS ADAPTER REGULATORY INFORMATION
Use On Aircraft Caution
Caution: Regulations of the FCC and FAA prohibit airborne operation of radio-frequency
wireless devices (wireless adapters) because their signals could interfere with critical
interfere with critical aircraft instruments.
The Wireless Adapter and Your Health
The wireless adapter, like other radio devices, emits radio frequency electromagnetic
energy. The level of energy emitted by the wireless adapter, however, is less than the
electromagnetic energy emitted by other wireless devices such as mobile phones. The
wireless adapter operates within the guidelines found in radio frequency safety
standards and recommendations.
These standards and recommendations reflect the consensus of the scientific
community and result from deliberations of panels and committees of scientists who
continually review and interpret the extensive research literature. In some situations or
environments, the use of the wireless adapter may be restricted by the proprietor of the
building or responsible representatives of the applicable organization.
Examples of such situations may include:
- Using the wireless adapter on board airplanes, or
- Using the wireless adapter in any other environment where the risk of interference
with other devices or services is perceived or identified as being harmful.
If you are uncertain of the policy that applies to the use of wireless adapters in a specific
organization or environment (an airport, for example), you are encouraged to ask for
authorization to use the adapter before you turn it on.
USA—FCC and FAA
The FCC with its action in ET Docket 96-8 has adopted a safety standard for human
exposure to radio frequency(RF) electromagnetic energy emitted by FCC certified
equipment. The wireless adapter meets the Human Exposurelimits found in OET
Bulletin 65, supplement C, 2001, and ANSI/IEEE C95.1, 1992. Proper operation of this
radioaccording to the instructions found in this manual will result in exposure
substantially below the FCC’srecommended limits.
The following safety precautions should be observed:
- Do not touch or move antenna while the unit is transmitting or receiving.
- Do not hold any component containing the radio such that the antenna is very close
or touching anyexposed parts of the body, especially the face or eyes, while
transmitting.
- Do not operate the radio or attempt to transmit data unless the antenna is
connected; this behavior maycause damage to the radio.
• Use in specific environments:
- The use of wireless adapters in hazardous locations is limited by the constraints
posed by the safetydirectors of such environments.
- The use of wireless adapters on airplanes is governed by the Federal Aviation
Administration (FAA).
- The use of wireless adapters in hospitals is restricted to the limits set forth by each
hospital.
The product comply with the FCC portable RF exposure limit set forth for an uncontrolled
environment and are safe for intended operation as described in this manual. The further
RF exposure reduction can be achieved if the product can be kept as far as possible from
the user body or set the device to lower output power if such function is available.
Explosive device proximity warning
Warning: Do not operate a portable transmitter (including this wireless
adapter) near unshielded blastingcaps or in an explosive environment
unless the transmitter has been modified to be qualified for such use.
Interference statement
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio frequency energy. If the equipment
is not installed and used in accordance with the instructions, the equipment may cause
harmful interference to radio communications. There is no guarantee, however, that
such interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception (which can be determined by turning
the equipment off and on), the user is encouraged to try to correct the interference by
taking one or more of the following measures:
- Reorient or relocate the receiving antenna of the equipment experiencing the
interference.
- Increase the distance between the wireless adapter and the equipment
experiencing the interference.
- Connect the computer with the wireless adapter to an outlet on a circuit different
from that to which the equipment experiencing the interference is connected.
- Consult the dealer or an experienced radio/TV technician for help.
Caution: Changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate
the equipment.
FCC RF exposure information (SAR)
This device meets the government's requirements for exposure to radio waves. This
device is designed and manufactured not to exceed the emission limits for exposure to
radio frequency (RF) energy set by the Federal Communications Commission of the
U.S. Government.
The exposure standard for wireless devices employs a unit of measurement known as
the Specific Absorption Rate, or SAR. The SAR limit set by the FCC is 1.6 W/kg. Tests
for SAR are conducted using standard operating positions accepted by the FCC with the
device transmitting at its highest certified power level in all tested frequency bands.
Although the SAR is determined at the highest certified power level, the actual SAR level
of the device while operating can be well below the maximum value. This is because the
device is designed to operate at multiple power levels so as to use only the poser
required to reach the network.
In general, the closer you are to a wireless base station antenna, the lower the power
output. While there may be differences between the SAR levels of various devices and
at various positions, they all meet the government requirement.
The FCC has granted an Equipment Authorization for this device with all reported SAR
levels evaluated as in compliance with the FCC RF exposure guidelines. SAR
information on this device is on file with the FCC and can be found under the Display
Grant section of www.fcc.gov/oet/ea/fccid after searching on FCC ID for your device.
Canada – Industry Canada (IC)
This device complies with RSS210 of Industry Canada. Cet appareil se conforme à
RSS210 de Canada d'Industrie.
This device complies with Industry Canada license-exempt RSS standard(s).
Operation is subject to the following two conditions: (1) this device may not cause
interference, an d (2) this device must accept any interfe rence, including interference that
may cause undesired operation of the device.
Ce dispositif est conforme a la norme CNR-210 d'Industrie Canada applicable aux
appareils radio exempts de licence. Son fonctionnement est sujet aux deux conditions
suivantes: (1) le dispositif ne doit pas produire de brouillage prejudiciable, et (2) ce
dispositif doit accepter tout brouillage recu, y compris un brouillage susceptible de
provoquer un fonctionnement indesirable.
- Radiation Exposure Statement:
The product comply with the Canada portable RF exposure limit set forth for an
uncontrolled environment and are safe for intended operation as described in this
manual.
