Acer Incorporated Smart HandHeld Manual
Manual
(Model: Z130)
Quick guide
HC.HCS11.005
*HC.HCS11.005*
© 2013 All Rights Reserved
Acer Liquid Z3 Smartphone Quick Guide
Model : Z130
This revision: 8/2013
Acer Liquid Z3 Smartphone
Model number: __________________________________
Serial number: ___________________________________
Date of purchase: ________________________________
Place of purchase: ________________________________
Android is a trademark of Google Inc. Use of this trademark is subject to Google Permissions.
Product information
For detailed product information, please go to www.acer.com.
For service and support information, or to download the User Guide,
drivers and applications, please follow the instructions below:
1. Go to www.acer.com and click Support > DRIVER DOWNLOADS.
2. Select appropriate items from Select Product Family > Select
Product Line > Select Product Model.
3. Select the operating system from the pop-up list.
2
Quick Guide
Setting up for the first time
Inserting the SIM card, battery and microSD Card
Insert your fingernail into the cutout between the battery cover
and the phone. Unclip the cover and lift off the battery cover.
Insert the SIM and microSD Card as shown.
2
1
Note: Specifications vary depending on region and configuration.
Note: Ensure that the microSD Card is inserted all the way into the
card slot.
SIM card 1
microSD Card
SIM card 2 (optional)
3
Quick Guide
Place the battery into the battery compartment, lining up the
battery connectors with those at the bottom of the compartment.
Align the tabs on the bottom into the slots on the phone. Gently
press the cover until it snaps in place.
4
3
4
Quick Guide
Charging your phone
Prior to initial use, you will need to charge your smartphone for
eight hours. After that you can recharge the battery as needed.
Connect the AC adapter cord to the micro USB connector on
your smartphone. Plug the AC adapter into any AC outlet and
charge the device.
It is normal for the phone to heat up when charging or during
long periods of use.
All phones are factory tested before they are released.
Download and install the latest USB driver on your computer
before connecting your smartphone to the computer. Visit
www.acer.com/worldwide/support/download.htm for the
latest driver.
Resetting the phone
Open Settings from the Applications menu, then tap Backup &
reset. Tap Factory data reset and then tap Reset phone. Tap
Erase everything to format your phone.
1
Safety
Safety
Replacing the battery
Your smartphone uses a Lithium battery. Replace the battery with the same type as that
which came bundled with your product. Use of another battery may present a risk of fire or
explosion.
Warning! Batteries may explode if not handled properly. Do not disassemble or
dispose of them in re. Keep them away from children. Follow local regulations
when disposing of used batteries.
Disposal and recycling information
Do not throw this electronic device into the trash when discarding.
To minimize pollution and ensure utmost protection of the global
environment, please recycle. For more information on the Waste from Electrical
and Electronics Equipment (WEEE) regulations, visit
www.acer-group.com/public/Sustainability
EEE yönetmeligine uygundur.
It is compliant with EEE regulation.
Regulatory information
Compliant with Russian regulatory certification
RoHS compliance
This product is in compliance with Directive 2011/65/EU of the European
Parliament and of the Council of 8 June 2011, on the restriction of the use of certain
hazardous substances (RoHS) in electrical and electronic equipment and its amendments.
Prevention of hearing loss
2
Safety
FCC regulations
This mobile phone complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not cause
harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
This mobile phone has been tested and found to comply with the limits for
a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiated
radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a
particular installation If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
RF exposure warning
The equipment complies with FCC RF exposure limits set forth for an
uncontrolled environment.
The antenna(s) used for this transmitter must not be co-located or operating
in conjunction with any other antenna or transmitter.
3
Safety
RF exposure information (SAR)
This mobile phone meets the government's requirements for exposure to
radio waves. This phone is designed and manufactured not to exceed the
emission limits for exposure
to radio frequency (RF) energy set by the Federal Communications
Commission of the U.S. Government.
The exposure standard for wireless mobile phones employs a unit of
measurement known as the Specific Absorption Rate, or SAR. The SAR limit
set by the FCC is 1.6 W/kg.
Tests for SAR are conducted using standard operating positions accepted by
the FCC with the phone transmitting at its highest certified power level in all
tested frequency bands. Although the SAR is determined at the highest
certified power level, the actual SAR level of the phone while operating can
be well below the maximum value. This is because the phone is designed to
operate at multiple power levels so as to use only the poser required to reach
the network. In general, the closer you are to a wireless base station
antenna, the lower the power output.
The highest SAR value for US model phones as reported to the FCC when
tested for use at the ear is 1.43 W/kg and when worn on the body, as
described in this user guide, is 1.52 W/kg.
Important: Body-worn measurements differ among phone models, depending
upon available enhancements and FCC requirements.
While there may be differences between the SAR levels of various phones
and at various positions, they all meet the government requirements.
The FCC has granted an Equipment Authorization for this model phone with
all reported SAR levels evaluated as in compliance with the FCC RF exposure
guidelines. SAR information on this model phone is on file with the FCC and
can be found under the Display Grant section of www.fcc.gov/oet/ea/fccid
after searching on
FCC ID: HLZDMZ130 (for US models).
For body worn operation, this phone has been tested and meets the FCC RF
exposure guidelines for use with accessories that contain no metal and that
position the handset a minimum of 1 cm from the body. Use of other
accessories may not ensure compliance with FCC RF exposure guidelines. If
you do not use a body-worn accessory and are not holding the phone at the
ear, position the handset a minimum of 1 cm from your body when the
phone is switched on.
