AcoustMax MNSTRMBLK Monster Roam User Manual

ACOUSTMAX INTERNATIONAL CO., LTD Monster Roam Users Manual

Users Manual

MODEL: ROAM
USER
MANUAL
MUSIC WITHOUT LIMITS
1-800-976-0677 • support@mymonsteraudio.com • MyMonsterAudio.com
Monster and the Monster logo are registered trademarks of Monster Inc., and it’s subsidiaries in the U.S. and other countries, used under license.
The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. Other trademarks and trade names are those of their respective owners.
The N-Mark is a trademark or registered trademark of NFC Forum, Inc. in the United States and in other countries.
PRODUCT CONTROLS 1
POWER & BATTERY: 2
• Power/Charging
• Battery Level Indicator
AUDIO
• Bluetooth Pairing 3
• NFC Pairing (Android Devices) 4
• AM/FM Radio 5
BACK PANEL:
• AUX-IN (3.5 mm)
• USB Power Banks
6
AQUATIC
• IP67 Dustproof & Waterproof
• Aquatic/Self-Righting Design
7
TABLE OF CONTENTSPACKAGE CONTENTS
THANK YOU FOR
CHOOSING MONSTER
ROAM
Bluetooth Speaker
Micro USB AC Charger
(Cable Length: 54”)
User Manual
& Quick Strat Guide
(Incl. Warranty Statement)
Included with your ROAM purchase:
Congratulations on your ROAM Bluetooth® Speaker.
Please take your time to explore all of the features
and utilities we have built into this product.
We put all of our products through rigorous testing
and quality control. We take great pride in presenting
this product to you now. For your peace of mind,
we oer a one-year limited warranty against
manufacturing defects and workmanship. Please
refer to the warranty section of the user manual for
more details.
For more information on all of our products,
please visit: MyMonsterAudio.com.
FOLLOW US:
@MyMonsterAudio
@MyMonsterAudio
/MyMonsterAudio
TROUBLESHOOTING 8
SPECIFICATIONS 9
IMPORTANT SAFETY INSTRUCTIONS 10
LIMITED WARRANTY 11
FCC WARNING STATEMENT 12
21
Control Panel
Back Panel
Control Panel Back Panel
1. POWER Indicator
2. SOURCE Button
3. BLUETOOTH Indicator
4. BLUETOOTH Button
5. BLUETOOTH LED Icon
6. SSD Display
7. AUX LED Icon
8. FM LED Icon
9. AM LED Icon
10. VOLUME DOWN Button
11. PLAY/PAUSE Button
12. POWER Button
13. VOLUME DOWN Button
14. AM Button
15. FM Button
16. ARROW Buttons
17. NUMBER Buttons
16. BATTERY Button
17. AUX IN
18. USB OUT
19. DC IN
AUX IN USB OUT
DC IN
1
14 15 16 17 18
3 11
17 18
19
10 13122 4 5 7 8 9
PRODUCT CONTROLS
6
IMPORTANT: Before first use, charge for ~6 hours.
1 Connect USB cable into
speakers DC IN port.
2 Connect USB cable into USB
AC Adapter.
3 Connect USB AC Adapter to
an external power source.
POWER & BATTERY
Full Charge – achieved in 7 hours while powered OFF
– achieved in 15 hours while powered ON.
Power/Charging
(Press)
Battery Level Indicator
• Press BATTERY button
at any time to check the
speaker’s level of charge.
The LED display will give a three
digit range (000-100).
The indicator is only active while the speaker is on.
(Press)
(Hold)
• Push POWER Button to
turn ON.
The speaker will make visual LED
conformation. Power indicator
will light up for ~ 4 seconds.
• Hold POWER Button ~2
seconds to turn OFF.
DC IN
43
(Press)
3 ft.
“Bluetooth”
“Pairing”
Bluetooth Pairing
“Connected”
Monster RR4
1 Place your mobile device
within 3 feet of the speaker.
Make sure Bluetooth is enabled
on your mobile device.
2 Press the BLUETOOTH
button to set the speaker to
Bluetooth mode.
~30 feet max connection range after paired.
Moving devices outside this range may cause
disruption or signal loss.
The speaker will automatically enter pairing mode.
The speaker will make audible
and visual LED conformation.
Bluetooth Indicator light will
flash in pairing mode.
3 Select “Monster RR4” on
your mobile device to pair
with the speaker.
The speaker will make audible
confirmation and the Bluetooth
Indicator light will stop flashing.
If the Bluetooth Indicator light is NOT flashing, press and hold the
BLUETOOTH button to manually enter pairing mode.
(Press)
“Bluetooth”
“Pairing”
NFC Pairing (Android Devices)
“Connected”
1 Enable NFC on the music
device you wish to pair.
