Welcome!
This Wireless Display Adapter allows you to project the display of your Windows notebook, tablet, or Miracast-certified device onto a bigger
screen.
Instructions:
Step 1: Plug the wireless adapter into the MHL/HDMI® port of your TV or monitor.
Step 2: For ADR132, you need to plug in the micro USB connector to supply power after plugging the adapter into the HDMI port of your
TV or monitor.
Step 3: You will see the screen shown below in less than 30 seconds, Follow the instruction of your Miracast-certified device to search for
this adapter, and establish screen projection.
Important notice:
1. Please download the installation guide from the Acer website first and follow the instructions.
2. The instructions to search for the adapter and establish connection may vary, depending on your source device, please contact the
device provider for detailed instructions.
Package content
Wireless Display
Adapter
Micro-USB Cable
(Only for ADR132)
Specification
Installation guide
Please visit www.acer.com for the installation guide and for more information.
SupportDrivers and ManualsMonitorAccessories
Features Description
Network WiFi 802.11 a/b/g/n
Output Display Protocol - MHL 1.2 (ADR131)
- HDMI 1.3a (ADR132)
Power supply - MHL (ADR131)
- Micro-USB (ADR132)
![](/img.php?id=1961325&img=bg4.png)
¡Bienvenido! (Spanish)
Este Wireless Display Adapter le permite proyectar la pantalla de su portátil Windows, tableta o dispositivo certificado Miracast en una
pantalla más grande.
Instrucciones:
Paso 1: Conecte el adaptador inalámbrico al puerto MHL/HDMI® de su TV o monitor.
Paso 2: Para ADR132, tiene que enchufar el conector micro USB para que suministre alimentación después de conectar el adaptador al
puerto HDMI de su TV o monitor.
Paso 3: Verá la pantalla que aparece a continuación en menos de 30 segundos. Siga las instrucciones de su dispositivo certificado por
Miracast para buscar este adaptador, y establezca la proyección en pantalla.
Aviso importante:
1. Por favor, descargue primero la guía de instalación del sitio web de Acer y siga las instrucciones.
2. Las instrucciones para buscar el adaptador y establecer la conexión pueden variar dependiendo del dispositivo de fuente. Póngase en
contacto con el proveedor del dispositivo para obtener instrucciones más detalladas.
Contenido del paquete
Wireless Display
Adapter
Cable Micro-USB
(Solo para ADR132)
ESPECIFICACIONES
Guía de instalación
Por favor, visite www.acer.com para consultar la guía de instalación y obtener más información.
SuporteControladores y manualesPantallaAccessories
Red WiFi 802.11 a/b/g/n
Mostrar - MHL 1.2 (ADR131)
- HDMI 1.3a (ADR132)
fuente de alimentación
- MHL (ADR131)
- Micro-USB (ADR132)
![](/img.php?id=1961325&img=bg5.png)
Bienvenue ! (French)
Ce Wireless Display Adapter vous permet de projeter l’écran de votre notebook Windows, tablette, ou appareil certifié Miracast sur un écran
plus grand.
Instructions :
Étape 1: Branchez l’adaptateur sans fil dans le port MHL/HDMI® de votre téléviseur ou moniteur.
Étape 2 : Pour ADR132, vous devez brancher le connecteur micro USB à l’alimentation après avoir branché l’adaptateur dans le port HDMI
de votre téléviseur ou moniteur.
Étape 3 : Vous verrez l’écran présenté ci-dessous dans les 30 secondes. Suivez les instructions de votre appareil certifié Miracast pour
rechercher cet adaptateur, et établir la projection de l’écran.
Avis important :
1. Veuillez d’abord télécharger le guide d’installation sur le site Web Acer et suivez les instructions.
2. Les instructions pour rechercher l’adaptateur et établir la connexion peuvent varier en fonction de votre appareil source, veuillez
contacter le fournisseur de l’appareil pour des instructions détaillées.
Contenu de l’emballage
Wireless Display
Adapter
Connecteur Micro-USB
(Pour ADR132 seulement)
SPÉCIFICATIONS
Guide d’installation
Veuillez visiter www.acer.com pour le guide d’installation et pour plus d’informations.
