1
Acer beTouch E120
User Guide
![](/img.php?id=1308448&img=bg2.png)
2
© 2010 All Rights Reserved
Acer beTouch E120 Smartphone User Guide
Original issue: 06/2010
Acer beTouch E120 Smartphone
Model number: __________________________________
Serial number: ___________________________________
Date of purchase: ________________________________
Place of purchase: ________________________________
![](/img.php?id=1308448&img=bg3.png)
3
End User Licence Agreement
IMPORTANT-READ CAREFULLY: THIS END USER LICENSE AGREEMENT ("AGREEMENT") IS A LEGAL AGREEMENT BETWEEN
YOU (EITHER AN INDIVIDUAL OR A SINGLE ENTITY), AND ACER INC. INCLUDING ITS SUBSIDIARIES ("ACER") FOR THE
SOFTWARE (WHETHER PROVIDED BY ACER OR BY ACER'S LICENSORS OR SUPPLIERS) THAT ACCOMPANIES THIS
AGREEMENT, INCLUDING ANY ASSOCIATED MEDIA, PRINTED MATERIALS AND RELATED USER ELECTRONIC
DOCUMENTATION WHICH MAY BE BRANDED "ACER" ("SOFTWARE"). AGREEMENTS RELATING TO ANY OTHER PRODUCT
OR TOPIC ARE NEITHER INTENDED NOR SHOULD THEY BE IMPLIED. BY INSTALLING THE ACCOMPANYING SOFTWARE OR
ANY PORTION THEREOF, YOU AGREE TO BE BOUND BY THE TERMS AND CONDITIONS OF THIS AGREEMENT. IF YOU DO
NOT AGREE TO ALL OF THE TERMS AND CONDITIONS OF THIS AGREEMENT, DO NOT CONTINUE THE INSTALLATION
PROCESS AND IMMEDIATELY DELETE ALL INSTALLED FILES, IF ANY, OF THE ACCOMPANYING SOFTWARE FROM YOUR
PHONE.
IF YOU DO NOT HAVE A VALIDLY-LICENSED COPY OF THE APPLICABLE SOFTWARE, YOU ARE NOT AUTHORIZED TO
INSTALL, COPY OR OTHERWISE USE THE SOFTWARE, AND HAVE NO RIGHTS UNDER THIS AGREEMENT.
The Software is protected by U.S. and international copyright laws and conventions as well as other intellectual property
laws and treaties. The Software is licensed, not sold.
GRANT OF LICENSE
Acer grants to you the following non-exclusive and non-transferable rights with respect to the Software. Under this
Agreement, you may:
1. Install and use the Software only on a single designated phone. A separate license is required for each phone on
which the Software will be used;
2. Make one copy of the Software solely for backup or archival purposes;
3. Make one hardcopy of any electronic documents included in the Software, provided that you receive the
documents electronically.
RESTRICTIONS
You may NOT:
1. Use or copy the Software except as provided in this Agreement;
2. Rent or lease the Software to any third party;
3. Modify, adapt, or translate the Software in whole or in part;
4. Reverse engineer, decompile, or disassemble the Software or create derivative works based upon the Software;
5. Merge the Software with any other program or modify the Software, except for your personal use; and
6. Sublicense or otherwise make the Software available to third parties, except that you may, after prior written
notification to Acer, transfer the Software as a whole to a third party so long as you do not retain any copies of the
Software and such third party accepts the terms of this Agreement.
7. Transfer your rights under this Agreement to any third parties.
8. Export the Software in contravention of applicable export laws and regulations, or (i) sell, export, re-export,
transfer, divert, disclose technical data, or dispose of, any Software to any prohibited person, entity, or destination
including, without limitation, Cuba, Iran, North Korea, Sudan and Syria; or (ii) use any Software for any use
prohibited by the laws or regulations of the United States.
SUPPORT SERVICES
Acer is not obligated to provide technical or other support for the Software.
ACER LIVE UPDATE
Certain of the software contains elements that enable the use of the Acer Live Update service, which allows for updates
for such software to be automatically downloaded and installed on your phone. By installing the software, you hereby
agree and consent that Acer (or its licensors) may automatically check the version of such software that you are using on
your phone and may provide upgrades to such software that may be automatically downloaded on to your phone.
OWNERSHIP AND COPYRIGHT
Title, ownership rights and intellectual property rights in and to the Software and all copies thereof shall remain with Acer
or Acer's licensors or suppliers (as applicable). You do not have or shall not gain any proprietary interest in the Software
(including any modifications or copies made by or for you) or any related intellectual property rights. Title and related
rights in the content accessed through the Software is the property of the applicable content owner and may be protected
by applicable law. This license gives you no rights to such contents. You hereby agree
1. Not to remove any copyright or other proprietary notices from the Software;
2. To reproduce all such notices on any authorized copies you make; and
3. To use best efforts to prevent any unauthorized copying of the Software.
TRADEMARKS
This Agreement does not grant to you any rights in connection with any trademarks or service marks of Acer or of Acer's
licensors or suppliers.
DISCLAIMER OF WARRANTIES
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, ACER, ITS SUPPLIERS, AND ITS LICENSORS, PROVIDE THE
SOFTWARE "AS IS" AND WITH ALL FAULTS, AND HEREBY DISCLAIM ALL OTHER WARRANTIES AND CONDITIONS, EITHER
EXPRESS, IMPLIED OR STATUTORY, INCLUDING, BUT NOT LIMITED TO, ANY IMPLIED WARRANTIES, DUTIES OR
CONDITIONS OF MERCHANTABILITY, OF FITNESS FOR A PARTICULAR PURPOSE, OF ACCURACY OR COMPLETENESS OF
RESPONSES, OF RESULTS, OF WORKMANLIKE EFFORT, OF LACK OF VIRUSES, AND OF LACK OF NEGLIGENCE, ALL WITH
REGARD TO THE SOFTWARE AND THE PROVISION OF OR FAILURE TO PROVIDE SUPPORT SERVICES. ALSO, THERE IS NO
![](/img.php?id=1308448&img=bg4.png)
4
WARRANTY OR CONDITION OF TITLE, QUIET ENJOYMENT, QUIET POSSESSION, CORRESPONDENCE TO DESCRIPTION OR
NON-INFRINGEMENT WITH REGARD TO THE SOFTWARE.
EXCLUSION OF INCIDENTAL, CONSEQUENTIAL AND CERTAIN OTHER DAMAGES
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO EVENT SHALL ACER, ACER'S SUPPLIERS, OR ACER'S
LICENSORS, BE LIABLE FOR ANY SPECIAL, INCIDENTAL, INDIRECT, PUNITIVE, OR CONSEQUENTIAL DAMAGES
WHATSOEVER (INCLUDING, BUT NOT LIMITED TO, DAMAGES FOR LOSS OF PROFITS OR CONFIDENTIAL OR OTHER
INFORMATION, FOR BUSINESS INTERRUPTION, FOR PERSONAL INJURY, FOR LOSS OF PRIVACY, FOR FAILURE TO MEET ANY
DUTY INCLUDING OF GOOD FAITH OR OF REASONABLE CARE, FOR NEGLIGENCE, AND FOR ANY OTHER PECUNIARY OR
OTHER LOSS WHATSOEVER) ARISING OUT OF OR IN ANY WAY RELATED TO THE USE OF OR INABILITY TO USE THE
SOFTWARE, THE PROVISION OF OR FAILURE TO PROVIDE SUPPORT SERVICES, OR OTHERWISE UNDER OR IN CONNECTION
WITH ANY PROVISION OF THIS AGREEMENT, EVEN IN THE EVENT OF THE FAULT, TORT (INCLUDING NEGLIGENCE), STRICT
LIABILITY, BREACH OF CONTRACT OR BREACH OF WARRANTY OF ACER OR ITS SUPPLIERS OR LICENSORS, AND EVEN IF
ACER AND ITS SUPPLIERS AND LICENSORS HAVE BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
LIMITATION OF LIABILITY AND REMEDIES
NOTWITHSTANDING ANY DAMAGES THAT YOU MIGHT INCUR FOR ANY REASON WHATSOEVER (INCLUDING, WITHOUT
LIMITATION, ALL DAMAGES REFERENCED ABOVE AND ALL DIRECT OR GENERAL DAMAGES), THE ENTIRE LIABILITY OF
ACER, ITS SUPPLIERS, AND ITS LICENSORS, UNDER ANY PROVISION OF THIS AGREEMENT, AND YOUR EXCLUSIVE REMEDY
FOR ALL OF THE FOREGOING, SHALL BE LIMITED TO THE AGGREGATE AMOUNT PAID BY YOU FOR THE SOFTWARE. THE
FOREGOING LIMITATIONS, EXCLUSIONS AND DISCLAIMERS (INCLUDING DISCLAIMER OF WARRANTIES AND EXCLUSION OF
INCIDENTAL, CONSEQUENTIAL AND CERTAIN OTHER DAMAGES ABOVE) SHALL APPLY TO THE MAXIMUM EXTENT
PERMITTED BY APPLICABLE LAW, EVEN IF ANY REMEDY FAILS ITS ESSENTIAL PURPOSE; PROVIDED, HOWEVER, THAT
BECAUSE SOME JURISDICTIONS DO NOT ALLOW THE EXCLUSION OR LIMITATION OR LIABILITY FOR CONSEQUENTIAL OR
INCIDENTAL DAMAGES, THE ABOVE LIMITATION MAY NOT APPLY TO YOU.
TERMINATION
Without prejudice to any other rights, Acer may immediately terminate this Agreement without notice if you fail to
comply with any terms and conditions of this Agreement.
In such event, you must:
1. Cease all use of the Software;
2. Destroy or return to Acer the original and all copies of the Software; and
3. Delete the Software from all phones on which it was resident.
All disclaimers of warranties and limitation of liability set forth in this Agreement shall survive termination of this
Agreement.
GENERAL
This Agreement represents the complete agreement between you and Acer relating to this license for the Software and
supersedes all prior agreements, communications, proposals and representations between the parties and prevails over
any conflicting or additional terms of any quote, order, acknowledgement or similar communication. This Agreement may
only be modified by a written document signed by both parties. If any provision of this Agreement is held by a court of
competent jurisdiction to be contrary to law that provision will be enforced to the maximum extent permissible and the
remaining provisions of this Agreement will remain in full force and effect.
