Acer orporated DME330NFCCE Smart HandHeld User Manual Acer E330 UM EN 2012
Acer Incorporated Smart HandHeld Acer E330 UM EN 2012
Contents
Users Manual
AasdfasdUser’s Manual
Acer Liquid Glow E330
User Guide
© 2012 All Rights Reserved
Acer Liquid Glow Smartphone User’s Manual
Model: E330
First issue: 5/2012
Acer Liquid Glow Smartphone
Model number: __________________________________
Serial number: ___________________________________
Date of purchase: ________________________________
Place of purchase: ________________________________
![](/img.php?id=1695899&img=bg3.png)
Table of contents
Setting up....................................................................................................................5
Unpacking your smartphone ..................................................................................5
Getting to know your smartphone..........................................................................5
Installing or removing the battery ...........................................................................7
Installing a SIM or microSD Card ...........................................................................8
Using your smartphone ............................................................................................9
Turning on for the first time ....................................................................................9
Locking your smartphone.......................................................................................9
Using the touchscreen..........................................................................................10
The Home screen .................................................................................................12
Managing contacts...................................................................................................17
Managing your contacts.......................................................................................17
Making calls..............................................................................................................19
Before making a call .............................................................................................19
Making a call.........................................................................................................19
The voice call screen ............................................................................................20
Internet calling..........................................................................................................22
Adding an Internet calling account.......................................................................22
Editing or removing an Internet calling account...................................................22
Using Internet calling............................................................................................22
Receiving Internet calls.........................................................................................22
Calling a contact’s Internet calling address .........................................................22
Calling a phone number using Internet calling .....................................................22
Messaging.................................................................................................................24
Creating a new message ......................................................................................24
Replying to a message .........................................................................................25
MMS messages....................................................................................................25
Going online..............................................................................................................27
Browsing the Internet ...........................................................................................27
Setting up your Google email ...............................................................................27
Composing an email.............................................................................................28
Setting up Email ...................................................................................................28
Maps, Navigation, Places and Latitude................................................................29
Using the camera .....................................................................................................30
Camera icons and indicators................................................................................30
Taking a photo......................................................................................................31
Shooting a video...................................................................................................31
Supported formats ...............................................................................................31
Viewing and sharing photos and videos...............................................................31
Advanced settings....................................................................................................32
Putting your smartphone in Airplane mode..........................................................32
Adjusting settings .................................................................................................32
Connecting to a PC ..............................................................................................36
FM radio ...............................................................................................................37
Multimedia playback.............................................................................................37
Restoring to factory settings ................................................................................39
Accessories and tips................................................................................................40
Using the headset.................................................................................................40
Using a Bluetooth headset ...................................................................................40
Inserting a microSD Card .....................................................................................40
Appendix ...................................................................................................................41
FAQ and troubleshooting .....................................................................................41
Other sources of help ...........................................................................................42
Warnings and precautions....................................................................................42
Emergency calls ...................................................................................................45
Disposal and recycling information ......................................................................45
Taking care of your smartphone...........................................................................45
Specifications .......................................................................................................47
Safety....................................................................................................................49
End User License Agreement..................................................................................59
![](/img.php?id=1695899&img=bg5.png)
5
Setting up
Unpacking your smartphone
Your new smartphone comes packed in a protective box. Carefully unpack the box
and remove the contents. If any of the following items is missing or damaged,
contact your dealer immediately:
• Acer Liquid Glow Smartphone
• Battery
•Quick Guide
• USB cable
• AC adapter
•Headset
Getting to know your smartphone
Views
No. Item Description
1 Power button Press to turn the screen on/off or enter sleep mode;
press and hold to turn the smartphone on or off.
2 Phone speaker Emits audio from your smartphone; suitable for
holding to your ear.
3 Home button Return to the Home screen; press and hold to view
recently-used applications, tap an icon to open the
associated program.
4 Search button Open the Search application or search within the
active application.
5 Back button Go back one menu step; close the keyboard.
![](/img.php?id=1695899&img=bg6.png)
6
6 Menu button Open the option menu; press and hold to display the
keyboard.
7 Touchscreen 3.7-inch, 800 x 480 pixel capacitive touchscreen to
display data, phone content and enter information.
8 3.5 mm headphone jack Connect to stereo headphones.
9 Volume up/down buttons Increase or decrease the phone volume.
10 Camera A 5-megapixel camera for taking high-resolution
images.
11 Flash LED flash for camera.
12 Handsfree speaker Emits audio from your smartphone; suitable for
handsfree use.
13 Micro USB connector Connect to a USB cable/charger.
14 Microphone Internal microphone.
No. Item Description
![](/img.php?id=1695899&img=bg7.png)
7
Installing or removing the battery
Your smartphone uses a replaceable battery to provide power. It is packed
separately from your smartphone and needs to be inserted and charged before you
can use the smartphone.
Installing the battery
Insert your fingernail into the cutout between the
battery cover and the phone. Unclip the cover and
lift off the battery cover.
Place the battery into the battery compartment,
lining up the battery connectors with those at the
bottom of the compartment.
Align the tabs on the cover into the slots on the
phone. Gently press the cover until it snaps in
place.
CAUTION: RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT
TYPE.
DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS.
Charging the battery
For initial use, you need to charge your smartphone for eight hours. After that you
can recharge the battery as needed.
Connect the AC adapter cord to the micro USB connector on your smartphone.
![](/img.php?id=1695899&img=bg8.png)
8
Removing the battery
Open the battery compartment as shown in "Installing the battery" on page 7. Lift
the battery out of the compartment by lifting at the top of the battery on either side
of the camera.
Replace the battery cover as described above.
Installing a SIM or microSD Card
To take full advantage of your smartphone’s telephony capabilities, you must install
a SIM card. The SIM card holder is located at the top of the battery bay.
Additionally, you may wish to increase your smartphone’s storage by inserting a
microSD Card into the slot provided. This is next to the SIM card slot.
1. Turn off the phone by pressing and holding the power button.
2. Open the cover and remove the battery as
described in "Removing the battery" on
page 8.
3. Insert the SIM or microSD Card as shown.
4. Replace the battery and battery cover.
Note: Ensure that the microSD Card is inserted all the way into the card slot.
SIM card lock
Your smartphone may come with a SIM card lock, i.e., you will only be able to use
the SIM card provided by your network operator.
To cancel the SIM lock, contact your network provider.
![](/img.php?id=1695899&img=bg9.png)
9
Using your smartphone
Turning on for the first time
To turn on your smartphone for the first time, press and hold the power button until
the screen turns on. You will then be asked to configure some settings before you
can use your smartphone.
Follow the onscreen instructions to complete setup.
Sign in to or create a Google account
If you have Internet access, your smartphone allows you to synchronize information
with a google account.
During the start-up process, you may create or sign in to your account, which will
be used to synchronize your contact list, email, calendar and other information. If
you do not yet have Internet access, or do not want to use this feature, then tap
Skip.
Creating multiple Google accounts
You can create and easily access multiple Google accounts. Open the Application
menu and then tap Settings > Accounts & sync > Add account.
Entering your PIN
When you install a SIM card for the first time, you may need to enter a PIN using the
onscreen number pad.
Important: Depending on your settings, you may be required to enter your PIN each time
you switch on the phone function.
Activating a new SIM card
If you are using your SIM card for the first time, it may require activation. Contact
your network operator for details on how to do this.
Locking your smartphone
If you will not use your smartphone for a while, briefly press the power button to
lock access. This saves power and ensures your smartphone does not
unintentionally use any services. Your smartphone will lock automatically if it is not
used for one minute.
![](/img.php?id=1695899&img=bga.png)
10
Waking your smartphone
If the screen is off and the smartphone does not react to any
taps on the screen or front panel button, then it has been
locked and is in sleep mode.
Press the power button to wake your smartphone. Unlock
your smartphone by dragging the lock icon to the right side of
the screen towards the unlock icon.
For additional security, you may set an unlock pattern, a set of
dots that must be tapped in the correct order to access the
phone. Open the Application menu and then tap Settings >
Security > Screen lock.
Note: If you forget your unlock pattern, please refer to "Unlock pattern" on page 41.
Using the touchscreen
Your smartphone uses a touchscreen for selecting items and entering information.
Use your finger to tap the screen.
Ta p : Touch the screen once to open items and select options.
Drag: Hold your finger on the screen and drag across the screen to select text and
images.
Tap and hold: Tap and hold an item to see a list of actions available for that item.
On the pop-up menu that appears, tap the action you want to perform.
Scroll: To scroll up or down the screen, simply drag your finger up or down the
screen in the direction that you want to scroll.
Android keyboard
This is a standard onscreen QWERTY keyboard that
allows you to enter text. Tap and hold a key with
numbers at the top to select alternative characters, such
as letters with accents.
Tap th e ?123 button to see numbers and special
characters, and then tap the ALT key to see even more.
You can switch between multiple input languages by
swiping across the space bar. The keyboard layout will
change accordingly. To select your preferred languages, open the Application
menu and then tap Settings > Language & input > Android keyboard > Input
languages.
Text assistance
The Android keyboard has various features that assist you to enter correct text. In
the Application menu, tap the Settings icon, Language & input and then tap the
![](/img.php?id=1695899&img=bgb.png)
11
settings icon on the right side of Android keyboard. From here you can enable or
disable the several keyboard related settings, including the following:
Changing the text input method
To change the input method, in the Application menu tap Settings > Language &
input > Default and then select your preferred input method.
Predictive text
Both XT9 Text Input and Android keyboard provide predictive text input. As you tap
the letters of a word, a selection of words are displayed above the keyboard that
continue the sequence of letters tapped, or are a close match allowing for errors.
The word list changes after every key press. If the word you need is displayed, you
can tap on it to insert it into your text.
XT9 Text Input
Tap th e ?123 button to see numbers and special
characters, and then tap the ALT key to see even more.
Additional keys vary depending on the type of text you
enter, e.g. a key to add a smiley is available when typing
a text message. Like other keys, tap and hold for
additional options.
Text assistance
The standard XT9 keyboard has various features that assist you to enter correct
text. In the Application menu, tap Settings > Language & input > XT9 Text Input.
You can also tap and then tap . From here you can enable or disable the
following:
Function Description
Auto correction Spacebar and punctuation automatically correct mistyped words.
Show correction
suggestions
Shows suggested words while you are typing.
Function Description
Languages and
settings
Set the languages that will be available.
Select the keyboard layout you prefer. There are three layouts available:
• Keyboard: A full QWERTY keyboard.
• Reduced keyboard: Two letters are available on each key. Tap and
hold the key to select a letter, including special characters.
• Phone keypad: Three letters are available on each key. Tap and hold
the key to select a letter, including special characters.
