Specifications
Specifications
Performance
• Qualcomm MSM 7230-1, 800 MHz
• System memory:
• 512 MB of RAM
• 512 MB of ROM
• Google Android operating system
Display
• 3.61” WVGA TFT-LCD, capacitive multi-touch
screen
• 800 x 480 resolution
• 65K colors support
Multimedia
• CD-quality stereo output
• Mono speaker
• Dual microphone
• Dolby Mobile
• Formats supported
USB connector
• Micro USB connector
• USB Client
• DC power-in (5 V, 1 A)
Connectivity
• Bluetooth 2.1+EDR & A2DP support
Type Formats
Audio playback MP3, AMR, WMA
Ringtone MP3, MIDI, iMelody, WAVE, WMA
Video recording 3GP, MPEG-4, H.263
Video playback 3GP, MPEG-4, H.263, H.264, WMA
2
• IEEE Wi-Fi 802.11b/g/n WLAN
• GSM 850 / 900 / 1800 / 1900
• UMTS 900 / 1900 / 2100 (EU models)
• UMTS 850 / 1900 / 2100 (US models)
• HSDPA / HSUPA / HSPA+ / EDGE / GPRS
•GPS / AGPS
Camera
• 5-megapixel
• Auto-focus
•Flash
Expansion
• microSD memory card (up to 32 GB)
Battery
• High density, rechargeable 1500 mAh Lithium-ion
battery (replaceable)
Note: Length of battery operation will depend on
power consumption which is based on system resource
use. For example, constantly using the backlight or
using power-demanding applications will shorten
battery life between charges.
Dimensions
Height 115 mm
Width 63 mm
Thickness 13.55 mm
Weight <135 g (with battery)
3
Battery information
This product uses a Lithium-ion battery. Do not use it in a
humid, wet and/or corrosive environment. Do not put,
store or leave your product in or near a heat source, in a
high temperature location, in strong direct sunlight, in a
microwave oven or in a pressurized container, and do not
expose it to temperatures over 60 °C (140 °F). Failure to
follow these guidelines may cause the battery to leak acid,
become hot, explode or ignite and cause injury and/or
damage. Do not pierce, open or disassemble the battery. If
the battery leaks and you come into contact with the
leaked fluids, rinse thoroughly with water and seek
medical attention immediately. For safety reasons, and to
prolong the lifetime of the battery, charging will not occur
at low (below 0 °C/32 °F) or high (over 40 °C/104 °F)
temperatures.
The full performance of a new battery is achieved only
after two or three complete charge and discharge cycles.
The battery can be charged and discharged hundreds of
times, but it will eventually wear out. When the talk and
standby times are noticeably shorter than normal, buy a
new battery. Use only Acer approved batteries, and
recharge your battery only with Acer approved chargers
designated for this device.
Unplug the charger from the electrical plug and the device
when not in use. Do not leave a fully charged battery
connected to the ac charger, since overcharging may
shorten its lifetime. If left unused, a fully charged battery
will lose its charge over time. If the battery is completely
discharged, it may take a few minutes before the charging
indicator appears on the display or before any calls can be
made.
Use the battery only for its intended purpose. Never use
any charger or battery that is damaged.
4
Do not short-circuit the battery. Accidental short-circuiting
can occur when a metallic object such as a coin, clip, or pen
causes direct connection of the positive (+) and negative
(-) terminals of the battery. (These look like metal strips on
the battery.) This might happen, for example, when you
carry a spare battery in your pocket or purse. Short-
circuiting the terminals may damage the battery or the
connecting object.
Leaving the battery in hot or cold places, such as in a
closed car in summer or winter conditions, will reduce the
capacity and lifetime of the battery. Always try to keep the
battery between 15 °C and 25 °C (59 °F and 77 °F). A device
with a hot or cold battery may not work temporarily, even
when the battery is fully charged. Battery performance is
particularly limited in temperatures well below freezing.
