Aspire 4553/4553G Series
Service Guide
PRINTED IN TAIWAN
Service guide files and updates are available
on the ACER/CSD web; for more information,
please refer to http://csd.acer.com.tw
II
Revision History
Please refer to the table below for the updates made on Aspire 4553/4553G service guides.
Date Chapter Updates
III
Copyright
Copyright © 2010 by Acer Incorporated. All rights reserved. No part of this publication may be reproduced,
transmitted, transcribed, stored in a retrieval system, or translated into any language or computer language, in
any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual or otherwise, without
the prior written permission of Acer Incorporated.
Disclaimer
The information in this guide is subject to change without notice.
Acer Incorporated makes no representations or warranties, either expressed or implied, with respect to the
contents hereof and specifically disclaims any warranties of merchantability or fitness for any particular
purpose. Any Acer Incorporated software described in this manual is sold or licensed "as is". Should the
programs prove defective following their purchase, the buyer (and not Acer Incorporated, its distributor, or its
dealer) assumes the entire cost of all necessary servicing, repair, and any incidental or consequential
damages resulting from any defect in the software.
Acer is a registered trademark of Acer Corporation.
Intel is a registered trademark of Intel Corporation.
Other brand and product names are trademarks and/or registered trademarks of their respective holders.
IV
Conventions
The following conventions are used in this manual:
NOTE: This symbol where placed in the Service Guide designates a component that should be recycled
according to the local regulations.
SCREEN MESSAGES Denotes actual messages that appear
on screen.
NOTE Gives bits and pieces of additional
information related to the current
topic.
WARNING Alerts you to any damage that might
result from doing or not doing specific
actions.
CAUTION Gives precautionary measures to
avoid possible hardware or software
problems.
IMPORTANT Reminds you to do specific actions
relevant to the accomplishment of
procedures.
V
Preface
Before using this information and the product it supports, please read the following general information.
1. This Service Guide provides you with all technical information relating to the BASIC CONFIGURATION
decided for Acer's "global" product offering. To better fit local market requirements and enhance product
competitiveness, your regional office MAY have decided to extend the functionality of a machine (e.g.
add-on card, modem, or extra memory capability). These LOCALIZED FEATURES will NOT be covered
in this generic service guide. In such cases, please contact your regional offices or the responsible
personnel/channel to provide you with further technical details.
2. Please note WHEN ORDERING FRU PARTS, that you should check the most up-to-date information
available on your regional web or channel. If, for whatever reason, a part number change is made, it will
not be noted in the printed Service Guide. For ACER-AUTHORIZED SERVICE PROVIDERS, your Acer
office may have a DIFFERENT part number code to those given in the FRU list of this printed Service
Guide. You MUST use the list provided by your regional Acer office to order FRU parts for repair and
service of customer machines.
VI
1
Table of Contents
System Specifications 1
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
System Block Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Your Acer Aspire Notebook tour . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Front View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Closed Front View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Left View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Right View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Bottom View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
TouchPad Basics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Using the Keyboard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Lock Keys and embedded numeric keypad . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Windows Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Hot Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Hardware Specifications and Configurations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
System Utilities 31
BIOS Setup Utility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
Navigating the BIOS Utility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
Aspire 4553/4553G BIOS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
Main . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33
Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34
Boot . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36
Exit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37
BIOS Flash Utilities . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38
DOS Flash Utility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39
WinFlash Utility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40
Remove HDD/BIOS Password Utilities . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .41
Machine Disassembly and Replacement 47
Disassembly Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .47
General Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .48
Pre-disassembly Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .48
Disassembly Process . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .48
External Module Disassembly Process . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .49
External Modules Disassembly Flowchart . . . . . . . . . . . . . . . . . . . . . . . . . . . . .49
Removing the Battery Pack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .50
Removing the SD dummy card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .51
Removing the Lower Cover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .52
Removing the Optical Drive Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .53
Removing the DIMM Modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .55
Removing the WLAN Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .56
Removing the Hard Disk Drive Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .58
Main Unit Disassembly Process . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .59
Main Unit Disassembly Flowchart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .59
Removing the Keyboard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .60
Removing the Upper Cover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .61
Removing the Power Switch Board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .64
Removing the Function Board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .65
Removing the USB Board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .67
Removing the Bluetooth Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .68
Removing the LCD Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .69
2
Table of Contents
Removing the Mainboard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .72
Removing the Thermal Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .73
Removing the PCH Thermal Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .75
Removing the CPU . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .75
Removing the RTC Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .76
LCD Module Disassembly Process . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .77
LCD Module Disassembly Flowchart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .77
Removing the LCD Bezel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .78
Removing the Camera Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .79
Removing the LCD Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .80
Removing the FPC Cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .81
Removing the Microphone Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .82
Removing the Antennas . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .83
Removing the Hinges . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .84
LCD Module Reassembly Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .85
Replacing the MIC and WiFi Antennas . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .85
Replacing the FPC Cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .86
Replacing the LCD Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .87
Replacing the Webcam . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .88
Replacing the LCD Bezel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .89
Main Module Reassembly Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .90
Replacing the RTC Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .90
Replacing the CPU . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .90
Replacing the Thermal Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .91
Replacing the PCH Thermal Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .92
Replacing the LCD Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .94
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .94
Replacing the Bluetooth Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .97
Replacing the USB Board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .98
Replacing the Function Board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .99
Replacing the Power Switch Board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .99
Replacing the Upper Cover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .100
Replacing the Keyboard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .103
Replacing the ODD Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .104
Replacing the Hard Disk Drive Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .104
Replacing the WLAN Board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .106
Replacing the DIMM Modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .106
Replacing the Lower Covers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .107
Replacing the Dummy Cards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .108
Replacing the Battery Pack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .108
Troubleshooting 109
Common Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .109
Power On Issue . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .110
No Display Issue . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .111
Random Loss of BIOS Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .112
LCD Failure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .113
Built-In Keyboard Failure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .113
TouchPad Failure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .114
Internal Speaker Failure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .114
HDD Not Operating Correctly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .116
ODD Failure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .117
Wireless Function Failure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .120
Thermal Unit Failure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .120
External Mouse Failure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .121
3
Table of Contents
Other Failures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .121
Intermittent Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .122
Undetermined Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .122
Post Codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .123
Jumper and Connector Locations 127
Top View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .127
Bottom View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .128
Clearing Password Check and BIOS Recovery . . . . . . . . . . . . . . . . . . . . . . . . . . . .129
Clearing Password Check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .129
Clear CMOS Jumper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .129
BIOS Recovery by Crisis Disk . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .130
FRU (Field Replaceable Unit) List 131
Aspire 4553/4553G Exploded Diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .132
LCD Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .132
FRU List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .135
Screw List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .147
Model Definition and Configuration 148
Aspire 4553/4553G . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .148
Test Compatible Components 173
Microsoft® Windows® 7 Environment Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .174
Online Support Information 183
Index 185
4
Table of Contents
Chapter 1 1
System Specifications
Features
Below is a brief summary of the computer’s many features:
NOTE: Items denoted with an (*) are only available for selected models.
Operating System
• Genuine Windows® 7 Home Premium 64-bit*
• Genuine Windows® 7 Home Basic 64-bit*
Platform
• AMD Phenom™ II quad-core mobile processor P920 (2 MB L2 cache, 1.60 GHz, 1066 MHz FSB,
25 W)
• AMD Phenom™ II triple-core mobile processor P820 (1.5 MB L2 cache, 1.80 GHz, 1066 MHz
FSB, 25 W)
• AMD Turion™ II dual-core mobile processor P520 (2 MB L2 cache, 2.30 GHz, 1066 MHz FSB, 25
W)
• AMD Athlon™ II dual-core processor P320 (1 MB L2 cache, 2.10 GHz, 1066 MHz FSB, 25 W)
• AMD M880G Chipset
System Memory
• Dual-channel DDR3 SDRAM support:
• Up to 4 GB of DDR3 1066 MHz memory, upgradeable to 8 GB using two soDIMM modules
Display
• 14" HD 1366 x 768 pixel resolution, high-brightness (200-nit) Acer CineCrystal™ LED-backlit TFT
LCD, supporting simultaneous multi-window viewing via Acer GridVista™
• Mercury free, environment friendly
• 16:9 aspect ratio
• Super-slim design
Graphics
• ATI Radeon™ HD 4250 Graphics with 384 MB of dedicated system memory, supporting Unified
Video Decoder 2 (UVD2), OpenGL® 2.0, OpenEXR High Dynamic-Range (HDR) technology,
Shader Model 4.0, Microsoft® DirectX® 10.1
• Dual independent display support
• 16.7 million colors
• External resolution / refresh rates:
• VGA port up to 2048x 1536: 85 Hz
Chapter 1
2Chapter 1
• HDMI™ port up to 1920 x 1080: 60 Hz
• MPEG-2/DVD decoding
• WMV9 (VC-1) and H.264 (AVC) decoding
• HDMI™ (High-Definition Multimedia Interface) with HDCP (High-bandwidth Digital Content
Protection) support
Audio
• Optimized Dolby Home Theater® v3 audio enhancement, featuring Dolby® Digital Live, Dolby® Pro
Logic® IIx, Dolby® Headphone, Dolby® Natural Bass, Dolby® Sound Space Expander, Dolby®
Audio Optimization, Dolby® High Frequency Enhancer technologies
• High-definition audio support
• S/PDIF (Sony/Philips Digital Interface) support for digital speakers
• MS-Sound compatible
• Built-in microphone
Storage
• 160/250/320/500/640 GB or larger hard disk drive
• Multi-in-1 card reader, supporting Secure Digital™ (SD) Card, MultiMediaCard™ (MMC), Memory
Stick™ (MS), Memory Stick PRO™ (MS PRO), xD-Picture Card™ (xD)
Optical Drive
• 4X Blu-ray Disc™ writer / DVD-Super Multi double-layer drive:
• Read: 24X CD-ROM, 24X CD-R, 24X CD-RW, 8X DVD-ROM, 8X DVD-R, 8X DVD+R, 6X
DVD-ROM DL, 6X DVD-R DL, 6X DVD+R DL, 8X DVD-RW, 8X DVD+RW, 5X DVD-RAM, 4X
BD-ROM, 4X BD-R, 4X BD-RE, 4X BD-ROM DL, 4X BD-R DL
• Write: 24X CD-R, 10X CD-RW, 8X DVD-R, 8X DVD+R, 6X DVD-RW, 6X DVD+RW, 5X DVD-
RAM, 4X DVD+R DL, 4X DVD-R DL, 4X BD-R, 2X BD-RE, 4X BD-R DL
• 4X Blu-ray Disc™ / DVD-Super Multi double-layer drive:
• Read: 24X CD-ROM, 24X CD-R, 16X CD-RW, 8X DVD-ROM, 8X DVD-R, 8X DVD+R, 4X
DVD-ROM DL, 4X DVD-R DL, 4X DVD+R DL, 4X DVD-RW, 4X DVD+RW, 5X DVD-RAM, 4X
BD-ROM, 4X BD-R, 4X BD-RE, 4X BD-ROM DL, 4X BD-R DL, 4X BD-RE DL
• Write: 16X CD-R, 10X CD-RW, 8X DVD-R, 8X DVD+R, 4X DVD-RW, 4X DVD+RW, 5X DVD-
RAM, 4X DVD+R DL, 4X DVD-R DL
• 8X DVD-Super Multi double-layer drive:
• Read: 24X CD-ROM, 24X CD-R, 24X CD-RW, 8X DVD-ROM, 8X DVD-R, 8X DVD+R, 6X
DVD-ROM DL, 4X DVD-R DL, 4X DVD+R DL, 6X DVD-RW, 6X DVD+RW, 5X DVD-RAM
• Write: 24X CD-R, 16X CD-RW, 8X DVD-R, 8X DVD+R, 4X DVD-R DL, 4X DVD+R DL, 6X
DVD-RW, 8X DVD+RW, 5X DVD-RAM
NOTE: Blu-ray Disc™ / DVD-Super Multi double-layer drive for discrete model only.
Chapter 1 3
Communication
• Acer Video Conference, featuring:
• Acer Crystal Eye webcam with 1280 x 1024 resolution
•WLAN:
• Acer InviLink™ Nplify™ 802.11 b/g/n Wi-Fi CERTIFIED™
• Acer InviLink™ 802.11 b/g Wi-Fi CERTIFIED™
• Supporting Acer SignalUp™ wireless technology
• WPAN: Bluetooth® 2.1+EDR
• WPAN: Bluetooth® 3.0+HS
• LAN: Gigabit Ethernet, Wake-on-LAN ready
Privacy control
• BIOS user, supervisor, HDD passwords
• Kensington lock slot
Dimensions and weight
•6 cell
• 342 (W) x 245 (D) x 25.55/29.87 (H) mm (13.46 x 9.64 x 1.01/1.18 inches) (not including
battery height)
• 342 (W) x 245 (D) x 25.55/31.24 (H) mm (13.46 x 9.64 x 1.01/1.23 inches) (includes battery,
not including foot rubber)
• 2.198 kg (4.84 lbs.) (UMA) with 6-cell battery pack
•9 cell
• 342 (W) x 245 (D) x 24/50.08 (H) mm
• 2.365 kg (5.20 lbs.) with 9-cell battery pack
Power adapter and battery
• ACPI 3.0 CPU power management standard: supports Standby and Hibernation power-saving
modes
• Acer PowerSmart 3-pin 65 W AC adapter
• 95 (W) x 50 (D) x 25.4 (H) mm (3.74 x 1.96 x 1 inches)
• 216 g (0.47 lbs) with 180 cm DC cable
• 48.8 W 4400 mAh 6-cell Li-ion standard battery pack
• Estimated battery life: up to 6 hours
• ENERGY STAR®
Special keys and controls
• 86-/87-/91-key keyboard with inverted "T" cursor layout
• Multi-gesture touchpad pointing device supporting scroll, pinch, rotate, flip
• 10 function keys, four cursor keys, two Windows® keys, hotkey controls, independent standard
numeric keypad, international language support
• Acer Programming key
4Chapter 1
• Easy-launch keys: Communication®
• Media control keys (printed on keyboard): play/pause, stop, previous, next
I/O interface
• Multi-in-1 card reader (SD™, MMC, MS, MS PRO, xD)
• Four USB 2.0 ports
• HDMI™ port with HDCP support
• External display (VGA) port
• Headphone/speaker jack with S/PDIF support
• Microphone-in jack
• Ethernet (RJ-45) port
• DC-in jack for AC adapter
Software
• Productivity
• Acer Backup Manager
• Acer PowerSmart Manager
• Acer eRecovery Management
• Adobe® Flash® Player 10
• Adobe® Reader® 9.1
•eSobi
™
• Google™ Setup
• Google Toolbar™
•Microsoft
® Office Personal 2007 (Service Pack 2) (Japan only, subject to customer request)
•Microsoft
® Office Trial (Service Pack 2)
•Microsoft
® Works SE 9
•Microsoft
® Works 9
•Microsoft
® Works 8.5
•Norton
™ Online Backup
• Security
• McAfee® Internet Security Suite 2009 Trial
• McAfee® Virus Definitions
• MyWinLocker
• Multimedia·
• Acer Arcade™ Deluxe·
• NTI Media Maker™
• Gaming·
• Oberon GameZone (except US, Canada, Hong Kong, Korea)
• WildTangent®1 (US, Canada only)
• Communication and ISP·
Chapter 1 5
• Acer Crystal Eye
• Acer Video Conference Manager
•Microsoft
® Silverlight™
• Skype™
• Windows Live™ Essentials — Wave 3.2 (Mail, Photo Gallery, Live™ Messenger, Movie Maker,
Writer)
• Web links and utilities
• Acer Accessory Store (Belgium, France, Germany, Italy, Netherlands, Spain, Sweden, UK only)
• Acer Assist
• Acer Identity Card
• Acer Registration
• Acer Updater
•eBay
® shortcut 2009 (Canada, France, Germany, Italy, Mexico, Spain, UK, US only)
• Netflix shortcut (US only)
Optional Items
• 1 GB / 2 GB DDR3 1066 MHz soDIMM module
• 6-cell Li-ion battery pack
• 3-pin 65 W AC adapter
• External USB floppy drive
• External USB optical disc drive
Warranty
• One-year International Travellers Warranty (ITW)
Environment
• Temperature:
• Operating: 41 °F to 95 °F (5 °C to 35 °C)
• Non-operating: -4 °F to -149 °F (20 °C to 65 °C)
• Humidity (non-condensing):
• Operating: 20% to 80%
• Non-operating: 20% to 80%
6Chapter 1
System Block Diagram
Keyboard
LAN
Atheros
PCIE-LAN
AR8151
RJ45
SATA0 150MB
CRT
HT3
ALINK X4
X1
(10/100/1000)
Speaker
SATA - CD-ROM
USB2.0
Winbond KBC
LPC
35mm X 35mm
A12
638P (PGA)45W/35W
64MX16X8,128 bit
64MX16X4,64 bit
VRAM
Azalia
SBLINK_CLK
NBGPP_CLK
NBGFX_CLK
CPU_CLK
HDMI
ATI
Park XT
128-bit M2 Pkg
S1G4 Processor
AMD Champlain
21mm X 21mm, 528pin BGA
BT
800MHz
DDR3
USB1.1
X1
CLOCK GEN
CPU THERMAL
SENSOR
SB820
RS880
NORTH BRIDGE
HDMI
DDR3-SODIMM1
DDR3-SODIMM2
USB2.0 Ports
LVDS
9
CPU FAN SPI
4.3W(Int)
4.5W(Ext)
29mm X 29mm
DDR3 channel B
DDR3 channel A
Touch Pad
Codec
RTL ALC271X
Mini PCI-E
Card
(Wireless LAN)
PCI-Express 8X
21mm X 21mm, 528pin BGA
(Phone/ MIC)
Digital MIC AUDIO CONN
X2
0
PCI-E
SOUTH BRIDGE
SATA1 150MB
SATA - HDD1
LVDS
CRT
NPCE781L
Webcam
8
USB2.0 Ports x3
10,11,12
CardReader
AU6437
5
USB BOARD
From SB
VGA Park
WLAN conn
4
Power BOARD
Switch BOARD
A11
DDR3 RAM
Side port
Chapter 1 7
Your Acer Aspire Notebook tour
Front View
No. Icon Item Description
1 Acer Crystal Eye
webcam Web camera for video communication
(for selected models).
2 Microphone Internal microphone for recording sound.
3 Display screen Also called Liquid-Crystal Display (LCD),
displays computer output.
1
2
3
4
5
6
7
8
10
11
12
13
9
8Chapter 1
4 HDD Indicates when the hard disk drive is active.
Num Lock
indicator
Lights up when Num Lock is activated.
Caps Lock
indicator
Lights up when Caps Lock is activated.
5 Power button Turns the computer on and off.
6 Keyboard For entering data into your computer.
7 TouchPad Touch-sensitive pointing device which functions
like a computer mouse.
8 Power Indicator Indicates the computer’s power status.
Battery Indicator Indicates the computer’s battery status.
1. Charging: The light shows amber when the
battery is charging.
2. Fully charged: The light shows blue when in
AC mode.
Communication
Indicator Indicates the computer's communication
device status.
(Function may vary by configuration.)
9 Click buttons (left
and right)
The left and right buttons function like the
left and right mouse buttons.
10 Palmrest Comfortable support area for your hands
when you use the computer.
11 Speakers Left and right speakers deliver stereo audio
output.
12 Optical drive
eject
button
Ejects the optical disk from the drive.
13 Programmable
key
User-programmable.
(only for certain models)
PowerSmart key Puts your computer into power-saving mode.
(only for certain models)
No. Icon Item Description
Chapter 1 9
Closed Front View
Left View
No. Icon Item Description
1Multi-in-1
card reader
Accepts Secure Digital (SD),
MultiMediaCard (MMC), Memory Stick
(MS), Memory Stick PRO (MS PRO),
xD-Picture Card (xD).
Note: Push to remove/install the card. Only
one card can operate at any given time.
No. Icon Item Description
1 Kensington lock
slot
Connects to a Kensington-compatible
computer security lock.
2 Ventilation slots Enable the computer to stay cool, even after
prolonged use.
3 External display
(VGA) port Connects to a display device
(e.g. external monitor, LCD projector).
4 HDMI Connect to HDMI devices
5 Ethernet (RJ-45)
port Connects to an Ethernet 10/100/1000-based
network.
6 USB 2.0 ports Connect to USB 2.0 devices (e.g. USB mouse,
USB camera).
7 Microphone-in
jack Accepts input from external microphones.
Headphones/
speaker/line-out
jack
Connects to audio line-out devices
(e.g. speakers, headphones).
1
2134567
10 Chapter 1
Right View
Bottom View
No. Icon Item Description
1 USB 2.0 ports Connect to USB 2.0 devices (e.g. USB mouse, USB
camera).
2 Optical drive Internal optical drive; accepts CDs or DVDs.
3 Optical disk access
indicator Lights up when the optical drive is active.
4 Emergency eject hole Ejects the optical drive tray when the computer is turned
off.
Note: Insert a paper clip into the emergency eject hole to
eject the optical drive tray when the computer is off.
5 DC-in jack Connects to an AC adapter.
No. Icon Item Description
1 Battery bay Houses the computer's battery pack.
2 Battery lock Locks the battery in position.
21345
1
2
34
5
6
Chapter 1 11
Indicators
The computer has several easy-to-read status indicators. The front panel indicators are visible even when the
computer cover is closed.
3 Hard disk bay Houses the computer's hard disk (secured
with screws).
4 Memory
compartment Houses the computer's main memory.
5 Ventilation slots
and cooling fan Enable the computer to stay cool, even after
prolonged use.
Note: Do not cover or obstruct the fan opening.
6 Batter release latch Releases the battery for removal.
Icon Function Description
Power Indicates the computer's power status.
Battery Indicates the computer's battery status.
NOTE: 1. Charging: The light shows amber when
the battery is charging. 2. Fully charged: The light
shows green when in AC mode.
HDD Indicates when the hard disk drive is active.
Communication indicator Indicates the computer’s wireless connectivity
device status.
No. Icon Item Description
12 Chapter 1
TouchPad Basics
The following items show you how to use the TouchPad:
• Move your finger across the TouchPad (1) to move the cursor.
• Press the left (2) and right (3) buttons located beneath the TouchPad to perform selection and
execution functions. These two buttons are similar to the left and right buttons on a mouse.
Tapping on the TouchPad is the same as clicking the left button.
NOTE: When using the TouchPad, keep it - and your fingers - dry and clean. The TouchPad is sensitive to
finger movement; hence, the lighter the touch, the better the response. Tapping too hard will not
increase the TouchPad’s responsiveness.
Function Left Button (2) Right Button (3) Main TouchPad (1)
Execute Quickly click twice. Tap twice (at the same speed
as double-clicking a mouse
button).
Select Click once. Tap once.
Drag Click and hold, then use
finger on the TouchPad to
drag the cursor.
Tap twice (at the same speed
as double-clicking a mouse
button); rest your finger on
the TouchPad on the second
tap and drag the cursor.
Access
context menu Click once.
Chapter 1 13
Using the Keyboard
The keyboard has full-sized keys and an embedded numeric keypad, separate cursor, lock, Windows, function
and special keys.
Lock Keys and embedded numeric keypad
The keyboard has two lock keys which you can toggle on and off.
The embedded numeric keypad functions like a desktop numeric keypad. It is indicated by small characters
located on the upper right corner of the keycaps. To simplify the keyboard legend, cursor-control key symbols
are not printed on the keys.
Lock key Description
Caps Lock When Caps Lock is on, all alphabetic characters typed are in uppercase.
Num Lock When Num Lock is on, the embedded keypad is in numeric mode.
Scroll Lock <Fn> +
<F12> When Scroll Lock is on, the screen moves one line up or down when you press
the up or down arrow keys respectively. Scroll Lock does not work with some
applications.
Desired access Num Lock on Num Lock off
Number keys on
embedded keypad Type numbers in a normal manner.
Cursor-control keys on
embedded keypad Hold <Shift> while using cursor-
control keys. Hold <Fn> while using cursor-
control keys.
Main keyboard keys Hold <Fn> while typing letters on
embedded keypad. Type the letters in a normal
manner.
14 Chapter 1
Windows Keys
The keyboard has two keys that perform Windows-specific functions.
Key Description
Windows key Pressed alone, this key has the same effect as clicking on the Windows Start button;
it launches the Start menu. It can also be used with other keys to provide a variety of
functions:
<>: Open or close the Start menu
<> + <D>: Display the desktop
<> + <E>: Open Windows Explore
<> + <F>: Search for a file or folder
<> + <G>: Cycle through Sidebar gadgets
<> + <L>: Lock your computer (if you are connected to a network domain), or
switch users (if you're not connected to a network domain)
<> + <M>: Minimizes all windows
<> + <R>: Open the Run dialog box
<> + <T>: Cycle through programs on the taskbar
<> + <U>: Open Ease of Access Center
<> + <X>: Open Windows Mobility Center
<> + <BREAK>: Display the System Properties dialog box
<> + <SHIFT+M>: Restore minimized windows to the desktop
<> + <TAB>: Cycle through programs on the taskbar
<> + <SPACEBAR>: Bring all gadgets to the front and select Windows Sidebar
<CTRL> + <> + <F>: Search for computers (if you are on a network)
<CTRL> + <> + <TAB>: Use the arrow keys to cycle through programs on the
taskbar
Note: Depending on your edition of Windows, some shortcuts may not function as
described.
Chapter 1 15
Hot Keys
The computer employs hotkeys or key combinations to access most of the computer’s controls like screen
brightness, volume output and the BIOS utility.
To activate hot keys, press and hold the <Fn> key before pressing the other key in the hotkey combination.
Hotkey Icon Function Description
<Fn> + <F3> Communication key Enables / disables the computer's
communication devices. (Communication
devices may vary by configuration.)
<Fn> + <F4> Sleep Puts the computer in Sleep mode.
<Fn> + <F5> Display toggle Switches display output between the display
screen, external monitor (if connected) and
both.
<Fn> + <F6> Display Off Turns the display screen backlight off to save
power. Press any key to return.
<Fn> + <F7> Touchpad toggle Turns the internal touchpad on and off.
<Fn> + <F8> Speaker toggle Turns the speakers on and off.
<Fn> + <F11> NumLk Turns the embedded numeric
keypad on or off.
<Fn> + < > Brightness up Increases the screen brightness.
<Fn> + < > Brightness down Decreases the screen brightness.
<Fn> + < > Volume up Increases the sound volume.
<Fn> + < > Volume down Decreases the sound volume.
<Fn> + <Home> Play/Pause Play or pause a selected media file.
<Fn> + <Pg Up> Stop Stop playing the selected media file.
<Fn> + <Pg Dn> Previous Return to the previous media file.
<Fn> + <End> Next Jump to the next media file.
<Fn> + < >
<Fn> + < >
<Fn> + < >
<Fn> + < >
16 Chapter 1
Hardware Specifications and Configurations
SKU Comparison
Part
C1 (UMA)
ZQ2(AMD2.3,CMO14,
1G*1+2G*1,TOS250G)
C2 (DIS)
ZQ2A(AMD2.5,LP14,S
AM2G*2,SGA320G)
C3 (DIS)
ZQ2A(AMD2.0,AU14,2
G*1+4G*1,WDC500G)
AMD CPU CPU AMD AthlonII
N330 2.3G 1M 35W
Dual-Core
CPU AMD TurionII
N530 2.5G 2M 35W
Dual-Core
CPU AMD PhenomII
N930 2.0G 2M 35W
Quad-Core
North Bridge Chip
Set AMD RS880M w/
HDCP EEPROM AMD RS880M w/
HDCP EEPROM AMD RS880M w/
HDCP EEPROM
LCD 14" Panel (Buy
and Sell) LED LCD CMO 14"
WXGA Glare N140B6-
L24 LF 200nit 8ms
650:1 (Power saving)
LED LCD LPL 14"
WXGA Glare
LP140WH2-TLL1 LF
200nit 16ms 500:1
(Power saving)
LED LCD AUO 14"
WXGA Glare
B140XW03 V0 LF
200nit 8ms 500:1
(Power saving)
System Memory Memory HYNIX SO-
DIMM DDRIII 1066
1GB
HMT112S6BFR6C-G7
N0 LF 64*16 0.055um
Memory HYNIX SO-
DIMM DDRIII 1066
2GB
HMT125S6BFR8C-G7
N0 LF 128*8 0.055um
Memory SAMSUNG
SO-DIMM DDRIII 1066
2GB M471B5673EH1-
CF8 LF 128*8 0.055um
Memory ELPIDA SO-
DIMM DDRIII 1333
2GB EBJ21UE8BDS0-
DJ-F LF 128*8
0.065um Memory
ELPIDA SO-DIMM
DDRIII 1333 4GB
EBJ41UF8BAS0-DJ-F
LF 256*8 0.055um
Hard Drive 9.5mm
only - SATA (Buy
and Sell)
HDD TOSHIBA 2.5"
5400rpm 250GB
MK2565GSX,
Capricorn BS, 320G/P
SATA 8MB LF F/
W:GJ002J
HDD SEAGATE 2.5"
5400rpm 320GB
ST9320325AS Wyatt
SATA LF F/
W:0001SDM1
HDD WD 2.5" 5400rpm
500GB WD5000BEVT-
22A0RT0,
ML320M,WD SATA
8MB LF F/W:01.01A01
Super-Multi (5.25"/
12.7mm-H) SATA ODD HLDS Super-
Multi DRIVE 12.7mm
Tray DL 8X GT30N LF
W/O bezel SATA (HF +
Windows 7)
ODD PLDS Super-Multi
DRIVE 12.7mm Tray
DL 8X DS-8A4SH LF
W/O bezel SATA (HF +
Windows 7)
#N/A
BD COMBO (5.25"/
12.7mm-H) SATA #N/A ODD PLDS BD
COMBO 12.7mm Tray
DL 4X DS-4E1S LF W/
O bezel SATA
(Windows 7)
Battery (Buy and
Sell) Battery SANYO AS10B
Li-Ion 3S2P SANYO 6
cell 4400mAh Main
COMMON ID:AS10B31
Battery SAMSUNG
AS10B Li-Ion 3S2P
SAMSUNG 6 cell
4400mAh Main
COMMON ID:AS10B61
Battery SIMPLO
AS10B Li-Ion 3S2P
LGC 6 cell 4400mAh
Main COMMON
ID:AS10B73
AC Adapter Adapter LITE-ON 65W
19V 1.7x5.5x11 Yellow
PA-1650-22AC LV5
LED LF
Adapter LITE-ON 90W
19V 1.7x5.5x11 Blue
PA-1900-34AR, LV5
LED LF
Adapter HIPRO 90W
19V 1.7x5.5x11 Blue
HP-A0904A3 B1LF,
LV5 LED LF
VRAM #N/A VRAM HYNIX Graphic
DDRIII 800 1Gb
H5TQ1G63BFR-12C
LF
VRAM SAMSUNG
Graphic DDRIII 800
1Gb K4W1G1646E-
HC12 LF
Chapter 1 17
NOTE: Parts that are the same across all skews have been removed from this table.
Chipset
Processor Specifications
CPU Fan True Value Table (Performance Mode)
• Throttling 50%: On = 95C; Off = 90C
• OS Shutdown: 98°C
• H/W Shutdown: 95°C
VGA chip #N/A AMD PARK_XT 40nm 29mm*29mm M2 package
Wireless Lan Mini
Card Foxconn Wirelss LAN
Atheros HB95BG (HM)
T77H121.10
Foxconn Wireless LAN
Atheros HB93 2x2
BGN (HM)
Foxconn Wireless LAN
Atheros HB97 2x2
BGN (HM)
Blue Tooth #N/A Foxconn Bluetooth
ATH AR3011 Foxconn Bluetooth
BRM 2046 BT2.1
(T60H928.33) f/w:861
Camera Suyin 1.3M SY9665SN Liteon 1.3M LT9665AL
(09P2SF119) Liteon 1.3M LT9665AL
(09P2SF119)
Item Specification
CPU AMD Champlain
Graphics ATI Park XT
CPU Package 638P (PGA) 35x35mm
Power
On-die Cache
Northbridge RS880MC 21x21mm, 528pin BGA
Southbridge SB820M 21x21mm, 528pin BGA
Graphics (SG models
only) ATI Park XT 29x29mm
Item CPU
Speed Cores Bus
Speed Cache
Size Package Core
Voltage Acer P/N
P320 2.1G 2 3.6 GT/s 1MB RS880 25W KC.AP002.320
N330 2.3G 2 3.6 GT/s 1MB RS880 35W KC.AN002.330
N830 2.1G 3 3.6 GT/s 1.5MB RS880 35W KC.PN002.830
N930 2.0G 4 3.6 GT/s 2MB RS880 35W KC.PN002.930
N530 2.5G 2 3.6 GT/s 2MB RS880 35W KC.TN002.530
P520 2.3G 2 3.6 GT/s 2MB RS880 25W KC.TP002.520
Fan On (°C) Fan Off (°C) RPM
42 38 2600
50 45 3200
58 52 3600
65 60 3900
78 73 4200
94 89 95% Duty
Part
C1 (UMA)
ZQ2(AMD2.3,CMO14,
1G*1+2G*1,TOS250G)
C2 (DIS)
ZQ2A(AMD2.5,LP14,S
AM2G*2,SGA320G)
C3 (DIS)
ZQ2A(AMD2.0,AU14,2
G*1+4G*1,WDC500G)
18 Chapter 1
CPU Fan True Value Table (Power Saving Mode)
• Throttling 50%: On = 95C; Off = 90C
• OS Shutdown: 98°C
• H/W Shutdown: 95°C
BIOS
System Memory
Fan On (°C) Fan Off (°C) RPM
43 38 2600
55 50 3200
65 60 3600
72 69 3900
81 76 4200
94 89 95% Duty
Item Specification
BIOS vendor Phoenix
BIOS Version 1.xx
BIOS ROM type 1M SPI ROM
Features • Flash ROM 1MB
• Support ISIPP
• Support Acer UI
• Support multi-boot
• Suspend to RAM (S3)/Disk (S4)
• Various hot-keys for system control
• DMI utility for BIOS serial number configurable/asset tag
• Support PXE
• Support Y2K solution
• Support WinFlash
• Wake on LAN from S3
• Wake on LAN from S4 in AC mode
Item Specification
Memory size 8GB maximum
DIMM socket number 2
Supports memory size per socket 4GB
Supports DIMM type 204-pin +1.5V DDRIII
Supports DIMM Speed 400/533/667 MHz
Supports DIMM voltage 1.5V
Chapter 1 19
Memory Combinations
NOTE: Above table lists some system memory configurations. You may combine DIMMs with various
capacities to form other combinations. On above table, the configuration of slot 1 and slot 2 could be
reversed.