Preferences Change your text input preferences.
![](/img.php?id=1695899&img=bgc.png)
12
The Home screen
After rebooting, your smartphone will display the home
screen. This screen gives you quick, icon-based access
to many of the frequently used features of your
smartphone.
At the bottom of the screen is the application dock
which displays default applications. Tap an icon to open
the application. Tap the Application icon in the middle of
the application dock to view your applications. To change
applications, see "Changing application dock icons"
on page 13.
The extended Home screen
The Home screen extends to either side of the screen, giving you more room to add
icons, widgets or features. To view the extended screen, slide your finger to the left
or right.
Adding or removing icons
You can set icons for installed applications on the Home screen. Tap and hold an
icon in the Application menu to copy it to the Home screen. To remove an icon from
the Home screen, tap and drag the icon from the Home screen to Remove that
appears at the top of the screen.
Adding or removing widgets
To add widgets, press the Application icon and then tap
WIDGETS.
Resizing widgets
Some widgets can be resized. As soon as you place a widget
on the Home screen, you can resize it by dragging the
corners.
To resize a widget that is already on the Home screen, tap
and hold the widget. Once the Remove icon appears, release
the widget. If the widget is resizable, you will be able to drag
the sides of the widget to resize it.
![](/img.php?id=1695899&img=bgd.png)
13
Adding or removing folders
You can also add folders to your Home screen. To create a
new folder drag and drop an application icon onto another
application icon in the Home screen. This will create an
Unnamed Folder. Tap the folder icon and then tap the
name of the folder to rename it.
To delete an application shortcut from a folder, tap on the
folder icon to display the applications inside and then tap
and hold the application icon that you want to remove.
Drag and drop the icon on Remove that will appear at the
top of the screen.
To delete a folder, tap and hold on the folder and then drag
and drop the folder on Remove that will appear at the top
of the screen.
Changing application dock icons
You can set icons for installed applications in the application dock. Open the
applications menu and find the application you want to add. Tap and hold the icon,
then drag it to a position in the dock, it will be added in place of the existing
application.
To remove an icon from the dock, open the applications menu, then tap and hold an
icon to select it. Either drag the icon to a different page in the applications menu, or
to the trash icon that appears at the bottom left corner of the screen.
Changing the wallpaper
On the Home screen, tap the Menu button and then tap Wallpaper to change the
current wallpaper. You can choose from images stored in the Gallery, or Live
Wallpapers featuring animated or interactive backgrounds, or standard wallpapers.
Multitasking
You can have multiple applications open at the same time.
To open a new application, press the Home button to
return to the Home screen, then start the new application.
To view your active applications, press and hold the Home
button. Then tap an icon to go to the application.
Tip: To prolong battery life, it is better to close an application when you’ve finished using
it. Do this by either pressing the Back key or the Menu button and selecting Exit (if
available).
![](/img.php?id=1695899&img=bge.png)
14
Recent apps
To access recently opened apps while working on another process, press and hold
the Home button.
The Application menu
To access the Application menu, on the Home screen tap in the center of the
dock.
Applications are displayed in alphabetical order. If more
applications are available, an outline of the second page will
be shown on the side of the screen. Swipe the outline towards
the center of the screen to switch pages.
Otherwise swipe to the left to see more Applications. When
you are on the last page of applications, swipe to the left to
see widgets available on your tablet.
Tap th e Shop icon to open the Google Play.
To quickly jump to applications or widgets, tap the APPS or
WIDGETS tabs at the top of the Application menu.
Note: All images are for reference only. The applications installed on your device can be
different from the applications shown in illustrations.
Notification area
The Notification area is at the top of the screen.
This area contains a variety of icons to inform you of your
phone’s status. The left side of the Notification area displays
event icons that indicate a new event (such as a new
message). The icons on the right side indicate signal strength,
connection, battery status and the time.
Drag the Notification area down the screen to view more
information about new events.
Connection icons
Note: Some connection icons appear blue if you have an active Google account.
Icon Description Icon Description
Connected to GPRS mobile network Roaming
![](/img.php?id=1695899&img=bgf.png)
15
Battery icons
Notification icons
Connected to EDGE mobile network Cellular signal strength
Connected to 3G mobile network Mobile data transferring
Connected to HSDPA network Connected to a wireless network
Bluetooth is on No signal
Bluetooth connected Airplane mode (Wireless
connectivity disconnected. Please
disable airplane mode before
trying to make a call.)
USB and wireless tethering are
activated
USB tethering is activated
Wireless tethering is activated
Icon Description Icon Description
Battery is very low Battery is partially drained
Battery is low Battery is full
Battery is charging
Icon Description Icon Description
Alarm is set SIM card is invalid or not installed
Speakerphone is on Vibrate mode
New Gmail message Ringer is silenced
New/unread SMS/MMS Phone microphone is off
Problem with sending SMS/MMS Application update available
New Google Talk message System update available
New voicemail Missed call
Upcoming event Song is playing
Syncing data More notifications
Warning, pull down notification area
for more information
GPS is on
SD card or USB storage is full Receiving location data from GPS
![](/img.php?id=1695899&img=bg10.png)
16
An open wireless network is
available
Uploading data
Phone is connected to PC via USB Downloading data
Carrier data use threshold exceeded Download finished
Connected to or disconnected from
virtual private network (VPN)
Icon Description Icon Description
![](/img.php?id=1695899&img=bg11.png)
17
Managing contacts
Managing your contacts
Your smartphone features an address book that allows
you to save contacts to either the internal memory or onto
your SIM card.
Open the People application from the APPS menu or tap
the People tab from the Dialer to view your contacts.
If you don’t have any contacts stored on your phone, you
can import your Google account contacts, add a new
contact or import contacts from your SIM or SD card.
Open the People application from the APPS menu and
then tap to add a contact, to search for a contact,
or tap the Menu button to open the menu.
Adding a contact
Tap to add a new contact. You may also scan a
person’s profile barcode to add the person to your
contact list or group.
To create a contact, you will be asked to enter the
contact’s:
•Name
• Organization
• Title
• Phone numbers
• Email addresses
• Postal addresses
Tap Add another field to add things such as:
• IM addresses.
• Add any personal notes about the contact.
• Phonetic name
• Link a website
To assign an image to your contact, tap the silhouette and select whether to take a
photo or select an image from your smartphone’s picture gallery.
When done, click Done at the top of the screen.
Tapping on the contacts name will bring up their profile. Tap the Menu button while
viewing a contact’s profile to:
• Edit the contact.
• Share the contact.
• Delete the contact.
• Set a ringtone for the contact.
![](/img.php?id=1695899&img=bg12.png)
18
• Divert calls from the contact to voicemail.
Tip: You may also create a contact from an already dialed or received number, see
"Saving a dialed number to contacts" on page 20.
![](/img.php?id=1695899&img=bg13.png)
19
Making calls
This chapter shows you how to make phone calls, and the various options available
to you during your call.
Before making a call
Check that the phone function is on before you make a call. You can confirm the
phone status from the icon on the right-hand side of the Notification area.
Note: Status and notification icon colors may vary.
Making a call
Note: The phone function needs to be enabled before the call can be connected.
1. From the Home screen tap Phone to open the onscreen
number pad.
2. Enter the number you wish to dial.
3. Tap to make the call.
4. To end the call, tap .
If the contact you need is displayed, simply tap the contact
name to make a call.
Dialing a number from Call Log
Your call history can be viewed by tapping the Call Log tab. It
displays recent received, dialed, and missed calls.
Tap the phone icon to redial. To view details of the call, tap the number or contact’s
name. While viewing the details of a call, tap the Menu button for other options:
Remove from call log; Edit number before call.
Viewing missed calls
Missed calls will be displayed by the call indicator in the Notification area with
the icon.
1. Open the notification list by tapping the Notification area to display the details of
the missed calls.
2. Select the call from the list and tap view the call in your Call Log.
Icon Description
Connected to the network: You may make a call.
Airplane mode: Wireless connectivity disconnected (Wi-Fi, Bluetooth, 2G and 3G).
Please disable airplane mode before trying to make a call.
![](/img.php?id=1695899&img=bg14.png)
20
You can save phone numbers to your contacts list from the Call Log. Please refer to
"Adding a contact" on page 17 for further details.
Saving a dialed number to contacts
You can save a number you have dialed to your contacts for future use.
1. Tap the Call log tab in the phone application to view your recently dialed
numbers.
2. Tap on the number, and then tap to add to your contacts.
Making a call to one of your contacts
Calling a contact from the People tab
1. Tap the People tab in the onscreen number pad to view your contacts.
2. Tap on a contact to call them.
Calling a contact from the People application
1. Tap the People icon in the Home screen or in the Application menu to view your
contacts.
2. Tap on a contact to open their profile.
3. Tap on the contact’s phone number to call them.
Dialing an international number
When dialing international numbers, there is no need to enter the international
direct dialing prefix (’00’ etc.) before the country code. Simply tap and hold 0+ on
the onscreen number pad until + appears onscreen.
Warning: International call rates can vary greatly depending on the country you are
calling and your network provider. We suggest you check all call rates with your
network provider, to avoid excessive phone bills. If you are using your smartphone
abroad, roaming charges will apply. Consult your network provider for roaming rates
specific to the country you are visiting before you leave.
Direct dial widget
You may add a direct dial widget for a contact on your Home screen. Open the
Application menu, then tap the WIDGETS tab. Tap and hold Direct dial and you
will be able to place the widget on your Home screen. Once placed, you will be able
to select a contact to associate with that particular widget on your Home screen.
The voice call screen
Once you have dialed your number the voice call screen
appears, which displays the number/contact you are talking
to, the call duration and voice call options.
![](/img.php?id=1695899&img=bg15.png)
21
Answering or declining a call
When you have an incoming call, the number will be
shown on the screen. To accept or decline the call,
drag the phone icon to the appropriate icon.
To decline the call with a text message, drag the
phone icon up to the icon and then select a
message.
Ending a call
To end a call, tap from the voice call screen.
Voice call options
Saving a dialed number to contacts
You can save a number you have dialed to your contacts for future use.
1. Select the number from the Call log tab, and tap Add to contacts .
2. Tap Create new contact and select how to complete the action. Please refer to
"Adding a contact" on page 22.
Conference calls
If you have one call on hold and another on line, you can combine both calls to
create a conference call.
After the first call is established, tap to add a second call. Tap to start the
conference call.
Icon Description
Place the call on hold.
Mute a call.
Speakerphone.
Access the keypad while a call is in progress.
Add a second call.
![](/img.php?id=1695899&img=bg16.png)
22
Internet calling
You can place and receive Internet calls over wireless network.