AssitancePilotes et Manuels ÉcranAccessories
réseau WiFi 802.11 a/b/g/n
Protocole d'affichage de sortie - MHL 1.2 (ADR131)
- HDMI 1.3a (ADR132)
Source d'Alimentation
- MHL (ADR131)
- Micro-USB (ADR132)
![](/img.php?id=1961325&img=bg6.png)
Willkommen!(German)
Der Wireless Display Adapter ermöglicht Ihnen die Projektion der Anzeige Ihres Windows-Notebooks, Tablets oder Miracast-zertifiziertem
Geräts auf eine größere Leinwand.
Anweisungen:
Schritt 1: Schließen Sie den Drahtlosadapter an den MHL/HDMI®-Anschluss das TV-Geräts oder des Monitors an.
Schritt 2: Für ADR132 müssen Sie den micro USB Stecker in das Netzteil stecken, nachdem Sie den Adapter an den HDMI-Anschluss des
TV-Geräts oder Monitors angeschlossen haben.
Schritt 3: Der unten gezeigte Bildschirm erscheint nach weniger als 30 Sekunden. Folgen Sie den Anweisungen auf Ihrem
Miracast-zertifiziertem Gerät, um nach diesem Adapter zu suchen und die Bildschirmprojektion herzustellen.
Wichtiger Hinweis:
1. Laden Sie bitte erst die Installationsanleitung von der Acer-Website herunter und folgen Sie den Anweisungen darin.
2. Die Anweisungen für die Suche des Adapters und die Herstellung der Verbindung können sich je nach Quellgerät unterscheiden.
Wenden Sie sich für genauere Informationen bitte an den Gerätehersteller.
Packungsinhalt
Wireless Display
Adapter
Micro-USB-Kabel
(nur für ADR132)
TECHNISCHE ANGABEN
Installationsanleitung
Unter www.acer.com finden Sie die Installationsanleitung sowie weitere Informationen.
SupportTreiber und Handbücher MonitorAccessories
Netzwerk WiFi 802.11 a/b/g/n
Ausgang Anzeige Protocol - MHL 1.2 (ADR131)
- HDMI 1.3a (ADR132)
Stromquelle - MHL (ADR131)
- Micro-USB (ADR132)
![](/img.php?id=1961325&img=bg7.png)
Benvenuti! (Italian)
Wireless Display Adapter consente di proiettare il display del notebook Windows, tablet, o dispositivo certificato Miracast su uno schermo più
grande.
Istruzioni:
Fase 1: Collegare l'adattatore wireless nella porta MHL/HDMI® della propria TV o monitor.
Fase 2: Per l'ADR132, è necessario collegare il connettore micro USB per fornire l'alimentazione dopo aver collegato l'adattatore nella
porta HDMI della propria TV o monitor.
Fase 3: Comparirà la schermata visualizzata di seguito in meno di 30 secondi, Seguire le istruzioni del proprio dispositivo certificato
Miracast per cercare questo adattatore e stabilire la proiezione dello schermo.
Avviso importante:
1. Scaricare prima la guida di installazione dal sito web Acer e seguire le istruzioni.
2. Le istruzioni per cercare l'adattatore e stabilire la connessione possono variare, a seconda del dispositivo sorgente, si prega di contattare
il provider del dispositivo per istruzioni dettagliate.
Contenuto dell’Imballaggio
Wireless Display
Adapter
SPECIFICHE
Cavo Micro-USB
(Solo per ADR132)
Guida d’installazione
Visitare www.acer.com per la guida di installazione e altre informazioni.
SupportoDownload DriverMonitorAccessories
rete WiFi 802.11 a/b/g/n
Uscita display protocollo - MHL 1.2 (ADR131)
- HDMI 1.3a (ADR132)
Sorgente d’alimentazione - MHL (ADR131)
- Micro-USB (ADR132)
![](/img.php?id=1961325&img=bg9.png)
ようこそ!