Do not dispose of batteries in a fire as they may explode.
Batteries may also explode if damaged. Dispose of
batteries according to local regulations. Please recycle
when possible. Do not dispose as household waste.
Replacing the battery pack
Your smartphone uses lithium batteries. Replace the
battery with the same type as that which came bundled
with your product. Use of another battery may present a
risk of fire or explosion.
Warning! Batteries may explode if not handled properly. Do
not disassemble or dispose of them in fire. Keep them away
from children. Follow local regulations when disposing of used
batteries.
5
Disposal and recycling information
Do not throw this electronic device into the trash
when discarding.
To minimize pollution and ensure utmost
protection of the global environment, please
recycle. For more information on the Waste from
Electrical and Electronics Equipment (WEEE) regulations,
visit www.acer-group.com/public/Sustainability/
sustainability01.htm
Regulatory information
Compliant with Russian regulatory certification
RoHS compliance
This product is in compliance with Directive 2002/95/EC of
the European Parliament and of the Council of 27 January
2003, on the restriction of the use of certain hazardous
substances in electrical and electronic equipment (RoHS) and
its amendments.
Prevention of hearing loss
Caution: Permanent hearing loss may occur if earphones or
headphones are used at high volume for prolonged periods of
time.
This device have been tested to comply with the Sound
Pressure Level requirement laid down in the applicable EN
50332-1 and/or EN 50332-2 standards.
Note: For France, mobile headphones or
earphones for this device have been tested to
comply with the Sound Pressure requirement
laid down in the applicable NF EN 50332-
6
1:2000 and/or NF EN 50332-2:2003 standards as required by
French Article L. 5232-1.
Wireless operation channels for different domains
France: Restricted wireless frequency bands
Some areas of France have a restricted frequency band.
The worst case maximum authorized power indoors is:
• 10 mW for the entire 2.4 GHz band (2400 MHz -
2483.5 MHz)
• 100 mW for frequencies between 2446.5 MHz
and 2483.5 MHz
Note: Channels 10 through 13 inclusive operate in the band
2446.6 MHz to 2483.5 MHz.
There are few possibilities for outdoor use: On private
property or on the private property of public persons, use
is subject to a preliminary authorization procedure by the
Ministry of Defense, with maximum authorized power of
100 mW in the 2446.5 - 2483.5 MHz band. Use outdoors on
public property is not permitted.
In the departments listed below, for the entire 2.4 GHz
band:
• Maximum authorized power indoors is 100 mW
• Maximum authorized power outdoors is 10 mW
N. America 2.412-2.462 GHz Ch01 through Ch11
Japan 2.412-2.484 GHz Ch01 through Ch14
Europe ETSI 2.412-2.472 GHz Ch01 through Ch13
7
Departments in which the use of the 2400 - 2483.5 MHz
band is permitted with an EIRP of less than 100 mW
indoors and less than 10 mW outdoors:
This requirement is likely to change over time, allowing
you to use your wireless LAN card in more areas within
France. Please check with ART for the latest information
(www.art-telecom.fr).
Note: Your WLAN Card transmitts less than 100 mW, but more
than 10 mW.
01 Ain Orientales
02 Aisne
03 Allier
05 Hautes Alpes
08 Ardennes
09 Ariege
11 Aude
12 Aveyron
16 Charente
24 Dordogne
25 Doubs
26 Drome
32 Gers
36 Indre
37 Indre et Loire
41 Loir et Cher
45 Loret
50 Manche
55 Meuse
58 Nievre
59 Nord
60 Oise
61 Orne
63 Puy Du Dome
64 Pyrenees
Atlantique
66 Pyrenees
67 Bas Rhin
68 Haut Rhin
70 Haute Saone
71 Saone et Loire
75 Paris
82 Tarn et
Garonne
84 Vaucluse
88 Vosges
89 Yonne
90 Territoire de
Belfort
94 Val de Marne
8
List of National Codes
This equipment may be operated in the following
countries:
FCC regulations
This mobile phone complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1)
This device may not cause harmful interference, and (2)
this device must accept any interference received,
including interference that may cause undesired
operation.