Adding an Internet calling account
In the Application menu tap Settings > More... > Call settings > Accounts. Tap
Add account, and input the Username, Password, and Server accounts. You can
also configure optional settings such as Display name, Outbound proxy address,
Port number, Transport type, and Send keep-alive.
Editing or removing an Internet calling account
Open an existing Internet calling account and make the edits you want on the SIP
account details. Tap Save to save your changes, tap the Menu button and then tap
Discard to discard the changes, or tap the Menu button and then select Remove
account to delete the existing account.
Using Internet calling
You can configure your phone to use Internet calling (when you’re connected to Wi-
Fi) for all calls, only for Internet calls, or to ask each time you place a call.
Receiving Internet calls
You can configure your phone to receive Internet calls made to an Internet calling
account you added to your phone. To receive Internet calls, in the Application
menu tap Settings > More... > Call settings > Accounts. Make sure the Receive
incoming calls box is checked.
Calling a contact’s Internet calling address
You must add an Internet calling address to a contact to be able to place an
Internet call to them.
To make an Internet call, open People from your Home screen or in the Application
menu. Tap on the contact to open their profile, and then tap on their Internet calling
address to place the call.
Calling a phone number using Internet calling
If you have configured your phone to place all calls using Internet calling or to ask
for each call, you may also call a phone number using Internet call, whenever you
are connected to a wireless network.
Dial the number and tap , or select the contact you wish to place a call to, then
tap the Internet call account you want to use to make the call.
![](/img.php?id=1695899&img=bg17.png)
23
Important: Calling a phone number using Internet calling requires that your service
provider supports it, and may incur additional charges. Please contact your service
provider if you have any questions.
![](/img.php?id=1695899&img=bg18.png)
24
Messaging
This chapter shows you how to set up and use the Phone messages, Social
messages and Social events functions of your smartphone.
All SMS and MMS messages are accessed via Messaging. Messaging
automatically arranges received and sent messages into threads.
To access Messaging tap Messaging on the Home screen.
Creating a new message
You can use your phone to compose Phone (SMS and MMS)
messages.
Tap to compose a new message.
Tap , or enter the recipient’s phone number or name in the
To field. Suggested contacts will be displayed in a drop-down
list below the text field. To select a suggested contact, tap the
contact’s name.
Once you have entered the recipient, enter your message in
the text box labeled Type message.
Note: SMS messages may be up to 160 characters long. If your message is longer than
160 characters, it will be sent as multiple linked messages. Most phones will automatically
join the linked messages to present the recipient with a single long message, however,
some older phones do not have this ability.
Tap the Menu button to see what options are available when creating a new
message. The options change depending on the status of the message.
Option Description
Add subject Add a subject to the message.
Send Send the message.
Insert smiley Insert a smiley/emoticon into your message text.
Delete thread Delete the message thread.
Discard Discard the message.
![](/img.php?id=1695899&img=bg19.png)
25
Replying to a message
When a new text message arrives a message icon appears in the Notification area
and the message icon on the top of the phone lights up.
Tap Messaging on the Home screen to view the message list or expand the
Notification area to see a summary of the message. Tap the summary to open the
message list.
To reply to an SMS or MMS message, open the message from the message list.
Enter your text in the text box labeled Type message. Tap the Menu button to see
available options.
MMS messages
MMS messages are similar to text messages but also allow you to attach
multimedia files such as pictures, audio or video clips. Each MMS message can be
up to 300 kB in size.
Note: You need to set up an MMS profile before you can send MMS messages. Normally,
your smartphone will set up the profile for you based on information retrieved from your
provider.
Tip: Ask your network provider for the necessary information if you need to manually set
up the MMS profile.
Receiving MMS messages
When a new MMS message arrives, a message icon appears at the top of the
screen and a notification message is displayed.
1. Open Messaging to view a summary of the message.
2. Tap Download to download the message content.
Note: Downloads can take a long time, depending on your connection quality. If you reply
or open another application, the download will be stopped.
Important: You may be charged to download message content, especially if you are
roaming. Please contact your provider if you have any questions.
Option Description
Add subject Add a subject to the message.
Send Send the message.
Insert smiley Insert a smiley/emoticon into your message text.
Delete thread Delete the message thread.
Discard Discard the message.
![](/img.php?id=1695899&img=bg1a.png)
26
3. Tap the message to view the content.
4. To reply to the message, enter your text in the text box
labeled Type message and tap the Send icon. Simple
text replies will be sent as SMS messages. If you wish to
attach a file, tap . You will be presented with a menu
of options.
5. When you have finished composing the message, tap the
Menu button and tap Send.
![](/img.php?id=1695899&img=bg1b.png)
27
Going online
Browsing the Internet
In order to browse the Internet with your smartphone, you must be connected to a
data or wireless network.
Using the browser
Tap Browser on the Home screen to start browsing. To
open a new website, tap the address box at the top of
the page. Enter the address using the keyboard and tap
Go.
To view your browsing history, bookmarks or saved
pages, open the browser then press and hold the Back
button.
You may open multiple pages. When a page is open,
scroll to the top of the page and tap from the
address bar that appears. Tap + to add a new tab.
You can zoom in or out of pages by pinching or reverse
pinching.
Voice search
Note: Voice search is available only in some regions.
With voice actions, you can send text messages, place calls, send emails, find
directions of establishments, automatically call establishments, search the Internet
and even send a note to yourself using your voice. Open Voice Search from the
Applications menu, or press and hold the Search button.
Setting up your Google email
1. Make sure your smartphone is connected to a data or Wi-Fi connection.
2. From the Applications menu tap Gmail.
![](/img.php?id=1695899&img=bg1c.png)
28
If you did not enter your Gmail account address and password when you first
started your phone, follow the on screen instructions.
Composing an email
1. Make sure your smartphone is connected to a data or Wi-Fi connection.
2. From the Applications menu tap Gmail.
3. Tap .
4. Enter the recipient's email address, the subject and message.
5. When you are finished composing your message, tap .
Setting up Email
Your smartphone enables you to access your email. Most
popular ISPs can be set up in two steps. In the
Applications menu tap Email to start setting up your
email account.
If necessary, enter your email address and tap Manual
setup to enter the parameters manually. Tap Next to
finish the setup process.
Google Play
Note: Google Play may not be available in all countries and regions.
Note: You need to have a Google account set up and active on your phone before you
can use Google Play.
Tap Play Store from the Applications menu to open the Google Play. Here you can
obtain a variety of add-on programs and applications to enhance the functionality
of your smartphone. The first time you access Google Play, you will need to read
and accept the Terms of Service.
You can browse the store by category or tap the search icon to search for a specific
application.
Once you have selected an application, tap the Download button to download and
install the application. You will be told which services on your phone that the
application has access to. Tap OK to proceed with the installation.
You may keep track of the download progress from the Notification Area.
![](/img.php?id=1695899&img=bg1d.png)
29
Important: Some applications may require payment before you can download them. You
will need to have a Google Checkout account in order to pay for these applications.
Uninstalling downloaded applications
Once you’ve downloaded and installed an application, you may uninstall the
application by tapping Settings from the Applications menu. In the Settings menu
select Apps > Manage applications. Tap the application you wish to uninstall, tap
Uninstall and confirm the uninstall.
Maps, Navigation, Places and Latitude
Get easy-to-follow directions using Google Maps, view real-time traffic condition
and navigate by using spoken, turn-by-turn driving instructions with Navigation,
view where your friends are and places of interest and local businesses on Google
Maps using Places and Latitude.
Important: Maps does not have information about every location.
Using the map
Tap the Maps icon in the applications menu. Drag the map with your finger to move
the map around.
To zoom in or out:
1. Double tap a location on the map to zoom in on the location, and tap once to
zoom out, or
2. Touch an area with two fingers at once and spread them apart to zoom in, and
pinch them together to zoom out.
Important: Not all zoom levels are available for all locations.
![](/img.php?id=1695899&img=bg1e.png)
30
Using the camera
Your smartphone features a 5-megapixel digital camera mounted on the rear. This
section will take you through all the steps in taking photos and videos with your
smartphone.
Note: You need to have a microSD Card inserted into the microSD slot before using the
camera.
To activate the camera, open the Applications tab and tap Camera.
Camera icons and indicators
In the camera window, the three icons on
the left can be tapped to expand. They
allow you to switch between the camera,
or camcorder. Use the zoom slider at the
bottom of the screen to adjust the zoom.
Camera settings
To adjust the settings, tap while the camera is active. The menu options are:
Icon Description
Activates the camera.
Activates the video recorder.
Icon Description
Display additional camera settings.
Set white balance.
Set the flash on, off, or auto.
Set the exposure.
Set the scene mode.
![](/img.php?id=1695899&img=bg1f.png)
31
Camcorder settings
To adjust the settings, tap while the camcorder is active. The menu options are:
Taking a photo
1. Frame your subject and steady your smartphone.
2. Zoom in or out as needed.
3. Tap the blue button to take the photo.
Shooting a video
Turn on camcorder mode by tapping the camcorder icon.
1. Frame your subject and steady your smartphone and zoom in or out as needed.
2. Tap the record button to begin recording.
Supported formats
Viewing and sharing photos and videos
After you have taken your photo or video, it is automatically saved.
Once you have taken a photo or video, you can view it in Gallery or share it on
various services by tapping the thumbnail icon in the lower right corner.
Alternatively, open the Applications tab and tap Gallery. From Gallery you can
share the file directly using various services.
Note: Share options vary depending on the file type.
Icon Description
Display additional camcorder settings.
Set white balance.
Set the flash on or off.
Set the time lapse interval.
Set the video quality.
Type Formats
Image JPEG
Video MPEG-4, H.263, H.264
![](/img.php?id=1695899&img=bg20.png)
32
Advanced settings
Putting your smartphone in Airplane mode
You can enter Airplane mode (also known as flight mode) to
turn off telephone and Bluetooth functions and use your
smartphone as a handheld device during a flight. Check with
your airline to make sure this is permitted onboard.
Switch your smartphone off during takeoff and landing as it
may interfere with aircraft electronic systems.
Turning Airplane mode on or off
1. Press and hold the power button until you get the phone
options menu.
2. Tap Airplane mode to switch it ON or OFF.
Note: When Airplane mode is active, the
icon will be displayed in the Notification
area.
Adjusting settings
This section will show you how to adjust detailed settings for your phone, data, Wi-
Fi and Bluetooth connections.
Activating or deactivating connections
Open the Applications menu and tap Settings to manage your connection settings.
Tap More... to access additional connection settings.
Item Description
Wi-Fi Turn the Wi-Fi function on or off.
Bluetooth Turn the Bluetooth function on or off.
More... Access additional connection settings.