この Wireless Display Adapter は、Windows ノートブック、タブレット、Miracast 認証デバイスの画面を大型スクリーンに投写します。
手順:
ステップ 1: ワイヤレス アダプタを TV またはモニタの MHL/HDMI® ポートに繋ぎます。
ステップ 2: ADR132 の場合は、アダプタを TV またはモニタの HDMI ポートに接続した後、電源を供給するために micro USB コネクタに繋ぐ必要がありま
す。
ステップ 3: 30 秒以内に次のような画面が表示されます。Miracast 認証デバイスの指示に従ってこのアダプタを検索し、スクリーン投写を行ってください。
重要:
1. 先に Acer ホームページからインストール ガイドをダウンロードして、その指示に従ってください。
2. アダプタを検出して接続を確立する手順は、ソース デバイスによって異なる場合があります。詳細は、デバイス メーカーにお問い合わせください。
パッケージ内容
Wireless Display
Adapter
Micro-USB ケーブル
(ADR132 専用)
仕様
インストールの手順
インストールの手順と詳細については、www.acer.com をご覧ください。
サポート ドライバとマニュアル 液晶モニター Accessories
ネットワーク WiFi 802.11 a/b/g/n
入力ビデオ信号 - MHL 1.2 (ADR131)
- HDMI 1.3a (ADR132)
電源 - MHL (ADR131)
- Micro-USB (ADR132)
![](/img.php?id=1961325&img=bgb.png)
歡迎!
本產品讓您能夠將通過 Miracast™ 認證的筆記型電腦,平板電腦或行動電話等裝置的畫面,投影到大螢幕上。
使用簡介:
步驟一:將本產品插入您的電視或監視器上的 HDMI 或MHL 埠
步驟二:若您購買的產品型號是 ADR132(採用 HDMI 輸出),您需要將 Micro-USB 線插入本產品上的 Micro-USB 埠,線材的另一端接入電源
配適器,USB 2.0,或 USB 3.0 埠。
步驟三:在三十秒內,您會看見如下圖的畫面顯示在電視或監視器上。請遵照您的電腦或手持裝置上的操作說明來進行 Miracast™連線。
重要提示:
請到 Acer 官方網站上找尋最新的安裝及操作說明,並且遵照其指示。
包裝內容
Wireless Display
Adapter
Micro-USB Cable
(Only for ADR132)
規格
安裝說明
請拜訪 www.acer.com,找尋安裝指引以及其他更多資訊。
服務支援驅動程式與說明手冊顯示器Accessories
網路 WiFi 802.11 a/b/g/n
輸出訊號格式 - MHL 1.2 (ADR131)
- HDMI 1.3a (ADR132)
電源 - MHL (ADR131)
- Micro-USB (ADR132)
![](/img.php?id=1961325&img=bgc.png)
欢迎!
本产品让您能够将通过 Miracast™ 认证的笔记本电脑,平板電腦,或移動电话等装置的画面,投影到大屏幕上。
使用简介:
步骤一:将本产品插入您的电视或监视器上的 HDMI 或MHL 埠
步骤二:若您购买的产品型号是 ADR132(采用 HDMI 输出),您需要将 Micro-USB 线插入本产品上的 Micro-USB 端口,线材的另一端接入电
源配适器,USB 2.0 或USB 3.0 埠。
步骤三:在三十秒内,您会看见如下图的画面显示在电视或监视器上。请遵照您的计算机或移動装置上的操作说明来进行 Miracast™联机。
重要提示:
请到 Acer 官方网站上找寻最新的安装及操作说明,并且遵照其指示。
包装内容
Wireless Display
Adapter
Micro-USB Cable
(Only for ADR132)
安装说明
请拜访 www.acer.com,找寻安装指引以及其他更多信息。
服务支持 驱动程序和手册 显示器
规格 描述
网络 WiFi 802.11 a/b/g/n
输出讯号格式 - MHL 1.2 (ADR131)
- HDMI 1.3a (ADR132)
电源 - MHL (ADR131)
- Micro-USB (ADR132)
![](/img.php?id=1961325&img=bgd.png)
www.acer.com
Federal Communications Commission
Declaration of Conformity
This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
The following local Manufacturer /Importer is responsible for this
declaration:
Product: Smart Monitor
Brand: Acer
Model Number: ADR131 / ADR132
Sku Number: ADR131 xxxxxx / ADR132 xxxxxx
(“*” is “0-9”, “a-z”, “A-Z”, “-“ or blank)
Name of Responsible Party: Acer America Corporation
Address of Responsible Party: 333 West San Carlos St., Suite 1500
San Jose, CA 95110, U. S. A.