System Board Major Chips
I/O Ports
Slot 1 Slot 2 Total Memory
0MB 1024MB 1024MB
0MB 2048MB 2048MB
0MB 4096MB 4096MB
1024MB 0MB 1024MB
1024MB 512MB 1536MB
1024MB 1024MB 2048MB
1024MB 2048MB 3072MB
2048MB 0MB 2048MB
2048MB 512MB 2560MB
2048MB 1024MB 3072MB
2048MB 2048MB 4096MB
2048MB 4096MB 6144MB
4096MB 4096MB 8192MB
Item Specification
Northbridge RS880
Southbridge SB820
VGA ATI Park XT
LAN AR8151
USB USB 2.0
Super I/O controller NPCE781
Bluetooth T60H928.33
Wireless Atheros HB93, HB97, HB95BG (HM), Broadcomm 43225
PCMCIA N/A
Audio codec Realtek ALC271X
Card reader AU6437
Item Specification
I/O support • 4-in-1 card reader (SD, MMC, MS, xD)
• Four USB 2.0 ports
• HDMI™ port
• External display (VGA) port
• Headphone/speaker/line-out jack
• Microphone-in jack
• Ethernet (RJ-45) port
• DC-in jack for AC adapter
20 Chapter 1
Wireless Module
LAN Module
Bluetooth
Hard Disk Drive Interface
Item Specification
Manufacturer • Atheros HB93, Broadcomm 43225, Atheros HB97,
Atheros HB95BG
Specifications • IEEE 802.11b/g and Draft-N1 compliant
• Advanced security via 802.11i
• Industry-leading power consumption
• Includes Wi-Fi PAN – Intel® My WiFi Technology
• Easy to use Intel® PROSet v12.5 WLAN Software
• Advanced IT capabilities with Intel® PROSet
Software4
• Support for Cisco Compatible Extensions* v4
• Connect with Intel® Centrino® program eligible
Item Specification
Chipset • Atheros AR8151 GbE LAN Controller with Integrated
Transceiver
Specifications • Integrated PHY for 10/100/1000 Mbps
• Supports automatic MDI/MDIX functions
• PCI Express base 1.1 compliant
• Wake on LAN support
• 256 byte memory (using eFuse) embedded on chip
• Supports up to 25% over-clocking without requiring
BIOS support
• Supports Energy Star 5.0
•Small footprint 40-pin QFN (5 x 5 mm) package
with dramatically improved thermal and electrical
characteristics over LQFP packaging
Item Specification
Chipset T60H928.33 miniUSB module
Data throughput
Protocol 2.1
Interface USB 2.0
Connector type 8 pin narrow pitch connector
Item Specification
Capacity (MB)
160
Vendor &
Model Name Seagate HGST Toshiba WD Samsung
Bytes per
sector 512
Data heads 2 1
Drive Format
Disks 1 1
Chapter 1 21
Hard Disk Drive Interface (continued)
Spindle speed
(RPM) 5400
Performance Specifications
Buffer size 8 MB
Interface SATA
Max. Media
Transfer Rate
(Mbytes/sec
max.)
300 384 384 384
Max. Data
Transfer Rate
(Mbytes/sec)
150400 108160 108544
DC Power Requirements
Voltage
tolerance 5V ±5%
Item Specification
Capacity (MB)
250
Vendor &
Model Name Seagate HGST Toshiba WD Samsung
Bytes per
sector 512
Data heads 2 3 2
Drive Format
Disks 1 2 1
Spindle speed
(RPM) 5400
Performance Specifications
Buffer size 8 MB
Interface SATA
Max. Media
Transfer Rate
(Mbytes/sec
max.)
300 384 384 384
Max. Data
Transfer Rate
(Mbytes/sec)
150400 112000 108544
DC Power Requirements
Voltage
tolerance 5V ±5%
Item Specification
22 Chapter 1
Hard Disk Drive Interface (continued)
Hard Disk Drive Interface (continued)
Item Specification
Capacity (MB)
320
Vendor & Model
Name Seagate HGST Toshiba WD
Bytes per sector 512
Data heads 3 3 2 2
Drive Format
Disks 2 2 1
Spindle speed
(RPM) 5400
Performance Specifications
Buffer size 8 MB
Interface SATA
Max. Media
Transfer Rate
(Mbytes/sec
max.)
300 384 384 384
Max. Data
Transfer Rate
(Mbytes/sec)
150400 112000 108544
DC Power Requirements
Voltage
tolerance 5V ±5%
Item Specification
Capacity (MB)
500
Vendor & Model
Name Seagate HGST Toshiba WD
Bytes per sector 512
Data heads 2 3 2
Drive Format
Disks 1 2 1
Spindle speed
(RPM) 5400
Performance Specifications
Buffer size 8 MB
Interface SATA
Max. Media
Transfer Rate
(Mbytes/sec
max.)
300 384 384 384
Max. Data
Transfer Rate
(Mbytes/sec)
150400 112000 108544
DC Power Requirements
Voltage
tolerance 5V ±5%
Chapter 1 23
Hard Disk Drive Interface (continued)
Item Specification
Capacity (MB)
640
Vendor & Model Name Western Digital
Bytes per sector 512
Data heads 4
Drive Format
Disks 2
Spindle speed (RPM) 5400
Performance Specifications
Buffer size 8 MB
Interface SATA
Max. Media Transfer Rate
(Mbytes/sec max.) 384
Max. Data Transfer Rate
(buffer to/from media)
(Mbytes/sec)
108544
DC Power Requirements
Voltage tolerance 5V ±5%
24 Chapter 1
Super-Multi Drive Module
Item Specification
Vendor & model name HLDS GT20N Sony AD7580S
Performance
Specification With CD Diskette With DVD Diskette With CD Diskette With DVD Diskette
Transfer rate
(MB/sec) Sustained:
3,600 KB/s (24x)
max.
Sustained:
11.08 Mbytes/s
(8x) max.
Sustained:
1,571 (typical)
Sustained:
10,993 (typical)
Buffer Memory 2 MB
Interface SATA
Applicable disc
formats DVD-ROM:
4.7GB (Single Layer)
8.5GB (Dual Layer)
DVD-R:
3.95GB (Ver. 1.0: read only)
4.7GB (Ver. 2.0 for Authoring: read only)
4.7GB (Ver. 2.1 for General: read & write)
(DL) 8.5GB (Ver. 3.0)
DVD-RW:
4.7GB (Ver. 1.2/ Rev 1.0, 2.0, 3.0)
DVD-RAM: 1.46GB/side, 4.7GB/side
(Ver. 2.2)
DVD+R: 4.7GB (Ver. 1.3)
(DL) 8.5GB (Ver. 1.1)
DVD+RW:
4.7GB (Vol.1 Ver.1.3)
CD-ROM Mode-1 data disc
CD-ROM Mode-2 data disc
CD-ROM XA, CD-I, Photo-CD Multi-
Session, Video CD
CD-Audio Disc
Mixed mode CD-ROM disc (data and
audio)
CD-Extra
CD-Text
CD-R (Conforming to “Orange Book Part
2”: read & write)
CD-RW (Conforming to “Orange Book
Part 3”: read & write)
DVD Read:
DVD-ROM (DVD-5, DVD-9, DVD-10, DVD-
18), DVD-Video, DVD-Audio, SACD (Hybrid),
UDF DVD, DVD-R, DVD-R DL, DVD-R 3.95
GB, DVD-R Authoring, DVD-R Multi-Border,
DVD-RW, DVD+R, DVD+R DL, DVD+R
Multi-Session, DVD+RW, DVD-RAM V1.0,
DVDRAM
V2.0 & 2.1 &2.2.
CD Read:
CD-DA, CD-ROM Mode-1, CD-ROM/XA
Mode-2 Form-1 and Mode-2 Form-2, CD-i,
CD-i
Bridge, Video-CD (MPEG-1), Karaoke CD,
Photo-CD, Enhanced CD, CD Plus, CD
Extra, itrax
CD, CD-Text, UDF CD, CD-R, and CD-RW
DVD Write:
DVD Data & Video
CD Read:
CD-DA, CD-ROM Mode-1, CD-ROM/XA
Mode-2 Form-1 and Mode-2 Form-2, CD-i,
Video-
CD, CD-Text
Loading mechanism Drawer (Solenoid Open)
Tact SW (Open)
Emergency Release (draw open hole)
Power Requirement
Input Voltage DC 5 V +/- 5%
Chapter 1 25
Audio Interface
Keyboard Controller
Battery
RTC Battery
Item Specification
Codec Controller Realtek ALC271X high definition audio codec with embedded class-D speaker
amplifier
Audio onboard or
optional • Onboard
Mono or Stereo • Stereo
Resolution • 98dB Signal-to-Noise Ratio (A-weighting) for DAC output
• 90dB Signal-to-Noise Ratio (A-weighting) for ADC input Internal Digital
Compatibility • Headphone-out
• S/PDIF, Line-In and Microphone-In.
• 2 stereo ADCs support 16/20/24-bit PCM format recording simultaneously.
Sampling Rate • All DACs supports 16/20/24-bit, 44.1k/48k/96k/192kHz sample rate.
• Two independent S/PDIF-OUT converters support 16/20/24-bit, 44.1k/48k/
88.2k/96k/192kHz sample rate. One for normal S/PDIF output, the other one
output an independent digital stream to HDMI transmitter.
Internal
Microphone • Digital MICRO PHONE ZK2(HFM-M101-006-L19-G)
• Digital MICRO PHONE ZK2(A-OA2408FM-018)
Internal Speakers • Two Med-High Speakers (1W/4Ù)
Item Specification
Controller Winbond NPCE781L
Total number of keypads 99-/100-/103-key keyboard
Windows logo key Yes
Hotkeys See “Hot Keys” on page 15.
Item Specification
6 Cell
Vendor & model name SANYO/SONY/PANASONIC/SAMSUNG/SIMPLO AS2009A
Battery Type Li-ion
Pack capacity 4400 mAh
Normal Voltage 2.2 Ah
Package configuration 3S2P
Item Specification
Part name CR2032
Pack capacity 220 mAh
Normal voltage 3V
26 Chapter 1
AC Adapter
System LED Indicator
LCD 14”
Item Specification
Input rating 100 Vac to 240 Vac
Maximum input AC current 100 Vac, 240 Vac / 3.42A load 1.5A
Inrush current 240 Vac; (Cold Start) No damage
Efficiency 100 Vac / 120W load 85%
240 Vac / 120W load 85%
Item Specification
Drive Activity Power Led: Blue
Suspend: Amber
Primary Battery charging state Amber: Battery Charging
Item Specification
Vendor/model name CMO N140B6-L24 LF,
Samsung LTN140AT06-A01/LTN140AT12-A01,
LG LP140WH2-TLA2/LP140WH2-TLL1/LP140WH2-TLL1,
AUO B140XW02 V1/B140XW03 V0/B140XW03 V0
Screen Diagonal (mm) 14” diagonal
Display Area (mm) 382.08 (H) x 214.92 (V) mm
Display resolution (pixels) 1600 x 900
Pixel Pitch 0.0796 (H) x 0.2388 (V) (TYP.) mm
Display Mode Normally white
Typical White Luminance (cd/m2)
(also called Brightness)
220 cd/m2
Contrast Ratio 600
Response Time (Optical Rise
Time/Fall Time) msec 8 ms
Weight 540g
Physical Size (mm) 398.1(H) x 232.8 (V) x 5.7 (D) mm
Electrical Interface LVDS
Support Color 16.7 million colors
Viewing Angle (up/down/right/
left) 40 Degrees (L+R),15 Degrees (H), 30 Degrees (L)
Temperature Range (°C)
Operating
Storage (shipping)
0 Min - 60 Max
-20 Min - 50 Max
Chapter 1 27
LCD Display Supported Resolution
Video Interface
VRAM
HDMI Port
Resolution 24 bits 30 bits 36 bits 48 bits
640X480p/60Hz 4:3 Yes Yes Yes Yes
720X480p/60Hz 4:3 Yes Yes Yes Yes
640X480p/60Hz 16:9 Yes Yes Yes Yes
1280X720p/60Hz 16:9 Yes Yes Yes Yes
1920X1080p/60Hz 16:9 Yes Yes Yes Yes
1440X480p/60Hz 4:3 Yes Yes Yes Yes
1440X480p/60Hz 16:9 Yes Yes Yes Yes
1920X1080p/50Hz 16:9 Yes Yes Yes Yes
720X576p/50Hz 4:3 Yes Yes Yes Yes
720X576p/50Hz 16:9 Yes Yes Yes Yes
1280X720p/50Hz 16:9 Yes Yes Yes Yes
1920X1080i/50Hz 16:9 Yes Yes Yes Yes
1440X576i/50Hz 4:3 Yes Yes Yes Yes
1440X576i/50Hz 16:9 Yes Yes Yes Yes
1920X1080p/50Hz 16:9 Yes Yes Yes Yes
Item Specification
Chipset ATI Park XT
Package 128bit M2 29x29mm
Features • PCI Express x8
• DirectX 11 complient
• 32 and 64 bit floating point processing per component
• OpenGL 3.1 supported
• Open CLTM 1.1 supported
Item Specification
Chipset SAMSUNG or HYNIX
Memory size 64Mx16x4, 64bit
64Mx16x8, 128bit
Interface GDDR3
Item Specification
Compliance level 1.3 compliant
Thoroughput Up to 2.5Gbps per lane (250MHz pixel clock)
Number of HDMI port(s) 1
Location Left side
28 Chapter 1
Card Reader
LCD Inverter (Not available with this model)
PCMCIA Port (Not available in this model)
Item Specification
Part Name RealTek RT5160
Package 5-in-1 card reader
General Features • PCI-E interface
• Push-push type
•Dummy card
Item Specification
Vendor & model name
Brightness conditions
Input voltage (v)
Input current (mA)
Output voltage (V, RMS)
Output current (mA, RMS)
Output voltage frequency (KHz)
Item Specification
PCMCIA controller
Supports card type
Number of slots
Access location
Supports ZV (Zoomed Video) port
Supports 32-bit CardBus
Chapter 1 29
System Power Management
Mechanical off is a condition where all power except the RTC battery has been removed from the system.
1. Initial to On state: When the AC adapter or Battery pack has been plugged into the system, the I WPC781
will be reset and initial all output pins then the system goes into Initial state and waiting for power on event. If
the power button is pressed then the system will go into the ON state.
2. ON to Standby state: The system will go into the Standby state when HM55 receives the POS command.
3. ON to Suspend state: The system will go into Suspend state when HM55 receives the S2R command.
4. ON to Hibernate state: The system will go into Hibernate state when HM55 receives the S2D command.
5. ON to Soft Off state: The system will go into Soft Off state when HM55 receives the Soft off command.
6. Standby to ON state: The system will go into ON state when the system receives any wake up events, for
example, keyboard, mouse.
7. Suspend to ON state: The system will go into ON state when the power button is pressed.
8. Hibernate to ON state: The system will go into ON state when the power button is pressed.
9. Soft Off to ON state: The system will go into ON state when the power button is pressed.
Item Initial On Standby Suspend Hibernate Soft Off
Initial 1
On(S0) 234 5
Standby(S1) 6
Suspend(S3) 7
Hibernate(S4) 8
Soft Off(S5) 9
30 Chapter 1
Chapter 2 31
System Utilities
BIOS Setup Utility
The BIOS Setup Utility is a hardware configuration program built into your computer’s BIOS (Basic Input/
Output System).
Your computer is already properly configured and optimized, and you do not need to run this utility. However, if
you encounter configuration problems, you may need to run Setup. Please also refer to Chapter 4
Troubleshooting when problems arise.
To activate the BIOS Utility, press F2 during POST (when “Press <F2> to enter Setup” message is prompted
on the bottom of screen).
The default parameter of F12 Boot Menu is set to “disabled”. If you want to change boot device without
entering BIOS Setup Utility, please set the parameter to “enabled”.
Press <F12> during POST to enter multi-boot menu. In this menu, user can change boot device without
entering BIOS SETUP Utility.
Navigating the BIOS Utility
There are five menu options: Information, Main, Security, Boot, and Exit.
Follow these instructions:
• To choose a menu, use the left and right arrow keys.
• To choose an item, use the up and down arrow keys.
• To change the value of a parameter, press F5 or F6.
• Press Esc while you are in any of the menu options to go to the Exit menu.
• In any menu, you can load default settings by pressing F9. You can also press F10 to save any
changes made and exit the BIOS Setup Utility.
NOTE: You can change the value of a parameter if it is enclosed in square brackets. Navigation keys for a
particular menu are shown on the bottom of the screen. Help for parameters are found in the Item
Specific Help part of the screen. Read this carefully when making changes to parameter values. Please
note that system information is subject to different models.
Chapter 2
32 Chapter 2
Aspire 4553/4553G BIOS
Information
The Information screen displays a summary of the computer hardware information.
NOTE: The screen above is for your reference only. Actual values may differ according to model.
The table below describes the parameters in this screen.
Parameter Description
CPU Type This field shows the CPU type and speed of the system.
CPU Speed This field shows the speed of the CPU.
IDE0 Model Name This field shows the model name of HDD installed.
IDE0 Serial Number This field displays the serial number of HDD installed on the system.
ATAPI Model Name This field shows the model name of the Optical device installed in
the system.
System BIOS Version Displays system BIOS version.
VGA BIOS Version This field displays the VGA firmware version of the system.
Serial Number This field displays the serial number of this unit.
Asset Tag Number This field displays the asset tag number of the system.
Product Name This field shows product name of the system.
Manufacturer Name This field displays the manufacturer of this system.
UUID Universally Unique Identifier (UUID) is an identifier standard used in
software construction, standardized by the Open Software
Foundation (OSF) as part of the Distributed Computing Environment
(DCE).
Phoenix SecureCore (tm) Setup Utility
F1
ESC Help
Exit Select Item
Select Menu Change Values
Select SubMenu
Enter F9
F10 Setup Defaults
Save and Exit
AMD Phenom(tm) II
N830 Triple-Core
2100 MHz
WDC WD6400BEVT-22A0RT0
WD-WXC0AC9D1762
TSSTcorp CDDVDW TS-U633F
V0.18
ATi 012.019.000.007.035523
Acer
00000000000000000000000000000000
AMD Phenom(tm) II
N830 Triple-Core
2100 MHz
WDC WD6400BEVT-22A0RT0
WD-WXC0AC9D1762
TSSTcorp CDDVDW TS-U633F
V0.18
ATi 012.019.000.007.035523
Acer
00000000000000000000000000000000
CPU Type
CPU Speed
IDE0 Model Name:
IDE0 Serial Number:
ATAPI Model Name:
System BIOS Version:
VGA BIOS Version:
Serial Number:
Asset Tag Number:
Product Name:
Manufacturer Name:
UUID:
CPU Type
CPU Speed
IDE0 Model Name:
IDE0 Serial Number:
ATAPI Model Name:
System BIOS Version:
VGA BIOS Version:
Serial Number:
Asset Tag Number:
Product Name:
Manufacturer Name:
UUID:
F5/F6
Main Boot Exit
SecurityInformation
Chapter 2 33
Main
The Main screen allows the user to set the system time and date as well as enable and disable boot options
and recovery.
NOTE: The screen above is for your reference only. Actual values may differ.
The table below describes the parameters in this screen.
Parameter Description Format/Option
System Time Sets the system time. The hours are displayed with 24-
hour format. Format: HH:MM:SS
System Date Sets the system date. Format MM/DD/YYYY
Total Memory
Displays the total memory available.
N/A
Video Memory
Displays the available memory for Video.
N/A
Quiet Boot The notebook displays an illustration called the OEM
screen during system boot instead of the traditional
POST screen that displays the normal diagnostic
messages.
Option: Enabled or
Disabled
Network Boot Enables, disables the system boot from LAN (remote
server). Option: Enabled or
Disabled
F12 Boot Menu Enables, disables Boot Menu during POST. Option: Enabled or
Disabled
D2D Recovery Enables, disables D2D Recovery function. The function
allows the user to restore the system to factory defaults. Option: Enabled or
Disabled
SATA CLASS ID Select SATA conrtoller mode. Option: IDE Mode or AHCI
Mode
Special Graphics
Features Select discreet graphics for switchable graphics, or
integrated graphics. Option: Switchable/
Integrated
Processor
Assisted
Virtualization
Enable CPU hardware virtualization support. Option: Enabled or
Disabled
Item Specific Help
<Tab>, <Shift-Tab>, or
<Enter> selects field.
F1
ESC Help
Exit Select Item
Select Menu Change Values
Select SubMenu
Enter F9
F10 Setup Defaults
Save and Exit
[19:10:59]
[01/22/2010]
2048 MB
32 MB
[Enabled]
[Enabled]
[Disabled]
[Enabled]
[AHCI]
[PowerXpress]
[Enabled]
[19:10:59]
[01/22/2010]
2048 MB
32 MB
[Enabled]
[Enabled]
[Disabled]
[Enabled]
[AHCI]
[PowerXpress]
[Enabled]
System Time:
System Date:
Total Memory:
Video Memory:
Quiet Boot:
Network Boot:
F12 Boot Menu:
D2D Recovery:
SATA Class ID:
Special Graphics Features:
Processor Assisted Virtualization:
System Time:
System Date:
Total Memory:
Video Memory:
Quiet Boot:
Network Boot:
F12 Boot Menu:
D2D Recovery:
SATA Class ID:
Special Graphics Features:
Processor Assisted Virtualization:
F5/F6
Phoenix SecureCore(tm) Setup Utility
Boot Exit
Security
Information Main
34 Chapter 2
Security
The Security screen contains parameters that help safeguard and protect your computer from unauthorized
use.
The table below describes the parameters in this screen. Settings in boldface are the default and suggested
parameter settings.
NOTE: When you are prompted to enter a password, you have three tries before the system halts. Don’t forget
your password. If you forget your password, you may have to return your notebook computer to your
dealer to reset it.
Parameter Description Option
Supervisor Password Is Shows the setting of the Supervisor password Clear or Set
User Password Is Shows the setting of the user password. Clear or Set
HDD Password Is Shows the setting of the hard disk password. Clear or Set
Set Supervisor Password Press Enter to set the supervisor password. When set,
this password protects the BIOS Setup Utility from
unauthorized access. The user can not either enter the
Setup menu nor change the value of parameters.
N/A
Set User Password Press Enter to set the user password. When user
password is set, this password protects the BIOS Setup
Utility from unauthorized access. The user can enter
Setup menu only and does not have right to change the
value of parameters.
N/A
Set IDE0 Password Enter HDD Password. N/A
Password on Boot Defines whether a password is required or not while the
events defined in this group happened. The following
sub-options are all requires the Supervisor password
for changes and should be grayed out if the user
password was used to enter setup.
Disabled or
Enabled
Item Specific Help
Supervisor Password
controls access to the
setup utility.
F1
ESC Help
Exit Select Item
Select Menu Change Values
Select SubMenu
Enter F9
F10 Setup Defaults
Save and Exit
Clear
Clear
Clear
[Enter]
[Enter]
[Enter]
[Disabled]
Clear
Clear
Clear
[Enter]
[Enter]
[Enter]
[Disabled]
Supervisor Password Is:
User Password Is:
HDD Password Is:
Set Supervisor Password
Set User Password
Set IDE0 Password
Password on Boot
Supervisor Password Is:
User Password Is:
HDD Password Is:
Set Supervisor Password
Set User Password
Set IDE0 Password
Password on Boot
F5/F6
Phoenix SecureCore(tm) Setup Utility
Information Main Boot Exit
Security
Chapter 2 35
Setting a Password
Follow these steps as you set the user or the supervisor password:
1. Use the ↑ and ↓ keys to highlight the Set Supervisor Password parameter and press the Enter key. The
Set Supervisor Password box appears:
2. Type a password in the “Enter New Password” field. The password length can not exceed 8 alphanumeric
characters (A-Z, a-z, 0-9, not case sensitive). Retype the password in the “Confirm New Password” field.
IMPORTANT:Be very careful when typing your password because the characters do not appear on the screen.
3. Press Enter. After setting the password, the computer sets the User Password parameter to “Set”.
4. If desired, you can opt to enable the Password on boot parameter.
5. When you are done, press F10 to save the changes and exit the BIOS Setup Utility.
Removing a Password
Follow these steps:
1. Use the ↑ and ↓ keys to highlight the Set Supervisor Password parameter and press the Enter key. The
Set Password box appears:
2. Type the current password in the Enter Current Password field and press Enter.
3. Press Enter twice without typing anything in the Enter New Password and Confirm New Password fields.
The computer then sets the Supervisor Password parameter to “Clear”.
4. When you have changed the settings, press u to save the changes and exit the BIOS Setup Utility.
Set Supervisor Password
Enter New Password [ ][ ]
Confirm New Password [ ]
Set Supervisor Password
Enter Current Password [ ][ ]
Enter New Password [ ]
Confirm New Password [ ][ ]
36 Chapter 2
Boot
This menu allows the user to decide the order of boot devices to load the operating system. Bootable devices
includes the USB diskette drives, the onboard hard disk drive and the DVD drive in the module bay.
Select Boot Devices to select specific devices to support boot.
Item Specific Help
Use < > or < > to select
a device, then press
<F6> to move it up the
list, or <F6> to move
it down the list. Press
<Esc> to escape the
menu.
F1
ESC Help
Exit Select Item
Select Menu Change Values
Select SubMenu
Enter F9
F10 Setup Defaults
Save and Exit
Boot priority order:
1. IDE HDD: WDC WD6400BEVT-22A0RT0-(S1
2. IDE CD: TSSTcorp CDDVDW TS-U633F-(
3. USB FDC:
4. PCI BEV: Atheros Boot Agent
5. USB HDD:
6. USB CDROM:
7. USB KEY:
8.
Excluded from boot order:
Boot priority order:
1. IDE HDD: WDC WD6400BEVT-22A0RT0-(S1
2. IDE CD: TSSTcorp CDDVDW TS-U633F-(
3. USB FDC:
4. PCI BEV: Atheros Boot Agent
5. USB HDD:
6. USB CDROM:
7. USB KEY:
8.
Excluded from boot order:
F5/F6
Phoenix SecureCore(tm) Setup Utility
Information Main Boot Exit
Security
Chapter 2 37
Exit
The Exit screen allows you to save or discard any changes you made and quit the BIOS Utility.
The table below describes the parameters in this screen.
Parameter Description
Exit Saving Changes Exit System Setup and save your changes.
Exit Discarding
Changes Exit utility without saving setup data.
Load Setup Default Load default values for all setup items.
Discard Changes Load previous values for all setup items.
Save Changes Save setup data.
Item Specific Help
Exit System Setup and
save your changes to
CMOS.
F1
ESC Help
Exit Select Item
Select Menu Change
Execute Command
Values
Enter F9
F10 Setup Defaults
Save and Exit
Exit Saving Changes
Exit Discarding Changes
Load Setup Defaults
Discard Changes
Save Changes
Exit Saving Changes
Exit Discarding Changes
Load Setup Defaults
Discard Changes
Save Changes
F5/F6
Phoenix SecureCore(tm) Setup Utility
Information Main Boot Exit
Security
38 Chapter 2
BIOS Flash Utilities
The BIOS flash memory update is required for the following conditions:
• New versions of system programs
• New features or options
• Restore a BIOS when it becomes corrupted.
Use the flash utility to update the system BIOS flash ROM.
NOTE: If you do not have a crisis recovery diskette at hand, then you should create a Crisis Recovery
Diskette before you use the flash utility.
NOTE: Do not install memory-related drivers (XMS, EMS, DPMI) when you use the flash.
NOTE: Please use the AC adaptor power supply when you run the flash utility. If the battery pack does not
contain enough power to finish BIOS flash, you may not boot the system because the BIOS is not
completely loaded.
Fellow the steps below to run the flash.
1. Prepare a bootable diskette.
2. Copy the flash utilities to the bootable diskette.
3. Then boot the system from the bootable diskette. The flash utility has auto-execution function.
Chapter 2 39
DOS Flash Utility
Perform the following steps to use the DOS Flash Utility:
1. Press F2 during boot to enter the Setup Menu.
2. Select Boot Menu to modify the boot priority order, for example, if using USB HDD to Update BIOS, move
USB HDD to position 1.
3. Execute the BIOS.BAT batch file to update BIOS.
The flash process begins as shown.
4. In flash BIOS, the message Please do not remove AC Power Source displays.
NOTE: If the AC power is not connected, the following message displays.
Plug in the AC power to continue.
5. Flash is complete when the message Flash programming complete displays.
Item Specific Help
Use < > or < > to select
a device, then press
<F6> to move it up the
list, or <F6> to move
it down the list. Press
<Esc> to escape the
menu.
F1
ESC Help
Exit Select Item
Select Menu Change Values
Select SubMenu
Enter F9
F10 Setup Defaults
Save and Exit
Boot priority order:
1. IDE HDD: WDC WD6400BEVT-22A0RT0-(S1
2. IDE CD: TSSTcorp CDDVDW TS-U633F-(
3. USB FDC:
4. PCI BEV: Atheros Boot Agent
5. USB HDD:
6. USB CDROM:
7. USB KEY:
8.
Excluded from boot order:
Boot priority order:
1. IDE HDD: WDC WD6400BEVT-22A0RT0-(S1
2. IDE CD: TSSTcorp CDDVDW TS-U633F-(
3. USB FDC:
4. PCI BEV: Atheros Boot Agent
5. USB HDD:
6. USB CDROM:
7. USB KEY:
8.
Excluded from boot order:
F5/F6
Phoenix SecureCore(tm) Setup Utility
Information Main Boot Exit
Security
40 Chapter 2
WinFlash Utility
Perform the following steps to use the WinFlash Utility:
1. Double-click the WinFlash executable.
2. Click OK to begin the update. A progress screen displays.
Chapter 2 41
Remove HDD/BIOS Password Utilities
This section provides you with details about removing HDD/BIOS password:
Remove HDD Password:
If you key in the wrong HDD password three times, an error is generated.
To reset the HDD password, perform the following steps:
1. On another computer, run HDD_PW.exe.
2. Enter “hdd_pw 15494 0”
3. Chose one (1) of the generated passwords.
4. Reboot the locked computer and key in one of the passwords from number 3 above.
42 Chapter 2
Removing BIOS Passwords
If you key in the wrong HDD password three times, an error is generated.
To clean the User or Supervisor passwords, perform the following steps:
To reset the BIOS password, perform the following steps:
1. On another computer, run BIOS_PW.exe.
2. Enter “bios_pw 14452 0”
3. Chose one (1) of the generated passwords.
4. Reboot the locked computer and key in one of the passwords from number 3 above.
Chapter 2 43
44 Chapter 2
Clearing BIOS Passwords
To clear the User or Supervisor passwords, open the DIMM door and use a metal instrument to short the G1
jumper.
Chapter 2 45
Using Boot Sequence Selector
The Boot Sequence Selector allows the boot order to be changed without accessing the BIOS. To use Boot
Sequence Selector, perform the following steps:
1. Enter into DOS.
2. Execute BS.exe to display the usage screen.
3. Select the desired boot sequence by entering the corresponding sequence. For example, enter BS2 to
change the boot sequence to HDD | CD ROM | LAN | Floppy.
Using DMITools
The DMI (Desktop Management Interface) Tool copies BIOS information to EEPROM to be used in the DMI
pool for hardware management.
When the BIOS displays “Verifying DMI pool data”, it is checking that the table correlates with the hardware
before sending that information to the operating system (Windows, etc.).
To update the DMI Pool, perform the following steps:
1. Boot into DOS.
2. Execute qdmi30a.exe. The following screen displays:
Type "1" to modify "Asset Tag" values.
Type "2" to modify "Product Name" values.
Type "3" to modify "Serial Number" values.
Type "4" to modify "1394 GUID Number" values.
Type "0" to Exit the program
3. Run VEEPROM.exe to write the values to EEPROM.
46 Chapter 2
Configuring UUID Values
1. Boot into DOS.
2. Run UUID.bat
Using the LAN MAC EEPROM Utility
You can use the MAC.BAT utility to write the MAC.CFG file to the EEPROM under DOS mode.
1. Use a text editor (for example: Notepad) to open the MAC.CFG file. You can see the MAC.CFG contents
as below:
• WriteData= '001122334455' <------- MAC value
• StartAddr=7A <------- MAC address
• WriteLeng=6 <------- MAC value length
• KeepByte=0 <------- can be any value
2. Boot into DOS.
3. Execute MAC.BAT to write MAC information to eeprom.
WriteData = ‘001122334455' MAC value
StartAddr=7A MAC address
WriteLeng=6 MAC value length
KeepByte=0 don’t care
Chapter 3 47
Machine Disassembly and Replacement
IMPORTANT:The outside housing and color may vary from the mass produced model.