Item Description
Airplane mode Disable all wireless connections so you can safely use this device
onboard an aircraft.
VPN settings Set up and manage Virtual Private Networks.
Tethering & portable
hotspot
Share your phone’s mobile data connection via USB or as a portable
Wi-Fi hotspot.
NFC Turn the NFC function on or off.
Android Beam Turn the Android Beam function on or off.
Wi-Fi direct Turn the Wi-Fi Direct function on or off.
Wi-Fi direct settings Set up and manage your Wi-Fi Direct devices.
![](/img.php?id=1695899&img=bg21.png)
33
Important: If your phone is in Airplane mode, the option to turn Bluetooth on will be
disabled. Please refer to "Putting your smartphone in Airplane mode" on page 32 for
instructions on turning Airplane mode on or off.
Adjusting Bluetooth settings
You can use Bluetooth to exchange information between your smartphone and
other mobile devices.
Bluetooth connections
For all Bluetooth settings, open the Applications menu and tap Settings >
Bluetooth. Here you can switch Bluetooth on or off, set a device name and
discoverability. Tap SEARCH FOR DEVICES to scan for available devices.
To connect to a device, tap the device in the list of available devices. You may be
asked to enter a PIN on both devices to establish the connection.
Near Field Communication
Your device contains a Near Field Communication (NFC) chip that enables it to
communicate with other NFC devices to send and receive tags such as contact
information, text messages, and URLs.
To enable NFC, open the Applications menu and tap Settings > More... > NFC.
The box next to NFC will have a blue check when turned on.
Note: To send or receive tags your phone must be powered on and not in sleep mode.
Note: Your phone may require a third-party application to communicate with other NFC
devices. Search Google Play for available applications or contact the NFC device’s
vendor for more information.
Android Beam
When this feature is turned on, you can beam app content to another NFC-capable
device by holding the devices close together. For example, you can beam Browser
pages, Youtube videos, People contacts, and more.
Just bring the devices together (typically back to back) and then touch your screen.
The app determines what gets beamed.
To turn Android Beam on, in the Applications menu tap Settings > More... >
Android Beam. Tap ON or OFF to active or deactivate Android Beam.
Mobile networks set your options for connecting to mobile networks.
Call settings Set up voicemail, call forwarding, call waiting, and caller ID.
Item Description
![](/img.php?id=1695899&img=bg22.png)
34
Internet sharing
Tethering via USB
If you wish to share your mobile Internet connection with a computer, you can
connect your phone to a PC using the supplied USB cable.
1. Plug the USB sync cable into the micro USB connector on your smartphone.
2. Plug the USB client connector into an available USB port on your computer.
3. Push the Menu button and then tap Settings > More.. > Tethering & portable
hotspot and then tap USB tethering.
Wi-Fi hotspot
You can turn your smartphone into a portable Wi-Fi hotspot to share your mobile
Internet connection with up to 8 clients.
1. Push the Menu button and then tap Settings > More... > Tethering & portable
hotspot > Configure Wi-Fi hotspot
2. Set the Network SSID and adjust security between Open and WPA2 PSK. Tap
Save to finish.
Note: When your smartphone is serving as a Wi-Fi hotspot, you can’t use your phone’s
applications to access the Internet via its Wi-Fi connection.
Phone network settings
In the Applications menu tap Settings > More... > Mobile networks to adjust your
network settings. You can turn data connection on or off when roaming, choose a
preferred network mode, specify a network operator and define access point
names.
Selecting a network
Your phone will automatically detect your carrier/network settings when you insert a
new SIM card. However, you may prefer to manually select a network. This may be
a good idea when roaming.
Tip: When you are traveling, manually selecting a network may help to reduce your
roaming charges. Check with your home service provider for the network offering the
most competitive rates at your destination.
1. Open the Applications menu and tap Settings > More... > Mobile networks >
Network operators.
2. Your phone will search for available networks.
3. Select your preferred network from the list generated. You phone will attempt to
register on the selected network.
4. Tap Select automatically to connect to the available network with the strongest
signal. This may lead to your phone jumping between networks when you move
around.
![](/img.php?id=1695899&img=bg23.png)
35
Note: Contact your service provider should you have any problems obtaining voice mail
and the text message service center numbers.
Data usage control settings
Data usage controls let you monitor total usage by network type and application
and then set limits if needed.
To access the Data usage settings, from the Application menu tap Settings > Data
usage.
Note: To set a data limit, Wi-Fi or Mobile data must be enabled.
Sound
To adjust your phone’s sound settings, in the Application menu tap Settings >
Sound.
Display
To adjust your phone’s display settings, in the Application menu tap Settings >
Display.
Phone settings
Many phone settings are automatically configured by your smartphone when you
insert a SIM card. The device will communicate with your provider and
Item Description
Volumes Adjust the media, ringtone & notification, and alarm volumes.
Silent mode Silence all sounds except media and alarms.
Phone ringtone Sets your phone’s ringtone.
Default notification Set your phone’s default notification sound.
Vibrate and ring Set your phone to vibrate and ring when not in silent mode.
Dial pad touch tones Play tones when using dial pad.
Touch sounds Play sounds when touching certain UI elements.
Screen lock sound Play sound when locking and unlocking the screen.
Vibrate on touch Vibrate when pressing soft keys and on certain UI interactions.
Item Description
Brightness Adjust screen brightness.
Wallpaper Change the Home screen’s wallpaper
Auto-rotate screen Enable rotation of the screen when device is tilted.
Sleep Adjust the delay before the screen automatically turns off.
Font size Change the default font size for the UI.
![](/img.php?id=1695899&img=bg24.png)
36
automatically obtain all necessary settings, such as network name, voice mail and
text message center numbers.
You can also view and modify these settings manually through the Call settings
screen.
Open the Applications menu and tap Settings > More... > Call settings.
Connecting to a PC
If you wish to transfer information between the microSD Card
in your phone and your computer, you can connect your phone
to a PC using the supplied USB cable. Plug the USB sync
cable into the micro USB connector on your smartphone. Plug
the USB client connector into an available USB port on your
computer.
Pull down the notification bar, and tap Connected as media
device, or Connected as a camera to configure the USB
options.
You will now be able to see the microSD Card in your phone as
a drive in your computer’s file explorer.
Note: After turning on USB storage, you will not be able to access the files in the microSD
card or applications such as Gallery or Music.
Synchronization
You can sync your calendar, email and contacts on your phone
and never worry about losing them again. Sync in real time or
adjust it as you please. In the Applications menu tap Settings
> Accounts & sync to access the synchronization settings.
To have your smartphone auto-sync, make sure Accounts &
sync is set to ON.
To manage synchronization of individual accounts, tap an
account to see their settings.
To add a new account, tap ADD ACCOUNT. Select the type of
account (Corporate, Email, Facebook, or Google) and then
follow on the on screen instructions.
Google Sync
In Google, you can set synchronization for contacts, email, photos and calendar. In
the Accounts & sync menu, tap on a Google account and then tap the checkmark
next to the item you would like to have auto-sync. Tap again to uncheck any for
manual synchronization.
To manually synchronize an item, make sure the item is checked, tap the Menu
button and then tap Sync now.
![](/img.php?id=1695899&img=bg25.png)
37
Note: You need a Google account to sync your calendar and appointments.
FM radio
The FM radio allows you to listen to your favorite stations while
on the move. Headphones must be inserted to the 3.5 mm jack
as it functions as an antenna.
You can access the radio by tapping FMRadio from the
Applications menu.
Tap the power button on the upper right corner to turn the radio
off.
Multimedia playback
Your smartphone comes supplied with a variety of programs
that you can use to enjoy multimedia content.
Media server
Your phone can act as a digital media server using uPnP technology. This means
that you can use it to send media content to other uPnP-enabled home
entertainment devices that are connected to a home wireless network.
To set up the media server, open the Applications menu and tap Media server.
You will need to enable Share Contents before you can start using the service.
Adjusting the volume
Adjust the volume of your phone using the volume button on the side of the phone.
Alternatively, you can set the Ringer volume and Media volume by opening the
Applications menu and tapping Settings > Sound > Volumes.
Setting the date and time
To set the date and time, open the Applications menu and tap Settings > Date &
time.
Tip: If you travel frequently or live in an area that uses daylight saving time, activate
Automatic date & time from this menu. This will enable your smartphone to set the date
and time based on information it receives from the network.
Setting alarms
There are two predefined alarms on your phone by default. Tap Clock in the
Applications menu, and then tap the alarm icon to edit alarm settings. You may:
• Turn the alarm on or off.
• Set the alarm time.
• Set which days to repeat the alarm.
![](/img.php?id=1695899&img=bg26.png)
38
• Set a ringtone.
• Enable or disable vibrate.
• Give it a label.
Changing language and text options
Set your location and language input preferences by opening the Applications
menu and going to Settings > Language & input.
Managing applications
App-2-SD
When installing an application, you may have a choice to install the program to the
internal memory or installed memory card.
Note: Not all applications support App-2-SD. Please see application specifications for
compatibility.
Warning! Make sure you trust the source of any application you install. If you are not
sure of the source, do not install an application. Installing applications from
unknown sources increases your risk of virus attacks and theft of personal and
private data.
Moving applications to the installed memory card
Once an application is installed, it may be possible to move it to the installed
memory card to free up more space on the device’s internal storage.
To move an application to the installed memory card:
1. In the Applications menu, tap Settings > Apps.
2. Tap on the Downloaded tab and then tap on the application you would like to
move.
3. If it is possible to move the application, then you will be able to tap Move to SD
card. If the option is greyed-out, then the application can not be moved. If you
see the Move to phone option, then the application is already on SD card.
Note: Not all applications can be moved to the external memory card.
Closing an application
To close an active application, in the Applications menu tap Settings > Apps. Tap
the Running tab, then tap the program you wish to close. Select Stop to close the
program.
Uninstalling an application
You can remove programs installed on your smartphone to free up extra storage
memory.
1. In the Applications menu tap Settings > Apps.
2. Click on the Downloaded tab.
![](/img.php?id=1695899&img=bg27.png)
39
3. Find the application in the list and tap on it.
4. Tap the Uninstall button and then tap OK. and hold a program icon from the
Applications menu and drag it into the trash can on the bottom left hand corner.
Warning! You should only remove programs if you are familiar with the Android
operating system.
Restoring to factory settings
You may perform a clean boot to restore your smartphone to the factory settings.
Note: Before performing a clean boot, ensure that your smartphone is not locked. Press
any key or tap the screen to see if the phone responds.
Warning! You should only perform a clean boot when all other options have failed to
restore your smartphone to an operational state.
Warning! This will erase all your personal information, any contacts stored on your
phone and any programs you installed.