ADDITIONAL PROVISIONS APPLICABLE TO THIRD PARTY SOFTWARE AND SERVICES
Software provided hereunder by Acer's licensors or suppliers ("Third Party Software") is made available to you for your
personal, non-commercial use only. You may not use the Third Party Software in any manner that could damage, disable,
overburden, or impair the services provided by Acer's licensors or suppliers hereunder ("Third Party Services").
Furthermore, you may not use the Third Party Software in any manner that could interfere with any other party's use and
enjoyment of the Third Party Services, or the services and products of Acer's licensors' or suppliers' third party licensors.
Your use of the Third Party Software and Third Party Services is also subject to additional terms and conditions and policies
which can be accessed through our global website.
Privacy policy
During registration you will be asked to submit some information to Acer. Please refer to Acer’s privacy policy at
www.acer.com or your local Acer website.
![](/img.php?id=1308448&img=bg5.png)
5
Table of Contents
End User Licence Agreement
Getting to know your smartphone
Features and functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Product registration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Setting Up
Unpacking your smartphone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Getting to know your smartphone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Installing or removing the battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Installing a SIM and microSD Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Using your Smartphone
Turning on for the first time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Using the touchscreen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
The onscreen keyboard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
The Home screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Managing contacts
Managing your contacts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Making Calls
Before making a call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Making a call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
The voice call screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Onscreen call options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Messaging
Creating a new message . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Replying to a message . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
MMS messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
Going online
Browsing the Internet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
Setting up Email . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Online applications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Using the Camera
Camera icons and indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Taking a photo . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
Shooting a video . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
Viewing photos and videos . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Advanced Settings
Putting your smartphone in Airplane mode . . . . . . . . . . . . . . . . . . . . . . .27
Acer Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Activating or deactivating connections . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Adjusting connection settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
Phone settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
urFooz . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
Connecting to a PC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
Managing your calendar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
GPS tracker . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
![](/img.php?id=1308448&img=bg6.png)
6
FM radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33
Multimedia playback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33
Resetting your smartphone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Accessories and Tips
Using the headset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Using a Bluetooth headset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Using your smartphone as a modem . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38
Setting up the modem on your PC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38
Inserting a microSD Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Appendix
FAQ and troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Other sources of help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40
Aux ADB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Warnings and precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .41
Emergency calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Disposal and recycling information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44
Taking care of your smartphone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .46
Regulatory information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
![](/img.php?id=1308448&img=bg7.png)
7Features and functions
Getting to know your smartphone
Features and functions
Your new smartphone offers leading, easy-to-access multimedia and
entertainment features. You can:
• Access your email while on the move.
• Connect to the Internet at high speed, via HSDPA (3.6 Mbps) or Wi-Fi.
• Keep in touch with your friends via your Contacts and social networking
applications.
Product registration
When using your product for the first time, it is recommended that you
immediately register it. This will give you access to some useful benefits, such
as:
• Faster service from our trained representatives.
• Membership in the Acer community: receive promotions and participate
in customer surveys.
• The latest news from Acer.
Hurry and register, as other advantages await you!
How to register
To register your Acer product, please visit http://mobile.acer.com. Click Product
Registration and follow the simple instructions.
You can also register directly from your smartphone by tapping Acer
Registration.
After we receive your product registration, you will be sent a confirmation
email with important data that you should keep in a safe place.
![](/img.php?id=1308448&img=bg8.png)
8
Chapter 1: Setting Up
Unpacking your smartphone
Your new smartphone comes packed in a protective box. Carefully unpack the
box and remove the contents. If any of the following items is missing or
damaged, contact your dealer immediately:
•Acer beTouch E120 Smartphone
• Battery
• Quick Guide
• USB cable
• AC adapter
• Headset
Getting to know your smartphone
Views
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
No. Item Description
1 Phone speaker Emits audio from your smartphone; suitable for
holding to your ear.
2 Volume up / down button Increase or decrease the phone volume.
3 Touchscreen 2.8-inch, 320 x 240 pixel resistive touchscreen to
display data, phone content and enter information.
4 microSD card slot Insert a microSD card.
![](/img.php?id=1308448&img=bg9.png)
9Getting to know your smartphone
LED indicators
5 Home button Return to the Home screen; press and hold to view
recently-used applications, tap an icon to open the
associated program.
6 Search button Open the Google search function.
7 Call button Activate phone/dial/view recently dialed numbers/
answer a call.
8 Navigation buttons 4-way navigation control to move the cursor.
9 Center button Press the center button to activate the selected item.
10 Microphone Internal microphone.
11 End button / Power button Press to end a call. / Press to turn the screen on/off or
enter sleep mode; press and hold to turn the
smartphone off.
12 Back button Go back one menu step; close the keyboard.
13 Menu button Open the option menu; press and hold to display the
keyboard.
14 Micro USB connector Connect to a USB cable/charger.
15 LED indicator Indicates battery level and event status.
16 3.5 mm headphone jack Connect to stereo headphones.
17 Camera A 3-megapixel camera for taking high-resolution
images.
18 Handsfree speaker Emits audio from your smartphone; suitable for
handsfree use.
No. Item Description
Red Steady Battery is charging.
Slow flashing Battery level is low.
Flashes twice rapidly Battery level is critically low.
Flashes rapidly Battery level is too low to start the phone.
Flashes every 10
seconds
New event (missed call, new message, voicemail, etc.)
No. Item Description
![](/img.php?id=1308448&img=bga.png)
10
Installing or removing the battery
Your smartphone uses a replaceable battery to provide power. It is packed
separately from your smartphone and needs to be inserted and charged before
you can use the smartphone.
Installing the battery
2
1
Insert your fingernail into the cutout between
the battery cover and the phone. Unclip the cover
and lift off the battery cover.
Place the battery into the battery compartment,
lining up the battery connectors with those at the
bottom of the compartment.
Insert the tabs on the bottom of the battery cover
into the slots in the phone. Carefully press the top
of the cover until the clips on the side of the
cover click in place.
CAUTION: RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE.
DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS.
Charging the battery
For initial use, you need to charge your smartphone for eight hours. After that
you can recharge the battery as needed.
Connect the AC adapter cord to the micro USB connector on your smartphone.
Removing the battery
Open the battery compartment as shown in “Installing the battery“. Lift the
battery out of the compartment using the clip on the top of the battery.
Replace the battery cover as described above.
![](/img.php?id=1308448&img=bgb.png)
11Installing a SIM and microSD Card
Installing a SIM and microSD Card
To take full advantage of your smartphone’s telephony capabilities, you must
install a SIM card. The SIM card holder is located at the bottom of the battery
bay.
Additionally, you may wish to increase your smartphone’s storage by inserting a
microSD Card into the slot provided. This is next to the SIM card slot.
1. Turn off the phone by pressing and holding the power button.
2. Open the cover and remove the battery.
3. Insert the SIM card and microSD card as shown.
4. Replace the battery and battery cover.
Note: Ensure that the microSD Card is inserted all the way into the card slot.
Caution: Turn off your smartphone and remove the battery before installing or
removing the SIM or microSD card. You may damage the card or your smartphone if
the battery is still installed.
SIM card lock
Your smartphone may come with a SIM card lock, i.e., you will only be able to
use the SIM card provided by your network operator.
To cancel the SIM lock, contact your network provider.
![](/img.php?id=1308448&img=bgc.png)
12
Chapter 2: Using your Smartphone
Turning on for the first time
To turn on your smartphone for the first time, press and hold the power button
until the screen turns on. You will then be asked to configure some settings
before you can use your smartphone.
Follow the onscreen instructions to complete setup.
Sign in to or create a Google account
If you have Internet access, your smartphone allows you to synchronize
information with a google account.
During the start-up process, you may create or sign in to your account, which
will be used to synchonize your contact list, email, calendar and other
information. If you do not yet have Internet access then tap Try Again, but then
tap Back and then skip the connection step.
Entering your PIN
When you install a SIM card for the first time, you may need to enter a PIN
using the onscreen number pad.
Important: Depending on your settings, you may be required to enter your PIN each
time you switch on the phone function.
Activating a new SIM card
If you are using your SIM card for the first time, it may require activation.
Contact your network operator for details on how to do this.
Using the touchscreen
Your smartphone uses a touchscreen for selecting items and entering
information. Use your finger to tap the screen.
Tap: Touch the screen once to open items and select options.
Drag: Hold your finger on the screen and drag across the screen to select text
and images.
Tap and hold: Tap and hold an item to see a list of actions available for that
item. On the pop-up menu that appears, tap the action you want to perform.
Scroll: To scroll up or down the screen, simply drag your finger up or down the
screen in the direction that you want to scroll.
![](/img.php?id=1308448&img=bgd.png)
13The onscreen keyboard
The onscreen keyboard
When you tap a text box to enter text, the onscreen
keyboard will automatically display.
The Home screen
After rebooting, your smartphone will display the
Home screen. This screen gives you quick, icon-based
access to many of the frequently-used features of
your smartphone.
The first time you start your smartphone, you will see
some icons on the screen.
At the bottom of the screen is the Applications tab
which lists all the applications you have installed. Tap
the tab to open the Applications tab. Tap an icon to
open the application.
Multitasking
You can have multiple applications open at the same time. To open a new
application, press the Home button to return to the Home screen, then start the
new application.
To view your active applications, press and hold the Home button. Then tap an
icon to go to the application.
Tip: To prolong battery life, it is better to close an application when you’ve finished
using it. Do this by either pressing the Back key or the Menu button and selecting Exit
(if available).
The extended Home screen
The Home screen extends to either side of the screen, giving you more room to
add icons, widgets or features. To view the extended Home screen slide your
finger to the left or right of the Home screen.
![](/img.php?id=1308448&img=bge.png)
14
Notification area
The Notification area is at the top of the screen.
This area contains a variety of icons to inform you of your phone’s status. The
left side of the Notification area displays event icons that indicate a new event
(such as a new message). The icons on the right side indicate signal strength,
connection, battery status and the time.
Drag the Notification area down the screen, or tap the area, to view more
information about new events.
Personalizing the Home screen
You may personalize your Home screen by adding or removing icons, shortcuts
or widgets, or changing the wallpaper.
Icon Description
Indicates that storage is running low. Remove programs or files to increase the
available storage.