This chapter contains step-by-step procedures on how to disassemble the notebook computer for
maintenance and troubleshooting.
Disassembly Requirements
To disassemble the computer, you need the following tools:
• Wrist grounding strap and conductive mat for preventing electrostatic discharge
• Flat screwdriver
• Philips screwdriver
• Plastic flat screwdriver
• Plastic tweezers
NOTE: The screws for the different components vary in size. During the disassembly process, group the
screws with the corresponding components to avoid mismatch when putting back the components.
Chapter 3
48 Chapter 3
General Information
Pre-disassembly Instructions
Before proceeding with the disassembly procedure, make sure that you do the following:
1. Turn off the power to the system and all peripherals.
2. Place the system on a flat, stable surface.
3. Unplug the AC adapter and all power and signal cables from the system.
Disassembly Process
The disassembly process is divided into the following stages:
• External module disassembly
• Main unit disassembly
The flowcharts provided in the succeeding disassembly sections illustrate the entire disassembly sequence.
Observe the order of the sequence to avoid damage to any of the hardware components. For example, if you
want to remove the mainboard, you must first remove the keyboard, then disassemble the inside assembly
frame in that order.
Main Screw List
Screw Quantity Part Number
M2.5*3 1 86.PSR07.002
M2.0*3 16 86.PSR07.003
M2.0*6 7 86.S6507.001
M2.5*6.5 12 86.ARE07.001
M2.5*4 11 86.PSR07.001
Chapter 3 49
External Module Disassembly Process
IMPORTANT:The outside housing and color may vary from the mass produced model.
External Modules Disassembly Flowchart
The flowchart below gives you a graphic representation on the entire disassembly sequence and instructs you on
the components that need to be removed during servicing. For example, if you want to remove the main board, you
must first remove the keyboard, then disassemble the inside assembly frame in that order.
.
Screw List
Step Screw Quantity Part No.
ODD Module M2.5*4L 1 86.PSR07.001
ODD Bracket M2.0*3L 2 86.PSR07.003
WLAN Module M2.0*3L 1 86.PSR07.003
HDD Carrier M3.0*4L 2 86.N1407.007
Disconnect power
and signal cables
from system
Remove
Dummy Card
Turn off system
and peripherals
power
Remove
DIMM
Remove
HDD
Remove
Lower Covers
Remove
WLAN Board
Remove
Battery
50 Chapter 3
Removing the Battery Pack
1. Turn computer over. Slide the battery lock in the direction shown.
2. Slide and hold the battery release latch to the release position (1), then lift out the battery pack from the main
unit (2).
Please detach the battery and follow local regulations for disposal.
1
2
Chapter 3 51
Removing the SD dummy card
1. Push the SD dummy card all the way in to eject it.
2. Pull it out from the slot.
52 Chapter 3
Removing the Lower Cover
1. See “Removing the Battery Pack” on page 50.
2. Remove the six (6) screws from the lower cover.
3. Remove the lower cover as shown.
Step Size Quantity Screw Type
Lower Cover M2.5*6.5 5
Chapter 3 53
Removing the Optical Drive Module
1. See “Removing the Lower Cover” on page 52.
2. Remove the screw securing the ODD module.
3. Using your fingers, pull the optical drive module out from the chassis.
4. Remove the two screws securing the ODD bracket and remove the ODD bracket from the optical disk drive
module.
Step Size Quantity Screw Type
ODD Module M2.5*3 1
54 Chapter 3
5. Remove the ODD bezel by rotating the top edge downward and pulling it clear of the module.
Step Size Quantity Screw Type
ODD Bracket M2.0*3 2
Chapter 3 55
Removing the DIMM Modules
1. See “Removing the Lower Cover” on page 52.
2. Push out the release latches on both sides of the DIMM socket to release the DIMM module.
3. Remove the DIMM module.
4. Repeat steps for the second DIMM module if present.
56 Chapter 3
Removing the WLAN Module
1. See “Removing the Lower Cover” on page 52.
2. Disconnect the two (2) antenna cables from the WLAN Board
NOTE: Cable placement is Black to the TR1 terminal (next to DIMM module) and White to the TR2 terminal
(closest to the edge of the chassis).
3. Remove the one (1) screw to release the WLAN Board.
Step Size Quantity Screw Type
WLAN Board M2.0*3 1
Chapter 3 57
4. Detach and remove the WLAN Board from the WLAN socket.
58 Chapter 3
Removing the Hard Disk Drive Module
1. See “Removing the Lower Cover” on page 52.
2. Using the pull-tab, slide the HDD Module in the direction of the arrow to disconnect the interface.
3. Lift the HDD Module clear of the HDD bay.
4. Remove the two (2) screws from the carrier.
5. Remove the carrier from the HDD.
Step Size Quantity Screw Type
HDD Carrier M3.0*3 2
Chapter 3 59
Main Unit Disassembly Process
Main Unit Disassembly Flowchart
Screw List
Step Screw Quantity Part No.
Lower Cover M2.5*6.5 11 86.ARE07.001
M2.5*4 2 86.PSR07.001
M2.0*6 2 86.S6507.001
M2.0*3widehead 4 86.ARE07.002
Upper Cover M2.5*4 5 86.PSR07.001
M2.0*3widehead 2 86.ARE07.002
Function Board M2.0*3widehead 2 86.ARE07.002
Power Switch
Board M2.0*3widehead 2 86.ARE07.002
USB Board M2.5*4 1 86.PSR07.001
Mainboard M2.5*4 3 86.PSR07.001
Remove external
modules before
proceeding
Remove keyboard
Remove upper cover
Remove Function
Board
Remove Power Switch
Board Remove main board
Remove thermal
module
Remove LCD module
Remove CRT Cable Remove USB Board Remove Bluetooth
Module
Remove CPURemove RTC Battery
Remove PCH
Heatsink
60 Chapter 3
Removing the Keyboard
CAUTION: Using metal tools to remove the Keyboard may cause damage to the outer casing. It is
recommended that you use only your fingers and plastic tools to remove the Keyboard.
1. See “Removing the Battery Pack” on page 50.
2. Turn the computer over and fully open the lid. There are five (5) securing clips that must be released in order to
remove the keyboard.
3. Release each clip, working from one side to the other.
4. Using both hands, gently pry up the cover as shown and turn it over.
Chapter 3 61
5. Open the locking latch on the FFC, and disconnect the cable as shown.
6. Lift the keyboard clear of the chassis.
Removing the Upper Cover
1. See “Removing the Keyboard” on page 60.
2. Turn the computer over. Disconnect the following four cables from the Mainboard:
a. Left speaker cable
b. Touchpad FFC
c. Power Switch FFC
d. Function Board FFC
AB
CD
62 Chapter 3
NOTE: Avoid pulling on cables directly to prevent damage to the connectors. Use the pull-tabs on FFC cables
whenever available.
3. Disconnect A as shown. 4. Release the locking latch and remove B as shown.
5. Release the locking latch and remove C as shown. 6. Release the locking latch and remove D as shown.
Chapter 3 63
7. Remove the sixteen (16) securing screws from the lower cover.
NOTE:
8. Remove the seven (7) screws from the top cover.
Step Size Quantity Screw Type
Lower Cover
(red callout)
M2.5*6.5 11
Lower Cover
(green callout)
M2.5*4L 4
Lower Cover
(blue callout)
M2.0*3widehead 2
Step Size Quantity Screw Type
Upper Cover
(red callout)
M2*3L 2
Upper Cover
(blue callout)
M2.5*4L 5
64 Chapter 3
9. Remove the Upper Cover by lifting directly upward from the front as shown.
Removing the Power Switch Board
1. See “Removing the Upper Cover” on page 61.
2. Locate the Power Switch Board in the Upper Cover.
3. Release the securing latch holding the Power Switch Board FFC and remove.
Chapter 3 65
4. Remove the two (2) screws and lift the Power Switch Board clear of the Upper Cover.
Removing the Function Board
1. See “Removing the Upper Cover” on page 61.
2. Locate the Function Board in the Upper Cover.
Step Size Quantity Screw Type
Power Switch
Board M2.0*3widehead 2
66 Chapter 3
3. Remove the two (2) screws attaching it to the upper cover.
4. Lift the Function Board clear of the Upper Cover, but do not remove completely.
5. Turn the Function Board over. Release the securing latch holding the Function Board FFC and remove.
Step Size Quantity Screw Type
Function Board M2.0*3widehead 2
Chapter 3 67
Removing the USB Board
1. See See “Removing the Upper Cover” on page 61.
2. Remove the single securing screw from the USB Board.
3. Release the FFC latch and remove the FFC cable from the mainboard connector.
4. Release the FFC latch and remove the FFC cable from the USB connector.
Step Size Quantity Screw Type
USB Board M2.5*4 1
68 Chapter 3
5. Lift the USB Board upward away from the chassis.
Removing the Bluetooth Module
1. See “Removing the Upper Cover” on page 61.
2. Disconnect the cable from the Mainboard and lift the Bluetooth Module off the mainboard.
3. Remove the single securing screw from the Bluetooth board.
Step Size Quantity Screw Type
Bluetooth Board M2.0*3 1
Chapter 3 69
4. Remove the Bluetooth board from the mainboard and disconnect the cable as shown.
Removing the LCD Module
1. See “Removing the Upper Cover” on page 61.
2. Disengage the WiFi antennas from the guides on the bottom cover.
3. Rest the computer on the back of the LCD as shown. Thread the WiFi antennas through the chassis and
disengage from the cable guides as shown.
70 Chapter 3
4. Peel back the adhesive holding the LVDS cable.
5. Pull up on the LVDS cable to disconnect it from the mainboard.
6. Unlock the microphone cable release it from the clasps on the cooling fan.
Chapter 3 71
7. Remove the four securing screws (two each side) from the LCD module.
8. Ensure that all cables entering the LCD are free of the chassis and remove the LCD module from the chassis.
Step Size Quantity Screw Type
LCD Module (red
callouts) M2.5*6.5 3
LCD Module
(green callout) M2.5*3 1
72 Chapter 3
Removing the Mainboard
1. See “Removing the Bluetooth Module” on page 68.
2. See “Removing the LCD Module” on page 69.
3. Disconnect the right speaker cable.
4. Turn the computer over and remove the DC-In cable.
5. Remove the three (3) securing screws from the Mainboard.
Chapter 3 73
6. Lift the Mainboard right side first and remove it from the Lower Cover.
Removing the Thermal Module
1. See “Removing the Mainboard” on page 72.
2. Turn the Mainboard over and disconnect the Fan cable as shown.
Step Size Quantity Screw Type
Mainboard M2.5*4 3
74 Chapter 3
3. Loosen the six (6) captive screws (in numerical order from 1 to 6) and remove the two (2) screws (green
callouts - numbers 7 & 8) from the CPU Thermal Module.
4. Using both hands, lift the Thermal Module clear of the Mainboard.
Step Size Quantity Screw Type
Thermal Module M2.0*3 2
1
23
45
6
7
8
Chapter 3 75
Removing the PCH Thermal Module
1. See “Removing the Mainboard” on page 72.
2. remove the two (2) screws from the PCH Thermal Module.
3. Lift the PCH Thermal Module clear of the Mainboard.
Removing the CPU
1. See “Removing the Thermal Module” on page 73.
2. Using a phillips screw driver, rotate the CPU locking screw 180° counter-clockwise as shown.
76 Chapter 3
3. Lift the CPU clear of the socket as shown.
IMPORTANT:The pins on the underside of the CPU are very delicate. If they are damaged, the CPU may
malfunction. Place the CPU on a clean, dry surface when it is not installed.
Removing the RTC Battery
1. See “Removing the Mainboard” on page 72.
2. Pry the RTC battery from the mainboard.
Please detach the RTC battery and follow local regulations for disposal.
Please detach the mainboard and follow local regulations for disposal.
Chapter 3 77
LCD Module Disassembly Process
LCD Module Disassembly Flowchart
Screw List
Step Screw Quantity Part No.
LCD Bezel M2.5*4 2 86.PSR07.001
LCD Panel M2.0*3 4 86.ARE07.002
Hinges M2.5*3 4 86.TPK07.003
Remove LCD panel
from main unit before
preceeding
Remove LCD bezel
Remove camera
module
Remove LCD panel
Remove HingesRemove FPC cable Remove WLAN
antennas
Remove microphone
78 Chapter 3
Removing the LCD Bezel
1. See “Removing the LCD Module” on page 69.
2. Remove the two (2) bezel screws.
3. Starting from the top-center of the bezel, pry the bezel upwards and away from the panel. Move along the top
and sides until the bezel is completely detached.
Step Size Quantity Screw Type
LCD Bezel M2.5*4 2
Chapter 3 79
4. Grasp the hinges and lift the Bezel clear of the LCD Module in the direction shown.
Removing the Camera Module
1. See “Removing the LCD Bezel” on page 78.
2. Disconnect the camera cable.
3. Remove the Camera from the module.
80 Chapter 3
Removing the LCD Panel
1. See “Removing the Camera Module” on page 79.
2. Disengage the various cables from the hinges.
3. Remove the four (4) securing screws from the LCD Panel.
4. Disengage the LVDS cable from the left hinge and the cable guides.
Step Size Quantity Screw Type
LCD Panel M2.0*3 4
Chapter 3 81
5. Lift the LCD Panel clear of the module as shown.
Removing the FPC Cable
1. See “Removing the LCD Panel” on page 80.
2. Turn the LCD panel over to expose the rear. Disengage the adhesive strip securing it in place.
3. Lift the adhesive protector and disconnect the cable from the LCD Panel.
4. Remove the FPC cable from the panel.
82 Chapter 3
Removing the Microphone Module
1. See “Removing the LCD Panel” on page 80.
2. Remove the adhesive tape covering the microphone cable.
3. Disengage the cable from the cable guides.
4. Lift the Microphone Module clear of the cover.
Chapter 3 83
Removing the Antennas
1. See “Removing the LCD Panel” on page 80.
2. Disengage the left antenna cable from the guides.
3. Disengage the right antenna cable from the guides.
4. Remove the adhesive tape and lift the left side antenna from the LCD module as shown.
84 Chapter 3
5. Remove the adhesive tape and lift the right side antenna from the LCD module as shown.
Removing the Hinges
1. See “Removing the LCD Panel” on page 80.
2. Remove the four (4) screws from the hinges
3. Remove the hinges from the LCD cover.
Step Size Quantity Screw Type
LCD Hinges M2.5*3 4
Chapter 3 85
LCD Module Reassembly Procedure
Replacing the MIC and WiFi Antennas
1. Replace the left and right antennas as shown. Press down on the adhesive pads to secure the antennas in
place.
2. Replace the left antenna cable (white) as shown.
Ensure that the cables are secured in the cable
guides.
3. Replace the right antenna cables (black) as shown.
Ensure that the cables are secured in the cable
guides.
4. Replace the Microphone Module into the top cover. 5. Replace the cable into the cable guides as shown.
86 Chapter 3
Replacing the FPC Cable
1. Attach the FPC cable to the LCD panel and attach the adhesive protector.
6. Replace the adhesive tape onto the microphone cable.
7. Ensure the antenna cables pass through the hinge well as shown.
Chapter 3 87
2. Press down on the adhesive tape to secure the FPC cable in place.
Replacing the LCD Panel
3. Place the LCD Panel into the module as shown.
4. Replace the four (4) securing screws to secure the LCD Panel.
88 Chapter 3
Replacing the Webcam
1. Place the camera in the LCD Module. 2. Connect the cable to the camera module.
Chapter 3 89
Replacing the LCD Bezel
1. Reattach the hinges first, then press down until there are no gaps between the bezel and the LCD Module.
IMPORTANT: Ensure that the LCD cables pass through the hinge wells and are not trapped by the bezel.
2. Press down around the entire perimeter of the bezel until there are no gaps between the bezel and the LCD
Module.
3. Replace the two screws.
90 Chapter 3
Main Module Reassembly Procedure
Replacing the RTC Battery
1. Snap the RTC battery into its socket as shown, plus side (+) up.
Replacing the CPU
IMPORTANT:The CPU has a Pin1 locator that must be positioned corresponding to the marker on the CPU
socket.
1. Place the CPU into the CPU socket as shown, taking note of the Pin1 locator.
2. Using a flat-bladed screw driver, rotate the CPU locking screw 180° clockwise to secure the CPU in place.
CPU
Pin1 Locator
Chapter 3 91
Replacing the Thermal Module
IMPORTANT:Apply a suitable thermal grease and ensure all heat pads are in place before replacing the
Thermal Module.
The following thermal grease types are approved for use:
•Silmore GP50
•Honeywell PCM45F-SP
•ShinEtsu 7762
The following thermal pads are approved for use:
• Eapus XR-PE
1. Remove all traces of thermal grease from the CPU using a lint-free cloth or cotton swab and Isopropyl
Alcohol, Acetone, or other approved cleaning agent.
2. Apply a small amount of thermal grease to the centre of the CPU—there is no need to spread the grease
manually, the force used during the installation of the Thermal Module is sufficient.
3. Align the screw holes on the Thermal Module and
Mainboard then replace the module. Keep the
module as level as possible to spread the thermal
grease evenly.
4. Replace the eight (8) securing screws (in
numerical order from screw 1 to screw 8) to secure
the Thermal Module in place.
5. Connect the fan cable to the Mainboard.
1
23
45
6
7
8
92 Chapter 3
Replacing the PCH Thermal Module
1. Replace the PCH Thermal Module onto the Mainboard.
2. Replace the two (2) screws to secure the PCH Thermal Module.
Chapter 3 93
3. Replacing the MainboardDisengage the WiFi antennas from the guides on the bottom
1. Place the Mainboard in the chassis, left edge first
(1), then rotate it downward into position (2).
NOTE: Ensure the left side I/O ports are positioned
correctly through the casing.
2. Replace the three (3) securing screws in the
mainboard.
3. Turn the computer over and replace the DC-In
cable. 4. Turn the computer over. Feed the mircophone
cable through the guides on the fan.
12
94 Chapter 3
Replacing the LCD Module
1. Replace the LCD module onto the chassis.
2. Replace the four securing screws (two each side) to the LCD module.
3. Starting at the top, slide your finger down the length of the LVDS cable to reattach the adhesive.
Chapter 3 95
cover.
6. Replace the WLAN cables into the cable guides
4. Snap the FPC cable into place.
5. Connect the right speaker cable.
96 Chapter 3
7. Rest the computer on the back of the LCD as shown. Pull the WiFi antennas through the hole in the chassis as
shown.
8. Insert the WLAN cables into the cable guides as shown.
Chapter 3 97
Replacing the Bluetooth Module
NOTE: The Bluetooth Module and USB Board can be replaced independently and in any order.
1. Connect the smaller end of the Bluetooth cable to
the Bluetooth Module as shown. 2. Secure the Bluetooth module in place using the
one (1) screw.
1. Connect the Bluetooth cable to the Mainboard.
98 Chapter 3
Replacing the USB Board
1. Replace the USB Board in the Lower Cover. 2. Insert the FFC cable in to the connector on the
Mainboard and secure the locking latch.
3. Insert the FFC cable in to the connector on the
USB Board and secure the locking latch. 4. Replace the single securing screw.
Chapter 3 99
Replacing the Function Board
Replacing the Power Switch Board
1. Replace the Function Board FFC and lock it into
place. 2. Place the Function Board in to the Upper Cover as
shown and replace the two (2) screws.
1. Place the Power Switch Board in to the Upper
Cover as shown and replace the two (2) screws. 2. Replace the Power Switch Board FFC and lock it
into place.
100 Chapter 3
Replacing the Upper Cover
1. Place the Upper Cover on the Lower Cover back
edge first. 2. Lower the cover into position and press down the
sides as shown.
3. Continue pressing around the edges of the casing until there are no gaps between the Upper and Lower
Covers.
Chapter 3 101
4. Replace the eight (8) securing screws as shown.
NOTE: The securing screws differ in length: M2.5*5 (red callout) and M2.5*3 (green callout). Ensure that the
correct screw is used to secure the Upper Cover in place.
5. Connect the four cables to the Mainboard as shown.
AB
CD
102 Chapter 3
6. Connect A as shown. 7. Insert B as shown and close the locking latch.
8. Insert C as shown and close the locking latch. 9. Insert D as shown and close the locking latch.
10. Turn the computer over and replace the fourteen screws as shown.
Chapter 3 103
Replacing the Keyboard
1. Place the keyboard face down on the Upper Cover. Reconnect keyboard FFCs to the mainboard, and
secure the locking latch.
2. Slide the Keyboard front edge first into the Upper Cover, ensuring that the four locating tabs are correctly
seated.
3. Press down as indicated to secure the Keyboard in place.
104 Chapter 3
Replacing the ODD Module
Replacing the Hard Disk Drive Module
1. Press the bezel into the tray, bottom edge first, to
secure it to the ODD Module. 2. Secure the ODD bracket with the two screws.
3. Push the ODD Module into the ODD bay until it is
flush with the casing. 4. Replace the single screw to secure the Module.
1. Replace the HDD carrier and replace the two (2) screws.
Chapter 3 105
2. Insert the HDD, left side first, and lower it into place.
3. Slide the HDD to the right to connect the interface.
106 Chapter 3
Replacing the WLAN Board
Replacing the DIMM Modules
3. Repeat with the second DIMM module if present.
1. Insert the WLAN board into the WLAN socket. 2. Replace the one (1) screw to secure the module.
3. Connect the two (2) antenna cables to the module.
NOTE: Cable placement is Black to the TR1 terminal (next to DIMM module) and White to the TR2 terminal
(closest to the edge of the chassis).
1. Insert the DIMM Module in place. 2. Press down to lock the DIMM module in place.
Chapter 3 107
Replacing the Lower Covers
1. Replace the HDD Cover as shown.
IMPORTANT:Press down around the perimeter of the cover to ensure that the all the securing tabs are
snapped correctly.
2. Secure the five captive screws to hold the covers in place.
108 Chapter 3
Replacing the Dummy Cards
Replacing the Battery Pack
1. Insert the SD Dummy Card into the slot and push until the card clicks into place and is flush with the casing.
1.
Insert the battery pack and press down.
2. Slide the battery lock in the direction shown to
secure the battery in place.
Chapter 4 109
Troubleshooting
Common Problems
Use the following procedure as a guide for computer problems.
NOTE: The diagnostic tests are intended to test only Acer products. Non-Acer products, prototype cards, or
modified options can give false errors and invalid system responses.
1. Obtain the failing symptoms in as much detail as possible.
2. Verify the symptoms by attempting to re-create the failure by running the diagnostic test or by repeating
the same operation.
3. Use the following table with the verified symptom to determine which page to go to.
4. If the Issue is still not resolved, see “Online Support Information” on page 165.
Symptoms (Verified) Go To
Power On Issue Page 110
No Display Issue Page 111
LCD Failure Page 113
Internal Keyboard Failure Page 113
TouchPad Failure Page 114
Internal Speaker Failure Page 114
ODD Failure Page 117
WLAN Failure Page 120
Thermal Unit Failure Page 120
Other Functions Failure Page 121
Intermittent Failures Page 122
Undermined Failures Page 122
Chapter 4
110 Chapter 4
Power On Issue
If the system doesn’t power on, perform the following actions one at a time to correct the problem. Do not
replace a non-defective FRUs:
Computer Shutsdown Intermittently
If the system powers off at intervals, perform the following actions one at a time to correct the problem.
1. Check the power cable is properly connected to the computer and the electrical outlet.
2. Remove any extension cables between the computer and the outlet.
3. Remove any surge protectors between the computer and the electrical outlet. Plug the computer directly
into a known good electrical outlet.
4. Disconnect the power and open the casing to check the Thermal Unit (see “Thermal Unit Failure” on page
120) and fan airways are free of obstructions.
5. Remove all external and non-essential hardware connected to the computer that are not necessary to
boot the computer to the failure point.
6. Remove any recently installed software.
7. If the Issue is still not resolved, see “Online Support Information” on page 165.
Chapter 4 111
No Display Issue
If the Display doesn’t work, perform the following actions one at a time to correct the problem. Do not replace
a non-defective FRUs:
No POST or Video
If the POST or video doesn’t display, perform the following actions one at a time to correct the problem.
1. Make sure that the internal display is selected. On this notebook model, switching between the internal
display and the external display is done by pressing Fn+F5. Reference Product pages for specific model
procedures.
2. Make sure the computer has power by checking at least one of the following occurs:
• Fans start up
• Status LEDs light up
If there is no power, see “Power On Issue” on page 110.
3. Drain any stored power by removing the power cable and battery and holding down the power button for
10 seconds. Reconnect the power and reboot the computer.
4. Connect an external monitor to the computer and switch between the internal display and the external
display is by pressing Fn+F5 (on this model).
If the POST or video appears on the external display, see “LCD Failure” on page 113.
5. Disconnect power and all external devices including port replicators or docking stations. Remove any
memory cards and CD/DVD discs. Restart the computer.
If the computer boots correctly, add the devices one by one until the failure point is discovered.
6. Reseat the memory modules.
7. Remove the drives (see “Disassembly Process” on page 46).
8. If the Issue is still not resolved, see “Online Support Information” on page 165.
112 Chapter 4
Abnormal Video Display
If video displays abnormally, perform the following actions one at a time to correct the problem.
1. Reboot the computer.
2. If permanent vertical/horizontal lines or dark spots display in the same location, the LCD is faulty and
should be replaced. See “Disassembly Process” on page 46.
3. If extensive pixel damage is present (different colored spots in the same locations on the screen), the LCD
is faulty and should be replaced. See “Disassembly Process” on page 46.
4. Adjust the brightness to its highest level. See the User Manual for instructions on adjusting settings.
NOTE: Ensure that the computer is not running on battery alone as this may reduce display brightness.
If the display is too dim at the highest brightness setting, the LCD is faulty and should be replaced. See
“Disassembly Process” on page 46.
5. Check the display resolution is correctly configured:
a. Minimize or close all Windows.
b. If display size is only abnormal in an application, check the view settings and control/mouse wheel
zoom feature in the application.
c. If desktop display resolution is not normal, right-click on the desktop and select
Personalize´ Display Settings.
d. Click and drag the Resolution slider to the desired resolution.
e. Click Apply and check the display. Readjust if necessary.
6. Roll back the video driver to the previous version if updated.
7. Remove and reinstall the video driver.
8. Check the Device Manager to determine that:
• The device is properly installed. There are no red Xs or yellow exclamation marks.
• There are no device conflicts.
• No hardware is listed under Other Devices.
9. If the Issue is still not resolved, see “Online Support Information” on page 165.
10. Run the Windows Memory Diagnostic from the operating system DVD and follow the onscreen prompts.
11. If the Issue is still not resolved, see “Online Support Information” on page 165.
Random Loss of BIOS Settings
If the computer is experiencing intermittent loss of BIOS information, perform the following actions one at a
time to correct the problem.
1. If the computer is more than one year old, replace the CMOS battery.
2. Run a complete virus scan using up-to-date software to ensure the computer is virus free.
3. If the computer is experiencing HDD or ODD BIOS information loss, disconnect and reconnect the power
and data cables between devices.
If the BIOS settings are still lost, replace the cables.
4. If HDD information is missing from the BIOS, the drive may be defective and should be replaced.
5. Replace the Motherboard.
6. If the Issue is still not resolved, see “Online Support Information” on page 165.
Chapter 4 113
LCD Failure
If the LCD fails, perform the following actions one at a time to correct the problem. Do not replace a non-
defective FRUs:
Built-In Keyboard Failure
If the built-in Keyboard fails, perform the following actions one at a time to correct the problem. Do not replace
a non-defective FRUs:
114 Chapter 4
TouchPad Failure
If the TouchPad doesn’t work, perform the following actions one at a time to correct the problem. Do not
replace a non-defective FRUs:
Internal Speaker Failure
If the internal Speakers fail, perform the following actions one at a time to correct the problem. Do not replace
a non-defective FRUs:
Chapter 4 115
Sound Problems
If sound problems are experienced, perform the following actions one at a time to correct the problem.
1. Reboot the computer.
2. Navigate to Start´ Control Panel´ System and Maintenance´ System´ Device Manager. Check
the Device Manager to determine that:
• The device is properly installed.
• There are no red Xs or yellow exclamation marks.
• There are no device conflicts.
• No hardware is listed under Other Devices.
3. Roll back the audio driver to the previous version, if updated recently.
4. Remove and reinstall the audio driver.
5. Ensure that all volume controls are set mid range:
a. Click the volume icon on the taskbar and drag the slider to 50. Ensure that the volume is not muted.
b. Click Mixer to verify that other audio applications are set to 50 and not muted.
6. Navigate to Start´ Control Panel´ Hardware and Sound´ Sound. Ensure that Speakers are selected
as the default audio device (green check mark).
NOTE: If Speakers does not show, right-click on the Playback tab and select Show Disabled Devices
(clear by default).
7. Select Speakers and click Configure to start Speaker Setup. Follow the onscreen prompts to configure
the speakers.
8. Remove and recently installed hardware or software.
9. Restore system and file settings from a known good date using System Restore.
If the issue is not fixed, repeat the preceding steps and select an earlier time and date.
10. Reinstall the Operating System.
11. If the Issue is still not resolved, see “Online Support Information” on page 165.
Microphone Problems
If internal or external Microphones do no operate correctly, perform the following actions one at a time to
correct the problem.
1. Check that the microphone is enabled. Navigate to Start´ Control Panel´ Hardware and Sound´
Sound and select the Recording tab.
2. Right-click on the Recording tab and select Show Disabled Devices (clear by default).
3. The microphone appears on the Recording tab.
4. Right-click on the microphone and select Enable.
5. Select the microphone then click Properties. Select the Levels tab.
6. Increase the volume to the maximum setting and click OK.
7. Test the microphone hardware:
a. Select the microphone and click Configure.
b. Select Set up microphone.
c. Select the microphone type from the list and click Next.
d. Follow the onscreen prompts to complete the test.
8. If the Issue is still not resolved, see “Online Support Information” on page 165.
116 Chapter 4
HDD Not Operating Correctly
If the HDD does not operate correctly, perform the following actions one at a time to correct the problem.
1. Disconnect all external devices.
2. Run a complete virus scan using up-to-date software to ensure the computer is virus free.
3. Run the Windows 7 Startup Repair Utility:
a. insert the Windows 7 Operating System DVD in the ODD and restart the computer.
b. When prompted, press any key to start to the operating system DVD.
c. The Install Windows screen displays. Click Next.
d. Select Repair your computer.
e. The System Recovery Options screen displays. Click Next.
f. Select the appropriate operating system, and click Next.
NOTE: Click Load Drivers if controller drives are required.
g. Select Startup Repair.
h. Startup Repair attempts to locate and resolve issues with the computer.
i. When complete, click Finish.
If an issue is discovered, follow the onscreen information to resolve the problem.
4. Run the Windows Memory Diagnostic Tool. For more information see Windows Help and Support.
5. Restart the computer and press F2 to enter the BIOS Utility. Check the BIOS settings are correct and that
CD/DVD drive is set as the first boot device on the Boot menu.
6. Ensure all cables and jumpers on the HDD and ODD are set correctly.
7. Remove any recently added hardware and associated software.
8. Run the Windows Disk Defragmenter. For more information see Windows Help and Support.
9. Run Windows Check Disk by entering chkdsk /r from a command prompt. For more information see
Windows Help and Support.
10. Restore system and file settings from a known good date using System Restore.
If the issue is not fixed, repeat the preceding steps and select an earlier time and date.
11. Replace the HDD. See “Disassembly Process” on page 46.
Chapter 4 117
ODD Failure
If the ODD fails, perform the following actions one at a time to correct the problem. Do not replace a non-
defective FRUs:
ODD Not Operating Correctly
If the ODD exhibits any of the following symptoms it may be faulty:
• Audio CDs do not play when loaded
• DVDs do not play when loaded
• Blank discs do not burn correctly
• DVD or CD play breaks up or jumps
• Optical drive not found or not active:
• Not shown in My Computer or the BIOS setup
• LED does not flash when the computer starts up
• The tray does not eject
• Access failure screen displays
• The ODD is noisy
Perform the following general solutions one at a time to correct the problem.
1. Reboot the computer and retry the operation.
2. Try an alternate disc.
3. Navigate to Start´ Computer. Check that the ODD device is displayed in the Devices with Removable
Storage panel.
4. Navigate to Start´ Control Panel´ System and Maintenance´ System´ Device Manager.
118 Chapter 4
a. Double-click lDE ATA/ATAPI controllers. If a device displays a down arrow, right-click on the device
and click Enable.
b. Double-click DVD/CD-ROM drives. If the device displays a down arrow, right-click on the device and
click Enable.
c. Check that there are no yellow exclamation marks against the items in lDE ATA/ATAPI controllers. If
a device has an exclamation mark, right-click on the device and uninstall and reinstall the driver.
d. Check that there are no yellow exclamation marks against the items in DVD/CD-ROM drives. If a
device has an exclamation mark, right-click on the device and uninstall and reinstall the driver.
e. If the exclamation marker is not removed from the item in the lists, try removing any recently installed
software and retrying the operation.
Discs Do Not Play
If discs do not play when inserted in the drive, perform the following actions one at a time to correct the
problem.