If your phone is responding to screen input, then open Settings from the
Applications menu. Tap Backup & reset > Factory data reset; click Reset phone
and then Erase everything to format your phone.
![](/img.php?id=1695899&img=bg28.png)
40
Accessories and tips
This chapter shows you how to use accessories with your smartphone, as well as
provide useful tips for when you are using your smartphone.
Using the headset
Your smartphone comes packaged with a headset with built-in microphone for
handsfree use when making calls.
To use the headset, plug it into the 3.5 mm headphone jack at the top of the phone.
When the headset is plugged in, all audio is routed to the headset, and the
speakers are turned off.
• To answer an incoming call, press the button on the microphone.
• Adjust the volume using the volume up/down button on the smartphone.
• End the call by pressing the button again.
Using a Bluetooth headset
Your smartphone’s Bluetooth functions make it fully compatible with all Bluetooth
headsets. This allows you to use the unit handsfree when making calls, without the
inconvenience of wires.
Creating a new access point
When you need to add another GPRS/3G/EDGE connection on your phone, obtain
the access point name and settings (including username and password if required)
from your wireless service provider.
1. Open the Applications menu and tap Settings > More... > Mobile networks >
Access Point Names.
2. Tap the Menu button and then tap New APN.
3. Enter the APN settings. Tap an item to adjust it.
4. When you have finished tap the Menu button and then tap Save.
Important: Some providers and countries do not allow the use of a smartphone as a
modem over HSDPA. Please check with your provider before attempting to do so.
Inserting a microSD Card
Your smartphone features a memory expansion slot that accepts a microSD Card
to expand memory and storage capacity.
Please refer to "Installing a SIM or microSD Card" on page 8 for instructions on
installing a microSD Card.
![](/img.php?id=1695899&img=bg29.png)
41
Appendix
FAQ and troubleshooting
This section lists frequently asked questions that may arise during the use of your
smartphone, and gives easy answers and solutions to these questions.
Aspect Question Answer
Audio Why is there no sound
coming from the
device?
If the headset is plugged into the device, the
speaker is automatically shut off. Disconnect
the headset.
Check that the device volume setting is not
muted.
Check that the volume control is not at its
lowest setting.
Multimedia files Why can’t I view my
video files?
You may be trying to view a video that is not
supported. Refer to "Multimedia" on
page 47.
Why can’t I play my
music files?
You may be trying to play a file that is not
supported. Refer to "Multimedia" on
page 47.
System information
and performance
How do I check the OS
version of my device?
Tap Apps > Settings > About phone to check
the OS version (Build number) and other
hardware and software information.
Power I can’t turn on the
device.
The battery power may be depleted. Recharge
the device. Refer to "Charging the battery"
on page 7 for more information.
RAM / ROM How do I check the
RAM and ROM memory
status?
To check the ROM status, press the Menu
button and then tap System settings >
Storage.
To check RAM status, tap Apps > Settings >
RUNNING.
Internal storage My device’s available
internal storage is full or
almost full.
Uninstall applications or move applications to
the SD card to increase available storage. See
"Managing applications" on page 38.
Unlock pattern I forgot my unlock
pattern.
After a certain number of wrong entries, you
will be presented with an option to reset your
pattern. Tap Forgot pattern? and enter your
google account username and password.
Note: You must have an active Google
account on the smartphone.
Alternatively, you restore your smartphone to
factory settings. See "Restoring to factory
settings" on page 39.
![](/img.php?id=1695899&img=bg2a.png)
42
Other sources of help
Warnings and precautions
• Do not use this product near water.
• Do not place this product on an unstable cart, stand or table. If the product falls, it
could be seriously damaged.
• Slots and openings are provided for ventilation to ensure reliable operation of the
product and to protect it from overheating. These openings must not be blocked or
covered. The openings should never be blocked by placing the product on a bed,
sofa, rug or other similar surface. This product should never be placed near or over a
radiator or heat register, or in a built-in installation unless proper ventilation is
provided.
• Never push objects of any kind into this product through cabinet slots as they may
touch dangerous voltage points or short-out parts that could result in a fire or electric
shock. Never spill liquid of any kind onto or into the product.
• To avoid damage of internal components and to prevent battery leakage, do not
place the product on a vibrating surface.
• Never use this product when engaging in sporting activities, exercising, or in any
vibrating environment which may cause a short circuit or damage, and even a risk of
explosion from the battery pack.
CAUTION when listening to music
To protect your hearing, follow these instructions.
• Increase the volume gradually until you can hear clearly and comfortably.
• Do not increase the volume level after your ears have adjusted.
• Do not listen to music at high volumes for extended periods.
• Do not increase the volume to block out noisy surroundings.
• Decrease the volume if you can’t hear people speaking near you.
Battery information
This product uses a Lithium-ion battery. Do not use it in a humid, wet and/or corrosive
environment. Do not put, store or leave your product in or near a heat source, in a high
temperature location, in strong direct sunlight, in a microwave oven or in a pressurized
container, and do not expose it to temperatures over 60 °C (140 °F). Failure to follow these
Heat The phone heats up
when charging or
making long duration
calls.
It is normal for the phone to heat up when
charging. When charging is complete, it will
return to its normal temperature.
It is also normal for the phone to heat up
during long periods of use, such as watching
a video or a long phone conversation.
For information on: Refer to:
Up-to-date information regarding your
smartphone
www.acer.com
mobile.acer.com
Service enquiries www.acer.com/support
Aspect Question Answer
![](/img.php?id=1695899&img=bg2b.png)
43
guidelines may cause the battery to leak acid, become hot, explode or ignite and cause injury
and/or damage. Do not pierce, open or disassemble the battery. If the battery leaks and you
come into contact with the leaked fluids, rinse thoroughly with water and seek medical
attention immediately. For safety reasons, and to prolong the lifetime of the battery, charging
will not occur at low (below 0° C/32° F) or high (over 40° C/104° F) temperatures.
The full performance of a new battery is achieved only after two or three complete charge and
discharge cycles. The battery can be charged and discharged hundreds of times, but it will
eventually wear out. When the talk and standby times are noticeably shorter than normal, buy
a new battery. Use only Acer approved batteries, and recharge your battery only with Acer
approved chargers designated for this device.
Unplug the charger from the electrical plug and the device when not in use. Do not leave a
fully charged battery connected to the ac charger, since overcharging may shorten its lifetime.
If left unused, a fully charged battery will lose its charge over time. If the battery is completely
discharged, it may take a few minutes before the charging indicator appears on the display or
before any calls can be made.
Use the battery only for its intended purpose. Never use any charger or battery that is
damaged.
Do not short-circuit the battery. Accidental short-circuiting can occur when a metallic object
such as a coin, clip, or pen causes direct connection of the positive (+) and negative (-)
terminals of the battery. (These look like metal strips on the battery.) This might happen, for
example, when you carry a spare battery in your pocket or purse. Short-circuiting the
terminals may damage the battery or the connecting object.
Leaving the battery in hot or cold places, such as in a closed car in summer or winter
conditions, will reduce the capacity and lifetime of the battery. Always try to keep the battery
between 15° C and 25° C (59° F and 77° F). A device with a hot or cold battery may not work
temporarily, even when the battery is fully charged. Battery performance is particularly limited
in temperatures well below freezing.
Do not dispose of batteries in a fire as they may explode. Batteries may also explode if
damaged. Dispose of batteries according to local regulations. Please recycle when possible.
Do not dispose as household waste.
Replacing the battery pack
Your smartphone uses lithium batteries. Replace the battery with the same type as that which
came bundled with your product. Use of another battery may present a risk of fire or
explosion.
Warning! Batteries may explode if not handled properly. Do not disassemble or
dispose of them in fire. Keep them away from children. Follow local regulations
when disposing of used batteries.
Additional safety information
Your device and its enhancements may contain small parts. Keep them out of the reach of
small children.
![](/img.php?id=1695899&img=bg2c.png)
44
Operating environment
Warning! For safety reasons, turn off all wireless or radio transmitting devices when
using your smartphone device under the following conditions. These devices may
include, but are not limited to: wireless LAN (WLAN), Bluetooth and/or 3G.
Remember to follow any special regulations in force in any area, and always switch off your
device when its use is prohibited or when it may cause interference or danger. Use the device
only in its normal operating positions. To successfully transmit data files or messages, this
device requires a good quality connection to the network. In some cases, transmission of data
files or messages may be delayed until such a connection is available. Ensure that the above
separation distance instructions are followed until the transmission is completed. Parts of the
device are magnetic. Metallic materials may be attracted to the device, and persons with
hearing aids should not hold the device to the ear with the hearing aid. Do not place credit
cards or other magnetic storage media near the device, because information stored on them
may be erased.
Medical devices
Operation of any radio transmitting equipment, including wireless phones, may interfere with
the functionality of inadequately protected medical devices. Consult a physician or the
manufacturer of the medical device to determine if they are adequately shielded from external
RF energy or if you have any questions. Switch off your device in health care facilities when
any regulations posted in these areas instruct you to do so. Hospitals or health care facilities
may be using equipment that could be sensitive to external RF transmissions.
Pacemakers. Pacemaker manufacturers recommend that a minimum separation of 15.3 cm
(6") be maintained between wireless devices and a pacemaker to avoid potential interference
with the pacemaker. These recommendations are consistent with the independent research
by and recommendations of Wireless Technology Research. Persons with pacemakers should
do the following:
• Always keep the device more than 15.3 cm (6") from the pacemaker.
• Not carry the device near your pacemaker when the device is switched on. If you
suspect interference, switch off your device, and move it.
Hearing aids. Some digital wireless devices may interfere with some hearing aids. If
interference occurs, consult your service provider.
Vehicles
RF signals may affect improperly installed or inadequately shielded electronic systems in
motor vehicles such as electronic fuel injection systems, electronic anti-skid (anti-lock)
braking systems, electronic speed control systems, and air bag systems. For more
information, check with the manufacturer, or its representative, of your vehicle or any
equipment that has been added. Only qualified personnel should service the device, or install
the device in a vehicle. Faulty installation or service may be dangerous and may invalidate any
warranty that may apply to the device. Check regularly that all wireless equipment in your
vehicle is mounted and operating properly. Do not store or carry flammable liquids, gases, or
explosive materials in the same compartment as the device, its parts, or enhancements. For
vehicles equipped with an air bag, remember that air bags inflate with great force. Do not
place objects, including installed or portable wireless equipment in the area over the air bag or
in the air bag deployment area. If in-vehicle wireless equipment is improperly installed, and
the air bag inflates, serious injury could result. Using your device while flying in aircraft is
![](/img.php?id=1695899&img=bg2d.png)
45
prohibited. Switch off your device before boarding an aircraft. The use of wireless teledevices
in an aircraft may be dangerous to the operation of the aircraft, disrupt the wireless telephone
network, and may be illegal.