Contact Person: Acer Representative
Phone No.: 1-254-298-4000
Fax No.: 1-254-298-4147
March 29, 2013
![](/img.php?id=1961325&img=bge.png)
Acer Incorporated
8F, 88, Sec. 1, Xintai 5th Rd., Xizhi
New Taipei City 221, Taiwan
Declaration of Conformity
We,
Acer Incorporated
8F, 88, Sec. 1, Xintai 5th Rd., Xizhi, New Taipei City 221, Taiwan
Contact Person: Mr. RU Jan, e-mail:ru.jan@acer.com
And,
Acer Italy s.r.l
Via Lepetit, 40, 20020 Lainate (MI) Italy
Tel: +39-02-939-921 ,Fax: +39-02 9399-2913
www.acer.it
Declare under our own responsibility that the product:
Product: Smart Monitor
Trade Name: Acer
Model Number: ADR131 / ADR132
SKU Number: ADR131 xxxxxx/ ADR132 xxxxxx
To which this declaration refers conforms to the relevant standard or other standardizing documents:
EN55022:2006/A1:2007 Class B; EN55024:2010
EN301 489-1 V1.9.2; EN301 489-17 V2.1.1
EN300 328 V1.7.1
EN301 893 V1.6.1
EN60950-1:2006/A11:2009/A1:2010+A12:2011
EN50581:2012
We hereby declare above product i
s in compliance with the essential requirements and other relevant
provisions of EMC Directive 2004/108/EC, Low Voltage Directive 2006/95/EC, R&TTE Directive
1999/5/EC and RoHS Directive 2011/65/EU
and Directive 2009/125/EC with regard to establishing a
framework for the setting of ecodesign requirements for energy-related product.
Year to begin affixing CE marking 2013.
_______________________________ Mar. 29, 2013
RU Jan / Sr. Manager Date
Regulation, Acer Inc.
![](/img.php?id=1961325&img=bgf.png)
Europe – EU Declaration of Conformity
This device complies with the essential requirements of the R&TTE Directive 1999/5/EC. The following test
methods have been applied in order to prove presumption of conformity with the essential requirements
of the R&TTE Directive 1999/5/EC:
- EN 60950-1: 2001
- EN 60950-1/A1: 2010
- EN 60950-1/A11: 2009
- EN 60950-1/A12: 2011
Safety of Information Technology Equipment
- EN 62311: 2008 / Article 3(1)(a) and Article 2 2006/95/EC)
Assessment of electronic and electrical equipment related to human exposure restrictions for
electromagnetic fields (0 Hz-300 GHz) (IEC 62311:2007 (Modified))
- EN 300 328 V1.7.1: 2006
Electromagnetic compatibility and Radio spectrum Matters (ERM); Wideband Transmission systems;
Data transmission equipment operating in the 2,4 GHz ISM band and using spread spectrum
modulation techniques; Harmonized EN covering essential requirements under article 3.2 of the R&TTE
Directive
- EN 301 893 V1.6.1: 2011
Broadband Radio Access Networks (BRAN); 5 GHz high performance RLAN; Harmonized EN covering
essential requirements of article 3.2 of the R&TTE Directive
- EN 301 489-1 V1.9.2: 2008
Electromagnetic compatibility and Radio Spectrum Matters (ERM); ElectroMagnetic Compatibility
(EMC) standard for radio equipment and services; Part 1: Common technical requirements
- EN 301 489-17 V2.1.1: 2009
- Electromagnetic compatibility and Radio spectrum Matters (ERM); ElectroMagnetic Compatibility
(EMC) standard for radio equipment and services; Part 17: Specific conditions for 2,4 GHz wideband
transmission systems and 5 GHz high performance RLAN equipment
Česky
[Czech]
[Jméno výrobce] tímto prohlašuje, že tento [typ zařízení] je ve shodě se základními požadavky a
dalšími příslušnými ustanoveními směrnice 1999/5/ES.