1. Check that the disc is correctly seated in the drive tray and that the label on the disc is visible.
2. Check that the media is clean and scratch free.
3. Try an alternate disc in the drive.
4. Ensure that AutoPlay is enabled:
a. Navigate to Start´ Control Panel´ Hardware and Sound´ AutoPlay.
b. Select Use AutoPlay for all media and devices.
c. In the Audio CD and DVD Movie fields, select the desired player from the drop down menu.
5. Check that the Regional Code is correct for the selected media:
IMPORTANT:Region can only be changed a limited number of times. After Changes remaining reaches zero,
the region cannot be changed even Windows is reinstalled or the drive is moved to another computer.
a. Navigate to Start´ Control Panel´ System and Maintenance´ System´ Device Manager.
b. Double-click DVD/CD-ROM drives.
c. Right-click DVD drive and click Properties, then click the DVD Region tab.
d. Select the region suitable for the media inserted in the drive.
Discs Do Not Burn Properly
If discs can not be burned, perform the following actions one at a time to correct the problem.
1. Ensure that the default drive is record enabled:
a. Navigate to Start´ Computer and right-click the writable ODD icon. Click Properties.
b. Select the Recording tab. In the Desktop disc recording panel, select the writable ODD from the
drop down list.
c. Click OK.
2. Ensure that the software used for burning discs is the factory default. If using different software, refer to
the software's user manual.
Playback is Choppy
If playback is choppy or jumps, perform the following actions one at a time to correct the problem.
1. Check that system resources are not running low:
a. Try closing some applications.
b. Reboot and try the operation again.
2. Check that the ODD controller transfer mode is set to DMA:
a. Navigate to Start´ Control Panel´ System and Maintenance´ System´ Device Manager.
Chapter 4 119
b. Double-click IDE ATA/ATAPI controllers, then right-click ATA Device 0.
c. Click Properties and select the Advanced Settings tab. Ensure that the Enable DMA box is
checked and click OK.
d. Repeat for the other ATA Devices shown if applicable.
Drive Not Detected
If Windows cannot detect the drive, perform the following actions one at a time to correct the problem.
1. Restart the computer and press F2 to enter the BIOS Utility.
2. Check that the drive is detected in the ATAPI Model Name field on the Information page.
NOTE: Check that the entry is identical to one of the ODDs specified in “Hardware Specifications and
Configurations” on page 16.
3. Turn off the power and remove the cover to inspect the connections to the ODD. See “Disassembly
Process” on page 46.
a. Check for broken connectors on the drive, motherboard, and cables.
b. Check for bent or broken pins on the drive, motherboard, and cable connections.
c. Try an alternate cable, if available. If the drive works with the new cable, the original cable should be
replaced.
4. Reseat the drive ensuring and all cables are connected correctly.
5. Replace the ODD. See “Disassembly Process” on page 46.
Drive Read Failure
If discs cannot be read when inserted in the drive, perform the following actions one at a time to correct the
problem.
1. Remove and clean the failed disc.
2. Retry reading the CD or DVD.
d. Test the drive using other discs.
e. Play a DVD movie
f. Listen to a music CD
If the ODD works properly with alternate discs, the original disc is probably defective and should be
replaced.
3. Turn off the power and remove the cover to inspect the connections to the ODD. See “Disassembly
Process” on page 46.
a. Check for broken connectors on the drive, motherboard, and cables.
b. Check for bent or broken pins on the drive, motherboard, and cable connections.
c. Try an alternate cable, if available. If the drive works with the new cable, the original cable should be
replaced.
4. Replace the ODD. See “Disassembly Process” on page 46.
120 Chapter 4
Wireless Function Failure
If the WLAN fails, perform the following actions one at a time to correct the problem. Do not replace a non-
defective FRUs:
Thermal Unit Failure
If the Thermal Unit fails, perform the following actions one at a time to correct the problem. Do not replace a
non-defective FRUs:
Chapter 4 121
External Mouse Failure
If an external Mouse fails, perform the following actions one at a time to correct the problem.
1. Try an alternative mouse.
2. If the mouse uses a wireless connection, insert new batteries and confirm there is a good connection. See
the mouse user manual.
3. If the mouse uses a USB connection, try an alternate USB port.
4. Try an alternative program to verify mouse operation. Reinstall the program experiencing mouse failure.
5. Restart the computer.
6. Remove any recently added hardware and associated software.
7. Remove any recently added software and reboot.
8. Restore system and file settings from a known good date using System Restore.
If the issue is not fixed, repeat the preceding steps and select an earlier time and date.
9. Run the Event Viewer to check the events log for errors. For more information see Windows Help and
Support.
10. Roll back the mouse driver to the previous version if updated recently.
11. Remove and reinstall the mouse driver.
12. Check the Device Manager to determine that:
• The device is properly installed. There are no red Xs or yellow exclamation marks.
• There are no device conflicts.
• No hardware is listed under Other Devices.
13. If the Issue is still not resolved, see “Online Support Information” on page 165.
Other Failures
If the CRT Switch, Dock, LAN Port, external MIC or Speakers, PCI Express Card, 5-in-1 Card Reader or
Volume Wheel fail, perform the following general steps to correct the problem. Do not replace a non-defective
FRUs:
1. Check Drive whether is OK.
2. Check Test Fixture is ok.
3. Swap M/B to Try.
122 Chapter 4
Intermittent Problems
Intermittent system hang problems can be caused by a variety of reasons that have nothing to do with a
hardware defect, such as: cosmic radiation, electrostatic discharge, or software errors. FRU replacement
should be considered only when a recurring problem exists.
When analyzing an intermittent problem, do the following:
1. Run the advanced diagnostic test for the system board in loop mode at least 10 times.
2. If no error is detected, do not replace any FRU.
3. If any error is detected, replace the FRU. Rerun the test to verify that there are no more errors.
Undetermined Problems
The diagnostic problems does not identify which adapter or device failed, which installed devices are incorrect,
whether a short circuit is suspected, or whether the system is inoperative.
Follow these procedures to isolate the failing FRU (do not isolate non-defective FRU).
NOTE: Verify that all attached devices are supported by the computer.
NOTE: Verify that the power supply being used at the time of the failure is operating correctly. (See “Power On
Issue” on page 110.):
1. Power-off the computer.
2. Visually check them for damage. If any problems are found, replace the FRU.
3. Remove or disconnect all of the following devices:
• Non-Acer devices
• Printer, mouse, and other external devices
•Battery pack
• Hard disk drive
•DIMM
• CD-ROM/Diskette drive Module
• PC Cards
4. Power-on the computer.
5. Determine if the problem has changed.
6. If the problem does not recur, reconnect the removed devices one at a time until you find the failing FRU.
7. If the problem remains, replace the following FRU one at a time. Do not replace a non-defective FRU:
• System board
• LCD assembly
Chapter 4 123
Post Codes
These tables describe the POST codes and descriptions during the POST.
Code POST Routine Description
02h Verify Real Mode
03h Disable Non-Maskable Interrupt (NMI)
04h Get CPU type
06h Initialize system hardware
08h Initialize chipset with initial POST values
09h Set IN POST flag
0Ah Initialize CPU registers
0Bh Enable CPU cache
0Ch Initialize caches to initial POST values
0Eh Initialize I/O component
Code Beeps POST Routine Description
0Fh Initialize the local bus IDE
10h Initialize Power Management
11h Load alternate registers with initial POST values
12h Restore CPU control word during warm boot
13h Initialize PCI Bus Mastering devices
14h Initialize keyboard controller
16h 1-2-2-3 BIOS ROM checksum
17h Initialize cache before memory autosize
18h 8254 timer initialization
1Ah 8237 DMA controller initialization
1Ch Reset Programmable Interrupt Controller
20h 1-3-1-1 Test DRAM refresh
22h 1-3-1-3 Test 8742 Keyboard Controller
24h Set ES segment register to 4 GB
26h Enable A20 line
28h Autosize DRAM
29h Initialize POST Memory Manager
2Ah Clear 512 KB base RAM
2Ch 1-3-4-1 RAM failure on address line xxxx*
2Eh 1-3-4-3 RAM failure on data bits xxxx* of low byte of memory bus
2Fh Enable cache before system BIOS shadow
30h 1-4-1-1 RAM failure on data bits xxxx* of high byte of memory bus
32h Test CPU bus-clock frequency
33h Initialize Phoenix Dispatch Manager
36h Warm start shut down
38h Shadow system BIOS ROM
3Ah Autosize cache
3Ch Advanced configuration of chipset registers
124 Chapter 4
3Dh Load alternate registers with CMOS values
42h Initialize interrupt vectors
45h POST device initialization
46h 2-1-2-3 Check ROM copyright notice
48h Check video configuration against CMOS
49h Initialize PCI bus and devices
4Ah Initialize all video adapters in system
4Bh QuietBoot start (optional)
4Ch Shadow video BIOS ROM
Code Beeps POST Routine Description
4Eh Display BIOS copyright notice
50h Display CPU type and speed
51h Initialize EISA board
52h Test keyboard
54h Set key click if enabled
58h 2-2-3-1 Test for unexpected interrupts
59h Initialize POST display service
5Ah Display prompt "Press F2 to enter SETUP"
5Bh Disable CPU cache
5Ch Test RAM between 512 and 640 KB
60h Test extended memory
62h Test extended memory address lines
64h Jump to UserPatch1
66h Configure advanced cache registers
67h Initialize Multi Processor APIC
68h Enable external and CPU caches
69h Setup System Management Mode (SMM) area
6Ah Display external L2 cache size
6Bh Load custom defaults (optional)
6Ch Display shadow-area message
6Eh Display possible high address for UMB recovery
70h Display error messages
72h Check for configuration errors
76h Check for keyboard errors
7Ch Set up hardware interrupt vectors
7Eh Initialize coprocessor if present
80h Disable onboard Super I/O ports and IRQs
81h Late POST device initialization
82h Detect and install external RS232 ports
83h Configure non-MCD IDE controllers
84h Detect and install external parallel ports
85h Initialize PC-compatible PnP ISA devices
Code Beeps POST Routine Description
Chapter 4 125
86h Re-initialize onboard I/O ports.
87h Configure Motheboard Configurable Devices (optional)
88h Initialize BIOS Data Area
89h Enable Non-Maskable Interrupts (NMIs)
8Ah Initialize Extended BIOS Data Area
8Bh Test and initialize PS/2 mouse
8Ch Initialize floppy controller
Code Beeps POST Routine Description
8Fh Determine number of ATA drives (optional)
90h Initialize hard-disk controllers
91h Initialize local-bus hard-disk controllers
92h Jump to UserPatch2
93h Build MPTABLE for multi-processor boards
95h Install CD ROM for boot
96h Clear huge ES segment register
97h Fixup Multi Processor table
98h 1-2 Search for option ROMs. One long, two short beeps on checksum
failure
99h Check for SMART Drive (optional)
9Ah Shadow option ROMs
9Ch Set up Power Management
9Dh Initialize security engine (optional)
9Eh Enable hardware interrupts
9Fh Determine number of ATA and SCSI drives
A0h Set time of day
A2h Check key lock
A4h Initialize Typematic rate
A8h Erase F2 prompt
AAh Scan for F2 key stroke
ACh Enter SETUP
AEh Clear Boot flag
B0h Check for errors
B2h POST done - prepare to boot operating system
B4h 1 One short beep before boot
B5h Terminate QuietBoot (optional)
B6h Check password (optional)
B9h Prepare Boot
BAh Initialize DMI parameters
BBh Initialize PnP Option ROMs
BCh Clear parity checkers
BDh Display MultiBoot menu
BEh Clear screen (optional)
Code Beeps POST Routine Description
126 Chapter 4
BFh Check virus and backup reminders
C0h Try to boot with INT 19
C1h Initialize POST Error Manager (PEM)
C2h Initialize error logging
C3h Initialize error display function
Code Beeps POST Routine Description
C4h Initialize system error handler
C5h PnPnd dual CMOS (optional)
C6h Initialize notebook docking (optional)
C7h Initialize notebook docking late
C8h Force check (optional)
C9h Extended checksum (optional)
D2h Unknown interrupt
Code Beeps For Boot Block in Flash ROM
E0h Initialize the chipset
E1h Initialize the bridge
E2h Initialize the CPU
E3h Initialize system timer
E4h Initialize system I/O
E5h Check force recovery boot
E6h Checksum BIOS ROM
E7h Go to BIOS
E8h Set Huge Segment
E9h Initialize Multi Processor
EAh Initialize OEM special code
EBh Initialize PIC and DMA
ECh Initialize Memory type
EDh Initialize Memory size
EEh Shadow Boot Block
EFh System memory test
F0h Initialize interrupt vectors
F1h Initialize Run Time Clock
F2h Initialize video
F3h Initialize System Management Mode
F4h 1 Output one beep before boot
F5h Boot to Mini DOS
F6h Clear Huge Segment
F7h Boot to Full DOS
Code Beeps POST Routine Description
Chapter 5 127
Jumper and Connector Locations
Top View
Item Description Item Description
1 CN2/LED Board conn. 10 Glide PAD Left SW
2 U2,U3/Dis VRAM 11 CN13 Int. SPK. conn. (R)
3 CN6/K/B conn. 12 CN10/Card reader conn.
4 Glide PAD FFC conn. 13 U2/LAN control IC
5 Y1/KBC X’tal 14 CN9/BT wire
6 U10/EC/KBC 15 CN8/Int. SPK. conn. (L)
7 CN12/S/W TJAG DEBUG conn. 16 CN4/LCD wire
8 CNN/USB Board conn. 17 CN3/CAMERA Module conn.
9 Glide PAD Right SW 18 CN1/POWER Board conn.
18
17
16
15
14
13
12
11
10 9
8
7
6
5
4
3
2
1
Chapter 5
128 Chapter 5
Bottom View
Item Description Item Description
1 PJ1 Battery conn. 15 CN25/Line-out/SPDIF
2 U16/U18 Dis VRAM IC. 16 CN24/EXT Mic conn.
3 U24/CPU Socket 17 CN16/USB conn.
4 PJ2/PWR Jack conn. 18 CN9/LAN conn.
5 CN16/ODD conn. 19 U21/LAN transformer
6 U23/System BIOS 20 CN15/HDMI conn.
7 CN18, CN19/Memory DIMM 21 PU11/CPU core
8 CN22/HDD conn. 22 CN11/CRT conn.
9 CN23/Mini card conn. 23 U25/CPU thermal IC
10 U29/SB Chip 24 U28/N.B.
11 PU14/3V/5V PWM IC 25 U39/Sideport Memory
12 Y8/S.B. X’tal 26 U10/Park VGA IC
13 U18 Card Reader IC 27 U39/Sideport Memory
14 U31/Codec IC 28 CN14 FAN conn.
1
2
3
7
8
10
4
5
6
9
1112
1314
24
23
22
25
21
20
19
18
17
16
15
28
27
26
Chapter 5 129
Clearing Password Check and BIOS Recovery
This section provides you with the standard operating procedures of clearing password and BIOS recovery for
the Aspire 4553/4553G. The machine provides one Hardware Open Gap on main board for clearing password
check, and one Hotkey for enabling BIOS Recovery.
Clearing Password Check
Steps for Clearing BIOS Password Check
If users set BIOS Password (Supervisor Password and/or User Password) for a security reason, BIOS will ask
the password during systems POST or when systems enter to BIOS Setup menu. However, once it is
necessary to bypass the password check, users need to short the HW Gap to clear the password by the
following steps:
1. Power Off the system, and remove HDD, AC and Battery from the machine.
2. Remove the RTC Battery cable and locate the R671/R675 jumper.
3. Use an electric conductivity tool to short the two points of the HW Gap.
4. Plug in AC, keeping the HW Gap shorted. Press Power Button utill BIOS POST is finished, then remove
the tool from the HW Gap.
5. Restart the system. Press F2 key to enter BIOS Setup menu.
6. If there is no Password request, BIOS Password is cleared. Otherwise, please follow the steps and try
again.
NOTE: These steps are only for clearing BIOS Password (Supervisor Password and User Password).
Clear CMOS Jumper
Item Description
G1 Clear CMOS Jumper
130 Chapter 5
BIOS Recovery by Crisis Disk
BIOS Recovery Boot Block:
BIOS Recovery Boot Block is a special block of BIOS. It is used to boot up the system with minimum BIOS
initialization. Users can enable this feature to restore the BIOS firmware to a successful one once the previous
BIOS flashing process failed.
BIOS Recovery Hotkey:
The system provides a function hotkey: Fn+Esc, to enable the BIOS Recovery process when the system is
powered on during BIOS POST. To use this function, it is strongly recommended to have the AC adapter and
Battery present. If this function is enabled, the system will force the BIOS to enter a special BIOS block, called
Boot Block.
Steps for BIOS Recovery from USB Storage:
Before doing this, prepare the Crisis USB key. The Crisis USB key could be made by executing the Crisis Disk
program in another system with Windows 7 OS.
Follow the steps below:
1. Insert a USB stick/floppy.
2. Execute WINCRIS.exe and click Start to create the crisis disk.
3. Plug USB storage into USB port of the system that needs to be rescued.
4. Press Fn + ESC and the power button to power on the system.
5. The system will go into crisis mode and recover BIOS.
Chapter 6 131
FRU (Field Replaceable Unit) List
This chapter gives you the FRU (Field Replaceable Unit) listing in global configurations of Aspire 4553/4553G. Refer to this
chapter whenever ordering for parts to repair or for RMA (Return Merchandise Authorization).
Please note that WHEN ORDERING FRU PARTS, you should check the most up-to-date information available on your
regional web or channel. For whatever reasons a part number change is made, it will not be noted on the printed Service
Guide. For ACER AUTHORIZED SERVICE PROVIDERS, your Acer office may have a DIFFERENT part number code from
those given in the FRU list of this printed Service Guide. You MUST use the local FRU list provided by your regional Acer
office to order FRU parts for repair and service of customer machines.
NOTE: To scrap or to return the defective parts, you should follow the local government ordinance or regulations on how to
dispose it properly, or follow the rules set by your regional Acer office on how to return it.
Chapter 6
132 Chapter 6
Aspire 4553/4553G Exploded Diagrams
LCD Assembly
No. Description Acer P/N No. Description Acer P/N
1 ZQ1 LCD COVER
SUB ASSY (AL/3G) 60.PSR07.003 7 CABLE ASSY
ZQ1LCD(19V,40/
30P,WXGA,1A)FOX
50.PSR07.002
2 CAMERA
CNF915721004970L
H(CMOS, 1.3M,
SXGA)
AM.21400.067 8 SCREW M2.0*3.0-
I(BKAG)(NYLOK)
IRON
86.ARE07.002
3 LCD AUO 14”
WXGA LK.14005.011 9 HINGE L SZS ZQ1 33.PSR07.002
1
2
3
4
5
6
7
8
10
11
9
Chapter 6 133
Chassis Assembly
4 ZQ1 LCD BEZEL
SUB ASSY 60.PSR07.004 10 SCREW
M2.5*3.0(ZN)(NYLOK)
IRON T=0.5‘
86.PSR07.002
5 LCD SCREW
MYLAR ZQ1 47.PSR07.004 11 HINGE R SZS ZQ1 33.PSR07.003
6 SCREW M2.5*3.0-
I(ZN)(NYLOK)IRON
T=0.5
86.PSR07.003
No. Description Acer P/N No. Description Acer P/N
1 ZQ1 TOP SUB
ASSY 60.PSR07.001 15 PCB ZQ1 SW/
B(4L,44*14,REVD) N/A
2PCB ZQ1 POWER
SW/
B(4L,59*22,REVD)
55.PSR07.001 16 BATT LI,AS10B6E
3S2P 6.0A(B) STN
BSQ
BT.00606.007
3 ZQ1 BASE SUB
ASSY (JM/65W) 60.PSR07.002 17 SCREW M2.0*3.0-
I(BKAG)(NYLOK)
IRON
86.ARE07.002
4 ZQ1 BASE DOOR
ASSY (JM/CP) 42.PSR07.001 18 K/
B(UI)ZQ1(AEZQ1R00,
3A)API
5 SCREW M2.5*6.5-
I(BZN(NYLOK-
RED)D4.4 T0.8
86.ARE07.001 14 SCREW M2.5*2-I
(NI,NYLOK)IRON 86.EDM07.002
6 ZQ1 USB/B ASSY 55.PSR07.002 19 SCREW M2.5*4.0-
I(BKAG)(NYLOK)IRO
N
86.PSR07.001
No. Description Acer P/N No. Description Acer P/N
1
2
3
4
5
67 8
9
10
11
12
13
14
15
16
17
18
19
20
21
26
25
24
23
22
134 Chapter 6
7 HDD-BKT
ZR6(FBZR6004,REV
3A)
33.EDM07.001 20 ZQ1
MB(SG,PARK,SAM,BT
,WO CPU)ASSY
N/A
8 HDD(160G)WD1600
BEVT-22A23T0 STN
BSQ
KH.16008.027 21 WWAN MINICARD
EM770W
FW:11.126.07.02.00
N/A
9 33ZQ1UB0000 N/A 22 CARD READER
DUMMY CARD
ZR7(EBZR7009,R3A)
42.PSR07.002
10 3GZR7CRTN10 42.PSR07.003 23 CPU(988P)I5-520M
2.4G
SLBNB(PGA)STN
BSQ
KC.54001.DMP
11 DVD/RW/RAM TS-
U633F F/W:AC00
STN BSQ
KU.0080E.027 24 RAM(2GB)DDR3
EBJ21UE8BDS0-AE-F
STN BSQ
KN.2GB09.006
12 ODD BKT
ZQ1(FBZQ1016,RE
V3A)
33.PSR07.001 25 W/L 802.11BGN
112BN.HMWG 1X2
STN BSQ
NI.23600.047
13 ZQ1 3G/B ASSY 55.PSR07.004 26 WWAN MINICARD
EM770W
FW:11.126.07.02.00
N/A
No. Description Acer P/N No. Description Acer P/N
Chapter 6 135
FRU List
Category Partname Description P/N
Adapter
Adapter DELTA 65W 19V
1.7x5.5x11 Yellow ADP-65JH DB
A, LV5 LED LF
Z06 ADP 19V 3.42A
ADP-65JH DBA S.P AP.06501.026
Adapter LITE-ON 65W 19V
1.7x5.5x11 Yellow PA-1650-22AC
LV5 LED LF
Z06 ADP 19V 3.42A
PA-1650-22 AC S.P AP.06503.024
Adapter HIPRO 65W 19V
1.7x5.5x11 Yellow HP-A0652R3B
1LF, LV5 LED LF
Z06 ADP 19V
3.42AHP-
A0652R3B1LF S.P
AP.0650A.012
Adapter DELTA 90W 19V
1.7x5.5x11 Blue ADP-90CD DB
A, LV5 LED LF
ZK6 ADP 19V 4.74A
ADP-90CD DBA S.P AP.09001.027
Adapter LITE-ON 90W 19V
1.7x5.5x11 Blue PA-1900-34AR,
LV5 LED LF
ZK6 ADP 19V 4.74A
PA-1900-34AR S.P AP.09003.021
Adapter HIPRO 90W 19V
1.7x5.5x11 Blue HP-A0904A3
B1LF, LV5 LED LF
ZK6 ADP 19V
4.74AHP-
A0904A3B1LF S.P
AP.0900A.005
Battery
Battery SANYO AS10B Li-Ion
3S2P SANYO 6 cell 4400mAh
Main COMMON ID:AS10B31
ZQ1 BATT
LI,AS10B31 3S2P
4.4A(B)S.P
BT.00603.110
Battery SONY AS10B Li-Ion 3S2P
SONY 6 cell 4400mAh Main
COMMON ID:AS10B41
ZQ1 BATT
LI,AS10B41 3S2P
4.4A(B)S.P
BT.00604.048
Battery PANASONIC AS10B Li-
Ion 3S2P PANASONIC 6 cell
4400mAh Main COMMON
ID:AS10B51
ZQ1 BATT
LI,AS10B51 3S2P
4.4A(B)S.P
BT.00605.061
Battery SAMSUNG AS10B Li-Ion
3S2P SAMSUNG 6 cell 4400mAh
Main COMMON ID:AS10B61
ZQ1 BATT
LI,AS10B61 3S2P
4.4A(B)S.P
BT.00606.007
Battery SIMPLO AS10B Li-Ion
3S2P PANASONIC 6 cell
4400mAh Main COMMON
ID:AS10B71
ZQ1 BATT
LI,AS10B71 3S2P
4.4A(B)S.P
BT.00607.122
Battery SIMPLO AS10B Li-Ion
3S2P LGC 6 cell 4400mAh Main
COMMON ID:AS10B73
ZQ1 BATT
LI,AS10B73 3S2P
4.4A(B)S.P
BT.00607.123
Battery SIMPLO AS10B Li-Ion
3S2P SAMSUNG 6 cell 4400mAh
Main COMMON ID:AS10B75
ZQ1 BATT
LI,AS10B75 3S2P
4.4A(B)S.P
BT.00607.124
136 Chapter 6
Boards
Foxconn Wireless LAN Atheros
HB93 2x2 BGN (HM) ZY6 W/L 802.11 B/
G/N H
MINI(T77H047.31)
S.P
NI.23600.062
TBD ZQ2 W/L MINICARD
802.11BGN(T77H16
7.07)S.P
TBD
TBD ZQ2 W/L MINICARD
802.11BG(T77H121.
10)S.P
TBD
Foxconn Wireless LAN
Broadcomm 43225 2x2 BGN
(HM) T77H103.00
ZQ2 W/L 802.11 B/
G/N T77H103.00S.P NI.23600.066
USB MODEM ZR7 USB
MODEM,D-
1156UA9B S.P
54.PTN07.001
Foxconn Bluetooth FOX BRM
2046 BT2.1 ZY9 BLUETOOTH
T60H928.33 S.P BH.21100.004
BLUETOOTH MODULE
MT77H056.00 ZQ1 BLUETOOTH
MODULE
MT77H056.00 S.P
TBD
POWER SWITCH BOARD ZQ1 POWER SW/B
S.P 55.PSR07.001
USB BOARD ZQ1 USB/B S.P 55.PSR07.002
FUNCTION BOARD ZQ1 SW/B S.P 55.PSR07.003
Cables
PWR CORD V943B30001218008
DANISH 3P ZR1 PWR CORD
V943B30001218008
DANISH S/P
27.A03V7.006
PWR CORD(ISR)1.8M 3PBLK
FZ0I0008-038 ZR1 PWR
CORD(ISR)1.8M
3PBLK S/P
27.TATV7.005
PWR CORD
V50CB3T3012180QD TW-
110V,3P
ZR1 PWR CORD
V50CB3T3012180Q
D TW S/P
27.A99V7.002
POWER CORD(SWI)1.8M
3PBLACK FZ010008-011 ZR1 POWER
CORD(SWI)1.8M
3PBLACK S/P
27.A99V7.004
POWER CORD(IT) 1.8M
3PBLACK FZ010008-008 ZR1 POWER
CORD(IT) 1.8M 3P
S/P
27.A99V7.005
POWER CORD(S.A) 1.8M
3BLACK FZ010008-006 ZR1 POWER
CORD(S.A) 1.8M
3BLACK S/P
27.T48V7.001
Category Partname Description P/N
Chapter 6 137
POWER CORD US 3PIN ROHS ZB1 PWR CORD US
S/P 27.TAXV7.001
POWER CORD(EU) 1.8M
3PBLACK FM010008-010 ZR1 POWER
CORD(EU) 1.8M
3PBLACK S/P
27.TATV7.001
POWER CORD BRAZIL IMETRO
3 PIN BL3 POWER CORD
BRAZIL 3P S/P 27.S0607.001
POWER CORD UK 3PIN ET2S POWER
CORD S/P-UK 27.A03V7.004
POWER CORD ITALIAN 3PIN EI2 POWER CORD
3P ITALY S.P. 27.A99V7.005
POWER CORD PRC 3P
Y536B30001218008 EW1 POWER
CORD S.P.
(CHINESE)
27.TATV7.004
BLUETOOTH CABLE ZQ1 BLUETOOTH
CABLE ASSY(5P/
8P,1A)S.P
50.PSR07.001
DC-IN CABLE 90W ZQ1 DC-IN CABLE
90W(4P/4P,1A)19V
S.P
50.PSR07.006
DC-IN CABLE 65W ZQ1 DC-IN CABLE
65W(4P/4P,1A)19V
S.P
50.PSR07.005
FFC CABLE - MB TO POWER/B
IN UPPER CASE ZQ1 CABLE FFC
POWER
(118MM,12P,1A)3V
S.P
50.PSR07.007
FFC CABLE - MB TO TP IN
UPPER CASE ZQ1 CABLE FFC TP
(110MM,12P,1A)3V
S.P
50.PSR07.008
FFC CABLE - MB TO FUNC/B IN
UPPER CASE ZQ1 CABLE FFC
FUNC
(150MM,6P,1A)3V
S.P
50.PSR07.009
ZQ1 CABLE FFC-
MB-USB(146MM,
20P,3A)3V S.P
CABLE ASSY
MIC(5P/8P,1A)3.3V
Case/Cover/Bracket Assembly
UPPER CASE(W/FFC*3,TP,TP
BD,SPK-L) ZQ2 TOP SUB
ASSY(JV) S.P 60.PSK07.001
LOWER CASE(W/DC JACK,USB
CABLE,SPK-R,FOR 65W) ZQ2 BASE SUB
ASSY(JV/65W)S.P 60.PSU07.001
LOWER CASE(W/DC JACK,USB
CABLE,SPK-R,FOR 90W) ZQ2 BASE SUB
ASSY(JV/90W)S.P 60.PSK07.002
BASE COVER ZQ2 BASE DOOR
ASSY (JV/DN)S.P 42.PSK07.001
DUMMY CARD ZQ1 READER
DUMMY CARD S.P 42.PSR07.002
Category Partname Description P/N
138 Chapter 6
CPU/Processor
CPU AMD AthlonII N330 2.3G 1M
35W Dual-Core ZQ2
CPU(638P)AMN330
DCR22GM
2.3G(PGA)S.P
KC.AN002.330
CPU AMD TurionII N530 2.5G 2M
35W Dual-Core ZQ2
CPU(638P)TMN530
DCR23GM
2.5G(PGA)S.P
KC.TN002.530
CPU AMD PhenomII N830 2.1G
35W 1.5M L2, Triple-Core ZQ2
CPU(638P)HMN830
DCR32GM
2.1G(PGA)S.P
KC.PN002.830
CPU AMD PhenomII N930 2.0G
2M 35W Quad-Core ZQ2
CPU(638P)HMN930
DCR42GM
2.0G(PGA)S.P
KC.PN002.930
CPU AMD AthlonII P320 2.1G 1M
25W Dual-Core ZQ2
CPU(638P)AMP320
SGR22GM
2.1G(PGA)S.P
KC.AP002.320
CPU AMD TurionII P520 2.3G 2M
25W Dual-Core ZQ2
CPU(638P)TMP520
SGR23GM
2.3G(PGA)S.P
KC.TP002.520
ODD Super Multi
ODD SUPER MULTI MODULE
ASSY TRAY 8X DL SM 12.7mm(JV)
Module 6M.PSR07.001
ODD TOSHIBA Super-Multi
DRIVE 12.7mm Tray DL 8X TS-
L633C LF W/O bezel SATA (HF +
Windows 7)
ZY9 DVD+/-RW
SATA TS-L633C S.P KU.00801.035
ODD PANASONIC Super-Multi
DRIVE 12.7mm Tray DL 8X
UJ890A LF W/O bezel SATA (HF
+ Windows 7)
ZQ1 DVDRW SATA
SM+DL
UJ890ADAA-A S.P
KU.00807.070
ODD HLDS Super-Multi DRIVE
12.7mm Tray DL 8X GT30N LF
W/O bezel SATA (HF + Windows
7)
ZY7 DVD+/-RW/
RAM GT30N S.P KU.0080D.048
ODD SONY Super-Multi DRIVE
12.7mm Tray DL 8X AD-7585H
LF W/O bezel SATA (HF +
Windows 7)
ZY9 DVD/RW/RAM
AD-7585H S.P KU.0080E.027
ODD PLDS Super-Multi DRIVE
12.7mm Tray DL 8X DS-8A4SH
LF W/O bezel SATA (HF +
Windows 7)
ZY9 DVD/RW/RAM
DS-8A4SH F/W:
CA11 S.P
KU.0080F.006
ODD HLDS Super-Multi DRIVE
12.7mm Tray DL 8X GT31N (R5-
1) LF W/O bezel SATA with
Renesas Solution (HF + Windows
7)
ZQ1 DVD+/-RW/
RAM GT31N S.P KU.0080D.054
Category Partname Description P/N
Chapter 6 139
ODD BEZEL -SUPER MULTI ZR8 ODD BEZEL
SUPER MULTI S.P 42.PSR07.003
ODD BRACKET ZQ1 ODD BKT
(FBZQ1016,REV3A)
S.P
33.PSR07.001
BD Combo Drive
ODD BD COMBO MODULE
ASSY 4X BLUE RAY COMBO
12.7mm Module 6M.PSR07.002
ODD HLDS BD COMBO 12.7mm
Tray DL 4X CT21N LF W/O bezel
1.00 SATA (HF + Windows 7)
ZQ1 DVD/RW SATA
BD-COMBO CT21N
F/W:1.00 S.P
KO.0040D.004
ODD SONY BD COMBO 12.7mm
Tray DL 4X BC-5500H LF W/O
bezel SATA (HF + Windows 7)
ZQ1 DVD/RW BD-
COMBO BC-5500H-
AR FW:1.B0 S.P
KO.0040E.003
ODD PLDS BD COMBO 12.7mm
Tray DL 4X DS-4E1S LF W/O
bezel SATA (Windows 7)
ZY9 BLUE RAY
COMBO DS-4E1S
FW: EA17 S.P
KO.0040F.003
ODD BEZEL - BD COMBO ZR8 ODD BEZEL
BD COMBO ASSY
S.P
42.PSR07.004
ODD BRACKET ZQ1 ODD BKT
(FBZQ1016,REV3A)
S.P
33.PSR07.001
BD Combo Drive
ODD BD RW MODULE ASSY 4X BD RW 6M.PSR07.003
ODD PANASONIC BD RW
12.7mm Tray DL 4X UJ240A LF
W/O bezel SATA (HF+Windows 7)
ZQ1 DVD BLUE
RAY+RW
UJ240ABAA-A S.P
KU.00407.015
ODD BEZEL - BD COMBO ZR8 ODD BEZEL
BD COMBO ASSY
S.P
42.PSR07.004
ODD BRACKET ZQ1 ODD BKT
(FBZQ1016,REV3A)
S.P
33.PSR07.001
HDD
HDD WD 2.5" 5400rpm 160GB
WD1600BEVT-22A23T0 , WD,
ML320S SATA 8MB LF F/
W:01.01A01
ZQ1
HDD(160G)WD1600
BEVT-22A23T0 S.P
KH.16008.027
HDD SEAGATE 2.5" 5400rpm
160GB ST9160314AS Wyatt
SATA LF F/W:0001SDM1
ZH7
HDD(160G)ST9160
314AS 9HH13C-188
STN BSQ
KH.16001.042
HDD TOSHIBA 2.5" 5400rpm
160GB MK1665GSX, Capricorn
BS, 320G/P SATA 8MB LF F/
W:GJ001J
ZQ1 HDD(160G)
MK1665GSX-EUL
S.P
KH.16004.008
Category Partname Description P/N
140 Chapter 6
HDD HGST 2.5" 5400rpm 160GB
HTS545016B9A300 Panther B
SATA LF F/W:C60F Disk
imbalance criteria = 0.014g-cm
ZH7 HDD(160G)
HTS545016B9A300
S.P
KH.16007.026
HDD WD 2.5" 5400rpm 250GB
WD2500BEVT-22A23T0, WD,
ML320S SATA 8MB LF F/
W:01.01A01.