Potentially explosive environments
Switch off your device when in any area with a potentially explosive atmosphere and obey all
signs and instructions. Potentially explosive atmospheres include areas where you would
normally be advised to turn off your vehicle engine. Sparks in such areas could cause an
explosion or fire resulting in bodily injury or even death. Switch off the device at refueling
points such as near gas pumps at service stations. Observe restrictions on the use of radio
equipment in fuel depots, storage, and distribution areas; chemical plants; or where blasting
operations are in progress. Areas with a potentially explosive atmospheres are often, but not
always, clearly marked. They include below deck on boats, chemical transfer or storage
facilities, vehicles using liquefied petroleum gas (such as propane or butane), and areas where
the air contains chemicals or particles such as grain, dust or metal powders.
Follow any restrictions. Do not use the device where blasting is in progress.
Emergency calls
Important: Wireless phones, including this device, operate using radio signals, wireless
networks, landline networks, and user-programmed functions. Because of this, connections
in all conditions cannot be guaranteed. You should never rely solely on any wireless device for
essential communications like medical emergencies.
If certain features are in use, you may first need to turn those features off before you can make
an emergency call. Consult this guide or your service provider for more information.
When making an emergency call, give all the necessary information as accurately as possible.
Your wireless device may be the only means of communication at the scene of an accident.
Do not end the call until given permission to do so.
Disposal and recycling information
Do not throw this electronic device into the trash when discarding.
To minimize pollution and ensure utmost protection of the global environment,
please recycle. For more information on the Waste from Electrical and Electronics
Equipment (WEEE) regulations, visit
www.acer-group.com/public/Sustainability/sustainability01.htm
Mercury advisory
For projectors or electronic products containing an LCD/CRT monitor or display:
Lamp(s) inside this product contain mercury and must be recycled or disposed of
according to local, state or federal laws. For more information, contact the
Electronic Industries Alliance at www.eiae.org. For lamp-specific disposal
information, check www.lamprecycle.org.
Taking care of your smartphone
1. DO take care not to scratch the screen of your smartphone. Keep the screen clean. When
working with your smartphone, use your finger or fingernail. Never use an actual pen or
pencil or other sharp object on the screen surface.
2. DO NOT expose your smartphone to rain or moisture. Do not let water enter the circuitry
through the front panel buttons or expansion slots. In general, treat your smartphone as
you would a mobile phone or other small electronic device.
![](/img.php?id=1695899&img=bg2e.png)
46
3. DO be careful not to drop your smartphone or subject it to any strong impact. Do not place
your smartphone in your back pocket.
4. DO NOT expose your smartphone to extreme temperatures. For example, do not leave
your smartphone on the dashboard of a car on a hot day or when temperatures are below
freezing point. Also, keep it away from heaters and other sources of heat.
5. DO NOT use or store your smartphone in any location that is dusty, damp or wet.
6. DO use a soft, damp cloth to clean your smartphone. If the surface of the screen becomes
soiled, clean it with a soft cloth moistened with diluted window-cleaning solution.
7. DO NOT press down on the screen with force, otherwise you may crack the screen.
![](/img.php?id=1695899&img=bg2f.png)
47
Specifications
Performance
• Qualcomm MSM 7227A, 1 GHz
• System memory:
• 512 MB of RAM
• 1 GB of ROM
• Android operating system
Display
• 3.7" WVGA TFT, capacitive touch panel
• 800 x 480 resolution
Multimedia
Formats supported:
USB connector
• Micro USB connector
•USB client
• DC power-in (5 V, 1 A)
Connectivity
• Bluetooth 3.0
• IEEE Wi-Fi 802.11b/g/n WLAN
• GSM 900 / 1800 / 1900
• UMTS 900 / 2100
• HSDPA / GPRS / EDGE
•GPS
•aGPS
•NFC
Camera
• 5-megapixel
•LED flash
Type Formats
Audio
playback
MP3, AMR, WMA
Ringtone MP3, MIDI, iMelody, WAVE, WMA
Video
recording
3GP, MPEG-4, H.263, H.264
Video
playback
3GP, MPEG-4, H.263, H.264, WMV
![](/img.php?id=1695899&img=bg30.png)
48
Expansion
• microSD memory card slot (up to 32 GB)
Battery
• Rechargeable high density 1300 mAh Lithium-ion battery (replaceable)
Note: Length of battery operation will depend on power consumption which is based on
system resource use. For example, constantly using the backlight or using power-
demanding applications will shorten battery life between charges.
Dimensions
Height 117 mm
Width 58.5 mm
Thickness 11.5 mm
Weight 125 g (with battery)
![](/img.php?id=1695899&img=bg31.png)
49
Safety
Battery information
This product uses a Lithium-ion battery. Do not use it in a humid, wet and/or
corrosive environment. Do not put, store or leave your product in or near a heat
source, in a high temperature location, in strong direct sunlight, in a microwave
oven or in a pressurized container, and do not expose it to temperatures over 60 °C
(140 °F). Failure to follow these guidelines may cause the battery to leak acid,
become hot, explode or ignite and cause injury and/or damage. Do not pierce,
open or disassemble the battery. If the battery leaks and you come into contact
with the leaked fluids, rinse thoroughly with water and seek medical attention
immediately. For safety reasons, and to prolong the lifetime of the battery, charging
will not occur at low (below 0 °C/32 °F) or high (over 40 °C/104 °F) temperatures.
The full performance of a new battery is achieved only after two or three complete
charge and discharge cycles. The battery can be charged and discharged hundreds
of times, but it will eventually wear out. When the talk and standby times are
noticeably shorter than normal, buy a new battery. Use only manufacturer approved
batteries, and recharge your battery only with manufacturer approved chargers
designated for this device.
Unplug the charger from the electrical plug and the device when not in use. Do not
leave a fully charged battery connected to the AC charger, since overcharging may
shorten its lifetime. If left unused, a fully charged battery will lose its charge over
time. If the battery is completely discharged, it may take a few minutes before the
charging indicator appears on the display or before any calls can be made.
Use the battery only for its intended purpose. Never use any charger or battery that
is damaged.
Do not short-circuit the battery. Accidental short-circuiting can occur when a
metallic object such as a coin, clip, or pen causes direct connection of the positive
(+) and negative (-) terminals of the battery. These look like metal strips on the
battery. This might happen, for example, when you carry a spare battery in your
pocket or purse. Short-circuiting the terminals may damage the battery or the
connecting object.
Leaving the battery in hot or cold places, such as in a closed car in summer or
winter conditions, will reduce the capacity and lifetime of the battery. Always try to
keep the battery between 15 °C and 25 °C (59 °F and 77 °F). A device with a hot or
cold battery may not work temporarily, even when the battery is fully charged.
Battery performance is particularly limited in temperatures well below freezing.
Do not dispose of batteries in a fire as they may explode. Batteries may also
explode if damaged. Dispose of batteries according to local regulations. Please
recycle when possible. Do not dispose as household waste.
Replacing the battery
Your smartphone uses a Lithium-ion battery. Replace the battery with the same
type as that which came bundled with your product. Use of another battery may
present a risk of fire or explosion.
![](/img.php?id=1695899&img=bg32.png)
50
Warning! Batteries may explode if not handled properly. Do not disassemble or
dispose of them in fire. Keep them away from children. Follow local regulations
when disposing of used batteries.
Disposal and recycling information
Do not throw this electronic device into the trash when discarding.
To minimize pollution and ensure utmost protection of the global
environment, please recycle. For more information on the Waste from
Electrical and Electronics Equipment (WEEE) regulations, visit www.acer-
group.com/public/Sustainability/sustainability01.htm
EEE yönetmeligine uygundur.
It is compliant with EEE regulation.
Regulatory information
Compliant with Russian regulatory certification
RoHS compliance
This product is in compliance with Directive 2002/95/EC of the European
Parliament and of the Council of 27 January 2003, on the restriction of the use of
certain hazardous substances in electrical and electronic equipment (RoHS) and its
amendments.
Prevention of hearing loss
Caution: Permanent hearing loss may occur if earphones or headphones are used at
high volume for prolonged periods of time.
This device have been tested to comply with the Sound Pressure Level requirement
laid down in the applicable EN 50332-1 and/or EN 50332-2 standards.
A pleine puissance, l’écoute prolongée du baladeur peut endommager
l’oreille de l’utilisateur.
Note: For France, mobile headphones or earphones for this device have been
tested to comply with the Sound Pressure requirement laid down in the
applicable NF EN 50332-1:2000 and/or NF EN 50332-2:2003 standards as
required by French Article L. 5232-1.
![](/img.php?id=1695899&img=bg33.png)
51
Wireless operation channels for different domains
France: Products with a 2.4 GHz WLAN device
For products with 2.4 GHz Wireless LAN device operation, certain restrictions
apply:
• The maximum authorized power indoors is 100 mW for 2400-2483.5 MHz.
• The maximum authorized power outdoors is 100 mW for 2400-2454 MHz.
• The maximum authorized power outdoors is 10 mW for 2454-2483.5 MHz.
For the latest requirements, see
www.art-telecom.fr.
L'utilisation de cet equipement (2.4GHz WLAN) est soumise à certaines restrictions:
• La puissance maximale autorisée en intérieur est de 100 mW pour 2400 -
2483.5 MHz.
• La puissance maximale autorisée est de 100 mW en extérieur pour 2400 -
2454MHz.
• La puissance maximale autorisée est de 10 mW en extérieur pour 2454 -
2483.5MHz.
Pour les dernières restrictions, voir
www.art-telecom.fr.
List of National Codes
This equipment may be operated in the following countries:
Certificate Information (SAR)
This device meets the EU requirements (1999/519/EC) on the limitation of exposure
of the general public to electromagnetic fields by way of health protection.
The limits are part of extensive recommendations for the protection of the general
public. These recommendations have been developed and checked by
N. America 2.412-2.462 GHz Ch01 through Ch11
Japan 2.412-2.484 GHz Ch01 through Ch14
Europe ETSI 2.412-2.472 GHz Ch01 through Ch13
Country
Austria
Belgium
Cyprus
Czech Republic
Denmark
Estonia
Finland
France
Germany
Greece
Hungary
Ireland
Italy
Latvia
Lithuania
Luxembourg
ISO 3166
2 letter code
AT
BE
CY
CZ
DK
EE
FI
FR
DE
GR
HU
IE
IT
LV
LT
LU
Country
Malta
Netherlands
Poland
Portugal
Slovakia
Slovenia
Spain
Sweden
United Kingdom
Iceland
Liechtenstein
Norway
Switzerland
Bulgaria
Romania
Tur key
ISO 3166
2 letter code
MT
NT
PL
PT
SK
SL
ES
SE
GB
IS
LI
NO
CH
BG
RO
TR
![](/img.php?id=1695899&img=bg34.png)
52
independent scientific organizations through regular and thorough evaluations of
scientific studies. To guarantee the safety of all persons, regardless of age and
health, the limits include a significant safety buffer.