2 Press the BLUETOOTH
button to set the speaker to
Bluetooth mode.
~30 feet max connection range after paired.
Moving devices outside this range may cause
disruption or signal loss.
The speaker will automatically enter pairing mode.
The speaker will make audible
and visual LED conformation.
Bluetooth Indicator light will
flash in pairing mode.
If the Bluetooth Indicator light is NOT flashing, press and hold the
BLUETOOTH button to manually enter pairing mode.
3 Place your music device
directly on the speaker’s
NFC logo until paired.
The speaker will make audible
confirmation and the Bluetooth
Indicator light will stop flashing
AUDIO
6
“AUX IN”
AUX-IN (3.5mm)
• Connect a music device
to the AUX IN port with a
standard 3.5 mm jack. The
speaker will automatically
change to AUX mode.
Speaker will make audible and
visual LED display confirmation.
AUX IN
(Press)
or
(Press or Hold)
“AM Radio” “FM Radio”
or
AM/FM Radio
1 Press the FM or AM button to
select RADIO source.
Speaker will make audible and
visual LED display confirmations.
2 Press the ARROW buttons
to change radio frequency.
Press and hold the ARROW
buttons to scan for a station. USB Power Bank
• Connect devices to USB
OUT to charge a devices
from the speaker’s
internal battery.
USB OUT is for charging ONLY
– they will not make audio connections.
USB OUT
BACK PANEL
(Hold)
/
• Save the current radio
station by pressing and
holding one of the NUMBER
BUTTONS (1-6).
The LED display will confirm the
saves station (P-1, P-2, etc.)
Press the NUMBER KEY
while in radio mode to
go to the corresponding
SAVED station.
(Press)
87
Speaker is not
powering on
• Verify that the Power switch is fully turned to the ON position (see pg. 2).
• Ensure the speaker is not in STANDBY MODE (see pg. 6).
• Make sure AC POWER cord is fully inserted into the unit (see pg. 2).
Buttons are not
responding
• Reset the speaker by turning the power OFF, and then back ON (see pg. 2).
• Unplug the AC POWER cord, then plug it back in (see pg. 2).
No music is playing
• Make sure the speaker is set to the same source as your audio device. If you are playing
audio via AUX cable, make sure the speaker is in AUX IN mode, etc. (See pg. 3-5).
• Make sure the VOLUME is high enough on your audio device as well as the speaker.
Bluetooth audio
quality is poor
• Move your music device closer to the speaker.
• Remove objects that may be interfering with the wireless connection.
Bluetooth/NFC device
is not pairing
• Verify that the speaker and your device have BLUETOOTH mode active (see pg. 3).
• Make sure the speaker and/or your device is not already paired with another device.
• Check that the speaker is in pairing mode (see pg. 3).
• Turn the speaker OFF, and then back ON. Press and hold the BLUETOOTH button to
manually enter pairing mode (see pg. 3).
Contact our support
team for additional
services
Call: 1-800-976-0677
Email: support@mymonsteraudio.com
Hours of Operation:
Monday - Friday: 7:00 am - 5:00 pm (PST) Saturday - Sunday: CLOSED
TROUBLESHOOTING
IP67 Dustproof & Waterproof
Aquatic/Self-Righting Design
AQUATIC
• The speaker is Ingress
Protection (IP) rated for full
protection against dust and
protection against water to a
maximum depth of 1 meter
(~3 feet) for 30 minutes.
• The ROAM has been
designed to float to the
surface when immersed in
a body of water. This means
you can safely use the
speaker in a swimming pool,
lake, or other similar areas.
• When floating in water,
the speaker’s built-in
counterbalance will force
it to face upwards. This
allows the button interface
to be accessible and
prevents the audio from
being mued underwater.
For more information on IP ratings, visit nema.org.
The input/output port hole must be sealed
before immersing the speaker in water.
Make sure the twist cap is firmly in place and in the
“closed” position. Leaving the cap detached or in the
“open” position may allow water to seep into the input/
output ports and permanently damage the speaker.
IP67
109
General
Bluetooth Version BT2.1+EDR
Power Input DC 5V2A
Speaker Drivers 10W (2x 3.5”driver, 1x treble)
THD + Noise <10%
Cabinet Material Plastic
Battery Capacity 2200mA (14 hours at max volume)
USB Output 5V/1A
Dimensions (W x H x D) 15.7” x 10.7” x 6.7”
Weight XX lbs
IP Rating IP67
Operating Temperature
Operating Temperature Range 32F° - 104F°
Operating Humidity Range 40~90% RH
Storage Temperature Range -13F° to 158F°
SPECIFICATIONS IMPORTANT SAFETY INSTRUCTIONS
1) Read these instructions – All the safety and operating instructions
should be read before this product is operated.