SD Card removed.
WLAN signal strength.
Vibrate mode enabled.
SIM card is invalid or not installed.
Battery status.
Missed call.
New/unread SMS.
New/unread MMS.
New/unread email.
HSDPA connected: Downloading data.
3G connected: You may make a call.
Connected to a 2G network: You may make a call.
Airplane mode: Wireless connectivity disconnected. Please disable airplane
mode before trying to make a call.
Incoming call or active call.
![](/img.php?id=1308448&img=bgf.png)
15The Home screen
Adding or removing icons
You can set icons for installed applications on the Home screen. Tap and hold
an icon in the Applications tab to copy it to the Home screen. To remove an
icon from the Home screen, tap and drag the icon from the Home screen to the
trash tab that appears at the bottom of the screen.
Adding or removing shortcuts or widgets
To add shortcuts or widgets, tap and hold anywhere on the Home screen to
open the Add to Home screen menu.
Tap Shortcuts to open a list of quick links to
applications and settings you can add to the Home
screen.
Tap Widgets to open a list of small applications that
you can add to your Home screen. Widgets are handy
applications that you can add to your Home screen to
display various information.
You can also add folders to your Home screen. There
are some pre-defined folders available or you can add
a New folder. This will be placed on your Home screen
and named Folder. To change the name of the folder,
tap to open it. Tap and hold the name bar at the top
of the folder window to open a dialog box that will
allow you to rename the folder.
![](/img.php?id=1308448&img=bg10.png)
16
Chapter 3: Managing contacts
Managing your contacts
Your smartphone features an address book that allows you to save contacts to
either the internal memory or onto your SIM card.
Tap Contacts from the Home screen or the Contacts tab from the Dialer to view
your contacts.
If you don’t have any contacts stored on your phone, you can import your
Google account contacts, add a new contact or import any SIM contacts. Press
the Menu button to open the menu.
Adding a contact
Tap New to add a new contact. You will be asked if you want to create a SIM
contact or a Phone contact.
To create a contact, you will be asked to enter the
contact’s:
• Given and Family name.
• Phone numbers.
• Email addresses.
•IM addresses.
• Postal addresses.
You may also:
• Enter information such as organizations the
contact belongs to.
• Any personal notes about the contact.
• Set a ringtone.
• Send any calls from this contact directly to your voicemail.
Icon Description
Search for a contact.
Add a new contact.
Display the contacts you have assigned to a group.
Delete contacts.
Import contacts.
Export contacts.
![](/img.php?id=1308448&img=bg11.png)
17Before making a call
Chapter 4: Making Calls
This chapter shows you how to make phone calls, and the various options
available to you during your call.
Before making a call
Check that the phone function is on before you make a call. You can confirm
the phone status from the icon on the right-hand side of the Notification area.
Making a call
Note: The phone function needs to be enabled before the call can be connected.
1. From the Home screen tap Dialer or open Dialer
from the menu to open the onscreen number pad.
2. Enter the number you wish to dial.
3. Press the Call button to make the call.
4. To end the call, press the End button.
Dialing a number from Call Log
Your call history can be viewed by tapping the Call
Log tab. It displays recent received, dialed, and missed
calls.
Tap a number to view the call details. To redial any
number in the call history, select the number and tap
. You may also tap and hold the number to open a menu with other options:
Call <the number>; Edit number before call; Send SMS/MMS; Add to contacts or
Remove from call log.
Missed calls will be displayed by the call indicator on the top of your phone and
in the Notification area with the icon .
You can also view missed calls from the Notification area.
1. Open the notification list by tapping and dragging the Notification area
downwards to display the details of the missed calls.
2. Select the call from the list and tap to return the missed call.
You can save phone numbers to your Contacts from the Call Log. Please refer to
“Adding a contact“ on page 16 for further details.
Icon Description
Connected: You may make a call.
Airplane mode: Wireless connectivity disconnected. Please disable airplane mode
before trying to make a call.
![](/img.php?id=1308448&img=bg12.png)
18
Making a call to one of your contacts
1. Tap the Contacts tab in the dialer or Contacts from the Home screen to view
your contacts.
2. Tap a contact. A dialog will open, asking if you want to Call the contact or
send the contact an SMS.
Dialing an international number
When dialing international numbers, there is no need to enter the
international direct dialing prefix (‘00’ etc.) before the country code. Simply tap
and hold 0+ on the onscreen number pad until + appears onscreen.
Warning: International call rates can vary greatly depending on the country you are
calling and your network provider. We suggest you check all call rates with your
network provider, to avoid excessive phone bills. If you are using your smartphone
abroad, roaming charges will apply. Consult your network provider for roaming rates
specific to the country you are visiting before you leave.
The voice call screen
Once you have dialed your number the voice call screen appears, which displays
the number/contact you are talking to, the call duration and the dialpad tab.
Onscreen call options
Answering a call
Press the Call button to answer a call.
Rejecting a call
Press the End button to reject a call.
Ending a call
To end a call, press the End button.
Using the speakerphone
The speakerphone function allows you to make calls without having to hold
your smartphone. This handsfree function is especially useful for multitasking.
To activate the speakerphone, tap Speaker on the voice call screen. Tap Speaker
again to disable the speakerphone.
Muting a call
To mute a call, tap Mute on the voice call screen to switch off the microphone.
Tap Mute again to switch the microphone back on.
![](/img.php?id=1308448&img=bg13.png)
19Onscreen call options
Saving a dialed number to contacts
You can save a number you have dialed to your contacts for future use.
1. Select the number from the Call log tab, and tap Add to contacts.
2. Tap Create new contact and select how to complete the action. Please refer
to “Adding a contact“ on page 16.
Conference calls
If you have one call on hold and another online, you can combine both calls to
create a conference call.
After the first call is established, tap Add call to add a second call. Tap Merge
calls to start the conference call.
![](/img.php?id=1308448&img=bg14.png)
20
Chapter 5: Messaging
This chapter shows you how to set up and use the SMS and MMS functions of
your smartphone.
All SMS and MMS messages are accessed via Messaging. Messaging
automatically arranges received and sent messages into threads.
To access Messaging tap Messaging on the Home screen.
Creating a new message
You can use your phone to compose SMS or MMS
messages.
Tap New message to compose a new message.
Enter the recipient’s phone number or name in the To
field. Suggested contacts will be displayed in a drop-
down list below the text field. To select a suggested
contact, tap the contact’s name.
Once you have entered the recipient, enter your
message in the text box labeled Type to compose.
Note: SMS messages may be up to 160 characters long. If your message is longer than
160 characters, it will be sent as multiple linked messages. Most phones will
automatically join the linked messages to present the recipient with a single long
message, however, some older phones do not have this ability.
Press the Menu button to see what options are available when creating a new
message.The options change depending on the status of the message.
Icon Description
Convert the SMS to an MMS, allowing you to add a subject to the message.
Convert the SMS to an MMS, allowing you to attach a file to the message.
Discard the message.
View all the threads currently on your phone.
![](/img.php?id=1308448&img=bg15.png)
21Replying to a message
Replying to a message
When a new text message arrives a message icon appears in the Notification
area and the message icon on the top of the phone lights up.
Tap Messaging on the Home screen to view the message list or expand the
Notification area to see a summary of the message. Tap the summary to open
the message list.
To reply to an SMS or MMS message, open the message from the message list.
Enter your text in the text box labeled Type to compose. Press the Menu button
to see available options.
MMS messages
MMS messages are similar to text messages but also allow you to attach
multimedia files such as pictures, audio or video clips. Each MMS message can
be up to 300 kB in size.
Note: You need to set up an MMS profile before you can send MMS messages.
Normally, your smartphone will set up the profile for you based on information
retrieved from your provider.
Tip: Ask your network provider for the necessary information if you need to manually
set up the MMS profile.
Icon Description
Open the Dialer to call the recipient.
Convert the SMS to an MMS, allowing you to add a subject to the message.
Convert the SMS to an MMS, allowing you to attach a file to the message.
Send the message.
Insert a smiley/emoticon into your message text.
Show other available options.
![](/img.php?id=1308448&img=bg16.png)
22
Receiving MMS messages
When a new MMS message arrives, a message icon appears at the top of the
screen and a notification message is displayed.
1. Open Messaging to view a summary of the message.
2. Tap Download to download the message content.
Note: Downloads can take a long time, depending on your connection quality. If you
reply or open another application, the download will be stopped.
Important: You may be charged to download message content, especially if you are
roaming. Please contact your provider if you have any questions.
3. Tap the message to view the content.
4. Press the Menu button and tap Reply. Enter your
text in the text box labeled Type to compose and
tap Send. Simple text replies will be sent as SMS
messages. If you wish to attach a file, press the
Menu button and tap Attach. You will be
presented with a menu of options.
5. When you have finished composing the message,
press the Menu button and tap Send.
![](/img.php?id=1308448&img=bg17.png)
23Browsing the Internet
Chapter 6: Going online
Browsing the Internet
In order to browse the Internet with your smartphone, you must be connected
to a data or wireless network.
Using the browser
Tap Browser on the Home screen to start browsing. To open a new website, tap
the address box at the top of the page. Enter the address using the keyboard
and tap Go.
To view your browsing history, bookmarks or frequently visited sites, open the
browser then press and hold the back button.
You may open multiple pages. When a page is open, press the Menu button
and tap New window from the menu that opens. Tap Windows to view all the
windows that are open.
You can zoom in or out of pages using the zoom bar that appears when you
tap the screen. Tap and hold an item on a page to open a contextual menu.
Setting up Email
Your smartphone enables you to access your email.
Most popular ISPs can be set up in two steps. Tap the
Applications tab and then Email to start setting up
your email access.
If necessary, enter your email address and tap Manual
setup to enter the parameters manually. Tap Next to
finish the setup process.
The combined inbox feature of your smartphone
allows you to view emails from multiple accounts in a
single inbox.
![](/img.php?id=1308448&img=bg18.png)
24
Online applications
Your smartphone has a variety of applications installed on it from the factory.
Note: Applications installed may vary according to your region.
These applications may include:
•Facebook: View your Facebook profile and keep up-to-date with friends.
•Maps:Get easy-to-follow directions using Google Maps.
•YouTube: View the Most viewed and Most discussed video clips on
YouTube.
Android market
Note: The Android Market may not be available in all countries and regions.