Before radio devices can be put in circulation, their agreement with European laws
or limits must be confirmed; only then may the CE symbol be applied.
The unit of measurement for the European Council's recommended limit for mobile
telephones is the "Specific Absorption Rate" (SAR). This SAR limit is 2.0 W/kg,
averaged over 10 g of body tissue. It meets the requirements of the International
Commission on Non-Ionizing Radiation Protection (ICNIRP) and was included in the
European Standard EN 50360 for mobile radio devices. The SAR regulation for
mobile telephones is in line with European Standard EN 62209-1. The maximum
SAR value is calculated at the highest output level in all frequency bands of the
mobile telephone.
For body worn operation, this phone (EU model) has been tested and meets the
ICNIRP exposure guidelines, and was included in the European Standard EN 62311
and EN 62209-2 for use with accessories that contain no metal and that position
the handset a minimum of 1.5 cm from the body. Use of other accessories may not
ensure compliance with ICNIRP exposure guidelines. If you do not use a body-worn
accessory and are not holding the phone at the ear, position the handset a
minimum of 1.5 cm from your body when the phone is switched on.
During use, the actual SAR level is usually much lower than the maximum value,
because the mobile telephone works in different output levels. It only transmits with
as much output as is required to reach the network. In general the following applies:
The closer you are to a base station, the lower the transmission output of your
mobile telephone. The tested SAR of this device is as follows:
FCC regulations
This mobile phone complies with part 15 of the FCC Rules. Operation is subject to
the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
This mobile phone has been tested and found to comply with the limits for a Class
B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
NCC CE
Head (W/kg) Body (W/kg) Head (W/kg)
1.68 0.863 1.68
![](/img.php?id=1695899&img=bg35.png)
53
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
RF exposure warning
The equipment complies with FCC RF exposure limits set forth for an uncontrolled
environment.
The antenna(s) used for this transmitter must not be co-located or operating in
conjunction with any other antenna or transmitter.
RF exposure information (SAR)
This mobile phone meets the government's requirements for exposure to radio
waves.
This phone is designed and manufactured not to exceed the emission limits for
exposure to radio frequency (RF) energy set by the Federal Communications
Commission of the U.S. Government.
The exposure standard for wireless mobile phones employs a unit of measurement
known as the Specific Absorption Rate, or SAR. The
SAR limit set by the FCC is 1.6 W/kg.
Tests for SAR are conducted using standard
operating positions accepted by the FCC with
the phone transmitting at its highest certified power level in all tested frequency
bands.
Although the SAR is determined at the highest certified power level, the actual SAR
level of the phone while operating can be well below the maximum value. This is
because the phone is designed to operate at multiple power levels so as to use only
the power required to reach the network. In general, the closer you are to a wireless
base station antenna, the lower the power output.
The highest SAR value as reported to the FCC when tested for use at the ear is
0.816 W/kg and when worn on the body, as described in this user guide, is 0.959
W/kg for GSM 1900 MHz band.
Important: Body-worn measurements differ amount phone models, depending upon
available enhancements and FCC requirements.
![](/img.php?id=1695899&img=bg36.png)
54
While there may be differences between the SAR levels of various phones and at
various positions, they all meet the government requirements.
The FCC has granted an Equipment Authorization for this model of phone with all
reported SAR levels evaluated as in compliance with the FCC RF exposure
guidelines. SAR information on this model of phone is on file with the FCC and can
be found under the Display Grant section of www.fcc.gov/oet/ea/fccid after
searching on FCC ID: HLZDME330NFCCE.
For body worn operation, this phone has been tested and meets the FCC RF
exposure guidelines for use with accessories that contain no metal and that
position the handset a minimum of 1 cm from the body. Use of other accessories
may not ensure compliance with FCC RF exposure guidelines. If you do not use a
body-worn accessory and are not holding the phone at the ear, position the
handset a minimum of 1 cm from your body when the phone is switched on.
![](/img.php?id=1695899&img=bg37.png)
55
Certification logos
To view the certification logos on your device: tap Settings > About phone > Legal
information > Certification logo.
![](/img.php?id=1695899&img=bg38.png)
56
NCC warning
巵崭
倢⨚㆞崜巘⚗㫋⃚⇝┮䘖⺓櫊榊㳮᧨槭倢峀♾᧨⏻⚇ᇬ⟕壮㒥∎䞷劔⧖ₜ㈦㝔呹帙㦃
櫊䘖ᇬ┯⮶┮䘖㒥帙㦃☮岼岗⃚䔈㊶♙┮厌ᇭ
⇝┮䘖⺓櫊榊㳮⃚∎䞷ₜ㈦㈀檎歪咹⸘⏷♙㞍⚗㽤抩≰᧷倢䤋䚍㦘㞍䚍廰㣑᧨㑘
䵚☂⋫䞷᧨₵㟈⠓咂䎰㞍㣑㡈㈦儋儛∎䞷ᇭ
ⓜ檔⚗㽤抩≰᧨㖖∬榊≰㽤尞⸩⇫㯼⃚䎰偩榊抩≰ᇭ
⇝┮䘖⺓櫊榊㳮檗㉜♦⚗㽤抩≰㒥ぴ㯼ᇬ䱠⸇♙携䣑䞷榊㽱懊⺓㊶榊㳮岼⌨⃚㞍᧨
䂪⺠榊䭐㽱㈀檎᧨嵚ⰴ⠓∎䞷ᇭ
Note: SAR㲨䄥⋋2.0 W/kg抐䂻䞱❐䂻⋋䍉 1.68 W/kg
Lithium-ion battery warning
ATTENZIONE! Rischio di esplosione della batteria se
sostituita in modo errato. Sostituire la batteria con un
una di tipo uguale o equivalente consigliata dalla
fabbrica. Non disperdere le batterie nell’ambiente.
VORSICHT! Explosionsgefahr bei unsachgemäßen
Austausch der Batterie. Ersatz nur durch denselben
oder einem vom Hersteller empfohlenem ähnlichen
Typ. Entsorgung gebrauchter Batterien nach
Angaben des Herstellers.
ADVARSELI! Lithiumbatteri - Eksplosionsfare ved
fejlagtig håndtering. Udskiftning må kun ske med
batteri af samme fabrikat og type. Levér det brugte
batteri tilbage til leverandøren.
VARNING! Explosionsfara vid felaktigt batteribyte.
Använd samma batterityp eller en ekvivalent typ som
rekommenderas av apparattillverkaren. Kassera
använt batteri enligt fabrikantens instruktion.
VAROITUS! Paristo voi räjähtää, jos se on
virheellisesti asennettu. Vaihda paristo ainoastaan
laitevalmistajan sousittelemaan tyyppiin. Hävitä
käytetty paristo valmistagan ohjeiden mukaisesti.
ATTENTION! Il y a danger d’explosion s’il y a
remplacement incorrect de la batterie. Remplacer
uniquement avec une batterie du mêre type ou d’ un
type équivalent recommandé par le constructeur.
Mettre au rebut les batteries usagées conformément
aux instructions du fabricant.
ADVARSEL! Eksplosjonsfare ved feilaktig skifte av
batteri. Benytt samme batteritype eller en tilsvarende
type anbefalt av apparatfabrikanten. Brukte batterier
kasseres i henhold til fabrikantens instruksjoner.
![](/img.php?id=1695899&img=bg39.png)
57
Acer Incorporated
Date: May 7, 2012
Declaration of Conformity
We, Acer Incorporated,
of 8F., No. 88, Sec. 1, Xintai 5th Rd., Xizhi Dist, New Taipei City, 22181, Taiwan
Declare under sole responsibility that the product:
Model: E330
Description: Smart Handheld
To which this declaration relates, is in conformity with the following standards and/
or other normative documents:
• EN 301 511 V9.0.2
• EN 301 908-1 V5.2.1; EN 301 908-2 V5.2.1
• EN 300 328 V1.7.1
• EN 300 440-1 V1.6.1; EN 300 440-2 V1.4.1
• EN 301 489-1 V1.9.2; EN 301 489-3 V1.4.1; EN 301 489-7 V1.3.1
• EN 301 489-17 V2.1.1; EN 301 489-24 V1.5.1
• EN 302 291-1 V1.1.1; EN 302 291-2 V1.1.1
• EN 55022:2010/AC:2011 Class B; EN 55024:2010
• EN 55013:2001/A1:2003/A2:2006; EN 55020:2007
• EN 60950-1: EN 60950-1:2006+A11:2009+A1:2010+A12:2011
• EN 50332-1:2000; EN 50332-2:2003
• EN 50360:2001/AC:2006; EN 50364:2010; EN 62311:2008; EN 62209-
1:2006;EN 62209-2:2010; EN 62479:2010
• RoHS Directive 2002/95/EC on the Restriction of Use of certain Hazardous
Substances in Electrical and Electronic Equipment.
•The maximum concentration values of the restricted substances by weight in
homogenous material are:
We hereby declare that the above named product is in conformance to all the
essential requirements of the R&TTE Directive (99/5/EC) issued by the Commission
of the European Community.
The conformity assessment procedure referred to in Article 10 and detailed in Annex
[IV] of directive 1999/5/EC has been followed related to Articles:
• R&TTE Article 3.1 (a) Health and Safety
• R&TTE Article 3.1 (b) EMC
• R&TTE Article 3.2 Spectrum Usage
with the involvement of the following Notified Body:
Lead 0.1% Polybrominated Biphenyls (PBB’s) 0.1%
Mercury 0.1% Polybrominated Diphenyl Ethers (PBDE’s) 0.1%
Hexavalent Chromium 0.1% Cadmium 0.01%
0682
![](/img.php?id=1695899&img=bg3a.png)
58
CETECOM, Untertuerkheimer Str. 6 – 10 66117 Saarbruecken
Identification mark: 0682 (Notified Body) CE
The technical documentation relevant to the above equipment will be held at:
Acer Incorporated
8F., No. 88, Sec. 1, Xintai 5th Rd., Xizhi Dist, New Taipei City, 22181, Taiwan
Authorized person:
Name: Harriot SL Lee
For the address/telephone number of Acer service center, please refer to the warranty card.