ZQ1
HDD(250G)WD2500
BEVT-22A23T0 S.P
KH.25008.025
HDD SEAGATE 2.5" 5400rpm
250GB ST9250315AS Wyatt
SATA LF F/W:0001SDM1
Z06
HDD(250G)ST9250
315AS 9HH132-188
S.P
KH.25001.016
HDD TOSHIBA 2.5" 5400rpm
250GB MK2565GSX, Capricorn
BS, 320G/P SATA 8MB LF F/
W:GJ001J
ZQ1 HDD(250G)
MK2565GSX-EUL
S.P
KH.25004.005
HDD HGST 2.5" 5400rpm 250GB
HTS545025B9A300 Panther B
SATA LF F/W:C60F Disk
imbalance criteria = 0.014g-cm
ZH7
HDD(250G)HTS545
025B9A300 S.P
KH.25007.016
HDD WD 2.5" 5400rpm 320GB
WD3200BEVT-
22A23T0,ML320S,WD SATA 8MB
LF F/W:01.01A01
ZQ1
HDD(320G)WD3200
BEVT-22A23T0 S.P
KH.32008.019
HDD SEAGATE 2.5" 5400rpm
320GB ST9320325AS Wyatt
SATA LF F/W:0001SDM1
ZH7
HDD(320G)ST9320
325AS 9HH13E-188
S.P
KH.32001.017
HDD TOSHIBA 2.5" 5400rpm
320GB Capricorn BS
,MK3265GSX SATA 8MB LF F/
W:GJ001J
ZQ1 HDD(320G)
MK3265GSX-EUL
S.P
KH.32004.004
HDD HGST 2.5" 5400rpm 320GB
HTS545032B9A300 Panther B
SATA LF F/W:C60F Disk
imbalance criteria = 0.014g-cm
ZH7 HDD(320G)
HTS545032B9A300
S.P
KH.32007.008
HDD WD 2.5" 5400rpm 500GB
WD5000BEVT-22A0RT0,
ML320M,WD SATA 8MB LF F/
W:01.01A01
ZQ1
HDD(500G)WD5000
BEVT-22A0RT0 S.P
KH.50008.017
HDD SEAGATE 2.5" 5400rpm
500GB ST9500325AS Wyatt
SATA LF F/W:0001SDM1
ZK2 HDD(500G)
ST9500325AS S.P KH.50001.011
HDD TOSHIBA 2.5" 5400rpm
500GB MK5065GSX,Capricorn
BS, 320G/P SATA 8MB LF F/
W:GJ001J
ZQ1 HDD(500G)
MK5065GSX-EUL
S.P
KH.50004.002
HDD HGST 2.5" 5400rpm 500GB
HTS545050B9A300 Panther B
SATA LF F/W:C60F Disk
imbalance criteria = 0.014g-cm
ZH7 HDD(500G)
HTS545050B9A300
S.P
KH.50007.010
Category Partname Description P/N
Chapter 6 141
HDD WD 2.5" 5400rpm 640GB
WD6400BEVT-22A0RT0, ML320
SATA 8MB LF F/W:01.01A01
ZY9
HDD(640GB)WD64
00BEVT-22A0RT0
S.P
KH.64008.004
ZQ2 HDD (640G)
MK6465GSX-
EULS.P
HDD BRACKET ZR6 HDD-BKT S.P 33.EDM07.001
Keyboard
Keyboard ACER AC4T_A10B
AC4T 86KS Black Arabic Texture ZQ1 K/B(ARAB-EN)
S.P KB.I140A.204
Keyboard ACER AC4T_A10B
AC4T 87KS Black Belgium
Texture
ZQ1 K/B(BELGIUM)
S.P KB.I140A.205
Keyboard ACER AC4T_A10B
AC4T 87KS Black Brazilian
Portuguese Texture
ZQ1 K/B(BRAZIL)
S.P KB.I140A.206
Keyboard ACER AC4T_A10B
AC4T 87KS Black CZ/SK Texture ZQ1 K/B(CZ-
SLOVAK) S.P KB.I140A.207
Keyboard ACER AC4T_A10B
AC4T 86KS Black Chinese
Texture
ZQ1 K/B(TAIWAN)
S.P KB.I140A.208
Keyboard ACER AC4T_A10B
AC4T 87KS Black Danish Texture ZQ1 K/B(DANISH)
S.P KB.I140A.209
Keyboard ACER AC4T_A10B
AC4T 87KS Black FR/Arabic
Texture
ZQ1 K/B(ARAB-FR)
S.P KB.I140A.210
Keyboard ACER AC4T_A10B
AC4T 87KS Black French Texture ZQ1 K/B(FRENCH)
S.P KB.I140A.211
Keyboard ACER AC4T_A10B
AC4T 87KS Black German
Texture
ZQ1 K/B(GERMAN)
S.P KB.I140A.212
Keyboard ACER AC4T_A10B
AC4T 86KS Black Greek Texture ZQ1 K/B(GREEK)
S.P KB.I140A.213
Keyboard ACER AC4T_A10B
AC4T 87KS Black Hungarian
Texture
ZQ1 K/
B(HUNGARIAN) S.P KB.I140A.214
Keyboard ACER AC4T_A10B
AC4T 87KS Black Italian Texture ZQ1 K/B(ITALIAN)
S.P KB.I140A.215
Keyboard ACER AC4T_A10B
AC4T 91KS Black Japanese
Texture
ZQ1 K/B(JAPAN)
S.P KB.I140A.216
Keyboard ACER AC4T_A10B
AC4T 86KS Black Korean Texture ZQ1 K/B(KOREA)
S.P KB.I140A.217
Keyboard ACER AC4T_A10B
AC4T 87KS Black Nordic Texture ZQ1 K/B(NORDICS)
S.P KB.I140A.218
Category Partname Description P/N
142 Chapter 6
Keyboard ACER AC4T_A10B
AC4T 87KS Black Norwegian
Texture
ZQ1 K/
B(NORWEGIAN)
S.P
KB.I140A.219
Keyboard ACER AC4T_A10B
AC4T 87KS Black Portuguese
Texture
ZQ1 K/
B(PORTUGUESE)
S.P
KB.I140A.220
Keyboard ACER AC4T_A10B
AC4T 86KS Black Russian
Texture
ZQ1 K/B(RUSSIAN)
S.P KB.I140A.221
Keyboard ACER AC4T_A10B
AC4T 87KS Black SLO/CRO
Texture
ZQ1 K/
B(CROATIAN) S.P KB.I140A.222
Keyboard ACER AC4T_A10B
AC4T 87KS Black Spanish
Texture
ZQ1 K/B(SPANISH)
S.P KB.I140A.223
Keyboard ACER AC4T_A10B
AC4T 87KS Black Sweden
Texture
ZQ1 K/B(SWEDISH)
S.P KB.I140A.224
Keyboard ACER AC4T_A10B
AC4T 87KS Black Swiss/G
Texture
ZQ1 K/B(SWISS)
S.P KB.I140A.225
Keyboard ACER AC4T_A10B
AC4T 86KS Black Thailand
Texture
ZQ1 K/B(THAI) S.P KB.I140A.226
Keyboard ACER AC4T_A10B
AC4T 87KS Black Turkish Texture ZQ1 K/B(TURKISH)
S.P KB.I140A.227
Keyboard ACER AC4T_A10B
AC4T 87KS Black UK Texture ZQ1 K/B(UK) S.P KB.I140A.228
Keyboard ACER AC4T_A10B
AC4T 86KS Black US
International Texture
ZQ1 K/B(UI) S.P KB.I140A.229
Keyboard ACER AC4T_A10B
AC4T 86KS Black US
International w/ Hebrew Texture
ZQ1 K/B(HEBREW)
S.P KB.I140A.230
Keyboard ACER AC4T_A10B
AC4T 87KS Black US w/
Canadian French Texture
ZQ1 K/B(US-FR-
CAN) S.P KB.I140A.231
ZQ1 K/B(CHINA)
S.P
ZQ1 K/B(SLOVAK)
S.P
ZQ1 K/B(CZECH)
S.P
ZQ1 K/B(POLAND)
S.P
ZQ1 K/B(DUTCH)
S.P
ZQ1 K/B(FRA-CAN)
S.P
ZQ1 K/B(LATIN) S.P
Category Partname Description P/N
Chapter 6 143
ZQ1 K/B(US)S.P
ZQ1 K/B(ICELAND)
S.P
LCD Module
LCD MODULE ASSY IMR W/
MIC,CCD CABLE,WLAN
ANTENNA*2 FOR NON-3G
LCD IMR/WO 3G JV 6M.PSK07.001
LED LCD AUO 14" WXGA Glare
B140XW03 V0 LF 200nit 8ms
500:1 (Power saving)
ZQ1 LCD 14'' HD
B140XW03 V0 (0A)
S.P
LK.14005.011
LED LCD LPL 14" WXGA Glare
LP140WH2-TLL1 LF 200nit 16ms
500:1 (Power saving)
ZQ1 LCD 14'' HD
LP140WH2-TLL1
S.P
LK.14008.006
LED LCD CMO 14" WXGA Glare
N140B6-L24 LF 200nit 8ms 650:1
(Power saving)
ZQ1 LCD 14'' HD
N140B6-L24 S.P LK.1400D.007
LED LCD SAMSUNG 14" WXGA
Glare LTN140AT12-A01 LF 200nit
16ms 500:1 (Power saving)
ZQ1 LCD 14" HD
LTN140AT12-A01
S.P
LK.14006.012
HINGE - L ZQ2 HINGE L S.P 60.PSK07.003
HINGE - R ZQ2 HINGE R S.P 60.PSK07.004
LCD CABLE ZQ1 LCD
CABLE(19V,40/
30P,WXGA,1A) S.P
50.PSR07.002
LCD COVER ASSY IMR W/MIC,
CCD CABLE,ANTENNA*2,
HINGE CAP
ZQ1 LCD COVER
SUB (IMR/
WO3G)S.P
60.PSR07.003
LCD BEZEL ASSY W/CCD ZQ1 LCD BEZEL
SUB S.P 60.PSR07.004
Suyin 1.3M SY9665SN ZQ1 CAMERA
09P2BF127 S.P AM.21400.068
Chicony 1.3M CH9665SN
(CNF9157) ZQ1 CAMERA
CNF915721004970
LH S.P
AM.21400.067
Liteon 1.3M LT9665AL
(09P2SF119) ZQ1 CAMERA
09P2SF119 S.P AM.21400.069
Liteon 1.3M LT6AASP(
09P2BF127) ZQ1 CAMERA
09P2BF127 S.P AM.21400.070
Mainboard
MB AMD UMA W/CARD
READER W/O CPU ZQ2
MB(AMD,UMA,W/O
CPU)S.P
MB.PSU06.001
MB AMD PARK W/CARD
READER W/O CPU ZQ2
MB(AMD,PARK,ATI,
W/O CPU)S.P
MB.PSK06.001
Category Partname Description P/N
144 Chapter 6
ZQ2B 6L JM MB (W/
GRN,SAM,W/O
CPU)ASSY
ZQ2B 6L JM MB (W/
GRN,W/O
CPU,VRAM)ASSY
ZQ2B 6L JM MB
(SAM,W/O
CPU,GRN)ASSY
ZQ2B 6L JM MB (W/
O
CPU,GRN,VRAM)A
SSY
ZQ2B 6L JM MB (W/
GRN,HYU,W/O
CPU)ASSY
ZQ2B 6L JM MB
(HYU,W/O
CPU,GRN)ASSY
ZQ2B 6L JV MB (W/
GRN,SAM,W/O
CPU)ASSY
ZQ2B 6L JV MB (W/
GRN,W/O
CPU,VRAM)ASSY
ZQ2B 6L JV MB
(SAM,W/O
CPU,GRN)ASSY
ZQ2B 6L JV MB (W/
O
CPU,GRN,VRAM)A
SSY
ZQ2B 6L JV MB (W/
GRN,HYU,W/O
CPU)ASSY
ZQ2B 6L JV MB
(HYU,W/O
CPU,GRN)ASSY
Category Partname Description P/N
Chapter 6 145
Memory
Memory ELPIDA SO-DIMM
DDRIII 1066 1GB
EBJ10UE8BDS0-AE-F LF 128*8
0.065um
ZE8
RAM(1GB)DDR3
EBJ10UE8BDS0-
AE-F S.P
KN.1GB09.012
Memory SAMSUNG SO-DIMM
DDRIII 1066 1GB
M471B2873EH1-CF8 LF 64*16
0.055um
ZR6 RAM(1G)DDR3
M471B2873EH1-
CF8 S.P
KN.1GB0B.028
Memory HYNIX SO-DIMM DDRIII
1066 1GB HMT112S6BFR6C-G7
N0 LF 64*16 0.055um
ZE9
RAM(1GB)DDR3
HMT112S6BFR6C
N0 LF S.P
KN.1GB0G.025
Memory ELPIDA SO-DIMM
DDRIII 1333 1GB
EBJ10UE8BDS0-DJ-F LF 128*8
0.065um
ZQ1
RAM(1GB)DDR3
EBJ10UE8BDS0-
DJ-F S.P
KN.1GB09.015
Memory SAMSUNG SO-DIMM
DDRIII 1333 1GB
M471B2873FHS-CH9 LF 128*8
46nm
ZQ1
RAM(1GB)DDR3
M471B2873FHS-
CH9 S.P
KN.1GB0B.035
Memory ELPIDA SO-DIMM
DDRIII 1066 2GB
EBJ21UE8BDS0-AE-F LF 128*8
0.065um
ZE8
RAM(2GB)DDR3
EBJ21UE8BDS0-
AE-F S.P
KN.2GB09.006
Memory SAMSUNG SO-DIMM
DDRIII 1066 2GB
M471B5673EH1-CF8 LF 128*8
0.055um
ZR6
RAM(2GB)DDR3
M471B5673EH1-
CF8 S.P
KN.2GB0B.012
Memory HYNIX SO-DIMM DDRIII
1066 2GB HMT125S6BFR8C-G7
N0 LF 128*8 0.055um
ZK6
RAM(2GB)DDR3
HMT125S6BFR8C-
G7 S,P
KN.2GB0G.014
Memory ELPIDA SO-DIMM
DDRIII 1333 2GB
EBJ21UE8BDS0-DJ-F LF 128*8
0.065um
ZQ1
RAM(2GB)DDR3
EBJ21UE8BDS0-
DJ-F S.P
KN.2GB09.007
Memory ELPIDA SO-DIMM
DDRIII 1333 4GB
EBJ41UF8BAS0-DJ-F LF 256*8
0.055um
ZQ1
RAM(4GB)DDR3
EBJ41UF8BAS0-
DJ-F S.P
KN.4GB09.001
Memory SAMSUNG SO-DIMM
DDRIII 1333 4GB
M471B5273CH0-CH9 LF 256*8
46nm
ZQ2
RAM(4GB)DDR3
M471B5273CH0-
CH9S.P
KN.4GB0B.010
Memory NANYA SO-DIMM
DDRIII 1333 2GB
NT2GC64B8HC0NS-CG LF
128*8 0.065um
ZQ2
RAM(2GB)DDR3
NT2GC64B8HC0NS
-CG S.P
KN.2GB03.017
Category Partname Description P/N
146 Chapter 6
Heatsink
THERMAL MODULE - DIS ZQ2 THERMAL
MODULE 35W
DISS.P
60.PSH07.004
THERMAL MODULE - UMA ZQ2 THERMAL
MODULE 35W
UMA S.P
60.PSS07.002
HEAT SINK ZQ2 HEAT SINK
PCH(FBZQ2005,RE
V3A)S.P
60.PSH07.005
SPEAKER L ZQ1 SPK
ASSY(WITH L) S.P 23.PSR07.001
SPEAKER R ZQ1 SPK
ASSY(WITH R) S.P 23.PSR07.002
SPEAKER L ZQ1B SPK
ASSY(WITH L) S.P 23.PSN07.001
SPEAKER R ZQ1B SPK
ASSY(WITH R) S.P 23.PSN07.002
Miscellaneous
HDD RUBBER - 1 ZQ1 HDD RUBBER-
1 S.P 47.PSR07.008
HDD RUBBER - 2 ZQ1 HDD RUBBER-
2 S.P 47.PSR07.009
TOP HDD RUBBER - 1 ZQ1 TOP HDD
RUBBER-1 S.P 47.PSR07.010
LOWER CASE RUBBER FOOT -
FZQ1 BASE FOOT
RUBBER F S.P 47.PSR07.001
LOWER CASE RUBBER FOOT -
MZQ1 BASE FOOT
RUBBER M S.P 47.PSR07.002
RUBBER FOOT - REAR ZQ1 BASE FOOT
RUBBER REAR S.P 47.PSR07.003
BASE COVER RUBBER FOOT -
1ZQ1 DOOR FOOT
RUBBER-1 S.P 47.PSR07.006
LCD RUBBER - 1 ZQ1 LCD RUBBER-
1 S.P 47.PSR07.004
LCD RUBBER - 2 ZQ1 LCD RUBBER-
2 S.P 47.PSR07.005
Category Partname Description P/N
Chapter 6 147
Screw List
Part Name Description P/N
Screw
ZR6 SCREW M2.5*2-I (NI,NYLOK)IRON S.P 86.EDM07.002
ZA3 SCREW M2.0*3.0-
I(BKAG)(NYLOK)IRON SP 86.PSR07.003
ZQ1 SCREW M2.5*3.0-I(ZN) T=0.5 S.P 86.PSR07.002
TE1 SCREW M2.0*6.0-I SP 86.S6507.001
SCREW M2.5*4.0-I(BKAG)(NYLOK)IRON 86.PSR07.001
ZY2 SCREW M2.5*6.5-I(BZN(NYLOK-RED)
S.P 86.ARE07.001
ZY5D SCREW M3*0.5+3.5I S.P 86.N1407.007
ZY2 SCREW M2.5*3.0-I(BZN) S.P 86.TPK07.003
AJ2 SCREW M2-0.4*2-I(BNI)(NYLOK)IRON
S.P 86.W4107.002
Appendix A 148
Model Definition and Configuration
Aspire 4553/4553G
Model RO Country Acer
Part No Description
AS4553-
1_BR2G25M_brn WW WW S2.PW
D02.00
1
AS4553-1_BR2G25M_brn W7HP64AWW1
MC UMACks_3_BR 1*2G/250_BR/
6L2.2_BR/5R/cb_br_bgn_1.3C_GEk_ES62
AS4553-
1_BR2G25M_brn WW WW S2.PW
D02.00
1
AS4553-1_BR2G25M_brn W7HP64AWW1
MC UMACks_3_BR 1*2G/250_BR/
6L2.2_BR/5R/cb_br_bgn_1.3C_GEk_ES62
AS4553-
1_BR3G25M_brn PA ACLA-
Portuguese LX.PW
D01.00
1
AS4553-1_BR3G25M_brn EM
W7HB64EMATXC2 MC UMACks_3_BR
2G+1G/250_BR/6L2.2_BR/5R/
cb_br_bgn_1.3C_GEk_XC21
AS4553-
1_BR4G32M_brn PA ACLA-
Portuguese LX.PW
D02.00
1
AS4553-1_BR4G32M_brn EM
W7HP64EMATXC2 MC UMACks_3_BR
2*2G/320_BR/6L2.2_BR/5R/
cb_br_bgn_1.3C_GEk_XC21
AS4553G-
N332G32Mn AAP Singapore LX.PSK
02.001 AS4553G-N332G32Mn W7HP64ATSG1
MC PARK_XT512Cks_3V3 1*2G/320/BT/
6L2.2/5R/cb_bgn_1.3C_GEk_ZH31
AS4553G-
N332G32Mn AAP Thailand LX.PSK
0C.019 AS4553G-N332G32Mn LINPUSATH1
PARK_XT512Cks_3V3 1*2G/320/BT/6L2.2/
5R/cb_bgn_1.3C_GEk_TH51
AS4553G-
N332G32Mn WW WW S2.PSK
02.002 AS4553G-N332G32Mn W7HP64ATWW4
MC PARK_XT512Ckk_3V3 2*1G/320/
6L2.2/5R/cb_bgn_1.3C_GEk_IT91
AS4553G-
N332G50Mn AAP Thailand LX.PSK
0C.012 AS4553G-N332G50Mn LINPUSATH1
PARK_XT512Cks_3V3 1*2G/500_L/BT/
6L2.2/5R/cb_bgn_1.3C_GEk_TH51
AS4553G-
N332G64Mn AAP Thailand LX.PSK
0C.024 AS4553G-N332G64Mn LINPUSATH1
PARK_XT512Cks_3V3 1*2G/640/BT/6L2.2/
5R/cb_bgn_1.3C_GEk_TH51
AS4553G-
N334G32Mn AAP Singapore LX.PSK
02.009 AS4553G-N334G32Mn W7HP64ATSG1
MC PARK_XT512Cks_3V3 2*2G/320/BT/
6L2.2/5R/cb_bgn_1.3C_GEk_ZH31
AS4553G-
N334G32Mn AAP Thailand LX.PSK
0C.017 AS4553G-N334G32Mn LINPUSATH1
PARK_XT512Cks_3V3 2*2G/320/BT/6L2.2/
5R/cb_bgn_1.3C_GEk_TH51
AS4553G-
N334G50Mn AAP Thailand LX.PSK
0C.006 AS4553G-N334G50Mn LINPUSATH1
PARK_XT512Cks_3V3 2*2G/500_L/BT/
6L2.2/5R/cb_bgn_1.3C_GEk_TH51
AS4553G-
N334G64Mn AAP Thailand LX.PSK
0C.009 AS4553G-N334G64Mn LINPUSATH1
PARK_XT512Cks_3V3 2*2G/640/BT/6L2.2/
5R/cb_bgn_1.3C_GEk_TH51
Appendix A
149 Appendix A
AS4553G-
N532G32Mn AAP Singapore LX.PSK
02.004 AS4553G-N532G32Mn W7HP64ATSG1
MC PARK_XT512Cks_3V3 1*2G/320/BT/
6L2.2/5R/cb_bgn_1.3C_GEk_ZH31
AS4553G-
N532G32Mn AAP Thailand LX.PSK
0C.020 AS4553G-N532G32Mn LINPUSATH1
PARK_XT512Cks_3V3 1*2G/320/BT/6L2.2/
5R/cb_bgn_1.3C_GEk_TH51
AS4553G-
N532G50Mn AAP Thailand LX.PSK
0C.013 AS4553G-N532G50Mn LINPUSATH1
PARK_XT512Cks_3V3 1*2G/500_L/BT/
6L2.2/5R/cb_bgn_1.3C_GEk_TH51
AS4553G-
N532G64Mn AAP Thailand LX.PSK
0C.014 AS4553G-N532G64Mn LINPUSATH1
PARK_XT512Cks_3V3 1*2G/640/BT/6L2.2/
5R/cb_bgn_1.3C_GEk_TH51
AS4553G-
N534G32Mn WW WW S2.PSK
02.004 AS4553G-N534G32Mn W7HP64AWW1
MC PARK_XT512Cks_3V3 2*2G/320/BT/
6L2.2/5R/cb_bgn_1.3C_GEk_ES62
AS4553G-
N534G32Mn WW WW S2.PSK
02.004 AS4553G-N534G32Mn W7HP64AWW1
MC PARK_XT512Cks_3V3 2*2G/320/BT/
6L2.2/5R/cb_bgn_1.3C_GEk_ES62
AS4553G-
N534G32Mn AAP Singapore LX.PSK
02.006 AS4553G-N534G32Mn W7HP64ATSG1
MC PARK_XT512Cks_3V3 2*2G/320/BT/
6L2.2/5R/cb_bgn_1.3C_GEk_ZH31
AS4553G-
N534G32Mn AAP Thailand LX.PSK
0C.018 AS4553G-N534G32Mn LINPUSATH1
PARK_XT512Cks_3V3 2*2G/320/BT/6L2.2/
5R/cb_bgn_1.3C_GEk_TH51
AS4553G-
N534G50Bn WW WW S2.PSK
02.003 AS4553G-N534G50Bn W7HP64ATWW4
MC PARK_XT512Ckk_3V3 2*2G/500_L/
6L2.2/5R/cb_bgn_1.3C_GEk_IT91
AS4553G-
N534G50Mn AAP Singapore LX.PSK
02.007 AS4553G-N534G50Mn W7HP64ATSG1
MC PARK_XT512Cks_3V3 2*2G/500_L/BT/
6L2.2/5R/cb_bgn_1.3C_GEk_ZH31
AS4553G-
N534G50Mn AAP Thailand LX.PSK
0C.002 AS4553G-N534G50Mn LINPUSATH1
PARK_XT512Cks_3V3 2*2G/500_L/BT/
6L2.2/5R/cb_bgn_1.3C_GEk_TH51
AS4553G-
N534G64Mn AAP Singapore LX.PSK
02.008 AS4553G-N534G64Mn W7HP64ATSG1
MC PARK_XT512Cks_3V3 2*2G/640/BT/
6L2.2/5R/cb_bgn_1.3C_GEk_ZH31
AS4553G-
N534G64Mn AAP Thailand LX.PSK
0C.010 AS4553G-N534G64Mn LINPUSATH1
PARK_XT512Cks_3V3 2*2G/640/BT/6L2.2/
5R/cb_bgn_1.3C_GEk_TH51
AS4553G-
N832G32Mn CHINA China LX.PSK
01.002 AS4553G-N832G32Mn W7HB64SCATCN1
MC PARK_XT512Cks_3V3 1*2G/320/BT/
6L2.2/5R/cb_bgn_1.3C_GEk_SC13
AS4553G-
N832G32Mn CHINA China LX.PSK
01.001 AS4553G-N832G32Mn W7HB64SCATCN1
MC PARK_XT512Cks_3V3 1*2G/320/
6L2.2/5R/cb_bgn_1.3C_GEk_SC13
AS4553G-
N832G32Mn AAP Philippines LX.PSK
0C.025 AS4553G-N832G32Mn LINPUSAPH1
PARK_XT512Cks_3V3 1*2G/320/BT/6L2.2/
5R/cb_bgn_1.3C_GEk_EN11
AS4553G-
N832G32Mn AAP Singapore LX.PSK
02.002 AS4553G-N832G32Mn W7HP64ATSG1
MC PARK_XT512Cks_3V3 1*2G/320/BT/
6L2.2/5R/cb_bgn_1.3C_GEk_ZH31
Model RO Country Acer
Part No Description
Appendix A 150
AS4553G-
N832G32Mn AAP Thailand LX.PSK
0C.021 AS4553G-N832G32Mn LINPUSATH1
PARK_XT512Cks_3V3 1*2G/320/BT/6L2.2/
5R/cb_bgn_1.3C_GEk_TH51
AS4553G-
N832G50Mn TWN GCTWN LX.PSK
02.022 AS4553G-N832G50Mn W7HP64ATTW1
MC PARK_XT512Cks_3V3 1*2G/500_L/BT/
6L2.2/5R/cb_bgn_1.3C_GEk_TC11
AS4553G-
N832G50Mn AAP Thailand LX.PSK
0C.022 AS4553G-N832G50Mn LINPUSATH1
PARK_XT512Cks_3V3 1*2G/500_L/BT/
6L2.2/5R/cb_bgn_1.3C_GEk_TH51
AS4553G-
N832G64Mn AAP Thailand LX.PSK
0C.015 AS4553G-N832G64Mn LINPUSATH1
PARK_XT512Cks_3V3 1*2G/640/BT/6L2.2/
5R/cb_bgn_1.3C_GEk_TH51
AS4553G-
N834G32Mn AAP Singapore LX.PSK
02.005 AS4553G-N834G32Mn W7HP64ATSG1
MC PARK_XT512Cks_3V3 2*2G/320/BT/
6L2.2/5R/cb_bgn_1.3C_GEk_ZH31
AS4553G-
N834G32Mn AAP Thailand LX.PSK
0C.005 AS4553G-N834G32Mn LINPUSATH1
PARK_XT512Cks_3V3 2*2G/320/BT/6L2.2/
5R/cb_bgn_1.3C_GEk_TH51
AS4553G-
N834G50Mn AAP Singapore LX.PSK
02.017 AS4553G-N834G50Mn W7HP64ATSG1
MC PARK_XT512Cks_3V3 2*2G/500_L/BT/
6L2.2/5R/cb_bgn_1.3C_GEk_ZH31
AS4553G-
N834G50Mn AAP Thailand LX.PSK
0C.007 AS4553G-N834G50Mn LINPUSATH1
PARK_XT512Cks_3V3 2*2G/500_L/BT/
6L2.2/5R/cb_bgn_1.3C_GEk_TH51
AS4553G-
N834G64Bn AAP Thailand LX.PSK
02.012 AS4553G-N834G64Bn EM
W7HP64EMATTH1 MC
PARK_XT512Cks_3V3 2*2G/640/BT/6L2.2/
5R/cb_bgn_1.3C_GEk_TH41
AS4553G-
N834G64Mn AAP Singapore LX.PSK
02.016 AS4553G-N834G64Mn W7HP64ATSG1
MC PARK_XT512Cks_3V3 2*2G/640/BT/
6L2.2/5R/cb_bgn_1.3C_GEk_ZH31
AS4553G-
N834G64Mn AAP Thailand LX.PSK
0C.003 AS4553G-N834G64Mn LINPUSATH1
PARK_XT512Cks_3V3 2*2G/640/BT/6L2.2/
5R/cb_bgn_1.3C_GEk_TH51
AS4553G-
N932G32Mn AAP Singapore LX.PSK
02.003 AS4553G-N932G32Mn W7HP64ATSG1
MC PARK_XT512Cks_3V3 1*2G/320/BT/
6L2.2/5R/cb_bgn_1.3C_GEk_ZH31
AS4553G-
N932G32Mn AAP Thailand LX.PSK
0C.011 AS4553G-N932G32Mn LINPUSATH1
PARK_XT512Cks_3V3 1*2G/320/BT/6L2.2/
5R/cb_bgn_1.3C_GEk_TH51
AS4553G-
N932G50Mn TWN GCTWN LX.PSK
02.021 AS4553G-N932G50Mn W7HP64ATTW1
MC PARK_XT512Cks_3V3 1*2G/500_L/BT/
6L2.2/5R/cb_bgn_1.3C_GEk_TC11
AS4553G-
N932G50Mn AAP Thailand LX.PSK
0C.023 AS4553G-N932G50Mn LINPUSATH1
PARK_XT512Cks_3V3 1*2G/500_L/BT/
6L2.2/5R/cb_bgn_1.3C_GEk_TH51
AS4553G-
N932G64Mn AAP Thailand LX.PSK
0C.016 AS4553G-N932G64Mn LINPUSATH1
PARK_XT512Cks_3V3 1*2G/640/BT/6L2.2/
5R/cb_bgn_1.3C_GEk_TH51
AS4553G-
N934G32Mn AAP Thailand LX.PSK
0C.001 AS4553G-N934G32Mn LINPUSATH1
PARK_XT512Cks_3V3 2*2G/320/BT/6L2.2/
5R/cb_bgn_1.3C_GEk_TH51
Model RO Country Acer
Part No Description
151 Appendix A
AS4553G-
N934G50Bn WW WW S2.PSK
0C.001 AS4553G-N934G50Bn LINPUSAWW1
PARK_XT512Cks_3V3 2*2G/500_L/6L2.2/
5R/cb_bgn_1.3C_GEk_EN11
AS4553G-
N934G50Mn AAP Singapore LX.PSK
02.011 AS4553G-N934G50Mn W7HP64ATSG1
MC PARK_XT512Cks_3V3 2*2G/500_L/BT/
6L2.2/5R/cb_bgn_1.3C_GEk_ZH31
AS4553G-
N934G50Mn AAP Thailand LX.PSK
0C.008 AS4553G-N934G50Mn LINPUSATH1
PARK_XT512Cks_3V3 2*2G/500_L/BT/
6L2.2/5R/cb_bgn_1.3C_GEk_TH51
AS4553G-
N934G64Mn AAP Singapore LX.PSK
02.014 AS4553G-N934G64Mn W7HP64ATSG1
MC PARK_XT512Cks_3V3 2*2G/640/BT/
6L2.2/5R/cb_bgn_1.3C_GEk_ZH31
AS4553G-
N934G64Mn AAP Thailand LX.PSK
0C.004 AS4553G-N934G64Mn LINPUSATH1
PARK_XT512Cks_3V3 2*2G/640/BT/6L2.2/
5R/cb_bgn_1.3C_GEk_TH51
AS4553G-
N936G50Bn WW WW S2.PSK
02.005 AS4553G-N936G50Bn W7HP64AWW1 MC
PARK_XT512Cks_3V3 2G+4G/500_L/BT/
6L2.2/5R/cb_bgn_1.3C_GEk_ES62
AS4553G-
N936G50Bn WW WW S2.PSK
02.005 AS4553G-N936G50Bn W7HP64AWW1 MC
PARK_XT512Cks_3V3 2G+4G/500_L/BT/
6L2.2/5R/cb_bgn_1.3C_GEk_ES62
AS4553G-
N936G64Mn AAP Singapore LX.PSK
02.015 AS4553G-N936G64Mn W7HP64ATSG1
MC PARK_XT512Cks_3V3 4G+2G/640/BT/
6L2.2/5R/cb_bgn_1.3C_GEk_ZH31
AS4553G-
P322G50Mn TWN GCTWN LX.PSK
02.010 AS4553G-P322G50Mn W7HP64ATTW1
MC PARK_XT512Cks_3V3 1*2G/500_L/BT/
6L2.2/5R/cb_bgn_1.3C_GEk_TC11
AS4553G-
P324G50Mn AAP Singapore LX.PSK
02.019 AS4553G-P324G50Mn W7HP64ATSG1
MC PARK_XT512Cks_3V3 2*2G/500_L/BT/
6L2.2/5R/cb_bgn_1.3C_GEk_ZH31
AS4553G-
P522G50Mn TWN GCTWN LX.PSK
02.020 AS4553G-P522G50Mn W7HP64ATTW1
MC PARK_XT512Cks_3V3 1*2G/500_L/BT/
6L2.2/5R/cb_bgn_1.3C_GEk_TC11
AS4553G-
P522G50Mn AAP Indonesia LX.PSK
0C.026 AS4553G-P522G50Mn LINPUSAID1
PARK_XT512Cks_3V3 1*2G/500_L/BT/
6L2.2/5R/cb_bgn_1.3C_GEk_ID22
AS4553G-
P522G50Mn AAP Malaysia LX.PSK
02.013 AS4553G-P522G50Mn EM
W7HP64EMATMY1 MC