Note: You need to have a Google account set up and active on your phone before you
can use the Android Market.
Tap Market from the applications tab to open the
Android Market. Here you can obtain a variety of
add-on programs and applications to enhance the
functionality of your smartphone. The first time you
access the Android Market, you will need to read and
accept the Terms of Service.
You can browse the market by category or tap the
search icon to search for a specific application.
Once you have selected an application, tap the Install
button to download and install the application. You
will be told which services on your phone that the
application has access to. Tap OK to proceed with the
installation.
You may keep track of the download progress from the Notification Area.
Important: Some applications may require payment before you can download them.
You will need to have a Google Checkout account in order to pay for these
applications.
Uninstalling downloaded applications
Once you’ve downloaded and installed an application, you may uninstall the
application by tapping Settings from the Applications tab. Select Applications >
Manage applications. Tap the application you wish to uninstall, tap Uninstall
and confirm the uninstall.
![](/img.php?id=1308448&img=bg19.png)
25Camera icons and indicators
Chapter 7: Using the Camera
Your smartphone features a 3-megapixel digital camera mounted on the rear.
This section will take you through all the steps in taking photos and videos with
your smartphone.
Note: You need to have a microSD Card inserted into the microSD Card slot before
using the camera.
To activate the camera, open the Applications tab and tap Camera.
Camera icons and indicators
In the camera window, use the zoom slider at the bottom of the screen to
adjust the zoom. Tap to take a picture.
Icon Description
Indicates the last photo taken.
Slide to adjust brightness.
Slide to switch between camcorder and photo mode.
Shutter button. Tap to take the photo. Changes to Record or Stop in
video mode.
Tap to zoom in or out.
![](/img.php?id=1308448&img=bg1a.png)
26
Camera settings menu
Tap the Menu button to open the Camera settings menu.
•Store location picture
• Jpeg quality
• Prompt after capture
•Grid
• Enable shutter sound
• Antibanding
• Resolution
• White balance / lighting
• Select effect
• Scene mode
• Flash mode
Taking a photo
1. Ensure you have adjusted the parameters described above.
2. Frame your subject and steady your smartphone.
3. Zoom in or out as needed.
4. Tap to take a picture.
Shooting a video
To turn on camcorder mode, tap the Menu button and Select Switch to video.
1. Frame your subject and steady your smartphone and zoom in or out as
needed.
2. Tap the Record button to begin recording. Tap again to stop recording.
Supported formats
Viewing photos and videos
After you have taken your photo or video, it is automatically saved.
Once you have taken a photo or video, you can view it in Gallery by tapping the
thumbnail icon in the upper right corner. Alternatively, open the Applications
tab and tap Gallery. From Gallery you can share the file directly using various
services.
Note: Share options vary depending on the file type.
Type Formats
Image JPEG
Video MPEG-4, H.263
![](/img.php?id=1308448&img=bg1b.png)
27Putting your smartphone in Airplane mode
Chapter 8: Advanced Settings
Putting your smartphone in Airplane mode
You can enter Airplane mode (also known as flight mode) to turn off telephone
and Bluetooth functions and use your smartphone as a handheld device during
a flight. Check with your airline to make sure this is permitted onboard.
Switch your smartphone off during takeoff and landing as it may interfere with
aircraft electronic systems.
Turning Airplane mode on or off
Note: When Airplane mode is active, the
icon will be displayed in the Notification
area.
1. Press and hold the power button until you get the
phone options menu.
2. Tap Airplane mode to switch it ON or OFF.
Acer Settings
Acer Settings is a convenient all-in-one place for you to
adjust commonly-used settings on your phone. Open the
Applications tab and tap Acer Settings.
From this screen you can turn Bluetooth on or off or adjust
their settings by tapping .
You can also set your Phone network settings, set the screen
Brightness or Screen Timeout.
Important: If your phone is in Airplane mode, the option to turn Bluetooth on will be disabled.
Please refer to “Putting your smartphone in Airplane mode“ on page 27 for instructions on
turning Airplane mode on or off.
![](/img.php?id=1308448&img=bg1c.png)
28
Activating or deactivating connections
Open the Applications tab and tap Settings > Wireless controls to manage your
connection settings.
Each connection icon will be highlighted when turned on.
Phone network settings
Tap Mobile networks to adust your network settings. You can turn data
connection on or off when roaming, restrict the connection to 2G networks
only, specify a network operator and define access point names. Please refer to
“Selecting a network“ on page 29.
Adjusting connection settings
This section will show you how to adjust detailed settings for your phone, data,
Wi-Fi and Bluetooth connections.
Sound & display
Once you have inserted a SIM card, your smartphone will automatically detect
your network provider.
You can adjust your phone settings by tapping Settings > Sound & display.
Item Description
Wi-Fi Turn the Wi-Fi function on or off.
Wi-Fi settings Set up and manage your wireless access points.
Bluetooth Turn the Bluetooth function on or off.
Bluetooth settings Manage your Bluetooth connections, set a device name and
discoverability.
Mobile networks Set your options for connecting to mobile networks.
Airplane mode Disable all wireless connections so you can safely use this device
onboard an aircraft.
Item Description
Silent mode Turn off all sounds except for alarms and media.
Ringer volume Adjust the ringer volume.
Media volume Set the playback volume for media.
Phone ringtone Set your phone’s ringtone.
Phone vibrate Turn the vibrate function on.
Notification ringtone Set a ringtone for notifications.
Audible touch tones Play tones when using dial pad.
Audible selection Play a sound whenever a screen selection is made.
SD card notifications Play a sound for SD card notifications.
Orientation Switch screen orientation when the smartphone is rotated.
Animation Animate when opening or closing windows.
![](/img.php?id=1308448&img=bg1d.png)
29Phone settings
Selecting a network
Your phone wil automatically detect your carrier/network settings when you
insert a new SIM card. However, you may prefer to manually select a network.
This may be a good idea when roaming.
Tip: When you are traveling, manually selecting a network may help to reduce your
roaming charges. Check with your home service provider for the network offering the
most competitive rates at your destination.
1. Open the Applications tab and tap Settings > Wireless controls > Mobile
networks > Network operators.
2. Your phone will search for available networks.
3. Select your preferred network from the list generated. You phone will
attempt to register on the selected network.
4. Tap Select automatically to connect to the available network with the
strongest signal. This may lead to your phone jumping between networks
when you move around.
Note: Contact your service provider should you have any problems obtaining voice
mail and the text message service center numbers.
Adjusting Bluetooth settings
You can use Bluetooth to exchange information between your smartphone and
other mobile devices.
Bluetooth connections
For all Bluetooth settings, open the Applications tab and tap Settings > Wireless
controls > Bluetooth settings. Here you can switch Bluetooth on or off, set a
device name and discoverability. Tap Scan for devices to scan for available
devices.
To connect to a device, tap the device in the list of available devices. You may
be asked to enter a PIN on both devices to establish the connection.
Phone settings
Many phone settings are automatically configured by your smartphone when
you insert a SIM card. The device will communicate with your provider and
automatically obtain all necessary settings, such as network name, voice mail
and text message center numbers.
Brightness Adjust screen brightness.
Screen timeout Set a delay before the screen will be turned off.
Notification LED Turns notification LED indicators on or off.
Item Description
![](/img.php?id=1308448&img=bg1e.png)
30
You can also view and modify these settings manually through the Phone
Settings screen.
Open the Applications tab and tap Settings > Call settings.
urFooz
urFooz is your portable profile that lives where you live.
•Fooz Creator lets you create a Fooz avatar, which is your virtual look-a-like.
•Fooz World lets you edit and manage your Fooz avatar(s), create new avatars and
share them on Facebook, MySpace, blogs and more.
•Share it lets you post your Fooz card to Facebook, MySpace and other social net-
works. You can also email it to your friends.
You can email your Fooz card to friends, or post it to your social networks and
blogs and always be connected.
Launching urFooz
To launch urFooz, tap UrFooz from the applications tab.
Creating your urFooz avatar
If you have not yet set up an account to urFooz,
tap the Get Started button. If you have an existing
urFooz account, select Sign in and login with your
email and password.
To start creating your avatar, select your Gender,
Ethnicity, Zodiac Sign, Relationship Status and
Areas of Interest.
Next, start customizing your avatar. Tap Features
to choose your face shape, eyes, nose, mouth and
other facial features. Select Clothing to dress your
svatar. Select Accessories to choose other items
such as earrings, headbands, and whatever else to
give your Fooz avatar your personal touch. Simply
tap the image to apply the item to your avatar
and preview how it looks on the left side of the
screen.
Select SAVE and type in a name for your Fooz avatar. The next screen will ask
you for the email address, password, and required user information. The email
and password you enter will be used to sign into your urFooz account.
Managing your avatar
Now that you have created your Fooz avatar, go
to Fooz World and personalize your Fooz card, or
your portable profile.
Select Profile/Apps to fill in your profile and other
information such as bookmarks of your social
network profiles and favorite websites.
![](/img.php?id=1308448&img=bg1f.png)
31Connecting to a PC
Select Switch Avatar to change your default avatar, modify existing avatars, or
create a new avatar.
Sharing your Fooz card and avatar
urFooz lets you share your Fooz card with friends
by posting it to your social networks, blogs, and
websites; or emailing it to friends.
In Fooz World, select Share it. Select Post to post
your Fooz card to Facebook or other social
networks, or select Email to email your Fooz card
to a friend.
Note: Fuhu, Spinlets, Spinlet, urFooz, Fooz Avatars, Fooz Creator, Fooz Card, and Fooz
World are trademarks or registered trademarks of Fuhu, Inc. in the U.S. and/or other
countries.
Connecting to a PC
If you wish to transfer information between the microSD Card in your phone
and your computer, you can connect your phone to a PC using the supplied USB
cable. Plug the USB sync cable into the micro USB connector on your
smartphone. Plug the USB client connector into an available USB port on your
computer.
Pull down the notification bar, and tap USB Connected. Click Mount.
You will now be able to see the microSD Card in your phone as a drive in your
computer’s file explorer.
Note: After mounting, you will not be able to access the files in the microSD card or
applications such as Gallery or Music.
Synchronizing your calendar
You can sync your calendar on your phone with your Google calendar. Tap
Calendar from the Applications tab to connect to your Google calendar and
sync appointments.