This mobile phone has been tested and found to comply
with the limits for a Class B digital device, pursuant to Part
15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses
and can radiated radio frequency energy and, if not
installed and used in accordance with the instructions, may
cause harmful interference to radio communications.
However, there is no guarantee that interference will not
occur in a particular installation If this equipment does
Country
Austria
Belgium
Cyprus
Czech Republic
Denmark
Estonia
Finland
France
Germany
Greece
Hungary
Ireland
Italy
Latvia
Lithuania
Luxembourg
ISO 3166
2 letter code
AT
BE
CY
CZ
DK
EE
FI
FR
DE
GR
HU
IE
IT
LV
LT
LU
Country
Malta
Netherlands
Poland
Portugal
Slovakia
Slovenia
Spain
Sweden
United Kingdom
Iceland
Liechtenstein
Norway
Switzerland
Bulgaria
Romania
Turkey
ISO 3166
2 letter code
MT
NT
PL
PT
SK
SL
ES
SE
GB
IS
LI
NO
CH
BG
RO
TR
9
cause harmful interference to radio or television reception,
which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment
and receiver.
• Connect the equipment into an outlet on a circuit
different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV
technician for help.
Changes or modifications not expressly approved by the
party responsible for compliance could void the user's
authority to operate the equipment.
RF exposure warning
The equipment complies with FCC RF exposure limits set
forth for an uncontrolled environment.
The antenna(s) used for this transmitter must not be co-
located or operating in conjunction with any other
antenna or transmitter
FCC_US model FCC_EU model CE NCC
Head
(W/kg)
Body
(W/kg)
Head
(W/kg)
Body
(W/kg)
Head
(W/kg)
Body
(W/kg)
Head
(W/kg)
0.768 1.33 0.95 0.665 0.678 1.72 0.678
FCC ID_US model HLZJMS120 FCC ID_EU model HLZJMS120EU
10
For body worn operation, this phone (US model) has been
tested and meets the FCC RF exposure guidelines for use
with accessories that contain no metal and that position
the handset a minimum of 1.5 cm from the body. Use of
other accessories may not ensure compliance with FCC RF
exposure guidelines. If you do not use a body-worn
accessory and are not holding the phone at the ear,
position the handset a minimum of 1.5 cm from your body
when the phone is switched on.
For Canadian users
Operation is subject to the following two conditions: (1)
this device may not cause interference, and (2) this device
must accept any interference, including interference that
may cause undesired operation of the device.
This Class B digital apparatus complies with Canadian ICES-
003.
This Category II radiocommunication device complies with
Industry Canada Standard RSS-310.
Important note
IC radiation exposure statement
This EUT is compliance with SAR for general population/
uncontrolled exposure limits in IC RSS-102 and had been
tested in accordance with the measurement methods and
procedures specified in IEEE 1528. This equipment should
be installed and operated with minimum distance 1.5 cm
between the radiator and your body.
This device and its antenna(s) must not be co-located or
operating in conjunction with any other antenna or
transmitter.
Note: The county code selection feature is disabled for products
marketed in the US/Canada.
11
NCC warning
警語
經型式認證合格之低功率射頻電機，非經許可，公司、商號或使用者均
不得擅自變更頻率、加大功率或變更原設計之特性及功能。
低功率射頻電機之使用不得影響飛航安全及干擾合法通信；經發現有干
擾現象時，應立即停用，並改善至無干擾時方得繼續使用。
前項合法通信，指依電信法規定作業之無線電通信。
低功率射頻電機須忍受合法通信或工業、科學及醫療用電波輻射性電機
設備之干擾，減少電磁波影響，請妥善使用。
SAR 標準值 2.0 W/kg；送測產品實測值為 0.678 W/kg。
12
Lithium-ion battery warning
ATTENZIONE! Rischio di esplosione della batteria se
sostituita in modo errato. Sostituire la batteria con
un una di tipo uguale o equivalente consigliata
dalla fabbrica. Non disperdere le batterie nell’ambi-
ente.
