There are two formats, one is for a quarter-folded manual, another just a single page, full size. The final user manual,
whether a folded sheet, single full-page, or stitched booklet should have the same “cover” layout. The supplier, however,
will be required to obtain the fonts, Myriad Pro and Pirulen.
Supplier should probably have the fonts for future mockups.
The text in the files should already call for the correct fonts:
The fonts can be purchased from this website:
http://www.myfonts.com/search/myriad+pro/fonts/
http://www.myfonts.com/search/pirulen/fonts/.
Product Name - Pirulen Regular
Vendor Stock Number - Myriad Pro Regular
“Product Guide” - Pirulen Regular
• The volume of speaker is too low, adjust the volume to a n appropriate level.
Whenyoufindthefloaterwithlowvolume
ornovolumeinthewater, it might be
because the floater has too much water
on top of the speaker driver. This prevents
the driver from producing sound.
Reversethefloater, drainout
thewater. Afterthat, thefloaterwill
workproperlyagain.
• The speaker may be too far away from the Bluetooth device,move closer to it.
G. TECHNICAL SPECIFICATIONS
Carrier Frequency: Bluetooth 4.0
Power Requirements: DC 9V 1.1A
Frequency Response: 30 Hz -18 KHz
Distortion: <0.5%
S/N Ratio: 65dB (typical)
Operation Distance: Up to 10 meters / 33 feet (open area)
Output Power: 5 W (Max)
The Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc.
All other trademarks and trade names are those of their respective owners.
using your device.
Please read the following safety warnings and precautions before
CAUTION: Your speaker will operate at its
best and loudest with no water resting on top
of the speaker. Periodically draining the speaker
by inverting it will ensure that not toomuch
waterremainsstandingontopofthe speaker
driver. Turn the speaker over and lightly
shake it to let the water drain out quickly for
best audio performance and when storing the
speaker between uses.
Water Outlet
H. TROUBLE SHOOTING
NO SOUND
The speaker's battery charge is too low. Replace with new batteries.
• Ensure the speaker is ON.
• Ensure Bluetooth device is ON.
• Unable to connect with Bluetooth device, restart the pairin g process.
WARNING: Changes or modifications to this unit not expressly
approved by the party responsible for compliance could void the user's
authority to operate the equipment.
Note: Clean the speaker with soft, lint - free, dry cloth. Never use
detergents or abrasive cleaners to clean.
THE FCC WANTS YOU TO KNOW
Warning! This device complies with Part 15 of the FCC rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including
interference that might cause undesired operation.
Changes or modifications to this unit not expressly approved by the
party responsible for compliance could void the user's authority to
operate the equipment.
SAFETY WARNINGS
CAUTION
• Read these instructions.
• Keep these instructions for future reference.
• Heed all warnings.
• Follow all instructions.
• Clean only with a dry cloth.
• Only use attachments/accessories specified by the manufacturer.
• Refer all servicing to qualified personnel.
“PAIR”
C. PACKAGING
1 X Bluetooth speaker
1 X User manual
1 X Power adapter
A. INTRODUCTION
This Bluetooth wireless speaker system applies the latest BT 4.0 wireless technology platform that
enables you to enjoy music or video anywhere you want.
B. FEATURES
1. Bluetooth 4.0 Platform
2. Operating distance up to 10 meters / 33 feet (open area)
3. IPX 6 Water-proof feature
4. Floating feature
5. Blue LED mood light
E. PAIRING
6. Enter “ 0000 ”ifpassword is required.
8. Listen to your music.
Blue LED will be solid.7. WhenBluetoothconnectionismade,the
5. Select“ATLANTIS”inthelistshown on the
Bluetooth device.
4. If noauto pairing connection is made, press the Pair button .
andhold for 5 seconds until the Blue LED flashes quickly.
3. TheBluetoothspeaker will automatically search your Bluetooth
device and pair it up.
1. Press the power button for 3 seconds to turn the speaker on,
The Blue LED light will flash quickly.
2. Enable any Bluetooth device such as cell phones, tablets or
other Bluetooth media, and make sure it is in searching mode.
D. COMPONENT IDENTIFICATION
1. Power On/Off Control
2. Power LED Indicator
3. Pair/Pause
4. Mood Light
5. Volume +, Nextsong
6. Volume -, Previous song
7. Charging jack with rubber stopper
7
2
3
4
1
6
5 8
8. Power adapter
•
F. CHARGING
Charge the speaker using the power adapter provided.
Using the speaker in water without the rubber stopper at the DC jack in place will
causedemagetothespeaker.
Pressing and holding the pair key for 12 seconds will clear the memory of any
Bluetooth devices previously paired with the speaker.
FCC ID:VHC-AAI-BS4160-00
TM
PRODUCT GUIDE
There is an indication sound when the battery is low.
Please drain the water from the speaker before charging.
Model: BWA15AV106
aTLANTIS