PARK_XT512Cks_3V3 1*2G/500_L/BT/
6L2.2/5R/cb_bgn_1.3C_GEk_ES61
AS4553G-
P524G50Mn AAP Singapore LX.PSK
02.018 AS4553G-P524G50Mn W7HP64ATSG1
MC PARK_XT512Cks_3V3 2*2G/500_L/BT/
6L2.2/5R/cb_bgn_1.3C_GEk_ZH31
AS4553-
N332G16Bn WW WW S2.PSK
02.001 AS4553-N332G16Bn W7HP64ATWW4 MC
PARK_XT512Ckk_3V3 2*1G/160/6L2.2/5R/
cb_bgn_1.3C_GEk_IT91
AS4553-
N332G16Bn WW WW S2.PS
U02.00
1
AS4553-N332G16Bn W7HP64ATWW4 MC
UMACkk_3 2*1G/160/6L2.2/5R/
cb_bgn_1.3C_GEk_IT91
AS4553-
N332G25Mn AAP Thailand LX.PS
U0C.00
1
AS4553-N332G25Mn LINPUSATH1
UMACks_3 1*2G/250/BT/6L2.2/5R/
cb_bgn_1.3C_GEk_TH51
Model RO Country Acer
Part No Description
Appendix A 152
AS4553-
N332G32Mn AAP Singapore LX.PS
U02.00
3
AS4553-N332G32Mn W7HP64ATSG1 MC
UMACks_3 1*2G/320/BT/6L2.2/5R/
cb_bgn_1.3C_GEk_ZH31
AS4553-
N332G32Mn AAP Thailand LX.PS
U0C.00
2
AS4553-N332G32Mn LINPUSATH1
UMACks_3 1*2G/320/BT/6L2.2/5R/
cb_bgn_1.3C_GEk_TH51
AS4553-
N332G50Mn AAP Thailand LX.PS
U0C.00
3
AS4553-N332G50Mn LINPUSATH1
UMACks_3 1*2G/500_L/BT/6L2.2/5R/
cb_bgn_1.3C_GEk_TH51
AS4553-
N332G64Mn AAP Thailand LX.PS
U0C.01
6
AS4553-N332G64Mn LINPUSATH1
UMACks_3 1*2G/640/BT/6L2.2/5R/
cb_bgn_1.3C_GEk_TH51
AS4553-
N333G25Mi WW WW S2.PS
U02.00
3
AS4553-N333G25Mi W7HP64AWW1 MC
UMACks_3 1G+2G/250/6L2.2/5R/
cb_bg_1.3C_GEk_ES62
AS4553-
N333G25Mi WW WW S2.PS
U02.00
3
AS4553-N333G25Mi W7HP64AWW1 MC
UMACks_3 1G+2G/250/6L2.2/5R/
cb_bg_1.3C_GEk_ES62
AS4553-
N333G32Mn AAP Singapore LX.PS
U02.00
7
AS4553-N333G32Mn W7HP64ATSG1 MC
UMACks_3 2G+1G/320/BT/6L2.2/5R/
cb_bgn_1.3C_GEk_ZH31
AS4553-
N334G32Mn AAP Thailand LX.PS
U0C.01
5
AS4553-N334G32Mn LINPUSATH1
UMACks_3 2*2G/320/BT/6L2.2/5R/
cb_bgn_1.3C_GEk_TH51
AS4553-
N334G50Mn AAP Thailand LX.PS
U0C.00
4
AS4553-N334G50Mn LINPUSATH1
UMACks_3 2*2G/500_L/BT/6L2.2/5R/
cb_bgn_1.3C_GEk_TH51
AS4553-
N334G64Mn AAP Thailand LX.PS
U0C.01
7
AS4553-N334G64Mn LINPUSATH1
UMACks_3 2*2G/640/BT/6L2.2/5R/
cb_bgn_1.3C_GEk_TH51
AS4553-
N532G32Mn AAP Singapore LX.PS
U02.00
6
AS4553-N532G32Mn W7HP64ATSG1 MC
UMACks_3 1*2G/320/BT/6L2.2/5R/
cb_bgn_1.3C_GEk_ZH31
AS4553-
N532G32Mn AAP Thailand LX.PS
U0C.00
5
AS4553-N532G32Mn LINPUSATH1
UMACks_3 1*2G/320/BT/6L2.2/5R/
cb_bgn_1.3C_GEk_TH51
AS4553-
N532G50Mn AAP Thailand LX.PS
U0C.01
8
AS4553-N532G50Mn LINPUSATH1
UMACks_3 1*2G/500_L/BT/6L2.2/5R/
cb_bgn_1.3C_GEk_TH51
AS4553-
N532G64Mn AAP Thailand LX.PS
U0C.00
7
AS4553-N532G64Mn LINPUSATH1
UMACks_3 1*2G/640/BT/6L2.2/5R/
cb_bgn_1.3C_GEk_TH51
AS4553-
N534G32Mn AAP Thailand LX.PS
U0C.00
6
AS4553-N534G32Mn LINPUSATH1
UMACks_3 2*2G/320/BT/6L2.2/5R/
cb_bgn_1.3C_GEk_TH51
AS4553-
N534G50Mn AAP Singapore LX.PS
U02.01
0
AS4553-N534G50Mn W7HP64ATSG1 MC
UMACks_3 2*2G/500_L/BT/6L2.2/5R/
cb_bgn_1.3C_GEk_ZH31
AS4553-
N534G50Mn AAP Thailand LX.PS
U0C.01
9
AS4553-N534G50Mn LINPUSATH1
UMACks_3 2*2G/500_L/BT/6L2.2/5R/
cb_bgn_1.3C_GEk_TH51
Model RO Country Acer
Part No Description
153 Appendix A
AS4553-
N534G64Mn AAP Singapore LX.PS
U02.00
1
AS4553-N534G64Mn W7HP64ATSG1 MC
UMACks_3 2*2G/640/BT/6L2.2/5R/
cb_bgn_1.3C_GEk_ZH31
AS4553-
N534G64Mn AAP Thailand LX.PS
U0C.00
8
AS4553-N534G64Mn LINPUSATH1
UMACks_3 2*2G/640/BT/6L2.2/5R/
cb_bgn_1.3C_GEk_TH51
AS4553-
N832G32Mn AAP Singapore LX.PS
U02.00
4
AS4553-N832G32Mn W7HP64ATSG1 MC
UMACks_3 1*2G/320/BT/6L2.2/5R/
cb_bgn_1.3C_GEk_ZH31
AS4553-
N832G32Mn AAP Thailand LX.PS
U0C.00
9
AS4553-N832G32Mn LINPUSATH1
UMACks_3 1*2G/320/BT/6L2.2/5R/
cb_bgn_1.3C_GEk_TH51
AS4553-
N832G50Mn AAP Thailand LX.PS
U0C.02
0
AS4553-N832G50Mn LINPUSATH1
UMACks_3 1*2G/500_L/BT/6L2.2/5R/
cb_bgn_1.3C_GEk_TH51
AS4553-
N832G64Mn AAP Thailand LX.PS
U0C.01
2
AS4553-N832G64Mn LINPUSATH1
UMACks_3 1*2G/640/BT/6L2.2/5R/
cb_bgn_1.3C_GEk_TH51
AS4553-
N834G32Mn AAP Singapore LX.PS
U02.00
2
AS4553-N834G32Mn W7HP64ATSG1 MC
UMACks_3 2*2G/320/BT/6L2.2/5R/
cb_bgn_1.3C_GEk_ZH31
AS4553-
N834G32Mn AAP Thailand LX.PS
U0C.01
0
AS4553-N834G32Mn LINPUSATH1
UMACks_3 2*2G/320/BT/6L2.2/5R/
cb_bgn_1.3C_GEk_TH51
AS4553-
N834G50Mn AAP Singapore LX.PS
U02.00
9
AS4553-N834G50Mn W7HP64ATSG1 MC
UMACks_3 2*2G/500_L/BT/6L2.2/5R/
cb_bgn_1.3C_GEk_ZH31
AS4553-
N834G50Mn AAP Thailand LX.PS
U0C.01
1
AS4553-N834G50Mn LINPUSATH1
UMACks_3 2*2G/500_L/BT/6L2.2/5R/
cb_bgn_1.3C_GEk_TH51
AS4553-
N834G64Mn AAP Thailand LX.PS
U0C.01
3
AS4553-N834G64Mn LINPUSATH1
UMACks_3 2*2G/640/BT/6L2.2/5R/
cb_bgn_1.3C_GEk_TH51
AS4553-
N932G32Mn AAP Singapore LX.PS
U02.00
5
AS4553-N932G32Mn W7HP64ATSG1 MC
UMACks_3 1*2G/320/BT/6L2.2/5R/
cb_bgn_1.3C_GEk_ZH31
AS4553-
N932G32Mn AAP Thailand LX.PS
U0C.02
1
AS4553-N932G32Mn LINPUSATH1
UMACks_3 1*2G/320/BT/6L2.2/5R/
cb_bgn_1.3C_GEk_TH51
AS4553-
N932G50Mn AAP Thailand LX.PS
U0C.02
2
AS4553-N932G50Mn LINPUSATH1
UMACks_3 1*2G/500_L/BT/6L2.2/5R/
cb_bgn_1.3C_GEk_TH51
AS4553-
N932G64Mn AAP Thailand LX.PS
U0C.02
4
AS4553-N932G64Mn LINPUSATH1
UMACks_3 1*2G/640/BT/6L2.2/5R/
cb_bgn_1.3C_GEk_TH51
AS4553-
N934G32Mn AAP Thailand LX.PS
U0C.01
4
AS4553-N934G32Mn LINPUSATH1
UMACks_3 2*2G/320/BT/6L2.2/5R/
cb_bgn_1.3C_GEk_TH51
AS4553-
N934G50Mn AAP Singapore LX.PS
U02.00
8
AS4553-N934G50Mn W7HP64ATSG1 MC
UMACks_3 2*2G/500_L/BT/6L2.2/5R/
cb_bgn_1.3C_GEk_ZH31
Model RO Country Acer
Part No Description
Appendix A 154
AS4553-
N934G50Mn AAP Thailand LX.PS
U0C.02
3
AS4553-N934G50Mn LINPUSATH1
UMACks_3 2*2G/500_L/BT/6L2.2/5R/
cb_bgn_1.3C_GEk_TH51
AS4553-
N934G64Mn AAP Thailand LX.PS
U0C.02
5
AS4553-N934G64Mn LINPUSATH1
UMACks_3 2*2G/640/BT/6L2.2/5R/
cb_bgn_1.3C_GEk_TH51
AS4553-
P321G16Mn AAP Vietnam LX.PS
U0C.02
7
AS4553-P321G16Mn LINPUSAVN1
UMACks_3 1*1G/160/BT/6L2.2/5R/
cb_bgn_1.3C_GEk_EN11
AS4553-
P322G32Mn AAP Vietnam LX.PS
U0C.02
6
AS4553-P322G32Mn LINPUSAVN1
UMACks_3 1*2G/320/BT/6L2.2/5R/
cb_bgn_1.3C_GEk_EN11
AS4553-
P522G25Mn WW WW S2.PS
U02.00
2
AS4553-P522G25Mn W7HP64ATWW4 MC
UMACkk 2*1G/250/6L2.2/5R/
cb_bgn_1.3C_GEk_IT91
AS4553-
P524G32Mn PA Chile LX.PS
U02.01
5
AS4553-P524G32Mn EM
W7HP64EMATCL3 MC UMACks_3 2*2G/
320/6L2.2/5R/cb_bgn_1.3C_GEk_ES51
AS4553-
P524G32Mn PA ACLA-
Spanish LX.PS
U02.01
4
AS4553-P524G32Mn EM
W7HP64EMATEA4 MC UMACks_3 2*2G/
320/6L2.2/5R/cb_bgn_1.3C_GEk_EN31
AS4553-
P524G32Mn PA ACLA-
Spanish LX.PS
U02.01
3
AS4553-P524G32Mn EM
W7HP64EMATEA1 MC UMACks_3 2*2G/
320/6L2.2/5R/cb_bgn_1.3C_GEk_ES51
AS4553-
P524G32Mn PA ACLA-
Spanish LX.PS
U02.01
2
AS4553-P524G32Mn EM
W7HP64EMATEA3 MC UMACks_3 2*2G/
320/6L2.2/5R/cb_bgn_1.3C_GEk_ES51
AS4553-
P524G32Mn PA ACLA-
Portuguese LX.PS
U02.01
1
AS4553-P524G32Mn EM
W7HP64EMATXC3 MC UMACks_3 2*2G/
320/6L2.2/5R/cb_bgn_1.3C_GEk_EN61
Model Country Acer
Part No BOM Name CPU LCD
AS4553-
1_BR2G25M_brn WW S2.PWD
02.001 AS4553_UMACk
s_3_BR AAP320_BR NLED14WXGA
GS_BR
AS4553-
1_BR2G25M_brn WW S2.PWD
02.001 AS4553_UMACk
s_3_BR AAP320_BR NLED14WXGA
GS_BR
AS4553-
1_BR3G25M_brn ACLA-
Portuguese LX.PWD
01.001 AS4553_UMACk
s_3_BR AAP320_BR NLED14WXGA
GS_BR
AS4553-
1_BR4G32M_brn ACLA-
Portuguese LX.PWD
02.001 AS4553_UMACk
s_3_BR AAP320_BR NLED14WXGA
GS_BR
AS4553G-
N332G32Mn Singapore LX.PSK
02.001 AS4553G_PARK
_XT512Cks_3V3 AAN330 NLED14WXGA
GS
AS4553G-
N332G32Mn Thailand LX.PSK
0C.019 AS4553G_PARK
_XT512Cks_3V3 AAN330 NLED14WXGA
GS
AS4553G-
N332G32Mn WW S2.PSK
02.002 AS4553G_PARK
_XT512Cks_3V3 AAN330 NLED14WXGA
GS
AS4553G-
N332G50Mn Thailand LX.PSK
0C.012 AS4553G_PARK
_XT512Cks_3V3 AAN330 NLED14WXGA
GS
Model RO Country Acer
Part No Description
155 Appendix A
AS4553G-
N332G64Mn Thailand LX.PSK
0C.024 AS4553G_PARK
_XT512Cks_3V3 AAN330 NLED14WXGA
GS
AS4553G-
N334G32Mn Singapore LX.PSK
02.009 AS4553G_PARK
_XT512Cks_3V3 AAN330 NLED14WXGA
GS
AS4553G-
N334G32Mn Thailand LX.PSK
0C.017 AS4553G_PARK
_XT512Cks_3V3 AAN330 NLED14WXGA
GS
AS4553G-
N334G50Mn Thailand LX.PSK
0C.006 AS4553G_PARK
_XT512Cks_3V3 AAN330 NLED14WXGA
GS
AS4553G-
N334G64Mn Thailand LX.PSK
0C.009 AS4553G_PARK
_XT512Cks_3V3 AAN330 NLED14WXGA
GS
AS4553G-
N532G32Mn Singapore LX.PSK
02.004 AS4553G_PARK
_XT512Cks_3V3 ATN530 NLED14WXGA
GS
AS4553G-
N532G32Mn Thailand LX.PSK
0C.020 AS4553G_PARK
_XT512Cks_3V3 ATN530 NLED14WXGA
GS
AS4553G-
N532G50Mn Thailand LX.PSK
0C.013 AS4553G_PARK
_XT512Cks_3V3 ATN530 NLED14WXGA
GS
AS4553G-
N532G64Mn Thailand LX.PSK
0C.014 AS4553G_PARK
_XT512Cks_3V3 ATN530 NLED14WXGA
GS
AS4553G-
N534G32Mn WW S2.PSK
02.004 AS4553G_PARK
_XT512Cks_3V3 ATN530 NLED14WXGA
GS
AS4553G-
N534G32Mn WW S2.PSK
02.004 AS4553G_PARK
_XT512Cks_3V3 ATN530 NLED14WXGA
GS
AS4553G-
N534G32Mn Singapore LX.PSK
02.006 AS4553G_PARK
_XT512Cks_3V3 ATN530 NLED14WXGA
GS
AS4553G-
N534G32Mn Thailand LX.PSK
0C.018 AS4553G_PARK
_XT512Cks_3V3 ATN530 NLED14WXGA
GS
AS4553G-
N534G50Bn WW S2.PSK
02.003 AS4553G_PARK
_XT512Cks_3V3 ATN530 NLED14WXGA
GS
AS4553G-
N534G50Mn Singapore LX.PSK
02.007 AS4553G_PARK
_XT512Cks_3V3 ATN530 NLED14WXGA
GS
AS4553G-
N534G50Mn Thailand LX.PSK
0C.002 AS4553G_PARK
_XT512Cks_3V3 ATN530 NLED14WXGA
GS
AS4553G-
N534G64Mn Singapore LX.PSK
02.008 AS4553G_PARK
_XT512Cks_3V3 ATN530 NLED14WXGA
GS
AS4553G-
N534G64Mn Thailand LX.PSK
0C.010 AS4553G_PARK
_XT512Cks_3V3 ATN530 NLED14WXGA
GS
AS4553G-
N832G32Mn China LX.PSK
01.002 AS4553G_PARK
_XT512Cks_3V3 APN830 NLED14WXGA
GS
AS4553G-
N832G32Mn China LX.PSK
01.001 AS4553G_PARK
_XT512Cks_3V3 APN830 NLED14WXGA
GS
AS4553G-
N832G32Mn Philippines LX.PSK
0C.025 AS4553G_PARK
_XT512Cks_3V3 APN830 NLED14WXGA
GS
AS4553G-
N832G32Mn Singapore LX.PSK
02.002 AS4553G_PARK
_XT512Cks_3V3 APN830 NLED14WXGA
GS
AS4553G-
N832G32Mn Thailand LX.PSK
0C.021 AS4553G_PARK
_XT512Cks_3V3 APN830 NLED14WXGA
GS
AS4553G-
N832G50Mn GCTWN LX.PSK
02.022 AS4553G_PARK
_XT512Cks_3V3 APN830 NLED14WXGA
GS
Model Country Acer
Part No BOM Name CPU LCD
Appendix A 156
AS4553G-
N832G50Mn Thailand LX.PSK
0C.022 AS4553G_PARK
_XT512Cks_3V3 APN830 NLED14WXGA
GS
AS4553G-
N832G64Mn Thailand LX.PSK
0C.015 AS4553G_PARK
_XT512Cks_3V3 APN830 NLED14WXGA
GS
AS4553G-
N834G32Mn Singapore LX.PSK
02.005 AS4553G_PARK
_XT512Cks_3V3 APN830 NLED14WXGA
GS
AS4553G-
N834G32Mn Thailand LX.PSK
0C.005 AS4553G_PARK
_XT512Cks_3V3 APN830 NLED14WXGA
GS
AS4553G-
N834G50Mn Singapore LX.PSK
02.017 AS4553G_PARK
_XT512Cks_3V3 APN830 NLED14WXGA
GS
AS4553G-
N834G50Mn Thailand LX.PSK
0C.007 AS4553G_PARK
_XT512Cks_3V3 APN830 NLED14WXGA
GS
AS4553G-
N834G64Bn Thailand LX.PSK
02.012 AS4553G_PARK
_XT512Cks_3V3 APN830 NLED14WXGA
GS
AS4553G-
N834G64Mn Singapore LX.PSK
02.016 AS4553G_PARK
_XT512Cks_3V3 APN830 NLED14WXGA
GS
AS4553G-
N834G64Mn Thailand LX.PSK
0C.003 AS4553G_PARK
_XT512Cks_3V3 APN830 NLED14WXGA
GS
AS4553G-
N932G32Mn Singapore LX.PSK
02.003 AS4553G_PARK
_XT512Cks_3V3 APN930 NLED14WXGA
GS
AS4553G-
N932G32Mn Thailand LX.PSK
0C.011 AS4553G_PARK
_XT512Cks_3V3 APN930 NLED14WXGA
GS
AS4553G-
N932G50Mn GCTWN LX.PSK
02.021 AS4553G_PARK
_XT512Cks_3V3 APN930 NLED14WXGA
GS
AS4553G-
N932G50Mn Thailand LX.PSK
0C.023 AS4553G_PARK
_XT512Cks_3V3 APN930 NLED14WXGA
GS
AS4553G-
N932G64Mn Thailand LX.PSK
0C.016 AS4553G_PARK
_XT512Cks_3V3 APN930 NLED14WXGA
GS
AS4553G-
N934G32Mn Thailand LX.PSK
0C.001 AS4553G_PARK
_XT512Cks_3V3 APN930 NLED14WXGA
GS
AS4553G-
N934G50Bn WW S2.PSK
0C.001 AS4553G_PARK
_XT512Cks_3V3 APN930 NLED14WXGA
GS
AS4553G-
N934G50Mn Singapore LX.PSK
02.011 AS4553G_PARK
_XT512Cks_3V3 APN930 NLED14WXGA
GS
AS4553G-
N934G50Mn Thailand LX.PSK
0C.008 AS4553G_PARK
_XT512Cks_3V3 APN930 NLED14WXGA
GS
AS4553G-
N934G64Mn Singapore LX.PSK
02.014 AS4553G_PARK
_XT512Cks_3V3 APN930 NLED14WXGA
GS
AS4553G-
N934G64Mn Thailand LX.PSK
0C.004 AS4553G_PARK
_XT512Cks_3V3 APN930 NLED14WXGA
GS
AS4553G-
N936G50Bn WW S2.PSK
02.005 AS4553G_PARK
_XT512Cks_3V3 APN930 NLED14WXGA
GS
AS4553G-
N936G50Bn WW S2.PSK
02.005 AS4553G_PARK
_XT512Cks_3V3 APN930 NLED14WXGA
GS
AS4553G-
N936G64Mn Singapore LX.PSK
02.015 AS4553G_PARK
_XT512Cks_3V3 APN930 NLED14WXGA
GS
AS4553G-
P322G50Mn GCTWN LX.PSK
02.010 AS4553G_PARK
_XT512Cks_3V3 AAP320 NLED14WXGA
GS
Model Country Acer
Part No BOM Name CPU LCD
157 Appendix A
AS4553G-
P324G50Mn Singapore LX.PSK
02.019 AS4553G_PARK
_XT512Cks_3V3 AAP320 NLED14WXGA
GS
AS4553G-
P522G50Mn GCTWN LX.PSK
02.020 AS4553G_PARK
_XT512Cks_3V3 ATP520 NLED14WXGA
GS
AS4553G-
P522G50Mn Indonesia LX.PSK
0C.026 AS4553G_PARK
_XT512Cks_3V3 ATP520 NLED14WXGA
GS
AS4553G-
P522G50Mn Malaysia LX.PSK
02.013 AS4553G_PARK
_XT512Cks_3V3 ATP520 NLED14WXGA
GS
AS4553G-
P524G50Mn Singapore LX.PSK
02.018 AS4553G_PARK
_XT512Cks_3V3 ATP520 NLED14WXGA
GS
AS4553-
N332G16Bn WW S2.PSK
02.001 AS4553G_PARK
_XT512Cks_3V3 AAN330 NLED14WXGA
GS
AS4553-
N332G16Bn WW S2.PSU
02.001 AS4553_UMACk
s_3 AAN330 NLED14WXGA
GS
AS4553-
N332G25Mn Thailand LX.PSU
0C.001 AS4553_UMACk
s_3 AAN330 NLED14WXGA
GS
AS4553-
N332G32Mn Singapore LX.PSU
02.003 AS4553_UMACk
s_3 AAN330 NLED14WXGA
GS
AS4553-
N332G32Mn Thailand LX.PSU
0C.002 AS4553_UMACk
s_3 AAN330 NLED14WXGA
GS
AS4553-
N332G50Mn Thailand LX.PSU
0C.003 AS4553_UMACk
s_3 AAN330 NLED14WXGA
GS
AS4553-
N332G64Mn Thailand LX.PSU
0C.016 AS4553_UMACk
s_3 AAN330 NLED14WXGA
GS
AS4553-
N333G25Mi WW S2.PSU
02.003 AS4553_UMACk
s_3 AAN330 NLED14WXGA
GS
AS4553-
N333G25Mi WW S2.PSU
02.003 AS4553_UMACk
s_3 AAN330 NLED14WXGA
GS
AS4553-
N333G32Mn Singapore LX.PSU
02.007 AS4553_UMACk
s_3 AAN330 NLED14WXGA
GS
AS4553-
N334G32Mn Thailand LX.PSU
0C.015 AS4553_UMACk
s_3 AAN330 NLED14WXGA
GS
AS4553-
N334G50Mn Thailand LX.PSU
0C.004 AS4553_UMACk
s_3 AAN330 NLED14WXGA
GS
AS4553-
N334G64Mn Thailand LX.PSU
0C.017 AS4553_UMACk
s_3 AAN330 NLED14WXGA
GS
AS4553-
N532G32Mn Singapore LX.PSU
02.006 AS4553_UMACk
s_3 ATN530 NLED14WXGA
GS
AS4553-
N532G32Mn Thailand LX.PSU
0C.005 AS4553_UMACk
s_3 ATN530 NLED14WXGA
GS
AS4553-
N532G50Mn Thailand LX.PSU
0C.018 AS4553_UMACk
s_3 ATN530 NLED14WXGA
GS
AS4553-
N532G64Mn Thailand LX.PSU
0C.007 AS4553_UMACk
s_3 ATN530 NLED14WXGA
GS
AS4553-
N534G32Mn Thailand LX.PSU
0C.006 AS4553_UMACk
s_3 ATN530 NLED14WXGA
GS
AS4553-
N534G50Mn Singapore LX.PSU
02.010 AS4553_UMACk
s_3 ATN530 NLED14WXGA
GS
Model Country Acer
Part No BOM Name CPU LCD
Appendix A 158
AS4553-
N534G50Mn Thailand LX.PSU
0C.019 AS4553_UMACk
s_3 ATN530 NLED14WXGA
GS
AS4553-
N534G64Mn Singapore LX.PSU
02.001 AS4553_UMACk
s_3 ATN530 NLED14WXGA
GS
AS4553-
N534G64Mn Thailand LX.PSU
0C.008 AS4553_UMACk
s_3 ATN530 NLED14WXGA
GS
AS4553-
N832G32Mn Singapore LX.PSU
02.004 AS4553_UMACk
s_3 APN830 NLED14WXGA
GS
AS4553-
N832G32Mn Thailand LX.PSU
0C.009 AS4553_UMACk
s_3 APN830 NLED14WXGA
GS
AS4553-
N832G50Mn Thailand LX.PSU
0C.020 AS4553_UMACk
s_3 APN830 NLED14WXGA
GS
AS4553-
N832G64Mn Thailand LX.PSU
0C.012 AS4553_UMACk
s_3 APN830 NLED14WXGA
GS
AS4553-
N834G32Mn Singapore LX.PSU
02.002 AS4553_UMACk
s_3 APN830 NLED14WXGA
GS
AS4553-
N834G32Mn Thailand LX.PSU
0C.010 AS4553_UMACk
s_3 APN830 NLED14WXGA
GS
AS4553-
N834G50Mn Singapore LX.PSU
02.009 AS4553_UMACk
s_3 APN830 NLED14WXGA
GS
AS4553-
N834G50Mn Thailand LX.PSU
0C.011 AS4553_UMACk
s_3 APN830 NLED14WXGA
GS
AS4553-
N834G64Mn Thailand LX.PSU
0C.013 AS4553_UMACk
s_3 APN830 NLED14WXGA
GS
AS4553-
N932G32Mn Singapore LX.PSU
02.005 AS4553_UMACk
s_3 APN930 NLED14WXGA
GS
AS4553-
N932G32Mn Thailand LX.PSU
0C.021 AS4553_UMACk
s_3 APN930 NLED14WXGA
GS
AS4553-
N932G50Mn Thailand LX.PSU
0C.022 AS4553_UMACk
s_3 APN930 NLED14WXGA
GS
AS4553-
N932G64Mn Thailand LX.PSU
0C.024 AS4553_UMACk
s_3 APN930 NLED14WXGA
GS
AS4553-
N934G32Mn Thailand LX.PSU
0C.014 AS4553_UMACk
s_3 APN930 NLED14WXGA
GS
AS4553-
N934G50Mn Singapore LX.PSU
02.008 AS4553_UMACk
s_3 APN930 NLED14WXGA
GS
AS4553-
N934G50Mn Thailand LX.PSU
0C.023 AS4553_UMACk
s_3 APN930 NLED14WXGA
GS
AS4553-
N934G64Mn Thailand LX.PSU
0C.025 AS4553_UMACk
s_3 APN930 NLED14WXGA
GS
AS4553-
P321G16Mn Vietnam LX.PSU
0C.027 AS4553_UMACk
s_3 AAP320 NLED14WXGA
GS
AS4553-
P322G32Mn Vietnam LX.PSU
0C.026 AS4553_UMACk
s_3 AAP320 NLED14WXGA
GS
AS4553-
P522G25Mn WW S2.PSU
02.002 AS4553_UMACk
s_3 ATP520 NLED14WXGA
GS
AS4553-
P524G32Mn Chile LX.PSU
02.015 AS4553_UMACk
s_3 ATP520 NLED14WXGA
GS
Model Country Acer
Part No BOM Name CPU LCD
159 Appendix A
AS4553-
P524G32Mn ACLA-
Spanish LX.PSU
02.014 AS4553_UMACk
s_3 ATP520 NLED14WXGA
GS
AS4553-
P524G32Mn ACLA-
Spanish LX.PSU
02.013 AS4553_UMACk
s_3 ATP520 NLED14WXGA
GS
AS4553-
P524G32Mn ACLA-
Spanish LX.PSU
02.012 AS4553_UMACk
s_3 ATP520 NLED14WXGA
GS
AS4553-
P524G32Mn ACLA-
Portuguese LX.PSU
02.011 AS4553_UMACk
s_3 ATP520 NLED14WXGA
GS
Model Country Acer Part No VGA Chip VRAM 1
AS4553-
1_BR2G25M_brn WW S2.PWD02.001 UMA N
AS4553-
1_BR2G25M_brn WW S2.PWD02.001 UMA N
AS4553-
1_BR3G25M_brn ACLA-
Portuguese LX.PWD01.001 UMA N
AS4553-
1_BR4G32M_brn ACLA-
Portuguese LX.PWD02.001 UMA N
AS4553G-
N332G32Mn Singapore LX.PSK02.001 PARK_XT 512M-DDR3 (64*16*4)
AS4553G-
N332G32Mn Thailand LX.PSK0C.019 PARK_XT 512M-DDR3 (64*16*4)
AS4553G-
N332G32Mn WW S2.PSK02.002 PARK_XT 512M-DDR3 (64*16*4)
AS4553G-
N332G50Mn Thailand LX.PSK0C.012 PARK_XT 512M-DDR3 (64*16*4)
AS4553G-
N332G64Mn Thailand LX.PSK0C.024 PARK_XT 512M-DDR3 (64*16*4)
AS4553G-
N334G32Mn Singapore LX.PSK02.009 PARK_XT 512M-DDR3 (64*16*4)
AS4553G-
N334G32Mn Thailand LX.PSK0C.017 PARK_XT 512M-DDR3 (64*16*4)
AS4553G-
N334G50Mn Thailand LX.PSK0C.006 PARK_XT 512M-DDR3 (64*16*4)
AS4553G-
N334G64Mn Thailand LX.PSK0C.009 PARK_XT 512M-DDR3 (64*16*4)
AS4553G-
N532G32Mn Singapore LX.PSK02.004 PARK_XT 512M-DDR3 (64*16*4)
AS4553G-
N532G32Mn Thailand LX.PSK0C.020 PARK_XT 512M-DDR3 (64*16*4)
AS4553G-
N532G50Mn Thailand LX.PSK0C.013 PARK_XT 512M-DDR3 (64*16*4)
AS4553G-
N532G64Mn Thailand LX.PSK0C.014 PARK_XT 512M-DDR3 (64*16*4)
AS4553G-
N534G32Mn WW S2.PSK02.004 PARK_XT 512M-DDR3 (64*16*4)
AS4553G-
N534G32Mn WW S2.PSK02.004 PARK_XT 512M-DDR3 (64*16*4)
Model Country Acer
Part No BOM Name CPU LCD
Appendix A 160
AS4553G-
N534G32Mn Singapore LX.PSK02.006 PARK_XT 512M-DDR3 (64*16*4)
AS4553G-
N534G32Mn Thailand LX.PSK0C.018 PARK_XT 512M-DDR3 (64*16*4)
AS4553G-
N534G50Bn WW S2.PSK02.003 PARK_XT 512M-DDR3 (64*16*4)
AS4553G-
N534G50Mn Singapore LX.PSK02.007 PARK_XT 512M-DDR3 (64*16*4)
AS4553G-
N534G50Mn Thailand LX.PSK0C.002 PARK_XT 512M-DDR3 (64*16*4)
AS4553G-
N534G64Mn Singapore LX.PSK02.008 PARK_XT 512M-DDR3 (64*16*4)
AS4553G-
N534G64Mn Thailand LX.PSK0C.010 PARK_XT 512M-DDR3 (64*16*4)
AS4553G-
N832G32Mn China LX.PSK01.002 PARK_XT 512M-DDR3 (64*16*4)
AS4553G-
N832G32Mn China LX.PSK01.001 PARK_XT 512M-DDR3 (64*16*4)
AS4553G-
N832G32Mn Philippines LX.PSK0C.025 PARK_XT 512M-DDR3 (64*16*4)
AS4553G-
N832G32Mn Singapore LX.PSK02.002 PARK_XT 512M-DDR3 (64*16*4)
AS4553G-