Dansk
[Danish]
Undertegnede [fabrikantens navn] erklærer herved, at følgende udstyr [udstyrets typebetegnelse]
overholder de væsentlige krav og øvrige relevante krav i direktiv 1999/5/EF.
![](/img.php?id=1961325&img=bg10.png)
Deutsch
[German]
Hiermit erklärt [Name des Herstellers], dass sich das Gerät [Gerätetyp] in Übereinstimmung mit den
grundlegenden Anforderungen und den übrigen einschlägigen Bestimmungen der Richtlinie
1999/5/EG befindet.
Eesti
[Estonian]
Käesolevaga kinnitab [tootja nimi = name of manufacturer] seadme [seadme tüüp = type of
equipment] vastavust direktiivi 1999/5/EÜ põhinõuetele ja nimetatud direktiivist tulenevatele teistele
asjakohastele sätetele.
English Hereby, [name of manufacturer], declares that this [type of equipment] is in compliance with the
essential requirements and other relevant provisions of Directive 1999/5/EC.
Español
[Spanish]
Por medio de la presente [nombre del fabricante] declara que el [clase de equipo]
cumple con los
requisitos esenciales y cualesquiera otras disposiciones aplicables o exigibles de la Directiva
1999/5/CE.
Ελληνική
[Greek]
ΜΕ ΤΗΝ ΠΑΡΟΥΣΑ [name of manufacturer] ΔΗΛΩΝΕΙ ΟΤΙ [type of equipment] ΣΥΜΜΟΡΦΩΝΕΤΑΙ
ΠΡΟΣ ΤΙΣ ΟΥΣΙΩΔΕΙΣ ΑΠΑΙΤΗΣΕΙΣ ΚΑΙ ΤΙΣ ΛΟΙΠΕΣ ΣΧΕΤΙΚΕΣ ΔΙΑΤΑΞΕΙΣ ΤΗΣ ΟΔΗΓΙΑΣ 1999/5/ΕΚ.
Français
[French]
Par la présente [nom du fabricant] déclare que l'appareil [type d'appareil] est conforme aux
exigences essentielles et aux autres dispositions pertinentes de la directive 1999/5/CE.
Italiano
[Italian]
Con la presente [nome del costruttore] dichiara che questo [tipo di apparecchio] è conforme ai
requisiti essenziali ed alle altre disposizioni pertinenti stabilite dalla direttiva 1999/5/CE.
Latviski
[Latvian]
Ar šo [name of manufacturer / izgatavotāja nosaukums] deklarē, ka [type of equipment / iekārtas
tips] atbilst Direktīvas 1999/5/EK būtiskajām prasībām un citiem ar to saistītajiem noteikumiem.
Lietuvių
[Lithuanian]
Šiuo [manufacturer name] deklaruoja, kad šis [equipment type]
atitinka esminius reikalavimus ir kitas
1999/5/EB Direktyvos nuostatas.
Nederlands
[Dutch]
Hierbij verklaart [naam van de fabrikant] dat het toestel [type van toestel] in overeenstemming is
met de essentiële eisen en de andere relevante bepalingen van richtlijn 1999/5/EG.
Malti
[Maltese]
Hawnhekk, [isem tal-manifattur], jiddikjara li dan [il-mudel tal-prodott] jikkonforma mal-ħtiġijiet
essenzjali u ma provvedimenti oħrajn relevanti li hemm fid-Dirrettiva 1999/5/EC.
Magyar
[Hungarian]
Alulírott, [gyártó neve] nyilatkozom, hogy a [... típus] megfelel a vonatkozó alapvetõ
követelményeknek és az 1999/5/EC irányelv egyéb elõírásainak.