Note: You need a Google account to sync your calendar and appointments.
![](/img.php?id=1308448&img=bg20.png)
32
Managing your calendar
The Calendar allows you to keep track of your events and tasks. You can access it by
tapping Calendar on the home screen or in the Applications tab.
The Calendar offers a variety of viewing modes and settings to manage your events. Tap
Menu and you will see the following options:
•Agenda
•Day
• Week
•Month
• New event
• Today
•More
• Hide declined events
•Set alerts & notifications
• Select ringtone
• Vibrate
• Set default reminder
Adding a new event
To add a new event, tap Menu and tap New event. Under Event details you have the
option of filling out:
•Event name
•From
-
Date and time
•To
-
Date and time
•Location
•Description
• Repetition
• Reminder intervals
GPS tracker
The GPS tracker will determine the precise location of the device at regular intervals.
The tracker provides information on GPS time, tracking distance, moving speed, trackers,
and point of interest (POI).
You can track your location by tapping . You can also
pause, mark a POI ( ) and save your progress by tapping on
the diskette.
Tapping Menu provides additional settings:
•Mode
-
(adjust data gathering intervals)
• Walk
-
6-second intervals
• Bicycle
-
4-second intervals
•Car
-
2-second intervals
•Format
-
Saved file format
• Save to path
•Hide
![](/img.php?id=1308448&img=bg21.png)
33FM radio
FM radio
The FM radio allows you to listen to your favorite stations while on the move.
Headphones must be inserted to the 3.5 mm jack as it functions as an antenna.
You can access the radio by tapping Radio from the Applications tab. Once the
application is open, turn the radio on by tapping Menu and Turn on. You can now leave
the radio application and use other functions of the smartphone and listen to your
station.
To turn the radio off, return to the radio application and tap
Menu and Turn off.
Other functions are available through the Menu such as:
•Mute
• Set frequency
•Scan
•Save
•More
• Speaker on
•R
DS
• Station list
• Send station info
Multimedia playback
Your smartphone comes supplied with a variety of programs that you can use
to enjoy multimedia content.
nemoPlayer
Open nemoPlayer from the applications tab to play media you have stored on
your phone.
nemoPlayer enables you to listen to music, view video clips and pictures in the
following formats.
Note: Music recognition technology and related data are provided by Gracenote®.
Gracenote®, Gracenote logo and logotype, and the "Powered by Gracenote" logo are
either a registered trademark or a trademark of Gracenote, Inc. in the United States
and/or other countries.
Type Formats
Audio playback MP3, AMR, WMA
Ringtone MP3, MIDI, iMelody, WAVE, WMA
Video recording 3GP, MPEG-4, H.263
Video playback 3GP, MPEG-4, H.263, H.264, WMV
![](/img.php?id=1308448&img=bg22.png)
34
Spinlets
Spinlets gives you access to your favorite music, movie and television content.
Get your favorite music, photos and videos from your mobile phone and share
your favorite Spinlets on social networks, websites and more.
Note: Some contents may not be available in some countries.
Launching Spinlets
To launch the Spinlets application, tap Spinlets in the applications tab.
Browsing Spinlets gallery
You can sort or search your media content by albums or genres.
Browsing albums
Once Spinlets is opened, you will see a display of
featured albums. Browse this display by sliding your
finger horizontally (left or right), and select an album
by tapping it.
Browsing genres
To browse the Gallery by genre, tap the Genres
button on the bottom left corner of the screen. You
will see a new screen with a list of different genres.
Tap on the genre you wish to view.
Sort
To sort through Spinlets by Name, Ratings, or Newest
content, select the Sort button at the bottom of the
screen.
Search
To search the Gallery for a specific name, select the
Search button at the bottom right corner of the screen. Type the name of an
artist in the search box and find potential matches.
![](/img.php?id=1308448&img=bg23.png)
35Multimedia playback
Exploring Spinlets widgets
When you select an album, you will see a Spinlet.
To play the featured song, select the red Play button.
To play selected songs, select the Music tab and
choose which songs you would like to play.
To view artist photos, select the Photos tab.
To visit the artist's social networks and websites, select
the icons located along the bottom of the screen.
Sharing your Spinlets
You can share your favorite Spinlets in two ways.
To post the Spinlet you are currently viewing to your
social networks, blogs, or other websites, tap Share It
at the top right corner of the Spinlet. Select Post it
and tap the icon of the social network site or blog you
want to post the widget to. Log in to your social
network account or blog page and follow the steps.
You can also share Spinlets through email. Tap Share
It at the top right corner, select Send it, and enter
your name and your friend’s email address.
Note: Fuhu, Spinlets, Spinlet, urFooz, Fooz Avatars, Fooz Creator, Fooz Card, and Fooz
World are trademarks or registered trademarks of Fuhu, Inc. in the U.S. and/or other
countries.
Adjusting the volume
Adjust the volume of your phone using the volume button on the side of the
phone. Alternatively, you can set the Ringer volume and Media volume by
opening the Applications tab and going to Settings > Sound & display.
Setting the date and time
To set the date and time, open the Applications tab and tap Settings > Date &
time.
Tip: If you travel frequently or live in an area that uses daylight saving time, activate
Automatic from this menu. This will enable your smartphone to set the date and time
based on information it receives from the network.
![](/img.php?id=1308448&img=bg24.png)
36
Setting alarms
There are three predefined alarms on your phone by
default. To edit alarm settings, tap Alarm Clock in the
Applications tab. You may:
• Turn the alarm on or off.
• Set the alarm time.
• Set a ringtone.
• Enable or disable vibrate.
• Set which days to repeat the alarm.
• Give it a label.
Changing location and text options
Set your location and language input preferences by opening the Applications
tab and going to Settings > Locale & text.
Managing applications
Warning! Make sure you trust the source of any program you install. If you are not
sure of the source, do not install a program. Installing programs from unknown
sources increases your risk of virus attacks and theft of personal and private data.
You can remove programs installed on your smartphone to free up extra
storage memory. Open the Applications tab and go to Settings > Applications.
Here you can allow programs from Unknown sources to be installed and
Manage applications.
Warning! You should only remove programs if you are familiar with the Android
operating system.
Resetting your smartphone
You may have to perform a reset if your smartphone fails to respond when
buttons are pressed or the screen is tapped.
Note: Before performing a reset, ensure that your smartphone is not locked. Press any
key or tap the screen to see if the phone responds.
![](/img.php?id=1308448&img=bg25.png)
37Resetting your smartphone
Clean boot
A clean boot will restore your smartphone to the factory settings.
Warning! You should only perform a clean boot when all other options have failed to
restore your smartphone to an operational state.
Warning! This will erase all your personal information, any contacts stored on your
phone and any programs you installed.
If your phone is responding to screen input
Open Settings from the Applications tab, then tap Privacy > Factory data reset;
click Reset phone and then Erase everything to format your phone.
![](/img.php?id=1308448&img=bg26.png)
38
Chapter 9: Accessories and Tips
This chapter shows you how to use accessories with your smartphone, as well as
provide useful tips for when you are using your smartphone.
Using the headset
Your smartphone comes packaged with a headset with built-in microphone for
handsfree use when making calls.
To use the headset, plug it into the 3.5 mm headphone jack at the top of the
phone.
When the headset is plugged in, all audio is routed to the headset, and the
speakers are turned off.
• To answer an incoming call, press the button on the microphone.
• Adjust the volume using the volume up/down button on the
smartphone.
• End the call by pressing the button again.
Using a Bluetooth headset
Your smartphone’s Bluetooth functions make it fully compatible with all
Bluetooth headsets. This allows you to use the unit handsfree when making
calls, without the inconvenience of wires.
Using your smartphone as a modem
When connected to the PC, your smartphone can function as a modem via GPRS
or 3G connection.
When you insert your SIM card, please ensure the data connection setting is
enabled. Click Settings > Wireless controls > Mobile networks > Data enabled.
Your phone will automatically configure itself to use your provider’s GPRS/3G/
EDGE service.
Note: You may incur additional charges depending on your data plan.
Setting up the modem on your PC
Connect your smartphone to a PC via USB, and do the following steps:
1. Install Acer PC Suite on your PC or notebook.
2. After the installation is complete, click Start > All Programs > Acer > Acer PC
Suite > Acer PC Suite to launch the application.
3. Click Easylink to run Easy link.
4. Click Select Device.
5. Click Refresh in the Select Device window to detect a standard modem port.
Select the port and click Select.
![](/img.php?id=1308448&img=bg27.png)
39Inserting a microSD Card
6. Click Connect to start dialing up to data network.
Note: If the connection fails, restart and reconnect your smartphone to your PC, and
then repeat the installation.
Note: Updates are available at the Acer website. Visit http://mobile.acer.com.
Creating a new access point
When you need to add another GPRS/3G/EDGE connection on your phone,
obtain the access point name and settings (including username and password if
required) from your wireless service provider.
1. Open the Applications tab and tap Settings > Wireless controls > Mobile
networks > Access Point Names.
2. Press the Menu button and tap New APN.
3. Enter the APN settings. Tap an item to adjust it.
4. When you have finished press the Menu button and tap Save.
Important: Some providers and countries do not allow the use of a smartphone as a
modem over HSDPA. Please check with your provider before attempting to do so.
Inserting a microSD Card
Your smartphone features a memory expansion slot that accepts a microSD
Card to expand memory and storage capacity.
Please refer to “Installing a SIM and microSD Card“ on page 11 for instructions
on installing a microSD Card.
![](/img.php?id=1308448&img=bg28.png)
40
Chapter 10: Appendix
FAQ and troubleshooting
This section lists frequently asked questions that may arise during the use of
your smartphone, and gives easy answers and solutions to these questions.
Other sources of help
Refer to:
Aspect Question Answer
Audio Why is there no sound
coming from the
device?
If the headset is plugged into the device,
the speaker is automatically shut off.
Disconnect the headset.
Check that the device volume setting is not
muted.
Check that the volume control is not at its
lowest setting.
Multimedia files Why can’t I view my
picture files?
You may be trying to view an image that is
not supported. Refer to “Multimedia” on
page 46 for more information.
Why can’t I view my
video files?
You may be trying to view a video that is
not supported. Refer to “Multimedia” on
page 46 for more information.
Why can’t I play my
music files?
You may be trying to play a file that is not
supported. Refer to “Multimedia” on
page 46 for more information.