VORSICHT! Explosionsgefahr bei unsachgemäßen
Austausch der Batterie. Ersatz nur durch denselben
oder einem vom Hersteller empfohlenem ähnlichen
Typ. Entsorgung gebrauchter Batterien nach Ang-
aben des Herstellers.
ADVARSELI! Lithiumbatteri - Eksplosionsfare ved
fejlagtig håndtering. Udskiftning må kun ske med
batteri af samme fabrikat og type. Levér det brugte
batteri tilbage til leverandøren.
VARNING! Explosionsfara vid felaktigt batteribyte.
Använd samma batterityp eller en ekvivalent typ
som rekommenderas av apparattillverkaren. Kassera
använt batteri enligt fabrikantens instruktion.
VAROITUS! Paristo voi räjähtää, jos se on virheellis-
esti asennettu. Vaihda paristo ainoastaan laitevalm-
istajan sousittelemaan tyyppiin. Hävitä käytetty
paristo valmistagan ohjeiden mukaisesti.
ATTENTION ! Il y a danger d’explosion s’il y a rem-
placement incorrect de la batterie. Remplacer
uniquement avec une batterie du mêre type ou d’
un type équivalent recommandé par le constructeur.
Mettre au rebut les batteries usagées conformé-
ment aux instructions du fabricant.
ADVARSEL! Eksplosjonsfare ved feilaktig skifte av
batteri. Benytt samme batteritype eller en tils-
varende type anbefalt av apparatfabrikanten.
Brukte batterier kasseres i henhold til fabrikantens
instruksjoner.
13
14
Acer Incorporated
Date: September 16, 2010
Declaration of Conformity
We, Acer Incorporated,
of 8F., No. 88, Sec. 1, Hsin Tai Wu Rd. Hsichih Taipei Hsien 221, Taiwan
Declare under sole responsibility that the product:
Model: S120
Description: Smart HandHeld
To which this declaration relates, is in conformity with the following standards and/ or other
normative documents:
zEN 301 511 V9.0.2
zEN 300 328 V1.7.1
zEN 301 908-1/ -2 V3.2.1
zEN 300 440-1 V1.5.1/ EN300 440-2 V1.3.1
zEN 301 489-1 V1.8.1/ -3 V1.4.1/ -7 V1.3.1/ -17 V2.1.1/ -24 V.1.4.1
zEN 55022:2006/A1:2007 Class B; EN 55024:1998/A1:2001/A2:2003
zEN 55013:2001/A1:2003/A2:2006; EN 55020:2007
zEN 60950-1: 2006+A11:2009
zEN 50332-1:2000/ -2: 2003
zEN 50360:2001/ EN 62209-1:2006/ EN62311:2008/ OET65C
We hereby declare that the above named product is in conformance to all the essential requirements
of the R&TTE Directive (99/5/EC) issued by the Commission of the European Community.
The conformity assessment procedure referred to in Article 10 and detailed in Annex [IV] of
directive 1999/5/EC has been followed related to Articles
z R&TTE Article 3.1 (a) Health and Safety
z R&TTE Article 3.1 (b) EMC
z R&TTE Article 3.2 Spectrum Usage
with the involvement of the following Notified Body:
CETECOM, Untertuerkheimer Str. 6 – 10 66117 Saarbruecken
Identification mark: 0682 (Notified Body) CE
The technical documentation relevant to the above equipment will be held at:
Acer Incorporated
8F., No. 88, Sec. 1, Hsin Tai Wu Rd. Hsichih Taipei Hsien 221, Taiwan
Authorized Person:
_________________
Name: Harriot S.L. Lee