Polski
[Polish]
Niniejszym [nazwa producenta] oświadcza, że [nazwa wyrobu] jest zgodny z zasadniczymi
wymogami oraz pozostałymi stosownymi postanowieniami Dyrektywy 1999/5/EC.
Português
[Portuguese]
[Nome do fabricante] declara que este [tipo de equipamento] está conforme com os requisitos
essenciais e outras disposições da Directiva 1999/5/CE.
Slovensko
[Slovenian]
[Ime proizvajalca] izjavlja, da je ta [tip opreme] v skladu z bistvenimi zahtevami in ostalimi
relevantnimi določili direktive 1999/5/ES.
Slovensky
[Slovak]
[Meno výrobcu] týmto vyhlasuje, že [typ zariadenia] spĺňa základné požiadavky a všetky príslušné
ustanovenia Smernice 1999/5/ES.
Suomi
[Finnish]
[Valmistaja = manufacturer] vakuuttaa täten että [type of equipment = laitteen tyyppimerkintä]
tyyppinen laite on direktiivin 1999/5/EY oleellisten vaatimusten ja sitä koskevien direktiivin muiden
ehtojen mukainen.
Svenska
[Swedish]
Härmed intygar [företag] att denna [utrustningstyp] står I överensstämmelse med de väsentliga
egenskapskrav och övriga relevanta bestämmelser som framgår av direktiv 1999/5/EG.
Federal Communication Commission Interference Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)
This device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate this equipment.
This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
Industry Canada statement:
This device complies with RSS-210 of the Industry Canada Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
Ce dispositif est conforme à la norme CNR-210 d'Industrie Canada applicable aux appareils radio exempts de
licence. Son fonctionnement est sujet aux deux conditions suivantes: (1) le dispositif ne doit pas produire de
brouillage préjudiciable, et (2) ce dispositif doit accepter tout brouillage reçu, y compris un brouillage susceptible
de provoquer un fonctionnement indésirable.
Caution :
(i) the device for operation in the band 5150-5250 MHz is only for indoor use to reduce the potential for harmful
interference to co-channel mobile satellite systems;
(ii) high-power radars are allocated as primary users (i.e. priority users) of the bands 5250-5350 MHz and
5650-5850 MHz and that these radars could cause interference and/or damage to LE-LAN devices.
Avertissement:
(i) les dispositifs fonctionnant dans la bande 5 150-5 250 MHz sont réservés uniquement pour une utilisation à
l’intérieur afin de réduire les risques de brouillage préjudiciable aux systèmes de satellites mobiles utilisant les
mêmes canaux;
(ii) De plus, les utilisateurs devraient aussi être avisés que les utilisateurs de radars de haute puissance sont
désignés utilisateurs principaux (c.-à-d., qu’ils ont la priorité) pour les bandes 5 250-5 350 MHz et 5 650-5 850
MHz et que ces radars pourraient causer du brouillage et/ou des dommages aux dispositifs LAN-EL.
Radiation Exposure Statement:
This equipment complies with IC radiation exposure limits set forth for an uncontrolled environment. This
equipment should be installed and operated with minimum distance 20cm between the radiator & your body.
Déclaration d'exposition aux radiations:
Cet équipement est conforme aux limites d'exposition aux rayonnements IC établies pour un environnement non
contrôlé. Cet équipement doit être installé et utilisé avec un minimum de 20 cm de distance entre la source de
rayonnement et votre corps.
Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This
equipment should be installed and operated with minimum distance 20cm between the radiator & your body.
Operations in the 5.15-5.25GHz band are restricted to indoor usage only.
Note: The country code selection is for non-US model only and is not available to all US model. Per FCC regulation,
all WiFi product marketed in US must fixed to US operation channels only.
經型式認證合格之低功率射頻電機,非經許可,公司、商號或使用者均不得擅自變更頻率、加大功率或變更
原設計之特性及功能。
低功率射頻電機之使用不得影響飛航安全及干擾合法通信;經發現有干擾現象時,應立即停用,並改善至無
干擾時方得繼續使用。前項合法通信,指依電信法規定作業之無線電通信。低功率射頻電機須忍受合法通信
或工業、科學及醫療用電波輻射性電機設備之干擾。
![](/img.php?id=1961325&img=bg13.png)
LCD Monitor Quick Setup Guide
English
Safety Instructions
Observe the following safety guidelines when connection and using your monitor:
·Be sure that your monitor is electrically rated to operate with the AC power available in your location.