System information
and performance
How do I check the OS
version of my device?
Tap Menu > Settings > About phone to
check the OS version (Kernel/build number)
and other hardware and software
information.
Power I couldn’t turn on the
device.
The battery power may be depleted.
Recharge the device. Refer to “Charging the
battery” on page 10 for more information.
Heat The phone heats up
when charging or
making long duration
calls.
It is normal for the phone to heat up when
charging. When charging is complete, it will
return to its normal temperature.
It is also normal for the phone to heat up
during long periods of use, such as
watching a video or a long phone
conversation.
All Acer phones are factory tested before
release.
For information on:
Up-to-date information regarding
your smartphone
www.acer.com
http://mobile.acer.com
Service enquiries www.acer.com/support
![](/img.php?id=1308448&img=bg29.png)
41Aux ADB
Aux ADB
1. Set up the network configuration for the USB Ethernet device:
• IP address: 192.168.239.5
• Subnet mask: 255:255:255:0
2. Add ADBHOST to the PC environment variable.
• Variable name: ADBHOST
• Variable value: 192.168.239.4
3. Connect the smartphone via USB to the PC. Execute the following commands
before running adb.
• adb kill-server
• adb devices
Warnings and precautions
• Do not use this product near water.
• Do not place this product on an unstable cart, stand or table. If the product falls,
it could be seriously damaged.
• Slots and openings are provided for ventilation to ensure reliable operation of
the product and to protect it from overheating. These openings must not be
blocked or covered. The openings should never be blocked by placing the product
on a bed, sofa, rug or other similar surface. This product should never be placed
near or over a radiator or heat register, or in a built-in installation unless proper
ventilation is provided.
• Never push objects of any kind into this product through cabinet slots as they
may touch dangerous voltage points or short-out parts that could result in a fire
or electric shock. Never spill liquid of any kind onto or into the product.
• To avoid damage of internal components and to prevent battery leakage, do not
place the product on a vibrating surface.
• Never use this product when engaging in sporting activities, exercising, or in any
vibrating environment which may cause a short circuit or damage, and even a risk
of explosion from the battery pack.
CAUTION when listening to music
To protect your hearing, follow these instructions.
• Increase the volume gradually until you can hear clearly and comfortably.
• Do not increase the volume level after your ears have adjusted.
• Do not listen to music at high volumes for extended periods.
• Do not increase the volume to block out noisy surroundings.
• Decrease the volume if you can’t hear people speaking near you.
Battery information
This product uses a Lithium-ion battery. Do not use it in a humid, wet and/or corrosive
environment. Do not put, store or leave your product in or near a heat source, in a high
temperature location, in strong direct sunlight, in a microwave oven or in a pressurized
container, and do not expose it to temperatures over 60 °C (140 °F). Failure to follow
these guidelines may cause the battery to leak acid, become hot, explode or ignite and
cause injury and/or damage. Do not pierce, open or disassemble the battery. If the battery
leaks and you come into contact with the leaked fluids, rinse thoroughly with water and
![](/img.php?id=1308448&img=bg2a.png)
42
seek medical attention immediately. For safety reasons, and to prolong the lifetime of the
battery, charging will not occur at low (below 0 °C/32 °F) or high (over 40 °C/104 °F)
temperatures.
The full performance of a new battery is achieved only after two or three complete
charge and discharge cycles. The battery can be charged and discharged hundreds of
times, but it will eventually wear out. When the talk and standby times are noticeably
shorter than normal, buy a new battery. Use only Acer approved batteries, and recharge
your battery only with Acer approved chargers designated for this device.
Unplug the charger from the electrical plug and the device when not in use. Do not leave
a fully charged battery connected to the ac charger, since overcharging may shorten its
lifetime. If left unused, a fully charged battery will lose its charge over time. If the battery
is completely discharged, it may take a few minutes before the charging indicator
appears on the display or before any calls can be made.
Use the battery only for its intended purpose. Never use any charger or battery that is
damaged.
Do not short-circuit the battery. Accidental short-circuiting can occur when a metallic
object such as a coin, clip, or pen causes direct connection of the positive (+) and negative
(-) terminals of the battery. (These look like metal strips on the battery.) This might
happen, for example, when you carry a spare battery in your pocket or purse. Short-
circuiting the terminals may damage the battery or the connecting object.
Leaving the battery in hot or cold places, such as in a closed car in summer or winter
conditions, will reduce the capacity and lifetime of the battery. Always try to keep the
battery between 15 °C and 25 °C (59 °F and 77 °F). A device with a hot or cold battery may
not work temporarily, even when the battery is fully charged. Battery performance is
particularly limited in temperatures well below freezing.
Do not dispose of batteries in a fire as they may explode. Batteries may also explode if
damaged. Dispose of batteries according to local regulations. Please recycle when
possible. Do not dispose as household waste.
Replacing the battery pack
Your smartphone uses lithium batteries. Replace the battery with the same type as that
which came bundled with your product. Use of another battery may present a risk of fire
or explosion.
Warning! Batteries may explode if not handled properly. Do not disassemble or
dispose of them in fire. Keep them away from children. Follow local regulations when
disposing of used batteries.
Additional safety information
Your device and its enhancements may contain small parts. Keep them out of the reach of
small children.
Operating environment
Warning! For safety reasons, turn off all wireless or radio transmitting devices when
using your smartphone device under the following conditions. These devices may
include, but are not limited to: Bluetooth and/or 3G.
![](/img.php?id=1308448&img=bg2b.png)
43Warnings and precautions
Remember to follow any special regulations in force in any area, and always switch off
your device when its use is prohibited or when it may cause interference or danger. Use
the device only in its normal operating positions. Do not cover the antenna with metal
and you should position the device at the above-stated distance from your body. To
successfully transmit data files or messages, this device requires a good quality connection
to the network. In some cases, transmission of data files or messages may be delayed until
such a connection is available. Ensure that the above separation distance instructions are
followed until the transmission is completed. Parts of the device are magnetic. Metallic
materials may be attracted to the device, and persons with hearing aids should not hold
the device to the ear with the hearing aid. Do not place credit cards or other magnetic
storage media near the device, because information stored on them may be erased.
Medical devices
Operation of any radio transmitting equipment, including wireless phones, may interfere
with the functionality of inadequately protected medical devices. Consult a physician or
the manufacturer of the medical device to determine if they are adequately shielded
from external RF energy or if you have any questions. Switch off your device in health
care facilities when any regulations posted in these areas instruct you to do so. Hospitals
or health care facilities may be using equipment that could be sensitive to external RF
transmissions.
Pacemakers. Pacemaker manufacturers recommend that a minimum separation of 15.3
cm (6") be maintained between wireless devices and a pacemaker to avoid potential
interference with the pacemaker. These recommendations are consistent with the
independent research by and recommendations of Wireless Technology Research. Persons
with pacemakers should do the following:
• Always keep the device more than 15.3 cm (6") from the pacemaker.
• Not carry the device near your pacemaker when the device is switched on. If you
suspect interference, switch off your device, and move it.
Hearing aids. Some digital wireless devices may interfere with some hearing aids. If
interference occurs, consult your service provider.
Vehicles
RF signals may affect improperly installed or inadequately shielded electronic systems in
motor vehicles such as electronic fuel injection systems, electronic antiskid (antilock)
braking systems, electronic speed control systems, and air bag systems. For more
information, check with the manufacturer, or its representative, of your vehicle or any
equipment that has been added. Only qualified personnel should service the device, or
install the device in a vehicle. Faulty installation or service may be dangerous and may
invalidate any warranty that may apply to the device. Check regularly that all wireless
equipment in your vehicle is mounted and operating properly. Do not store or carry
flammable liquids, gases, or explosive materials in the same compartment as the device,
its parts, or enhancements. For vehicles equipped with an air bag, remember that air bags
inflate with great force. Do not place objects, including installed or portable wireless
equipment in the area over the air bag or in the air bag deployment area. If in-vehicle
wireless equipment is improperly installed, and the air bag inflates, serious injury could
result. Using your device while flying in aircraft is prohibited. Switch off your device
before boarding an aircraft. The use of wireless teledevices in an aircraft may be
dangerous to the operation of the aircraft, disrupt the wireless telephone network, and
may be illegal.
![](/img.php?id=1308448&img=bg2c.png)
44
Potentially explosive environments
Switch off your device when in any area with a potentially explosive atmosphere and
obey all signs and instructions. Potentially explosive atmospheres include areas where you
would normally be advised to turn off your vehicle engine. Sparks in such areas could
cause an explosion or fire resulting in bodily injury or even death. Switch off the device at
refueling points such as near gas pumps at service stations. Observe restrictions on the use
of radio equipment in fuel depots, storage, and distribution areas; chemical plants; or
where blasting operations are in progress. Areas with a potentially explosive atmospheres
are often, but not always, clearly marked. They include below deck on boats, chemical
transfer or storage facilities, vehicles using liquefied petroleum gas (such as propane or
butane), and areas where the air contains chemicals or particles such as grain, dust or
metal powders.
Follow any restrictions. Do not use the device where blasting is in progress.
Emergency calls
Important: Wireless phones, including this device, operate using radio signals, wireless
networks, landline networks, and user-programmed functions. Because of this,
connections in all conditions cannot be guaranteed. You should never rely solely on any
wireless device for essential communications like medical emergencies.
If certain features are in use, you may first need to turn those features off before you can
make an emergency call. Consult this guide or your service provider for more information.
When making an emergency call, give all the necessary information as accurately as
possible. Your wireless device may be the only means of communication at the scene of
an accident. Do not end the call until given permission to do so.
Disposal and recycling information
Do not throw this electronic device into the trash when discarding.
To minimize pollution and ensure utmost protection of the global
environment, please recycle. For more information on the Waste from Electrical
and Electronics Equipment (WEEE) regulations, visit
www.acer-group.com/public/Sustainability/sustainability01.htm
Mercury advisory
For projectors or electronic products containing an LCD/CRT monitor or display:
Lamp(s) inside this product contain mercury and must be recycled or disposed of
according to local, state or federal laws. For more information, contact the
Electronic Industries Alliance at www.eiae.org. For lamp-specific disposal
information, check www.lamprecycle.org.