The further RF exposure reduction can be achieved if the product can be kept as far as
possible from the user body or set the device to lower output power if such function is
available.
Déclaration d'exposition aux radiations : Le produit est conforme aux limites d'exposition
pour les appareils portables RF pour les Etats-Unis et le Canada établies pour un
environnement non contrôlé.
Le produit est sûr pour un fonctionnement tel que décrit dans ce manuel. La réduction
aux expositions RF peut être augmentée si l'appareil peut être conservé aussi loin que
possible du corps de l'utilisateur ou que le dispositif est réglé sur la puissance de sortie
la plus faible si une telle fonction est disponible.
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme a la norme NMB-003 du Canada.
"To prevent radio interference to the licensed service, this device is intended to be
operated indoors and away from windows to provide maximum shielding. Equipment (or
its transmit antenna) that is installed outdoors is subject to licensing."
« Pour empêcher que cet appareil cause du brouillage au service faisant l'objet d'une
licence, il doit être utilisé a l'intérieur et devrait être placé loin des fenêtres afin de fournir
un écran de blindage maximal. Si le matériel (ou son antenne d'émission) est installé à
l'extérieur, il doit faire l'objet d'une licence. »
Exposure of humans to RF fields (RSS-102)
The computers employ low gain integral antennas that do not emit RF field in excess of
Health Canada limits for the general population; consult Safety Code 6, obtainable from
Health Canada's Web site at http://www.hc-sc.gc.ca/
The radiated energy from the antennas connected to the wireless adapters conforms to
the IC limit of the RF exposure requirement regarding IC RSS-102, Issue 4 clause 4.1.
SAR tests are conducted using recommended operating positions accepted by the FCC/
RSS with the device transmitt ing at its highest certified power level in all tested frequency
band without distance attaching away from the body. Non-compliance with the above
restrictions may result in violation of FCC RF exposure guidelines.
Conformité des appareils de radiocommunication aux
limites d'exposition humaine aux radiofréquences
(CNR-102)
L'ordinateur utilise des antennes intégrales à faible gain qui n'émettent pas un champ
électromagnétique supérieur aux normes imposées par Santé Canada pour la
population. Consultez le Code de sécurité 6 sur le site Internet de Santé Canada à
l'adresse suivante : http://www.hc-sc.gc.ca/
L'énergie émise par les antennes reliées aux cartes sans fil respecte la limite
d'exposition aux radiofréquences telle que définie par Industrie Canada dans la clause
4.1 du document CNR-102, version 4.
Tests DAS sont effectués en utilisant les positions recommandées par la FCC/CNR avec
le téléphone émet à la puissance certifiée maximale dans toutes les bandes de
fréquences testées sans distance attacher loin du corps. Non-respect des restrictions ci-
dessus peut entraîner une violation des directives de la FCC/CNR.
Brazil
Este equipamento opera em caráter secundário, isto é, não tem direito a proteção contra
interferência prejudicial, mesmo de estações do mesmo tipo, e não pode causar
interferência a sistemas operando em caráter primário.
Mexico
Cofetel notice is:
“La operacion de este equipo esta sujeta a las siguientes dos condiciones: (1) es posible
que este equipo o dispositivo no cause interferencia perjudicial y (2) este equipo o
dispositivo debe aceptar cualquier interferencia, incluyendo la que pueda causar su
operacion no deseada.”
SAR information
RF exposure information (SAR)
This device meets the EU requirements (1999/519/EC) on the limitation of exposure of
the general public to electromagnetic fields by way of health protection. The limits are
part of extensive recommendations for the protection of the general public. These
recommendations have been developed and checked by independent scientific
organizations through regular and thorough evaluations of scientific studies. To
guarantee the safety of all persons, regardless of age and health, the limits include a
significant safety buffer. Before radio devices can be put in circulation, their agreement
with European laws or limits must be confirmed; only then may the CE symbol be
applied.
The unit of measurement for the European Council's recommended limit for mobile
devices is the "Specific Absorption Rate" (SAR). This SAR limit is 2.0 W/kg, averaged
over 10 g of body tissue. It meets the requirements of the International Commission on
Non-Ionizing Radiation Protection (ICNIRP). The maximum SAR value is calculated at
the highest output level in all frequency bands of the mobile device. The highest SAR
value reported under this standard during product certification for use of the device at
a distance of 0 cm from the body.
During use, the actual SAR level is usually much lower than the maximum value,
because the mobile device works in different output levels. It only transmits with as much
output as is required to reach the network. In general the following applies: The closer
you are to a base station, the lower the transmission output of your mobile device.
Environment
Temperature
• Operating: 0 °C to 35 °C
• Non-operating: -20 °C to 60 °C
Humidity (non-condensing)
• Operating: 20% to 80%
• Non-operating: 20% to 80%
© All Rights Reserved
Acer Iconia - Product and Safety Information
This revision: July 2014
Federal Communications Commission
Declaration of Conformity
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) this device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired
operation.
The following local Manufacturer / Importer is responsible for this declaration:
Product: Tablet Computer
Brand: Acer
Regulatory Model Number (RMN): A1401 / A1409
Marketing Name: A1-840xxx
(x= A~Z, a~z, 0~9, or blank)
Name of Responsible Party: Acer America Corporation
Address of Responsible Party: 333 West San Carlos St., Suite 1500
San Jose, CA 95110, U. S. A.
Contact Person: Acer Representative
Phone No.: 1-254-298-4000
Fax No.: 1-254-298-4147
July 18, 2014

Navigation menu