·Locate your monitor near an easily accessible electrical outlet.
·Place the monitor on a solid surface and treat it carefully. The screen can be damaged if dropped, sharply hit, or touched
with a sharp or abrasive implement.
·Put your monitor in a location with low humidity and a minimum of dust.
·Never use your monitor if the power cable has been damaged. Do not allow anything to rest on the power cable, and keep
the cable away from where people could trip over it.
·Never insert anything metallic into the monitor openings. Doing so may create the danger of electric shock.
·To avoid electric shock, never touch the inside of the monitor. Only a qualified technician should open the monitor’s case.
·Be sure to hold the plug, not the cable, when disconnecting the monitor from an electrical outlet.
·Openings in the monitor cabinet are provided for ventilation. To prevent overheating, these openings should not be
blocked or covered. Also, avoid using the monitor on a bed, sofa, rug, or other soft surface.
·Doing so may block the ventilation openings in the bottom of the cabinet. If you put the monitor in a bookcase or some
other enclosed space, be sure to provide adequate ventilation.
·Do not expose the monitor to rain or use it near water. If the monitor accidentally gets wet, unplug it and contact an
authorized dealer immediately. You can clean the exterior of the monitor with a damp cloth when necessary, but be sure
to unplug the monitor first. If your monitor does not operate normally-in particular, if there are any unusual sounds or smells
coming from it -unplug the monitor immediately and contact an authorized dealer or service center.
Troubleshooting Tips
No Power - The monitor’s power indicator is off.
Make sure the monitor power cable is fully inserted in the monitor’s power port and the electrical outlet.
Test the electrical oulet by plugging in a working electrical device such as a lamp.
Try another power cable on the monitor. You can use the computer’s power cable to perform this test.
No Video - The monitor’s power indicator is on but there are no
image on the screen.
Ensure that the video connector is properly connected to the computer.
Ensure that the computer is on and functioning properly.
Turn off the monitor and check the video cable pins. Make sure no pins are bent.
Operation Detail
Please refer to user’s guide in CD-ROM packaged with this monitor.
1.1-1Connect Video Cable
a. Make sure both the monitor and computer are powered-OFF.
b. Connect the VGA video cable to the computer.
1-2Digital Cable (Only Dual-Input Model)
a. Make sure both the monitor and computer are powered-OFF.
b. Connect one end of the 24-pin DVI cable to the back of the
monitor and connect the other end to the computer’s port.
2. Connect the Audio Cable(Only Audio-Input Model)(Optional)
3.Connect power cord
Connect the power cord to the monitor, then to a properly grounded AC
outlet.
4.Power-ON Monitor and Computer
Power-ON the monitor first, then power-ON the computer.
This sequence is very important.
5.If the monitor still does not function properly, please refer to the trouble-
shooting section to diagnose the problem.
Connecting Your Monitor to a Computer
![](/img.php?id=1961325&img=bg14.png)
LCD Monitor Quick Setup Guide
English
LAMP Disposal
Disposal of Waste Equipment by Users in Private Household in the
European Union
This symbol on the product or on its packaging indicates that this product must not be disposed of
with your other household waste. Instead, it is your responsibility to dispose of your waste
equipment by handing it over to a designated collection point for the recycling of waste electrical
and electronic equipment. The separate collection and recycling of your waste equipment at the
time of disposal will help to conserve natural resources and ensure that it is recycled in a manner
that protects human health and the environment. For more information about where you can drop
off your waste equipment for recycling, please contact your local city office, your household waste
disposal service or the shop where you purchased the product.
LAMP(S) INSIDE THIS PRODUCT CONTAIN MERCURY AND MUST BE RECYCLED OR DISPOSED OF ACCORD-
ING TO LOCAL, STATE OR FEDERAL LAWS. FOR MORE INFORMATION, CONTACT THE ELECTRONIC
INDUSTRIES ALLIANCE AT WWW.EIAE.ORG. FOR LAMP SPECIFIC DISPOSAL INFORMATION CHECK
WWW.LAMPRECYCLE.ORG.