Taking care of your smartphone
1. DO take care not to scratch the screen of your smartphone. Keep the screen clean.
When working with your smartphone, use your finger or fingernail. Never use an
actual pen or pencil or other sharp object on the screen surface.
2. DO NOT expose your smartphone to rain or moisture. Do not let water enter
the circuitry through the front panel buttons or expansion slots. In general,
treat your smartphone as you would a mobile phone or other small
electronic device.
![](/img.php?id=1308448&img=bg2d.png)
45Taking care of your smartphone
3. DO be careful not to drop your smartphone or subject it to any strong
impact. Do not place your smartphone in your back pocket.
4. DO NOT expose your smartphone to extreme temperatures. For example, do not leave
your smartphone on the dashboard of a car on a hot day or when temperatures are
below freezing point. Also, keep it away from heaters and other sources of heat.
5. DO NOT use or store your smartphone in any location that is dusty, damp or
wet.
6. DO use a soft, damp cloth to clean your smartphone. If the surface of the screen
becomes soiled, clean it with a soft cloth moistened with diluted window-cleaning
solution.
7. DO NOT press down on the screen with force, otherwise you may crack the screen.
![](/img.php?id=1308448&img=bg2e.png)
46
Specifications
Performance
• ST Ericsson PNX6715, 416 MHz
• System memory:
• 256 MB of SDRAM
• 512 MB of Flash ROM
• Google Android operating system
Display
• 2.8” TFT-LCD resistive touchscreen
• 320 x 240 resolution
• 65K colors support
Multimedia
• CD-quality stereo output
• Mono speaker 0.5 W (max)
• Omni-directional microphone
• Formats supported
USB connector
• Micro USB connector
• USB Client
• DC power-in (5 V, 1 A)
Connectivity
• Bluetooth 2.0+EDR
• IEEE Wi-Fi 802.11 b/g WLAN
• GSM 850 / 900 / 1800 / 1900
• UMTS 900 / 2100 (EU models)
• UMTS 850 / 1900 (US models)
• HSDPA / GPRS / EDGE
Camera
• 3-megapixel EDOF
Expansion
• microSD memory card (up to 32 GB)
Type Formats
Audio playback MP3, AMR, WMA
Ringtone MP3, MIDI, iMelody, WAVE, WMA
Video recording 3GP, MPEG-4, H.263
Video playback 3GP, MPEG-4, H.263, H.264, WMV
![](/img.php?id=1308448&img=bg2f.png)
47Specifications
GPS
•Built-in GPS
• Supports AGPS
Battery
• High density, rechargeable 1500 mAh Lithium-Ion battery (replaceable)
Note: Length of battery operation will depend on power consumption which is based
on system resource use. For example, constantly using the backlight or using power-
demanding applications will shorten battery life between charges.
Dimensions
Height 104.5 mm
Width 54.2 mm
Thickness 13.2 mm
Weight <105 g (with battery)
![](/img.php?id=1308448&img=bg30.png)
48
Regulatory information
Compliant with Russian regulatory certification
RoHS compliance
This product is in compliance with Directive 2002/95/EC of the European Parliament and
of the Council of 27 January 2003, on the restriction of the use of certain hazardous
substances in electrical and electronic equipment (RoHS) and its amendments.
LCD pixel statement
The LCD unit is produced with high-precision manufacturing techniques. Nevertheless,
some pixels may occasionally misfire or appear as black or red dots. This has no effect on
the recorded image and does not constitute a malfunction.
Radio device regulatory notice
Note: Regulatory information below is for models with wireless LAN and/or Bluetooth
only.
General
This product complies with the radio frequency and safety standards of any country or
region in which it has been approved for wireless use. Depending on configuration, this
product may or may not contain wireless radio devices (such as wireless LAN and/or
Bluetooth modules). Information below is for products with such devices.
Preventing hearing loss
Caution: Permanent hearing loss may occur if earphones or headphones are used at
high volume for prolonged periods of time.
This device has been tested to comply with the Sound Pressure Level requirement laid down
in the applicable EN 50332-1 and/or EN 50332-2 standards.
Note: For France, mobile headphones or earphones for this device have
been tested to comply with the Sound Pressure requirement laid done in the
applicable NF EN 50332-1:2000 and/or NF EN 50332-2:2003 standards as
required by French Article L. 5232-1.
Wireless operation channels for different domains
France: Restricted wireless frequency bands
Some areas of France have a restricted frequency band. The worst case maximum
authorized power indoors is:
N. America 2.412-2.462 GHz Ch01 through Ch11
Japan 2.412-2.484 GHz Ch01 through Ch14
Europe ETSI 2.412-2.472 GHz Ch01 through Ch13
![](/img.php?id=1308448&img=bg31.png)
49Regulatory information
• 10 mW for the entire 2.4 GHz band (2400 MHz - 2483.5 MHz)
• 100 mW for frequencies between 2446.5 MHz and 2483.5 MHz
Note: Channels 10 through 13 inclusive operate in the band 2446.6 MHz to 2483.5
MHz.
There are few possibilities for outdoor use: On private property or on the private
property of public persons, use is subject to a preliminary authorization procedure by the
Ministry of Defense, with maximum authorized power of 100 mW in the 2446.5 - 2483.5
MHz band. Use outdoors on public property is not permitted.
In the departments listed below, for the entire 2.4 GHz band:
• Maximum authorized power indoors is 100 mW
• Maximum authorized power outdoors is 10 mW
Departments in which the use of the 2400 - 2483.5 MHz band is permitted with an EIRP of
less than 100 mW indoors and less than 10 mW outdoors:
This requirement is likely to change over time, allowing you to use your wireless LAN card
in more areas within France.
Please check with ART for the latest information (www.art-telecom.fr).
Note: Your WLAN Card transmits less than 100 mW, but more than 10 mW.
List of National Codes
This equipment may be operated in the following countries:
Country
Austria
Belgium
Cyprus
Czech Republic
Denmark
Estonia
Finland
France
Germany
Greece
Hungary
Ireland
Italy
Latvia
Lithuania
Luxembourg
ISO 3166 (2 letter code)
AT
BE
CY
CZ
DK
EE
FI
FR
DE
GR
HU
IE
IT
LV
LT
LU
Country
Malta
Netherlands
Poland
Portugal
Slovakia
Slovenia
Spain
Sweden
United Kingdom
Iceland
Liechtenstein
Norway
Switzerland
Bulgaria
Romania
Turkey
ISO 3166 (2 letter code)
MT
NT
PL
PT
SK
SL
ES
SE
GB
IS
LI
NO
CH
BG
RO
TR
01 Ain Orientales
02 Aisne
03 Allier
05 Hautes Alpes
08 Ardennes
09 Ariege
11 Aude
12 Aveyron
16 Charente
24 Dordogne
25 Doubs
26 Drome
32 Gers
36 Indre
37 Indre et Loire
41 Loir et Cher
45 Loret
50 Manche
55 Meuse
58 Nievre
59 Nord
60 Oise
61 Orne
63 Puy Du Dome
64 Pyrenees Atlantique
66 Pyrenees
67 Bas Rhin
68 Haut Rhin
70 Haute Saone
71 Saone et Loire
75 Paris
82 Tarn et Garonne
84 Vaucluse
88 Vosges
89 Yonne
90 Territoire de Belfort
94 Val de Marne
![](/img.php?id=1308448&img=bg32.png)
50
FCC regulations
This mobile phone complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2) this
device must accept any interference received, including interference that may cause
undesired operation.
This mobile phone has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiated radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
RF exposure warning
The equipment complies with FCC RF exposure limits set forth for an uncontrolled
environment.
The antenna(s) used for this transmitter must not be co-located or operating in
conjunction with any other antenna or transmitter.
RF exposure information (SAR)
This mobile phone meets the government's requirements for exposure to radio waves.
This phone is designed and manufactured not to exceed the emission limits for exposure
to radio frequency (RF) energy set by the Federal Communications Commission of the U.S.
Government.
The exposure standard for wireless mobile phones employs a unit of measurement known
as the Specific Absorption Rate, or SAR. The SAR limit set by the FCC is 1.6 W/kg.
Tests for SAR are conducted using standard operating positions accepted by the FCC with
the phone transmitting at its highest certified power level in all tested frequency bands.
Although the SAR is determined at the highest certified power level, the actual SAR level
of the phone while operating can be well below the maximum value. This is because the
phone is designed to operate at multiple power levels so as to use only the poser required
to reach the network. In general, the closer you are to a wireless base station antenna,
the lower the power output.
The highest SAR value for US model phones as reported to the FCC when tested for use at
the ear is 1.03 W/kg and when worn on the body, as described in this user guide,
is 1.07 W/kg.
![](/img.php?id=1308448&img=bg33.png)
51Regulatory information
Important: Body-worn measurements differ among phone models, depending upon
available enhancements and FCC requirements.
While there may be differences between the SAR levels of various phones and at various
positions, they all meet the government requirements.
The FCC has granted an Equipment Authorization for this model phone with all reported
SAR levels evaluated as in compliance with the FCC RF exposure guidelines. SAR
information on this model phone is on file with the FCC and can be found under the
Display Grant section of www.fcc.gov/oet/ea/fccid after searching on FCC ID: HLZDME120
(for US models).
For body worn operation, this phone has been tested and meets the FCC RF exposure
guidelines for use with accessories that contain no metal and that position the handset a
minimum of 1.5 cm from the body. Use of other accessories may not ensure compliance
with FCC RF exposure guidelines. If you do not use a body-worn accessory and are not
holding the phone at the ear, position the handset a minimum of 1.5 cm from your body
when the phone is switched on.
Using your phone with a hearing aid device (US models)
Your device is compliant with the FCC Hearing Aid Compatibility (HAC) requirements.
When some wireless phones are used near some hearing devices (hearing aids and
cochlear implants) users may detect a buzzing, humming, or whining noise. Some hearing
devices are more immune than others to this interference noise, and phones also vary in
the amount of interference they generate. The wireless telephone industry has developed
ratings for some of their mobile phones, to assist hearing-device users in finding phones
that may be compatible with their hearing devices. Not all phones have been rated.
Phones that have been rated have a label on the box. Your device has been tested for
hearing aid device compatibility and has an M3 and/or T3 rating.
These ratings are not guarantees. Results will vary, depending on the level of immunity of
your hearing device and the degree of your hearing loss. If your hearing device happens
to be vulnerable to interference, you may not be able to use a rated phone successfully.