![](/img.php?id=1695899&img=bg3b.png)
End User License Agreement
IMPORTANT-READ CAREFULLY: THIS END USER LICENSE AGREEMENT ("AGREEMENT") IS A LEGAL AGREEMENT
BETWEEN YOU (EITHER AN INDIVIDUAL OR A SINGLE ENTITY), AND ACER INC. INCLUDING ITS SUBSIDIARIES ("ACER")
FOR THE SOFTWARE (WHETHER PROVIDED BY ACER OR BY ACER'S LICENSORS OR SUPPLIERS) THAT ACCOMPANIES
THIS AGREEMENT, INCLUDING ANY ASSOCIATED MEDIA, PRINTED MATERIALS AND RELATED USER ELECTRONIC
DOCUMENTATION WHICH MAY BE BRANDED "ACER" ("SOFTWARE"). AGREEMENTS RELATING TO ANY OTHER PRODUCT
OR TOPIC ARE NEITHER INTENDED NOR SHOULD THEY BE IMPLIED. BY INSTALLING THE ACCOMPANYING SOFTWARE
OR ANY PORTION THEREOF, YOU AGREE TO BE BOUND BY THE TERMS AND CONDITIONS OF THIS AGREEMENT. IF YOU
DO NOT AGREE TO ALL OF THE TERMS AND CONDITIONS OF THIS AGREEMENT, DO NOT CONTINUE THE INSTALLATION
PROCESS AND IMMEDIATELY DELETE ALL INSTALLED FILES, IF ANY, OF THE ACCOMPANYING SOFTWARE FROM YOUR
PHONE.
IF YOU DO NOT HAVE A VALIDLY-LICENSED COPY OF THE APPLICABLE SOFTWARE, YOU ARE NOT AUTHORIZED TO
INSTALL, COPY OR OTHERWISE USE THE SOFTWARE, AND HAVE NO RIGHTS UNDER THIS AGREEMENT.
The Software is protected by U.S. and international copyright laws and conventions as well as other intellectual property laws
and treaties. The Software is licensed, not sold.
GRANT OF LICENSE
Acer grants to you the following non-exclusive and non-transferable rights with respect to the Software. Under this Agreement,
you may:
1. Install and use the Software only on a single designated phone. A separate license is required for each phone on which
the Software will be used;
2. Make one copy of the Software solely for backup or archival purposes;
3. Make one hardcopy of any electronic documents included in the Software, provided that you receive the documents
electronically.
RESTRICTIONS
You ma y N OT:
1. Use or copy the Software except as provided in this Agreement;
2. Rent or lease the Software to any third party;
3. Modify, adapt, or translate the Software in whole or in part;
4. Reverse engineer, decompile, or disassemble the Software or create derivative works based upon the Software;
5. Merge the Software with any other program or modify the Software, except for your personal use; and
6. Sublicense or otherwise make the Software available to third parties, except that you may, after prior written notification
to Acer, transfer the Software as a whole to a third party so long as you do not retain any copies of the Software and such
third party accepts the terms of this Agreement.
7. Transfer your rights under this Agreement to any third parties.
8. Export the Software in contravention of applicable export laws and regulations, or (i) sell, export, re-export, transfer,
divert, disclose technical data, or dispose of, any Software to any prohibited person, entity, or destination including,
without limitation, Cuba, Iran, North Korea, Sudan and Syria; or (ii) use any Software for any use prohibited by the laws or
regulations of the United States.
SUPPORT SERVICES
Acer is not obligated to provide technical or other support for the Software.
ACER LIVE UPDATE
Certain of the software contains elements that enable the use of the Acer Live Update service, which allows for updates for such
software to be automatically downloaded and installed on your phone. By installing the software, you hereby agree and consent
that Acer (or its licensors) may automatically check the version of such software that you are using on your phone and may
provide upgrades to such software that may be automatically downloaded on to your phone.
OWNERSHIP AND COPYRIGHT
Title, ownership rights and intellectual property rights in and to the Software and all copies thereof shall remain with Acer or
Acer's licensors or suppliers (as applicable). You do not have or shall not gain any proprietary interest in the Software (including
any modifications or copies made by or for you) or any related intellectual property rights. Title and related rights in the content
accessed through the Software is the property of the applicable content owner and may be protected by applicable law. This
license gives you no rights to such contents. You hereby agree
1. Not to remove any copyright or other proprietary notices from the Software;
2. To reproduce all such notices on any authorized copies you make; and
3. To use best efforts to prevent any unauthorized copying of the Software.
TRADEMARKS
This Agreement does not grant to you any rights in connection with any trademarks or service marks of Acer or of Acer's
licensors or suppliers.
DISCLAIMER OF WARRANTIES
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, ACER, ITS SUPPLIERS, AND ITS LICENSORS, PROVIDE THE
SOFTWARE "AS IS" AND WITH ALL FAULTS, AND HEREBY DISCLAIM ALL OTHER WARRANTIES AND CONDITIONS, EITHER
EXPRESS, IMPLIED OR STATUTORY, INCLUDING, BUT NOT LIMITED TO, ANY IMPLIED WARRANTIES, DUTIES OR
CONDITIONS OF MERCHANTABILITY, OF FITNESS FOR A PARTICULAR PURPOSE, OF ACCURACY OR COMPLETENESS OF
RESPONSES, OF RESULTS, OF WORKMANLIKE EFFORT, OF LACK OF VIRUSES, AND OF LACK OF NEGLIGENCE, ALL
WITH REGARD TO THE SOFTWARE AND THE PROVISION OF OR FAILURE TO PROVIDE SUPPORT SERVICES. ALSO,
THERE IS NO WARRANTY OR CONDITION OF TITLE, QUIET ENJOYMENT, QUIET POSSESSION, CORRESPONDENCE TO
DESCRIPTION OR NON-INFRINGEMENT WITH REGARD TO THE SOFTWARE.
EXCLUSION OF INCIDENTAL, CONSEQUENTIAL AND CERTAIN OTHER DAMAGES
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO EVENT SHALL ACER, ACER'S SUPPLIERS, OR
ACER'S LICENSORS, BE LIABLE FOR ANY SPECIAL, INCIDENTAL, INDIRECT, PUNITIVE, OR CONSEQUENTIAL DAMAGES
WHATSOEVER (INCLUDING, BUT NOT LIMITED TO, DAMAGES FOR LOSS OF PROFITS OR CONFIDENTIAL OR OTHER
INFORMATION, FOR BUSINESS INTERRUPTION, FOR PERSONAL INJURY, FOR LOSS OF PRIVACY, FOR FAILURE TO MEET
ANY DUTY INCLUDING OF GOOD FAITH OR OF REASONABLE CARE, FOR NEGLIGENCE, AND FOR ANY OTHER
PECUNIARY OR OTHER LOSS WHATSOEVER) ARISING OUT OF OR IN ANY WAY RELATED TO THE USE OF OR INABILITY
TO USE THE SOFTWARE, THE PROVISION OF OR FAILURE TO PROVIDE SUPPORT SERVICES, OR OTHERWISE UNDER OR
IN CONNECTION WITH ANY PROVISION OF THIS AGREEMENT, EVEN IN THE EVENT OF THE FAULT, TORT (INCLUDING
NEGLIGENCE), STRICT LIABILITY, BREACH OF CONTRACT OR BREACH OF WARRANTY OF ACER OR ITS SUPPLIERS OR
LICENSORS, AND EVEN IF ACER AND ITS SUPPLIERS AND LICENSORS HAVE BEEN ADVISED OF THE POSSIBILITY OF
SUCH DAMAGES.
LIMITATION OF LIABILITY AND REMEDIES
NOTWITHSTANDING ANY DAMAGES THAT YOU MIGHT INCUR FOR ANY REASON WHATSOEVER (INCLUDING, WITHOUT
LIMITATION, ALL DAMAGES REFERENCED ABOVE AND ALL DIRECT OR GENERAL DAMAGES), THE ENTIRE LIABILITY OF
ACER, ITS SUPPLIERS, AND ITS LICENSORS, UNDER ANY PROVISION OF THIS AGREEMENT, AND YOUR EXCLUSIVE
REMEDY FOR ALL OF THE FOREGOING, SHALL BE LIMITED TO THE AGGREGATE AMOUNT PAID BY YOU FOR THE
SOFTWARE. THE FOREGOING LIMITATIONS, EXCLUSIONS AND DISCLAIMERS (INCLUDING DISCLAIMER OF WARRANTIES
AND EXCLUSION OF INCIDENTAL, CONSEQUENTIAL AND CERTAIN OTHER DAMAGES ABOVE) SHALL APPLY TO THE
MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, EVEN IF ANY REMEDY FAILS ITS ESSENTIAL PURPOSE; PROVIDED,
HOWEVER, THAT BECAUSE SOME JURISDICTIONS DO NOT ALLOW THE EXCLUSION OR LIMITATION OR LIABILITY FOR
CONSEQUENTIAL OR INCIDENTAL DAMAGES, THE ABOVE LIMITATION MAY NOT APPLY TO YOU.
TERMINATION
Without prejudice to any other rights, Acer may immediately terminate this Agreement without notice if you fail to comply with
any terms and conditions of this Agreement.
In such event, you must:
1. Cease all use of the Software;
2. Destroy or return to Acer the original and all copies of the Software; and
3. Delete the Software from all phones on which it was resident.
All disclaimers of warranties and limitation of liability set forth in this Agreement shall survive termination of this Agreement.
GENERAL
This Agreement represents the complete agreement between you and Acer relating to this license for the Software and
supersedes all prior agreements, communications, proposals and representations between the parties and prevails over any
conflicting or additional terms of any quote, order, acknowledgement or similar communication. This Agreement may only be
modified by a written document signed by both parties. If any provision of this Agreement is held by a court of competent
jurisdiction to be contrary to law that provision will be enforced to the maximum extent permissible and the remaining provisions
of this Agreement will remain in full force and effect.
ADDITIONAL PROVISIONS APPLICABLE TO THIRD PARTY SOFTWARE AND SERVICES
Software provided hereunder by Acer's licensors or suppliers ("Third Party Software") is made available to you for your personal,
non-commercial use only. You may not use the Third Party Software in any manner that could damage, disable, overburden, or
impair the services provided by Acer's licensors or suppliers hereunder ("Third Party Services"). Furthermore, you may not use
the Third Party Software in any manner that could interfere with any other party's use and enjoyment of the Third Party Services,
or the services and products of Acer's licensors' or suppliers' third party licensors. Your use of the Third Party Software and
Third Party Services is also subject to additional terms and conditions and policies which can be accessed through our global
website.
Privacy policy
During registration you will be asked to submit some information to Acer. Please refer to Acer’s privacy policy at www.acer.com
or your local Acer website.