2) Keep these instructions – The safety and operating instructions
should be retained for future reference.
3) Heed all warnings - All warnings on the appliance and in the
operating instructions should be adhered to.
4) Follow all instructions – All operating and use instructions should
be followed.
5) This apparatus can be used in wet location conditions after
disconnected the AC Mains supply and closing the water
proof cap for the AC inlet. It must not be used in wet location
conditions when charging. Do not use this apparatus near water-
The appliance should not be used near water or moisture – for
example, in wet basement or near a swimming pool.
6) Clean only with dry cloth.
7) Do not block any ventilation openings, install in accordance with
the manufacturer’s instructions.
8) Do not install near any heat sources such as radiations, heat
registers, stoves, or other apparatus (including amplifiers) that
produce heat.
9) Do not defeat the safety purpose of the polarized or grounding
plug. A polarized plug has two blades with one wider than the
other. A grounding plug has two blades and a third grounding
prong. The wide blade or the third prong is provided for your
safety. If the provided plug does not fit into your outlet, consult an
electrician for replacement of the obsolete outlet.
10) Protected the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the point
where they exit from the apparatus.
11) Only use attachments/accessories specified by the manufacturer.
12) Use only with the cart, stand, tripod, bracket,
or table specified by the manufacturer, or sold
with the apparatus. When a cart or rack is used,
use caution when moving the cart/apparatus
combination to avoid injury from tip-over.
13) Unplug this apparatus during lighting storms or when unused for
long periods of time.
14) Refer all servicing to qualified service personnel. Servicing is
required when the apparatus has been damaged in any way, such
as power-supply cord or plug is damaged, liquid has been spilled
or objects have fallen into the apparatus, the apparatus has been
exposed to rain or moisture, does not operate normally, or has
been dropped.
15) Mains plug is used as the disconnect device, the disconnect
device shall remain readily operable.
16) Do not install this equipment in a confined or building-in space
such as a book case or similar unit, and remain a well ventilation
conditions at open site. The ventilation should not be impeded by
covering the ventilation openings with items, such as newspapers,
table-cloth, curtains, etc.
17) No naked flame sources, such as lighted candles, should be
placed on the apparatus.
18) Attention should be drawn to the environmental aspects of
battery disposal.
19) The use of apparatus in moderate climate.
20) The apparatus shall not be exposed to dripping or splashing and
that no objects filled with liquids, such as vases, shall be placed
on the apparatus.
WARNING: To reduce the risk of fire or electric shock, do not expose
this apparatus to rain or moisture.
WARNING: The batteries shall not be exposed to excessive heat such
as sunshine, fire or the like.
CAUTION: Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type.
Protective earthing terminal. The apparatus should be
connected to a mains socket outlet with a protective
earthing connection.
Protective earthing terminal. The apparatus should be
connected to a mains socket outlet with protective earthing
connection.
1211
Model: ROAM
LIMITED WARRANTY
This Monster-branded product, marketed as new, in the original carton to the original
purchaser (“Product”), is warranted by Russell Distribution Company, LLC against
manufacturing defects in materials and workmanship for a limited warranty period
of Ninety (90) Days for Labor and One (1) year for Parts. This Limited Warranty is
conditioned upon proper use of Product by you, the Purchaser.
This Limited Warranty does not apply to store display products and product sold as
a ‘marked down” special, in as is condition, ‘close outs”, “liquidation and clearance
sales”, “open box”, products missing accessories, or no fault found.
Proof of purchase in the form of a Bill of Sale, Receipt or Receipted Invoice is
evidence the Product is within the limited warranty period. The Bill of Sale, Receipt
or Receipted Invoice must be presented as a pre-condition to obtaining the limited
warranty service.
This limited warranty begins on the original date of purchase and is valid only on
Products purchased through authorized dealers and used In the United States, and
Puerto Rico, by the original Purchaser. To receive warranty service, the Purchaser
must first contact us for problem determination and service procedures. The original
dated bill of sale, receipt or receipted invoice must be presented upon request as
proof of purchase.
We will repair your product or if repairs cannot be made, we will replace it at no
charge with the same or similar product. If the Product is defective as specified
in this limited warranty during the limited warranty period, we may use new or
remanufactured parts to repair the Product. All replaced parts and products become
our property and must be returned to us. Replacement parts and products assume
the remaining original limited warranty, or ninety (90) days, whichever is longer.
Product freight must be prepaid by you, the original Purchaser and shipped in either
its original packaging or packaging aording an equal degree of protection. We will
not be responsible for or obligated to replace damaged Products.