N832G32Mn Thailand LX.PSK0C.021 PARK_XT 512M-DDR3 (64*16*4)
AS4553G-
N832G50Mn GCTWN LX.PSK02.022 PARK_XT 512M-DDR3 (64*16*4)
AS4553G-
N832G50Mn Thailand LX.PSK0C.022 PARK_XT 512M-DDR3 (64*16*4)
AS4553G-
N832G64Mn Thailand LX.PSK0C.015 PARK_XT 512M-DDR3 (64*16*4)
AS4553G-
N834G32Mn Singapore LX.PSK02.005 PARK_XT 512M-DDR3 (64*16*4)
AS4553G-
N834G32Mn Thailand LX.PSK0C.005 PARK_XT 512M-DDR3 (64*16*4)
AS4553G-
N834G50Mn Singapore LX.PSK02.017 PARK_XT 512M-DDR3 (64*16*4)
AS4553G-
N834G50Mn Thailand LX.PSK0C.007 PARK_XT 512M-DDR3 (64*16*4)
AS4553G-
N834G64Bn Thailand LX.PSK02.012 PARK_XT 512M-DDR3 (64*16*4)
AS4553G-
N834G64Mn Singapore LX.PSK02.016 PARK_XT 512M-DDR3 (64*16*4)
AS4553G-
N834G64Mn Thailand LX.PSK0C.003 PARK_XT 512M-DDR3 (64*16*4)
AS4553G-
N932G32Mn Singapore LX.PSK02.003 PARK_XT 512M-DDR3 (64*16*4)
AS4553G-
N932G32Mn Thailand LX.PSK0C.011 PARK_XT 512M-DDR3 (64*16*4)
AS4553G-
N932G50Mn GCTWN LX.PSK02.021 PARK_XT 512M-DDR3 (64*16*4)
Model Country Acer Part No VGA Chip VRAM 1
161 Appendix A
AS4553G-
N932G50Mn Thailand LX.PSK0C.023 PARK_XT 512M-DDR3 (64*16*4)
AS4553G-
N932G64Mn Thailand LX.PSK0C.016 PARK_XT 512M-DDR3 (64*16*4)
AS4553G-
N934G32Mn Thailand LX.PSK0C.001 PARK_XT 512M-DDR3 (64*16*4)
AS4553G-
N934G50Bn WW S2.PSK0C.001 PARK_XT 512M-DDR3 (64*16*4)
AS4553G-
N934G50Mn Singapore LX.PSK02.011 PARK_XT 512M-DDR3 (64*16*4)
AS4553G-
N934G50Mn Thailand LX.PSK0C.008 PARK_XT 512M-DDR3 (64*16*4)
AS4553G-
N934G64Mn Singapore LX.PSK02.014 PARK_XT 512M-DDR3 (64*16*4)
AS4553G-
N934G64Mn Thailand LX.PSK0C.004 PARK_XT 512M-DDR3 (64*16*4)
AS4553G-
N936G50Bn WW S2.PSK02.005 PARK_XT 512M-DDR3 (64*16*4)
AS4553G-
N936G50Bn WW S2.PSK02.005 PARK_XT 512M-DDR3 (64*16*4)
AS4553G-
N936G64Mn Singapore LX.PSK02.015 PARK_XT 512M-DDR3 (64*16*4)
AS4553G-
P322G50Mn GCTWN LX.PSK02.010 PARK_XT 512M-DDR3 (64*16*4)
AS4553G-
P324G50Mn Singapore LX.PSK02.019 PARK_XT 512M-DDR3 (64*16*4)
AS4553G-
P522G50Mn GCTWN LX.PSK02.020 PARK_XT 512M-DDR3 (64*16*4)
AS4553G-
P522G50Mn Indonesia LX.PSK0C.026 PARK_XT 512M-DDR3 (64*16*4)
AS4553G-
P522G50Mn Malaysia LX.PSK02.013 PARK_XT 512M-DDR3 (64*16*4)
AS4553G-
P524G50Mn Singapore LX.PSK02.018 PARK_XT 512M-DDR3 (64*16*4)
AS4553-
N332G16Bn WW S2.PSK02.001 PARK_XT 512M-DDR3 (64*16*4)
AS4553-
N332G16Bn WW S2.PSU02.001 UMA N
AS4553-
N332G25Mn Thailand LX.PSU0C.001 UMA N
AS4553-
N332G32Mn Singapore LX.PSU02.003 UMA N
AS4553-
N332G32Mn Thailand LX.PSU0C.002 UMA N
AS4553-
N332G50Mn Thailand LX.PSU0C.003 UMA N
AS4553-
N332G64Mn Thailand LX.PSU0C.016 UMA N
AS4553-
N333G25Mi WW S2.PSU02.003 UMA N
Model Country Acer Part No VGA Chip VRAM 1
Appendix A 162
AS4553-
N333G25Mi WW S2.PSU02.003 UMA N
AS4553-
N333G32Mn Singapore LX.PSU02.007 UMA N
AS4553-
N334G32Mn Thailand LX.PSU0C.015 UMA N
AS4553-
N334G50Mn Thailand LX.PSU0C.004 UMA N
AS4553-
N334G64Mn Thailand LX.PSU0C.017 UMA N
AS4553-
N532G32Mn Singapore LX.PSU02.006 UMA N
AS4553-
N532G32Mn Thailand LX.PSU0C.005 UMA N
AS4553-
N532G50Mn Thailand LX.PSU0C.018 UMA N
AS4553-
N532G64Mn Thailand LX.PSU0C.007 UMA N
AS4553-
N534G32Mn Thailand LX.PSU0C.006 UMA N
AS4553-
N534G50Mn Singapore LX.PSU02.010 UMA N
AS4553-
N534G50Mn Thailand LX.PSU0C.019 UMA N
AS4553-
N534G64Mn Singapore LX.PSU02.001 UMA N
AS4553-
N534G64Mn Thailand LX.PSU0C.008 UMA N
AS4553-
N832G32Mn Singapore LX.PSU02.004 UMA N
AS4553-
N832G32Mn Thailand LX.PSU0C.009 UMA N
AS4553-
N832G50Mn Thailand LX.PSU0C.020 UMA N
AS4553-
N832G64Mn Thailand LX.PSU0C.012 UMA N
AS4553-
N834G32Mn Singapore LX.PSU02.002 UMA N
AS4553-
N834G32Mn Thailand LX.PSU0C.010 UMA N
AS4553-
N834G50Mn Singapore LX.PSU02.009 UMA N
AS4553-
N834G50Mn Thailand LX.PSU0C.011 UMA N
AS4553-
N834G64Mn Thailand LX.PSU0C.013 UMA N
AS4553-
N932G32Mn Singapore LX.PSU02.005 UMA N
AS4553-
N932G32Mn Thailand LX.PSU0C.021 UMA N
Model Country Acer Part No VGA Chip VRAM 1
163 Appendix A
AS4553-
N932G50Mn Thailand LX.PSU0C.022 UMA N
AS4553-
N932G64Mn Thailand LX.PSU0C.024 UMA N
AS4553-
N934G32Mn Thailand LX.PSU0C.014 UMA N
AS4553-
N934G50Mn Singapore LX.PSU02.008 UMA N
AS4553-
N934G50Mn Thailand LX.PSU0C.023 UMA N
AS4553-
N934G64Mn Thailand LX.PSU0C.025 UMA N
AS4553-
P321G16Mn Vietnam LX.PSU0C.027 UMA N
AS4553-
P322G32Mn Vietnam LX.PSU0C.026 UMA N
AS4553-
P522G25Mn WW S2.PSU02.002 UMA N
AS4553-
P524G32Mn Chile LX.PSU02.015 UMA N
AS4553-
P524G32Mn ACLA-Spanish LX.PSU02.014 UMA N
AS4553-
P524G32Mn ACLA-Spanish LX.PSU02.013 UMA N
AS4553-
P524G32Mn ACLA-Spanish LX.PSU02.012 UMA N
AS4553-
P524G32Mn ACLA-
Portuguese LX.PSU02.011 UMA N
Model Country Acer Part No Memory 1 Memory 2
AS4553-
1_BR2G25M_brn WW S2.PWD02.001 SO2GBIII13_BR N
AS4553-
1_BR2G25M_brn WW S2.PWD02.001 SO2GBIII13_BR N
AS4553-
1_BR3G25M_brn ACLA-
Portuguese LX.PWD01.001 SO2GBIII13_BR SO1GBIII13_BR
AS4553-
1_BR4G32M_brn ACLA-
Portuguese LX.PWD02.001 SO2GBIII13_BR SO2GBIII13_BR
AS4553G-
N332G32Mn Singapore LX.PSK02.001 SO2GBIII10 N
AS4553G-
N332G32Mn Thailand LX.PSK0C.019 SO2GBIII10 N
AS4553G-
N332G32Mn WW S2.PSK02.002 SO1GBIII10 SO1GBIII10
AS4553G-
N332G50Mn Thailand LX.PSK0C.012 SO2GBIII10 N
AS4553G-
N332G64Mn Thailand LX.PSK0C.024 SO2GBIII10 N
Model Country Acer Part No VGA Chip VRAM 1
Appendix A 164
AS4553G-
N334G32Mn Singapore LX.PSK02.009 SO2GBIII10 SO2GBIII10
AS4553G-
N334G32Mn Thailand LX.PSK0C.017 SO2GBIII10 SO2GBIII10
AS4553G-
N334G50Mn Thailand LX.PSK0C.006 SO2GBIII10 SO2GBIII10
AS4553G-
N334G64Mn Thailand LX.PSK0C.009 SO2GBIII10 SO2GBIII10
AS4553G-
N532G32Mn Singapore LX.PSK02.004 SO2GBIII10 N
AS4553G-
N532G32Mn Thailand LX.PSK0C.020 SO2GBIII10 N
AS4553G-
N532G50Mn Thailand LX.PSK0C.013 SO2GBIII10 N
AS4553G-
N532G64Mn Thailand LX.PSK0C.014 SO2GBIII10 N
AS4553G-
N534G32Mn WW S2.PSK02.004 SO2GBIII10 SO2GBIII10
AS4553G-
N534G32Mn WW S2.PSK02.004 SO2GBIII10 SO2GBIII10
AS4553G-
N534G32Mn Singapore LX.PSK02.006 SO2GBIII10 SO2GBIII10
AS4553G-
N534G32Mn Thailand LX.PSK0C.018 SO2GBIII10 SO2GBIII10
AS4553G-
N534G50Bn WW S2.PSK02.003 SO2GBIII10 SO2GBIII10
AS4553G-
N534G50Mn Singapore LX.PSK02.007 SO2GBIII10 SO2GBIII10
AS4553G-
N534G50Mn Thailand LX.PSK0C.002 SO2GBIII10 SO2GBIII10
AS4553G-
N534G64Mn Singapore LX.PSK02.008 SO2GBIII10 SO2GBIII10
AS4553G-
N534G64Mn Thailand LX.PSK0C.010 SO2GBIII10 SO2GBIII10
AS4553G-
N832G32Mn China LX.PSK01.002 SO2GBIII10 N
AS4553G-
N832G32Mn China LX.PSK01.001 SO2GBIII10 N
AS4553G-
N832G32Mn Philippines LX.PSK0C.025 SO2GBIII10 N
AS4553G-
N832G32Mn Singapore LX.PSK02.002 SO2GBIII10 N
AS4553G-
N832G32Mn Thailand LX.PSK0C.021 SO2GBIII10 N
AS4553G-
N832G50Mn GCTWN LX.PSK02.022 SO2GBIII10 N
AS4553G-
N832G50Mn Thailand LX.PSK0C.022 SO2GBIII10 N
AS4553G-
N832G64Mn Thailand LX.PSK0C.015 SO2GBIII10 N
Model Country Acer Part No Memory 1 Memory 2
165 Appendix A
AS4553G-
N834G32Mn Singapore LX.PSK02.005 SO2GBIII10 SO2GBIII10
AS4553G-
N834G32Mn Thailand LX.PSK0C.005 SO2GBIII10 SO2GBIII10
AS4553G-
N834G50Mn Singapore LX.PSK02.017 SO2GBIII10 SO2GBIII10
AS4553G-
N834G50Mn Thailand LX.PSK0C.007 SO2GBIII10 SO2GBIII10
AS4553G-
N834G64Bn Thailand LX.PSK02.012 SO2GBIII10 SO2GBIII10
AS4553G-
N834G64Mn Singapore LX.PSK02.016 SO2GBIII10 SO2GBIII10
AS4553G-
N834G64Mn Thailand LX.PSK0C.003 SO2GBIII10 SO2GBIII10
AS4553G-
N932G32Mn Singapore LX.PSK02.003 SO2GBIII10 N
AS4553G-
N932G32Mn Thailand LX.PSK0C.011 SO2GBIII10 N
AS4553G-
N932G50Mn GCTWN LX.PSK02.021 SO2GBIII10 N
AS4553G-
N932G50Mn Thailand LX.PSK0C.023 SO2GBIII10 N
AS4553G-
N932G64Mn Thailand LX.PSK0C.016 SO2GBIII10 N
AS4553G-
N934G32Mn Thailand LX.PSK0C.001 SO2GBIII10 SO2GBIII10
AS4553G-
N934G50Bn WW S2.PSK0C.001 SO2GBIII10 SO2GBIII10
AS4553G-
N934G50Mn Singapore LX.PSK02.011 SO2GBIII10 SO2GBIII10
AS4553G-
N934G50Mn Thailand LX.PSK0C.008 SO2GBIII10 SO2GBIII10
AS4553G-
N934G64Mn Singapore LX.PSK02.014 SO2GBIII10 SO2GBIII10
AS4553G-
N934G64Mn Thailand LX.PSK0C.004 SO2GBIII10 SO2GBIII10
AS4553G-
N936G50Bn WW S2.PSK02.005 SO2GBIII10 SO4GBIII10
AS4553G-
N936G50Bn WW S2.PSK02.005 SO2GBIII10 SO4GBIII10
AS4553G-
N936G64Mn Singapore LX.PSK02.015 SO4GBIII10 SO2GBIII10
AS4553G-
P322G50Mn GCTWN LX.PSK02.010 SO2GBIII10 N
AS4553G-
P324G50Mn Singapore LX.PSK02.019 SO2GBIII10 SO2GBIII10
AS4553G-
P522G50Mn GCTWN LX.PSK02.020 SO2GBIII10 N
AS4553G-
P522G50Mn Indonesia LX.PSK0C.026 SO2GBIII10 N
Model Country Acer Part No Memory 1 Memory 2
Appendix A 166
AS4553G-
P522G50Mn Malaysia LX.PSK02.013 SO2GBIII10 N
AS4553G-
P524G50Mn Singapore LX.PSK02.018 SO2GBIII10 SO2GBIII10
AS4553-
N332G16Bn WW S2.PSK02.001 SO1GBIII10 SO1GBIII10
AS4553-
N332G16Bn WW S2.PSU02.001 SO1GBIII10 SO1GBIII10
AS4553-
N332G25Mn Thailand LX.PSU0C.001 SO2GBIII10 N
AS4553-
N332G32Mn Singapore LX.PSU02.003 SO2GBIII10 N
AS4553-
N332G32Mn Thailand LX.PSU0C.002 SO2GBIII10 N
AS4553-
N332G50Mn Thailand LX.PSU0C.003 SO2GBIII10 N
AS4553-
N332G64Mn Thailand LX.PSU0C.016 SO2GBIII10 N
AS4553-
N333G25Mi WW S2.PSU02.003 SO1GBIII10 SO2GBIII10
AS4553-
N333G25Mi WW S2.PSU02.003 SO1GBIII10 SO2GBIII10
AS4553-
N333G32Mn Singapore LX.PSU02.007 SO2GBIII10 SO1GBIII10
AS4553-
N334G32Mn Thailand LX.PSU0C.015 SO2GBIII10 SO2GBIII10
AS4553-
N334G50Mn Thailand LX.PSU0C.004 SO2GBIII10 SO2GBIII10
AS4553-
N334G64Mn Thailand LX.PSU0C.017 SO2GBIII10 SO2GBIII10
AS4553-
N532G32Mn Singapore LX.PSU02.006 SO2GBIII10 N
AS4553-
N532G32Mn Thailand LX.PSU0C.005 SO2GBIII10 N
AS4553-
N532G50Mn Thailand LX.PSU0C.018 SO2GBIII10 N
AS4553-
N532G64Mn Thailand LX.PSU0C.007 SO2GBIII10 N
AS4553-
N534G32Mn Thailand LX.PSU0C.006 SO2GBIII10 SO2GBIII10
AS4553-
N534G50Mn Singapore LX.PSU02.010 SO2GBIII10 SO2GBIII10
AS4553-
N534G50Mn Thailand LX.PSU0C.019 SO2GBIII10 SO2GBIII10
AS4553-
N534G64Mn Singapore LX.PSU02.001 SO2GBIII10 SO2GBIII10
AS4553-
N534G64Mn Thailand LX.PSU0C.008 SO2GBIII10 SO2GBIII10
AS4553-
N832G32Mn Singapore LX.PSU02.004 SO2GBIII10 N
Model Country Acer Part No Memory 1 Memory 2
167 Appendix A
AS4553-
N832G32Mn Thailand LX.PSU0C.009 SO2GBIII10 N
AS4553-
N832G50Mn Thailand LX.PSU0C.020 SO2GBIII10 N
AS4553-
N832G64Mn Thailand LX.PSU0C.012 SO2GBIII10 N
AS4553-
N834G32Mn Singapore LX.PSU02.002 SO2GBIII10 SO2GBIII10
AS4553-
N834G32Mn Thailand LX.PSU0C.010 SO2GBIII10 SO2GBIII10
AS4553-
N834G50Mn Singapore LX.PSU02.009 SO2GBIII10 SO2GBIII10
AS4553-
N834G50Mn Thailand LX.PSU0C.011 SO2GBIII10 SO2GBIII10
AS4553-
N834G64Mn Thailand LX.PSU0C.013 SO2GBIII10 SO2GBIII10
AS4553-
N932G32Mn Singapore LX.PSU02.005 SO2GBIII10 N
AS4553-
N932G32Mn Thailand LX.PSU0C.021 SO2GBIII10 N
AS4553-
N932G50Mn Thailand LX.PSU0C.022 SO2GBIII10 N
AS4553-
N932G64Mn Thailand LX.PSU0C.024 SO2GBIII10 N
AS4553-
N934G32Mn Thailand LX.PSU0C.014 SO2GBIII10 SO2GBIII10
AS4553-
N934G50Mn Singapore LX.PSU02.008 SO2GBIII10 SO2GBIII10
AS4553-
N934G50Mn Thailand LX.PSU0C.023 SO2GBIII10 SO2GBIII10
AS4553-
N934G64Mn Thailand LX.PSU0C.025 SO2GBIII10 SO2GBIII10
AS4553-
P321G16Mn Vietnam LX.PSU0C.027 SO1GBIII10 N
AS4553-
P322G32Mn Vietnam LX.PSU0C.026 SO2GBIII10 N
AS4553-
P522G25Mn WW S2.PSU02.002 SO1GBIII10 SO1GBIII10
AS4553-
P524G32Mn Chile LX.PSU02.015 SO2GBIII10 SO2GBIII10
AS4553-
P524G32Mn ACLA-
Spanish LX.PSU02.014 SO2GBIII10 SO2GBIII10
AS4553-
P524G32Mn ACLA-
Spanish LX.PSU02.013 SO2GBIII10 SO2GBIII10
AS4553-
P524G32Mn ACLA-
Spanish LX.PSU02.012 SO2GBIII10 SO2GBIII10
AS4553-
P524G32Mn ACLA-
Portuguese LX.PSU02.011 SO2GBIII10 SO2GBIII10
Model Country Acer Part No Memory 1 Memory 2
Appendix A 168
Model Country Acer Part No HDD 1(GB) ODD
AS4553-
1_BR2G25M_brn WW S2.PWD02.001 N250GB5.4KS_BR NSM8XS_BR
AS4553-
1_BR2G25M_brn WW S2.PWD02.001 N250GB5.4KS_BR NSM8XS_BR
AS4553-
1_BR3G25M_brn ACLA-
Portuguese LX.PWD01.001 N250GB5.4KS_BR NSM8XS_BR
AS4553-
1_BR4G32M_brn ACLA-
Portuguese LX.PWD02.001 N320GB5.4KS_BR NSM8XS_BR
AS4553G-
N332G32Mn Singapore LX.PSK02.001 N320GB5.4KS NSM8XS
AS4553G-
N332G32Mn Thailand LX.PSK0C.019 N320GB5.4KS NSM8XS
AS4553G-
N332G32Mn WW S2.PSK02.002 N320GB5.4KS NSM8XS
AS4553G-
N332G50Mn Thailand LX.PSK0C.012 N500GB5.4KS NSM8XS
AS4553G-
N332G64Mn Thailand LX.PSK0C.024 N640GB5.4KS NSM8XS
AS4553G-
N334G32Mn Singapore LX.PSK02.009 N320GB5.4KS NSM8XS
AS4553G-
N334G32Mn Thailand LX.PSK0C.017 N320GB5.4KS NSM8XS
AS4553G-
N334G50Mn Thailand LX.PSK0C.006 N500GB5.4KS NSM8XS
AS4553G-
N334G64Mn Thailand LX.PSK0C.009 N640GB5.4KS NSM8XS
AS4553G-
N532G32Mn Singapore LX.PSK02.004 N320GB5.4KS NSM8XS
AS4553G-
N532G32Mn Thailand LX.PSK0C.020 N320GB5.4KS NSM8XS
AS4553G-
N532G50Mn Thailand LX.PSK0C.013 N500GB5.4KS NSM8XS
AS4553G-
N532G64Mn Thailand LX.PSK0C.014 N640GB5.4KS NSM8XS
AS4553G-
N534G32Mn WW S2.PSK02.004 N320GB5.4KS NSM8XS
AS4553G-
N534G32Mn WW S2.PSK02.004 N320GB5.4KS NSM8XS
AS4553G-
N534G32Mn Singapore LX.PSK02.006 N320GB5.4KS NSM8XS
AS4553G-
N534G32Mn Thailand LX.PSK0C.018 N320GB5.4KS NSM8XS
AS4553G-
N534G50Bn WW S2.PSK02.003 N500GB5.4KS NBDCB4XS
AS4553G-
N534G50Mn Singapore LX.PSK02.007 N500GB5.4KS NSM8XS
AS4553G-
N534G50Mn Thailand LX.PSK0C.002 N500GB5.4KS NSM8XS
169 Appendix A
AS4553G-
N534G64Mn Singapore LX.PSK02.008 N640GB5.4KS NSM8XS
AS4553G-
N534G64Mn Thailand LX.PSK0C.010 N640GB5.4KS NSM8XS
AS4553G-
N832G32Mn China LX.PSK01.002 N320GB5.4KS NSM8XS
AS4553G-
N832G32Mn China LX.PSK01.001 N320GB5.4KS NSM8XS
AS4553G-
N832G32Mn Philippines LX.PSK0C.025 N320GB5.4KS NSM8XS
AS4553G-
N832G32Mn Singapore LX.PSK02.002 N320GB5.4KS NSM8XS
AS4553G-
N832G32Mn Thailand LX.PSK0C.021 N320GB5.4KS NSM8XS
AS4553G-
N832G50Mn GCTWN LX.PSK02.022 N500GB5.4KS NSM8XS
AS4553G-
N832G50Mn Thailand LX.PSK0C.022 N500GB5.4KS NSM8XS
AS4553G-
N832G64Mn Thailand LX.PSK0C.015 N640GB5.4KS NSM8XS
AS4553G-
N834G32Mn Singapore LX.PSK02.005 N320GB5.4KS NSM8XS
AS4553G-
N834G32Mn Thailand LX.PSK0C.005 N320GB5.4KS NSM8XS
AS4553G-
N834G50Mn Singapore LX.PSK02.017 N500GB5.4KS NSM8XS
AS4553G-
N834G50Mn Thailand LX.PSK0C.007 N500GB5.4KS NSM8XS
AS4553G-
N834G64Bn Thailand LX.PSK02.012 N640GB5.4KS NBDCB4XS
AS4553G-
N834G64Mn Singapore LX.PSK02.016 N640GB5.4KS NSM8XS
AS4553G-
N834G64Mn Thailand LX.PSK0C.003 N640GB5.4KS NSM8XS
AS4553G-
N932G32Mn Singapore LX.PSK02.003 N320GB5.4KS NSM8XS
AS4553G-
N932G32Mn Thailand LX.PSK0C.011 N320GB5.4KS NSM8XS
AS4553G-
N932G50Mn GCTWN LX.PSK02.021 N500GB5.4KS NSM8XS
AS4553G-
N932G50Mn Thailand LX.PSK0C.023 N500GB5.4KS NSM8XS
AS4553G-
N932G64Mn Thailand LX.PSK0C.016 N640GB5.4KS NSM8XS
AS4553G-
N934G32Mn Thailand LX.PSK0C.001 N320GB5.4KS NSM8XS
AS4553G-
N934G50Bn WW S2.PSK0C.001 N500GB5.4KS NBDCB4XS
AS4553G-
N934G50Mn Singapore LX.PSK02.011 N500GB5.4KS NSM8XS
Model Country Acer Part No HDD 1(GB) ODD
Appendix A 170
AS4553G-
N934G50Mn Thailand LX.PSK0C.008 N500GB5.4KS NSM8XS
AS4553G-
N934G64Mn Singapore LX.PSK02.014 N640GB5.4KS NSM8XS
AS4553G-
N934G64Mn Thailand LX.PSK0C.004 N640GB5.4KS NSM8XS
AS4553G-
N936G50Bn WW S2.PSK02.005 N500GB5.4KS NBDCB4XS
AS4553G-
N936G50Bn WW S2.PSK02.005 N500GB5.4KS NBDCB4XS
AS4553G-
N936G64Mn Singapore LX.PSK02.015 N640GB5.4KS NSM8XS
AS4553G-
P322G50Mn GCTWN LX.PSK02.010 N500GB5.4KS NSM8XS
AS4553G-
P324G50Mn Singapore LX.PSK02.019 N500GB5.4KS NSM8XS
AS4553G-
P522G50Mn GCTWN LX.PSK02.020 N500GB5.4KS NSM8XS
AS4553G-
P522G50Mn Indonesia LX.PSK0C.026 N500GB5.4KS NSM8XS
AS4553G-
P522G50Mn Malaysia LX.PSK02.013 N500GB5.4KS NSM8XS
AS4553G-
P524G50Mn Singapore LX.PSK02.018 N500GB5.4KS NSM8XS
AS4553-
N332G16Bn WW S2.PSK02.001 N160GB5.4KS NBDCB4XS
AS4553-
N332G16Bn WW S2.PSU02.001 N160GB5.4KS NBDCB4XS
AS4553-
N332G25Mn Thailand LX.PSU0C.001 N250GB5.4KS NSM8XS
AS4553-
N332G32Mn Singapore LX.PSU02.003 N320GB5.4KS NSM8XS
AS4553-
N332G32Mn Thailand LX.PSU0C.002 N320GB5.4KS NSM8XS
AS4553-
N332G50Mn Thailand LX.PSU0C.003 N500GB5.4KS NSM8XS
AS4553-
N332G64Mn Thailand LX.PSU0C.016 N640GB5.4KS NSM8XS
AS4553-
N333G25Mi WW S2.PSU02.003 N250GB5.4KS NSM8XS
AS4553-
N333G25Mi WW S2.PSU02.003 N250GB5.4KS NSM8XS
AS4553-
N333G32Mn Singapore LX.PSU02.007 N320GB5.4KS NSM8XS
AS4553-
N334G32Mn Thailand LX.PSU0C.015 N320GB5.4KS NSM8XS
AS4553-
N334G50Mn Thailand LX.PSU0C.004 N500GB5.4KS NSM8XS
AS4553-
N334G64Mn Thailand LX.PSU0C.017 N640GB5.4KS NSM8XS
Model Country Acer Part No HDD 1(GB) ODD
171 Appendix A
AS4553-
N532G32Mn Singapore LX.PSU02.006 N320GB5.4KS NSM8XS
AS4553-
N532G32Mn Thailand LX.PSU0C.005 N320GB5.4KS NSM8XS
AS4553-
N532G50Mn Thailand LX.PSU0C.018 N500GB5.4KS NSM8XS
AS4553-
N532G64Mn Thailand LX.PSU0C.007 N640GB5.4KS NSM8XS
AS4553-
N534G32Mn Thailand LX.PSU0C.006 N320GB5.4KS NSM8XS
AS4553-
N534G50Mn Singapore LX.PSU02.010 N500GB5.4KS NSM8XS
AS4553-
N534G50Mn Thailand LX.PSU0C.019 N500GB5.4KS NSM8XS
AS4553-
N534G64Mn Singapore LX.PSU02.001 N640GB5.4KS NSM8XS
AS4553-
N534G64Mn Thailand LX.PSU0C.008 N640GB5.4KS NSM8XS
AS4553-
N832G32Mn Singapore LX.PSU02.004 N320GB5.4KS NSM8XS
AS4553-
N832G32Mn Thailand LX.PSU0C.009 N320GB5.4KS NSM8XS
AS4553-
N832G50Mn Thailand LX.PSU0C.020 N500GB5.4KS NSM8XS
AS4553-
N832G64Mn Thailand LX.PSU0C.012 N640GB5.4KS NSM8XS
AS4553-
N834G32Mn Singapore LX.PSU02.002 N320GB5.4KS NSM8XS
AS4553-
N834G32Mn Thailand LX.PSU0C.010 N320GB5.4KS NSM8XS
AS4553-
N834G50Mn Singapore LX.PSU02.009 N500GB5.4KS NSM8XS
AS4553-
N834G50Mn Thailand LX.PSU0C.011 N500GB5.4KS NSM8XS
AS4553-
N834G64Mn Thailand LX.PSU0C.013 N640GB5.4KS NSM8XS
AS4553-
N932G32Mn Singapore LX.PSU02.005 N320GB5.4KS NSM8XS
AS4553-
N932G32Mn Thailand LX.PSU0C.021 N320GB5.4KS NSM8XS
AS4553-
N932G50Mn Thailand LX.PSU0C.022 N500GB5.4KS NSM8XS
AS4553-
N932G64Mn Thailand LX.PSU0C.024 N640GB5.4KS NSM8XS
AS4553-
N934G32Mn Thailand LX.PSU0C.014 N320GB5.4KS NSM8XS
AS4553-
N934G50Mn Singapore LX.PSU02.008 N500GB5.4KS NSM8XS
AS4553-
N934G50Mn Thailand LX.PSU0C.023 N500GB5.4KS NSM8XS
Model Country Acer Part No HDD 1(GB) ODD
Appendix A 172
AS4553-
N934G64Mn Thailand LX.PSU0C.025 N640GB5.4KS NSM8XS
AS4553-
P321G16Mn Vietnam LX.PSU0C.027 N160GB5.4KS NSM8XS
AS4553-
P322G32Mn Vietnam LX.PSU0C.026 N320GB5.4KS NSM8XS
AS4553-
P522G25Mn WW S2.PSU02.002 N250GB5.4KS NSM8XS
AS4553-
P524G32Mn Chile LX.PSU02.015 N320GB5.4KS NSM8XS
AS4553-
P524G32Mn ACLA-
Spanish LX.PSU02.014 N320GB5.4KS NSM8XS
AS4553-
P524G32Mn ACLA-
Spanish LX.PSU02.013 N320GB5.4KS NSM8XS
AS4553-
P524G32Mn ACLA-
Spanish LX.PSU02.012 N320GB5.4KS NSM8XS
AS4553-
P524G32Mn ACLA-
Portuguese LX.PSU02.011 N320GB5.4KS NSM8XS
Model Country Acer Part No HDD 1(GB) ODD
Appendix B 173
Test Compatible Components
This computer’s compatibility is tested and verified by Acer’s internal testing department. All of its system
functions are tested under Windows® 7 environment.