Regulations and safety notices
FCC notice
This device has been tested and found to comply with the limits for a Class B digital device
pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This device generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this
device does cause harmful interference to radio or television reception, which can be determined
by turning the device off and on, the user is encouraged to try to correct the interference by one
or more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the device and receiver.
•Connect the device into an outlet on a circuit different from that to which the receiver
is connected.
•Consult the dealer or an experienced radio/television technician for help.
CE declaration of Conformity
Hereby, Acer Inc., declares that this LCD monitor is in compliance with the essential requirements , and other
relevant provisions of EMC Directive 2004/108/EC, Low Voltage Directive2006/95/EC,RoHS Directive 2002/95/EC
and Directive 2009/125/EC with regard to establishing a framework for the setting of eco design requirements
for energy-related product.
Notice: Shielded cables
All connections to other computing devices must be made using shielded cables to maintain
compliance with EMC regulations.
Notice: Peripheral devices
Only peripherals (input/output devices, terminals, printers, etc.) certified to comply with the Class
B limits may be attached to this equipment. Operation with non-certified peripherals is likely to
result in interference to radio and TV reception.
Caution
Changes or modifications not expressly approved by the manufacturer could void the user author-
ity, which is granted by the Federal Communications Commission, to operate this product.
Operation conditions
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
Notice: Canadian users
This Class B digital apparatus complies with Canadian ICES-003.
Remarque à l’intention des utilisateurs canadiens
Cet appareil numérique de la classe B est conforme a la norme NMB-003 du Canada.
![](/img.php?id=1961325&img=bg15.png)
SPECIFICATION
Driving system TFT Color LCD
Size 17.0" W (43cm)
Pixel pitch 0.264mm (H) x 0.264mm (V)
Brightness 250cd/m2 (Typical)
Contrast 20000:1 Max (ACM)
Viewable angle 1600(H) 1600(V)
LCD Panel
Response time 5 ms
Video R,G,B Analog Interface
H-Frequency 30KHz - 80KHz
V-Frequency 55-75Hz
Display Colors 16.7M Colors
Dot Clock 136MHz
Max. Resolution 1280 x 1024 @ 75Hz
Plug & Play VESA DDCCI/DDC2B
On Mode 19.73W (typ.)
SleepMode 0.58W (typ.)
Power
Consumption
(at 200 nits)
Off Mode 0.52W (typ.)
D-Sub
Input Connector
DVI-D 24pin (Only Dual-Input Model)
Analog:0.7Vp-p(standard),75 OHM, Positive
Input Video Signal Digital signal (Only Dual-Input Model) (Optional)
Speakers 1W x 2 (Only Audio-Input Model)(Optional)
Maximum Screen Size Horizontal : 338mm, Vertical : 270mm
Power Source 100-240VAC, 50/60Hz
Environmental Considerations Operating Temp: 50 to 350C, Storage Temp.: -200 to 600C, Operating Humidity:
10% to 85%
Dimensions 370.2(W) x376.0(H) x160.2(D)mm
Weight (N. W.) 3.75kg Unit (net)
Switch Power Button, </ >, MENU/ENTER, Automatic adjustment/ Exit, Empowering
Key/ Exit
External Controls:
Functions
Contrast, Brightness, ACM On/Off, Focus, Clock, H.Position, V.Position, (Warm)
Color, (Cool)Color, RGB Color temperature, Language, OSD position . timeout,
Auto configuration(only Analog input model), Input signal Selection (only DuaI
input mode), DDCCI On/Off,Display information, Reset, Exit
* All specifications are subject to change without notice.
Regulatory Compliance
ADM(Acer_eDisplay_Management)
Regarding the features and operation instructions, please refer to the "Help" section in the ADM
software on the CD Manual.(For Windows 98SE/ME/NT 4.0/2000/XP/Vista/Win7)
LCD Monintor Quick Setup Guide
English