If the Product is received damaged, it is your responsibility as the consumer to file a
claim against the carrier. We will only store the damaged Product for 30 days and
reserve the right, in our sole discretion, to dispose of the damaged Product or ship it
back to you at your expense after 30 days.
This limited warranty covers manufacturing defects in materials and workmanship
encountered in normal, and except to the extent otherwise expressly provided for
in this statement noncommercial use of this Product, and shall not apply to the
following, including, but not limited to: Damage which occurs in shipment; delivery
and installation; applications and uses for which this Product was not intended;
altered Product or serial numbers; cosmetic damage or exterior finish: accidents,
abuse, neglect, fire, water, lightning or other acts of nature; use of products,
equipment, systems,utilities, services, hardware, supplies, accessories, applications,
installations, repairs, external wiring or connectors not supplied or authorized by us
or the manufacturer, which damage this Product result in service problems: incorrect
electrical line voltage, fluctuations and surges: customer adjustments and failure to
follow operating instructions, cleaning, maintenance and environmental instructions
that are covered and prescribed in the instruction book; reception problems and
distortion related to noise, echo, interference or other signal transmission and
delivery problems; burned-in images. Uninterrupted or error-free operation of the
Product is not warranted.
THERE ARE NO EXPRESS OR IMPLIED WARRANTIES OTHER THAN THOSE
LISTED AND DESCRIBED ABOVE, AND NO WARRANTIES WHETHER EXPRESS
OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, ANY IMPLIED WARRANTIES
OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, SHALL
APPLY AFTER THE EXPRESS WARRANTY PERIODS STATED ABOVE, AND NO
OTHER EXPRESS WARRANTY OR GUARANTY GIVEN BY ANY PERSON, FIRM OR
CORPORATION WITH RESPECT TO THIS PRODUCT SHALL BE BINDING ON US.
REPAIR OR REPLACEMENT AS PROVIDED UNDER THIS LIMITED WARRANTY
IS YOUR EXCLUSIVE REMEDY AS THE CONSUMER. WE SHALL NOT BE LIABLE
FOR ANY INCIDENTAL, OR CONSEQUENTIAL DAMAGES FOR BREACH OF
ANY EXPRESS OR IMPLIED WARRANTY ON THIS PRODUCT; EXCEPT TO
THE EXTENT PROHIBITED BY APPLICABLE LAW, ANY IMPLIED WARRANTY
OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE ON THIS
PRODUCT IS LIMITED FOR THE DURATION OF THIS LIMITED WARRANTY THIS
LIMITED WARRANTY SHALL NOT EXTEND TO ANYONE OTHER THAN THE
ORIGINAL PURCHASER OF THIS PRODUCT, IS NONTRANSFERABLE AND STATES
YOUR EXCLUSIVE REMEDY.
Some states do not allow limitations on how long an implied warranty lasts, or
the exclusion or limitation of incidental or consequential damages, so the above
limitations or exclusions may not apply to you. This limited warranty gives you
specific legal rights, and you may also have other rights, which vary from state to
state. Any provision contained herein which is found contrary to state or local laws
shall be deemed null and void and the remaining provisions shall continue in full
force and eect.
To obtain warranty service, please contact technical support with questions
Phone: 1-800-976-0677 • Email: support@mymonsteraudio.com
DO NOT return this product to the store. Visit: MyMonsterAudio.com
FCC WARNING STATEMENT
Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority
to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment o and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment receiver.
• Connect the equipment into an outlet on a circuit dierent
from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
FCC Radiation Exposure Statement
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.
Prevent fire and shock hazards. Do not use extension
cords or outlets that expose plug blades. Do not
expose cables and plugs to rain or moisture.
Do not attempt to perform any servicing that is not
included in the operating instructions. Do not attempt
to replace the battery, as incorrect installation can
cause fire or explosion. For service, contact qualified
service personnel.
Do not remove cover or back of product. There
are no user-serviceable parts inside. Attempting
to modify controls or performance beyond
manufacturer specifications may result in
hazardous exposure to radiation.
A lightning flash and arrowhead
within an equilateral triangle
is intended to alert the user
to the presence of insulated
“dangerous voltage” within
the product’s enclosure that
may be of sucient magnitude
to constitute a risk of electric
shock to persons.
An exclamation point within an
equilateral triangle is intended
to alart the user to the presence
of important operation and
maintenance (servicing)
instructions in the literature
accompanying the appliance.
WARNING: TO REDUCE
THE RISK OF ELECTRIC
SHOCK DO NOT REMOVE
COVER (OR BACK), NO
USER SERVICEABLE PARTS
INSIDE REFER SERVICING
TO QUALIFIED SERVICE
PERSONNEL.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
WARNING

Navigation menu