Refer to the following lists for components, adapter cards, and peripherals which have passed these tests.
Regarding configuration, combination and test procedures, please refer to the Aspire 4553/4553G
Compatibility Test Report released by the Acer Mobile System Testing Department.
Appendix B
174 Appendix B
Microsoft® Windows® 7 Environment Test
Vendor Type Description Part No.
A cover
10000981
MISC Black IMR Black IMR LZ.21000.044
Adapter
10001023
LITE-ON 65W Adapter LITE-ON 65W 19V 1.7x5.5x11 Yellow PA-
1650-22AC LV5 LED LF AP.06503.024
10001023
LITE-ON 65W Adapter LITE-ON 65W 19V 1.7x5.5x11 Yellow (PA-
1650-22AG), LV5 Timeline LF AP.06503.026
10001023
LITE-ON 65W_BR Adapter LITE-ON 65W_BR 19V 1.7x5.5x11 Yellow
PA-1650-22AC LV5 LED LF (Brazil) AP.065B3.024
10001023
LITE-ON 65W_BR Adapter LITE-ON 65W_BR 19V 1.7x5.5x11 Yellow
PA-1650-22AB, LV5 LED LF (Brazil, by Palladium) AP.065B3.025
10001023
LITE-ON 90W Adapter LITE-ON 90W 19V 1.7x5.5x11 Blue PA-
1900-34AR, LV5 LED LF AP.09003.021
10001081
DELTA 65W Adapter DELTA 65W 19V 1.7x5.5x11 Yellow ADP-
65JH DB A, LV5 LED LF AP.06501.026
10001081
DELTA 65W Adapter DELTA 65W 19V 1.7x5.5x11 Yellow (ADP-
65MH B A) LV5, Timeline LF LF AP.06501.027
10001081
DELTA 65W_BR Adapter DELTA 65W_BR 19V 1.7x5.5x11 Yellow
ADP-65JH DB A, LV5 LED LF (Brazil) AP.065B1.026
10001081
DELTA 90W Adapter DELTA 90W 19V 1.7x5.5x11 Blue ADP-
90CD DB A, LV5 LED LF AP.09001.027
10001081
DELTA 90W Adapter DELTA 90W 19V 1.7x5.5x11 Blue ADP-
90CD DBH, LV5 LED LF AP.09001.031
60002015
HIPRO 65W Adapter HIPRO 65W 19V 1.7x5.5x11 Yellow HP-
A0652R3B 1LF, LV5 LED LF AP.0650A.012
60002015
HIPRO 65W Adapter HIPRO 65W 19V 1.7x5.5x11 Yellow HP-
A0653R3B 1LF,LV5 Timeline,Rev.02 w/Korea
safety LF w/Korea safety logo
AP.0650A.016
60002015
HIPRO 90W Adapter HIPRO 90W 19V 1.7x5.5x11 Blue HP-
A0904A3 B1LF, LV5 LED LF AP.0900A.005
Audio Codec
10004786
REALTEK ALC271X Realtek ALC271X LZ.21000.069
B cover
9999995
ONE TIME
VENDER
Mirror w/
Camera Mirror w/Camera LZ.21000.009
Battery
10001063
SONY 6CELL2.2 Battery SONY AS10B Li-Ion 3S2P SONY 6 cell
4400mAh Main COMMON ID:AS10B41 BT.00604.048
60001535
PANASONI
C
6CELL2.2 Battery PANASONIC AS10B Li-Ion 3S2P
PANASONIC 6 cell 4400mAh Main COMMON
ID:AS10B51
BT.00605.061
60001921
SANYO 6CELL2.2 Battery SANYO AS10B Li-Ion 3S2P SANYO 6 cell
4400mAh Main COMMON ID:AS10B31 BT.00603.110
60001921
SANYO 6CELL2.2_B
RBattery SANYO AS10B Li-Ion 3S2P SANYO 6 cell
4400mAh Main COMMON ID:AS10B31, for Brazil BT.006B3.110
Appendix B 175
60002162
SIMPLO 6CELL2.2 Battery SIMPLO AS10B Li-Ion 3S2P PANASONIC
6 cell 4400mAh Main COMMON ID:AS10B71 BT.00607.122
60002162
SIMPLO 6CELL2.2 Battery SIMPLO AS10B Li-Ion 3S2P LGC 6 cell
4400mAh Main COMMON ID:AS10B73 BT.00607.123
60002162
SIMPLO 6CELL2.2 Battery SIMPLO AS10B Li-Ion 3S2P SAMSUNG 6
cell 4400mAh Main COMMON ID:AS10B75 BT.00607.124
60002162
SIMPLO 6CELL2.2_B
RBattery SIMPLO AS10B Li-Ion 3S2P PANASONIC
6 cell 4400mAh Main COMMON ID:AS10B71, for
Brazil
BT.006B7.122
60002162
SIMPLO 6CELL2.2_B
RBattery SIMPLO AS10B Li-Ion 3S2P LGC 6 cell
4400mAh Main COMMON ID:AS10B73, for Brazil BT.006B7.123
60002162
SIMPLO 6CELL2.2_B
RBattery SIMPLO AS10B Li-Ion 3S2P SAMSUNG 6
cell 4400mAh Main COMMON ID:AS10B75, for
Brazil
BT.006B7.124
60013145
SAMSUNG
SDI
6CELL2.2 Battery SAMSUNG AS10B Li-Ion 3S2P
SAMSUNG 6 cell 4400mAh Main COMMON
ID:AS10B61
BT.00606.007
Bluetooth
10001018
HON HAI BT 3.0 Foxconn Bluetooth BRM 2046 BT3.0
(T60H928.33) f/w:861 BH.21100.008
10001018
HON HAI BT 3.0 Foxconn Bluetooth ATH AR3011 (BT3.0) BH.21100.009
10001018
HON HAI BT 3.0 Foxconn Bluetooth BRM 2070 (T77H114.01) BT
3.0 BH.21100.010
23707801
FOXCONN
TW
BT 2.1 Foxconn Bluetooth BRM 2046 BT2.1
(T60H928.33) f/w:861 BH.21100.004
23707801
FOXCONN
TW
BT 2.1 Foxconn Bluetooth ATH AR3011 BH.21100.005
23707801
FOXCONN
TW
BT 2.1 Foxconn Bluetooth BRM 2070 (T77H114.01) BH.21100.007
Camera
10001023
LITE-ON 1.3M Liteon 1.3M LT9665AL (09P2SF119) AM.21400.069
10001023
LITE-ON 1.3M Liteon 1.3M LT6AASP( 09P2BF127) AM.21400.070
10001044
CHICONY 1.3M Chicony 1.3M CH9665SN (CNF9157) AM.21400.067
PLM00012
Suyin 1.3M Suyin 1.3M SY9665SN AM.21400.068
Card Reader
PLM00014
ODM 5 in 1-Build in 5 in 1-Build in MS, MS Pro, SD, SC, XD CR.21500.013
22554573
AMD AAN330 CPU AMD AthlonII N330 2.3G 1M 35W Dual-Core KC.AN002.33
0
22554573
AMD AAP320 CPU AMD AthlonII P320 2.1G 1M 25W Dual-Core KC.AP002.320
Vendor Type Description Part No.
176 Appendix B
22554573
AMD APN830 CPU AMD PhenomII N830 2.1G 35W 1.5M L2,
Triple-Core KC.PN002.83
0
22554573
AMD APN930 CPU AMD PhenomII N930 2.0G 2M 35W Quad-
Core KC.PN002.93
0
22554573
AMD ATN530 CPU AMD TurionII N530 2.5G 2M 35W Dual-Core KC.TN002.530
22554573
AMD ATP520 CPU AMD TurionII P520 2.3G 2M 25W Dual-Core KC.TP002.520
60002168
AMDISS AAP320_BR CPU AMD AthlonII P320 2.1G 1M 25W 2C (Brazil) KC.AP0B2.32
0
60002168
AMDISS ATP520_BR CPU AMD TurionII P520 2.3G 2M 25W 2C (Brazil) KC.TP0B2.52
0
HDD
60001922
TOSHIBA
DIGI
N160GB5.4K
SHDD TOSHIBA 2.5" 5400rpm 160GB
MK1665GSX, Capricorn BS, 320G/P SATA 8MB
LF F/W:GJ002J
KH.16004.008
60001922
TOSHIBA
DIGI
N250GB5.4K
SHDD TOSHIBA 2.5" 5400rpm 250GB
MK2565GSX, Capricorn BS, 320G/P SATA 8MB
LF F/W:GJ002J
KH.25004.005
60001922
TOSHIBA
DIGI
N320GB5.4K
SHDD TOSHIBA 2.5" 5400rpm 320GB Capricorn BS
,MK3265GSX SATA 8MB LF F/W:GJ002J KH.32004.004
60001922
TOSHIBA
DIGI
N500GB5.4K
SHDD TOSHIBA 2.5" 5400rpm 500GB
MK5065GSX,Capricorn BS, 320G/P SATA 8MB LF
F/W:GJ002J
KH.50004.002
60001922
TOSHIBA
DIGI
N640GB5.4K
SHDD TOSHIBA 2.5" 5400rpm 640GB
MK6465GSX,Capricorn BS,320G/P SATA 8MB LF
F/W:GJ002J
KH.64004.001
60001994
WD N160GB5.4K
SHDD WD 2.5" 5400rpm 160GB WD1600BEVT-
22A23T0 , WD, ML320S SATA 8MB LF F/
W:01.01A01
KH.16008.027
60001994
WD N160GB5.4K
S_BR HDD WD 2.5" 5400rpm 160GB WD1600BEVT-
22A23T0,ML320S SATA 8MB LF F/W:01.01A01 KH.160B8.023
60001994
WD N250GB5.4K
SHDD WD 2.5" 5400rpm 250GB WD2500BEVT-
22A23T0, WD, ML320S SATA 8MB LF F/
W:01.01A01.
KH.25008.025
60001994
WD N250GB5.4K
S_BR HDD WD 2.5" 5400rpm 250GB WD2500BEVT-
22A23T0, ML320S, WD SATA 8MB LF F/
W:01.01A01
KH.250B8.022
60001994
WD N320GB5.4K
SHDD WD 2.5" 5400rpm 320GB WD3200BEVT-
22A23T0,ML320S,WD SATA 8MB LF F/
W:01.01A01
KH.32008.019
60001994
WD N500GB5.4K
SHDD WD 2.5" 5400rpm 500GB WD5000BEVT-
22A0RT0, ML320M,WD SATA 8MB LF F/
W:01.01A01
KH.50008.017
60001994
WD N640GB5.4K
SHDD WD 2.5" 5400rpm 640GB WD6400BEVT-
22A0RT0, ML320 SATA 8MB LF F/W:01.01A01 KH.64008.004
60002005
HGST SG N160GB5.4K
SHDD HGST 2.5" 5400rpm 160GB
HTS545016B9A300 Panther B SATA LF F/W:C60F
Disk imbalance criteria = 0.014g-cm
KH.16007.026
Vendor Type Description Part No.
Appendix B 177
60002005
HGST SG N160GB5.4K
S_BR HDD HGST 2.5" 5400rpm 160GB
HTS545016B9A300, HGST, Panther B, 250G/P
SATA 8MB LF F/W:C60F
KH.160B7.026
60002005
HGST SG N250GB5.4K
SHDD HGST 2.5" 5400rpm 250GB
HTS545025B9A300 Panther B SATA LF F/W:C60F
Disk imbalance criteria = 0.014g-cm
KH.25007.016
60002005
HGST SG N250GB5.4K
S_BR HDD HGST 2.5" 5400rpm 250GB
HTS545025B9A300, Panther B with better
imbalance SATA 8MB LF F/W:C60F
KH.250B7.017
60002005
HGST SG N320GB5.4K
SHDD HGST 2.5" 5400rpm 320GB
HTS545032B9A300 Panther B SATA LF F/W:C60F
Disk imbalance criteria = 0.014g-cm
KH.32007.008
60002005
HGST SG N320GB5.4K
S_BR HDD HGST 2.5" 5400rpm 320GB
HTS545032B9A300, PantherB with better
imbalance SATA 8MB LF F/W:C60F
KH.320B7.001
60002005
HGST SG N500GB5.4K
SHDD HGST 2.5" 5400rpm 500GB
HTS545050B9A300 Panther B SATA LF F/W:C60F
Disk imbalance criteria = 0.014g-cm
KH.50007.010
60002005
HGST SG N500GB5.4K
S_BR HDD HGST 2.5" 5400rpm 500GB
HTS545050B9A300 Panther B for Brazil SATA LF
F/W:C60F Disk imbalance criteria = 0.014g-cm
KH.500B7.010
60002036
SEAGATE N160GB5.4K
SHDD SEAGATE 2.5" 5400rpm 160GB
ST9160314AS Wyatt SATA LF F/W:0001SDM1 KH.16001.042
60002036
SEAGATE N250GB5.4K
SHDD SEAGATE 2.5" 5400rpm 250GB
ST9250315AS Wyatt SATA LF F/W:0001SDM1 KH.25001.016
60002036
SEAGATE N320GB5.4K
SHDD SEAGATE 2.5" 5400rpm 320GB
ST9320325AS Wyatt SATA LF F/W:0001SDM1 KH.32001.017
60002036
SEAGATE N500GB5.4K
SHDD SEAGATE 2.5" 5400rpm 500GB
ST9500325AS Wyatt SATA LF F/W:0001SDM1 KH.50001.011
60002215
SAMSUNG N160GB5.4K
S_BR HDD SAMSUNG 2.5" 5400rpm 160GB M5,
HM160HI SATA LF F/W:HH100-08 (Brazil) KH.160BB.001
60002215
SAMSUNG N160GB5.4K
S_BR HDD SAMSUNG 2.5" 5400rpm 160GB HM161GI,
M7E, 320G/P SATA 8MB LF F/W:2AJ0002 KH.160BB.002
60002215
SAMSUNG N250GB5.4K
S_BR HDD SAMSUNG 2.5" 5400rpm 250GB M7,
HM250HI SATA LF F/W:2AC101-C4 (Brazil) KH.250BB.002
60002215
SAMSUNG N250GB5.4K
S_BR HDD SAMSUNG 2.5" 5400rpm 250GB HM251HI,
M7E, 320G/P SATA 8MB LF F/W:2AJ0002 KH.250BB.003
60002215
SAMSUNG N320GB5.4K
S_BR HDD SAMSUNG 2.5" 5400rpm 320GB HM321HI,
M7E, 320G/P SATA 8MB LF F/W:2AJ0002 KH.320BB.002
60002215
SAMSUNG N500GB5.4K
S_BR HDD SAMSUNG 2.5" 5400rpm 500GB M7, 250G/
P, HM500JI /ACE SATA 8MB LF F/W:2AC101C4
Brazil
KH.500BB.001
Keyboard
60004864
DARFON AC4T_A10B Keyboard ACER AC4T_A10B AC4T Internal 14
Standard Black Y2010 Acer Legend Texture KB.I140A.202
LAN
10017383
Atheros AR8151L Atheros AR8151L NI.22400.048
LCD
10001038
CMO NLED14WX
GAGS LED LCD CMO 14" WXGA Glare N140B6-L24 LF
200nit 8ms 650:1 (Power saving) LK.1400D.007
Vendor Type Description Part No.
178 Appendix B
60002215
SAMSUNG NLED14WX
GAGS LED LCD SAMSUNG 14" WXGA Glare
LTN140AT06-A01 LF 200nit 16ms LK.14006.010
60002215
SAMSUNG NLED14WX
GAGS LED LCD SAMSUNG 14" WXGA Glare
LTN140AT12-A01 LF 200nit 16ms 500:1 (Power
saving)
LK.14006.012
60003089
LG NLED14WX
GAGS LED LCD LPL 14" WXGA Glare LP140WH2-TLA2
LF 200nit 16ms 500:1 LK.14008.005
60003089
LG NLED14WX
GAGS LED LCD LPL 14" WXGA Glare LP140WH2-TLL1
LF 200nit 16ms 500:1 (Power saving) LK.14008.006
60003089
LG NLED14WX
GAGS_BR LED LCD LPL 14" WXGA Glare LP140WH2-TLL1
LF 200nit 16ms 500:1 (Brazil) (Power saving) LK.140B8.006
60003316
AUO NLED14WX
GAGS LED LCD AUO 14" WXGA Glare B140XW02 V1
LF 200nit 8ms 500:1 LK.14005.007
60003316
AUO NLED14WX
GAGS LED LCD AUO 14" WXGA Glare B140XW03 V0
LF 200nit 8ms 500:1 (Power saving) LK.14005.011
60003316
AUO NLED14WX
GAGS_BR LED LCD AUO 14" WXGA Glare B140XW03 V0
LF 200nit 8ms 500:1 (Brazil) LK.140B5.011
MEM
60001993
NANYA SO2GBIII13 Memory NANYA SO-DIMM DDRIII 1333 2GB
NT2GC64B8HC0NS-CG LF 128*8 0.065um KN.2GB03.01
7
60002045
HYNIX SO1GBIII10 Memory HYNIX SO-DIMM DDRIII 1066 1GB
HMT112S6BFR6C-G7 N0 LF 64*16 0.055um KN.1GB0G.02
5
60002045
HYNIX SO1GBIII13 Memory HYNIX SO-DIMM DDRIII 1333 1GB
HMT112S6TFR8C-H9 LF 128*8 0.055um KN.1GB0G.02
6
60002045
HYNIX SO1GBIII13_
BR Memory HYNIX SO-DIMM DDRIII 1333 1GB
HMT112S6TFR8C-H9 LF 128*8 0.055um Brazil KN.1GBBG.02
6
60002045
HYNIX SO2GBIII10 Memory HYNIX SO-DIMM DDRIII 1066 2GB
HMT125S6BFR8C-G7 N0 LF 128*8 0.055um KN.2GB0G.01
4
60002045
HYNIX SO2GBIII13 Memory HYNIX SO-DIMM DDRIII 1333 2GB
HMT125S6TFR8C-H9 LF 128*8 0.055um KN.2GB0G.01
6
60002045
HYNIX SO2GBIII13_
BR Memory HYNIX SO-DIMM DDRIII 1333 2GB
HMT125S6TFR8C-H9 LF 128*8 0.055um (Brazil) KN.2GBBG.01
6
60002045
HYNIX SO4GBIII13 Memory HYNIX SO-DIMM DDRIII 1333 4GB
HMT351S6AFR8C-H9 LF 256*8 0.055um KN.4GB0G.00
3
60002215
SAMSUNG SO1GBIII10 Memory SAMSUNG SO-DIMM DDRIII 1066 1GB
M471B2873EH1-CF8 LF 64*16 0.055um KN.1GB0B.02
8
60002215
SAMSUNG SO1GBIII13 Memory SAMSUNG SO-DIMM DDRIII 1333 1GB
M471B2873FHS-CH9 LF 128*8 46nm KN.1GB0B.03
5
60002215
SAMSUNG SO1GBIII13_
BR Memory SAMSUNG SO-DIMM DDRIII 1333 1GB
M471B2873FHS-CH9 LF 128*8 46nm Brazil KN.1GBBB.03
5
60002215
SAMSUNG SO2GBIII10 Memory SAMSUNG SO-DIMM DDRIII 1066 2GB
M471B5673EH1-CF8 LF 128*8 0.055um KN.2GB0B.01
2
60002215
SAMSUNG SO2GBIII13 Memory SAMSUNG SO-DIMM DDRIII 1333 2GB
M471B5673FH0-CH9 LF 128*8 46nm KN.2GB0B.02
3
60002215
SAMSUNG SO2GBIII13_
BR Memory SAMSUNG SO-DIMM DDRIII 1333 2GB
M471B5673FH0-CH9 LF 128*8 46nm (Brazil) KN.2GBBB.02
3
60002215
SAMSUNG SO4GBIII13 Memory SAMSUNG SO-DIMM DDRIII 1333 4GB
M471B5273CH0-CH9 LF 256*8 46nm KN.4GB0B.01
0
60004668
ELPIDA SO1GBIII10 Memory ELPIDA SO-DIMM DDRIII 1066 1GB
EBJ10UE8BDS0-AE-F LF 128*8 0.065um KN.1GB09.01
2
Vendor Type Description Part No.
Appendix B 179
60004668
ELPIDA SO1GBIII13 Memory ELPIDA SO-DIMM DDRIII 1333 1GB
EBJ10UE8BDS0-DJ-F LF 128*8 0.065um KN.1GB09.01
5
60004668
ELPIDA SO2GBIII10 Memory ELPIDA SO-DIMM DDRIII 1066 2GB
EBJ21UE8BDS0-AE-F LF 128*8 0.065um KN.2GB09.00
6
60004668
ELPIDA SO2GBIII13 Memory ELPIDA SO-DIMM DDRIII 1333 2GB
EBJ21UE8BDS0-DJ-F LF 128*8 0.065um KN.2GB09.00
7
60004668
ELPIDA SO2GBIII13_
BR Memory ELPIDA SO-DIMM DDRIII 1333 2GB
EBJ21UE8BDS0-DJ-F LF 128*8 0.065um (Brazil) KN.2GBB9.00
7
60004668
ELPIDA SO4GBIII10 Memory NONE SO-DIMM DDRIII 1066 4GB
dummy P/N LF KN.4GB00.00
1
60004668
ELPIDA SO4GBIII13 Memory ELPIDA SO-DIMM DDRIII 1333 4GB
EBJ41UF8BAS0-DJ-F LF 256*8 0.055um KN.4GB09.00
1
60024207
KINGSTON SO1GBIII13 Memory KINGSTON SO-DIMM DDRIII 1333 1GB
ACR128X64D3S1333C9 LF 128*8 0.065um KN.1GB07.00
4
60024207
KINGSTON SO2GBIII13 Memory KINGSTON SO-DIMM DDRIII 1333 2GB
ACR256X64D3S1333C9 LF 128*8 0.065um KN.2GB07.00
4
60025023
SMARTM SO1GBIII13_
BR Memory SMART SO-DIMM DDRIII 1333 1GB
SH564288FH8NWPHSFR LF Brazil KN.1GBBS.00
3
60025023
SMARTM SO2GBIII13_
BR Memory SMART SO-DIMM DDRIII 1333 2GB
SH564568FH8NWPHSFR LF Brazil KN.2GBBS.00
3
Modem
10001023
LITE-ON External USB
Lite+LSI
modem
External USB Lite+LSI modem LC.MOD00.00
1
NB Chipset
22554573
AMD AMDRS880
MAMD RS880M w/ HDCP EEPROM KI.22600.050
60002168
AMDISS AMDRS880
M_BR AMD RS880M w/ HDCP EEPROM (Brazil) KI.22600.053
ODD
10001063
SONY NBDCB4XS ODD SONY BD COMBO 12.7mm Tray DL 4X BC-
5500H LF W/O bezel SATA (HF + Windows 7) KO.0040E.003
10001063
SONY NSM8XS ODD SONY Super-Multi DRIVE 12.7mm Tray DL
8X AD-7585H LF W/O bezel SATA (HF + Windows
7)
KU.0080E.027
10001070
PHILIPS NBDCB4XS ODD PLDS BD COMBO 12.7mm Tray DL 4X DS-
4E1S LF W/O bezel SATA (Windows 7) KO.0040F.003
10001070
PHILIPS NSM8XS ODD PLDS Super-Multi DRIVE 12.7mm Tray DL
8X DS-8A4SH LF W/O bezel SATA (HF + Windows
7)
KU.0080F.006
60001535
PANASONI
C
NBDRW4XS ODD PANASONIC BD RW 12.7mm Tray DL 4X
UJ240A LF W/O bezel SATA (HF+Windows 7) KU.00407.015
60001535
PANASONI
C
NSM8XS ODD PANASONIC Super-Multi DRIVE 12.7mm
Tray DL 8X UJ890A LF W/O bezel SATA (HF +
Windows 7)
KU.00807.070
60001922
TOSHIBA
DIGI
NSM8XS ODD TOSHIBA Super-Multi DRIVE 12.7mm Tray
DL 8X TS-L633C LF W/O bezel SATA (HF +
Windows 7)
KU.00801.035
Vendor Type Description Part No.
180 Appendix B
60001922
TOSHIBA
DIGI
NSM8XS_B
RODD TOSHIBA Super-Multi DRIVE 12.7mm Tray
DL 8X TS-L633C LF W/O bezel SATA (HF +
Windows 7) (Brazel)
KU.008B1.035
610105
HLDS NBDCB4XS ODD HLDS BD COMBO 12.7mm Tray DL 4X
CT21N LF W/O bezel 1.00 SATA (HF + Windows
7)
KO.0040D.004
610105
HLDS NSM8XS ODD HLDS Super-Multi DRIVE 12.7mm Tray DL
8X GT30N LF W/O bezel SATA (HF + Windows 7) KU.0080D.048
610105
HLDS NSM8XS ODD HLDS Super-Multi DRIVE 12.7mm Tray DL
8X GT31N (R5-1) LF W/O bezel SATA with
Renesas Solution (HF + Windows 7)
KU.0080D.054
610105
HLDS NSM8XS_B
RODD HLDS Super-Multi DRIVE 12.7mm Tray DL
8X GT30N LF W/O bezel SATA (HF + Windows 7)
(Brazel)
KU.008BD.04
8
SB Chipset
22554573
AMD AMDSB820
MAMD SB820M KI.22800.016
60002168
AMDISS AMDSB820
M_BR AMD SB820M (Brazil) KI.22800.018
Side Port
10000981
MISC 128MB-
DDR3
(64*16*1)
Side Port 128MB-DDR3 (64*16*1) LZ.24100.001
22554573
AMD VR1GbIII8 VRAM ATI Graphic DDRIII 800 1Gb 23BY2387MB-
12 LF+HF VR.1GB0T.00
2
60002045
HYNIX VR1GbIII8 VRAM HYNIX Graphic DDRIII 800 1Gb
H5TQ1G63BFR-12C LF VR.1GB0G.00
4
60002215
SAMSUNG VR1GbIII8 VRAM SAMSUNG Graphic DDRIII 800 1Gb
K4W1G1646E-HC12 LF VR.1GB0B.00
6
Software
10000981
MISC McAfee Antivirus application McAfee SR.23900.001
VGA Chip
22554573
AMD PARK_XT AMD PARK_XT 40nm 29mm*29mm M2 package KI.23200.162
22554573
AMD UMA UMA (AMD) KI.23200.154
VRAM
10000981
MISC 512M-DDR3
(64*16*4) 512M-DDR3 64*16*4 KI.23300.019
60002045
HYNIX VR1GbIII8 VRAM HYNIX Graphic DDRIII 800 1Gb
H5TQ1G63BFR-12C LF VR.1GB0G.00
4
60002045
HYNIX VR2GbIII8 VRAM HYNIX Graphic DDRIII 800 2Gb
H5TQ2G63BFR-12C LF+HF VR.2GB0G.00
1
60002215
SAMSUNG VR1GbIII8 VRAM SAMSUNG Graphic DDRIII 800 1Gb
K4W1G1646E-HC12 LF VR.1GB0B.00
6
60002215
SAMSUNG VR2GbIII8 VRAM SAMSUNG Graphic DDRIII 800 2Gb
K4W2G1646B-HC12 LF+HF VR.2GB0B.00
1
Vendor Type Description Part No.
Appendix B 181
WiFi Antenna
10000105
WNC PIFA PIFA LZ.23500.006
Wireless LAN
23707801
FOXCONN
TW
3rd WiFi 2x2
BGN Foxconn Wireless LAN Atheros HB93 2x2 BGN
(HM) NI.23600.062
23707801
FOXCONN
TW
3rd WiFi 2x2
BGN Foxconn Wireless LAN Broadcomm 43225 2x2
BGN (HM) T77H103.00 NI.23600.066
23707801
FOXCONN
TW
3rd WiFi 2x2
BGN Foxconn Wireless LAN Atheros HB97 2x2 BGN
(HM) NI.23600.072
23707801
FOXCONN
TW
3rd WiFi BG Foxconn Wirelss LAN Atheros HB95BG (HM)
T77H121.10 NI.23600.077
Vendor Type Description Part No.
182 Appendix B
Appendix C 183
Online Support Information
This section describes online technical support services available to help you repair your Acer Systems.
If you are a distributor, dealer, ASP or TPM, please refer your technical queries to your local Acer branch
office. Acer Branch Offices and Regional Business Units may access our website. However some information
sources will require a user i.d. and password. These can be obtained directly from Acer CSD Taiwan.
Acer's Website offers you convenient and valuable support resources whenever you need them.
In the Technical Information section you can download information on all of Acer's Notebook, Desktop and
Server models including:
• Service guides for all models
• Bios updates
• Software utilities
• Spare parts lists
• TABs (Technical Announcement Bulletin)
For these purposes, we have included an Acrobat File to facilitate the problem-free downloading of our
technical material.
Also contained on this website are:
• Detailed information on Acer's International Traveler's Warranty (ITW)
• Returned material authorization procedures
• An overview of all the support services we offer, accompanied by a list of telephone, fax and email
contacts for all your technical queries.
We are always looking for ways to optimize and improve our services, so if you have any suggestions or
comments, please do not hesitate to communicate these to us.
Appendix C
184 Appendix C
185
A
AFLASH Utility 34
Antennas
Removing 97, 99
Replacing 101
B
Battery
Replacing 141
Battery Pack
Removing 47
BIOS
ROM type 15
vendor 15
BIOS Utility 25–34
Advanced 29
Boot 32
Exit 33
Navigating 25
Onboard Device Configuration 30
Power 32
Save and Exit 33
Security 29
System Security 33
Board Layout
Top View 159
C
Camera Module
Removing 90, 91
Replacing 104, 106, 108, 109, 111
Common Problems 144
computer
on indicator 10
CPU
Removing 83
Replacing 115
D
DIMM Modules
Replacing 136
Display 5
display
hotkeys 14
E
EasyTouch Failure 154
External Module Disassembly
Flowchart 46
F
Features 1
Flash Utility 34
FPC Cable
Removing 95
FRU (Field Replaceable Unit) List 165
H
Hard Disk Drive
Removing 55
Replacing 134
HDTV Switch Failure 155
Hot Keys 12
I
Indicators 10
Intermittent Problems 156
Internal Microphone Failure 149
Internal Speaker Failure 148
J
Jumper and Connector Locations 159
K
Keyboard
Removing 58
Replacing 133
Keyboard Failure 147
L
LCD Bezel
Replacing 110
LCD Brackets
Removing 95
Replacing 103
LCD Cable
Index
186
Replacing 103
LCD Failure 147
LCD Module Disassembly
Flowchart 84
LCD Module Reassembly Procedure 101
LCD Panel
Removing 93
Replacing 103
Left Speaker Module
Removing 64
Replacing 128
M
Main Unit Disassembly
Flowchart 57
Mainboard
Removing 71, 73, 75, 77
Replacing 118
media access
on indicator 10
Memory
Replacing 136
Memory Check 144
Model Definition 176
N
No Display Issue 145
O
ODD Failure 151
Online Support Information 191
Optical Disk Drive
Replacing 137, 138
Optical Drive Module
Removing 49
P
Panel 6
Bottom 9
PC Card 10
Power On Failure 144
R
Replacing 126, 128
Right Speaker Module
Removing 65
Replacing 126
S
SD Dummy Card
Removing 48
Replacing 140
Speakers 126, 128
Removing 64, 65
System
Block Diagram 5
T
Test Compatible Components 179
Thermal Module
Removing 81
Replacing 116
Thermal Unit Failure 154
TouchPad
Removing 69
TouchPad Bracket
Removing 69
Replacing 124, 127
TouchPad Failure 148
Troubleshooting
Built-in KB Failure 147
EasyTouch Buttons 154
HDTV Switch 155
Internal Microphone 149
Internal Speakers 148
LCD Failure 147
No Display 145
ODD 151
Other Failures 155
Power On 144
Thermal Unit 154
TouchPad 148
WLAN 154
U
Undetermined Problems 156
Upper Cover
Removing 60
Replacing 129
utility
BIOS 25–34
187
W
Windows 2000 Environment Test 180
Wireless Function Failure 154
WLAN Module
Removing 53
Replacing 135
188

Navigation menu