Trying out the phone with your hearing device is the best way to evaluate it for your
personal needs.
M-Ratings: Phones rated M3 or M4 meet FCC requirements and are likely to generate less
interference with hearing devices than phones that are not labeled. M4 is the better/
higher of the two ratings.
T-Ratings: Phones rated T3 or T4 meet FCC requirements and are likely to be more usable
with a hearing device's telecoil ("T Switch" or "Telephone Switch") than unrated phones.
T4 is the better/higher of the two ratings.
Important: This device does not support VoIP. WLAN and Bluetooth do not have voice
capability for held-to-the-ear phone service.
Note: Not all hearing devices contain telecoils.
The more immune your hearing aid device is, the less likely you are to experience
interference noise from your wireless phone. Hearing aid devices should have ratings
![](/img.php?id=1308448&img=bg34.png)
52
similar to those of phones. Ask your hearing health-care professional for the rating of
your hearing aid.
Hearing devices may also be measured for immunity to this type of interference. Your
hearing device manufacturer or hearing health professional may help you find results for
your hearing device. The more immune your hearing aid is, the less likely you are to
experience interference noise from wireless devices.
For additional information about the FCC's actions with regard to hearing aid compatible
wireless devices and other steps the FCC has taken to ensure that individuals with
disabilities have access to telecommunications services, please go to
www.fcc.gov/cgb/dro.
Turning on Hearing Aid Compatibility mode
Open the Applications menu and tap Settings > Call settings > Hearing aids.
For Canadian users
Operation is subject to the following two conditions: (1) this device may not cause
interference, and (2) this device must accept any interference, including interference that
may cause undesired operation of the device.
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
This Category II radiocommunication device complies with Industry Canada Standard RSS-
310.
Ce dispositif de radiocommunication de catégorie II respecte la norme CNR-310
d'Industrie Canada.
Important note
IC radiation exposure statement
This EUT is compliance with SAR for general population/uncontrolled exposure limits in IC
RSS-102 and had been tested in accordance with the measurement methods and
procedures specified in IEEE 1528. This equipment should be installed and operated with
minimum distance 1.5cm between the radiator and your body.
This device and its antenna(s) must not be co-located or operating in conjunction with
any other antenna or transmitter.
Note: The county code selection feature is disabled for products marketed in the US/Canada.
Certificate Information (SAR)
This device meets the EU requirements (1999/519/EC) on the limitation of exposure of the
general public to electromagnetic fields by way of health protection.
The limits are part of extensive recommendations for the protection of the general
public. These recommendations have been developed and checked by independent
scientific organizations through regular and thorough evaluations of scientific studies. To
guarantee the safety of all persons, regardless of age and health, the limits include a
significant safety buffer.
Before radio devices can be put in circulation, their agreement with European laws or
limits must be confirmed; only then may the CE symbol be applied.
![](/img.php?id=1308448&img=bg35.png)
53Regulatory information
The unit of measurement for the European Council's recommended limit for mobile
telephones is the "Specific Absorption Rate" (SAR). This SAR limit is 2.0 W/kg, averaged
over 10 g of body tissue. It meets the requirements of the International Commission on
Non-Ionizing Radiation Protection (ICNIRP) and was included in the European Standard
EN 50360 for mobile radio devices. The SAR regulation for mobile telephones is in line
with European Standard EN 62209-1. The maximum SAR value is calculated at the highest
output level in all frequency bands of the mobile telephone. During use, the actual SAR
level is usually much lower than the maximum value, because the mobile telephone
works in different output levels. It only transmits with as much output as is required to
reach the network. In general the following applies: The closer you are to a base station,
the lower the transmission output of your mobile telephone. The tested SAR of this
device is as follows:
NCC warning
䄺䁲
㍧ൟᓣ䁡䄝ড়ḐПԢࡳ⥛ᇘ丏䳏″Δ䴲㍧䀅ৃΔ݀ৌΕଚ㰳Փ⫼㗙ഛϡᕫ᪙㞾䅞丏⥛Δࡴࡳ⥛
䅞ॳ䀁㿜П⡍ᗻঞࡳ㛑Ԣࡳ⥛ᇘ丏䳏″ПՓ⫼ϡᕫᕅ䷓亯㟾ᕅ䷓ᅝܼঞᑆড়⊩䗮ֵΔ㍧ⱐ⧒᳝ᑆ
⧒䈵ᰖΔឝゟेذ⫼ΔϺᬍ㟇⛵ᑆᰖᮍᕫ㑐㑠Փ⫼ࠡ䷙ড়⊩䗮ֵΔᣛϔ䳏ֵ⊩㽣ᅮὁП⛵㎮
䳏䗮ֵԢࡳ⥛ᇘ丏䳏″䳔ᖡফড়⊩䗮ֵᎹὁΔ⾥ᅌঞ䝿Ⱆ⫼䳏⊶䔏ᇘᗻ䳏″䀁٭ПᑆΔ⏯ᇥ䳏⺕⊶
ᕅ䷓Δ䂟ཹ䘽Փ⫼
Lithium-ion battery warning
CE NCC
Head (W/kg 10g) Body (W/kg 10g) Head (W/kg 10g) Body (W/kg 10g)
0.963 0.644 0.963 N/A
ATTENZIONE! Rischio di esplosione della batteria se sostituita in modo
errato. Sostituire la batteria con un una di tipo uguale o equivalente
consigliata dalla fabbrica. Non disperdere le batterie nell’ambiente.
VORSICHT! Explosionsgefahr bei unsachgemäßen Austausch der Batterie.
Ersatz nur durch denselben oder einem vom Hersteller empfohlenem
ähnlichen Typ. Entsorgung gebrauchter Batterien nach Angaben des
Herstellers.
ADVARSELI! Lithiumbatteri - Eksplosionsfare ved fejlagtig håndtering.
Udskiftning må kun ske med batteri af samme fabrikat og type. Levér det
brugte batteri tilbage til leverandøren.
VARNING! Explosionsfara vid felaktigt batteribyte. Använd samma
batterityp eller en ekvivalent typ som rekommenderas av
apparattillverkaren. Kassera använt batteri enligt fabrikantens instruktion.
VAROITUS! Paristo voi räjähtää, jos se on virheellisesti asennettu. Vaihda
paristo ainoastaan laitevalmistajan sousittelemaan tyyppiin. Hävitä käytetty
paristo valmistagan ohjeiden mukaisesti.
ATTENTION ! Il y a danger d’explosion s’il y a remplacement incorrect de la
batterie. Remplacer uniquement avec une batterie du mêre type ou d’ un
type équivalent recommandé par le constructeur. Mettre au rebut les
batteries usagées conformément aux instructions du fabricant.
ADVARSEL! Eksplosjonsfare ved feilaktig skifte av batteri. Benytt samme
batteritype eller en tilsvarende type anbefalt av apparatfabrikanten. Brukte
batterier kasseres i henhold til fabrikantens instruksjoner.
![](/img.php?id=1308448&img=bg36.png)
54
Acer Incorporated
Date: June 15, 2010
Declaration of Conformity
We, Acer Incorporated,
of 8F., No. 88, Sec. 1, Hsin Tai Wu Rd. Hsichih Taipei Hsien 221, Taiwan
Declare under sole responsibility that the product:
Model: E120
Description: Smart HandHeld
To which this declaration relates, is in conformity with the following standards and/ or other
normative documents:
zEN 301 511 V9.0.2
zEN 300 328 V1.7.1
zEN 301 908-1/ -2 V3.2.1
zEN 300 440-1 V1.5.1/ EN300 440-2 V1.3.1
zEN 301 489-1 V1.8.1/ -3 V1.4.1/ -7 V1.3.1/ -17 V2.1.1/ -24 V.1.4.1
zEN 55022:2006/A1:2007 Class B; EN 55024:1998/A1:2001/A2:2003
zEN 55013:2001/A1:2003/A2:2006;
zEN 60950-1: 2006+A11:2009
zEN 50332-1:2000/ -2: 2003
zEN 50360:2001/ EN 62209-1:2006/ EN62311:2008/ OET65C
We hereby declare that the above named product is in conformance to all the essential requirements
of the R&TTE Directive (99/5/EC) issued by the Commission of the European Community.
The conformity assessment procedure referred to in Article 10 and detailed in Annex [IV] of
directive 1999/5/EC has been followed related to Articles
z R&TTE Article 3.1 (a) Health and Safety
z R&TTE Article 3.1 (b) EMC
z R&TTE Article 3.2 Spectrum Usage
with the involvement of the following Notified Body:
CETECOM, Untertuerkheimer Str. 6 – 10 66117 Saarbruecken
Identification mark: 0682 (Notified Body) CE
The technical documentation relevant to the above equipment will be held at:
Acer Incorporated
8F., No. 88, Sec. 1, Hsin Tai Wu Rd. Hsichih Taipei Hsien 221, Taiwan
Authorized Person:
_________________
Name: Harriot S.L. Lee
![](/img.php?id=1308448&img=bg37.png)
B
battery
charging ............................................10
information .......................................47
Bluetooth
connections .......................................29
headset ..............................................38
C
call history ..............................................17
calls
answering ..........................................18
ending ...............................................18
onscreen options ...............................18
rejecting ............................................18
camera
icons and indicators ..........................25
information .......................................46
shooting a video ...............................26
supported formats ............................26
taking a photo ..................................26
conference calls ......................................19
connectivity ............................................46
contacts
adding ...............................................16
making calls to a contact ..................18
saving a dialed number ....................19
D
display .....................................................46
E
email .......................................................23
F
FAQs ........................................................40
FM radio .................................................33
G
Google ....................................................12
GPS tracker ............................................ 32
H
help
sources .............................................. 40
I
international numbers .......................... 18
L
LED indicators .......................................... 9
M
managing your calendar ....................... 32
MMS messages ...................................... 21
O
onscreen keyboard ................................ 13
P
performance .......................................... 46
phone
connections ....................................... 29
settings .............................................. 29
S
safety regulations .................................. 41
speakerphone ........................................ 18
specifications ......................................... 46
spinlets ................................................... 34
T
troubleshooting .................................... 40
turning on .............................................. 12
U
urFooz .................................................... 30
USB connector ....................................... 46
V
voice calls
the voice call screen ......................... 18
volume
adjusting ........................................... 35
